EnGenius Technologies ECB1200 User Manual

Table of Contents
1
Table of Contents
1 Introduction ....................................................................................................................................................................... 5
2 Before you Begin ............................................................................................................................................................. 10
2.1 Considerations for Wireless Installation .................................................................................................................................................. 10
2.2 Computer Settings (in Windows XP/Windows 7/Windows 8) ........................................................................................................ 11
2.3 Computer Settings in Apple Mac OS X .................................................................................................................................................... 15
3 Configuring Your ECB1200 ............................................................................................................................................. 20
4 Building a Wireless Network ......................................................................................................................................... 23
4.4 WDS Bridge Mode ...............................................................................................................
5 Overview .......................................................................................................................................................................... 27
5.3 Realtime ................................................................................................................................................................................................................ 29
............................................................................. 26
1
6 Network ............................................................................................................................................................................ 33
7 Wireless Setting ............................................................................................................................................................... 37
7.1 Wireless Network .............................................................................................................................................................................................. 37
7.4 Fast Handover ..................................................................................................................................................................................................... 51
7.6 Wireless MAC Filtering .................................................................................................................................................................................... 53
7.7 WDS Link Settings ............................................................................................................................................................................................. 54
8 Management .................................................................................................................................................................... 56
8.2 Management VLAN Settings ........................................................................................................................................................................ 57
8.7
8.9 CLI Setting ............................................................................................................................................................................................................ 68
8.10 Systom Log .......................................................................................................................................................................................................... 69
Time Settings ...................................................................................................................................................................................................... 64
2
Appendix A – FCC Interference Statement .......................................................................................................................... 76
Appendix B – CE Interference Statement ............................................................................................................................. 77
Revision History
Version Date Notes
1.0.0 201504 First Release
3
Chapter 1 Introduction
1 Introduction
The ECB1200 is a high-powered, long-range dual-band concurrent wireless 802.11ac/a/b/g/n access point with 5 major
functional modes. It is designed to operate in numerous environments from large homes, small and medium-sized
businesses, multiple-floor offices, hotels and other venues to larger enterprise deployments. Its high-powered, long-range
characteristics make it a cost-effective alternative to ordinary access points that don’t have the range and reach to connect
to a growing number of wireless users who wish to connect to a large home or business network.
The ECB1200 supports IEEE 802.11b/g/n standards in the 2.4GHz frequency band while at the same time supporting IEEE
802.11ac/a/n standards in the less congested 5GHz frequency band ideal for streaming or transferring other large files.
The ECB1200 delivers up to faster wireless speed and extended coverage than legacy 802.11a/b/g wireless devices. Even
though the ECB1200 has been designed and engineered for traffic heavy and demanding business environments it is also
quite at home in larger house scenarios because it efficiently extends the wireless range of an existing home router,
especially in very architecturally-challenging structures to provide whole home connectivity.
To protect sensitive data during wireless transmissions, the ECB1200 offers different encryption settings for wireless
transmissions including industry-standard WPA and WPA2 encryption. The ECB1200 also includes MAC address filtering to
allow network administrators to offer network access only to known computers and other devices based on their MAC
addresses.
5
1.1 Features and Benefits
Features Benefits
2x2 MIMO High Speed Data Rate Up to 867 Mbps for 5GHz and 300Mbps for 2.4GHz
Capable of handling heavy data payloads such as HD multimedia streaming.
High Transmit Power 28dBm for each 5GHz and 2.4GHz
10/100/1000 Gigabit Ethernet Supports up to 1000Mbps wired networking speed.
IEEE 802.11ac Compliant and Backwards Compatible with 802.11 n/a/b/g devices
Multiple Operation Modes Allowing users to select any one of the following modes: Access
Support Multiple SSIDs in AP mode (up to 8 in each frequency band)
WPA/WPA2/IEEE 802.1x Support Supports industry-standard wireless encryption.
MAC Address Filtering in AP Mode For more secure network connections with known users and devices.
User Isolation Support (AP mode) Offers an additional layer of protection within the network by
Power-over-Ethernet (IEEE802.3at) Allows installers to deploy the ECB1200 in locations via a PoE
Extensive long range connectivity
Fully compatible with IEEE 802.11 ac/a/b/g/n devices.
Point, Client Bridge, WDS AP, WDS Bridge, WDS Station on their specific networking deployment need.
Allows clients to access different networks through a single access point and assign different policies and functions for each SSID through the built-in software.
isolating specific client users.
connection (Ethernet cable) where a power outlet may not be available.
