Page 1
High performance CPU air cooler
www.enermax.com
ETS-T50A-DFP
Page 2
Powerful 250W+ TDP support
High performance CPU air cooler
Super high static pressure of the fan up to 4.812mm-H
TM
Patented Dust Free Rotation (DFR
) technology fan
Patented Pressure Differential Flow (PDF) design
Patented Rotatable Air Guide
ETS-T50A-DFP, a variant of ETS-T50 AXE coolers, is equipped with an
ENERMAX D.F. PRESSURE fan that can generate high static pressure up to
4.812mm-H
Dust Free Rotation fan technology, Pressure Differential Flow design and 5 x
Ø6mm heat pipes, offering users an outstanding cooling solution with powerful
250W+ TDP support. The included Rotatable Air Guide is a smart gadget for
airflow direction adjustment. Last but not least, the fan comes with the
patented smart APS (Adjustable Peak Speed) control to satisfy different users’
cooling needs and achieve a perfect balance between cooling performance
and silent operation.
Features
Patented PDF (Pressure Differential Flow) design
By using differential wind pressure, the PDF design is to
squeeze the air flow to pass through the cone-shaped
tunnel rapidly. This patented design can help increase
15% more airflow and enhance the cooling performance.
O. This high-performance side-flow CPU cooler features patented
2
O
2
ETS-T50A-DFP
+ 15%
airflow
Patented Air Guide with rotatable grill for
preferred airflow direction adjustment
directly toward the rear case fan area
Asymmetric heat pipe design allows extra space
for ideal RAM compatibility
360º
Page 3
Patented DFRTM (Dust Free Rotation) technology* instantly blows away the dust to prolong the lifespan
1. Patented DFR blows away the dust (full speed)
Within 10 sec.
2. Shift back to normal spin (PWM)
After 10 sec.
With DFR technology Without DFR technology
After 6 months
Unique air path creating high VEF (Vacuum Effect) to optimize the airflow
ETS-T50 AXE –
no air leaks from sides
Other coolerair leaks from sides
Patented VGF (Vortex Generator Flow) to increase air convection around the heat pipe
(more dust accumulates)
ETS-T50 AXE Other cooler
High Pressure Technology
High pressure blade design is a precision engineering of the blade angle and shape calculation. The blades centralize dispersed
air flow to the center of the fan and create extremely high air pressure high airflow while maintaining outstanding quietness.
ETS-T50 AXE –
D.F.Pressure
Other cooler –
Normal fan
3-Cooling modes:
Performance mode: 800~2000 RPM
Silence mode: 800~1500 RPM
Patented APS (Adjustable Peak Speed) control
Ultra silence mode: 800~1000 RPM
providing 3 peak rpm options
Page 4
HDT (Heat-pipe Direct Touch) technology to
ensure rapid thermal conduction and eliminate
CPU hot spots
Gen. 2 TCC (Thermal Conductive Coating) creates
better velocity of thermal transferring and
prevents oxidation
Dow Corning® TC-5121 (3g) thermal grease for
perfect thermal conduction between CPU and the
heat sink
Enermax (Dow Corning-TC5121)
Source: Hardware secrets(2011)
ENERMAX (Dow Corning-TC5121) compound performed
wonderfully.
“1-clip” fan bracket design for user-friendly
installation
Durable metal installation kits offer universal
AMD & Intel desktop CPU compatibility with
durable metal brackets
Page 5
Dimension
unit:mm
Specifications
Compatible Socket
ETS-T50A-DFPETS-T50A-DFP
®
LGA 775/115X/1366/2011/2011-3,
Intel
®
AMD
AM4/AM3/AM3+/AM2/AM2+/FM1/FM2/FM2+
Overall Dimension
Heat Sink Dimension
Weight
Heat Pipe
Material
Thermal Grease
Fan Dimension
Fan Speed (RPM)
Air Flow (CFM)
3
Air Flow (m
/h)
Static Pressure (mm-H
Noise (dBA)
Rated Voltage
Bearing Type
MTBF
138.7(L) x 112.5(W) x 160(H) mm
135.2(L) x 65(W) x 160(H) mm
860g (w/ fan)
5 x Ø6 mm
Copper Heat Pipes / Aluminum Fins
®
Dow Corning
TC-5121
120 x 120 x 25 mm
800 ~ 1000
33.69 ~ 42.30
57.24 ~ 71.87
O)
2
0.819 ~ 1.358
16 ~ 18
800 ~ 1500
33.69 ~ 66.87
57.24 ~ 113.61
0.819 ~ 2.701
16 ~ 23
800 ~ 2000
33.69 ~ 85.43
57.24 ~ 145.15
0.819 ~ 4.812
16 ~ 27
12V
Twister Bearing
≥ 160,000 hours
Connector
Barcode
Box Dimension
Gross Weight / box
Carton Dimension
Gross Weight / Carton
4 pin PWM connector
Shipping Information
EAN:4713157722720 / UPC:816163008940
222 x 175 x 130 mm
1390g
460 x 370 x 295 mm
12.5kg (8 units per carton)
www.enermax.com
©
2017 ENERMAX TECHNOLOGY CORPORATION. All rights reserved. Specifications are subject to change without notice. Content of delivery might differ
in different areas or from illustrations. Some trademarks m ay be claimed as the property of o thers.
Mar. 2017
