Page 1
High performance CPU air cooler
www.enermax.com
ETS-T50A-BVT
Page 2
High performance CPU air cooler
250W+ TDP support for superior cooling performance
Patented PDF design to increase 15% more airflow
12cm Dust Free Rotation technology fan
Patented Rotatable Air Guide
ETS-T50 AXE, a high-performance side-flow CPU cooler with 5 x Ø6mm
heat pipes, features a 12cm DFR
patented Pressure Differential Flow (PDF) design, offering users an
outstanding cooling solution with powerful 250W TDP support. The patented
Rotatable Air Guide is an ideal design for preferred airflow direction adjustment. With a patented circular-type 3-color LED fan, ETS-T50 AXE can
deliver dazzling LED lighting effects and help gaming enthusiasts create a
personalized look that matches their styles.
TM
(Dust Free Rotation) technology fan and
Features
Patented PDF (Pressure Differential Flow) design
By using differential wind pressure, the PDF design is to
squeeze the air flow to pass through the cone-shaped
tunnel rapidly. This patented design can help increase
15% more airflow and enhance the cooling performance.
ETS-T50A-BVT
+ 15%
airflow
Patented Air Guide with rotatable grill for
preferred airflow direction adjustment
directly toward the rear case fan area
360º
Asymmetric heat pipe design allows extra space for ideal RAM compatibility
Page 3
Patented DFRTM (Dust Free Rotation) technology* instantly blows away the dust to prolong the lifespan
With DFR technology Without DFR technology
1. Patented DFR blows away the dust (full speed)
Within 10 sec.
Automatic LED self-testing will be activated during DFR mode
＊
2. Shift back to normal spin (PWM)
After 10 sec.
After 6 months
Unique air path creating high VEF (Vacuum Effect) to optimize the airflow
ETS-T50 AXE – no air leaks from sides Other cooler- air leaks from sides
Patented VGF (Vortex Generation Flow) to increase air convection around the heat pipe
(more dust accumulates)
ETS-T50 AXE Other cooler
ENERMAX Patented Circular Type with 36 diodes and autoplay LED modes
5 switchable VEGAS LED modes
Blue Red Green
Each LED mode comes with 3 autoplay lighting effects
Blue Vegas :
FLASH
Red Vegas : Green Vegas :
FLASH FLASH
3-color
combo
Combo Vegas :
Off
FLASH
All-onSparkle Flash
＊ Quick Off : Press the LED control button for 3 seconds for “OFF” mode
＊ Memory Function : The design will save the last mode which has been chosen before shutting down the system
All-onSparkle Flash
All-onSparkle Flash
All-onSparkle Flash
Page 4
HDT (Heat-pipe Direct Touch) technology to
ensure rapid thermal conduction and eliminate
CPU hot spots
Gen. 2 TCC (Thermal Conductive Coating) creates
better velocity of thermal transferring and
prevents oxidation
Dow Corning® TC-5121 (3g) thermal grease for
perfect thermal conduction between CPU and the
heat sink
Enermax (Dow Corning-TC5121)
Source: Hardware secrets(2011)
ENERMAX (Dow Corning-TC5121) compound performed
wonderfully.
“1-clip” fan bracket design for user-friendly
installation
Durable metal installation kits offer universal
AMD & Intel desktop CPU compatibility with
durable metal brackets
Page 5
Dimension
unit:mm
Specifications
Compatible Socket
ETS-T50A-BVTETS-T50A-BVT
®
LGA 775/115X/1366/2011/2011-3,
Intel
®
AMD
AM2/AM2+/AM3/AM3+/FM1/FM2/FM2+
Overall Dimension
Heat Sink Dimension
Weight
Heat Pipe
Material
Thermal Grease
Fan Dimension
Fan Speed
Air Flow
Static Pressure
Rated Voltage
Bearing Type
MTBF
Noise
LED
138.7(L) x 111.9(W) x 160(H) mm
135.2(L) x 65(W) x 160(H) mm
860g (w/ fan)
5 x Ø6 mm
Copper Heat Pipes / Aluminum Fins
®
Dow Corning
TC-5121
120 x 120 x 25 mm
800 - 1800 RPM
3
27.69 - 62.32 CFM / 47 - 105.8 m
2
0.38 - 1.93 mm-H
O
/h
12V
Twister Bearing
160,000 hours
18.9 - 25 dBA
Circular Type 36 diodes LED with autoplay modes
Connector
Barcode
Box Dimension
Gross Weight / box
Carton Dimension
Gross Weight / Carton
4 pin PWM connector
Shipping Information
EAN:4713157722317 / UPC:816163008537
222 x 175 x 130 mm
1390g
460 x 370 x 295 mm
12.5kg (8 units per carton)
www.enermax.com
©
2016 ENERMAX TECHNOLOGY CORPORATION. All rights reserved. Specifications are subject to change without notice. Content of delivery might differ
in different areas or from illustrations. Some trademarks m ay be claimed as the property of o thers.
Jun. 2016
