Printer Server
Command Reference Guide
Revision 5.0
ER2053501-00A
Information contained in this document is believed to be accurate and reliable. However,
Emulex Corporation assumes no responsibility for its use nor for any infringements of patents
or other rights of third parties which may result from its use. Emulex Corporation reserves the
right to change product specifications at any time without notice.
The following trademarks of Emulex Corporation are used in this document:
The following are trademark acknowledgments:
Emulex
NETQue
NETQue Mate
NETQue Pro2
NETQue Token Ring
NETJet
enstall
rprint
UNIX is a trademark of AT&T Bell Laboratories
Novell and NetWare are trademarks of Novell Corporation
AppleTalk is a trademark of Apple Computer
Other brands and product names are trademarks of their respective companies.
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense. Shielded cables must be used between this equipment and
attached peripheral devices. The reader is cautioned that changes or modifications made to the
equipment not expressly approved by Emulex could void the user’s authority to operate this
equipment.
The above statement applies to products marketed in the U.S.A.
This class A digital apparatus meets all requirements of the Canadian Interference - Causing
Equipment Regulations. Cet Appareil numerique de la classe A respecte toutes les exigences
du reglement sur le material brouilleur du Canada.
The above statement applies to products marketed in Canada.
Emulex Corporation
3535 Harbor Boulevard
Costa Mesa, CA 92626
Copyright © 1995 Emulex Corporation. All rights reserved worldwide. No part of this
document may be reproduced by any means nor translated to any electronic medium without
the written consent of Emulex Corporation.
Table of Contents
CONVENTIONS.....................................................................................................................1
ORMATTING.................................................................................................................... 1
F
WHAT IS A COMMAND? ....................................................................................................1
C
OMMAND LINES .............................................................................................................2
ROMPTS..........................................................................................................................2
P
EYWORDS ...................................................................................................................... 2
K
ARIABLES ...................................................................................................................... 2
V
PTIONS...........................................................................................................................3
O
UOTATION MARKS.........................................................................................................3
Q
KEYWORD FUNCTIONS.....................................................................................................4
S
ET, DEFINE AND CHANGE .............................................................................................. 4
HOW, MONITOR AND LIST.............................................................................................. 5
S
LEAR, PURGE AND DELETE............................................................................................ 5
C
COMMAND SUMMARY ...................................................................................................... 6
GENERAL COMMANDS.................................................................................................... 10
ISPLAY INTERNAL ARP TABLE.................................................................................... 10
D
ALT PRINTER SERVER.................................................................................................. 10
H
ELP .............................................................................................................................. 10
H
NITIALIZE...................................................................................................................... 11
I
ELOW MIO VERSION 6.0...................................................................................... 11
B
OGOUT ......................................................................................................................... 12
L
HECK IP ADDRESS - PING............................................................................................. 12
C
PDATE MEMORY - SYNC .............................................................................................. 12
U
ii Command Reference Guide
PASSWORDS ....................................................................................................................12
PRIVILEGED ACCESS ...................................................................................................... 12
ET PRIVILEGE PASSWORD............................................................................................. 13
S
HANGE LOGIN PASSWORD ........................................................................................... 13
C
EMOTE CONSOLE PASSWORD....................................................................................... 13
R
NODE COMMANDS............................................................................................................ 14
S
HOW NODE................................................................................................................... 14
STABLISH OR CHANGE TCP/IP NODES......................................................................... 14
E
EFINE NETWARE NODE ............................................................................................... 16
D
ELETE NODE ................................................................................................................ 16
D
PORT COMMANDS ............................................................................................................ 17
S
HOW PORT CHARACTERISTICS...................................................................................... 17
EST PORT ..................................................................................................................... 17
T
HANGE PORT ACCESS .................................................................................................. 18
C
HANGE PORT TYPE....................................................................................................... 19
C
HANGE LINE FEED CHARACTER................................................................................... 19
C
HANGE PORT SPEED.....................................................................................................20
C
HOW PORT STATUS - NETJET ...................................................................................... 20
S
SERVER COMMANDS ....................................................................................................... 21
D
EFINE SERVER NAME................................................................................................... 21
HOW ALARMS .............................................................................................................. 21
S
HOW SERVER CHARACTERISTICS ................................................................................. 22
S
HOW SERVER CONFIGURATION .................................................................................... 22
S
HOW SERVER STATUS .................................................................................................. 22
S
ISPLAY NETWORK CHARACTERISTICS ......................................................................... 22
D
HOW SERVER LIMITS....................................................................................................23
S
ET CONSOLE TERMINAL PORT......................................................................................23
S
THER OPTIONS............................................................................................................. 24
O
ET PROMPT...................................................................................................................25
S
ODIFY SNMP.............................................................................................................. 25
M
HANGE DOMAIN........................................................................................................... 26
C
Table of Contents iii
PROTOCOLS ....................................................................................................................26
ENABLE OR DISABLE PROTOCOLS .................................................................................. 26
HOW NETBIOS CHARACTERISTICS................................................................................ 27
S
PPLETALK.................................................................................................................... 27
A
HOW SERVER APPLETALK ................................................................................... 27
S
PPLETALK BACKSPOOFING .................................................................................27
A
EFINE TBCP - APPLETALK.................................................................................. 27
D
HOW FONTS - APPLE............................................................................................ 28
S
DD FONTS - APPLE .............................................................................................. 28
A
EMOVE FONTS - APPLE........................................................................................ 28
R
LAT............................................................................................................................... 30
HANGE GROUPS................................................................................................... 30
C
HOW SERVER ....................................................................................................... 30
S
HANGE AUTHORIZED GROUPS............................................................................. 31
C
ETWARE COMMANDS.................................................................................................. 31
N
EFINE PASSWORD................................................................................................ 31
D
EFINE NETWARE NODE....................................................................................... 31
D
HOOSE FRAME TYPE............................................................................................ 32
C
ISPLAY CHARACTERISTICS .................................................................................. 32
D
EFINE REQUIRED FILESERVER............................................................................. 33
D
EFINE AS REMOTE PRINTER.................................................................................34
D
EDISCOVER INTERVAL......................................................................................... 34
R
DJUST PROCESSING SPEED .................................................................................. 34
A
ORMS................................................................................................................... 35
F
ELECTING BINDERY EMULATION OR NDS MODE ................................................ 35
S
EFINE CONTEXT - NDS .......................................................................................35
D
EFINE NDS TREE ................................................................................................36
D
TCP/IP
B
COMMANDS....................................................................................................... 36
HANGE TCP/IP ROUTING .................................................................................... 36
C
STABLISH OR CHANGE TCP/IP NODES ................................................................ 37
E
HOW TCP/IP CHARACTERISTICS.......................................................................... 38
S
OOTP, DHCP AND RARP PARAMETERS...................................................................... 38
EFINE BOOTP PARAMETERS................................................................................ 38
D
EFINE DHCP PARAMETERS.................................................................................39
D
EFINE RARP PARAMETERS................................................................................. 39
D
iv Command Reference Guide
LOAD/DUMP CONFIGURATION.....................................................................................40
DEFINE TCP/IP LOAD HOST........................................................................................... 40
EFINE SERVER LOAD....................................................................................................40
D
EFINE SOFTWARE FILE NAME ...................................................................................... 41
D
ET LOAD/DUMP GATEWAY .......................................................................................... 41
S
ET DUMP HOST............................................................................................................. 42
S
EFINE TCP/IP DUMP HOST.......................................................................................... 42
D
SERVICE COMMANDS...................................................................................................... 44
C
HANGE SERVICE........................................................................................................... 44
EFINE SERVICE............................................................................................................. 45
D
ELETE SERVICE............................................................................................................45
D
HOW SERVICE............................................................................................................... 45
S
Command Reference Guide 1
Conventions
This guide provides the correct syntax for commands used with Emulex
printer servers containing software release 5.0. This section describes
both general and command conventions used in this document and in
other printer server documentation.
