Emerson Process Management 396PVP, 396P User Manual
Combination pH/ORP Sensor
Instruction Manual
PN 51-396P/rev.H
March 2006
MODEL 396P
MODEL 396PVP
with mating cable
Models 396P and 396PVP
CAUTION
SENSOR/PROCESS
APPLICA
TION COMPATIBILITY
The wetted sensor materials may not be
compatible with process composition and
operating conditions. Application
compatibility is entirely the responsibility
of the user.
DANGER
HAZARDOUS AREA
INST
ALLATION
This sensor is not Intrinsically Safe. or Explosion
Proof. Installations near flammable liquids or in
hazardous area locations must be carefully evaluated by qualified on site safety personnel.
To secure and maintain an intrinsically safe
installation, an appropriate transmitter/ safety
barrier/sensor combination must be used. The
installation system must be in accordance with
the governing approval agency (FM, CSA or
BASEEFA/CENELEC) hazardous area classification requirements. Consult your analyzer/
transmitter instruction manual for details.
Proper installation, operation and servicing of
this sensor in a Hazardous Area Installation is
entirely the responsibility of the user.
ESSENTIAL INSTRUCTIONS
READ THIS PAGE BEFORE PROCEEDING!
Rosemount Analytical designs, manufactures, and tests its products to meet
many national and international standards. Because these instruments are
sophisticated technical products, you must properly install, use, and maintain
them to ensure they continue to operate within their normal specifications. The
following instructions must be adhered to and integrated into your safety program when installing, using, and maintaining Rosemount Analytical products.
Failure to follow the proper instructions may cause any one of the following situations to occur: Loss of life; personal injury; property damage; damage to this
instrument; and warranty invalidation.
• Read all instructions prior to installing, operating, and servicing the product.
If this Instruction Manual is not the correct manual, telephone 1-800-6547768 and the requested manual will be provided. Save this Instruction
Manual for future reference.
• If you do not understand any of the instructions, contact your Rosemount
representative for clarification.
• Follow all warnings, cautions, and instructions marked on and supplied with
the product.
• Inform and educate your personnel in the proper installation, operation, and
maintenance of the product.
• Install your equipment as specified in the Installation Instructions of the
appropriate Instruction Manual and per applicable local and national codes.
Connect all products to the proper electrical and pressure sources.
• To ensure proper performance, use qualified personnel to install, operate,
update, program, and maintain the product.
• When replacement parts are required, ensure that qualified people use
replacement parts specified by Rosemount. Unauthorized parts and procedures can affect the product’s performance and place the safe operation of
your process at risk. Look alike substitutions may result in fire, electrical
hazards, or improper operation.
Emerson Process Management
Liquid Division
2400 Barranca Parkway
Irvine, CA 92606 USA
Tel: (949) 757-8500
Fax: (949) 474-7250
http://www.raihome.com
© Rosemount Analytical Inc. 2006
About This Document
This manual contains instructions for installation and operation of the Models 396P and 396PVP
TUpH Combination pH/ORP Sensors. The following list provides notes concerning all revisions of
this document.
Rev. Level Date Notes
0 8/95-2/01 This is the initial release of the product manual. The manual has been reformatted to reflect the
Emerson documentation style and updated to reflect any changes in the product offering.
A 12/01 Added wiring diagram to page 14.
B 4/02 Revised drawings on pages 6, 7, and 14.
C 7/02 Added 1055 wiring diagrams.
D 8/03 Added Silcore information.
E 5/04 Added 5081 and Xmt wiring info. Deleted obsolete model information.
G 11/05 Changed Figure 4-6 drawing on page 17. Resized Figure 1-1 drawing on page 2.
