Page 1
www.enermax.com
ETS-T40F-BKA
Page 2
•Support 200W TDP
•100% RAM compatibility
®
•Intel
Skylake (LGA 1151) support
CPU cooler
ETS-T40F-BKA
Features
Compact side flow air cooler with fully RAM compatibility of all kinds
○
Outstanding cooling performance : Thermal resistance 0.117°C/W
○
- VGF (Vortex Generator Flow), to increase air convection in-between the fins
- VEF (Vacuum Effect Flow), to optimize airflow inside the cooler
- HDT (Heat-pipe Direct Touch), to improve thermal conductivity
Unique TCC (Thermal Conductive Coating) on heatsink, to create better velocity of thermal transferring
○
and to prevent oxidation
4 x Ø6mm high performance heat pipes to improve heat conductivity
○
Patented circular type LED fan for utmost and eye-catching light effects
○
Dual fan installation option
○
High thermal conductivity grease to ensure the best thermal conduction between CPU and the heat sink
○
Easy and solid Installation :
○
- All-in-one back-plate design offers universal AMD & Intel desktop CPU compatibility
- Durable metal mounting plate
”1-Clip” fan bracket design for user-friendly installation
○
Page 3
Close-up for features
Patented VGF/VEF
HDT design “1-Clip” fan bracket
design
Twister Bearing technology Dimension
●
MTBF≧160,000 hrs
●
Low noise profile
●
Detachable fan blades
Specifications
Patented circular
LED fan
100% RAM compatibility
unit : mm
Compatible Socket
Heat Sink Dimension (mm)
Weight
Heat Pipe
Material
Thermal Grease
Fan Dimension (mm)
Speed
Air Flow
Air Pressure
Fan
Rated Voltage
Bearing Type
MTBF
Noise
Connector
ETS-T40F-BKETS-T40F-BKAledoM ledoM
®
Intel
LGA775/1150/1151/1155/1156/1366/2011/2011-3
®
AMD
AM2/AM2+/AM3/AM3+/AM4/FM1/FM2/FM2+
126(L) x 40(W) x 161.7(H)
460g
4 x Ø6 mm
Copper Heat Pipes / Aluminum Fins
®
Dow Corning
TC5121
120 x 120 x 25 mm
800-1800 RPM
33.26 ~ 75.98 CFM
0.97 ~ 2.28 mmH
O
2
12V
Twister Bearing
160,000 hours
16 ~ 26dBA
4 pin PWM connector
www.enermax.com
©
2015 ENERMAX TECHNOLOGY CORPORATION. All rights reserved. Specifications are subject to change without notice. Content of delivery might differ
in different areas or from illustrations. Some trademarks may be claimed a s the property of ot hers.
Jul. 2015