NOTE: The user must login to the printer server to
perform an Emulex printer server command.
Formatting
You will notice text boxes labeled NOTE or CAUTION.
• Notes provide additional information.
• Caution statements provide warnings to prevent harm to people or
equipment.
CAUTION: Observe electrostatic discharge (ESD)
procedures during installation.
What is a Command?
A prompt, followed by a keyword and one or more variables, options or
quotation marks make up a command. The following explanation will
demonstrate the structure and formatting of 5.0 printer server commands.
2 Command Reference Guide
Command Lines
A command line begins with the symbol >, contains the word “Server”
and a prompt.
Prompts
A prompt consists of the word Server followed by one or two greater
than symbols (>). One (>) indicates nonprivileged status and two (>>)
signify privileged or supervisor status. The two prompts are shown
below:
Server > (nonprivileged users)
Server >> (privileged users)
Nonprivledged users have read only privileges. Privileged or supervisor
users have all read and write privileges.
Keywords
Keywords are enclosed in brackets and separated by vertical lines.
The user must enter a keyword to perform an action.
Variables
Variables are used as in mathematics: they represent a quantity, device
name, address or other entity. They are shown in bold italic type.
Server>> [set |define |change]
>
Server>> [set |define |change] server dhcp n m
>
n a variable
m a variable
Command Reference Guide 3
Options
Options are used to customize a command. When available, the user
should always use options. They are italicized and enclosed in brackets.
Server>> [set |define |change] server dhcp n m
>
[temp] [default]
temp an optional entry
default an optional entry
Quotation Marks
When case-sensitive information is required, it must begin and end with
quotation marks. Font names are case-sensitive and must appear in
quotes within command lines. The example below illustrates the use of a
font name within a command line.
Server>> change port 1 fonts add “Courier-Bold
>
Helvetica-Italics”
4 Command Reference Guide
Keyword Functions
Keywords either modify data (set, define or change), remove data (clear,
purge, or delete), or display requests (show, monitor, or list).
Set, Define And Change
set Modifications are immediate and temporary
(stored in volatile memory). Old port values will
return when the port is logged out. Old node,
server and service values return when the
printer server is reinitialized.
define Modifications are not immediate but once they
take effect, become permanent (stored in nonvolatile memory). Modifications to ports take
effect when port is logged out. Modifications to
nodes, servers and services take effect when
the printer server is reinitialized.
change Modifications are immediate and permanent.
NOTE: Commands which affect non-volatile memory
will cause a 30 second delay before nonvolatile memory is updated. If printer server
power is removed prior to this, the change will
be lost.
Command Reference Guide 5
Show, Monitor And List
show Displays current information stored in volatile
memory.
monitor Similar to show, except the display is updated
every second for privileged users or every 10
seconds for nonprivileged users.
list Displays information stored in non-volatile
memory.
Clear, Purge And Delete
clear Data is removed temporarily, but returns at next
reinitialization.
purge Data is not removed until reinitialization, but then
is removed permanently from non-volatile
memory.
delete Data is removed immediately and permanently.
6 Command Reference Guide
Command Summary
In the summary below, all commands are presented alphabetically. If the
keywords are either set, define or change, only change is listed. Page
numbers are provided as a quick directory to find an explanation of the
command.