H 3/06 Changed PN on Fig. 2-5, page 8, and in Table 7-3, page 29. Added a note on page 11.
i
MODEL 396P and 396PVP TABLE OF CONTENTS
MODEL 396P and 396PVP
COMBINATION pH/ORP SENSOR
TABLE OF CONTENTS
Section Title Page
1.0 DESCRIPTION AND SPECIFICATIONS................................................................. 1
1.1 Features and Applications........................................................................................ 1
1.2 Physical Specifications............................................................................................. 2
1.3 Ordering Information ................................................................................................ 3
2.0 INSTALLATION ....................................................................................................... 5
2.1 Unpacking and Inspection........................................................................................ 5
2.2 Mounting .................................................................................................................. 5
3.0 WIRING MODEL 396P-01 ....................................................................................... 10
4.0 WIRING MODELS 396P-02 AND 396PVP.............................................................. 16
5.0 START UP AND CALIBRATION ............................................................................. 24
5.1 Model 396P pH ........................................................................................................ 24
5.2 Model 396P ORP ..................................................................................................... 24
6.0 MAINTENANCE ...................................................................................................... 25
6.1 Automatic Temperature Compensator ..................................................................... 25
6.2 Model 396P pH ........................................................................................................ 25
6.3 Model 396P ORP ..................................................................................................... 26
7.0 DIAGNOSTICS AND TROUBLESHOOTING.......................................................... 27
7.1 Diagnostics & Troubleshooting With the Models 54e, 1055, 3081, 81, 4081, 5081.
and Xmt.................................................................................................................... 27
7.2 Troubleshooting Without Advanced Diagnostics ...................................................... 28
8.0 RETURN OF MATERIAL......................................................................................... 30
LIST OF TABLES
Number Title Page
1-1 Recommended Accessories for First Time Installations........................................... 4
3-1 Wiring Matrix Guide - Model 396P ........................................................................... 10
4-1 Wiring Matrix Guide - Model 396PVP....................................................................... 16
5-1 ORP of Saturated Quinhydrone Solution (In Millivolts)............................................. 24
6-1 Ro and R1 Values for Temperature Compensation Elements .................................. 25
6-2 Temperature vs Resistance of Auto T.C. Elements .................................................. 25
7-1 Troubleshooting With Advanced Diagnostics ........................................................... 27
7-2 Troubleshooting Without Advanced Diagnostics ...................................................... 28
7-3 Model 396P Replacement Parts and Accessories.................................................... 29
MODEL 396P and 396PVP TABLE OF CONTENTS
LIST OF FIGURES
Number Title Page
1-1 Cross Section Diagram of the TUpH Patented Reference Technology ............................................................................... 2
2-1 Dimensional Drawing .......................................................................................................................................................... 6
2-2 Flow-Through Tee with Adapter (PN 915240-xx)................................................................................................................. 6
2-3 Flow-Through and Insertion Installations ........................................................................................................................... 7
2-4 Model 396P/396PVP with Insertion Mounting Adapter (PN 23242-02)............................................................................... 7
2-5 Submersion Installations .................................................................................................................................................... 8
2-6 Low Flow Cell PN 23728-00 ................................................................................................................................................ 9
2-7 Jet Spray Cleaner PN 12707-00.......................................................................................................................................... 10
3-1 Wire Functions for Model 396P with & without Preamplifier................................................................................................ 10
3-2 Wiring Details Model 396P-01-50 for use with & without Junction Box (PN 22719-02) for Models 1181, 1050, & 1060 .... 12
3-3 Wiring Details Model 396P-01-54 for use with & sithout Junction Box (PN 22719-02) for Models 1054/A/B, 2054, 2081
and Extension Cable (PN 9200254).................................................................................................................................... 13
3-4 Wiring Details Model 396P-01-55 for use with Junction Box (PN 23550-00) for Models 54, 3081, 4081, 81, and 5081 ... 14
3-5 Wiring Details Model 396P-01-55 for use with Models 54, 81, 3081, 4081, and 5081........................................................ 15
3-6 Wiring Model 396P-01)-( )-55 Sensor to Model 1055-10-22-32 Analyzer ........................................................................... 15
4-1 Wire Functions for Mating Variopol Cable used with Model 396PVP.................................................................................. 17
4-2 Connector Pins and their Functions .................................................................................................................................... 17
4-3 Wiring Details for Models 396PVP or 396P-02-55 with Mating Variopol Cable (PN 23645-07) for use with Model 81....... 17
4-4 Wiring Details for Models 396PVP or 396P-02-50 with Mating Variopol Cable (PN 23645-07) for use with Model 1181 ... 17
4-5 Wiring Details for Models 396PVP or 396P-02-54 with Mating Variopol Cable (PN 23645-07) for use with Model 2081... 17
4-6 Wiring Details for Models 396PVP or 396P-02-55 with Mating Variopol Cable (PN 23645-07) for use with Models 3081,
4081, and 5081 ................................................................................................................................................................... 17
4-7 Wiring Details for Models 396PVP or 396P-02-55 with Mating Variopol Cable (PN 23645-07) for use with Remote ........
