Epson C11CC25002 Product Data Sheet

Financial Services and SIDM Range

KEEPING
BUSINESS
MOVING

ENGINEERED
FOR BUSINESS

FINANCIAL SERVICES
PRODUCT RANGE

Epson is the world’s largest manufacturer of printers for banks and

post ofces with a product range that offers the ultimate in high speed,
low cost, reliable and durable printing across all stationery types.
Ideal for back ofce, cheque processing, and multi-part stationery,
for which there is simply no alternative other than impact printing.

New technologies like inkjet in the heavy duty GP Series
now offer additional values at extremely low cost.

EPSON 9-PIN DOT MATRIX PRINTERS

Ideal for commercial, industrial and logistic applications, Epson’s 9-pin dot matrix range
offers excellent print quality for a competitive price. Combining high precision alignment
and sophisticated paper handling, this comprehensive range of narrow and wide carriage
printers can tackle even heavy duty print jobs.

EPSON 24-PIN DOT MATRIX PRINTERS

Offering all the features available across the 9-pin range, but with the advantage of scalable
fonts and letter quality printing. Epson 24-pin printers are ideal for front desk applications
in the retail and service industries, as well as invoice and order printing. The range also
includes atbed printers for use with a wider (and thicker) range of materials including
receipts and labels.

EPSON BUSINESS INKJET PRINTERS

Epson colour printing highlights important information and gives clarity to forms.
The high-resolution printouts of this new generation of tractor feed printers do not fade
and open new horizons and additional value in business printing. A low cost per page is
ensured by the high capacity single ink cartridges and the use of standard endless paper
or even labels. In addition, these new high speed printers reduce printing noise and energy
consumption by using the latest Epson Mirco Piezo

The easy-to-use front facing controls offer exible installation under the counter, on the
desktop or on a shelf.

®

inkjet technology.

1

Epson GP-C831/GP-M831

02

Printer model Printhead/

Epson GP-C831 5760x1440dpi High

Epson GP-M831 High

Epson LX-350 9-pin Light

Epson LX-1170II Medium

Epson FX-890/890A High

Epson FX-2190/2190N High

Epson DFX-9000/9000N Heavy

Epson LQ-50 24-pin Light

Epson LQ-350 Light

Epson LQ-590 Medium

Epson LQ-630 Light

Epson LQ-680Pro Medium

Epson LQ-690 Medium

Epson LQ-2090 Medium

Epson LQ-2190/2190N High

Epson DLQ-3500 Heavy

Epson PLQ-22/M Medium

Epson PLQ-22CS/CSM Medium

Epson PLQ-20/M Medium

Epson PLQ-20D/DM Medium

Epson TM-S9000MJ 180x180 High

Epson TM-S2000MJ – High

Epson TM-S1000 – Medium

Epson TM-J7000 Series 180x180 Medium

Epson TM-L90 203x203 Medium

Epson TM-T88V 180x180 High

Key

Low Medium High

Resolution

Duty Point

of sale

Field of application

Instore Accounting Listing Pass-book Cheque

handling

Brochure

page

6

6

8

8

9

9

10

10

11

11

12

12

13

13

14

14

16

16

17

17

18

19

19

20

21

21

DOT MATRIX PRINTER ADVANTAGES

• Excellent TCO per page ratio (as low as €0.20/100 pages)

• Multi-part capability (up to 1 original + 9 copies)

• Long lasting print-outs (up to 100 years)

• Can work under harsh conditions (hot, cold, dry, humid
or dusty environments)

• Low maintenance

• Handles continuous paper

• Can print on a wide range of media and of varying thickness
(paper, multi-part forms, envelopes, card etc)

• Multiple paper paths to choose from to suit your
working environment

• Handles cut sheet and continuous paper simultaneously

COMPATIBILITY – ESC/P2

ESC/P (Epson Standard Code for Printers) is the defacto
standard dot matrix printer control language, worldwide.
Adopted in the vast majority of popular software packages,
ESC/P enables you to plug straight in – and print. The versatility
and quality of Epson impact printing is further extended by
ESC/P2 which enables Epson 24-pin printers to achieve
scalable fonts and high-resolution graphics.

Fully compatible with existing software, ESC/P2 is designed
for use with non Windows
achieve font manipulation without the need for costly on-board
processors. If you are working within the Windows environment
you will be able to achieve your printer’s maximum speed by
using printer resident fonts.

®

operating systems, enabling you to

03

EPSON PRINTER SELECTOR

speed is more important than print quality – 9-pin

≤ A4 ≤ A3/A4 landscape

PAPER SIZE

PRINT VOLUMEPRINT VOLUME

top

front

bottom

Speed

Print volumes/durability

Footprint

Quieter printing

Flatbed printer atbed atbed atbed atbed atbed atbed

Platen gap adjustment manual manual manual manual automatic* manual manual manual automatic* N/A manual manual manual

Multi copy capability 1+4 parts 1+5 parts 1+4 parts 1+5 parts 1+9 parts 1+2 parts 1+3 parts 1+4 parts 1+6 parts N/A 1+4 parts 1+4 parts 1+5 parts 1+5 parts 1+6 parts 1+7 parts

Paper feeds/continuous rear rear rear rear rear rear rear rear rear rear rear rear rear rear rear

rear

Low Low HighHigh

Epson

LX-350

bottom bottom bottom bottom bottom (front) bottom bottom bottom bottom

Epson

FX-890

Epson

LX-1170II

Epson

FX-2190

Epson

DFX-9000

Epson
LQ-50

front front front front front

Cut sheet top top top top top front front N/A top top front front front front

front

(optional)

Print width

Colour printing optional optional optional standard

= low = high

* DFX-9000, LQ-680Pro, PLQ-22 and DLQ-3500 have automatic platen gap adjustment to ensure optimum settings when changing between different media types

with the minimum of user intervention. Automatic platen gap adjustment also allows printing on forms with varying thickness, such as multipart courier forms that
also include a label.

