Emerson Process Management 2400S User Manual

Configuration and Use Manual

P/N MMI-20008811, Rev. AA
September 2009

Micro Motion

®

Model 2400S Transmitters
for PROFIBUS-DP

Configuration and Use Manual

© 2009 Micro Motion, Inc. All rights reserved. The Micro Motion and Emerson logos are trademarks and service marks of Emerson
Electric Co. Micro Motion, ELITE, MVD, ProLink, MVD Direct Connect, and PlantWeb are marks of one of the Emerson Process
Management family of companies. All other trademarks are property of their respective owners.

Contents

Chapter 1 Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.3 Determining transmitter information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.4 PROFIBUS-DP functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.5 Determining version information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.6 Communication tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.7 Planning the configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.8 Pre-configuration worksheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.9 Flowmeter documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.10 Micro Motion customer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Chapter 2 Flowmeter Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.2 Setting the node address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.3 Bringing the transmitter online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Chapter 3 Using the Transmitter User Interface . . . . . . . . . . . . . . . . . . . . . . . . 9

3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.2 User interface without or with display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.3 Removing and replacing the transmitter housing cover . . . . . . . . . . . . . . . . . . . . . . 11

3.4 Using the optical switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3.5 Using the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3.5.1 Display language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3.5.2 Viewing process variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3.5.3 Using display menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.5.4 Display password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.5.5 Entering floating-point values with the display . . . . . . . . . . . . . . . . . . . . . 13

Chapter 4 Connecting with ProLink II or Pocket ProLink Software . . . . . . . . . . 17

4.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.2 Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.3 Configuration upload/download. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4.4 Connecting from a PC to a Model 2400S DP transmitter . . . . . . . . . . . . . . . . . . . . . 18

4.4.1 Connection options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4.4.2 Service port connection parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4.4.3 Making the connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.5 ProLink II language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Configuration and Use Manual i

Contents

Chapter 5 Using a PROFIBUS Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5.2 Support files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5.3 Connecting to the Model 2400S DP transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5.4 Using the GSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5.5 Using the EDD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

5.6 Using PROFIBUS bus parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Chapter 6 Required Transmitter Configuration . . . . . . . . . . . . . . . . . . . . . . . 25

6.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

6.2 Characterizing the flowmeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

6.2.1 When to characterize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

6.2.2 Characterization parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

6.2.3 How to characterize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

6.3 Configuring the measurement units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

6.3.1 Mass flow units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

6.3.2 Volume flow units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

6.3.3 Density units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

6.3.4 Temperature units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

6.3.5 Pressure units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Chapter 7 Using the Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

7.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

7.2 Using the I&M functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

7.3 Recording process variables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

7.4 Viewing process variables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

7.4.1 With the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

7.4.2 With ProLink II . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

7.4.3 With a PROFIBUS host and the EDD . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

7.4.4 With a PROFIBUS host and the GSD . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

7.4.5 With PROFIBUS bus parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

7.5 Using the LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

7.5.1 Using the network LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

7.5.2 Using the software address LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

7.6 Viewing transmitter status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

7.6.1 Using the status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

7.6.2 Using ProLink II . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

7.6.3 Using a PROFIBUS host and the EDD . . . . . . . . . . . . . . . . . . . . . . . . . . 39

7.6.4 Using PROFIBUS bus parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

7.7 Handling status alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

7.7.1 Using the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

7.7.2 Using ProLink II . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

7.7.3 Using a PROFIBUS host with the EDD . . . . . . . . . . . . . . . . . . . . . . . . . . 43

7.7.4 Using PROFIBUS bus parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

7.8 Using the totalizers and inventories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

7.8.1 Viewing current totals for totalizers and inventories. . . . . . . . . . . . . . . . . 45

7.8.2 Controlling totalizers and inventories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

ii Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Contents

Chapter 8 Optional Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

8.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

8.2 Configuring volume flow measurement for gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

8.2.1 Using ProLink II . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

8.2.2 Using a PROFIBUS host with the EDD . . . . . . . . . . . . . . . . . . . . . . . . . . 54

8.2.3 Using PROFIBUS bus parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

8.3 Configuring cutoffs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

8.3.1 Cutoffs and volume flow. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

8.4 Configuring the damping values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

8.4.1 Damping and volume measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

8.5 Configuring the flow direction parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

8.6 Configuring events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

8.6.1 Defining events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

8.6.2 Checking and reporting event status . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

8.6.3 Changing event setpoints from the display . . . . . . . . . . . . . . . . . . . . . . . 61

8.7 Configuring slug flow limits and duration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

8.8 Configuring status alarm severity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

8.9 Configuring the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

8.9.1 Update period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

8.9.2 Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

8.9.3 Display variables and display precision . . . . . . . . . . . . . . . . . . . . . . . . . . 66

8.9.4 LCD panel backlight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

8.9.5 Display functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

8.10 Configuring digital communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

8.10.1 PROFIBUS-DP node address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

8.10.2 IrDA port usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

8.10.3 Modbus address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

8.10.4 Modbus ASCII support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

8.10.5 Floating-point byte order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

8.10.6 Additional communications response delay . . . . . . . . . . . . . . . . . . . . . . . 71

8.10.7 Digital communications fault action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

8.10.8 Fault timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

8.11 Configuring device settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

8.12 Configuring PROFIBUS I&M function values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

8.13 Configuring sensor parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

8.14 Configuring the petroleum measurement application . . . . . . . . . . . . . . . . . . . . . . . . 74

8.14.1 About the petroleum measurement application . . . . . . . . . . . . . . . . . . . . 74

8.14.2 Configuration procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

8.15 Configuring the enhanced density application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

8.15.1 About the enhanced density application . . . . . . . . . . . . . . . . . . . . . . . . . 77

8.15.2 Configuration procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Chapter 9 Pressure Compensation and External Temperature

Compensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

9.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

9.2 Pressure compensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

9.2.1 Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

9.2.2 Pressure correction factors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

9.2.3 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

9.3 External temperature compensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

9.4 Obtaining external pressure and temperature data. . . . . . . . . . . . . . . . . . . . . . . . . . 86

Configuration and Use Manual iii

Contents

Chapter 10 Measurement Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

10.1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

10.2 Meter validation, meter verification, and calibration . . . . . . . . . . . . . . . . . . . . . . . . . 87

10.2.1 Meter verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

10.2.2 Meter validation and meter factors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

10.2.3 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

10.2.4 Comparison and recommendations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

10.3 Performing meter verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

10.3.1 Preparing for the meter verification test. . . . . . . . . . . . . . . . . . . . . . . . . . 91

10.3.2 Running the meter verification test, original version . . . . . . . . . . . . . . . . 91

10.3.3 Running Smart Meter Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

10.3.4 Reading and interpreting meter verification test results . . . . . . . . . . . . 102

10.3.5 Setting up automatic or remote execution of the

meter verification test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

10.4 Performing meter validation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

10.5 Performing zero calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

10.5.1 Preparing for zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

10.5.2 Zero procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

10.6 Performing density calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

10.6.1 Preparing for density calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

10.6.2 Density calibration procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

10.7 Performing temperature calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Chapter 11 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

11.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

11.2 Guide to troubleshooting topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

11.3 Micro Motion customer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

11.4 Transmitter does not operate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

11.5 Transmitter does not communicate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

11.6 Checking the communication device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

11.7 Diagnosing wiring problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

11.7.1 Checking the power supply wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

11.7.2 Checking PROFIBUS wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

11.7.3 Checking grounding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

11.8 Zero or calibration failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

11.9 Fault conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

11.10 Simulation mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

11.11 Transmitter LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

11.12 Status alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

11.13 Checking process variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

11.14 Checking slug flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

11.15 Checking the sensor tubes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

11.16 Checking the flow measurement configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

11.17 Checking the characterization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

11.18 Checking the calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

11.19 Restoring a working configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

11.20 Checking the test points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

11.20.1 Obtaining the test points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

11.20.2 Evaluating the test points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

11.20.3 Drive gain problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

11.20.4 Low pickoff voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

11.21 Checking sensor circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

iv Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Contents

Appendix A Default Values and Ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

A.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

A.2 Most frequently used defaults and ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Appendix B Transmitter Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

B.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

B.2 Transmitter components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

B.3 Terminals and connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

Appendix C Menu Flowcharts – Model 2400S DP Transmitters. . . . . . . . . . . . . 149

C.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

C.2 Version information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

C.3 ProLink II menu flowcharts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

C.4 EDD menu flowcharts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

C.5 Display menu flowcharts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

Appendix D PROFIBUS Bus Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

D.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

D.2 PROFIBUS-DP data types and data type codes. . . . . . . . . . . . . . . . . . . . . . . . . . . 166

D.3 Measurement block (Slot 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166

D.4 Calibration block (Slot 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

D.5 Diagnostic block (Slot 3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

D.6 Device Information block (Slot 4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

D.7 Local Display block (Slot 5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

D.8 API block (Slot 6). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

D.9 Enhanced Density block (Slot 7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

D.10 I&M functions (Slot 0) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

D.11 Totalizer and inventory measurement unit codes . . . . . . . . . . . . . . . . . . . . . . . . . . 185

D.12 Process variable codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

D.13 Alarm index codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Appendix E Display Codes and Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . 189

E.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

E.2 Codes and abbreviations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Configuration and Use Manual v

vi Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Chapter 1

Before You Begin

1.1 Overview

This chapter provides an orientation to the use of this manual, and includes a configuration overview
flowchart and a pre-configuration worksheet. This manual describes the procedures required to start,
configure, use, maintain, and troubleshoot the Micro Motion
PROFIBUS-DP (the Model 2400S DP transmitter).

If you do not know what transmitter you have, see Section 1.3 for instructions on identifying the
transmitter type from the model number on the transmitter’s tag.

Note: Information on configuration and use of Model 2400S transmitters with different I/O options is
provided in separate manuals. See the manual for your transmitter.

1.2 Safety

®

Model 2400S transmitter for

Startup Using ProLink IITransmitter User InterfaceBefore You Begin

Safety messages are provided throughout this manual to protect personnel and equipment. Read each
safety message carefully before proceeding to the next step.

1.3 Determining transmitter information

Transmitter type, user interface option, and output options are encoded in the model number located
on the transmitter tag. The model number is a string of the following form:

2400S*X*X******

In this string:

•

2400S identifies the transmitter family.

•The first

• The second

-

-

-

X (the seventh character) identifies the I/O option: D = PROFIBUS-DP

X (the ninth character) identifies the user interface option:

1 = Display with glass lens

3 = No display

4 = Display with non-glass lens

Configuration and Use Manual 1

Before You Begin

1.4 PROFIBUS-DP functionality

The Model 2400S DP transmitter implements the following PROFIBUS-DP functionality:

• Baud rates: standard baud rates between 9.6 kbits/sec and 12.0 Mbits/sec, automatically
detected by transmitter

• I/O slave messaging:

- Data exchange

- Acyclic

• Configuration methods:

- Node address: hardware address switches or software addressing

- Device description (EDD) conforming to the following: Specification for PROFIBUS

Device Description and Device Integration: Volume 2: EDDL V1.1, January 2001

- DP-V1 read and write services with PROFIBUS bus parameters

• Operation methods:

- GSD conforming to the following: Specification for PROFIBUS Device Description and

Device Integration: Volume 1: GSD V5.0, May 2003

- DP-V0 cyclic services

- Device description listed above

- DP-V1 read and write services

• Identification and maintenance (I&M) functions:

-I&M 0

-I&M 1

as specified in Profile Guidelines Part 1: Identification & Maintenance Functions
Version 1.1.1, March 2005.

1.5 Determining version information

Table 1-1 lists the version information that you may need and describes how to obtain the information.
(Additional information is available via the I&M functions. See Section 7.2.)

Table 1-1 Obtaining version information

Component Tool Method

Transmitter software With ProLink II

With EDD

With display

ProLink II With ProLink II

GSD version Text editor Open file MMI0A60.GSD

EDD version Text editor Open file MMICorFlowDP.ddl

View > Installed Options > Software Revision

MMI Coriolis Flow > Configuration Parameters >
Device

OFF-LINE MAINT > VER

Help > About ProLink II

Check parameter GSD_Revision

Check parameter DD_Revision

2 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Before You Begin

1.6 Communication tools

Most of the procedures described in this manual require the use of a communication tool. Table 1-2
lists the communication tools that can be used, with their functionality and requirements.

Note: You can use either ProLink II, the EDD, or PROFIBUS bus parameters for transmitter setup
and maintenance. It is not necessary to have more than one of these methods available.

Table 1-2 Communication tools for Model 2400S DP transmitter

Functionality

Tool

Transmitter display Partial Partial Transmitter with display

®

ProLink

Pocket ProLink

PROFIBUS host

• GSD Partial None GSD file (

• EDD Full Full

• Bus parameters Full Full

(1) Except for node address.

II Full Full

®

Full Full

(1)

(1)

(1)

(1)

RequirementView/operation Setup/maintenance

v2.5 (preliminary implementation)
v2.6 (full implementation)

v1.3 (preliminary implementation)
v1.4 (full implementation)

MMI0A60.GSD)

EDD file set

None

The EDD and the GSD can be downloaded from the Micro Motion web site:

www.micromotion.com.

In this manual:

• Basic information on using the transmitter’s user interface and display is provided in
Chapter 3.

• Basic information on using ProLink II or Pocket ProLink, and connecting ProLink II or
Pocket ProLink to your transmitter, is provided in Chapter 4. For more information, see the
ProLink II or Pocket ProLink manual, available on the Micro Motion web site
(www.micromotion.com).

• Basic information on using a PROFIBUS host is provided in Chapter 5.

Startup Using ProLink IITransmitter User InterfaceBefore You Begin

1.7 Planning the configuration

Refer to the configuration overview flowchart in Figure 1-1 to plan transmitter configuration. In
general, perform configuration steps in the order shown here.

Note: Depending on your installation and application, some configuration tasks may be optional.

Note: This manual provides information on topics that are not included in the configuration overview
flowchart, e.g.: using the transmitter, troubleshooting, and calibration procedures. Be sure to review
these topics as required.

Configuration and Use Manual 3

Before You Begin

Chapter 2
Flowmeter Startup

Chapter 1

Before You Begin

Chapter 9

Pressure Compensation and
Temperature Compensation

Fill out pre-configuration

worksheet

Apply power

Set the node address

Configure pressure

compensation (optional)

Configure temperature

compensation (optional)

Chapter 10

Measurement Performance

Perform initial meter

verification tests

Zero the flowmeter (optional)

Chapter 5

Using a Profibus Host

Obtain and import GSD

Establish communication

Import GSD input and output

modules

Obtain and import EDD

(if required)

Chapter 3 (if required)

Using the User Interface

Learn basic use

Chapter 4 (if required)

Connecting with ProLink II or
Pocket ProLink Software

Set up connection

Chapter 6

Required Configuration

Characterize the flowmeter

(if required)

Configure measurement units

Chapter 8

Optional Configuration

Configure volume flow

measurement for gas

Configure cutoffs

Configure damping

Configure flow direction

Configure events

Configure slug flow

Configure status alarm severity

Configure display functionality

Configure digital
communications

Configure device settings

Configure sensor parameters

Configure petroleum

measurement application or

enhanced density application

Configure I&M functions

Figure 1-1 Configuration overview

4 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Before You Begin

1.8 Pre-configuration worksheet

The pre-configuration worksheet provides a place to record information about your flowmeter and
your application. This information will affect your configuration options as you work through this
manual. You may need to consult with transmitter installation or application process personnel to
obtain the required information.

If you are configuring multiple transmitters, make copies of this worksheet and fill one out for each
individual transmitter.