Junction Box (PN 23555-00) to Model 81 ........................................................................................................................... 18
4-8 Wiring Details for Models 396PVP or 396P-02-50 with Mating Variopol Cable (PN 23645-07) for use with Remote ........
Junction Box (PN 23309-03) to Model 1181........................................................................................................................ 18
4-9 Wiring Details for Models 396PVP or 396P-02-55 with Mating Variopol Cable (PN 23645-07) for use with Model 54...... 18
4-10 Wiring Details for Models 396PVP or 396P-02-55 with Mating Variopol Cable (PN 23645-07) for use with Remote ........
Junction Box (PN 23555-00) to Model 54 ........................................................................................................................... 18
4-11 Wiring Details for Models 396PVP or 396P-02-54 with Mating Variopol Cable (PN 23645-06) for use with Remote ........
Junction Box (PN 23309-03) to Model 2081 ....................................................................................................................... 19
4-12 Wiring Details for Models 396PVP or 396P-02-55 with Mating Variopol Cable (PN 23645-07) for use with Remote ........
Junction Box (PN 23555-00) to Models 3081 and 4081...................................................................................................... 19
4-13 Wiring Details for Models 396PVP or 396P-02-54 with Mating Variopol Cable (PN 23645-07) for use with Model 1054... 19
4-14 Wiring Details for Models 396PVP or 396P-02-54 with Mating Variopol Cable (PN 23645-07) for use with ......................
Model SCL-(P/Q)................................................................................................................................................................. 19
4-15 Wiring Details for Models 396PVP or 396P-02-55 with Mating Variopol Cable (PN 23645-07) for use with Model 1055... 20
4-16 Wiring Model 396P-(02)-( )-54/55-(61) Sensor to Model 1055-01-10-22-32 Analyzer ........................................................ 20
4-17 Wiring Details for Models 396PVP or 396P-02-55 with Mating Variopol Cable (PN 23645-07) for use with Remote ........
Junction Box (PN 23557-00) to Model 1055 ....................................................................................................................... 20
4-18 Wiring Details for Models 396PVP or 396P-02-54 with Mating Variopol Cable (PN 23645-06) for use with Models ..........
1054A/B and 2054............................................................................................................................................................... 21
4-19 Wiring Details for Models 396PVP or 396P-02-54 with Mating Variopol Cable (PN 23645-06) for use with Remote ........
Junction Box (PN 23309-04) to Models 1054A/B and 2054................................................................................................ 21
4-20 Wiring to Model 54e pH/ORP with Variopol........................................................................................................................ 21
4-21 Wiring Details Model 396P-02-50 for use with Junction Box (PN 23309-03), Remote Preamplifier, and Extension ..........
Cable (PN 9200254)............................................................................................................................................................ 22
4-22 Wiring Details Model 396P-02-54 for use with Junction Box (PN 23309-04), Remote Preamplifier (PN 22698-03), and ..
Extension Cable (PN 9200254)........................................................................................................................................... 22
4-23 Wiring Model 396P-01 to Model Xmt-P-HT-10 ................................................................................................................... 23
4-24 Wiring Models 396P-02 and 396PVP to Model Xmt-P-HT-10 ............................................................................................ 23
ii
Model 396PVP is offered with a watertight sensor-tocable connector which eliminates re-wiring and cable
twisting when replacing sensors. The Variopol VP
multiple pin connector is an integral part of each sensor model and uses a mating VP cable. Once the
cable is installed and wired to the analyzer, sensors
are easily replaced without replacing the cable, and, if
the replacement sensor is the same as its predecessor, without rewiring the analyzer. Also the cable can
be disconnected from the sensor before removal from
the process which eliminates cable twisting.