arp [
change node node_nam ip ip_address [tcpip] [gateway
change port port_num [input |output] speed baud_rate 20
change port port_num access [dynamic |local |remote
change port port_num authorized groups group_list
change port port_num fonts add “font_list” 28
change port port_num fonts remove “font_list” [all] 28
change port port_num mapcrlf [enabled |disabled] 19
change port port_num type [ansi |hardcopy |softcopy] 19
change server console port_num 23
change server domain domain_name 26
change server dump [enabled |disabled] 42
change server groups group_list [enabled |disabled] 30
change server login password “pass_txt” 13
change server maintenance password “pass_txt” 13
change server name prntsvr_name 21
change server netware context “con_txt” 35
change server netware fast printserver [enabled
change server options option_list [enabled |disabled] 24
change server rarp n m [temp]
change server route IP dest_ip gateway gwy_name gwy_ip 36
change server snmp com_name access acc_right [trap IP 25
-a] [-b] [-d] [-f] [-l] [-s] [-t]
[default]] [syslog facility]
|virtual |slprt |none]
[enabled |disabled]
|disabled]
10
14
18
31
34
39
Command Reference Guide 7
ip_addr] [set] [enabled |disabled]
change service
[TCPport_num] [password “pass_txt”] [protocol]
[enabled |disabled]
crash 300 10
define node node_name [nfserver |npserver] 16
define port port_num appletalk backspoof [enabled
|disabled]
define port port_num appletalk tbcp [enabled
|disabled]
define server authorize protocol [all |none
specific] [enabled |disabled]
|
define server bootp n m [temp] 38
define server dhcp n m [temp] 39
define server gateway [load_dump] ip [ip_address
“servc_name” [port port_num]
|none]
define server load [selfload |TFTP [put] |decnet] 40
define server netware [default |802.2 |snap |802.3
|ethernet_II ether_type]
define server netware forms [enabled |disabled] 35
define server netware nds “tree_name” 36
define server netware password “pass_txt” 31
define server netware pserver [auto |disabled |3.x
|4.x]
define server netware rediscover minutes 34
define server netware required [enabled |disabled] 33
define server netware rprinter [enabled |disabled] 34
define server preferred dump ip ip_address 42
define server preferred load ip ip_address 40
define server software file_name 41
define service “servc_name” appletalk type “prn_type” 45
delete node node_name [all |ip ip_address |tcpip
|gateway |nfserver |npserver |syslog]
delete service “servc_name” 45
44
27
27
26
41
34
35
16
8 Command Reference Guide
help 10
initialize [server] [delay delay_min] [cancel]
[flash] [default] [disabled]
logout [port port_num]
ping ip_address 12
set server privilege password “pass_txt” 13
set server prompt “prompt_txt” 25
show node node_name [gateway |syslog |nfserver
|npserver]
show port port_num characteristics 17
show port port_num fonts 28
show port port_num status [netjet |device] 20
show server alarms 21
show server appletalk 27
show server characteristics 22
show server config [port port_num] [ps]
show server LAT 30
show server limits 23
show server netbios 27
show server netware 32
show server network 22
show server status 22
show server tcpip 38
show service “servc_name” characteristics 45
su 12
sync 12
test port_num count count_num 17
11
12
14
22
In the remaining portion of this guide, commands are grouped by their
effect.
Command Reference Guide 9
• General Commands
• Passwords
• Node Commands
• Port Commands
• Server Configuration
• Protocols
• Load/Dump Configuration
• Service Commands
10 Command Reference Guide
General Commands
Display Internal ARP Table
Display or control the printer server’s internal address resolution
protocol (ARP) table.
Server>> arp [-a] [-b] [-d] [-f] [-l] [-s] [-t]
>
-a Displays the ARP table.
-b Caches all ARP entries broadcast on the
-d Deletes specified IP address entry.
-f Fixes all entries in the table (turns off timer).
-l Caches only locally addressed mappings.
-s Allows addition of the server IP and MAC
addresses.
-t Turns on timer.
At least one option must be entered, but only one option can be specified
in a single arp command.
network.
Halt Printer Server
Stop printer server causing memory dump to the dump host and printer
server reinitialization. All users are logged off and all sessions are
disconnected without any warning.
Server>> crash 300
>
The entire command “crash 300” must be entered to be effective.
Help
Refers the user to the User Guide for Emulex Printer Servers.
help
>
Command Reference Guide 11
Initialize
Initialize NETQue printer servers and NETJet printer servers installed in
Hewlett-Packard printers with MIO version 6.0 or above.
Server>> initialize [server] [delay delay_min]
>
[cancel] [flash] [default] [disabled]
server Reinitializes the printer server.
delay Indicates reinitialization will not take place until
after a specified period of time.
delay_min A number specifying the amount of delay in
minutes. The default is 1 minute.
cancel Cancels a previously entered initialize command
if entered within the delay time specified in the
initial command.
flash Causes printer server software to download
from the host to flash memory if the printer
server is configured for a network load.
default Resets the printer server to factory defaults. IP
address and subnet mask are reset to none.
disabled Prevents any connections after initialization. To
enable connections, enter the initialize
command through a remote console without this
option.
When the initialize printer server command is issued with a delay, a
warning message is sent every 30 minutes to all logged in ports. Five
minutes before initialization, the warning is broadcast every minute.
When the printer server is reinitialized, all options modified by Set
commands are reset to their permanent values, and all options modified
by Change and Define commands take effect.
Below MIO Version 6.0
The initialize command will not reset NETJet printer servers in Hewlett
Packard printers that do not have MIO version 6.0 or above. To reset
these printer servers, recycle power on the printer.
12 Command Reference Guide
Logout
Logout of a printer server port, disconnecting associated local or remote
sessions.
Server>> logout [port port_num]
>
port Enter this option along with the port_num to log
out of a port other than the one you are currently
using. Leaving this option out will logout of your
current port.
port_num The number of the port to be logged out.
Check IP Address - Ping
Test whether a local or remote IP address exists and is responding.
Server>> ping ip_address
>
ip_address Enter the IP address of the designated node in
decimal dot notation. For example,
123.234.345.490.
Update Memory - Sync
Immediately update non-volatile memory.
Server>> sync
>
This command ensures changes are written to non-volatile memory.
Use this command prior to initializing a NETJet printer server. MIO
versions 6.0 and above do not require a sync command with
initialization.
Passwords
Privileged Access
Designate user as a “super user” with privileged access.
Server> su
>
A super user is authorized to perform all functions on the printer server.
Command Reference Guide 13
Set Privilege Password
Change the password a user must enter in order to use privileged
commands.
Server>> set server privilege password
>
“password”
“password” Enter from 1 to 16 characters, enclosed in
quotes. Default is System. This produces the
same result as using the SU (super user)
command.
Change Login Password
Specify the password users must enter at login to the printer server.
Server>> [set |define |change] server login
>
password “pass_txt”
“pass_txt” Enter a password containing 1 to 16 characters,
starting with an alphabetic character and
enclosed in quotation marks. The default is
Access.
Remote Console Password
Specify the password that must be entered by remote console operators
to gain access to the printer server’s remote port.