Pre-configuration worksheet Transmitter ____________________________

Item Configuration data

Transmitter model number

Transmitter serial number

Transmitter software revision

Sensor model number

Sensor serial number

PROFIBUS-DP node
address ______________________________________

Measurement units Mass flow

Volume flow

Density

Pressure

Temperature

Installed applications

______________________________________

______________________________________

______________________________________

______________________________________

______________________________________

______________________________________

______________________________________

______________________________________

______________________________________

______________________________________



Micro Motion Smart Meter Verification



Meter verification application, original version



Petroleum measurement application



Enhanced density application

Startup Using ProLink IITransmitter User InterfaceBefore You Begin

Configuration and Use Manual 5

Before You Begin

1.9 Flowmeter documentation

Table 1-3 lists documentation sources for additional information.

Table 1-3 Flowmeter documentation resources

Topic Document

Sensor installation Sensor documentation

Transmitter installation Micro Motion

Hazardous area installation See the approval documentation shipped with the transmitter, or

1.10 Micro Motion customer service

For customer service, phone the support center nearest you:

®

Model 2400S Transmitters: Installation Manual

download the appropriate documentation from the Micro Motion web
site (www.micromotion.com)

• In the U.S.A., phone

800-522-MASS (800-522-6277) (toll-free)

• In Canada and Latin America, phone [phone]

•In Asia:

- In Japan, phone [phone]

- In other locations, phone [phone] (Singapore)

•In Europe:

- In the U.K., phone [phone] (toll-free)

- In other locations, phone [phone] (The Netherlands)

Customers outside the U.S.A. can also email Micro Motion customer service at
[e-mail].

6 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Chapter 2

Flowmeter Startup

2.1 Overview

This chapter describes the following procedures:

• Setting the node address – see Section 2.2

• Bringing the flowmeter online – see Section 2.3

2.2 Setting the node address

Three address switches are provided on the user interface module (see Figure 3-1 or Figure 3-2).
These switches are used to set a three-digit node address for the device:

• The leftmost switch sets the first digit.

• The center switch sets the second digit.

• The rightmost switch sets the third digit.

The default setting for the address switches is

You can set the node address manually before bringing the device online, by rotating the address
switches to any value between
switches were set, it will not accept the new node address until you perform a power cycle.

If the transmitter is brought online with the switches set to

• The device shows up at address

• You can set the node address programmatically by sending a Set Slave Address telegram from
the PROFIBUS host.

• You can set the node address manually by rotating the switches to any value between

125, then power-cycling the device.

For more information on setting the node address, see Section 8.10.1.

Note: It is not necessary to set the baud rate. because the Model 2400S DP transmitter automatically
detects and uses the DP segment baud rate.

Startup Using ProLink IITransmitter User InterfaceBefore You Begin

126.

0 and 125. If the transmitter was powered on at the time the address

126:

126 in the live list.

0 and

2.3 Bringing the transmitter online

To bring the transmitter online:

1. Follow appropriate procedures to ensure that the process of configuring and commissioning
the Model 2400S DP transmitter does not interfere with existing measurement and control
loops.

2. Ensure that the PROFIBUS cable is connected to the transmitter as described in the transmitter
installation manual.

3. Ensure that all transmitter and sensor covers and seals are closed.

Configuration and Use Manual 7

Flowmeter Startup

WARNING

4. Apply power to the transmitter. The flowmeter will automatically perform diagnostic routines.

Note: If this is the initial startup, or if power has been off long enough to allow components to reach
ambient temperature, the flowmeter is ready to receive process fluid approximately one minute after
power-up. However, it may take up to ten minutes for the electronics in the flowmeter to reach thermal
equilibrium. During this warm-up period, you may observe minor measurement instability or
inaccuracy.

5. Ensure that the transmitter is visible on the network. For information on establishing

Operating the flowmeter without covers in place creates electrical hazards
that can cause death, injury, or property damage.

To avoid electrical hazards, ensure that the transmitter housing cover and all other
covers are in place before connecting the transmitter to the network.

When the flowmeter has completed its power-up sequence, the status LED will turn green. If
the status LED exhibits different behavior, an alarm condition is present or transmitter
calibration is in progress. See Section 7.6.

communications between the Model 2400S DP transmitter and a PROFIBUS host, see
Chapter 5.

8 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Chapter 3

Using the Transmitter User Interface

3.1 Overview

This chapter describes the user interface of the Model 2400S DP transmitter. The following topics are
discussed:

• Transmitters without or with display – see Section 3.2

• Removing and replacing the transmitter housing cover – see Section 3.3

•Using the

• Using the display – see Section 3.5

3.2 User interface without or with display

The user interface of the Model 2400S DP transmitter depends on whether it was ordered with or
without a display:

• If ordered without a display, there is no LCD panel on the user interface. The user interface
provides the following features and functions:

- Three address switches, used to set the PROFIBUS node address

Scroll and Select optical switches – see Section 3.4

Startup Using ProLink IITransmitter User InterfaceBefore You Begin

- An internal termination resistor switch

- Three LEDs: a status LED, a network LED, and a software address LED

- Service port clips

- Zero button

For all other functions, either ProLink II or a customer-supplied PROFIBUS host is required.

• If ordered with a display, no zero button is provided (you must zero the transmitter with the
display menu, ProLink II, or a PROFIBUS host), and the following features are added:

- An LCD panel, which displays process variable data and also provides access to the

off-line menu for basic configuration and management. Optical switches are provided for
LCD control.

- An IrDA port which provides wireless access to the service port

Note: The off-line menu does not provide access to all transmitter functionality; for access to all
transmitter functionality, either ProLink II, the EDD, or PROFIBUS bus parameters must be used.

Figures 3-1 and 3-2 show the user interface of the Model 2400S DP transmitter without and with a
display. In both illustrations, the transmitter housing cover has been removed.

Configuration and Use Manual 9

Using the Transmitter User Interface

Status LED

Unused

Service port clips

Zero button

Network LED

Address switches

Internal termination

resistor switch

Software address LED

267.329

FLOW

GS/

Address switches

Current value

Unit of measure

Scroll optical switch

Select optical switch

Optical switch indicator

Status LED

Service port clips

LCD panel

Optical switch indicator

Network LED

Unused

Process variable

Internal termination

resistor switch

Software address LED

Figure 3-1 User interface – Transmitters without display

Figure 3-2 User interface – Transmitters with display

If the transmitter does not have a display, the transmitter housing cover must be removed to access all
user interface features and functions.

IrDA port

10 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Using the Transmitter User Interface

WARNING

If the transmitter has a display, the transmitter housing cover has a lens. All of the features shown in
Figure 3-2 are visible through the lens, and the following functions may be performed through the
lens (i.e., with the transmitter housing cover in place):

• Viewing the LEDs

• Viewing the LCD panel

•Using the

Select and Scroll optical switches

• Making a service port connection via the IrDA port

All other functions require removal of the transmitter housing cover.

For information on:

• Using the address switches, see Section 8.10.1.

• Using the LEDs, see Section 7.5.

• Making a service port connection, see Section 4.4.

• Using the zero button, see Section 10.5.

Note: The termination resistor switch is used to enable or disable the internal terminator. The internal
terminator can be used instead of an external terminator if termination is required at the transmitter.

3.3 Removing and replacing the transmitter housing cover

For some procedures, you must remove the transmitter housing cover. To remove the transmitter
housing cover:

1. If the transmitter is in a Division 2 or Zone 2 area, remove power from the unit.

Startup Using ProLink IITransmitter User InterfaceBefore You Begin

Removing the transmitter housing cover in a Division 2 or Zone 2 area while
the transmitter is powered up can cause an explosion.

To avoid the risk of an explosion, remove power from the transmitter before
removing the transmitter housing cover.

2. Loosen the four captive screws.

3. Lift the transmitter housing cover away from the transmitter.

When replacing the transmitter housing cover, be sure to adjust the cover and tighten the screws so
that no moisture can enter the transmitter housing.

3.4 Using the optical switches

Note: This section applies only to transmitters with a display.

The

Scroll and Select optical switches are used to navigate the display menus. To activate an optical

switch, touch the lens in front of the optical switch or move your finger over the optical switch close
to the lens. There are two optical switch indicators: one for each switch. When an optical switch is
activated, the associated optical switch indicator is a solid red.

Configuration and Use Manual 11

Using the Transmitter User Interface

CAUTION

Attempting to activate an optical switch by inserting an object into the
opening can damage the equipment.

To avoid damage to the optical switches, do not insert an object into the openings.
Use your fingers to activate the optical switches.

3.5 Using the display

Note: This section applies only to transmitters with a display.

The display can be used to view process variable data or to access the transmitter menus for
configuration or maintenance.

3.5.1 Display language

The display can be configured for the following languages:

• English

•French

• Spanish

•German

Due to software and hardware restrictions, some English words and terms may appear in the
non-English display menus. For a list of the codes and abbreviations used on the display, see
Appendix E.

For information on configuring the display language, see Section 8.9.

In this manual, English is used as the display language.

3.5.2 Viewing process variables

In ordinary use, the
and the

Units of measure line shows the measurement unit for that process variable.

Process variable line on the LCD panel shows the configured display variables,

• See Section 8.9.3 for information on configuring the display variables.

• See Appendix E for information on the codes and abbreviations used for display variables.

If more than one line is required to describe the display variable, the

Units of measure line alternates

between the measurement unit and the additional description. For example, if the LCD panel is
displaying a mass inventory value, the
unit (for example,

G) and the name of the inventory (for example, MASSI).

Units of measure line alternates between the measurement

Auto Scroll may or may not be enabled:

• If Auto Scroll is enabled, each configured display variable will be shown for the number of
seconds specified for Scroll Rate.

• Whether Auto Scroll is enabled or not, the operator can manually scroll through the configured
display variables by activating

Scroll.

For more information on using the display to view process variables or manage totalizers and
inventories, see Chapter 7.

12 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Using the Transmitter User Interface

3.5.3 Using display menus

Note: The display menu system provides access to basic transmitter functions and data. It does not
provide access to all functions and data. To access all functions and data, use either ProLink II or a
customer-supplied PROFIBUS tool.

To enter the display menu system:

1. Activate

Scroll and Select simultaneously.

2. Hold

Scroll and Select until the words SEE ALARM or OFF-LINE MAINT appear.

Note: Access to the display menu system may be enabled or disabled. If disabled, the OFF-LINE
MAINT option does not appear. For more information, see Section 8.9.

For entry into certain sections of the display menu:

• If a password has been enabled, you will be prompted to enter it. See Section 3.5.4.

• If a display password is not required, you will be prompted to activate the optical switches in a
pre-defined sequence (

Scroll-Select-Scroll). This feature is designed to prevent unintentional

entry to the menu caused by variations in ambient lighting or other environmental factors.

If no optical switch activity occurs for two minutes, the transmitter will exit the off-line menu system
and return to the process variable display.

To move through a list of options, activate

To select from a list or to enter a lower-level menu, scroll to the desired option, then activate

Scroll.

Select. If

a confirmation screen is displayed:

• To confirm the change, activate

• To cancel the change, activate

Select.

Scroll.

To exit a menu without making any changes:

•Use the

• Otherwise, activate

EXIT option if available.

Scroll at the confirmation screen.

Startup Using ProLink IITransmitter User InterfaceBefore You Begin

3.5.4 Display password

Some of the display menu functions, such as accessing the off-line menu, can be protected by a
display password. For information about enabling and setting the display password, refer to
Section 8.9.

If a password is required, the word
of the password one at a time by using

CODE? appears at the top of the password screen. Enter the digits

Scroll to choose a number and Select to move to the next

digit.

If you encounter the display password screen but do not know the password, wait 60 seconds without
activating any of the display optical switches. The password screen will time out automatically and
you will be returned to the previous screen.

3.5.5 Entering floating-point values with the display

Certain configuration values, such as meter factors or output ranges, are entered as floating-point
values. When you first enter the configuration screen, the value is displayed in decimal notation (as
shown in Figure 3-3) and the active digit is flashing.

Configuration and Use Manual 13

Using the Transmitter User Interface

SX.XXXX

Sign

For positive numbers, leave this space
blank. For negative numbers, enter a
minus sign (–).

Digits

Enter a number (maximum length: eight
digits, or seven digits and a minus sign).
Maximum precision is four.

Figure 3-3 Numeric values in decimal notation

To change the value:

1.

Select to move one digit to the left. From the leftmost digit, a space is provided for a sign. The

sign space wraps back to the rightmost digit.

2.

Scroll to change the value of the active digit: 1 becomes 2, 2 becomes 3, ..., 9 becomes 0, 0

becomes 1. For the rightmost digit, an E option is included to switch to exponential notation.

To change the sign of a value:

Select to move to the space that is immediately left of the leftmost digit.

1.

2. Use

Scroll to specify – (for a negative value) or [blank] (for a positive value).

In decimal notation, you can change the position of the decimal point up to a maximum precision of
four (four digits to the right of the decimal point). To do this:

1.

Select until the decimal point is flashing.

Scroll. This removes the decimal point and moves the cursor one digit to the left.

2.

3.

Select to move one digit to the left. As you move from one digit to the next, a decimal point

will flash between each digit pair.

4. When the decimal point is in the desired position,

Scroll. This inserts the decimal point and

moves the cursor one digit to the left.

To change from decimal to exponential notation (see Figure 3-4):

1.

Select until the rightmost digit is flashing.

2.

Scroll to E, then Select. The display changes to provide two spaces for entering the exponent.

3. To enter the exponent:

a.

Select until the desired digit is flashing.

b.

Scroll to the desired value. You can enter a minus sign (first position only), values

between 0 and 3 (for the first position in the exponent), or values between 0 and 9 (for the
second position in the exponent).

c.

Select.

Note: When switching between decimal and exponential notation, any unsaved edits are lost. The
system reverts to the previously saved value.

Note: While in exponential notation, the positions of the decimal point and exponent are fixed.

14 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Using the Transmitter User Interface

SX.XXXEYY

Sign

Digits

Enter a four-digit
number; three digits
must fall to the right
of the decimal point.

E

Exponent
indicator

Sign or Digit (0–3)

Digit (0–9)

Figure 3-4 Numeric values in exponential notation

To change from exponential to decimal notation:

1.

Select until the E is flashing.

2.

Scroll to d.

3.

Select. The display changes to remove the exponent.

To exit the menu:

• If the value has been changed,
is displayed.

-

Select to apply the change and exit.

Startup Using ProLink IITransmitter User InterfaceBefore You Begin

Select and Scroll simultaneously until the confirmation screen

-

Scroll to exit without applying the change.

• If the value has not been changed,
is displayed.

Select and Scroll simultaneously until the previous screen

Configuration and Use Manual 15

16 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Chapter 4

Connecting with ProLink II or Pocket ProLink Software

4.1 Overview

ProLink II is a Windows-based configuration and management tool for Micro Motion transmitters. It
provides complete access to transmitter functions and data. Pocket ProLink is a version of ProLink II
that runs on a Pocket PC.

This chapter provides basic information for connecting ProLink II or Pocket ProLink to your
transmitter. The following topics and procedures are discussed:

• Requirements – see Section 4.2

• Configuration upload/download – see Section 4.3

• Connecting to a Model 2400S DP transmitter – see Section 4.4

The instructions in this manual assume that users are already familiar with ProLink II or
Pocket ProLink software. For more information on using ProLink II, see the ProLink II manual. For
more information on using Pocket ProLink, see the Pocket ProLink manual. Both manuals are
available on the Micro Motion web site (www.micromotion.com). Instructions in this manual will
refer only to ProLink II.

Startup Using ProLink IITransmitter User InterfaceBefore You Begin

4.2 Requirements

To use ProLink II with the Model 2400S DP transmitter:

• You must have ProLink II v2.5 or higher.

• You must have either the ProLink II installation kit appropriate to your PC and connection
type, or the equivalent equipment. See the ProLink II manual or quick reference guide for
details.

