Enfora WLN1501, WLN1502 User Manual

Users’ Guide: WLN1500UG001

Enfora® Wi-Fi® Adapter for

Treo 600/650 Smartphone

Users’ Guide

Revision 1.00

Copyright 2005 by Enfora Inc. All rights reserved. No portion of this document may be copied, photocopied, reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Enfora Inc.

Disclaimer

Enfora Inc. makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Further, Enfora Inc. reserves the right to revise this publication, and to make changes from time to time in the contents hereof without obligation of Enfora Inc. to notify any person of such revision or changes.

ALL INFORMATION IS PROVIDED BY ENFORA INC. ON AN “AS IS” BASIS ONLY. THIS COMPANY PROVIDES NO REPRESENTATIONS AND WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY AND NONINFRINGEMENT.

All product names mentioned within this document are the trademark of their respective owners.

Enfora, Inc. Proprietary Information WLN1500MAN001

WLN1501/WLN1502 Wi-Fi Adapter Page 2 Copyright, 2005 Enfora Inc.

Table of Contents

SAFETY INFORMATION FOR WIRELESS HANDHELD DEVICES.................... 1

GENERAL SAFETY INSTRUCTIONS ........................................................................ 3

PACKAGE CONTENTS ................................................................................................. 4

APPEARANCE................................................................................................................. 5

HARDWARE AND SOFTWARE INFORMATION.................................................... 6

BATTERY OPERATION...................................................................................................... 6

SYSTEM REQUIREMENTS.................................................................................................. 6

SOFTWARE INSTALLATION............................................................................................... 6

INSTALLING THE TREO SMARTPHONE INTO THE ENFORA® WI-FI® ADAPTER ................7

REMOVING THE ENFORA® WI-FI® ADAPTER FROM THE TREO 600/650......................... 8

NETWORK AND BATTERY STATUS LED DESCRIPTION..................................................... 8

CONFIGURING YOUR ENFORA® WI-FI® ADAPTER .......................................... 9

ADDITIONAL INFORMATION..................................................................................13

NETWORK INFORMATION............................................................................................... 13

ADVANCED CONFIGURATION................................................................................14

POWER SAVE ................................................................................................................. 14

RESTORE DEFAULT SETTINGS ........................................................................................ 14

SOFTWARE LICENSE AGREEMENT...................................................................... 15

LIMITED WARRANTY................................................................................................17

SCOPE ............................................................................................................................17

HARDWARE.................................................................................................................... 17

SOFTWARE..................................................................................................................... 17

OTHER CONSIDERATIONS............................................................................................... 18

WLN150x Wi-Fi Adapter Copyright, 2005 Enfora Inc.

Safety Information for Wireless Handheld Devices

The equipment certifications appropriate to your device are marked on the device and product specific information. The use of the equipment is subject to the following conditions:

FCC COMPLIANCE STATEMENT

This device complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

CAUTION

Changes or modifications without the express consent of Enfora, Inc. void the user’s authority to use the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not used in accordance with instructions, can cause harmful radiation to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If the equipment does cause harmful interference in radio and television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation distance between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Contact Enfora, Inc. Technical Support for assistance.

FCC Radiation Exposure Statement

1. CAUTION: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.

2. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. (This does not apply to the antenna that is part of the Treo 600/650.)

The Federal Communications Commission (FCC) with its action in ET Docket 96-8 has adopted a safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC certified equipment. Enfora products meet the uncontrolled environmental limits found in OET-65 and ANSI C95.1, 1991.Proper operation of this radio according to the instructions found in this manual and the hardware and software guides on the CD will result in user exposure that is substantially below the FCC recommended limits.

Customers in European countries

Battery is not replaceable, for service center only.

WLN1501/WLN1502 Wi-Fi Adapter Page 1 Copyright, 2005 Enfora, Inc.

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED BY INCORRECT TYPE. DISPOSE OF BATTERIES ACCORDING TO THE INSTRUCTIONS.

Use the following or equivalent certified Power Supply. Make: PHIHONG, Model PSA11R-050 Rated Input: 100-240Vac, 0.5A, 50-60hz, DC Output: 5V DC, 2.0A Limited Power Source.

General Safety Instructions

• Check if all peripherals are properly connected before turning on any equipment.

• Make sure to disconnect the power plug from the power source before installing or

removing the Enfora® Wi-Fi® Adapter.

• Always hold the product with dry hands. Droplets of water may cause it to short circuit and damage to the product.

• Use the product only under a dry environment. Humid places are not appropriate for the product.

• DO NOT use the product in a damp environment.

• DO NOT place the product on an unstable surface. Keep the product out of the reach of

children.

• DO NOT share the same extension power line for the product with high powerconsuming appliances to avoid power overload.

• NEVER attempt to disassemble the product! Doing so may cause permanent damage to the product and will void the warranty.

Package Contents

Check the contents of the package. The following items should be included. If there is any item that is damaged or missing, please contact your dealer immediately.

The following contents are included in the WLN1501 – Wi-Fi® Adapter for Treo 600:

Description Quantity

Enfora® Wi-Fi® Adapter for Treo Smartphone 1 Install CD-ROM 1 AC/DC Power Supply 1

The following contents are included in the WLN1502 – Wi-Fi® Adapter for Treo 650:

Description Quantity

Enfora® Wi-Fi® Adapter for Treo Smartphone 1 Install CD-ROM 1 AC/DC Power Supply 1 Battery Cover Door for the Treo 650 1