Server>> [set |define |change] server
>
maintenance password “pass_txt”
“pass_txt” Enter a password containing 0 to 16
hexadecimal characters (0-9 and A-F) enclosed
in quotes. A password of “0” means that no
password is required. Default is no password.
14 Command Reference Guide
Node Commands
The length of node names is dependent on the protocol. Any
alphanumeric character may be used, along with: ‘$’, ‘-’, ‘_’, ‘.’.
• NetWare node names can have a maximum of 47 characters
• LAT node names can have a maximum of 16 characters
• TCP/IP node names can have a maximum of 63 characters
TCP/IP node names consist of a 1-16 character local node name and
a domain name of 1-47 characters. This TCP/IP full node name
always ends with a period (.).
A remote node must be specified by the full node name. A name on
the local network may be specified by the local node name alone if
the domain name for the local network has been set by the [Set
|Define |Change] Server Domain Name command.
Show Node
Show which nodes are known to the printer server.
Server>> [show |list] node [node_name] [gateway
>
|syslog |nfserver |npserver]
node_name Optional variable. Shows only the node whose
name you enter here.
gateway Shows all nodes designated as TCP/IP gateway
nodes. Gateway nodes allow communication
between segments on a network.
syslog Shows all nodes designated as TCP/IP syslog
nodes. Syslog nodes are designated to receive
events or errors.
nfserver Shows all the nodes designated as NetWare
Preferred File Server nodes.
npserver Shows all the nodes designated as NetWare
Remote Printer nodes.
Establish or Change TCP/IP Nodes
Establish or change a TCP/IP node.
Command Reference Guide 15
> Server>> [set |define |change] node node_name
ip ip_address [tcpip] [gateway [default]]
[syslog facility]
node_name Enter either the TCP/IP full node name or the IP
address of the node. See naming conventions
in beginning of this section.
ip_address The IP address of the designated node in
decimal dot notation. For example,
123.234.345.490
tcpip Establishes the node as a TCP/IP node in the
server’s internal node table.
gateway Establishes the node as a TCP/IP gateway,
which allows communication between segments
on a network.
default If entered along with the gateway option, defines
the TCP/IP gateway to be the first gateway seen
after the routing table is checked.
syslog Establishes the node as a TCP/IP syslog node,
which is designated to receive events or errors.
facility Entered with syslog, this option defines what
type of facility reporting is done (LPR, local0 to
local7). Default is LPR.
IMPORTANT: Since only 10 entries are allowed in
the permanent table, a Set command
may succeed when Define or Change
generates a node table full error.
16 Command Reference Guide
Define NetWare Node
Define NetWare nodes as a Remote Printer or Preferred File Server.
Server>> define node node_name [nfserver |npserver]
>
node_name The name of the node to be affected.
nfserver Defines the node as the Novell Preferred File
Server. Only one nfserver node may be defined.
npserver Defines the node to act as a Novell Remote
Printer. More than one npserver node may be
defined.
Delete Node
Remove nodes from the printer server’s internal node table.
Server>> [clear |purge |delete] node [node_name]
>
[all |ip ip_address |tcpip |gateway |nfserver
|npserver |syslog]
node_name Enter the name of the node to be deleted. This
is an optional entry.
all Enter this to delete all nodes except the one you
are on. All is the default.
ip_address Enter the IP address of the node to be deleted in
decimal dot notation. For example,
123.234.345.490
tcpip Removes the flag that designates the node as a
TCP/IP node in the printer server’s internal node
table.
gateway Removes the flag that designates the node as a
TCP/IP gateway, which allows communication
between network segments.
nfserver Removes the flag that designates the node as a
NetWare Preferred File Server.
npserver Removes the flag that designates the node as a
NetWare Remote Printer.
syslog Removes the flag that designates the node as a
TCP/IP syslog node; a node designated to
receive events or errors.
Command Reference Guide 17
Port Commands
Show Port Characteristics
Display the characteristics of a specified port.
Server>> [show |list] port port_num ch
>
port_num The printer server port number.
This command will display a detailed listing of all port options such as:
local group, hardware group, network group, LAT_compatible group,
and TCP/IP group.
Test Port
Verify the operation of a port by sending a test pattern of characters to
the port. Terminate the test by pressing any key.
Server>> test port_num count count_num
>
port_num The number of the port to be tested.
count_num Enter the number of times the test pattern will be
sent to the port. The default is 23.
Deviations observed in the pattern indicate problems with either the
device connected to the port or its cable connection to the printer server.
If using the test command on a port connected to a PostScript printer, the
printer will display an error condition.
18 Command Reference Guide
Change Port Access
Specify the type of connections (access) the port can make.
Server>> [set |define |change] port port_num
>
access [dynamic |local |remote |virtual |slprt
|none]
port_num Enter the port number whose access is being
modified.
dynamic Allows the port to originate and accept remotely-
originated connections. This is a combination of
remote and local access.
local Allows a device connected to the port to
originate connections and use the printer
server’s local-mode command set.
remote Restricts the port to receiving connections; it
cannot originate connections or use any of the
printer server’s local-mode commands. This
type of port is typically defined as a service.
virtual Restricts the port to usage as a transparent
gateway.
slprt Allows the serial port to be used as a parallel
port on the printer server. This parallel port
continues to accept remote LAN connections
when the serial port is quiet.
none Disables all access to the port.
Command Reference Guide 19
Change Port Type
Specify the type of terminal or printer connected to a port.
Server>> [set |define |change] port port_num
>
type [ansi |hardcopy |softcopy]
port_num Enter the port number.
ansi Specifies an ANSI-compatible terminal.
hardcopy Specifies hardcopy serial terminal like a
teleprinter with a keyboard.
softcopy Specifies a generic video display terminal.
Change Line Feed Character
Control the line feed character.
Server>> [set |define |change] port port_num
>
mapcrlf [enabled |disabled]
port_num List of ports to be affected by the command
separated by commas.
enabled Removes the line-feed (LF) character from the
carriage-return (CR) sequence.
disabled Allows the line feed character to remain with the
carriage return sequence.
This command is used in some Telnet session environments to strip the
LF character. The printer server terminates its commands with CR. The
LF character will inhibit the privileged password on the printer server,
making it invalid.