Save User Settings Enables network administrators to save their device settings so
firmware upgrades do not permanently delete previous device settings.
6
SNMP Remote Configuration Management Allows remote connection to configure or manage the ECB1200
easily.
QoS (WMM) support 802.11e Prioritizes bandwidth-intensive and sensitive data traffic.
IPv6 Address support ECB1200 supports Ipv6, you can use Ipv6 address in ECB1200.
Band Steering When Band Steering is activated dual-band client devices are
associated to the ECB1200 access point on the 5 GHz frequency band.
Traff ic S hap ing Download and Upload Bandwidth Control Per SSID and Per User
Engenius EZ Controller Management (Optional)
Software-based EZ Controller Can Central Configure, Monitor APs.
1.2 Package Contents
The ECB1200 package contains the following items (Resellers and dealers require that all items must be in package to issue
a refund):
z ECB1200 Access Point/Client Bridge/WDS z 12V/2A 100V~280V Power Adapter z RJ-45 Ethernet LAN Cable z 2.4 GHz Detachable Antenna x 2 z 5 GHZ Detachable Antenna x 2 z Wall Mount Screw Kit z Quick Installation Guide
7
1.3 System Requirements
The following are the Minimum System Requirements in order configure the device.
z Computer with an Ethernet interface or wireless network capability z Windows OS (XP, Vista, 7, 8), Mac OS X, or Linux-based operating systems z Web-Browsing Application (i.e.: Internet Explorer, Firefox, Safari, or other similar browser application)
1.4 Applications
Wireless LAN (WLAN) products are easy to install and highly efficient. The following list describes the benefits of
deploying a wireless access point:
a) Difficult-to-Wire Environments
There are many situations where wires cannot be installed, deployed easily or cannot be hidden from view. Many
older buildings sites, or areas within a building may make the installation of an Ethernet-based LAN impossible,
impractical or expensive.
b) Temporary Workgroups
A deployed wireless access point or several access points, gives businesses the flexibility to create temporary
workgroups/networks in more open areas within a building – auditoriums, amphitheater classrooms, ballrooms,
arenas, exhibition centers, and temporary offices.
c) The Ability to Access Real-Time Information
Doctors/Nurses, Point-of-Sale Employees, and/or Warehouse Workers can access real-time information on their
network via the access point while dealing with patients, serving customers, and/or processing information.
8
d) Frequently Changing Environments
Setting up an access point, like the ECB1200, to provide access to a company network or its Internet connection is
quick and easy which also makes it ideal for establishing network access in temporary venues like exhibits, special
events, or show rooms.
e) Small Office and Home Office (SOHO) Networks
A wireless access point, like the ECB1200, is ideal for SOHO users who need a cost-effective way to expand their
existing network to provide more access for more devices, easy and quick installation of a small network.
f) Wireless Extensions to Existing Ethernet-based Networks
Wireless access points, like the ECB1200, enable network administrators, installers and end-users to extend the range
and reach of an existing Ethernet-based network.
g) Training/Educational Facilities
Training sites at corporations and universities deploy wireless access points to provide connectivity their networks
and the Internet connection for their employees and students.
9
Chapter 2 Before You Begin
2 Before you Begin
This section will guide you through the installation process. Placement of the EnGenius ECB1200 is essential to maximize
the access point’s performance. Avoid placing the ECB1200 in an enclosed space such as a closet, cabinet, or stairwell.
2.1 Considerations for Wireless Installation
Generally, the exact operating distance of a wireless device, like the ECB1200, cannot be pre-determined due to a number
of unknown variables or obstacles in the environment in which the device will be deployed. These could be the number,
thickness, and location of walls, ceilings, elevator shafts, stairwells, or other objects that the device's wireless signals must
pass through. Here are some key guidelines to allow the ECB1200 to have optimal wireless range.
z Keep the number of walls and/or ceilings between the ECB1200 and other network devices to a minimum. Each wall
and/or ceiling can reduce the signal strength, resulting in lower signal strength.
z Building materials make a difference. A solid metal door and/or aluminum studs may have a significant negative
effect on the signal strength of the ECB1200. Locate your wireless devices carefully so the signal can pass through
drywall and/or open doorways. Materials such as glass, steel, metal, concrete, water (example: fish tanks), mirrors, file
cabinets and/or brick can also diminish wireless signal strength.
z Interference from other electrical devices and/or appliances that generate RF noise can also diminish the ECB1200’s
signal strength. The most common types of devices are microwaves or cordless phones.
