Support Addressable RGB Lighting Synchronization
Spacious Interior Supports E-ATX Motherboard
Movable HDD Cage for 20cm PSU Installation
MAKASHI MK50, an addressable RGB-ready chassis, is characterized by a
brilliant RGB lighting strip in the front, a movable HDD cage for longer PSU
installation, a tempered glass side window, and versatile cooling support. The
roomy E-ATX chassis offers 3 designated mounting positions for liquid coolers
and can accommodate up to 8 fans, providing gamers and modders with great
flexibility in cooling configuration. MAKASHI MK50 is absolutely a great choice for
users to design their own masterpiece.
Features
Simple and decent exterior design
Unique lightning-shaped RGB strip in the front
panel creates a visually appealing look; the lighting
of the strip can be easily controlled via a button on
I/O (13 pre-set effects)
Addressable RGB lighting synchronization
Support synchronizable RGB Lighting via motherboards with
header (4-Pin assignment is +5V/D/-/G). Users can program
preferred lighting effects via the motherboard software with
16.8 million color options
*Press and hold Lighting Control for 3 seconds to switch M/N sync and case control
Page 3
Support E-ATX motherboard
Spacious interior supports E-ATX, ATX,
Micro-ATX, and Mini-ITX motherboards
Mini-ITX
Micro-ATX
ATX
E-ATX
Movable HDD cage
Movable HDD cage can create extra space for
longer PSU (max. 20cm) installation
258mm
Versatile water cooling options
Flexible cooling system configuration supports
3 x designated areas for liquid cooler installation
Liquid Cooler Compatibility Chart
Radiator size 360mm 280mm 240mm 140mm 120mm
Front
Top
Rear
Page 4
Advanced ventilation system to support up to 8x fans
Rear (exhaust)
1 x 120mm fan
(1 x 120mm fan included)
PSU tunnel (exhaust)
1 x 120mm fan
Top (exhaust)
2 x 140mm / 3 x 120mm fan
or
360mm / 280mm / 240mm
liquid cooler supported
Front (intake)
3 x 120mm fan
or
360mm / 240mm
liquid cooler supported
Flexible system configuration
2.5”
HDD/SSD
2 x 3.5”/2.5”
HDD/SSD trays
2.5”
HDD/SSD
2.5”
HDD/SSD
2.5”
HDD/SSD
CPU Heatsink
Max. Height:
160mm
Graphic Card
Max. Length: 410mm
4mm panoramic tempered glass window
4mm full-view tempered glass side panel allows
you to show off your rigs
Page 5
Anti-dust rubber plugs
PSU-Tunnel design
PSU-Tunnel design (aka PSU shroud)
The design minimizes the cable clutter, which
makes the system clean and neat, and helps
improve the air circulation
Dimensions
unit: mm
452
216
212
475
495
Page 6
Specifications
Model Number
Drive Bays
Expansion Slots
Fan Slots
Dimensions
Material
M/B Type
LED Strips
I/O
3.5”
2.5”
Front
Top
Rear
ECA-MK50-BB-ARGB
D452 x W212 x H495mm
SPCC, T=0.6mm
E-ATX, ATX, Micro ATX, Mini ITX
Addressable RGB
Pin assignment: 5V / D / - / G
USB3.0 x 1, USB2.0 x 2, HD Audio, Lighting control
2
6 (2 x Converted from 3.5”HDD tray)
7
3 x 120mm
2 x 140mm or 3 x 120mm
1 x 120mm ( 1 x 120mm fan pre-installed )
Liquid Cooling
Clearance
Barcode
Carton Dimensions
Gross Weight
Net Weight
PSU
PSU Tunnel
Front
Top
Rear
EAN
UPC
1 x 120mm
360mm / 240mm
360mm / 280mm / 240mm
120mm
180mm / 200mm (Moving HDD cage forward)
Suggested VGA Card Length: 410mm
Suggested CPU Cooler Height: 160mm
Shipping Information
4713157724014
819315024010
D535 x W270 x H520mm
8kgs
6.8kgs
*Options vary by countries or regions.
www.enermax.com
©
2019 ENERMAX TECHNOLOGY CORPORATION. All rights reserved. Specifications are subject to change without notice. Content of delivery might differ
in different areas or fro m illustrations. Some trademarks m ay be claimed as the property of o thers.
Mar. 2019