20 Command Reference Guide
Change Port Speed
Set the serial communication speed (baud rate) in bits per second.
Server>> [set |define |change] port port_num
>
[input |output] speed baud_rate
port_num The port affected by speed change.
input Enter the speed at which data is received. If
input speed is not chosen, the command sets
the speed in both directions.
output Enter the speed at which data is transmitted. If
output speed is not chosen, the command sets
the speed in both directions.
baud_rate Enter a speed: 75, 110, 134, 150, 300, 600,
1200, 2400, 1800, 2000, 2400, 4800, 9600,
19200, 38400.
Show Port Status - NETJet
Display port status for NETJet printer servers and MIO interfaces.
Server>> [show |monitor] port port_num status
>
[netjet |device]
port_num Enter the port number for which status is
desired.
netjet Gives the status for NETJet connected to MIO
interface (port 1).
device Gives the status of a Hewlett-Packard MIO
printer interface.
Command Reference Guide 21
Server Commands
Define Server Name
Define the printer server’s node name.
Server>> define server name prnsvr_nam
>
prnsvr_nam Enter a 1 to 16 character name for the printer
server. This must be established with the
Define command when any sessions are active.
Any alphanumeric character is valid.
The printer server’s node name is used in certain commands and by hostinitiated connections. The name must be different from all other node
names on the same local network if the printer server accepts hostinitiated connections or offers services.
Show Alarms
Show console error conditions.
Server>> show server alarms
>
This command displays the number of nonfatal console errors that have
occurred since the printer server was last booted, and the times and error
numbers of the sixteen most recent errors.
22 Command Reference Guide
Show Server Characteristics
Display the characteristics of the printer server.
Server>> [show |list] server characteristics
>
This command will display a detailed listing of all printer server options
such as local group, hardware group, network group, LAT_compatible
group, TCP/IP group, and port IP address. This information is not
continually updated since characteristic information does not change.
Show Server Configuration
Display port configuration information.
Server>> show server config [port port_num] [ps]
>
port_num Directs the output to the specified port number.
ps Puts the output in a PostScript format.
Show Server Status
Display the constantly changing printer server status information.
Server>> [show |monitor] server status
>
The monitor command continually updates the display information.
Display Network Characteristics
Display the printer server’s network characteristics.
Server>> [show |list] server network
>
Command Reference Guide 23
Show Server Limits
Display the current configurable memory table allocation.
Server>> [show |monitor] server limits
>
Trial values are available for five printer server resources: queue,
circuits, sessions, nodes and services.
The Show Server Limits command does not alter the limits, but allows
the user to experiment with trial values for these resources without
changing the actual limits in the printer server. For example:
Server>> show server limit nodes 256.
>
Set Console Terminal Port
Designate a printer server serial port as a console terminal port.
Server>> [set |define |change] server console
>
port_num
port_num Enter the printer server port number where the
console terminal will be connected. If a port
number is not designated, the lowest numbered
serial port will be assumed.
24 Command Reference Guide
Other Options
Enable or disable special printer server options.
Server>> [set |define |change] server options
>
option_list [all |enabled |disabled]
option_list Enter a list of options from the available options
section below.
all Enables all options.
enabled Adds the specified option to the existing option
list. If not specified, the existing list is replaced
by the new one.
disabled Removes a specified option from the existing
option list. The default is none -- all options
disabled.
Available options are:
0 Enable unknown frames (bypass protocol frame
filter).
2 Enable use of 0’s (not 1’s) in host portion of IP
broadcast address.
3 Pack Group Codes into smallest number of bytes.
4 Host Initiated Requests announce supported
services.
5 Print Information-Only messages to the console
port.
6 Print Non-Fatal error messages to the console
port.
7 Reserved.
8 Reserved.
9 Inhibit round robin port allocation.
10 Enable fast TCP/IP acknowledge to speed up
38400 baud and parallel ports.
11 Force an IP (or ARP) datagram to be sent out
when route cannot be found.
15 Enforce LAT Circuit Timer (slows performance
for bridged LAT usage and prevents timeouts).
Command Reference Guide 25
Set Prompt
Specify the prompt displayed when the printer server is in local mode
and awaiting a printer server command.
Server>> set server prompt “prompt”
>
“prompt” Enter 1 to 8 characters, enclosed in quotes.
The default is “server”. The printer server
always adds the string “>>“ after the prompt in
privileged mode or “>“ when not in privileged
mode. The RCF port will always display Local>.
Modify SNMP
Add or modify entries in the SNMP table or change the printer server’s
SNMP trap host IP address.
Server>> [set |define |change] server snmp
>
com_name access acc_right [trap IP ip_addr]
[set] [enabled |disabled]]
com_name The name of an SNMP community.
acc_right Specifies access privileges associated with the
community name: read, write, or read/write.
trap Establishes a trap host to receive messages
from the printer server.
ip_address Enter the IP address for the workstation that will
receive SNMP trap messages from the printer
server. The IP address must be entered in
decimal dot notation. For example,
123.234.345.490. The
set Allows an SNMP manager to perform set type
operations on the printer server.
enabled If enabled, SNMP set requests will be accepted.
disabled If disabled, SNMP set requests will be rejected.
26 Command Reference Guide
Change Domain
Specify the name of the local network’s domain or hierarchy within a
network.
Server>> [set |define |change] server domain
>
domain_name
domain_name The printer server’s domain name, which can
contain up to 48 alphanumeric characters
including periods.
Protocols
Enable or Disable Protocols
Enable or disable individual protocols.
Server>> define server authorize protocol [all
>
|none |specific] [enabled |disabled]
all Activates all protocols.
none Disables all protocols.
specific Select a protocol to be enabled from this list:
LAT, TCP, AppleTalk, NetWare, TES, or
NetBios).
enabled After selecting a specific protocol, enter this
command to activate it. Other protocols will be
disabled.
disabled Disables a specific protocol.
NOTE: If enable or disable is not included in
command, only the specified protocol will be
enabled. All others will be disabled.
Command Reference Guide 27
Show NetBios Characteristics
Show NetBios characteristics.