To use Pocket ProLink with the Model 2400S DP transmitter:

• You must have Pocket ProLink v1.3 or higher.

• In addition:

- If you will connect to the transmitter via the service port clips, you must have either the

Pocket ProLink installation kit or the equivalent equipment. See the Pocket ProLink
manual or quick reference guide for details.

- If you will connect via the IrDA port, no additional equipment is required.

Configuration and Use Manual 17

Connecting with ProLink II or Pocket ProLink Software

4.3 Configuration upload/download

ProLink II and Pocket ProLink provide a configuration upload/download function which allows you
to save configuration sets to your PC. This allows:

• Easy backup and restore of transmitter configuration

• Easy replication of configuration sets

Micro Motion recommends that all transmitter configurations be saved to a PC as soon as the
configuration is complete. See Figure C-1, and refer to the ProLink II or Pocket ProLink manual for
details.

4.4 Connecting from a PC to a Model 2400S DP transmitter

To connect to the Model 2400S DP transmitter using ProLink II or Pocket ProLink, you must use a
service port connection.

4.4.1 Connection options

The service port can be accessed via the service port clips or the IrDA port.

The service port clips have priority over the IrDA port:

• If there is an active connection via the service port clips, access via the IrDA port is disabled.

• If there is an active connection via the IrDA port and a connection attempt is made via the
service port clips, the IrDA connection is terminated.

Additionally:

• Access via the IrDA port may be disabled altogether. In this case, it is not available for
connections at any time. By default, access via the IrDA port is disabled.

• The IrDA port may be write-protected. In this case, it can be used only to retrieve data from the
transmitter. By default, the IrDA port is write-protected.

See Section 8.10.2 for more information or to change these settings.

4.4.2 Service port connection parameters

The service port uses default connection parameters. Both ProLink II and Pocket ProLink
automatically use these default parameters when Protocol is set to Service Port.

Additionally, to minimize configuration requirements, the service port employs an auto-detection
scheme when responding to connection requests. The service port will accept all connection requests
within the limits described in Table 4-1. If you are connecting to the service port from another tool,
ensure that configuration parameters are set within these limits.

18 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Connecting with ProLink II or Pocket ProLink Software

WARNING

Table 4-1 Service port auto-detection limits

Parameter Option

Protocol Modbus ASCII or Modbus RTU

Address Responds to both:

Baud rate

Stop bits 1, 2

Parity Even, odd, none

(1) Service port support for Modbus ASCII may be disabled. See Section 8.10.4.
(2) See Section 8.10.3 for information on configuring the Modbus address.
(3) This is the baud rate between the service port and the connecting program. It is not the PROFIBUS DP baud rate.

(3)

• Service port address (111)

• Configured Modbus address (default=1)

Standard rates between 1200 and 38,400

4.4.3 Making the connection

To connect to the service port:

1. If you are using the IrDA port:

a. Ensure that the IrDA port is enabled (see Section 8.10.2).

b. Ensure that there is no connection via the service port clips.

(1)

(2)

Startup Using ProLink IITransmitter User InterfaceBefore You Begin Startup Using ProLink IITransmitter User InterfaceBefore You Begin Startup Using ProLink IITransmitter User InterfaceBefore You Begin Startup Using ProLink IITransmitter User InterfaceBefore You Begin

Note: Connections via the service port clips have priority over connections via the IrDA port. If you
are currently connected to the service port clips, you will not be able to connect via the IrDA port.

c. Position the IrDA device for communication with the IrDA port (see Figure 3-2). You do

not need to remove the transmitter housing cover.

Note: The IrDA port is typically used with Pocket ProLink. To use the IrDA port with ProLink II, a
special device is required; the IrDA port built into many laptop PCs is not supported. For more
information on using the IrDA port with ProLink II, contact Micro Motion customer service.

2. If you are using the service port clips:

a. Attach the signal converter to the serial or USB port of your PC, using the appropriate

connectors or adapters (e.g., a 25-pin to 9-pin adapter or a USB connector).

b. Remove the transmitter housing cover from the transmitter (see Section 3.3), then connect

the signal converter leads to the service port clips. See Figure 4-1.

Removing the transmitter housing cover in a hazardous area can cause an
explosion.

Because the transmitter housing cover must be removed to connect to the service
port clips, the service port clips should be used only for temporary connections, for
example, for configuration or troubleshooting purposes.

When the transmitter is in an explosive atmosphere, use a different method to
connect to your transmitter.

Configuration and Use Manual 19

Connecting with ProLink II or Pocket ProLink Software

Service port clips

RS-485 to RS-232
signal converter

25-pin to 9-pin serial port
adapter (if necessary)

RS-485/A

RS-485/B

PC

Figure 4-1 Service port connections to service port clips

3. Start ProLink II or Pocket ProLink software. From the Connection menu, click

Device

•

. In the screen that appears, specify:

Protocol: Service Port

• COM Port: as appropriate for your PC

No other parameters are required.

4. Click

Connect. The software will attempt to make the connection.

Note: While you are connected to the IrDA port, both optical switch indicators will flash red, and both
the Scroll and Select optical switches are disabled.

5. If an error message appears:

a. Ensure that you are using the correct COM port.

b. For connections to the IrDA port, ensure that the IrDA port is enabled.

c. For connections to the service port clips, swap the leads between the clips and try again.

d. For connections to the service port clips, check all the wiring between the PC and the

transmitter.

4.5 ProLink II language

ProLink II can be configured for several different languages. To configure the ProLink II language,
use the Tools menu. See Figure C-1.

In this manual, English is used as the ProLink II language.

Connect to

20 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Chapter 5

Using a PROFIBUS Host

5.1 Overview

This chapter provides basic information for using a PROFIBUS host with the Model 2400S DP
transmitter. The following topics are discussed:

• Support files – see Section 5.2

• Connecting to the Model 2400S DP transmitter from a PROFIBUS host – see Section 5.3

• Using a PROFIBUS host with the GSD – see Section 5.4

• Using a PROFIBUS host with the device description (EDD) – see Section 5.5

• Using PROFIBUS bus parameters – see Section 5.6

5.2 Support files

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

The following files are available for use with the Model 2400S DP transmitter:

•

MMI0A60.GSD – enables:

- Viewing process data and alarms

- Managing totalizers and inventories

- Accepting external pressure or temperature data for use in pressure or temperature
compensation

• Device description (EDD) – enables all of the above, plus:

- Configuration functionality

- Viewing event status

- Acknowledging alarms

- Performing zero and density calibration

- Performing meter verification

The GSD can be downloaded from the Micro Motion web site (
used with any compatible PROFIBUS host. The EDD can be downloaded from the Micro Motion web
site, and has been certified to work with Siemens Simatic PDM.

Set up the GSD or EDD using the method appropriate to your PROFIBUS host.

5.3 Connecting to the Model 2400S DP transmitter

To connect to the Model 2400S DP transmitter:

1. The transmitter automatically detects and uses the DP segment baud rate. If no baud rate is
detected, the transmitter does not attempt communication.

www.micromotion.com), and can be

Configuration and Use Manual 21

Using a PROFIBUS Host

2. The factory setting for the hardware address switches is 126, which is the default PROFIBUS
address for decommissioned devices. To commission the transmitter, the node address must be
set to a value in the commissioned range (

• If you will set the node address via the hardware address switches:

a. Set the node address to the desired value. See Section 8.10.1.

b. From the PROFIBUS host, connect to the network where the transmitter is installed.

c. Using the same methods that you use for other PROFIBUS-DP devices, establish a

• If you will set the node address via software:

a. Ensure that the hardware address switches are set to

b. From the PROFIBUS host, connect to the network where the transmitter is installed.

c. Using the same methods that you use for other PROFIBUS-DP devices, establish a

d. Send a Set Slave Address telegram. See Section 8.10.1.

5.4 Using the GSD

Modules available with the GSD are listed in Table 5-1. Note that input and output are from the
perspective of the PROFIBUS host; i.e.:

• Input modules input data from the transmitter onto the network, and to the PROFIBUS host.

• Output modules take output data from the network into the transmitter.

0–125).

connection to the Model 2400S DP transmitter.

126 or above.

connection to the Model 2400S DP transmitter.

Set up any desired modules for data exchange. You may select a maximum of 10 input modules.

Table 5-1 Input and output modules

Module number Module name Type Size (bytes) Comments

1 Device Status Input 1 • 0 = Good data

2 Mass Flow Input 4

3 Mass Total Input 4

4 Mass Inventory Input 4

5 Temperature Input 4

6 Density Input 4

7 Volume Flow Input 4 Liquid volume

8 Volume Total Input 4 Liquid volume

9 Volume Inventory Input 4 Liquid volume

10 Drive Gain Input 4

11 GSV Flow Input 4 Gas standard volume

12 GSV Total Input 4 Gas standard volume

13 GSV Inventory Input 4 Gas standard volume

14 API Density Input 4

15 API Volume Flow Input 4

16 API Volume Total Input 4

17 API Volume Inventory Input 4

• 1 = Bad data

22 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Using a PROFIBUS Host

Table 5-1 Input and output modules continued

Module number Module name Type Size (bytes) Comments

18 API Avg Density Input 4

19 API Avg Temperature Input 4

20 API CTL Input 4

21 ED Ref Density Input 4

22 ED Specific Gravity Input 4

23 ED Std Vol Flow Input 4

24 ED Std Vol Total Input 4

25 ED Std Vol Inv Input 4

26 ED Net Mass Flow Input 4

27 ED Net Mass Total Input 4

28 ED Net Mass Inv Input 4

29 ED Net Vol Flow Input 4

30 ED Net Vol Total Input 4

31 ED Net Vol Inv Input 4

32 ED Concentration Input 4

33 ED Baume Input 4

34 Ext Pressure Output 4

35 Ext Temperature Output 4

36 Start/Stop Totals Output 1 • 0 = Stop

•1 = Start

37 Reset Process Totals Output 1 • 0 = No action

•1 = Reset

38 Reset Inv Totals Output 1 • 0 = No action

•1 = Reset

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

5.5 Using the EDD

When imported into a PROFIBUS host, the EDD controls the organization of specific menus and
parameters. The menus and parameters controlled by the EDD are shown in Appendix C, Figures C-4
through C-12.

5.6 Using PROFIBUS bus parameters

Depending on your PROFIBUS host, you may be able to read and write PROFIBUS bus parameters
directly using DP-V1 services. PROFIBUS bus parameters provide direct access to all of the
functionality available through the transmitter’s DP port. PROFIBUS bus parameters are documented
in Appendix D.

Note that if you choose to configure or use the Model 2400S DP transmitter using PROFIBUS bus
parameters, several kinds of detailed information will be required, for example:

• The codes used to represent different options (e.g., different measurement units)

• The bits used to start and stop activities (e.g., totalizers or calibration procedures) or reset
totals

• The meaning of status bits within status words

The required information is supplied either in the relevant section in the manual or in Appendix D.

Configuration and Use Manual 23

24 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Chapter 6

Required Transmitter Configuration

6.1 Overview

This chapter describes the configuration procedures that are usually required when a transmitter is
installed for the first time.

The following procedures are discussed:

• Characterizing the flowmeter – see Section 6.2

• Configuring measurement units – see Section 6.3

This chapter provides basic flowcharts for each procedure. For more detailed flowcharts, see the
flowcharts for your communication tool, provided in the appendices to this manual.

For optional transmitter configuration parameters and procedures, see Chapter 8.

Note: All procedures provided in this chapter assume that you have established communication with

the Model 2400S DP transmitter and that you are complying with all applicable safety requirements.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Note: If you are using Pocket ProLink, the interface is similar to the ProLink II interface described in
this chapter.

6.2 Characterizing the flowmeter

Characterizing the flowmeter adjusts the transmitter to compensate for the unique traits of the sensor
it is paired with. The characterization parameters, or calibration parameters, describe the sensor’s
sensitivity to flow, density, and temperature.

6.2.1 When to characterize

If the transmitter and sensor were ordered together, then the flowmeter has already been
characterized. You need to characterize the flowmeter only if the transmitter and sensor are being
paired together for the first time.

6.2.2 Characterization parameters

The characterization parameters that must be configured depend on your flowmeter’s sensor type:
“T-Series” or “Other” (also referred to as “Straight Tube” and “Curved Tube,” respectively), as listed
in Table 6-1. The “Other” category includes all Micro Motion sensors except T-Series.

The characterization parameters are provided on the sensor tag. See Figure 6-1 for illustrations of
sensor tags.

Configuration and Use Manual 25

Required Transmitter Configuration

Other sensors

19.0005.13

0.0010

0.9980

12502.000

14282.000

4.44000

310

12500142864.44

T- S er i e s

Table 6-1 Sensor calibration parameters

Sensor type

Parameter

K1 ✓✓

K2 ✓✓

FD ✓✓

D1 ✓✓

D2 ✓✓

Temp coeff (DT)

Flowcal ✓

FCF ✓

FTG ✓

FFQ ✓

DTG ✓

DFQ1 ✓

DFQ2 ✓

(1) On some sensor tags, shown as TC.
(2) See the section entitled “Flow calibration values.”

(1)

Figure 6-1 Sample calibration tags

T- S eri e s O t h er

✓✓

(2)

Flow calibration values

Two factors are used to define flow calibration:

• The flow calibration factor, which is a 6-character string (five numbers and a decimal point)

• The temperature coefficient for flow, which is a 4-character string (three numbers and a
decimal point)

These values are concatenated on the sensor tag, but different labels are used for different sensors. As
shown in Figure 6-1:

• For T-Series sensors, the value is called the FCF value.

• For other sensors, the value is called the Flow Cal value.

26 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Required Transmitter Configuration

When configuring the flow calibration factor:

• Using ProLink II, enter the concatenated 10-character string exactly as shown, including the
decimal points. For example, using the Flow Cal value from Figure 6-1, enter

• Using other methods, you may be required to enter the concatenated value, or you may be
required to enter the two factors separately, i.e., enter a 6-character string and a 4-character
string. Include the decimal point in both strings. For example, using the Flow Cal value from
Figure 6-1:

-Enter

-Enter

19.000 for the flow calibration factor.

5.13 for the temperature coefficient for flow.

6.2.3 How to characterize

To characterize the flowmeter:

1. See the menu flowcharts in Figure 6-2.

2. Ensure that the correct sensor type is configured.

3. Set required parameters, as listed in Table 6-1.

19.0005.13.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Configuration and Use Manual 27

Required Transmitter Configuration

Device

· Sensor type

T Series Config

Straight

tube

Curved

tube

Sensor type?

ProLink >
Configuration

Flow

Density

Flow

Density

Sensor

· Sensor type code

T-Series

(1)

MMI Coriolis Flow >
Configuration parameters

Density

Flow

Sensor type

Flow values

Block: Device Information (Slot 4)
Index 8 (sensor type code)

Density values

(3)

Block: Calibration (Slot 2)
Index 16 (D1)
Index 17 (D2)
Index 18 (FD)
Index 26 (DTC)
Index 27 (FTG)
Index 28 (FFQ)
Index 29 (DTG)
Index 30 (DFQ1)
Index 31 (DFQ2)

Block: Calibration (Slot 2)
Index 4 (flow calibration factor, first six characters)
Index 5 (flow calibration factor, last four characters)

PROFIBUS host with EDDProLink II

PROFIBUS host with bus parameters

(2)

(1) Required only for T-Series sensors.
(2) For details on bus parameters, see Tables D-5 and

D-3.

(3) You will configure only a subset of the density values,

depending on sensor type.

Figure 6-2 Characterizing the flowmeter

6.3 Configuring the measurement units

For each process variable, the transmitter must be configured to use the measurement unit appropriate
to your application.

To configure measurement units, see the menu flowcharts in Figure 6-3. For details on measurement
units for each process variable, see Sections 6.3.1 through 6.3.4.