80 columns,

8in

80 columns,

8in

136 columns,

13.6in

front

(optional)

136 columns,

13.6in

136 columns,

13.6in

50 columns,

5in

04

PRINT QUALITY

24-pin and inkjet – print quality is as important as speed

≤ A4

≤ A3/A4 landscape

PAPER SIZE

Low

No

PRINT VOLUME FLATBED

FLATBED

High

A4 landscape

No Yes A3

Epson

LQ-350

Epson

LQ-630

Epson

PLQ-20/22

Epson

GP-Series

Epson

LQ-590

Epson

LQ-2090

Epson

LQ-2190

Epson

LQ-680Pro

Epson

LQ-690

DLQ-3500

Yes

Epson

80 columns,

8in

80 columns,

8in

94 columns,

8in

95 columns,

9.5in

front front rear

80 columns,

8in

136 columns,

13.6in

136 columns,

13.6in

automatic*

(LQ-680Pro)

106 columns,

10.6in

manual automatic*

106 columns,

10.6in

136 columns,

13.6in

05

Epson GP-C831/M831 NEW

Newly developed by Epson, the GP Series heralds a new age in industrial-strength
inkjet printers. With a tractor feeder and top speed of 19.7ppm in draft mode, the GP
Series can handle large volume single ply printing in fast-paced work environments
where time is of the essence.

Epson pigment ink means the GP Series delivers outstanding print results as well
as excellent resistance to water, chemicals, fading and smudges. With a maximum
resolution of 5760x1440dpi it is possible to print clear, sharp barcodes and photos.
The high-capacity, affordable ink cartridges allow longer print runs before needing
to be replaced and the revolutionary printhead protection system reduces dust and
dirt from clogging the nozzles. Durability like this makes the GP Series ideal for a
wide range of environments including hospitals, laboratories, supermarkets, ofces
and warehouses.

Unlike conventional dot matrix printers, the GP Series keeps the peace thanks
to quiet inkjet printing. Reduced power consumption is a major advantage for
energy-conscious ofces. Built for demanding work environments, the GP Series
can withstand weights of up to 20kg on top and have large side grips making it easier
tomove the printer. If you are looking for an alternative to dot matrix technology,
the GP Series offers fast, high-quality printing combined into one.

The GP-C831 is the colour version and the GP-M831 is the mono version of the series.

INKJET PRINTER

Key features

• Tractor feed enables high-volume printing

• High-quality prints 5760x1440dpi

• Can print on a wide range of media

including normal and glossy paper,
as well as labels

• Unique head protection system protects

print nozzles from clogging

• Fast print speeds of up to 19.7ppm

• Micro Piezo inkjet technology

• Ink cartridge ordering codes:
Cyan: C13S020564
Magenta: C13S020565
Yellow: C13S020566
Black: C13S020563

• USB, Parallel and Ethernet (LAN

100/10BASE) interfaces as standard

High capacity inkset for colour printing. 2 black cartridges for low cost

per print.

06

GP-M831 for affordable black and white printing.

The printer panel clearly displays
the printer status.

The unique tractor feed ensures
perfect print results on various
paper and label media.

07

Epson LX-350 NEW

Due to its compact dimensions, the Epson LX-350 is not only the ideal 9-pin printer for
front and back ofce applications where space is limited, it’s also a low cost solution
for measurement and control systems. With auto switching USB, serial and parallel
interfaces, the LX-350 provides exible stand-alone connectivity.

9-PIN DOT MATRIX PRINTER

Key features

• Compact 9-pin narrow carriage printer

• Up to 357 characters per second (12cpi)

• Robust printer with an MTBF

of 10,000 hours

• Prints up to 5-part forms
(1 original + 4 copies)

• Versatile top and rear paper paths

• 8 built-in barcode fonts

• USB, parallel and serial interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of
4 million characters

Options

• Roll paper holder

For options and consumables see page 25-27

Epson LX-1170II

The Epson LX-1170II is the ideal 9-pin printer for light workloads. The copy capability
of one original plus four copies makes it suitable for a variety of environments including
data reporting (eg telephone statistics and call logs, helpdesk and computer system
reporting), listings, shipping documents and measurement and control systems.

9-PIN DOT MATRIX PRINTER

Key features

• 9-pin wide carriage printer

• Up to 337 characters per second (12cpi)

• Robust printer with an MTBF of

10,000 hours

• Prints up to 5 -part forms
(1 original + 4 copies)

• Versatile top, bottom and rear paper paths

• 8 built-in barcode fonts

• USB, parallel and serial interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of
3 million characters

Options

• 50 sheet cut sheet feeder

• Roll paper holder

• Push/pull tractor unit

For options and consumables see page 25-27

08

Standard Optional

Continuous

Cut sheet

Epson FX-890/890A

This narrow carriage printer combines high speed with the highest reliability.
A mean volume between failure of 52 million lines makes it ideal for medium and
large print volumes. Paper can be fed from the front, top, rear or bottom and an
optional push/pull tractor can be added to use a second continuous form – perfect
for warehouses, wholesalers, freight forwarders and nance departments. For harsher
printing environments the FX-890A has an additional sturdy, shock absorbing design.

9-PIN DOT MATRIX PRINTER

Key features

• Compact 9-pin narrow carriage printer

• Up to 680 characters per second (12cpi)

• Robust printer with an MTBF of

20,000 hours

• Prints up to 6-part forms
(1 original + 5 copies)

• Versatile top, bottom and rear paper paths

• USB, parallel and serial interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of

7.5 million characters

FX-890A only:

• Locked front cover for improved security

• Reinforced acrylic tear-off bar

• Shock absorbing cover and sheet feeder

Options

• 150 or 50 sheet cut sheet feeder

• Front sheet and paper guide

• Additional push/pull tractor unit

• Roll paper holder

• Wired network interface, serial interface

For options and consumables see page 25-27

Epson FX-2190/2190N

This wide carriage printer combines high speed printing with outstanding reliability.
A mean volume between failure of 52 million lines makes this printer suitable for
medium and large print volumes. The paper can be fed from the front, top, rear or
bottom and an optional additional push/pull tractor unit can store a second continuous
form, which is ideal for commercial and industrial environments. Also available as
network version FX-2190N.

9-PIN DOT MATRIX PRINTER

Key features

• 9-pin wide carriage printer

• Up to 680 characters per second (12cpi),

one of the fastest in its class

• Robust printer with an MTBF of
20,000 hours

• Prints up to 6 -part forms
(1 original + 5 copies)

• Versatile front , top, bottom and rear

paper paths

• USB and serial interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of
12 million characters

Options

• 150 or 50 sheet cut sheet feeder

• Front sheet guide

• Front paper guide

• Additional push/pull tractor unit

• Roll paper holder

• Wired network interfaces, serial interface

For options and consumables see page 25-27

09

Epson DFX-9000/9000N

The Epson DFX-9000 is a high print volume printer providing an unprec edented level
of speed and reliability for the most demanding business. Its advanced paper handling
accommodates a variety of paper types while the standard front and rear push tractors
can be switched easily between different types of continuous paper. An optional
perforation cutter provides paper nishing capabilities. Also available as network
version DFX-9000N.

