Page 1
With 14cm High Pressure Blades Silent Fan
www.enermax.com
ETS-T50A-FSS
Page 2
With 14cm High Pressure Blades Silent Fan
Support up to 230W+ TDP
14cm silent fan with huge airflow design
Patented Air Guide
Patented Pressure Differential Flow (PDF) design
ETS-T50A-FSS, a variant of ETS-T50 AXE coolers, is equipped with a
14cm high pressure blades silent fan that aims to reach the perfect
balance between silence and performance. This 14cm silent version
CPU cooler features patented Pressure Differential Flow design, Vortex
Generation Flow, proven VEF design and also the smart gadget
design- air guide to enhance the cooling capacity. Besides, five Ø6mm
heat pipes cooperated with 14cm silent fan offer users an outstanding
cooling solution with powerful 230W+ TDP support.
Features
ETS-T50A-FSS
Included 14cm silent fan aims to
reach the perfect balance between
silence and performance
14cm
Innovative High Pressure
Blades design enhances
the cooling performance
ETS-T50A-FSS Other cooler – Normal fan
Page 3
Patented Air Guide with rotatable
grill for preferred airflow direction
adjustment directly toward the
rear case fan area
360º
Asymmetric heat pipe design allows extra
space for ideal RAM compatibility
+ 15%
airflow
Patented PDF (Pressure Differential Flow)
design uses differential wind pressure to
increase 15% more airflow.
Page 4
Unique air path creating high VEF (Vacuum Effect) to optimize the airflow
ETS-T50 AXE – no air leaks from sides Other cooler - air leaks from sides
Patented VGF (Vortex Generation Flow) to increase air convection around the heat pipe
ETS-T50 AXE Other cooler
Patented Twister Bearing technology
MTBF≧160k hours
Detachable blade for easy cleaningLong life and low noise
Page 5
Dimension
unit:mm
Specifications
Compatible Socket
ETS-T50A-FSSETS-T50A-FSS
®
Intel
LGA 775/115X/1366/ 2011/2011-3/2066
®
AMD
AM2/AM2+/AM3/ AM3+/AM4/ FM1/FM2/FM2+
135.2
Overall Dimension
Heat Sink Dimension
Thermal Grease
Static Pressure (mm-H
Fan
Weight
Heat Pipe
Material
Fan Dimension
Speed (RPM)
Air Flow (CFM)
3
Air Flow (m
/h)
Minimal Noise (dBA)
Connector
Rated Voltage
Bearing Type
144.2(L) x 109.5(W) x 163(H) mm
135.2(L) x 65(W) x 160(H) mm
864g (w/ fan)
5 x Ø6 mm
Copper Heat Pipes/ Aluminum Fins
®
Dow Corning
TC-5121
140 x 140 x 25.5 mm
500 ~ 1000 ±10%
29.78~ 55.45
50.59~ 94.21
O)
2
0.57~ 2.13
13~ 22
4 pin connector
12V
Twister Bearing
MTBF
Barcode
Box Dimension
Gross Weight / Box
Carton Dimension
Q’ty / Carton
Gross Weight / Carton
www.enermax.com
©
2018 ENERMAX TECHNOLOGY CORPORATION. All rights reserved. Specifications are subject to change without notice. Content of delivery might differ
in different areas or from illustrations. Some trademarks m ay be claimed as the property of o thers.
≧160,000 hours @ 25°C
Shipping Information
EAN: 4713157723376 / UPC: 819315023372
222 x 175 x 130 mm
1390 g
460 x 370 x 295 mm
8 pcs
12.5 kg
Oct. 2018