The entire line of TUpH model sensors now incorporate the new SILCORE technology contaminant
barrier. This triple-seal barrier prevents moisture and
material impurities from migrating to the pH sensor’s
reference electrode’s metal lead wire. By preventing
these contaminants from compromising the integrity
of the pH measurement, sensor life is increased,
especially at higher temperatures where increased
migrations occur. In addition, the SILCORE technology provides added protection against sensor failure
due to vibrations and shock by transferring damaging
energy away from the glass-to-metal seal.
The AccuG
LASS pH glass formulations exceed
industry standards. The AccuGlass pH glass is a
result of many years of glass research resulting in a
formulation which has been found to increase the life
of the sensor. Unlike other pH glasses presently on
the market, this glass resists cracking especially at
higher temperatures and reduces sodium ion error
commonly found in high pH applications. Overall, the
AccuGlass formulation enhances the sensor performance to measure pH more accurately and have a
longer sensor life than ever before.
AccuGlass and Silcore are trademarks of Rosemount Analytical.
1
MODEL 396P and 396PVP SECTION 1.0
DESCRIPTIONS AND SPECIFICATIONS
SECTION 1.0
DESCRIPTION AND SPECIFICATIONS
1.1 FEATURES AND APPLICATIONS
The Rosemount Analytical Model 396P and 396PVP
Sensors measure the pH or the ORP of aqueous solutions in pipelines, open tanks, or ponds. It is designed
for harsh, dirty applications such as sourwater waste
treatment and scrubbers, where a high performance,
low maintenance, disposable sensor is required.
The combination electrode features a patented, large
area polypropylene reference junction for resistance to
process coatings, generally found in dirty, high solid
applications. The patented helical reference pathway
provides added resistance for poisoning applications.
In addition, it is available in two configurations:
glass/platinum electrode completely recessed within
the reference junction for added life in abrasive or
rough applications and the glass/platinum electrode
partially exposed for added life and accuracy in viscous and low flow applications.
Both Models feature a titanium solution ground constructed in an annular design around the pH/ORP electrode. The solution ground provides glass and reference sensor diagnostics for preventative maintenance
when used with the Model 54e, 1055, 5081, 3081,
4081, 81 pH/ORP, and Xmt-P transmitters. In addition
Models 396P and 396PVP can be used with most nondiagnostic Rosemount Analytical and other manufacturer’s instruments.
Each sensor is housed in a molded polypropylene
body with EPDM seals, making it virtually indestructible and chemically resistant. Complete encapsulation
eliminates leakage or high humidity problems traditionally found in other pH/ORP designs. The simplified
construction, designed with user convenience in mind,
does not require electrolyte (KCl) replenishment or any
high maintenance troubleshooting procedures.
The Model 396P is offered with or without an optional
integral preamplifier to convert the high impedance pH
or ORP mV signal into a stable, noise-free signal with
transmission capability of up to three miles. A remote
preamplifier must be used with Model 396PVP.
Installation is easily achieved through the wide variety
of mounting configurations. The Models 396P and
396PVP feature 1 in. (MNPT) front and rear facing
connections for insertion, submersion or flow through
pH and ORP applications.