10
2.2 Computer Settings (in Windows XP/Windows 7/Windows 8)
In order to use the ECB1200, you must first configure the TCP/IPv4 connection of your Windows OS computer system.
z Click Start button and open Control Panel.
Windows XP Windows 7
11
z Move your mouse to the lower right hot corner to display the Charms Bar and select the Control Panel in Windows 8
Windows 8
z In Windows XP, click Network Connections
z In Windows 7/Windows 8, click View Network Status and Tasks in the Network and Internet section, then select
Change adapter settings
12
z Right click on Local Area Connection and select Properties
z Select “Internet Protocol Version 4 (TCP/IPv4)” and then
select Properties
13
z Select Use the following IP address and enter an IP address that is
different from the ECB1200 and subnet mask then click OK.
Note: Ensure that the IP address and subnet mask are on the same subnet as
the device.
For example: ECB1200 IP address: 192.168.1.1
PC IP address: 192.168.1.2 – 192.168.1.255
PC subnet mask: 255.255.255.0
14
2.3 Computer Settings in Apple Mac OS X
z Go to System Preferences (can be opened in the Applications folder or selecting it in the Apple Menu) z Select Network in the Internet & Network section z Highlight Ethernet z In Configure IPv4, select Manually z Enter an IP address that is different from the ECB1200 and subnet mask then press OK
Note: Ensure that the IP address and subnet mask are on the same subnet as the device.
For example: ECB1200 IP address: 192.168.1.1
PC IP address: 192.168.1.2 – 192.168.1.255
PC subnet mask: 255.255.255.0
z Click Apply when done.
15
2.4 Hardware Installation
1. Ensure that the computer in use has an available Ethernet (RJ-45) Port. For more information, verify with your
computer’s user manual.
2. Connect one end of the Category 5e Ethernet cable into the RJ-45 port of the ECB1200 and the other end to the RJ-45
port of the computer. Ensure that the cable is securely connected to both the ECB1200 and the computer.
3. Connect the Power Adapter DC connector to the DC-IN port of the ECB1200 and the Power Adapter to an available
electrical outlet. Once both connections are secure, verify the following:
a) Ensure that the POWER light is on (it will be orange). b) Ensure that the 2.4GHz/5GHz WLAN light is on (both will be blue.). c) Ensure that the LAN (Computer/ECB1200 Connection) light is on (it will be blue). d) Once all lights are on, proceed to set up the ECB1200 using the computer.
16
This diagram depicts the hardware configuration.
17
Mounting the ECB1200
To attach ECB1200 on a wall using included mounting screw kit.
1. Drill the holes to input the mounting screws.(25mm x 8mm)
2. Use the included screws (18mm x 5.5mm) to attach on ECB1200
3. Lock ECB1200 on the mounting screws.
18
Front Panel
LED Lights LED lights for Power, Gigabit Ethernet port, WLAN 2.4GHz and WLAN 5GHz.
Rear Panel
Power DC IN for Power.
Gigabit Ethernet Port Gigabit Ethernet port for RJ-45 cable.
Reset Button One click for reset the device. Press over 10 seconds for reset to factory default.
19
Chapter 3 Configuring Your ECB1200
3 Configuring Your ECB1200
This section will show you how to configure the device using the web-based configuration interface.
3.1 Default Settings
Please use your Ethernet port or wireless network adapter to connect the ECB1200.
Default Settings
IP Address 192.168.1.1 Username / Password admin / admin Operation Mode AP / AP
20
3.2 Web Configuration
z Open a web browser (Internet Explorer/Firefox/Safari) and enter the IP Address http://192.168.1.1
Note: If you have changed the default LAN IP Address of the Access Point, ensure you enter the correct IP Address.
z The default username and password are admin. Once you have entered the correct username and password, click the
Login button to open the web-base configuration page.
21
z If successful, you will be logging in and see the ECB1200 User Menu.
22
Chapter 4 Building a Wireless Network
4 Building a Wireless Network
The ECB1200 has the ability to operate in various modes. This chapter describes the operating modes of the ECB1200.
4.1 Access Point Mode
In Access Point Mode, ECB1200 behaves likes a central connection for stations or clients that support
IEEE 802.11ac/a/b/g/n networks. The stations and clients must be configured to use the same SSID (Service Set Identifier)
and security password to associate with the ECB1200. The ECB1200 supports up to eight SSIDs at the same time for secure
access.
23