Server>> [show |list] server netbios
>
AppleTalk
Show Server AppleTalk
Show AppleTalk protocol is recognized by the printer server.
Server>> [show |list] server appletalk
>
AppleTalk Backspoofing
Enable or disable AppleTalk backspoofing on a port.
Server>> define port port_num appletalk
>
backspoof [enabled |disabled]
port_num Enter the printer server port number.
enabled Enables backspoofing on the port.
disabled Disables backspoofing on the port.
Define TBCP - AppleTalk
Allow Apple Adobe binary postscript files to print on Hewlett-Packard
printers.
Server>> define port port_num appletalk tbcp
>
[enabled |disabled]
port_num Enter the printer server port number.
enabled Enables HPTBCP on this port.
disabled Disables HPTBCP on this port. This is the default.
The Hewlett-Packard printers must support Hewlett-Packard’s Tagged
Binary Communications Protocol (TBCP). This command is
dynamically enabled on the printer server’s MIO port for most HewlettPackard printers (applicable to NETJet users only).
28 Command Reference Guide
Show Fonts
Display one or more port’s user-entered font list in Apple environments
only.
Server>> [show |list] port port_num fonts
>
port_num The printer server port number to which the
inquiry is directed.
Add Fonts - Apple
Add PostScript font names to one or more ports’ font list in Apple
environments on uni-directional ports. The number of font strings which
can be stored depends upon available memory.
Server>> [set |define |change] port port_num
>
fonts add “font_list”
port_num A list of port numbers separated by commas.
For example, ports 1,2.
“font_list” A list of PostScript font names set off by blanks
and/or tabs and enclosed in double quotes. If a
font name consists of more than one word,
separate words with dashes instead of spaces.
For example, “Arial-Narrow”
NOTE: Font names are case-sensitive and must be
Command example:
Remove Fonts - Apple
Remove one or more PostScript font names from a ports’ font list in
Apple environments only.
Server>> [set |define |change] port port_num
>
fonts remove “font_list” [all]
port_num A list of port numbers separated by commas.
enclosed in quotes.
> Server>> change port 1,2 fonts add
“Courier-Bold Helvetica-Italics”
For example, ports 1,2.
Command Reference Guide 29
“font_list” A list of PostScript font names set off by blanks
and/or tabs and enclosed in double quotes.
all Enter this option to remove all font names from
the font list.
NOTE Font strings are case-sensitive and must be
enclosed in quotes.
The asterisk character (*) may be used as a wild card in the font name;
however, it must be the last character of the font name preceded by at
least one alphanumeric character. For example, to remove all font names
beginning with the letter ‘A’, enter:
Server>> change port 1 fonts remove “a*”
>
30 Command Reference Guide
LAT
Change Groups
Select the LAT-compatible group code(s) for the printer server. These
group codes apply only to locally defined LAT-compatible services and
ports on the printer server.
Server>> [set |define |change] server groups
>
group_list [enabled |disabled]
group_list Enter the list of LAT-compatible group codes to
modify (see explanation of group codes below).
This list can be a single group code, a list of
group codes separated by commas, or a range
of group codes specified by two numbers
separated by a dash. Group codes must be
between 0 and 255.
enabled Enter enabled to add one or more groups to the
printer server’s existing group list.
disabled Enter disabled to removes one or more groups
from the printer server’s existing group list.
Show Server
Display the printer server’s LAT characteristics.
If neither enabled nor disabled is chosen, the printer server replaces
its entire existing group list with the new group list specified in the
command.
Group codes are assigned to LAT-compatible network devices based
on categories. For example, all engineering nodes on a network
might be assigned to a group code of 0 and accounting nodes to a
group code of 1. The network administrator may restrict a user to
the use of only engineering codes, so the administrator sets the port
to access only the group 0.
Server>> [show |list] server LAT
>
Command Reference Guide 31
Change Authorized Groups
Specify which group codes (groups of LAT-compatible services) are
accessible to a port. The default is no groups authorized for port.
Server>> [set |define |change] port port_num
>
authorized groups group_list [enabled |disabled]
port_num Enter number of the port that will be given
access to the group.
group_list Enter the group or list of groups that will be
assigned to the port.
enabled Enables specified groups access to a port.
disabled Disables specified groups access to a port.
NetWare Commands
Define Password
Define a password for the PSERVER emulation to use to login to the
NetWare file server.
Server>> define server netware password
>
“password”
“password” Enter a maximum of 8 characters and enclose
Define NetWare Node
Define NetWare nodes as Remote Printer or Preferred File Server.
Server>> define node node_name [nfserver
>
|npserver]
node_name The name of the node to be affected.
nfserver Defines the node as the Novell Preferred File
npserver Defines the node to act as a Novell Remote
them in quotes. The default is no password. To
clear, enter “” in its place.
Server. Only one nfserver node may be defined.
Printer. More than one npserver node may be
defined.
32 Command Reference Guide
Choose Frame Type
Specify the order in which the printer server will handle NetWare frame
types.
Server>> [set |define |change] server netware
>
[default |802.2 |snap |802.3 |ethernet_II
ether_type]
default IPX will try 802.2, Ethernet II, 802.3, and 802.2
snap in order. The first one found will be
selected.
802.2 IPX will only look for 802.2 Ethernet frames.
snap IPX will only look for 802.2 snap Ethernet
frames.
802.3 IPX will only look for 802.3 Ethernet frames.
ethernet_II IPX will only look for Ethernet II frames.
ether_type If Ethernet II is selected, the user can specify the
Ethernet type in ASCII hexadecimal characters.
For example, the NetWare default is 0x8137.
The Ethernet type is not changed if this is
omitted.
Display Characteristics
Display the printer server’s Novell NetWare characteristics.
Server>> [show |list] server netware
>
Command Reference Guide 33
Define Required Fileserver
The user must perform two operations to set up a Novell file server as the
required file server for the Emulex printer server.
1) Define whether the printer server will attach to the required file
server or preferred file server:
Server>> define server netware required [enabled
>
|disabled]
enabled If enabled, the printer server will attach only to
the required file server.
disabled If disabled, the printer server attaches to the
preferred file server.