2
MODEL 396P and 396PVP SECTION 1.0
DESCRIPTIONS AND SPECIFICATIONS
Measurements and Ranges *pH: 0-14
ORP: -1500 to 1500 mv
Available pH ACCUGLASS Types GPLR hemi or flat glass
Wetted Materials Titanium, Polypropylene, EPDM, glass; platinum (ORP only)
Process Connection 1 in. MNPT front and rear facing threads
Temperature Range 0-100°C (32-212°F)
Pressure Range-Hemi bulb 100-1135 kPa [abs] (0-150 psig)
Pressure Range-Flat bulb 100-790 kPa [abs] (0-100 psig)
Minimum Conductivity 75 μS/cm, nominal; 100 μS/cm
Integral Cable 396P: Code 01 - 25 ft; Code 02 - 15 ft coaxial
396PVP: none - must use mating VP cable
Preamplifier Options 396P: Remote or Integral
396PVP: Remote only
Weight/Shipping Weight 0.45 kg/0.9 kg (1 lb/2 lb)
1.2 SPECIFICATIONS
FIGURE 1-1. Cross Section Diagram of the TUpH Patented Reference Technology
All TUpH sensors are designed with a large area reference junction, helical reference pathway, and an AccuGlass pH
glass bulb. This patented sensor technology ensures superior performance while only requiring minimal maintenance.
PERCENT LINEARITY*
pH range GPLR hemi bulb GPLR flat bulb
0 - 2 pH 94% —
2 - 12 pH 99% 98%
12 - 13 pH 97% 95%
13 - 14 pH 92% —
3
MODEL 396P and 396PVP SECTION 1.0
DESCRIPTIONS AND SPECIFICATIONS
1.3 ORDERING INFORMATION
The Model 396P Sensor is housed in a molded reinforced polypropylene
body with 1 in. MNPT threads suitable for insertion, submersion or flow
through installation. The sensor includes a general purpose pH electrode
or a platinum ORP electrode, a patented reference junction and a solution
ground. The Model 396P comes standard with a recessed electrode; an
optional slotted tip is also available. In addition, the 396P features an
optional integral hermetically sealed preamplifier and 15 ft or 25 ft cable
lengths. Automatic temperature compensation, Pt 100 or 3K Balco, is
standard with the Model 396P.
CODE PREAMPLIFIER/CABLE (Required Selection)
01 With integral preamplifier, 25 ft cable
02 Without integral preamplifier, 15 ft cable
CODE MEASURING ELECTRODE TYPE (Required Selection)
10 GPLR hemi bulb, General Purpose Low Resistivity (0-14 pH)
12 ORP
13 GPLR flat bulb, General Purpose Low Resistivity (2 - 13 pH)
CODE ANALYZER/TC COMPATIBILITY (Required Selection)
50 For Models 1181 (3K TC)
54 For Models 1054A/B, 2054, 2081 (Pt 100 RTD)
55 For Models 54e, 3081, 81, 4081, 1055, 5081, Xmt (PT-100 RTD)
396P - 01 - 10 - 55 EXAMPLE
NOTE: The Model 396P is also compatible with Model SCL-P/Q (option 02-54 only).
CODE OPTIONAL SELECTION
41 Slotted Tip (not available on flat bulb sensors)
1. Mounting Accessories (optional)
Choose one: PN 915240-03, PVC flow through tee, 3/4 in. NPT process connection
PN 915240-04, PVC flow through tee, 1 in. NPT process connection
PN 915240-05, PVC flow through tee, 1-1/2 in. NPT process connection
PN 23728-00, acrylic low flow cell
PN 2002011, 1-1/2 in. CPVC tee with 1-in. FNPT connection
PN 11275-01, sensor handrail assembly
2. Junction Boxes (optional)
Remote Junction Boxes (used with option -02 sensors, for sensor to analyzer distances of more than 15 ft)
Choose one: PN 23555-00 includes preamplifier for Models 54, 81, 3081, 4081, 5081, Xmt
PN 23309-03 and PN 22698-02 plug-in preamplifier for Model 1181Analyzer
PN 23309-04 and PN 22698-03 plug-in preamplifier for Models 1054A/B series, 2054, 2081 Analyzers
Choose one: PN 9120516 BNC Adapter for use with remote junction boxes PNs 23309-03, 23309-04
Remote Junction Box (used with option -01 sensors)
Choose one: PN 23550-00 cable extension board
3. Extension cables (used with remote junction boxes)
Choose one: PN 23646-01, 11 conductor, shielded, prepped