9-PIN DOT MATRIX PRINTER

Key features

• 4x 9-pin wide carriage printer

• Up to 1450 characters per second (12cpi)

• Robust printer with an MTBF of

20,000 hours

• Prints up to 10-part forms
(1 original + 9 copies)

• Versatile front and rear paper paths

• USB, parallel and serial interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of
15 million characters

• Automatic platen gap adjustment

Options

• Pull tractor unit

• Perforation cutter

• Wired network interfaces

• Printer cabinet (Order code 7102677)

For options and consumables see page 25-27

Epson LQ-50

The Epson LQ-50 ts almost anywhere thanks to its small dimensions, which measure
just 275x240x153mm. This 24-pin, 50-column dot matrix printer takes 6-inch paper,
and is ideal for locations where space is at a premium such as delivery vans and small
shop counters. It is even suitable for dusty or dirty environments when used with the
optional protective roll paper cover.

24-PIN DOT MATRIX PRINTER

Key features

• 24-pin narrow carriage printer, 50 columns

• Up to 360 characters per second (12cpi)

• Robust printer with an MTBF of

10,000 hours

• Prints up to 3 -par t forms (1 original
+ 2 copies)

• USB and parallel inter faces

• Reliable printhead life of 20 0 million

strokes/wire

• Long lasting ribbon yield of
3 million characters

Options

• Roll paper holder

For options and consumables see page 25-27

10

Standard Optional

Continuous

Cut sheet

Epson LQ-350 NEW

The compact Epson LQ-350 is the ideal printer for front and back ofce
applications where space may be limited as well as for measurement and control
systems. The copy capability of one original plus three copies makes this 24-pin
printer suitable for point of sale applications where reliable, light duty printing
is required.

24-PIN DOT MATRIX PRINTER

Key features

• Compact 24-pin narrow carriage printer

• Up to 416 characters per second (12cpi)

• Robust printer with an MTBF

of 10,000 hours

• Prints up to 4-part forms
(1 original + 3 copies)

• Versatile top and rear paper paths

• 8 built-in bar code fonts

• USB, parallel and serial interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of

2.5 million characters

Options

• Roll paper holder

Epson LQ-590

With a mean volume between failure of 40 million lines and a high print speed of
529cps this extremely robust printer is ideal for medium and large print volumes.
Flexible paper management allows insertion from the front, top, rear, and bottom,
while a front sheet guide enables front feeding of even small paper types.
Typical applications are labels, barcodes and point of sale invoice printing.

24-PIN DOT MATRIX PRINTER

Key features

• Very high print speed of up to 529
characters per second (12cpi)

• Copy capability of 1 original + 4 copies

• Extremely robust printer with an MTBF
of20,000 POH

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon of 5 million characters

• Versatile front , top, rear and bottom

paper paths

• Sound reduction down to 49dB(A)
in low-noise mode

Options

• 150 or 50 sheet cut sheet feeder

• Front paper guide

• Additional push/pull tractor unit

• Roll paper holder

• Wired network interfaces, serial interface

For options and consumables see page 25-27

11

Epson LQ-630

With a small footprint (39x31cm), a column width of 80 characters, and print speed of
up to 360 characters per second, this printer is ideal for environments with restricted
space such as retail stores, doctors surgeries, ticket ofces and industrial trade and
service companies.

24-PIN DOT MATRIX PRINTER

Key features

• 24-pin narrow, atbed carriage printer

• Up to 360 characters per second (12cpi)

• Robust printer with an MTBF of

6,000 hours

• Prints up to 5-part forms
(1 original + 4 copies)

• USB and parallel interfaces

• Reliable printhead life of 200 million

strokes/wire

• Long lasting ribbon yield of
2 million characters

For options and consumables see page 25-27

Epson LQ-680Pro

An extremely durable printer with a straight, at paper path for ultra reliable
atbed printing. The Epson LQ-680Pro also includes automatic paper thickness
adjustment for optimised print quality and optimised paper feeding – ideal for
frequent changing between different paper types. It handles paper with varying
thickness (eg overlapping forms and labels), and has simple push button paper
source selection (eg between cut sheet and continuous paper).

24-PIN DOT MATRIX PRINTER

Key features

• 24-pin, 106 column atbed carriage printer

• Up to 413 characters per second (10cpi)

• Robust printer with an MTBF of

10,000 hours

• Prints up to 6 -part forms
(1 original + 5 copies)

• Parallel and Type B interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of
2 million characters

• Automatic platen gap adjustment

Options

• 150 sheet cut sheet feeder

• Roll paper holder

• Wired network and serial interfaces

For options and consumables see page 25-27

12

Standard Optional

Continuous

Cut sheet

Epson LQ-690

The Epson LQ-690 offers the best in dot matrix performance where it matters most;
speed, reliability, ribbon yield and ease-of-use. The LQ-690 is also versatile, handling
cut sheets, continuous paper, labels, envelopes and cards. The new innovative
Print Speed Enhancer feature allows fast printing of bit image data from Windows.

24-PIN DOT MATRIX PRINTER

Key features

• 24-pin medium duty, atbed
carriage printer

• Up to 529 characters per second (12cpi)

• Robust printer with an MTBF of

20,000 hours

• Prints up to 7-part forms
(1 original + 6 copies)

• USB and parallel interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of
10 million characters

Options

• Roll paper holder

For options and consumables see page 25-27

Epson LQ-2090

An extremely robust printer with a mean volume between failure of 40 million lines.
Its high print speed of 529cps makes it an ideal solution for medium and large print
volumes. The Epson LQ-2090 impresses with exible paper management which
allows paper insertion from the front, top, rear, and bottom. A front paper guide
makes it easy to insert even small sheets from the front.