The Emulex printer server will only attempt to directly attach to the
Novell file server and no other, even if that file server is currently
down.
2) Enter this command to further designate the preferred file server.
Server>> define node node_name nfserver
>
node_name Enter the name for the node that will be the
Novell Preferred File Server.
nfserver Specifies the file server as the Novell Preferred
File Server. Only one Novell nfserver node may
be defined.
The Emulex printer server will perform a get nearest query. The file
server that responds will be queried to see if it is the defined
preferred file server. If it is not, the file server’s bindery is scanned
to find the defined preferred file server. If this information is found
in the bindery, a direct attachment is made and the existing file
server attachment is dropped.
If no Novell file server is defined as the Emulex nfserver, the printer
server does a get nearest query, and will attach to the file server
which responds and use its bindery.
34 Command Reference Guide
Define as Remote Printer
Allow the printer server to emulate a NetWare Remote Printer.
Server>> [set |define |change] server netware
>
rprinter [enabled |disabled]
enabled Enables remote printer emulation.
disabled Disables the remote printer emulation.
Rediscover Interval
Set the RPRINTER rediscovery interval, which queries the network for
newly configured Novell print servers and starts all remote printers
found.
Server>> [set |define |change] server netware
>
rediscover minutes
minutes Enter the time in minutes between 1-14 to set
the interval for automatic rediscovery. Enter 0 to
disable automatic rediscovery. The default is 2
minutes. If the time is not specified, the printer
server will rediscover immediately.
Adjust Processing Speed
Enable NetWare PSERVER to adjust to the processing speed of the
computer.
Server>> define server netware fast printserver
>
[enabled| disabled]
enabled Use when operating PSERVER at a faster PC
disabled Use when operating PSERVER at 4.77 MHz or
speed than 4.77 MHz.
slower. Default is disabled.
Command Reference Guide 35
Forms
Enable or disable the NetWare forms function.
Server>> define server netware forms [enabled
>
|disabled]
forms Use this to designate the NetWare form
function.
enabled With forms enabled, the printer server will pause
a print job that requires a different type of paper
and wait for paper to be changed on the printer.
disabled The default is disabled.
Selecting Bindery Emulation or NDS Mode
Specify the discovery method used by PSERVER.
Server>> define server netware pserver [auto
>
|disabled |3.x |4.x]
auto Discovers through both NDS and bindery.
Default is auto.
disabled Disables the printer server protocol separately
from other NetWare protocols.
3.x Only discovers through bindery.
4.x Only discovers though NDS.
Define Context - NDS
Specify the NDS context where the PSERVER printer server object
exists.
Server>> define server netware context “context”
>
“context” Enclose the context in quotes. The default is no
context. To clear, enter “ ” in its place.
36 Command Reference Guide
Define NDS Tree
Specify the NDS Tree where the PSERVER object exists.
Server>> define server netware nds “tree_name”
>
“tree_name” Enter the NDS tree name where the printer
server is located, enclosed in quotes. The
default is no NDS tree name. To clear, enter “”
in its place.
TCP/IP Commands
Change TCP/IP Routing
Modify a TCP/IP routing entry in the printer server’s internal routing
table.
Server>> [set |define |change] server route IP
>
dest_ip gateway gwy_name gwy_ip
dest_ip Enter the IP address of a destination network
whose route you desire to add to the routing
table. The IP address must be in standard
decimal dot notation. For example,
123.234.345.490
gwy_name Enter the gateway node name to use when
routing packets to the destination.
gwy_ip Enter the gateway IP address to use when
routing packets to the destination. The IP
address must be in standard decimal dot
notation. For example, 123.234.345.490
Command Reference Guide 37
Establish or Change TCP/IP Nodes
Establish or change a TCP/IP node.
Server>> [set |define |change] node [node_name|
>
ip ip_address] [tcpip |gateway [default] |syslog
facility]
node_name Enter either the TCP/IP full node name or the IP
address of the node. See naming conventions
in beginning of this section.
ip_address The IP address of the designated node in
decimal dot notation. For example,
123.234.345.490
tcpip Establishes the node as a TCP/IP node in the
printer server’s internal node table.
gateway Establishes the node as a TCP/IP gateway,
which allows communication between segments
on a network.
default If entered along with the gateway option, defines
the TCP/IP gateway to be the first gateway seen
after the routing table is checked.
syslog Establishes the node as a TCP/IP syslog node,
which is designated to receive events or errors.
facility Entered with syslog, this option defines what
type of facility reporting is done (LPR, local0 to
local7). Default is LPR.
IMPORTANT: Since only 10 entries are allowed in
the permanent table, a Set command
may succeed when Define or Change
generates a node table full error.
38 Command Reference Guide
Show TCP/IP Characteristics
Display the printer server’s TCP/IP characteristics.
Server>> [show |list] server tcpip
>
BootP, DHCP and RARP Parameters
When the Emulex printer server reboots, the default sequence of IP
address acquisition is to attempt BootP first; if BootP fails, attempt
DHCP; if DHCP fails, attempt RARP.
Use the following three commands will define how many times the
printer server will attempt BootP, DHCP and RARP.
Define BootP Parameters
Define how many times printer server will attempt BootP.
Server>> define server bootp n m [temp]
>
n Enter the number of broadcast requests
(between 0 and 7) to be made if the printer
server does not know its IP address. The
default is 2.
m Enter the number of broadcast attempts to be
made if the printer server IP address is known.
The default is 0.
temp Enter the response in volatile memory only.
The default is permanent.
Command Reference Guide 39
Define DHCP Parameters
Define how many times printer server will attempt DHCP.
Server>>define server dhcp n m [temp]
>
n Enter the number of times (between 0 and 7) to
attempt DHCP if the server IP address is
unknown. The default is 2.
m Enter the number of times to attempt DHCP if
the server IP address is known. The default is
1.
temp If entered, the acquired IP address is stored in
volatile memory. Only “infinite” lease IP
addresses are stored in non-volatile memory.
The default is permanent.
If both n and m are zero, DHCP is effectively disabled.
Define RARP Parameters
Define how many times printer server will attempt RARP.
