EAP1750H
can be used with
802.3at
capable switches or injectors
Key Features
•
802.11ac wireless speeds of up to 1300 Mbps on the 5 GHz band
•
802.11n wireless speeds up to 450 Mbps on the 2.4 GHz band
•
Up to 28 dBm transmit power on both 2.4 GHz and 5 GHz band for
longer range and enhanced wireless coverage
•
Internal 3D Sectorized Antenna Array that minimizes RF interference
•
Can be monitored after deployment with EnGenius EZ Controller™
software for Windows, Mac OS X and Linux (available as a free
download)
•
Can be used with included power adapter or via PoE with PoE
802.3at capable switches
•
Quantum Beam Technology
•
Dual Band / Three Stream (3x3)
•
Band Steering feature detects Dual Band clients and shifts them to
the 5 GHz band to relieve network congestion on the 2.4 GHz band to
maintain optimal data trafc ow
•
Secured Guest Network option available
•
SSID-to-VLAN Tagging
™
802.11ac 3x3 Dual Band Ceiling
Mount Access Point/WDS
The EAP1750H leverages the breakthrough speed and performance of
802.11ac for connecting to laptops and other devices that need to wirelessly
stream HD video or transfer large les. The EAP1750H is an 802.11ac 3x3
Indoor Access Point. This high-powered ceiling mount Dual Band Access Point
features speeds up to 450 Mbps on 2.4 GHz and up to 1300 Mbps on the 5
GHz band when associated with AC client devices. It can be congured as an
Access Point, Client Bridge, or WDS (AP & Bridge) and features a high transmit
RF power of 28 dBm transmit RF power on both 2.4 GHz and 5 GHz band
for long range connectivity. The EAP1750H includes a Gigabit Ethernet port
for connecting to 802.3at-capable PoE Switches and an enhanced receive
sensitivity MIMO (Multiple In / Multiple Out) integrated sectorized 3D antenna
array. It’s an ideal solution for spacious interior environments such as large
homes, small and medium-sized businesses, multiple-oor buildings, hotels,
hospitals, and other venues.
The EAP1750H can be congured to operate in several different modes for unique and
customized deployment scenarios; as a Dual Band Wireless AC1750 Access Point, a WDS
Bridge, or a WDS Access Point.
The EAP1750H features Quantum Beam™ which nds the most efcient signal path to ACcompatible computers and other devices at wireless speeds nearly 3x faster than Wireless
N. The Access Point’s Gigabit Ethernet port also offers greater bandwidth capacity and faster
data transfers through the network. This makes the EAP1750H an excellent solution for
bandwidth-intensive applications such as HD video streaming.
The EAP1750H also features Band Steering, which shifts trafc for Dual Band-capable clients
to the 5 GHz band from the 2.4 GHz band, helping to relieve network congestion and maintain
optimal data throughput. Multiple EAP1750Hs can also be congured for Fast Roaming when
used with a RADIUS server, so employees can stay connected as they roam throughout
a building. The EAP1750H is a cost-effective solution for small-to-medium sized or larger
companies that need to provide employees with network or Internet access on either band
whenever they’re away from their desks or attending meetings in another part of the building.
To unobtrusively blend in with other common building infrastructure appliances, the ceiling
mount EAP1750H appears as a low prole smoke detector and can be powered via a PoE
(Power-over-Ethernet) from an IEEE 802.3at rated switch.
The EAP1750H also supports wireless encryption standards such as Wi-Fi Protected Access
(WPA-PSK/WPA2-PSK) Encryption, IEEE 802.1X with RADIUS. MAC Address Filtering is
also included for network administrators to allow or deny network access to client devices
(computers, tablet PCs, NAS, smartphones, etc.) according to their MAC addresses. EnGenius’
EZ Controller™ Management Software for Windows, Mac OSX, and Linux (available as a free
download) allows monitoring, management, and sequential rmware upgrades of EnGenius
Access Points that have already been deployed in the network from the convenience of a desk.
The EAP1750H also supports wireless encryption standards such as Wi-Fi Protected
Access (WPA-PSK/WPA2-PSK) Encryption, IEEE 802.1X with RADIUS. MAC
Address Filtering is also included allowing network administrators to allow or deny
network access to client devices (computers, tablet PCs, NAS, smartphones, etc.)
according to their MAC addresses. EnGenius’ EZ Controller™ Management Software
for Windows, Mac OSX, and Linux (available as a free download) allows monitoring,
management, and sequential rmware upgrades of EnGenius Access Points that
have already been deployed in the network from the convenience of a desk.
3 Stream 802.11ac Wireless Speeds on 5 GHz
Up to 1300 Mbps on its 5 GHz for faster le transfers and smoother video
streaming.
3 Stream 802.11n Wireless Speeds on 2.4 GHz
Up to 450 Mbps on the 2.4 GHz band.
High Power, Long-Range and Multiple Floor Penetration
28 dBm for both 2.4GHz and 5 GHz RF transmit power enables the wireless signal
to penetrate oors, ceilings, and walls for greater device connectivity.
Dual Band operation
- 2.4 GHz and 5 GHz frequency bands for expanded user capacity.
- Greater number of channels available on the 5 GHz frequency spectrum to support
higher bandwidth applications like HD video streaming.
Unobtrusive Housing
- Blends in with other common building infrastructure appliances, the ceiling mount
EAP1750H appears as a low prole smoke detector and can be powered via a PoE
(Power-over-Ethernet) from an IEEE 802.3at rated switch.