24-PIN DOT MATRIX PRINTER

Key features

• 24-pin wide carriage printer

• Up to 529 characters per second (12cpi)

• Robust printer with an MTBF of

20,000 hours

• Prints up to 5 -part forms
(1 original + 4 copies)

• USB, parallel and Type B interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of
8 million characters

Options

• 150 or 50 sheet cut sheet feeder

• Front sheet guide

• Additional push/pull tractor unit

• Roll paper holder

• Wired network interfaces, serial interface

For options and consumables see page 25-27

13

Epson LQ-2190/2190N

The Epson LQ-2190 is a 24-pin wide-format printer and like its predecessor – the
LQ-2180 – it is a fast, exible, cost-effective and highly reliable printing solution which
combines large print volumes with high letter quality – ideal for applications such as
invoices, delivery notes, inventory listings or even labels. Also available as network
version LQ-2190N.

24-PIN DOT MATRIX PRINTER

Key features

• 24-pin wide carriage printer

• Up to 576 characters per second (12cpi)

• Robust printer with an MTBF of

20,000 hours

• Prints up to 6-part forms
(1 original + 5 copies)

• USB, parallel and Type B interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of
15 million characters

• Front sheet guide

Options

• Additional pull tractor unit

• Roll paper holder

• Wired network interfaces, serial interface

For options and consumables see page 25-27

Epson DLQ-3500

This printer offers ultra reliable, high speed printing. An ability to print on 8-part
stationery is especially useful for multiple copy forms, while up to three media paths
provide versatile paper handling – front sheet feed with auto loading, rear tractor feed
with paper park, and an optional automatic cut sheet feeder. Supplied with both black
and colour fabric ribbons.

24-PIN DOT MATRIX PRINTER

Key features

• 24-pin wide carriage, atbed printer

• Up to 550 characters per second (10cpi)

• Robust printer with an MTBF of

10,000 hours

• Prints up to 8 -part forms
(1 original + 7 copies)

• USB, parallel and Type B interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield (black)
of 6 or 9 million characters

• Colour printing

• Front sheet guide

• Automatic platen gap adjustment

Options

• 250 sheet cut sheet feeder

• Automatic sheet alignment unit

• Wired network interfaces, serial interface

For options and consumables see page 25-27

14

Standard Optional

Continuous

Cut sheet

THE CATALUNIA
SUCCESS STORY

In the Spanish educational system, passbooks are commonly used to keep track
of students’ academic data. Although this is a national practice, the method of
recording data in passbooks is decided by local governments.

The Junta de Castilla y León (Autonomous Community of Castile
and León) is the largest of the seventeen self-governed communities
of Spain, with a population of 2.5 million. The schools of Junta de
Castilla had been using printed labels to enter academic records
into its students’ passbooks, which involved printing individual
labels and gluing them into the books.

THE PERFECT PRINTER FOR STUDENTS’ PASSBOOKS

As these printed labels were easy to forge or tamper with, the autonomous communities
decided it would be preferable to print directly onto the pages of the passbooks. At the
same time, the communities wanted to introduce thicker passbooks with more pages,
sothat a single book would last through primary and secondary school.

Epson offered the perfect solution by customising its PLQ-20 passbook printer to handle
thicker passbooks. This gives the schools of Junta de Castilla the exibility to print
passbooks of up to 46 pages plus the cover.

Furthermore, the PLQ-20 delivers high-quality, long-lasting prints which reduce the scope
for counterfeit passbook entries.

As some of the schools had only a basic IT infrastructure, Epson provided Windows drivers
to ensure the printer installation was as straightforward as possible.

Junta de Castilla is delighted with Epson’s solution and has made an initial purchase
of 1,000 PLQ-20 printers.

SOLUTION

With a customisation of its PLQ-20,
Epson offered the schools of Junta
de Castilla the solution to its problem,
enabling them to print directly on the

surface of the students’ passbooks.

15

Epson PLQ-22/M
Epson PLQ-22CS/CSM

The Epson PLQ-22 Series offers banks, post ofces and government institutions
a very quiet printer with a low total cost of ownership. With print speeds of up
to 576cps, the PLQ-22 Series is ideal to print a wide range of media including
passbooks, passports, tickets and visas. Customers and staff alike will appreciate
the quiet operation of this passbook printer, which has noise levels as low as 51dBA.

It’s efcient too, its print speed enhancer enables fast printing of bit image
data under Windows environments to help cut queues, while the highly accurate
MICR/OCR (CS and CSM models) and MSRW (M and CSM models) heads make
handling cheques and passbooks a smooth, trouble-free process.

Delivering substantial cost and energy savings, the PLQ-22/22M is qualied by
ENERGY STAR
Further reducing TCO, it can print around 10 million characters in draft mode
between ribbon changes.

The PLQ-22 Series offers excellent passbook handling and data processing exibility,
thanks to its 128KB memory and capacity for passbooks up to 2.6mm thick.

Simple to install, the series features a choice of emulations plus parallel, serial
and USB interfaces as standard for an easy t into most IT environments.

®

and has a very low standby power consumption of 4.5W.

24-PIN DOT MATRIX PRINTER

Key features

• 24-pin, 94 column atbed passbook printer

• Time saving automatic sheet alignment

and printhead adjustment

• Up to 576 characters per second (12cpi)

• Robust printer with an MTBF of

10,000 hours

• Easy to integrate into any IT environment

with Olivetti PR2E, Epson ESC/P2 and IBM
PPDS emulations

• Accurate MICR/OCR/MSRW data reading
(selected models)

• ENERGY STAR-qualied (except CS and

CSM models)

• USB, parallel and serial interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of
5 million characters

Options

• MICR/OCR head (CS/CSM model)

• MSRW head (M/CSM model)

• 3-port built-in USB hub (CSM HUB model)

• Space saving kit including top paper tray

and rear paper guide

For options and consumables see page 25-27

Compact design
and small footprint.

Change ribbon
cartridges in seconds.

Front operation with

easy paper loading.

16

Epson PLQ-20/M
Epson PLQ-20D/DM

The Epson PLQ-20 Series is ideal for all front desk applications such as banking and
public administration ofces. The PLQ-20 provides fast print speeds of up to 576cps
and can print on a wide range of media including passbooks, passports, tickets
or visas. With its automatic printhead adjustment feature, it can handle media up to

2.6mm in thickness and has automatic sheet alignment for ease-of-use. With an
MTBF of 10,000 hours thisimpact printer has been built to last.