Server>> [set |define |change] server rarp n m
>
[temp]
n Enter the number of times an attempt will be
made if the server IP address is unknown. The
default is 2.
m Enter the number of times the attempt will be
made if the IP address of the server is known.
The default is 1.
temp Enter this option to store the acquired IP
address in volatile memory; only “infinite” lease
IP addresses are stored in non-volatile memory.
The default is permanent.
40 Command Reference Guide
Load/Dump Configuration
Configuring a load host or dump host will allow you to:
• Upgrade printer server software.
• Define a workstation to receive and record memory image dumps.
Define TCP/IP Load Host
Specify the TCP/IP host where the printer server’s operational software
will load from.
Server>> define server preferred load ip
>
ip_address
ip_address Enter the IP address of the node where the
operational software is stored in decimal dot
notation. For example, 123.234.345.490. The
default is none.
Define Server Load
Specify the source of the operating software for subsequent loads. The
command determines which load protocol the printer server uses the next
time the printer server is reinitialized.
Server>> define server load [selfload |TFTP
>
[put] |decnet]
selfload Upon reinitialization, the printer server self-loads
its operational software from onboard non-
volatile memory. This keyword requires special
firmware which contains the operating software.
A printer server configured for a selfload also
has the ability to download its operational
software from a network load host.
TFTP Upon reinitialization, the printer server
downloads its operational software from a
network load host using standard TFTP load
protocol.
Command Reference Guide 41
put Use this keyword when the environment does
not support BootP, DHCP, or TFTP server load
requests to a printer server.
decnet Upon reinitialization, the printer server
downloads its operational software from a
network load host using standard decnet-
compatible load protocol. The default is dec.
Power must by cycled after this command is performed.
Define Software File Name
Specify the file name of the file on a load host that contains the printer
server’s operational software.
Server>> define server software file_name
>
file_name Enter the name of the file that contains the
printer server’s operational software. For
DECnet load hosts, this is a 1 to 9 character file
name. For TFTP load hosts, this is a 1 to 16
character file name. See the chart below for
DECnet and TFTP file names:
Printer Server TFTP DECnet
NETJet NJATLNE NJATLNE.SYS
NETQue NQATLNE NQATLNE.SYS
Token Ring NQTTLNE NQTTLNE.SYE
NETQue Mate NQMTLNE NQMTLNE.SYS
NETQue Pro2 NP2TLNE NP2TLNE.SYS
Set Load/Dump Gateway
Specify the IP address of the gateway through which the printer server
loads and dumps its internal software.
Server>> define server gateway [load_dump] ip
>
[ip_address |none]
load_dump Enter the gateway through which the printer
server loads and dumps its internal software.
The printer server maintains only one gateway
42 Command Reference Guide
IP address for both the load and dump
functions.
ip_address Enter the IP address of the gateway node in
decimal dot notation. For example,
123.234.345.490. This address must be on the
same subnet as the printer server.
none Enter none to remove an existing IP address.
Although no IP address is chosen, the printer
server attempts the load or dump operation
without using a gateway. The printer server
attempts to use the IP address of the load or
dump host even if the host IP address is on a
different subnet than the printer server’s IP
address.
When the printer server loads its internal software over the network, it
checks to see if a gateway load_dump IP address has been set and uses
the set gateway to contact the node from which it will download its
operational software. In the same way, when the printer server performs
a crash dump upload, it checks to see if a gateway load_dump IP address
has been set and uses the set gateway to contact the node to which it will
send the dump of its internal memory.
Set Dump Host
Enable or disable the printer server’s ability to send a copy of its internal
memory to a specified dump host.
Server>> [set |define |change] server dump
>
[enabled |disabled]
enabled Default is enabled. When this command is
disabled When the command is disabled, no dump can
Define TCP/IP Dump Host
enabled, the printer server sends a file memory
image to a specified host before reinitializing
after a fatal error or upon execution of a Crash
300 command.
occur. Prior to a dump occurring, a preferred
dump node must be specified.
Command Reference Guide 43
The dump will save a copy of the printer server’s memory to the
specified workstation.
Server>> define server preferred dump ip
>
ip_address
ip_address Enter the IP address of the destination node in
decimal dot notation. For example,
123.234.345.490. The default is none.
44 Command Reference Guide
Service Commands
Change Service
Specify the name of the service to be established or modified.
Server>> [set |define |change] service
>
“servc_name” [TCPport_num] [port port_num]
[password “pass_txt”] [protocol] [enabled
|disabled]
“servc_name” Enter the name of the service to be
created or modified, enclosed in quotes. The
maximum length of service names depend on
the protocol: NetWare - 47, LAT - 16, Apple -
32.
TCPport_num Enter the TCP/IP port number of the service to
be created. If this is omitted for a new service,
the printer server creates the services as a LAT-
only service. Enter the TCP/IP port number to
create a service that is a combined LAT-
compatible and TCP/IP service.
port_num Enter the port number on which the service is
being established. If on all ports, enter ALL.
RCF ports will not change, but the command
does affect virtual ports.
“pass_txt” Enter 1 to 16 characters, beginning with a letter
of the alphabet, and enclose the word in quotes.
To remove password protection from the
service, enter Password “ “. The default is none.
protocol Enter one of these protocols: AppleTalk, LAT,
NetBios, NetWare, TCP/IP.
Command Reference Guide 45
Define Service
Establish or modify an AppleTalk service.
Server>> define service “servc_name” appletalk
>
type “prn_type”
“servc_name” Enter the name of the service, enclosed
in quotations marks.
“prn_type” Enter the type of printer.
Delete Service
Remove a service from the printer server’s service table.
Server>> [clear |purge |delete] service
>
“servc_name”
“servc_name” Enter the name of the service to be
removed, enclosed in quotation marks (valid for
Apple service).
Show Service
Display the characteristics for a specified service.
Server> [show |list] service “servc_nam” ch
>
“servc_nam” Enter the name of the particular service,
enclosed in quotation marks.
This command will display a detailed listing of all service characteristics.
For remote services, the service or TCP port name, the applicable
protocols, and the identification phrase associated with the service are
given. For local services, the service or TCP port name and services
options set by the Set Service command are displayed.