The measurement units used for totalizers and inventories are assigned automatically, based on the
measurement unit configured for the corresponding process variable. For example, if
per hour) is configured for mass flow, the unit used for the mass flow totalizer and mass flow
inventory is
through D-12.

Note: Pressure unit configuration is required only if you are using pressure compensation (see
Section 9.2) or you are using the Gas Wizard and you need to change the pressure units (see
Section 8.2.1).

28 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

kg/hr (kilograms

kg (kilograms). Codes used for the totalizer measurement units are listed in Tables D-10

Required Transmitter Configuration

Density

Temperature

Flow

(1)

Pressure

ProLink >
Configuration

Units

Off-line maint >
Off-line config

Vol (or GSV)

Density

Mass

Temperature

Pressure

Mass flow unit

Temperature unit

Block: Measurement (Slot 1)
Index 5

Density unit

Volume flow unit

(liquid)

Block: Measurement (Slot 1)
Index 7

Block: Measurement (Slot 1)
Index 9

Block: Measurement (Slot 1)
Index 11

Volume flow unit

(GSV)

Block: Measurement (Slot 1)
Index 38

Pressure unit

Block: Calibration (Slot 2)
Index 38

Density

Temperature

Flow

(2)

Pressure

Flow > GSV >
GSV Process Variables

(3)

MMI Coriolis Flow >
Configuration parameters

Display

ProLink II PROFIBUS host with EDD

(1) Used for mass flow, liquid volume flow, and gas standard volume flow.
(2) Used for mass flow and liquid volume flow.
(3) Used for gas standard volume flow.
(4) Set parameters to the desired Unit Code, as listed in Tables 6-2 through 6-7. See Tables D-2 and D-3 if

required.

PROFIBUS host with bus parameters

(4)

Figure 6-3 Configuring measurement units

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Configuration and Use Manual 29

Required Transmitter Configuration

6.3.1 Mass flow units

The default mass flow measurement unit is

g/s. See Table 6-2 for a complete list of mass flow

measurement units.

Table 6-2 Mass flow measurement units

Mass flow unit

Unit descriptionDisplay ProLink II EDD label EDD code

G/S g/s g_per_s 1318 Grams per second

G/MIN g/min g_per_min 1319 Grams per minute

G/H g/hr g_per_hr 1320 Grams per hour

KG/S kg/s kg_per_s 1322 Kilograms per second

KG/MIN kg/min kg_per_min 1323 Kilograms per minute

KG/H kg/hr kg_per_hr 1324 Kilograms per hour

KG/D kg/day kg_per_day 1325 Kilograms per day

T/MIN mTon/min t_per_min 1327 Metric tons per minute

T/H mTon/hr t_per_hr 1328 Metric tons per hour

T/D mTon/day t_per_day 1329 Metric tons per day

LB/S lbs/s lb_per_s 1330 Pounds per second

LB/MIN lbs/min lb_per_min 1331 Pounds per minute

LB/H lbs/hr lb_per_hr 1332 Pounds per hour

LB/D lbs/day lb_per_day 1333 Pounds per day

ST/MIN sTon/min Ston_per_min 1335 Short tons (2000 pounds) per minute

ST/H sTon/hr Ston_per_hr 1336 Short tons (2000 pounds) per hour

ST/D sTon/day Ston_per_day 1337 Short tons (2000 pounds) per day

LT/H lTon/hr Lton_per_hr 1340 Long tons (2240 pounds) per hour

LT/D lTon/day Lton_per_day 1341 Long tons (2240 pounds) per day

6.3.2 Volume flow units

The default volume flow measurement unit is

l/s (liters per second).

Two different sets of volume flow measurement units are provided:

• Units typically used for liquid volume – see Table 6-3

• Units typically used for gas standard volume – see Table 6-4

If you are using ProLink II or the display, only liquid volume flow units are listed by default. To
access the gas standard volume flow units, you must first configure the volume flow type: liquid or
gas standard.

If you want to measure gas standard volume flow, additional configuration is required. See Section 8.2
for more information.

30 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Required Transmitter Configuration

Table 6-3 Volume flow measurement units – Liquid

Volume flow unit

Display ProLink II EDD label EDD code Unit description

CUFT/S ft3/sec CFS 1356 Cubic feet per second

CUF/MN ft3/min CFM 1357 Cubic feet per minute

CUFT/H ft3/hr CFH 1358 Cubic feet per hour

CUFT/D ft3/day ft3_per_day 1359 Cubic feet per day

M3/S m3/sec m3_per_s 1347 Cubic meters per second

M3/MIN m3/min m3_per_min 1348 Cubic meters per minute

M3/H m3/hr m3_per_hr 1340 Cubic meters per hour

M3/D m3/day m3_per_day 1350 Cubic meters per day

USGPS US gal/sec gal_per_s 1362 U.S. gallons per second

USGPM US gal/min GPM 1363 U.S. gallons per minute

USGPH US gal/hr gal_per_hour 1364 U.S. gallons per hour

USGPD US gal/d gal_per_day 1365 U.S. gallons per day

MILG/D mil US gal/day Mgal_per_day 1366 Million U.S. gallons per day

L/S l/sec L_per_s 1351 Liters per second

L/MIN l/min L_per_min 1352 Liters per minute

L/H l/hr L_per_hr 1353 Liters per hour

MILL/D mil l/day Ml_per_day 1355 Million liters per day

UKGPS Imp gal/sec ImpGal_per_s 1367 Imperial gallons per second

UKGPM Imp gal/min ImpGal_per_min 1368 Imperial gallons per minute

UKGPH Imp gal/hr ImpGal_per_hr 1369 Imperial gallons per hour

UKGPD Imp gal/day ImpGal_per_day 1370 Imperial gallons per day

BBL/S barrels/sec bbl_per_s 1371 Barrels per second

BBL/MN barrels/min bbl_per_min 1372 Barrels per minute

BBL/H barrels/hr bbl_per_hr 1373 Barrels per hour

BBL/D barrels/day bbl_per_day 1374 Barrels per day

BBBL/S Beer barrels/sec Beer_bbl_per_s 1642 Beer barrels per second

BBBL/MN Beer barrels/min Beer_bbl_per_min 1643 Beer barrels per minute

BBBL/H Beer barrels/hr Beer_bbl_per_hr 1644 Beer barrels per hour

BBBL/D Beer barrelsday Beer_bbl_per_day 1645 Beer barrels per day

(1)

(1)

(1)

(1)

(2)

(2)

(2)

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

(2)

(1) Unit based on oil barrels (42 U.S. gallons).
(2) Unit based on U.S. beer barrels (31 U.S. gallons).

Configuration and Use Manual 31

Required Transmitter Configuration

Table 6-4 Volume flow measurement units – Gas

Volume flow unit

Display ProLink II EDD label EDD code Unit description

NM3/S Nm3/sec Nm3_per_s 1522 Normal cubic meters per second

NM3/MN Nm3/min Nm3_per_min 1523 Normal cubic meters per minute

NM3/H Nm3/hr Nm3_per_hr 1524 Normal cubic meters per hour

NM3/D Nm3/day Nm3_per_day 1525 Normal cubic meters per day

NLPS NLPS NL_per_s 1532 Normal liter per second

NLPM NLPM NL_per_min 1533 Normal liter per minute

NLPH NLPH NL_per_hr 1534 Normal liter per hour

NLPD NLPD NL_per_day 1535 Normal liter per day

SCFS SCFS SCFS 1604 Standard cubic feet per second

SCFM SCFM SCFM 1360 Standard cubic feet per minute

SCFH SCFH SCFH 1361 Standard cubic feet per hour

SCFD SCFD SCFD 1605 Standard cubic feet per day

SM3/S Sm3/S Sm3_per_s 1527 Standard cubic meters per second

SM3/MN Sm3/min Sm3_per_min 1528 Standard cubic meters per minute

SM3/H Sm3/hr Sm3_per_hr 1529 Standard cubic meters per hour

SM3/D Sm3/day Sm3_per_day 1530 Standard cubic meters per day

SLPS SLPS SL_per_s 1537 Standard liter per second

SLPM SLPM SL_per_min 1538 Standard liter per minute

SLPH SLPH SL_per_hr 1539 Standard liter per hour

SLPD SLPD SL_per_day 1540 Standard liter per day

6.3.3 Density units

The default density measurement unit is

g/cm3. See Table 6-2 for a complete list of density

measurement units.

Table 6-5 Density measurement units

Density unit

Unit descriptionDisplay ProLink II EDD label EDD code

G/CM3 g/cm3 g_per_cm3 1100 Grams per cubic centimeter

G/L g/l g_per_L 1105 Grams per liter

G/ML g/ml g_per_ml 1104 Grams per milliliter

KG/L kg/l kg_per_L 1103 Kilograms per liter

KG/M3 kg/m3 kg_per_m3 1097 Kilograms per cubic meter

LB/GAL lbs/Usgal lb_per_gal 1108 Pounds per U.S. gallon

LB/CUF lbs/ft3 lb_per_ft3 1107 Pounds per cubic foot

LB/CUI lbs/in3 lb_per_in3 1106 Pounds per cubic inch

32 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Required Transmitter Configuration

Table 6-5 Density measurement units continued

Density unit

Unit descriptionDisplay ProLink II EDD label EDD code

ST/CUY sT/yd3 Ston_per_yd3 1109 Short ton per cubic yard

D API degAPI DegAPI 1113 Degrees API

SGU SGU SGU 1114 Specific gravity unit (not temperature

corrected)

6.3.4 Temperature units

The default temperature measurement unit is °

C. See Table 6-6 for a complete list of temperature

measurement units.

Table 6-6 Temperature measurement units

Temperature unit

Unit descriptionDisplay ProLink II EDD label EDD code

°C °C Deg_C 1001 Degrees Celsius

°F °F Deg_F 1002 Degrees Fahrenheit

°R °R Deg_R 1003 Degrees Rankine

°K °K K 1000 Kelvin

6.3.5 Pressure units

The flowmeter does not measure pressure. You need to configure the pressure units if either of the
following is true:

• You will configure pressure compensation (see Section 9.2). In this case, configure the
pressure unit to match the pressure unit used by the external pressure device.

• You will use the Gas Wizard, you will enter a reference pressure value, and you need to change
the pressure unit to match the reference pressure value (see Section 8.2).

If you do not know whether or not you will use pressure compensation or the Gas Wizard, you do not
need to configure a pressure unit at this time. You can always configure the pressure unit later.

The default pressure measurement unit is

PSI. See Table 6-7 for a complete list of pressure

measurement units.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Table 6-7 Pressure measurement units

7

Pressure unit

Unit descriptionDisplay ProLink II EDD label EDD code

FTH2O Ft Water @ 68°F ft. H2O @68 DegF 1154 Feet water @ 68 °F

INW4C In Water

INW60 In Water @ 60°F inch H2O @60 DegF 1146 Inches water @ 60 °F

INH2O In Water

mmW4C mm Water @ 4°C mm H2O @4 DegC 1150 Millimeters water @ 4 °C

mmH2O mm Water

mmHG mm Mercury

Configuration and Use Manual 33

@ 4°C inch H2O @4 DegC 1147 Inches water @ 4 °C

@ 68°F inch H2O @68 DegF 1148 Inches water @ 68 °F

@ 68°F mm H2O @68 DegF 1151 Millimeters water @ 68 °F

@ 0°C mm Hg @0 DegC 1158 Millimeters mercury @ 0 °C

Required Transmitter Configuration

Table 6-7 Pressure measurement units continued

Pressure unit

Unit descriptionDisplay ProLink II EDD label EDD code

INHG In Mercury @ 0°C inch Hg @0 DegC 1156 Inches mercury @ 0 °C

PSI PSI psi 1141 Pounds per square inch

BAR bar bar 1137 Bar

mBAR millibar milibar 1138 Millibar

G/SCM g/cm2 g_per_cm2 1144 Grams per square centimeter

KG/SCM kg/cm2 kg_per_cm2 1145 Kilograms per square centimeter

PA pascals Pa 1130 Pascals

KPA Kilopascals KiloPa 1133 Kilopascals

MPA megapascals MegaPa 1132 Megapascals

TORR Torr

ATM atms atm 1140 Atmospheres

@ 0C torr @0 DegC 1139 Torr @ 0 °C

34 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Chapter 7

Using the Transmitter

7.1 Overview

This chapter describes how to use the transmitter in everyday operation. The following topics and
procedures are discussed:

• Using the I&M functions – see Section 7.2

• Recording process variables – see Section 7.3

• Viewing process variables – see Section 7.4

• Using the LEDs – see Section 7.5

• Viewing transmitter status and alarms – see Section 7.6

• Handling status alarms – see Section 7.7

• Viewing and using the totalizers and inventories – see Section 7.8

Note: All procedures provided in this chapter assume that you have established communication with
the Model 2400S DP transmitter and that you are complying with all applicable safety requirements.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Note: If you are using Pocket ProLink, the interface is similar to the ProLink II interface described in
this chapter.

7.2 Using the I&M functions

The Model 2400S DP transmitter implements the following PROFIBUS identification and
maintenance (I&M) functions:

•I&M 0

•I&M 1

as specified in Profile Guidelines Part 1: Identification & Maintenance Functions Version 1.1.1,

March 2005.

The I&M functions contain a variety of device and manufacturer information. Two of the I&M value
are set by the user during installation (see Section 8.12). The other values, including the Manufacturer
ID, are hard-coded. The Manufacturer ID stored on the transmitter can be used as a code to obtain
current device and manufacturer data from the PROFIBUS web site
(http://www.profibus.com/IM/Man_ID_Table.xml).

The I&M functions are not accessible via ProLink II or the display. If you are using Siemens Simatic
PDM, v6.0 SP2 or higher is required. Earlier versions do not support I&M functions.

Configuration and Use Manual 35

Using the Transmitter

To use the I&M functions:

1. Read the data from the transmitter:

• Using a PROFIBUS host with the EDD, connect to the transmitter as a Specialist. See
Figure C-12.

• Using PROFIBUS bus parameters, use the I&M Functions block (see Table D-9). You
must read the entire 64-byte dataset.

2. If desired, log onto the PROFIBUS web site and enter the Manufacturer ID code retrieved
from the transmitter.

7.3 Recording process variables

Micro Motion suggests that you make a record of the process variables listed below, under normal
operating conditions. This will help you recognize when the process variables are unusually high or
low, and may help in fine-tuning transmitter configuration.

Record the following process variables:

• Flow rate

• Density

•Temperature

• Tube frequency

• Pickoff voltage

•Drive gain

To view these values, see Section 7.4. For information on using this information in troubleshooting,
see Section 11.13.

7.4 Viewing process variables

Process variables include measurements such as mass flow rate, volume flow rate, mass total, volume
total, temperature, and density.

You can view process variables with the display (if your transmitter has a display), ProLink II, or a
PROFIBUS host.

Note: If the petroleum measurement application is enabled, two of the API process variables are
averages: Batch Weighted Average Density and Batch Weighted Average Temperature. For both of
these, the averages are calculated for the current totalizer period, i.e., since the last reset of the API
volume totalizer.

7.4.1 With the display

By default, the display shows the mass flow rate, mass total, volume flow rate, volume total,
temperature, density, and drive gain. If desired, you can configure the display to show other process
variables. See Section 8.9.3.

The LCD panel reports the abbreviated name of the process variable (e.g.,
current value of that process variable, and the associated unit of measure (e.g.,

DENS for density), the

G/CM3). See

Appendix E for information on the codes and abbreviations used for display variables.

36 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Using the Transmitter

To view a process variable with the display, refer to Figure 3-2 and:

• If Auto Scroll is enabled, wait until the desired process variable appears on the LCD panel.

• If Auto Scroll is not enabled,

- Appears on the process variable line, or

- Begins to alternate with the units of measure

The display precision can be configured separately for each process variable (see Section 8.9.3). This
affects only the value shown on the display, and does not affect the actual value as reported by the
transmitter via digital communications.