24-PIN DOT MATRIX PRINTER

Key features

• 24-pin, 94 column atbed passbook printer

• Time saving automatic sheet alignment

and printhead adjustment

• Up to 576 characters per second (12cpi)

• Robust printer with an MTBF of

10,000 hours

• Easy to integrate into any IT environment

with Olivetti PR2E, Epson ESC/P2 and IBM
PPDS emulations

• Accurate MSRW data reading
(selected models)

• ENERGY STAR-qualied

• USB, parallel and serial interfaces

• Reliable printhead life of 400 million

strokes/wire

• Long lasting ribbon yield of
5 million characters

Options

• MSRW head (M model)

• Dual serial port (D and DM models)

• Space saving kit including top paper tray

and rear paper guide

For options and consumables see page 25-27

PLQ-20 PLQ-20M PLQ-20D PLQ20DM PLQ-22 PLQ-22M PLQ-22CS PLQ-22CSM

MSRW –

Dual-user sharing

Scanning – – – – – –

MICR/OCR – – – – – –

IR – – – – – –

Via network

sharing

Via network

sharing

– – –

Dual serial

port

Dual serial

port

Via network

sharing

Via network

sharing

Via network

sharing

Via network

sharing

17

EPSON SOLUTIONS
FOR BANKS

Accuracy, performance, reliability, security, ease-of-use. Delivering
all these qualities through innovative print and scanning technology,
Epson’s cheque scanners make electronic cheque capture simple
to implement – for both retailers and nancial organisations.

Epson TM-S9000MJ NEW

Combine double-sided colour scanning, endorsement inkjet printing and thermal
receipt printing in one compact device and set new standards in speed and
accuracy. Cheques can be scanned at speeds of up to 200dpm, with automatic
skew correction and background noise ltering.

Photo ID cards and cut sheets can also be scanned quickly and precisely. An extra
large endorsement printing area allows all the necessary information to be printed
for endorsement. Receipts are printed at up to 300mm/sec with the option of
printing greyscale logos and reducing paper usage by up to 30 percent.

3-IN-1 SCANNER AND PRINTER

Key features

• True all-in-one colour cheque scanner,

endorsement printer and receipt printer

• Compact design saves counter space

• Double-sided, full-colour cheque scanning

at up to 200dpm

• Extra large endorsement printing area:
up to 16 lines

• Highly efcient, greyscale receipt printing

at up to 300mm/sec

• Photo ID and cut sheet scanning

• MICR recognition accuracy of more than

99.9%

• Also available with MSR reader and

USB hub

Scan method Contact Image Sensor

Scan speed 800mm/s

Paper dimensions

(mm) (H to L)

Print method Cut sheet paper unit: Line

Print speed Cut sheet paper unit:

Print height Cut sheet paper unit: 50.8mm

Interfaces USB

Power supply Exclusive AC adapter

Dimensions

(mm) (WxDxH)

Weight 5kg

60 to 120x120 to 235

inkjet/Roll paper unit: Thermal
line printing

800mm/s/Roll paper unit: 300
mm/s

(included)

One-pocket model:
250x374.8 (263.8 with stored
output pocket) x177

Two-pocket model also
available

18

Epson TM-S2000MJ NEW

The Epson TM-S2000MJ combines double-sided colour scanning andinkjet
endorsement printing in one compact device for the efcient processing of
cheques, vouchers and cut sheets.

2-IN-1 SCANNER AND PRINTER

Key features

• Double-sided, full-colour scanner with

endorsement printer

• Fast and accurate at up to 200dpm

• Extra-large endorsement printing area

• Photo ID cards can also be scanned

quickly and precisely

• 100-sheet automatic sheet feeder

Scan method Contact Image Sensor

Scan speed 800mm/s

Paper dimensions

(mm) (H to L)

Print method Line inkjet

Print speed 800mm/s

Print height 50.8mm

Interfaces USB

Power supply Exclusive AC adapter

Dimensions

(mm) (WxDxH)

Weight 4.5kg

60 to 120x120 to 235

(included)

One-pocket model:
142x374.8 (263.8 with stored
output pocket) x177

Two-pocket model also
available

Epson TM-S1000

Add reliability and innovation to crucial scanning in nancial and corporate
markets. Achieve the highest MICR accuracy in the desktop scanning
market and make the process fast, easy and world class quality.

CHEQUE AND VOUCHER SCANNER

Key features

• High accuracy for cheque and document

scanning

• Process up to 60 cheques per minute

• Drop-in auto sheet feeder and 2 pockets

• Large image scanning area of

26.95x10.26cm

Scan method Contact Image Sensor

Scan speed 500mm/s

Paper dimensions

(mm) (H to L)

Interfaces USB

Power supply Exclusive AC adapter

Dimensions

(mm) (WxDxH)

Weight 4kg

120×68 to 235×120

(included)

176×355×160

19

EPSON PRINTERS FOR
THE POST OFFICE

In more than 20 European countries Epson is the preferred brand for
processing all different kinds of materials in post ofces. A perfect
example is the UK Post with its 16,000 branches. The company needed
a hard-working, secure solution to enhance the company’s brand image.

The Epson solution

The Epson TM-J7100 inkjet is faster, quieter and prints high-quality
two-colour logos for added security. It’s very reliable, with low cost
consumables for superb value across the 30,000 printer eet.
A key feature was its ability to t easily into the existing emulation,
with built-in exibility to meet future changes.

Epson TM-J7000 Series

Enjoy fast, smooth retail and banking POS operations with this compact multifunction
inkjet and cheque processor. Enhance the customer experience and your business
efciency with high-quality 2-colour receipts and slips including graphics and
barcodes. Make a real difference to receipts with bright, eye-catching colour logos,
coupons and advertisements. Print and validate customer cheques in seconds.

With class-leading print speeds and high resolution 2-colour graphics, prints are
permanent so they last and stand out for longer. Print and endorse cheques in as
little as 12 seconds with this multifunction printer’s single-insertion system.

RECEIPT, SLIP

(ENDORSEMENT OPTION)

Key features

• Class-leading speeds up to

14.3 text lines/sec

• One-pass cheque printing with

SmartPass technology

• Durable and reliable for low cost
of ownership

• High resolution 2-colour printing

• Autocutter life 1.5 million lines,

MCBF 50 million lines

• Long-life ink cartridges last up to
20 million characters

• Quality and ef ficiency with unique
inkjet technology

• Handles cheques that have been
folded or crumpled

“ The TM-J7100 printer has

more than lived up to our

expectations, helping

us deliver outstanding

customer service.”

20

Andy McLean,
Head of Service Delivery
UK Post

Epson TM-L90

Enhance your business with the fast, compact printer that produces high-quality
1 and 2-colour custom labels and barcodes. Choose from a wide variety of paper,
including liner and thermal labels, receipts and tickets.