- Integrated sectorized 3D Antenna array to minimize RF interference.
Fast Roaming
Multiple EAP1750Hs can also be congured for Fast Roaming when used with a RADIUS
server. This means that employees can be constantly connected to the network – whether
they are warehouse workers scanning and capturing barcode information, employees on Wi-Fi
phone calls while walking to meetings on another part of a building or healthcare professionals
capturing patient information on mobile devices.
SSID-to-VLAN Tagging
Can be congured to broadcast up to eight (8) SSIDs per frequency band. Each SSID can be
tagged to a specied company network VLAN for different user access based on established
access rights.
Quantum Beam Technology
Seeks the most efcient signal path to AC compatible computers and other devices and
transfers data up to 1300 Mbps and nearly 3x faster than Wireless N
Simplied AP Monitoring and Management
For easier monitoring and maintenance after deployment on rooftops and other hard to reach
places, users can monitor the Access Point remotely with SNMP-based EZ Controller wireless
Access Point software for Windows, Mac OSX, and Linux (available online as a free download).
Reset Button
Supports Separate Mode Conguration per Frequency Band
Choose one of two (2) modes available depending on your need: Access Point or
WDS (AP & Bridge).
Band Steering
Detects and allows Dual Band clients to shift to the 5 GHz band from the 2.4 GHz
band, relieving network congestion and maintain optimal data trafc ow.
3D Sectorized Antenna
WPS LED Power LED
5 GHz LED
Ethernet Port Power Connector
LAN LED
2.4 GHz LED
Ceiling (Wall)
Mount Hole
Kensington
Security Slot
2
Band Steering
How Band Steering Works and Its Benet
When wireless networks experience excessive trafc, users may be
inconvenienced by slower le transfers and frequent video buffering especially
on the 2.4 GHz band. Several of the Electron Series Access Points include a
Band Steering option which when applied in the browser-based interface,
Band Steering: OFF
2.4 GHz
Single Band Devices
automatically shifts the connection of Dual-Band client computers, tablets, smart phones
and other devices to the 5 GHz band where there is less trafc and more available RF
channels. This leaves Single-Band 2.4 GHz (802.11b/g/n) clients to operate in the 2.4
GHz band that with Band Steering activated becomes less congested.
2.4 GHz / 5 GHz
Dual Band Devices
2.4 GHz Single Band Devices Congested Trafc on Dual
Band Devices
Band Steering: ON
2.4 GHz Single Band Devices
Shifts Dual Band Devices
to 5 GHz Band for
Smooth Connection
2.4 GHz Band 5 GHz Band
3
2.4 GHz (450 Mbps) 5 GHz (1300 Mbps)
Specications
Standards
IEEE 802.11a/n/ac on 5 GHz
IEEE 802.11b/g/n on 2.4 GHz
IEEE 802.3at
Antenna
Integrated 3D Sectorized Antenna
4 dBi on 2.4 GHz
5 dBi on 5 GHz
Physical Interface
1 x 10/100/1000 Gigabit Ethernet Port
1 x Reset Button
1 x Power Connector
LED Indicator
Power
WPS
WLAN (Wireless Connection)
LAN
Power Requirements
Active Ethernet (Power-over-Ethernet)
Proprietary PoE Design
Power Adapter
Operation Modes
Access Point/WDS
WDS AP
WDS Bridge
4
Security
WEP (64/128bit)
WPA/WPA2 (TKIP/AES)
Hidden SSID
MAC address ltering, up to 50 eld
802.1x Authenticator (MD5/TLS/TTLS/PEAP)
Guest Network
QoS (Quality of Service)
WMM (Wireless Multimedia)
Wireless Management
Web interface (HTTP/HTTPS)
SNMP v1/v2c/v3 with MIB I/II and private MIB
CLI (Telnet/SSH)
Firmware Upgrade
Backup/Restore Settings
Save Conguration as Default
Auto Reboot
E-mail Alert/Syslog Notication
Environmental & Mechanical
Power Source
DC Input: 12VDC/2A
PoE: Compatible with 802.3at
Temperature Range
Operating: 32 to 104°F / 0 to 40°C
Storage: -4 to 140°F / -20 to 60 ° C
Humidity (non-condensing)
Operating: 90% or less
Storage: 90% or less
Weights & Measures
Diameter: 6.36” (161.54 mm)
Height: 1.64” (41.66 mm)
Weight: 0.65 lbs
Warranty
1 Year
Package Contents
EAP1750H 802.11ac 3x3 Dual Band Ceiling Mount Indoor Access Point
12V/2A Power Adapter
T-Rail Mounting Kit
Ceiling and Wall Mount Screw Kit
Mounting Bracket
RJ-45 Ethernet Cable
Quick Installation Guide
Physical Security
Kensington Security Slot
EnGenius Technologies | 1580 Scenic Ave. Costa Mesa, CA 92626
Features and specications subject to change without notice. Trademarks and registered trademarks are the
property of their respective owners. For United States of America: Copyright © 2014 EnGenius Technologies,
Inc. All rights reserved.
Version 2.0 - 06/23/14
Maximum data rates are based on IEEE 802.11 standards. Actual throughput and range may vary
depending on many factors including environmental conditions, distance between devices, radio
interference in the operating environment, and mix of devices in the network. . Compliant with FCC - This
equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his/her own expense.
