IC Interference Statement..............................................................77
CE Interference StatEment.............................................................79
Professional installation instruction...........................................80
3
Chapter 1
Product Overview
4
Introduction
Key Features-ENH1750EXT
• Up to 29 dBm transmit power enabling long range connectivity
• Supports IEEE802.11ac/a/b/g/n wireless standards with up to
450 Mbps data rate on 2.4GHz band and 1300Mbps on 5GHz
band
• Three detachable 5 dBi 2.4 GHz Omni-directional antennas
• Three detachable 7 dBi 5 GHz Omni-directional antennas
• Can be monitored after deployment with EnGenius EZ
Controller
• Mesh Supported
• Can be used with included power adapter or via PoE with PoE
802.3at - capable switches or injectors
• Dual Band/Three Stream
• Band Steering shifts dual band clients to 5 GHz for better
throughput performance
• Secured Guest Network option available
TM
software for Windows (Free online download)
Introduction
The ENH1750EXT is a high-powered, long-range 3x3 DualBand Wireless 802.11 ac/a/b/g/n Outdoor Access Point
with speeds up to 450 Mbps on 2.4GHz and 1300Mbps on
5GHz band. It can be congure as an: Access Point, Client
Bridge, or WDS (AP, Station & Bridge). The ENH1750EXT is
designed to operate in a variety of outdoor environments.
Its high-powered, long-range characteristics make it a cost-
effective alternative to ordinary Access Points that don’t
have the range and reach to connect to a growing number of
wireless users who wish to connect to a business network.
The ENH1750EXT supports the 2.4GHz frequency band
under 802.11 b/g/n mode while at the same time providing
5GHz band under 802.11 ac/a/n mode for communicating
to and from 5GHz capable computers, tablets or smart
phones or transferring les. Several ENH1750EXTs can
be deployed in a campus setting using the 5GHz band as
a backhaul to provide multiple 2.4GHz wireless cells for
System Requirements
The following are the Minimum System Requirements in
order to congure the device.
computers or mobile devices in common outdoor areas.
The ENH1750EXT is easy to install in virtually any location
with its included PoE (Power over Ethernet) injector for
quick outdoor installation. The ENH1750EXT enables
network administrators to control its transmit power
and feature settings for selecting narrow bandwidth and
trafc shaping. The ENH1750EXT also supports wireless
encryption including Wi-Fi Protected Access (WPA-PSK/
WPA2-PSK) Encryption, and IEEE 802.1x with RADIUS.
• Computer with an Ethernet interface or wireless network capability
• Windows OS (XP, Vista, 7), Mac OS, or Linux-based operating systems
• Web-Browsing Application (i.e.: Internet Explorer, Firefox, Safari, or
another similar browser application)
6
Package Contents
The ENH1750EXT package contains the following items:*
*(all items must be in package to issue a refund):
7
Introduction
Key Features-ENH1350EXT
• Up to 28 dBm transmit power enabling long range connectivity
• Supports IEEE802.11ac/a/b/g/n wireless standards with up to
450 Mbps data rate on 2.4GHz band and 1300Mbps on 5GHz band
• Two detachable 5.17 dBi 2.4 GHz Omni-directional antennas
• Two detachable 5.17 dBi 5 GHz Omni-directional antennas
• Can be monitored after deployment with EnGenius EZ
ControllerTM software for Windows (Free online download)
• Can be used with included power adapter or via PoE with
Proprietary 48V.
• Fast Transition and Handover between Access Points
• Band Steering shifts client devices to a proper frequency band
for getting more bandwidth and speed under an Access Point.
• Secured Guest Network option available
Introduction
ENH1350EXT equips with two powerful RF interfaces that
support up to 867 Mbps in 5GHz frequency band and 400
Mbps in 2.4GHz frequency band (with 2ss/VHT40 clients).
It can be congured as an: Access Point, Client Bridge, or
WDS (AP, Station & Bridge). The ENH1350EXT is designed
to withstand harsh environment conditions including
serve and prolonged exposure to sunlight, extreme cold,
frost, snow, rainfall, hail and humidity. The ENH1350EXT
supports the 2.4GHz frequency band under 802.11 b/g/n
mode while at the same time providing 5GHz band under
802.11 ac/a/n mode for communicating to and from 5GHz
capable computers, tablets or smart phones or transferring
les. Several ENH1350EXTs can be deployed in a campus
setting using the 5GHz band as a backhaul to provide
multiple 2.4GHz wireless cells for computers or mobile
8
devices in common outdoor areas.
The ENH1350EXT is easy to install in virtually any location
with its included PoE (Power over Ethernet) adapter for
quick outdoor installation. The ENH1350EXT enables
network administrators to control its transmit power
and feature settings for selecting narrow bandwidth and
trafc shaping. The ENH1350EXT also supports wireless
encryption including Wi-Fi Protected Access (WPA2-PSK)
Encryption, and IEEE 802.1x with RADIUS.
System Requirements
The following are the Minimum System Requirements in
order to congure the device.