LABEL AND RECEIPT

Key features

• Print at up to 150mm/sec at 203×203dpi

• Design custom labels quickly and easily

• Easy drop-in paper rolls

• Excellent reliability with an MCBF
of 70 million lines

Print method Thermal line printing

Print speed 150mm/s

Column capacity 48/64

Paper dimensions

(mm)

Interfaces Changeable interface

Power supply PS-180 (option)

Dimensions

(mm) (WxDxH)

Weight 1.9kg

37.5 ± 0.5, 59.5 ± 0.5, 79.5
± 0.5 × dia. 90

board (see table page 23)

140×203×148

Epson TM-T88V

Like the Epson TM-T88IV before it, innovation is at the heart of this printer. It is the
world’s rst ENERGY STAR-qualied thermal receipt printer, and the rst greyscale
graphic POS printer too. It works harder for your business at the point of sale, with
metal hinges, splash resistance, an integrated paper cutter with a 2 million cut life,
MCBF of 70 million lines and a printhead with 50% more capacity. With this level
of reliability we’re happy to offer a 4-year commercial warranty.

RECEIPT PRINTING

Key features

• Very fast printing up to 300mm/sec

• Design and customise your own receipts

• Reduce waste with auto paper reduction

• Outstanding reliabilit y with MCBF
70 million lines

• Easy to install and upgrade

• Includes 58mm spacer

• ENERGY STAR-qualied for power

• Choose from cool white or dark grey

• Up to 30% paper saving. Customise

receipts with images and reduce waste
with auto paper reduction

Print method Thermal line printing

Print speed 300mm/s

Column capacity 42/56

Paper dimensions

(mm)

Interfaces USB on board and

Power supply PS-180 (option)

Dimensions

(mm) (WxDxH)

Weight 1.6kg

79.5 ± 0.5, 57.5 ± 0.5 (W)
× dia. 83

changeable interface
board (see table page 23)

145×195×148

21

SPECIFICATIONS EPSON 24-PIN

CARRIAGE WIDTH IN COLUMNS 50 80 80 80 106 106 136 136 136 94 94 94
PRINT SPEEDS 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi

High speed draft 300 360 347 357 440 529 300 360 413 n/a 440 529 440 529 480 576 550 n/a 480 576 480 576 480 576
Draft 225 270 260 312 330 396 225 270 310 372 330 396 330 396 360 432 495 594 360 432 360 432 360 432
Letter quality 75 90 65 78 110 132 79 94 103 124 11 0 132 110 132 120 144 165 198 120 144 120 144 120 144

EMULATIONS

Epson ESC/P2 ESC/P2 ESC/P2 ESC/P2 ESC/P2

LQ-50 LQ-350 LQ-590 LQ-630 LQ-680Pro LQ-690 LQ-2090 LQ-2190/N DLQ-3500 PLQ-20/M PLQ-20D/DM PLQ-22CS/CSM

IBM/OLIVETTI IMB 2390 plus IBM PPDS IBM PPDS IBM PPDS 2390 Plus IBM PPDS IBM PPDS IMB PPDS

PAPER HANDLING FEATURES

Auto paper loading
Auto and manual tear off position
Paper parking – continuous stationery
Micro feed
Automatic platen gap adjustment *

CUT SHEET STATIONERY

Single sheet, paper, labels or envelopes

Multi-part forms (original + copies) 1+3

Sheets with varying thickness *

1+4 *

4

1+4 1+5 1+6 1+4 1+5 1+7 1+6 1+6 1+6

Multi-part with overlap *

7

7

7

Front in front out
Front in rear out
Front in top out
Top in top out
50 sheet cut sheet feeder

3

*

150 sheet cut sheet feeder
250 sheet cut sheet feeder
Combined 50/150 sheet cut sheet feeders
Front paper guide *
Front sheet guide

5

6

*

Automatic sheet alignment unit
ROLL PAPER
CONTINUOUS STATIONARY

Single sheet or labels

Multi-part (original + copies) 1+2 1+3 1+4 1+4 1+5 1+6 1+4 1+5 1+7

Sheets with varying thickness *

Multi-part with overlap *

7

7

Rear in front out – push feed

Rear in top out – push feed

Rear in top out – pull feed

Rear in top out – push and pull feed

Front in top out – push feed

Front in top out – pull feed

Front in top out – push and pull feed

Bottom in top out – pull feed

Two stationery types loaded at once
BUFFER 64KB 128KB 128KB 32KB 64KB 128KB 128KB 128KB 128KB 64KB 64KB 128KB
ACOUSTIC NOISE LEVEL 54dB(A) 53dB(A) 49dB(A) 57dB(A) 55dB(A) 57dB(A) 50dB(A) 54dB(A) 59dB(A) 53dB(A) 53dB(A) 51dB(A)
COLOUR PRINTING

FONTS

Epson Draft

Epson Courier

Epson OCR-B

Epson Orator

Epson Orator-S

Epson Prestige

Epson Roman S S S S S S S S S

Epson Roman T S S S S S S S S S

Epson Sans Serif S S S S S S S S S

Epson Sans Serif H S S S S S S S S S

Epson Script

Epson Script C
BARCODE FONTS

Code 128

Code 39

EAN-13

EAN-8

Interleave 2 of 5

PostNet

UPC-A

UPC-E
INTERFACES

USB

Parallel

Serial Dual Dual

*9

Network print server

Type B internal interface slot
DIMENSIONS IN MILLIMETRES

Width 262mm 348mm 437.5mm 386mm 497mm

Depth 240mm 275mm 374.5mm 306mm 387mm 370mm 374.5mm 402mm 432mm 280mm 280mm 370mm

Height 153mm 154mm 171.5mm 185mm 230mm 210mm 171.5mm 256mm 276mm 203mm 203mm 210mm
WEIGHT 3.3kg 4.1kg 7.1kg 3.5kg 9.4kg 6.8kg 9.5kg 13kg 18.1kg 7.7/8.7kg 7.7/8.7kg 8.2/9.2kg

MTBF (POWER ON HOURS) 10,000 10,000 20,000 6,000 10,000 20,000 20,000 20,000 10,000 10,000 10,000 10,000
PRINT HEAD LIFE (MILLION STROKES PER WIRE)

Black 200m 400m 400m 200m 400m 400m 400m 400m 400m 400m 400m 400m

Colour

RIBBON LIFE (IN MILLION CHARACTERS)

BLACK RIBBON 3m 2.5m 5m 2m 2m
COLOUR RIBBON

Black

Cyan 1.1m

Magenta 1.1m

Yellow 0.8m

*1Requires additional convertible tractor unit option. *2Requires two additional convertible tractor unit options. *3150 sheet cut sheet feeder must be tted rst. *4Front feed only.