PN 9200273, 11 conductor, shielded, unprepped
TABLE 1-1. RECOMMENDED ACCESSORIES FOR FIRST TIME INSTALLATIONS
The Model 396P insertion/submersion
sensor with integral cable is offered with
or without a built-in preamplifier
MODEL
396P TUpH INSERTION/SUBMERSION POLYPROPYLENE pH/ORP SENSOR
4
MODEL 396P and 396PVP SECTION 1.0
DESCRIPTIONS AND SPECIFICATIONS
Optional Slotted Tip
is available on all
hemi bulb sensors,
ordered as option -41
Flat Tip is avail-
able with flat
glass bulb sen-
sors
Examples of all sensing tip offerings
Shrouded Tip is
standard on all
hemi bulb sensors
Variopol connector
shown with mating variopol
cable receptacle
MODEL
396PVP TUpH INSERTION/SUBMERSION POLYPROPYLENE pH/ORP SENSOR
CODE MEASURING ELECTRODE TYPE (Required Selection)
10 GPLR hemi bulb, General Purpose Low Resistivity (0-14 pH)
12 ORP
13 GPLR flat bulb, General Purpose Low Resistivity (2 - 13 pH)
CODE ANALYZER/TC COMPATIBILITY (Required Selection)
50 For Models 1181 (3K TC)
54 For Models 1054A/B, 2054, 2081 (Pt 100 RTD)
55 For Models 54e, 3081, 81, 4081, 1055, 5081, Xmt (PT-100 RTD)
CODE OPTIONAL SELECTION
41 Slotted Tip (not available on flat bulb sensors)
PN MATING VP CONNECTOR CABLE (Required for all new installations)
23645-06 15 ft. cable with mating VP connector, prepped with BNC on analyzer end
23645-07 15 ft. cable with mating VP connector, prepped without BNC on analyzer end*
The Model 396PVP Sensor has similar features to the Model 396P.
However, the Model 396PVP is offered with the new Variopol (VP)
connector and uses a mating VP cable (purchased separately).
A remote preamplifier must be used with this sensor.
A Variopol cable is required for all new installations. See below
for cable selection.
The Model 396PVP insertion/ submersion sensor with the VP (Variopol) connector
OTHER ACCESSORIES FOR MODELS 396P AND 396PVP
PART DESCRIPTION
22698-00 Preamplifier plug-in for junction box, for Model 1003,
22698-02 Preamplifier plug-in for junction box, for Models 1181, 1050
22698-03 Preamplifier plug-in for junction box, for Models 1054A/B, 2054, 2081
22743-01 Pt100 preamplifier for Model 1181
22744-01 3K Preamplifier for Model 1181
23557-00 Preamplifier for junction box for Models 54, 3081, 81, 4081, 5081
9210012 Buffer solution, 4.01 pH, 16 oz
9210013 Buffer solution, 6.86 pH, 16 oz
9210014 Buffer solution, 9.18 pH, 16oz
R508-160Z ORP solution, 460 mv ± 10 at 20°C
12707-00 Jet Spray Cleaner
*For use with connections to Models 1181, 1054A/B, 2081, 54e, 81, 3081, 4081, 5081, Xmt, and remote junction box PN 23555-00.
5
MODEL 396P and 396PVP SECTION 2.0
INSTALLATION
SECTION 2.0
INSTALLATION
2. Do not install the sensor on the horizontal. The
sensor must be 10° off the horizontal to ensure
accuracy.
3. Do not install the sensor upside down.
4. Air bubbles may become trapped in the sensor end
between the glass bulb and the sensor body. This
problem is most commonly encountered in areas
of low flow or during calibration. Shake the probe
while immersed in solution to remove bubbles.
This problem can be avoided by ordering the sensor with the slotted tip (option -41).
In most cases, the pH sensor can simply be installed
as shipped and readings with an accuracy of ± 0.6 pH
may be obtained. To obtain greater accuracy or to verify proper operation, the sensor must be calibrated as
a loop with its compatible analyzer or transmitter.
2.2.1 Flow Through and Insertion Mounting.
Model 396P and 396PVP Sensors have a 1-inch
MNPT process connection at the front of the sensor for
mounting into a 1-1/2 inch tee or the process pipes.
See Figure 2-1 through Figure 2-7 for installation configurations.
