Page 1
www.enermax.com
Page 2
High density sound insulation foam with removable
top cover
4mm panoramic glass window with cushion foam
which combines the silence and aesthetics
Extensive cooling potential - flexible cooling system
configuration supports 360/280/240mm radiators or
up to 9 fans
EQUILENCE is a top-end, silent computer chassis featuring high
density insulation foam on the front, right, and top panel to minimize
the noise. With extensive cooling potential, EQUILENCE can
support multiple radiators and fans. EQUILENCE comes with 4mm
tinted panoramic tempered glass panel for users to show off their
precious rigs. This premium silent case incorporates LED lighting
surrounding the I/O and ENERMAX logo as power-on indicator,
which perfectly blends elegant aesthetics with practicality.
Features
Glossy finish front panel for an exquisite look
EQUILENCE comes with a glossy finish front panel
for simple yet refreshing looks.
LED backlit I/O panel with anti-dust rubber plugs
Backlit I/O includes 2 x USB3.0, 2 x USB2.0, and HD audio socket; anti-dust plugs are included.
Page 3
Integrated 3-speed fan controller
Integrated 3-speed fan controller connecting up to 6 fans allows the user to reach the preferred balance
between silence and cooling performance.
4mm panoramic glass window with
sound-dampening cushion
The 4mm tinted tempered glass side
panel with insulation cushion not only
allows you to show off your rig,
but also provides silent performance.
High density sound insulation foam
Premium foam is used on the front, top, and
right sides of the case for ultimate silence,
together with removable top cover which also
provides an option for extra cooling.
Page 4
Solid structure with ample space
Constructed of 0.8 mm sturdy steel,
EQUILENCE offers spacious interior
design for large, high-end components.
Extensive liquid cooling potential
Flexible cooling system configuration
supports 4 designated locations for
liquid cooler installation.
Liquid Cooler Compatibility Chart
1 x 140/120mm fan
(1 x 140mm silent fan included)
Advanced ventilation
system with support
of up to 9 fans
Rear (exhaust)
Radiator size (mm)
Front
Top
Rear
Side
Top (exhaust)
3 x 120mm fan/2 x 140mm fan
360/280/240mm liquid
cooler supported
360
●
●
or
280●240
2x 120mm or 240mm
liquid cooler supported
3 x 120mm or 360/240mm
liquid cooler supported
(2 x 120mm silent fan included)
*
140
●
●
●
Side (exhaust)
Front (intake)
●
●
120
●
●
●
●
ECA3511A-BB only
*
Page 5
Flexible system configuration
Supports up to 2 x 3.5” HDD, and 6 x 2.5 SSD/HDD (2 x Converted from 3.5” tray) to satisfy your storage needs.
2.5”
HDD/SSD
2.5”
HDD/SSD
2 x 3.5”/2.5”
HDD/SSD trays
2.5”
HDD/SSD
2.5”
HDD/SSD
CPU Heatsink
Graphic Card
Max. Length: 420mm
Max. Height: 175mm
PSU-Tunnel design (aka PSU shroud)
The design minimizes the cable clutter to
make the system clean and neat, which
helps improve the air circulation.
Support the latest long VGA
card and tall CPU cooler
PSU-Tunnel Design
Page 6
Specifications
Model Number
Dimensions
Material
M/B Type
Drive Bays
Expansion Slots
Fan Slots
Liquid Cooling
I/O
3.5"
2.5"
Front
Top
Rear
Side
Front
Top
Rear
ECA3511A-BBECA3510A-BB
D500 x W235 x H510 mm
0.8mm SPCC
ATX, Micro ATX, Mini ITX
USB3.0 x 2, USB2.0 x 2, HD Audio, Fan controller
2
6 (2 x Converted from 3.5” trays)
7
3 x 120mm 3 x 120mm (2 x 120mm fan pre-installed)
2 x 140 or 3 x 120mm
1 x 140 / 120mm (1 x 140mm fan pre-installed)
2 x 120mm
360 / 240mm radiator
360 / 280 / 240mm radiator
140 / 120mm radiator
Side
PSU
Maximum Compatibility
EAN
Barcode
UPC
Carton Dimensions
Gross Weight
Net Weight
*Options vary by countries or regions.
240mm radiator
Standard ATX Type
VGA Card Length: 420mm (280mm with side radiator)
CPU Cooler Height: 175mm
Shipping Information
4713157723314
819315023310
4713157723406
819315023402
D579 x W320 x H598mm
11.72 kgs
9.78 kgs
11.92 kgs
9.98 kgs
www.enermax.com
©
2017 ENERMAX TECHNOLOGY CORPORATION. All rights reserved. Specifications are subject to change without notice. Content of delivery might differ
in different areas or fro m illustrations. Some trademarks m ay be claimed as the property of o thers.
Sep. 2017