*5Can be used in conjunction with front continuous paper feeding. *6Cannot be used in conjunction with front continuous paper feeding. *7LQ-680Pro only.

1

*

1

*

1

*

1

*

22

SPECIFICATIONS EPSON 24-PIN

ESC/P2 ESC/P2 ESC/P2 ESC/P2 ESC/P2 ESC/P2 ESC/P2

5

*
*6

1

*

5

*

ProPrinter 2391+

ProPrinter DS

IBM PPDS/PR2

IBM PPDS/PR2

IBM4722FP/WNI4915+

IBM PPDS

1

*

1

*

1

*

480mm 612.5mm 639mm 660mm 384mm 384mm 480mm

10m 8m 15m 6m or 9m 5m 5m 5m

1.5m

*8Multi-part 1+6 copies when using pull feed. *9Not available in all countries. Please contact your local Epson representative.

= Standard = Optional S = Scalable from 2 to 32 point in 2 point steps.

23

SPECIFICATIONS EPSON 9-PIN

CARRIAGE WIDTH IN COLUMNS 80 136 80 136 136

LX-350 LX-1170II FX-890 FX-2190/N DFX-9000/N

PRINT SPEEDS 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi 10cpi 12cpi

Ultra high speed draft 566 680 566 680

High speed draft 347 357 300 337 559 627 559 627 1550 1450

Draft 260 312 225 270 419 503 419 503 1320 1320

Near letter quality 65 78 56 67 104.6 125.9 104.6 125.9 330 330
EMULATIONS

Epson ESC/P ESC/P ESC/P ESC/P ESC/P

IBM/OKI IMB PPDS 2381 Plus ProPrinter DS/ML ProPrinter DS/ML 2381 Plus/PPDS
PAPER HANDLING FEATURES

Auto paper loading

Auto and manual tear off position

Paper parking – continuous stationery

Micro feed

Automatic platen gap adjustment
CUT SHEET STATIONARY

Single sheet, paper, labels or envelopes

Multi-part forms (original + copies) 1+4 1+4 1+5 1+5

Front in top out

Top in top out

50 sheet cut sheet feeder

150 sheet cut sheet feeder

Combined 50/150 sheet cut sheet feeders

Front paper guide

Front sheet guide

5

*

6

*

5

*

6

*

ROLL PAPER
CONTINUOUS STATIONERY

Single sheet or labels

Multi-part (original + copies) 1+4 1+4 1+5 *

8

1+5 *

8

1+9 front 1+6 rear

Sheets with varying thickness

Multipart with overlap

Rear in top out – push feed

Rear in top out – pull feed

Rear in top out – push and pull feed

1

*

1

*

1

*

1

*

Front in top out – push feed

Front in top out – pull feed

Front in top out – push and pull feed

Bottom in top out – pull feed

Two stationery types loaded at once

1

*

1

*

1

*

1

*

BUFFER 128KB 64KB 128KB 128KB 128KB
ACOUSTIC NOISE LEVEL 53dB(A) 49dB(A) 55dB(A) 55dB(A) 58dB(A)
COLOUR PRINTING
FONTS

Epson Draft

Epson Roman

Epson Sans Serif
BARCODE FONTS

Code 128

Code 39

EAN-13

EAN-8

Interleave 2 of 5

PostNet

UPC-A

UPC-E
INTERFACES*

9

USB

Parallel

Serial

Network print server

Type B internal interface slot
DIMENSIONS IN MILLIMETRES

Width 348mm 546mm 414mm 589mm 700mm

Depth 275mm 275mm 350mm 350mm 378mm

Height 154mm 163mm 167.5mm 167.5mm 363mm
WEIGHT 4.1kg 6.3kg 7.2kg 9.4kg 34kg

MTBF (POWER ON HOURS) 10,000 6,000 20,000 20,000 20,000
PRINT HEAD LIFE (MILLION STROKES PER WIRE)

Black 400m 400m 400m 400m 400m

Colour characters characters characters

RIBBON LIFE (IN MILLION CHARACTERS)

BLACK RIBBON 4m 3m 7.5m 12m 15m
COLOUR RIBBON

Black

Cyan

Magenta

Yellow

1

*

Requires additional convertible tractor unit option. *2Requires two additional convertible tractor unit options. *3150 sheet cut sheet feeder must be tted rst. *4Front feed only. *5Can be used

in conjunction with front continuous paper feeding. *6Cannot be used in conjunction with front continuous paper feeding. *7LQ-680Pro only. *8Multi-part 1+6 copies when using pull feed.

*9Not available in all countries. Please contact your local Epson representative

= Standard = Optional S = Scalable from 2 to 32 point in 2 point steps.

24

OPTIONS, ACCESSORIES AND SUPPLIES

OPTIONAL
PAPER HANDLING

Convertible tractor unit C12C800202

Pull tractor unit C12C800382

Roll paper holder C12C811141

Front sheet guide C12C814011

50 sheet cut sheet feeder C12C806372

150 sheet cut sheet feeder C12C806382

Perforation cutter C12C815072

9-pin

SUPPLIES

Black fabric ribbon C13S015637 C13S015020 C13S015329 C13S015327 C13S015384

OPTIONAL
INTERFACES*

Serial interface (0K buffer) C12C824432

EpsonNet 10/100 Base Tx
Int. Printer Server 5e

WARRANTY*

1 year replacement or repair

1 year on-site

Optional extension to 3 years ECPGRP10 ECPGRP20 ECPGRP20 ECPGRP25 ECPGRP70

4

4

Order code LX-350 LX-1170II FX-890 FX-2190/N DFX-9000/N

C12C800212

C12C800302

C12C800341

3

*

C12C806402

C12C824352

OPTIONAL
PAPER HANDLING

Convertible tractor unit C12C800202

Roll paper holder C12C811141

Front sheet guide C12C814011

50 sheet cut sheet feeder C12C806372

150 sheet cut sheet feeder C12C806382

250 sheet cut sheet feeder C12C806832

Space saving kit C12C802202

24-pin

Automatic sheet alignment unit C12C806882

SUPPLIES

Black fabric ribbon C13S015(+) +624 +633 +337 +307 +262 +610 +336 +086 +066 +339 +339