Process variable values are displayed using either standard decimal notation or exponential notation:

•Values < 100,000,000 are displayed in decimal notation (e.g.,

•Values ≥ 100,000,000 are displayed using exponential notation (e.g.,

Scroll until the name of the desired process variable either:

1234567.8).

1.000E08).

- If the value is less than the precision configured for that process variable, the value is
displayed as

0 (i.e., there is no exponential notation for fractional numbers).

- If the value is too large to be displayed with the configured precision, the displayed
precision is reduced (i.e., the decimal point is shifted to the right) as required so that the
value can be displayed.

7.4.2 With ProLink II

The Process Variables window opens automatically when you first connect to the transmitter. This
window displays current values for the standard process variables (mass, volume, density,
temperature, external pressure, and external temperature).

To view the standard process variables with ProLink II, if you have closed the Process Variables
window, click

To view API process variables (if the petroleum measurement application is enabled), click

API Process Variables

ProLink > Process Variables.

ProLink >

.

To view enhanced density process variables (if the enhanced density application is enabled), click

ProLink > ED Process Variables. Different enhanced density process variables are displayed,

depending on the configuration of the enhanced density application.

7.4.3 With a PROFIBUS host and the EDD

If you are using a PROFIBUS host with the EDD:

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

• Use the View menu (see Figure C-5) to view the standard process variables. Gas standard
volume, API, and enhanced density process variables are not displayed.

• Use the Device menu (see Figure C-6) to view all process variables.

7.4.4 With a PROFIBUS host and the GSD

If you are using a PROFIBUS host with the GSD, you must import the desired input modules to your
PROFIBUS host (see Section 5.4). The selected process variables will be available for viewing at the
PROFIBUS host.

Configuration and Use Manual 37

Using the Transmitter

7.4.5 With PROFIBUS bus parameters

To read process variable data with PROFIBUS bus parameters:

• For petroleum measurement process variables, use the API block (see Table D-7)

• For enhanced density process variables, use the Enhanced Density block (see Table D-8)

• For all other process variables, use the Measurement block (see Table D-2)

7.5 Using the LEDs

The user interface module provides three LEDs: a status LED, a network LED, and a software address
LED (see Figures 3-1 and 3-2).

• For transmitters with a display, the LEDs can be viewed with the transmitter housing cover in
place.

• For transmitters without a display, the transmitter housing cover must be removed to view the
LEDs (see Section 3.3).

For information on:

• Using the network LED, see Section 7.5.1.

• Using the software address LED, see Section 7.5.2.

• Using the status LED, see Section 7.6.1.

7.5.1 Using the network LED

Table 7-1 lists the different states of the network LED and defines each state.

Table 7-1 Network LED states, definitions, and recommendations

Network LED state Definition Comments

Off Device not online The PROFIBUS-DP communication channel is not

Solid green Device online and connected The device is in data exchange with a Class 1

Flashing green Device online but not connected The device has detected the network baud rate, but

Solid red Communication error Check for any of the following PROFIBUS

connected to any host system. Check the host
configuration and the wiring, and retry the
connection.

master or is being configured by a Class 2 master.
No action is required.

communication with a host has not been established.

communication issues: Invalid Parameterization,
Invalid Configuration, Invalid Slot, Invalid Index,
Invalid C2 Acyclic Communication Initiate Telegram.

7.5.2 Using the software address LED

Table 7-2 lists the different states of the software address LED and defines each state.

38 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Using the Transmitter

Table 7-2 Software address LED states, definitions, and recommendations

Software address LED state Definition

Off Device is in hardware addressing mode.

Solid red Device is in software addressing mode but address has not been set by host.

Solid green Device is in software addressing mode and address has been set by host.

7.6 Viewing transmitter status

You can view transmitter status using the status LED, ProLink II, a PROFIBUS host using the EDD,
or PROFIBUS bus parameters. Depending on the method chosen, different information is displayed.

7.6.1 Using the status LED

The status LED shows transmitter status as described in Table 7-3. Note that the status LED does not
report event status or alarm status for alarms with severity level set to Ignore (see Section 8.8).

Table 7-3 Transmitter status LED

Status LED state Alarm priority Definition

Green No alarm Normal operating mode

Flashing yellow A104 alarm Zero or calibration in progress

Yellow Low severity (information) alarm • Alarm condition: will not cause measurement error

• Digital communications report process data

Red High severity (fault) alarm • Alarm condition: will cause measurement error

• Digital communications go to configured fault
action (see Section 8.10.7)

7.6.2 Using ProLink II

ProLink II provides a Status window that displays:

• Device (alarm) status

•Event status

• Assorted other transmitter data

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

7.6.3 Using a PROFIBUS host and the EDD

Status information is located in the View menu (see Figure C-5) and the Device menu (see Figures
C-6 and C-7). The View menu displays alarm status. The Device menu displays:

•Alarm status

•Event status

• Meter and core processor diagnostics

7.6.4 Using PROFIBUS bus parameters

Status information is located in the Diagnostic block (see Table D-4).

Configuration and Use Manual 39

Using the Transmitter

7.7 Handling status alarms

Specific process or flowmeter conditions cause status alarms. Each status alarm has an alarm code.

Status alarms are classified into three severity levels: Fault, Information, and Ignore. Severity level
controls how the transmitter responds to the alarm condition.

Note: Some status alarms can be reclassified, i.e., configured for a different severity level. For
information on configuring severity level, see Section 8.8.

Note: For detailed information on a specific status alarm, including possible causes and
troubleshooting suggestions, see Table 11-2. Before troubleshooting status alarms, first acknowledge
all alarms. This will remove inactive alarms from the list so that you can focus troubleshooting efforts
on active alarms.

The transmitter maintains two status flags for each alarm:

• The first status flag indicates current “active” or “inactive” status.

• The second status flag indicates current “acknowledged” or “unacknowledged” status.

In addition, the transmitter maintains alarm history for the 50 most recent alarm occurrences. Alarm
history includes:

• The alarm code

• The “alarm active” timestamp

• The “alarm inactive” timestamp

• The “alarm acknowledged” timestamp

When the transmitter detects an alarm condition, it checks the severity level of the specific alarm and
performs the actions described in Table 7-4.

Table 7-4 Transmitter responses to status alarms

Alarm severity

(1)

level

Fault • “Alarm active” status flag set

Informational • “Alarm active” status flag set

Ignore • “Alarm active” status flag set

Status flags Alarm history

immediately

• “Alarm unacknowledged” status
flag set immediately

immediately

• “Alarm unacknowledged” status
flag set immediately

immediately

• “Alarm unacknowledged” status
flag set immediately

Transmitter response

Digital communications
fault action

“Alarm active” record
written to alarm history
immediately

“Alarm active” record
written to alarm history
immediately

No action Not activated

Activated after configured fault
timeout has expired (if
applicable)

Not activated

(2)

(1) See Section 8.8 for information on setting the alarm severity level.
(2) See Sections 8.10.7 and 8.10.8 for more information on digital communications fault action and fault timeout.

40 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Using the Transmitter

When the transmitter detects that the alarm condition has cleared:

• The first status flag is set to “inactive.”

• Digital communications fault action is deactivated (Fault alarms only).

• The “alarm inactive” record is written to alarm history (Fault and Informational alarms only).

• The second status flag is not changed.

Operator action is required to return the second status flag to “acknowledged.” Alarm
acknowledgment is optional. If the alarm is acknowledged, the “alarm acknowledged” record is
written to alarm history.

7.7.1 Using the display

The display shows information only about active Fault or Informational alarms, based on alarm status
bits. Ignore alarms are filtered out, and you cannot access alarm history via the display.

To view or acknowledge alarms using the display menus, see the flowchart in Figure 7-1.

If the transmitter does not have a display, or if operator access to the alarm menu is disabled (see
Section 8.9.5), alarms can be viewed and acknowledged using ProLink II, a PROFIBUS host with the
EDD, or PROFIBUS bus parameters. Alarm acknowledgment is optional.

Additionally, the display may be configured to enable or disable the Ack All function. If disabled, the
Ack All screen is not displayed and alarms must be acknowledged individually.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Configuration and Use Manual 41

Using the Transmitter

SEE ALARM

Scroll and Select simultaneously

for 4 seconds

ACK ALL

(1)

Yes

EXIT

Select

No

Alarm code

Scroll

ACK

Yes

Select

No

Active/

unacknowledged

alarms?

NoYes

Select

NO ALARM

EXIT

Scroll

Scroll

Select

Scroll

ScrollSelect

(1) This screen is displayed only if the ACK ALL

function is enabled (see Section 8.9.5) and
there are unacknowledged alarms.

Figure 7-1 Viewing and acknowledging alarms with the display

7.7.2 Using ProLink II

ProLink II provides two ways to view alarm information:

• The Status window

• The Alarm Log window

Status window

The Status window displays the current status of the alarms considered to be most useful for
information, service, or troubleshooting, including Ignore alarms. The Status window reads alarm
status bits, and does not access alarm history. The Status window does not display acknowledgment
information, and you cannot acknowledge alarms from the Status window.

42 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Using the Transmitter

In the Status window:

• Alarms are organized into three categories: Critical, Informational, and Operational. Each
category is displayed on a separate panel.

• If one or more alarms is active on a panel, the corresponding tab is red.

• On a panel, a green LED indicates “inactive” and a red LED indicates “active.”

Note: The location of alarms on the Status panels is pre-defined, and is not affected by alarm severity.

To use the Status window:

1. Click

ProLink > Status.

2. Click the tab for the alarm category you want to view.

Alarm Log window

The Alarm Log window selects information from alarm history, and lists all alarms of the following
types:

• All active Fault and Information alarms

• All inactive but unacknowledged Fault and Information alarms

Ignore alarms are never listed.

You can acknowledge alarms from the Alarm Log window.

In the Alarm Log window:

• The alarms are organized into two categories: High Priority and Low Priority. Each category is
displayed on a separate panel.

• On a panel, a green LED indicates “inactive but unacknowledged” and a red LED indicates
“active.”

Note: The location of alarms on the Alarm Log panels is pre-defined, and is not affected by alarm
severity.

To use the Alarm Log window:

1. Click

ProLink > Alarm Log.

2. Click the tab for the alarm category you want to view.

3. To acknowledge an alarm, click the

Ack checkbox. When the transmitter has processed the

command:

- If the alarm was inactive, it will be removed from the list.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

- If the alarm was active, it will be removed from the list as soon as the alarm condition

clears.

7.7.3 Using a PROFIBUS host with the EDD

If you are using a PROFIBUS host with the EDD, alarm information can be viewed in the Alarm
Status window. You can open the Alarm Status window in either of the following ways:

• By clicking

Device > Device > Alarm Status

• By clicking View > Display > Alarm Status

Configuration and Use Manual 43

Using the Transmitter

The Alarm Status window displays the current status of the alarms considered to be most useful for
information, service, or troubleshooting, including Ignore alarms. Active alarms are indicated with a
check.

Note: The Alarm Status window reads alarm status bits, and does not access alarm history.

You can use the Alarm Status window to acknowledge a single alarm or to acknowledge all alarms. To
acknowledge a single alarm:

1. Set the

2. Send the command to the transmitter.

To acknowledge all alarms:

1. Set the

2. Send the command to the transmitter.

7.7.4 Using PROFIBUS bus parameters

Using PROFIBUS bus parameters, you can use the Diagnostic block to view the status of a group of
preselected alarms, view information about a specific alarm, acknowledge a single alarm or all alarms,
and retrieve information from alarm history. See Table D-4.

To view the status of a group of preselected alarms, use Indices 10–17.

Acknowledge Alarm control to the alarm you want to acknowledge.

Acknowledge All Alarms control to Acknowledge.

Note: These are the same alarms that are displayed in the ProLink II Status window.

To view information about a single alarm:

1. Set Index 20 to the code of the alarm you want to check.

2. Read Index 22, and interpret the data using the following codes:

• 0x00 = Acknowledged and cleared

• 0x01 = Active and acknowledged

• 0x10 = Not acknowledged, but cleared

• 0x11 = Not acknowledged, and active

3. Other information about the indexed alarm is available in the following locations:

• Index 23: Number of times this alarm has become active

• Index 24: The time this alarm was last posted

• Index 25: The time this alarm was last cleared

To acknowledge a single alarm:

1. Set Index 20 to the code of the alarm you want to check.

2. Write a value of

To acknowledge all alarms, write a value of

0 to Index 22.

1 to Index 30.

To retrieve information from alarm history:

1. Set Index 26 to specifying the number of the alarm record you want to check. Valid values are

0–49.

Note: The alarm history is a circular buffer, and older records are overwritten by newer records. To
determine whether a record is newer or older than another record, you must compare their
timestamps.

44 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Using the Transmitter

2. Read the following values:

• Index 27: The alarm type

• Index 29: The time that this alarm changed status

• Index 28: The type of status change:

-1 = Alarm posted

- 2 = Alarm cleared

7.8 Using the totalizers and inventories

The totalizers keep track of the total amount of mass or volume measured by the transmitter over a
period of time. The totalizers can be started and stopped, and the totals can be viewed and reset.

The inventories track the same values as the totalizers. Whenever totalizers are started or stopped, all
inventories (including the API volume inventory and enhanced density inventories) are started or
stopped automatically. However, when totalizers are reset, inventories are not reset automatically –
you must reset inventories separately. This allows you to use the inventories to keep running totals
across multiple totalizer resets.

The transmitter can store totalizer and inventory values up to 2
internal totalizer to go into overflow.

64

. Values larger than this cause the

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

7.8.1 Viewing current totals for totalizers and inventories

You can view current totals for the totalizers and inventories with the display (if your transmitter has a
display), ProLink II, a PROFIBUS host, or PROFIBUS bus parameters.

With the display

You cannot view current totals with the display unless the display has been configured to show them.
See Section 8.9.3.

To view a totalizer or inventory value, refer to Figure 7-2 and:

1. Check for the word

TOTAL in the lower left corner of the LCD panel.

• If Auto Scroll is enabled, wait until the desired value appears on the LCD panel. You can

also

Scroll until the desired value appears.

• If Auto Scroll is not enabled,

Scroll until the desired value appears.

2. Refer to Table 7-5 to identify the process variable and unit of measure.

3. Read the current value from the top line of the display.

Table 7-5 Totalizer and inventory values on display

Process variable Display behavior

Mass total Unit of measure displayed; no alternation

Mass inventory Unit of measure alternates with

Volume total (liquid) Unit of measure displayed; no alternation

Volume inventory (liquid) Unit of measure alternates with

Gas standard volume total Unit of measure displayed; no alternation

Gas standard volume inventory Unit of measure alternates with GSV I

API corrected volume total Unit of measure alternates with TCORR

MASSI

LVO L I

Configuration and Use Manual 45

Using the Transmitter

208772.63
L

TOTAL

Current value

Unit of measure

TOTAL

Scroll optical switch

Select optical switch

Table 7-5 Totalizer and inventory values on display continued

Process variable Display behavior

API corrected volume inventory Unit of measure alternates with TCORI

ED net mass total Unit of measure alternates with NET M

ED net mass inventory Unit of measure alternates with NETMI

ED net volume total Unit of measure alternates with NET V

ED net volume inventory Unit of measure alternates with NETVI

ED standard volume total Unit of measure alternates with STD V

ED standard volume inventory Unit of measure alternates with STDVI

Figure 7-2 Totalizer and inventory values on display

With ProLink II

To view current totals for the totalizers and inventories with ProLink II:

1. Click

2. Select

ProLink.

Process Variables, API Process Variables, or ED Process Variables.

With a PROFIBUS host and the EDD

If you are using a PROFIBUS host with the EDD:

• Use the View menu (see Figure C-5) to view the standard totals and inventories. Totals for gas
standard volume, API, and enhanced density process variables are not displayed.