NOTE
LARGE PIPE WRENCHES MUST NOT BE
USED TO TIGHTEN THE SENSOR INTO A
FLANGE OR OTHER TYPE OF MOUNTING.
2.2.2 Submersion Mounting. Model 396P and
396PVP Sensors also have a 1 inch MNPT process
connection at the back of the sensor. Utilizing a standard 1 inch union, the sensor may be mounted to a 1
inch SCH 80 CPVC or PVDF standpipe (see Figure 2x). Tapered pipe threads in plastic tend to loosen after
installation. It is therefore recommended that Teflon
1
tape be used on the threads and that the tightness of
the connection be checked frequently to assure that no
loosening has occurred. To prevent rain water or condensation from running into the sensor, a weatherproof
junction box is recommended (see Figure 2-x). The
sensor cable must be run through a protective conduit
for isolation from electrical interference or physical
abuse from the process. The sensor should be installed
within 80° of vertical, with the electrode facing down.
The sensor’s cable should not be run with power or
control wiring.
1
Teflon is a registered trademark of E.I. du Pont de Nemours & Co.
2.1 UNPACKING AND INSPECTION.
Inspect the outside of the carton for any damage. If damage is detected, contact the carrier immediately. Inspect
the hardware. Make sure all the items in the packing list
are present and in good condition. Notify the factory if any
part is missing. If the sensor appears to be in satisfactory
condition, proceed to Section 2.2, Mounting.
NOTE
Save the original packing cartons and materials as most carriers require proof of damage
due to mishandling, etc. Also, if it is necessary
to return the sensor to the factory, you must
pack the sensor in the same manner as it was
received. Refer to Section 6.0 for return
instructions. If the sensor is to be stored, the
vinyl boot should be filled with pH buffer solution and replaced on sensor tip until ready to
use.
CAUTION
Buffer solution, in the vinyl boot, may cause
skin or eye irritation.
WARNING
Glass electrode must be wetted at all times (in
storage and in line) to maximize sensor life.
2.2 MOUNTING.
The sensor has been designed to be located in industrial process environments. Temperature and pressure
limitations must not be exceeded at any time. A caution
label regarding this matter is attached to the sensor.
Please do not remove the label. See Figure 2-1.
CAUTION
Internal electrolyte fill solution may cause skin
or eye irritation.
Mounting Guidelines:
1. Shake the sensor in a downward motion to
remove any air bubbles that may be present inside
the tip of the pH glass.
6
MODEL 396P and 396PVP SECTION 2.0
INSTALLATION
FIGURE 2-1. Dimensional Drawing
DWG. NO. REV.
40396P01 D
MILLIMETER
INCH
FIGURE 2-2. Flow-Through Tee with Adapter (PN 915240-xx*)
MILLIMETER
INCH
xx* Process Connection
Threads
03 3/4 inch
04 1 inch
05 1-1/2 inch
SENSOR CABLE (OR VP CONNECTOR - NOT SHOWN)
SENSOR CABLE
(OR VP CONNECTOR
- NOT SHOWN)
MODEL 396P and 396PVP SECTION 2.0
INSTALLATION
FIGURE 2-4. Model 396P with Insertion Mounting Adapter (PN 23242-02).
Not for use with Model 396PVP.
Mounting adapter allows for sensor removal without twisting or
disconnecting interconnecting cable for ease of maintenance.
WHEN INCH AND METRIC DIMS
ARE GIVEN
MILLIMETER
INCH
DWG. NO. REV.
40396P02 A
FIGURE 2-3. Flow-Through and Insertion Installations
1-1/2” PIPE “Y”
1-1/2” X 1”
Reducing
Bushing
1-1/2” X 1”
Reducing
Bushing
1-1/2” X 1”
Reducing
Bushing
1-1/2” Pipe Tee
PN 2002011
1-1/2” Pipe Tee
PN 2002011
PIPE “Y”
INSTALLATION
SHOWN
STRAIGHT
FLOW
SHOWN
FLOW
ANGLE
FLOW
SHOWN
7
Loading...