Colour fabric ribbon C13S015(+) +067

Black lm ribbon C13S015255

OPTIONAL
INTERFACES*

Serial interface (0K buffer) C12C824432

EpsonNet 10/100 Base Tx
Int. Print Server 5e

WARRANTY*

1 year replacement or repair

1 year on-site

Extension to 3 years ECP-(+) +GRP5 +GRP10 +GRP20 +GRP20 +GRP20 +GRP20 +GRP30 +GRP30 +GRP50 +GRP20 +GRP20

4

4

Order code

C12C800212

C12C800302

C12C800322

C12C811262

C12C806402

C12C806872

C12C824352

LQ- 50LQ-

350

LQ-
590

LQ-
630

LQ-

680/

Pro

LQ-
690

LQ-

2090

LQ-

2190/N

DLQ-

3500

PLQ-

20/

M/D/

DM

PLQ-

22/

CS/

CSM

*1150 sheet cut sheet feeder must be tted rst. *2Can be used in conjunction with front continuous paper feeding. *3Cannot be used in conjunction with front continuous paper feeding.

4

*

Not available in all countries. Please contact your local Epson representative.

25

OPTIONS AND ACCESSORIES

TYPICAL PAPER PATHS

MOTORISED SHEET FEEDERS

For high volume cut sheet printing, optional motorised
cut sheet feeders are available for selected products, like
the 150 sheet cut sheet feeder for the Epson LQ-2180.
Equipped with productivity enhancing, independent motor
drives, these feeders reduce paper handling time and ensure
optimum paper throughput.

DFX-8500 PERFORATION CUTTER
C12C815072

LX-300 PULL TRACTOR UNIT
C12C800302

CUT SHEET FEEDERS

Offering 50, 150 and 250 sheet, for automatic selection of
forms and plain stationery.

PAPER FEED TRACTORS

A choice of push, pull and push/pull combined tractors not only
enable more than one stationery type to be permanently loaded
for delivery on demand, but handle continuous and multi-part
stationery more efciently.

LX-1170 PULL TRACTOR UNIT
C12C800341

LQ-1170 PUSH/PULL TRACTOR UNIT
C12C800212

ROLL PAPER HOLDER
C12C811141

26

FX-/LQ-2170 PULL TRACTOR UNIT
C12C800322

LQ-50 ROLL PAPER HOLDER
C12C811262

LQ-870 PUSH/PULL TRACTOR UNIT
C12C800202

AUTOMATIC SHEET ALIGNMENT UNIT
C12C806882

LQ-1170 FRONT SHEET GUIDE

C12C814011

DLQ-3000+/3500 SINGLE-BIN CSF
C12C806832

LQ-/SQ-870/LQ-570 SINGLE CSF
C12C806372

LQ-570 HIGH CAPACITY CSF

C12C806382

SERIAL I/F BOARD NO BUFFER TYPE-B

C12C824432

LQ-680/680PRO HIGH CAPACITY CSF
C12C806872

EPSON NET 10/100 BASE TX. INT. PRINT
SERV. 5E
C12C824352

LQ-1170 HIGH CAPACITY CSF
C12C806402

DFX-9000 CABINET
7102677

27

At Epson, we know that planning for the future requires a strong commitment to the environment.
That is why we strive to create innovative products that are reliable, recyclable, and energy efcient.
Better products that use fewer resources help ensure a better future for us all.

To nd out more visit www.epson.co.uk/ecopos

This optional, additional warranty extends your peace of mind for three years
fromthe date of purchase. Epson CoverPlus allows the option of extending and
upgrading the standard warranty available with the product to provide additional
cover should the product develop any fault. Epson CoverPlus extended warranty
packs must be purchased within 90 days of the purchase date of the original
product it is to cover.

THE WORLD’S LEADING DOT MATRIX PRINTER MANUFACTURER

Epson is the world’s largest manufacturer of dot matrix printers with a product range that offers the
ultimate in high speed, low cost, reliable and durable printing across all stationery types. Ideal for
back ofce, high volume data processing and multi-part stationery – for which there is simply no
alternative – no other technology offers such broad capability from a single machine.

1

Offering a wider choice than any other manufacturer – and spanning every duty cycle, from light to
heavy duty – the Epson dot matrix range enables you to strike exactly the right balance between
capability, performance and cost.

2

*1 Wor ldwi de sa les vo lum e, ID C
*2 Source: Interconnection Consulting, 2010

All features and specications described are subject to change without notice. When Epson products are used for applications requiring
high reliability/safety such as transportation devices related to aviation, rail, marine, automotive etc.; disaster prevention devices; various
safety device etc.; or functional/precision device etc.; you should use the products only after giving consideration to inclusion of fail-safes
and redundancies into your design to maintain safety and total system reliability.

Not all products are available in all countries. Please contact your local Epson ofce for more details.

For further information please contact your local Epson ofce or visit www.epson-europe.com

Austria0810/200113 (0,07 €/Min.) Belgium070/350120 (0.1735 €/min.) Czech800/142052 Denmark44508585 Finland0201552091
France0974750404 (Cost of local call, operator charges may apply) Germany01805/234110 (0,14 €/Min. aus dem dt. Festnetz, Mobilfunkpreise

abweichend. Ab 1.3.2010 Mobilfunkpreis max. 0,42 €/Min.) Greece210-8099499 Hungary0680014783 Ireland014367742 Italy02-66032110
(0,12€/min.) Luxembourg900/43010(0,24€/min.) MiddleEast+97148818934 Netherlands0900-5050808 (0.05€/oproep+0.15€/min.)

Norway+4767113700 Poland0-0-8004911299 (0,16zł/min.) Portugal707222111 Russia(095)777-03-55 Slovakia0850111429 South
Africa(+2711)465-9621 Spain935821500 Sweden0771-400135 (Mobilsamtal–0,99kr/min, Lokala samtal–0,30kr/min, Utlandssamtal–0,89kr/min)
Switzerland0848448820 (4-8cent./min.) Turkey(0212)3360303 UnitedKingdom08712226702

Trademarks and registered trademarks are the property of Seiko Epson Corporation or their respective owners.

SIDM-Range_Brochure_1EN-INT_08/12

Product information is subject to change without prior notice.