• Use the Device menu (see Figure C-6) to view all total and inventory values.

With a PROFIBUS host and the GSD

If you are using a PROFIBUS host with the GSD, you must import the desired input modules to your
PROFIBUS host (see Section 5.4). The selected process variables will be available for viewing at the
PROFIBUS host.

46 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Using the Transmitter

RESET

(6)(7)

Select

Scroll

STOP/START

(4)(5)

RESET YES?

Process variable

display

STOP/START YES?

Scroll

Mass total

(1)

Volume total

(1)

Scroll

Select

Yes No

Select Scroll

EXIT

Select

Yes No

Select Scroll

ED total

(1)(2)

Scroll

API total

(1)(2)

Scroll

E1--SP

(3)

E2--SP

(3)

Scroll Scroll

(1) Displayed only if configured as a display variable.
(2) The petroleum measurement application or enhanced density application must be enabled.
(3) The Event Setpoint screens can be used to define or change Setpoint A for Event 1 or Event 2 only. These screens are displayed

only for specific types of events. To reset the setpoint for an event defined on mass total, you must enter the totalizer management
menu from the mass total screen. To reset the setpoint for an event defined on volume total, you must enter the totalizer
management menu from the volume total screen. See Section 8.6.3 for more information.

(4) The display must be configured to allow stopping and starting. See Section 8.9.5.
(5) All totalizers and inventories will be stopped and started together, including API and enhanced density totalizers and inventories.
(6) The display must be configured to allow totalizer resetting. See Section 8.9.5.
(7) Only the totalizer currently shown on the display will be reset. No other totalizers will be reset, and no inventories will be reset.

Be sure that the totalizer you want to reset is displayed before performing this reset.

With PROFIBUS bus parameters

To view current totals for the totalizers and inventories using PROFIBUS bus parameters, see
Section 7.4.5.

7.8.2 Controlling totalizers and inventories

Specific starting, stopping, and resetting functionality depends on the tool you are using.

With the display

If the required value is shown on the display, you can use the display to start and stop all totalizers
and inventories simultaneously, or to reset individual totalizers. See the flowchart in Figure 7-3. You
cannot reset any inventories with the display.

Figure 7-3 Controlling totalizers and inventories with the display

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Configuration and Use Manual 47

Using the Transmitter

With ProLink II

The totalizer and inventory control functions available with ProLink II are listed in Table 7-6. Note
the following:

• ProLink II does not support separate resetting of the API volume totalizer and API volume
inventory. To reset these, you must reset all totalizers or all inventories.

• By default, the ability to reset inventories from ProLink II is disabled. To enable it:

a. Click

b. Check the

View > Preferences.

Enable Inventory Totals Reset checkbox.

c. Click

Apply.

Table 7-6 Totalizer and inventory control functions supported by ProLink II

Inventory reset

Object Function Disabled Enabled

Totalizers and
inventories

Totalizers Resetting all ✓✓

Inventories Resetting all ✓

Starting and stopping as a group ✓✓

Resetting mass totalizer separately ✓✓

Resetting volume totalizer separately ✓✓

Resetting enhanced density totalizers separately ✓✓

Resetting API volume totalizer separately Not supported Not supported

Resetting mass inventory separately ✓

Resetting volume inventory separately ✓

Resetting enhanced density inventories separately ✓

Resetting API volume inventory separately Not supported Not supported

To start or stop all totalizers and inventories:

1. Click

ProLink > Totalizer Control or ProLink > ED Totalizer Control (if the enhanced

density application is enabled).

2. Click the All Totals

Start or All Totals Stop button.

Note: The All Totals functions are replicated in these two windows for convenience. You can start or
stop all totalizers and inventories from either window.

To reset all totalizers:

1. Click

ProLink > Totalizer Control or ProLink > ED Totalizer Control (if the enhanced

density application is enabled).

2. Click the All Totals

Reset button.

To reset all inventories:

1. Click

ProLink > Totalizer Control or ProLink > ED Totalizer Control (if the enhanced

density application is enabled).

2. Click the All Totals

48 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Reset Inventories button.

Using the Transmitter

To reset an individual totalizer or inventory:

1. Click

ProLink > Totalizer Control or ProLink > ED Totalizer Control (if the enhanced

density application is enabled).

2. Click the appropriate button (e.g.,

Mass Total

).

Reset Mass Total, Reset Volume Inventory, Reset Net

With a PROFIBUS host and the EDD

If you are using a PROFIBUS host with the EDD, you can use the Device window to stop and start all
totalizers and inventories together; reset all totalizers together; reset all inventories together; or reset
standard, API, or enhanced density totals and inventories separately. See Figure C-6.

With a PROFIBUS host and the GSD

If you are using a PROFIBUS host with the GSD, output modules 36, 37, and 38 are used for totalizer
and inventory control. You can start and stop all totalizers and inventories together, reset all totalizers
together, or reset all inventories together. To use these output modules:

1. Import them to your PROFIBUS host.

2. Send the appropriate Reset command to the transmitter.

With PROFIBUS bus parameters

The totalizer and inventory control functions available with PROFIBUS bus parameters are listed in
Table 7-7.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Table 7-7 Totalizer and inventory control with PROFIBUS bus parameters

To accomplish this Use

Stop all totalizers and inventories Measurement block (Slot 1)

Index: 22
Val ue: 0

Start all totalizers and inventories Measurement block (Slot 1)

Index: 22
Val ue: 1

Reset all totalizers Measurement block (Slot 1)

Reset all inventories Measurement block (Slot 1)

Reset mass totalizer Measurement block (Slot 1)

Reset mass inventory Measurement block (Slot 1)

Reset liquid volume totalizer Measurement block (Slot 1)

Reset liquid volume inventory Measurement block (Slot 1)

Reset gas standard volume totalizer Measurement block (Slot 1)

Index: 23
Val ue: 1

Index: 24
Val ue: 1

Index: 25
Val ue: 1

Index: 43
Val ue: 1

Index: 26
Val ue: 1

Index: 44
Val ue: 1

Index: 41
Val ue: 1

Configuration and Use Manual 49

Using the Transmitter

Table 7-7 Totalizer and inventory control with PROFIBUS bus parameters continued

To accomplish this Use

Reset gas standard volume inventory Measurement block (Slot 1)

Index: 42
Val ue: 1

Reset API reference volume total API block (Slot 6)

Reset API reference volume inventory API block (Slot 6)

Reset ED standard volume total Enhanced Density block (Slot 7)

Reset ED net mass total Enhanced Density block (Slot 7)

Reset ED net volume total Enhanced Density block (Slot 7)

Reset ED standard volume inventory Enhanced Density block (Slot 7)

Reset ED net mass inventory Enhanced Density block (Slot 7)

Reset ED net volume inventory Enhanced Density block (Slot 7)

Index: 11
Val ue: 1

Index: 12
Val ue: 1

Index: 17
Val ue: 1

Index: 18
Val ue: 1

Index: 19
Val ue: 1

Index: 20
Val ue: 1

Index: 21
Val ue: 1

Index: 22
Val ue: 1

50 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Chapter 8

Optional Configuration

8.1 Overview

This chapter describes transmitter configuration parameters that may or may not be used, depending
on your application requirements. For required transmitter configuration, see Chapter 6.

Table 8-1 lists the parameters that are discussed in this chapter. Default values and ranges for the most
commonly used parameters are provided in Appendix A.

Note: All procedures provided in this chapter assume that you have established communication with
the Model 2400S DP transmitter and that you are complying with all applicable safety requirements.

Note: If you are using Pocket ProLink, the interface is similar to the ProLink II interface described in
this chapter.

Table 8-1 Configuration map

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Method

Topic Subtopic ProLink II PROFIBUS host

Volume flow
measurement for gas

Cutoffs ✓✓ 8.3

Damping ✓✓ 8.4

Flow direction ✓✓ 8.5

Events ✓✓ 8.6

Slug flow ✓✓ 8.7

Status alarm severity ✓✓ 8.8

Display

(2)

Update period ✓✓ ✓8.9.1

Display language ✓✓ ✓8.9.2

Display variables and
precision

LCD panel backlight ✓✓ 8.9.4

Totalizer start/stop ✓✓ ✓8.9.5

Totalizer reset ✓✓ ✓

Auto scroll ✓✓ ✓

Scroll rate ✓✓ ✓

Offline menu ✓✓ ✓

Password ✓✓ ✓

Alarm menu ✓✓ ✓

Ack all ✓✓ ✓

✓✓ 8.2

✓✓ 8.9.3

(1)

Display Section

Configuration and Use Manual 51

Optional Configuration

Table 8-1 Configuration map continued

Method

(1)

Topic Subtopic ProLink II PROFIBUS host

Digital communication
settings

Device settings ✓✓

I&M functions ✓ 8.12

Sensor parameters ✓✓ 8.13

Petroleum
measurement
application

Enhanced density
application

PROFIBUS node
address

IrDA port usage ✓✓ ✓8.10.2

Modbus address ✓✓8.10.3

Modbus ASCII support ✓✓8.10.4

Floating-point byte
order

Additional
communications
response delay

Digital communications
fault action

Fault timeout ✓✓ 8.10.8

✓ 8.10.5

✓ 8.10.6

✓✓ 8.10.7

✓✓ 8.14

✓✓ 8.15

(3)

✓

(5)

Display Section

(4)

✓

8.10.1

8.11

(1) Via either the EDD or PROFIBUS bus parameters.
(2) These parameters apply only to transmitters with a display.
(3) Via a Set Slave Address telegram.
(4) Via the address witches on the face of the transmitter.
(5) Via PROFIBUS bus parameters only.

8.2 Configuring volume flow measurement for gas

Two types of volume flow measurement are available:

• Liquid volume (the default)

•Gas standard volume

Only one type of volume flow measurement can be performed at a time (i.e., if liquid volume flow
measurement is enabled, gas standard volume flow measurement is disabled, and vice versa).
Different sets of volume flow measurement units are available, depending on which type of volume
flow measurement is enabled (see Tables 6-3 and 6-4). If you want to use a gas volume flow unit,
additional configuration is required.

Note: If you will use the petroleum measurement application or the enhanced density application,
liquid volume flow measurement is required.

52 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

The method used to configure volume flow measurement for gas depends on the method you are
using: ProLink II, a PROFIBUS host with the EDD, or PROFIBUS bus parameters. In all cases, you
must:

• Enable gas standard volume flow

• Select the measurement unit to use

• Set the low flow cutoff value

• Specify the standard density (density at reference conditions) of your gas

Note: Using the display, you can only select a volume measurement unit from the set available for the
configured volume flow type. You cannot configure any other parameters.

8.2.1 Using ProLink II

To configure volume flow measurement for gas using ProLink II:

1. Click

2. Set

3. Select the measurement unit you want to use from the
The default is

4. Configure the

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

ProLink > Configure > Flow.

Vol Flow Type to Std Gas Volume.

Std Gas Vol Flow Units dropdown list.

SCFM.

Std Gas Vol Flow Cutoff (see Section 8.3). The default is 0.

5. If you know the standard density of the gas that you are measuring, enter it in the

Density

field. If you do not know the standard density, you can use the Gas Wizard. See the

following section.

Using the Gas Wizard

The Gas Wizard is used to calculate the standard density of the gas that you are measuring.

To use the Gas Wizard:

1. Click

2. Click the

3. If your gas is listed in the

ProLink > Configure > Flow.

Gas Wizard button.

a. Enable the

Choose Gas radio button.

Choose Gas dropdown list:

b. Select your gas.

4. If your gas is not listed, you must describe its properties.

a. Enable the

b. Enable the method that you will use to describe its properties:

Specific Gravity Compared to Air, or Density.

c. Provide the required information. Note that if you selected

Enter Other Gas Property radio button.

Molecular Weight,

Density, you must enter the

value in the configured density units and you must provide the temperature and pressure at
which the density value was determined.

Std Gas

Note: Ensure that the values entered here are correct, and that fluid composition is stable. If either of
these conditions is not met, gas flow measurement accuracy will be degraded.

5. Click

Next.

6. Verify the reference temperature and reference pressure. If these are not appropriate for your
application, click the

Change Reference Conditions button and enter new values for

reference temperature and reference pressure.

Configuration and Use Manual 53

Optional Configuration

7. Click Next. The calculated standard density value is displayed.

• If the value is correct, click

• If the value is not correct, click

Finish. The value will be written to transmitter configuration.

Back and modify input values as required.

Note: The Gas Wizard displays density, temperature, and pressure in the configured units. If required,
you can configure the transmitter to use different units. See Section 6.3.

8.2.2 Using a PROFIBUS host with the EDD

To configure volume flow measurement for gas using a PROFIBUS host with the EDD:

1. Referring to Figure C-8:

a. Enable GSV.

b. Send the command to the transmitter.

c. Configure

Gas density value, GSV flow units, GSV total units, and GSV cutoff as

desired.

2. Send the command to the transmitter.

8.2.3 Using PROFIBUS bus parameters

To configure volume flow measurement for gas using PROFIBUS bus parameters:

1. Referring to the Measurement block (Table D-2):

a. Enable gas standard volume measurement (Index 33).

b. Set other gas measurement parameters as desired (Indices 34, 38, and 40).

2. Send the command to the transmitter.

8.3 Configuring cutoffs

Cutoffs are user-defined values below which the transmitter reports a value of zero for the specified
process variable. Cutoffs can be set for mass flow, volume flow, gas standard volume flow, and
density.

See Table 8-2 for cutoff default values and related information. See Section 8.3.1 for information on
how the cutoffs interact with other transmitter measurements.

To configure cutoffs:

• Using ProLink II, see Figure C-2.

• Using a PROFIBUS host with the EDD, see Figure C-8.

• Using PROFIBUS bus parameters, use the Measurement block (see Table D-2), Indices 18, 19,
20, and 40.

Note: This functionality cannot be configured via the display menus.

54 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

Table 8-2 Cutoff default values

Cutoff type Default Comments

Mass flow 0.0 g/s Recommended setting: 5% of the sensor’s rated maximum flowrate

Volume flow 0.0 L/s Limit: the sensor’s flow calibration factor in liters per second, multiplied by 0.2

Gas standard volume
flow

Density 0.2 g/cm

0.0 SCFM No limit

3

Range: 0.0–0.5 g/cm

3

8.3.1 Cutoffs and volume flow

If liquid volume flow is enabled:

• The density cutoff is applied to the volume flow calculation. Accordingly, if the density drops
below its configured cutoff value, the volume flow rate will go to zero.

• The mass flow cutoff is not applied to the volume flow calculation. Even if the mass flow
drops below the cutoff, and therefore the mass flow indicators go to zero, the volume flow rate
will be calculated from the actual mass flow process variable.

If gas standard volume flow is enabled, neither the mass flow cutoff nor the density cutoff is applied
to the volume flow calculation.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

8.4 Configuring the damping values

A damping value is a period of time, in seconds, over which the process variable value will change to
reflect 63% of the change in the actual process. Damping helps the transmitter smooth out small,
rapid measurement fluctuations.

• A high damping value makes the output appear to be smoother because the output must change
slowly.

• A low damping value makes the output appear to be more erratic because the output changes
more quickly.

Damping can be configured for flow, density, and temperature.

When you specify a new damping value, it is automatically rounded down to the nearest valid
damping value. Valid damping values are listed in Table 8-3.

Note: For gas applications, Micro Motion recommends a minimum flow damping value of 2.56.

Before setting the damping values, review Section 8.4.1 for information on how the damping values
affect other transmitter measurements.

To configure damping values:

• Using ProLink II, see Figure C-2.

• Using a PROFIBUS host with the EDD, see Figure C-8.

• Using PROFIBUS bus parameters, use the Measurement block (see Table D-2), Indices 12, 13,
and 14.

Note: This functionality cannot be configured via the display menus.