• Computer with an Ethernet interface or wireless network capability
• Windows OS(XP, Vista, 7, 8, 10), Mac OS, or Linux-based operating
systems
• Web-Browsing Application (i.e.: Internet Explorer, Firefox, Safari, or
another similar browser application)
Package Contents
The ENH1350EXT package contains the following items:*
External Power Adapter, DC IN, 48V/0.8A
IEEE802.3at support
Operation Modes
Access Point
WDS
Mesh
Control
CLI Supported
Distance Control (Ack Timeout)
802.1X Supplicant (CB Mode)
Multicast Supported
Auto Reboot
Obey Regulatory Power
10
Security
WEP Encryption - 64/128/152 bit
WPA/WPA2 Personal (WPA-PSK using TKIP or AES)
WPA/WPA2 Enterprise (WPA-PSK using TKIP or AES)
Hides SSID in beacons
MAC address ltering, up to 50 MACs
Wireless STA (Client) connection list
Https Support
SSH Support
QoS (Quality of Service)
Complaint with IEEE 802.11e standard
Physical/Environment Conditions
Operating:
Temperature: -4 °F to 158 °F (-20 °C to 70 °C)
Humidity (non-condensing): 90% or less
Storage:
Temperature: -22 °F to 176 °F (-30 °C to 80 °C)
Humidity (non-condensing): 90% or less
11
ENH1350EXT
Standard:
IEEE802.11ac/a/n on 5 GHz
IEEE802.11b/g/n on 2.4 GHz
IEEE802.3at
3 LAN Port (802.3af and Proprietary 48V PoE Input): Ethernet
port for RJ-45 cable.
4 LED Indicators: LED lights for Power, LAN Port, 2.4 GHz
Connection and 5 GHz Connection.
5 Mounting Holes: Using the provided hardware, the ENH1350EXT
can be attached to a wall or pole.
1 52
3
1
4
2
15
Chapter 2
Before You Begin
16
Computer Settings
Windows XP/Windows 7/Windows 8/Windows
10
In order to use the Access Point, you must rst congure the
TCP/IPv4 connection of your Windows OS computer system.
1a. Click the Start button and open the Control Panel
1b. Move your mouse to the lower right hot corner to
display the Charms Bar and select the Control Panel in
Windows 8 OS.
Windows 8
1c. In Windows 10, click Start to select All APPs to enter
the folder of Windows system for selecting Control
Panel.
Windows XPWindows 7
Windows 10
17
2a. In Windows XP, click Network Connections.
2b. In Windows 7/Windows 8/Windows 10, click View
Network Status and Tasks in the Network and
Internet section, then select Change adapter settings.
3. Right click on Local Area Connection and select Properties.
4. Select Internet Protocol Version 4 (TCP/IPv4) and then select Properties.
5. Select Use the following IP address and enter an IP
address that is different from the Access Point and Subnet
mask, then click OK.
18
Note: Ensure that the IP address and Subnet mask are
on the same subnet as the device.
For example: ENH220EXT IP address: 192.168.1.1
PC IP address: 192.168.1.2 – 192.168.1.255
PC Subnet mask: 255.255.255.0
19
Apple Mac OS X
4. In Congure IPv4, select Manually.
1. Go to System Preferences (Which can be opened in the
Applications folder or selecting it in the Apple Menu).
2. Select Network in the Internet & Network section.
5. Enter an IP address that is different from the Access
Point and Subnet mask then press OK.
Note: Ensure that the IP address and Subnet mask are
on the same subnet as the device.
For example: ENH900EXT IP address: 192.168.1.1
PC IP address: 192.168.1.2 – 192.168.1.255
PC Subnet mask: 255.255.255.0
6. Click Apply when done.
3. Highlight Ethernet.
20
Hardware Installation
ENH1750EXT
1. Connect one end of the Ethernet cable into the main
LAN port (PoE) of the Access Point and the other end to
the AP Ethernet port on the PoE injector.
2. Connect the Power Adapter to the DC-IN port of the
PoE injector and plug the other end in to an electrical
outlet.
3. Connect the second Ethernet cable into the LAN port of
the PoE injector and the other end to the Ethernet port
on the computer.
4. Screw on the provided antennas to the device. Once
both connections are secure, verify the following:
a) Ensure that the POWER light is on (it will be green).
b) Ensure that the 2.4 GHz/5 GHz WLAN light is on (it will
be green for both 5 GHz and 2.4 GHz).
This diagram depicts the hardware conguration.
PoE Injector/
PoE Swtich
Ethernet
PC
c) Ensure that the LAN (Computer/ENH1750EXT
Connection) light is on (it will be green).
d) Once all three lights are on, proceed to set up the
Access Point using the computer.
Power
Outlet
Note: The Access Point supports both IEEE 802.3at PoE
(Power over Ethernet) or the included power injector.
You may use either one as the power source. Do NOT
use both at the same time.
21
Mounting the ENH1750EXT
Using the provided hardware, the ENH1750EXT can be attached to a wall or a pole.
1. Wall Mount Kit 260x180x7 (mm) 2. Pole Mount Kit 140x112x33 (mm)
3. Pipe 63.5 (D) x 12.7 (mm) 4. Tool 20(D) x 6 (mm)5. Screws: 6.5(D) x 9.95 (mm)
22
To attach the ENH1750EXT to a wall using wall
mounting kit.
1. Mark the four locations of the mounting holes on the
at mounting surface.
2. Drill a 37 mm deep 8 mm hole in the markings and
hammer the bolts into the openings.
1.
2.
3.
3. Place the lock and at washers on the four hex cap screws
and drive the screws to attach the bracket to the back of
the Access Point.
4. Tighten the at washers to secure the bracket to the
mounting surface.
4.
23
To attach the ENH1750EXT to a pole using the
provided pole mounting kit:
1. Place the lock and at washers on the four hex cap screws
and drive the screws to attach the bracket to the back of
the Access Point.
2. Drive the four round head screws to attach the Pole
Mount Bracket to the bracket.
1.3.2.
3. Thread the open end of the Pole Strap through the two
tabs on the Pole Mount Bracket .
4. Lock and tighten the Pole Strap to secure the Pole Mount
Bracket to the pole.
Note: See diagram below for vertical and horizonal
placements.
