Energy pI0 Panoramic User Manual

ENERGY

Photo Frame

p10

Panoramic

DIGITAL PHOTO FRAME

Manual de usuario / User manual
Manuel de l’utilisateur / Manual do Utilizador

23

ESPAÑOL

User manual

25

ENGLISH

INTRODUCTION

≥

Energy Sistem® thanks you for buying your new digital photo frame Energy™
Photo Frame p10. We wish you enjoy using it.

This digital photo frame is a perfect gift to remember the most special moments,
it offers exceptional picture quality with the 10.1” LED High Definition screen.
Furthermore, it also offers functions such as calendar, clock, card reader and USB
Host.

We recommend that you fully read this user manual in order to enjoy the product in
a safe way and with the best results.

CARE AND MAINTENANCE

≥

Do not expose your Energy™ Photo Frame to collisions, violent shakes, dust, direct
sun light, moisture or extreme temperatures.

≥ Do not use abrasive or corrosive cleansers.
≥ Keep the device clean and dust free with a soft and dry cloth. We recommend you

to use the provided cleaning cloth.

≥ Clean the unit while it is turned off and unplugged from electric power.
≥ Do not disassemble the device. Any repairs must be performed by the qualified

Energy Sistem Soyntec´s personnel.

26

MAIN FEATURES

≥

10,1” TFT LED backlight 16:9 screen.

≥ 1024x600 pixels resolution, 250cd / m2, 500:1.
≥ Compatible with the JPEG/JPG/BMP pictures of the majority of the digital cameras

with maximum resolution 8000 x 8000 pixels.

≥ Compatible with memory cards: MMC / MS / SD / SDHC (up to 32GB).
≥ USB Host connector to load pictures from your USB flash drive (up to 32GB).
≥ Selection of pictures by miniatures on screen and starting Slide Show from the

selected picture.

≥ Slide Show with Magic Window mode (4 windows).
≥ Several time intervals for the Slide Show (5/15/30 sec., 1/5/15 min.).
≥ Different transition effects for the Slide Show (6 effects including random mode).
≥ Calendar and clock functions with photo Slide Show at the same time.
≥ Automatic image fit (3 modes: Auto-Fit, Optimal and Full).
≥ Brightness, contrast, color and tone adjustments.
≥ Allows 90º, 180º and 270º picture rotation.
≥ 5 levels of zoom available.

27

ENGLISH

≥ File browser function.
≥ Slim remote control.
≥ AC/DC power adapter (Europlug). Input 100-240V; Output 5V/1.5A; 50/60Hz.
≥ Includes mounting holes on the back to be fixed to the wall.

PRODUCT CONTENT

≥

Energy Sistem® Digital Frame Energy™ Photo Frame p10 Panoramic.

≥ Stand.
≥ User manual.
≥ Screen cleaning cloth.
≥ Slim remote control.
≥ AC/DC power adapter (Europlug).

28

GENERAL OVERVIEW

MENU

8

1

2

4

7

5

6

3

9

10

11