Configuration and Use Manual 55

Optional Configuration

Table 8-3 Valid damping values

Process variable Valid damping values

Flow (mass and volume) 0, 0.04, 0.08, 0.16, ... 40.96

Density 0, 0.04, 0.08, 0.16, ... 40.96

Temperature 0, 0.6, 1.2, 2.4, 4.8, ... 76.8

8.4.1 Damping and volume measurement

When configuring damping values, note the following:

• Liquid volume flow is derived from mass and density measurements; therefore, any damping
applied to mass flow and density will affect liquid volume measurement.

• Gas standard volume flow is derived from mass flow measurement, but not from density
measurement. Therefore, only damping applied to mass flow will affect gas standard volume
measurement.

Be sure to set damping values accordingly.

8.5 Configuring the flow direction parameter

The flow direction parameter controls how the transmitter reports flow rate and how flow is added to
or subtracted from the totalizers, under conditions of forward flow, reverse flow, or zero flow.

• Forward (positive) flow moves in the direction of the arrow on the sensor.

• Reverse (negative) flow moves in the direction opposite of the arrow on the sensor.

Options for flow direction include:

• Forward only

•Reverse only

• Absolute value

• Bidirectional

• Negate/Forward only

• Negate/Bidirectional

For the effect of flow direction on flow totals and flow values, see Table 8-4.

To configure flow direction:

• Using ProLink II, see Figure C-2.

• Using a PROFIBUS host with the EDD, see Figure C-8.

• Using PROFIBUS bus parameters, use the Measurement block (see Table D-2), Index 21.

Note: This functionality cannot be configured via the display menus.

56 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

Table 8-4 Effect of flow direction on totalizers and flow values

Forward flow

Flow direction value

Forward only Increase Positive

Reverse only No change Positive

Bidirectional Increase Positive

Absolute value Increase Positive

Negate/Forward only No change Negative

Negate/Bidirectional Decrease Negative

Flow totals Flow values

(1)

Zero flow

Flow direction value

All No change 0

Flow direction value

Forward only No change Negative

Reverse only Increase Negative

Bidirectional Decrease Negative

Absolute value Increase Positive

Negate/Forward only Increase Positive

Negate/Bidirectional Increase Positive

Flow totals Flow values

Reverse flow

(3)

Flow totals Flow values

(2)

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

(2)

(1) Process fluid flowing in same direction as flow direction arrow on sensor.
(2) Refer to the digital communications status bits for an indication of whether flow is positive or negative.
(3) Process fluid flowing in opposite direction from flow direction arrow on sensor.

8.6 Configuring events

An event occurs if the real-time value of a user-specified process variable varies above or below a
user-specified value, or inside or outside a user-specified range. You can configure up to five events.

You may optionally specify one or more actions that will occur if the event occurs. For example, if
Event 1 occurs, you may specify that the transmitter will stop all totalizers and inventories and reset
the mass totalizer.

8.6.1 Defining events

To define an event:

• Using ProLink II, see Figure C-3.

• Using a PROFIBUS host with the EDD, see Figure C-9.

• Using PROFIBUS bus parameters, use the Diagnostic block (see Table D-4).

The following general steps are required:

1. Select the event to define (Diagnostic block, Index 4).

2. Specify the Event Type (Diagnostic block, Index 5). Event Type options are defined in
Table 8-5.

3. Assign a process variable to the event (Diagnostic block, Index 8).

Configuration and Use Manual 57

Optional Configuration

4. Specify the event’s setpoint(s) – the value(s) at which the event will occur or switch state (ON
to OFF, or vice versa).

• If Event Type is High or Low, only Setpoint A (Diagnostic block, Index 6) is used.

• If Event Type is In Range or Out of Range, both Setpoint A (Diagnostic block, Index 6)

Note: If a mass or volume total has been assigned to Event 1 or Event 2 and also configured as a
display variable, if the event type is High or Low, and the transmitter is configured to allow resetting
totalizers from the display, you can use the display to define or change the high setpoint (Setpoint A).
See Section 7-3.

5. Assign the event to an action or actions, if desired. Possible actions are listed in Table 8-6. To
do this:

• Using ProLink II, open the Discrete Input panel in the Configuration window, identify the

Note: For consistency with other Micro Motion products, the Discrete Input panel is used here even
though the Model 2400S DP transmitter does not provide a discrete input.

• Using the display, see Figure C-15 and use the ACT submenu.

• Using a PROFIBUS host with the EDD, see Figure C-10.

• Using PROFIBUS bus parameters, use Index 83 in the Diagnostic block (see Table D-4) to

and Setpoint B (Diagnostic block, Index 7) are required.

action to be performed, then specify the event using the dropdown list. See Figure C-3.

specify the event, and Index 82 to assign the action.

Table 8-5 Event types

Type Description

High (> A) Default. Discrete event will occur if the assigned variable is greater than the setpoint (A).

Low (< A) Discrete event will occur if the assigned variable is less than the setpoint (A).

In Range Discrete event will occur if the assigned variable is greater than or equal to the low setpoint (A) and less

than or equal to the high setpoint (B).

Out of Range Discrete event will occur if the assigned variable is less than or equal to the low setpoint (A) or greater

than or equal to the high setpoint (B).

(1) An event does not occur if the assigned variable is equal to the setpoint.
(2) An event occurs if the assigned variable is equal to the setpoint.

(2)

(2)

(1)

(1)

Table 8-6 Event actions

ProLink II label Display label EDD label Description

Start sensor zero START ZERO Start Sensor

Zero

Reset mass total RESET MASS Reset Mass

To tal

Reset volume total RESET VOL Reset

Volume Total

Reset gas std volume total RESET GSV Reset GSV

To tal

Reset API ref vol total RESET TCORR Reset API

Volume Total

Reset ED ref vol total RESET STD V Reset ED

Volume Total

Initiates a zero calibration procedure

Resets the value of the mass totalizer to 0

Resets the value of the liquid volume totalizer to 0

Resets the value of the gas standard volume totalizer

(2)

to 0

Resets the value of the API temperature-corrected
volume totalizer to 0

Resets the value of the ED standard volume totalizer

(4)

to 0

(3)

(1)

58 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

Table 8-6 Event actions continued

ProLink II label Display label EDD label Description

Reset ED net mass total RESET NET M Reset ED Net

Mass Total

Reset ED net vol total RESET NET V Reset ED Net

Volume Total

Reset all totals RESET ALL Reset All

To tal s

Start/stop all totalization START STOP Start/Stop All

To tal s

Increment current ED
curve

INCR CURVE Increment ED

Curve

Start meter verification START VERFY Start Meter

Verification

(1) Displayed only if Volume Flow Type = Liquid.
(2) Displayed only if Volume Flow Type = Gas.
(3) Available only if the petroleum measurement application is installed.
(4) Available only if the enhanced density application is installed.
(5) Applies only to systems with Smart Meter Verification.

Resets the value of the ED net mass totalizer to 0

Resets the value of the ED net volume totalizer to 0

Resets the value of all totalizers to 0

If totalizers are running, stops all totalizers
If totalizers are not running, starts all totalizers

Changes the active enhanced density curve from
curve 0 to curve 1, from 1 to 2, etc.

Starts a Smart Meter Verification test

(4)

(4)

(4)

(5)

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Configuration and Use Manual 59

Optional Configuration

Example

Define Discrete Event 1 to be active when the mass flow rate in forward
or backward direction is less than 2 lb/min or greater than 20 lb/min.
Additionally, if this occurs, all totalizers should be stopped.

Using ProLink II:

1. Specify lb/min as the mass flow unit. See Section 6.3.1.

2. Set Flow Direction to Absolute Value. See Section 8.5.

3. Select Event 1.

4. Configure:

• Event Type = Out of Range

• Process Variable (PV) = Mass Flow Rate

• Low Setpoint (A) = 2

• High Setpoint (B) = 20

5. In the Discrete Input panel, open the dropdown list for Start/Stop
All Totalization and select Discrete Event 1.

Using PROFIBUS bus parameters:

1. Specify lb/min as the mass flow unit. See Section 6.3.1.

2. Set Flow Direction to Absolute Value. See Section 8.5.

3. In the Diagnostic block, set the following attributes:

• Discrete event index (Index 4) = 0

• Discrete event action type (Index 5) = 3

• Discrete event process variable (Index 8) = 0

• Discrete event setpoint A (Index 6) = 2

• Discrete event setpoint B (Index 7) = 20

• Discrete event assignment (Index 83) = 57

• Discrete event action code (Index 82) = 9

8.6.2 Checking and reporting event status

There are several ways that event status can be determined:

• ProLink II automatically displays event information on the Informational panel of the Status
window, and also in the Output Levels window.

• For PROFIBUS hosts using the EDD, event status is displayed in the Device menu (see
Figure C-6).

• Using PROFIBUS bus parameters, event status is reported in the Diagnostic block, Index 9
(see Table D-4).

Note: You cannot view event status using a PROFIBUS host with the GSD.

60 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

8.6.3 Changing event setpoints from the display

For Event 1 or Event 2 only, the value of Setpoint A can be changed from the display, under the
following circumstances:

• A mass total, volume total, petroleum measurement total, or enhanced density total must be
assigned to the event.

• The event type must be either High or Low.

• The assigned total must be configured as a display variable (see Section 8.9.3).

• The transmitter must be configured to allow resetting totalizers from the display (see
Section 8.9.5

Then, to change Setpoint A from the display:

).

1. Referring to the totalizer management flowchart in Figure 7-3,
display screen.

2.

Select.

3. Enter the new setpoint value. See Section 3.5.5 for instructions on entering floating-point
values with the display.

8.7 Configuring slug flow limits and duration

Slugs – gas in a liquid process or liquid in a gas process – occasionally appear in some applications.
The presence of slugs can significantly affect the process density reading. The slug flow parameters
can help the transmitter suppress extreme changes in process variables, and can also be used to
identify process conditions that require correction.

Slug flow parameters are as follows:

• Low slug flow limit – the point below which a condition of slug flow will exist. Typically, this
is the lowest density point in your process’s normal density range. Default value is
range is

0.0–10.0 g/cm3.

• High slug flow limit – the point above which a condition of slug flow will exist. Typically, this
is the highest density point in your process’s normal density range. Default value is
range is

0.0–10.0 g/cm3.

• Slug flow duration – the number of seconds the transmitter waits for a slug flow condition
(outside the slug flow limits) to return to normal (inside the slug flow limits). Default value is

0.0 sec; range is 0.0–60.0 sec.

Scroll to the appropriate

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

0.0 g/cm3;

5.0 g/cm3;

If the transmitter detects slug flow:

• A slug flow alarm is posted immediately.

• During the slug duration period, the transmitter holds the mass flow rate at the last measured
pre-slug value, independent of the mass flow rate measured by the sensor. The reported mass
flow rate is set to this value, and all internal calculations that include mass flow rate will use
this value.

• If slugs are still present after the slug duration period expires, the transmitter forces the mass
flow rate to
reported as

0, independent of the mass flow rate measured by the sensor. Mass flow rate is

0 and all internal calculations that include mass flow rate will use 0.

• When process density returns to a value within the slug flow limits, the slug flow alarm is
cleared and the mass flow rate reverts to the actual measured value.

Configuration and Use Manual 61

Optional Configuration

To configure slug flow parameters:

• Using ProLink II, see Figure C-2.

• Using a PROFIBUS host with the EDD, see Figure C-8.

• Using PROFIBUS bus parameters, use the Diagnostic block (see Table D-4), Indices 1, 2,
and 3.

Note: This functionality cannot be configured via the display menus.

Note: The slug flow limits must be entered in g/cm
density. Slug flow duration is entered in seconds. Raising the low slug flow limit or lowering the high
slug flow limit will increase the possibility of slug flow conditions. Conversely, lowering the low slug
flow limit or raising the high slug flow limit will decrease the possibility of slug flow conditions. If
slug flow duration is set to 0, the mass flow rate will be forced to 0 as soon as slug flow is detected.

8.8 Configuring status alarm severity

The 2400S DP transmitter can report faults in the following ways:

• Setting the “alarm active” status bit

• Writing an “alarm active” record to alarm history

• Implementing the digital communications fault action (see Section 8.10.7)

Status alarm severity determines which methods the transmitter will use when a specific alarm
condition occurs. See Table 8-8. (For a more extensive discussion of status alarm processing and
handling, see Section 7.7.)

3

, even if another unit has been configured for

Table 8-7 Alarm severity levels and fault reporting

Transmitter action if condition occurs

“Alarm active”

Severity level

Fault Yes Yes Yes

Informational Yes Yes No

Ignore Yes No No

(1) For some alarms, the digital communications fault action will not begin until the fault timeout has expired. To configure fault timeout,

see Section 8.8. Other fault reporting methods occur as soon as the fault condition is recognized. Table 8-8 includes information on
which alarms are affected by the fault timeout.

status bit set?

“Alarm active” record
written to history? Fault action activated?

(1)

Some alarms can be reclassified. For example:

• The default severity level for Alarm A020 (calibration factors unentered) is
reconfigure it to either

• The default severity level for Alarm A102 (drive over-range) is
reconfigure it to either

Informational or Ignore.

Informational, but you can

Ignore or Fault.

Fault, but you can

For a list of all status alarms and default severity levels, see Table 8-8. (For more information on
status alarms, including possible causes and troubleshooting suggestions, see Table 11-2.)

62 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

To configure alarm severity:

• Using ProLink II, see Figure C-3.

• Using a PROFIBUS host with the EDD, see Figure C-9.

• Using PROFIBUS bus parameters, use the Diagnostic block (see Table D-4), Indices 20 and

21.

Note: This functionality cannot be configured via the display menus.

Table 8-8 Status alarms and severity levels

Alarm code Message

A001 EEprom Checksum Error (Core Processor) Fault No No

(E)EPROM Checksum Error (CP)

A002 RAM Test Error (Core Processor) Fault No No

RAM Error (CP)

A003 Sensor Not Responding (No Tube Interrupt) Fault Yes Yes

Sensor Failure

A004 Temperature sensor out of range Fault No Yes

Temperature Sensor Failure

A005 Input Over-Range Fault Yes Yes

Input Overrange

A006 Transmitter Not Characterized Fault Yes No

Not Configured

A008 Density Outside Limits Fault Yes Yes

Density Overrange

A009 Transmitter Initializing/Warming Up Ignore Yes No

Transmitter Initializing/Warming Up

A010 Calibration Failure Fault No No

Calibration Failure

A011 Excess Calibration Correction, Zero too Low Fault Yes No

Zero Too Low

A012 Excess Calibration Correction, Zero too High Fault Yes No

Zero Too High

A013 Process too Noisy to Perform Auto Zero Fault Yes No

Zero Too Noisy

A014 Transmitter Failed Fault No No

Transmitter Failed

A016 Line RTD Temperature Out-Of-Range Fault Yes Yes

Line RTD Temperature Out-of-Range

A017 Meter RTD Temperature Out-Of-Range Fault Yes Yes

Meter RTD Temperature Out-of-Range

A020 Calibration Factors Unentered Fault Yes No

Calibration Factors Unentered (FlowCal)

(1)

Default
severity Configurable

Affected by
fault timeout

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Configuration and Use Manual 63

Optional Configuration

Table 8-8 Status alarms and severity levels continued

Alarm code Message

(1)

Default
severity Configurable

Affected by
fault timeout

A021 Unrecognized/Unentered Sensor Type Fault No No

Incorrect Sensor Type (K1)

A029 Internal Communication Failure Fault No No

PIC/Daughterboard Communication Failure

A030 Hardware/Software Incompatible Fault No No

Incorrect Board Type

A031 Undefined Fault No No

Low Power

A032

(2)

Meter Verification Fault Alarm Fault No No

Meter Verification/Outputs In Fault

A032

(3)

Outputs Fixed during Meter Verification Varies

(4)

No No

Meter Verification In Progress and Outputs
Fixed

A033 Sensor OK, Tubes Stopped by Process Fault Yes Yes

Sensor OK, Tubes Stopped by Process

(3)

A034

Meter Verification Failed Info Yes No

Meter Verification Failed

A035

(3)

Meter Verification Aborted Info Yes No

Meter Verification Aborted

A102 Drive Over-Range/Partially Full Tube Info Yes No

Drive Overrange/Partially Full Tube

A104 Calibration-In-Progress Info Yes

(5)

No

Calibration in Progress

A105 Slug Flow Info Yes No

Slug Flow

A107 Power Reset Occurred Info Yes No

Power Reset Occurred

A116 API Temperature Out-of-Limits Info Yes No

API: Temperature Outside Standard Range

A117 API Density Out-of-Limits Info Yes No

API: Density Outside Standard Range

A120 ED: Unable to fit curve data Info No No

ED: Unable to Fit Curve Data

64 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

Table 8-8 Status alarms and severity levels continued

Alarm code Message

A121 ED: Extrapolation alarm Info Yes No

ED: Extrapolation Alarm

(2)

A131

(3)

A131

A132 Simulation Mode Active Info Yes No

A133 PIC UI EEPROM Error Info Yes No

(1) Depending on the method you are using to view the alarm, different messages may be displayed. This table shows two possible

message versions. The ProLink II version is displayed in the second message of each pair.
(2) Applies only to systems with the original version of the meter verification application.
(3) Applies only to systems with Smart Meter Verification.
(4) If outputs are set to Last Measured Value, severity is Info. If outputs are set to Fault, severity is Fault.
(5) Can be set to either Informational or Ignore, but cannot be set to Fault.

Meter Verification Info Alarm Info Yes No

Meter Verification/Outputs at Last Value

Meter Verification in Progress Info Yes No

Meter Verification In Progress

Simulation Mode Active

PIC UI EEPROM Error

(1)

Default
severity Configurable

Affected by
fault timeout

8.9 Configuring the display

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

If your transmitter has a display, you can configure a variety of parameters that control the display
functionality.

8.9.1 Update period

The Update Period (or Display Rate) parameter controls how often the display is refreshed with
current data. The default is

200 milliseconds; the range is 100 milliseconds to 10,000 milliseconds

(10 seconds).

To configure Update Period:

• Using ProLink II, see Figure C-3.

• Using the display, see Figure C-15.

• Using a PROFIBUS host with the EDD, see Figure C-10.

• Using PROFIBUS bus parameters, use the Local Display block (see Table D-6), Index 31.

8.9.2 Language

The display can be configured to use any of the following languages for data and menus:

• English

•French

•German

• Spanish

Configuration and Use Manual 65

Optional Configuration

To set the display language:

• Using ProLink II, see Figure C-3.

• Using the display, see Figure C-15.

• Using a PROFIBUS host with the EDD, see Figure C-10.

• Using PROFIBUS bus parameters, use the Local Display block (see Table D-6), Index 33.

8.9.3 Display variables and display precision

The display can scroll through up to 15 process variables in any order. You can configure the process
variables to be displayed and the order in which they should appear. Additionally, you can configure
display precision for each display variable. Display precision controls the number of digits to the right
of the decimal place. Precision can be set to any value between

To configure display variables or display precision:

• Using ProLink II, see Figure C-3.

• Using a PROFIBUS host with the EDD, see Figure C-10.

• Using PROFIBUS bus parameters, use the Local Display block (see Table D-6):

- Use Indices 16–30 to specify the display variables.

0 and 5.

- Use Indices 14 and 15 to specify display precision.

Note: This functionality cannot be configured via the display menus.

Table 8-9 shows an example of a display variable configuration. Notice that you can repeat variables,
and you can also specify None for any display variable except Display Variable 1. For information on
how the display variables will appear on the display, see Appendix E.

Table 8-9 Example of a display variable configuration

Display variable Process variable

Display variable 1

Display variable 2 Mass totalizer

Display variable 3 Volume flow

Display variable 4 Volume totalizer

Display variable 5 Density

Display variable 6 Temperature

Display variable 7 External temperature

Display variable 8 External pressure

Display variable 9 Mass flow

Display variable 10 None

Display variable 11 None

Display variable 12 None

Display variable 13 None

Display variable 14 None

Display variable 15 None

(1)

Mass flow

(1) Display Variable 1 cannot be set to None.

66 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

8.9.4 LCD panel backlight

The backlight of the LCD panel on the display can be turned on or off. To turn the backlight on or off:

• Using ProLink II, see Figure C-3.

• Using the display, see Figure C-15.

• Using a PROFIBUS host with the EDD, see Figure C-10.

• Using PROFIBUS bus parameters, use the Local Display block (see Table D-6), Index 13.

In addition, ProLink II, the EDD, and the bus parameters allow you to control the intensity of the
backlight. You can specify any value between
backlight. To control the intensity of the backlight:

• Using ProLink II, see Figure C-3.

• Using a PROFIBUS host with the EDD, see Figure C-10.

0 and 63; the higher the value, the brighter the

• Using PROFIBUS bus parameters, use the Local Display block (see Table D-6), Index 32.

8.9.5 Display functions

Table 8-10 lists the display functions and describes their behavior when enabled (shown) or disabled
(hidden).

Table 8-10 Display functions

Parameter Enabled (shown) Disabled (hidden)

Totalizer start/stop Operators can start or stop totalizers using the

display.

Totalizer reset Operators can reset the mass and volume

totalizers using the display.

Auto scroll

Off-line menu Operators can access the off-line menu (zero,

Off-line password

Alarm menu Operators can access the alarm menu

Acknowledge all
alarms

(1)

(2)

The display automatically scrolls through each
process variable at a configurable rate.

simulation, and configuration).

Operators must use a password to access the
off-line menu.

(viewing and acknowledging alarms).

Operators are able to acknowledge all current
alarms at once.

Operators cannot start or stop totalizers using
the display.

Operators cannot reset the mass and volume
totalizers using the display.

Operators must
variables.

Operators cannot access the off-line menu.

Operators can access the off-line menu
without a password.

Operators cannot access the alarm menu.

Operators must acknowledge alarms
individually.

Scroll to view process

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

(1) If enabled, you may want to configure Scroll Rate.
(2) If enabled, the off-line password must also be configured.

To configure display functions:

• Using ProLink II, see Figure C-3.

• Using a PROFIBUS host with the EDD, see Figure C-10.

• Using PROFIBUS bus parameters, use the Local Display block (see Table D-6), Indices 4–12.

• Using the display, see Figure C-15.

Configuration and Use Manual 67

Optional Configuration

Note the following:

• If you use the display to disable access to the off-line menu, the off-line menu will disappear
as soon as you exit the menu system. If you want to re-enable access, you must use a different
method (e.g., ProLink II or a PROFIBUS host with the EDD).

• Scroll Rate is used to control the speed of scrolling when Auto Scroll is enabled. Scroll Rate
defines how long each display variable (see Section 8.9.3) will be shown on the display. The
time period is defined in seconds; e.g., if Scroll Rate is set to 10, each display variable will be
shown on the display for 10 seconds.

• The off-line password prevents unauthorized users from gaining access to the off-line menu.
The password can contain up to four numbers.

• If you are using the display to configure the display:

- You must enable Auto Scroll before you can configure Scroll Rate.

- You must enable the off-line password before you can configure the password.

8.10 Configuring digital communications

The digital communications parameters control how the transmitter will communicate using digital
communications. The following digital communications parameters can be configured:

• PROFIBUS-DP node address

• IrDA port usage

• Modbus address

• Modbus ASCII support

• Floating-point byte order

• Additional communications response delay

• Digital communications fault action

• Fault timeout

8.10.1 PROFIBUS-DP node address

The PROFIBUS-DP node address can be set with the address switches on the device (hardware
addressing mode) or with a PROFIBUS host.

Note: You cannot set the node address from ProLink II or the display.

The transmitter operates in either hardware addressing mode or software addressing mode:

• In hardware addressing mode, the address switches are set to a value between

0 and 126, and

the position of the address switches determines the actual node address. The software address
LED on the face of the transmitter is off (see Figure 3-1 or Figure 3-2).

• In software addressing mode, the address switches are set to

126 or greater, and the node

address is set via a Set Slave Address telegram from the host. The position of the address
switches does not necessarily match the actual node address. The software address LED is
either red or green:

- Red – the transmitter has not received a Set Slave Address telegram.

- Green – the transmitter has received a Set Slave Address telegram and recognized the

address.

The default node address for the Model 2400S DP transmitter is

126, which allows either hardware

addressing or software addressing.

68 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

To set the node address with address switches:

1. Remove the transmitter housing cover as described in Section 3.3.

2. Identify the three address switches on the user interface module of your transmitter (see
Figure 3-1 or Figure 3-2).

3. For each switch, insert a small blade into the slot to rotate the arrow to the desired position. For
example, to set the node address to

a. Rotate the arrow in the left switch to point to the digit

b. Rotate the arrow in the center switch to point to the digit

60:

0.

6.

c. Rotate the arrow in the right switch to point to the digit

0.

4. Power-cycle the transmitter. At this point, the new node address is recognized by the
transmitter, but not the host. You must update the host configuration for the new address.

To set the node address with software:

1. Ensure that the transmitter is in software addressing mode (software address LED is red or
green). If it is, skip this step and go to Step 2. If it is currently in hardware addressing mode
(software address LED is off):

a. Set the address switches to

126 or higher.

b. Power-cycle the transmitter. At this point, the transmitter enters software addressing mode,

and the software address LED is red.

2. Send a Set Slave Address telegram from the host. It is not necessary to power-cycle the
transmitter. At this point, the new node address is recognized by both the transmitter and the
host, and the software address LED is green.

To return the node address to

1. Because a Set Slave Address telegram cannot specify a node address of

126 (sometimes required for maintenance):

126, you must set this

address via the address switches. If the transmitter is currently in hardware addressing mode
(software address LED is off), skip this step and go to Step 2. If it is currently in software
addressing mode (software address LED is red or green), switch to hardware addressing mode
as follows:

a. Set the address switches to any value between

0 and 125 (e.g., 100).

b. Power-cycle the transmitter. The transmitter enters hardware addressing mode, and the

software address LED is off.

2. Set the address switches to

126.

3. Power-cycle the transmitter.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

8.10.2 IrDA port usage

The IrDA port on the display can be enabled or disabled. If enabled, it can be set for read-only or
read/write.

To enable or disable the IrDA port:

• Using ProLink II, see Figure C-2.

• Using the display menus, see Figure C-15.

• Using a PROFIBUS host with the EDD, see Figure C-10.

• Using PROFIBUS bus parameters, use the Local Display block (see Table D-6), Index 34.

Configuration and Use Manual 69

Optional Configuration

To configure the IrDA port for read-only or read/write access:

• Using ProLink II, see Figure C-2.

• Using the display menus, see Figure C-15.

• Using a PROFIBUS host with the EDD, see Figure C-10.

• Using PROFIBUS bus parameters, use the Local Display block (see Table D-6), Index 35.

8.10.3 Modbus address

Note: The Modbus address is applicable only when you are connecting to the service port from a tool
that uses Modbus protocol. After initial startup, service port connections are typically used only for
troubleshooting or for specific procedures such as temperature calibration. ProLink II is typically
used for service port connections, and by default ProLink II will use the standard service port address
rather than the configured Modbus address. See Section 4.4 for more information.

The set of valid Modbus addresses depends on whether or not support for Modbus ASCII is enabled
or disabled (see Section 8.10.4). Valid Modbus addresses are as follows:

• Modbus ASCII enabled:

• Modbus ASCII disabled: 0–127

To configure the Modbus address:

• Using ProLink II, see Figure C-2.

1–15, 32–47, 64–79, 96–110

• Using the display, see Figure C-15.

Note: This functionality cannot be configured via PROFIBUS protocol.

8.10.4 Modbus ASCII support

When support for Modbus ASCII is enabled, the service port can accept connection requests that use
either Modbus ASCII or Modbus RTU. When support for Modbus ASCII is disabled, the service port
cannot accept connection requests that use Modbus ASCII. Only Modbus RTU connections are
accepted.

The primary reason to disable Modbus ASCII support is to allow a wider range of Modbus addresses
for the service port.

To enable or disable Modbus ASCII support:

• Using ProLink II, see Figure C-2.

• Using the display, see Figure C-15.

Note: This functionality cannot be configured via PROFIBUS protocol.

8.10.5 Floating-point byte order

Note: This parameter affects only Modbus communications. PROFIBUS communications are not
changed.

Four bytes are used to transmit floating-point values. For contents of bytes, see Table 8-11.

70 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

Table 8-11 Byte contents in Modbus commands and responses

Byte Bits Definitions

1 S E E E E E E E S = Sign

2 E M M M M M M M E = Exponent

3 M M M M M M M M M = Mantissa

4 M M M M M M M M M = Mantissa

The default byte order for the Model 2400S transmitter is 3–4 1–2. You may need to reset byte order
to match the byte order used by a remote host or PLC.

To configure byte order using ProLink II, see Figure C-2.

Note: This functionality cannot be configured via the display menus or PROFIBUS protocol.

8.10.6 Additional communications response delay

Note: This parameter affects only Modbus communications. PROFIBUS communications are not
changed.

E = Exponent

M = Mantissa

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

Some hosts or PLCs operate at slower speeds than the transmitter. In order to synchronize
communication with these devices, you can configure an additional time delay to be added to each
response the transmitter sends to the remote host.

The basic unit of delay is 2/3 of one character time, as calculated for the current serial port baud rate
setting and character transmission parameters. This basic delay unit is multiplied by the configured
value to arrive at the total additional time delay. You can specify a value in the range 1 to 255.

To configure additional communications response delay using ProLink II, see Figure C-2.

Note: This functionality cannot be configured via the display menus or PROFIBUS protocol.

8.10.7 Digital communications fault action

Note: This parameter affects both PROFIBUS and Modbus communications.

Digital communications fault action controls how process variables will be reported via digital
communications during fault conditions. Table 8-12 lists the options for digital communications fault
action.

Note: Digital communications fault action does not affect the alarm status bits. For example, if digital
communications fault action is set to None, the alarm status bits will still be set if an alarm occurs.
See Section 7.7 for more information.

Configuration and Use Manual 71

Optional Configuration

Table 8-12 Digital communications fault action options

Option

DefinitionProLink II label EDD label

Upscale Upscale • Process variables indicate that the value is greater than the

upper sensor limit.

• Totalizers stop incrementing.

Downscale Downscale • Process variables indicate that the value is less than the

lower sensor limit.

• Totalizers stop incrementing.

Zero IntZero-All 0 • Flow rate variables go to the value that represents zero

Not-A-Number (NAN) Not-a-Number • Process variables report IEEE NAN.

Flow to Zero IntZero-Flow 0 • Flow rate variables go to the value that represents zero

None (default) None • Process variables are reported as measured.

flow. Density is reported as zero.

• Temperature is reported as 0 °C, or the equivalent if other
units are used (e.g., 32 °F).

• Totalizers stop incrementing.

• Drive gain is reported as measured.

• Modbus scaled integers are reported as Max Int.

• Totalizers stop incrementing.

flow;

• Other process variables are reported as measured.

• Totalizers stop incrementing.

• Totalizers increment if they are running.

To configure digital communications fault action:

• Using ProLink II, see Figure C-2.

• Using a PROFIBUS host with the EDD, see Figure C-9.

• Using PROFIBUS bus parameters, use the Diagnostic block (see Table D-4), Index 18.

Note: This functionality cannot be configured via the display menus.

Note: Digital communications fault action is affected by the configured fault timeout. See
Section 8.10.8.

8.10.8 Fault timeout

By default, the transmitter activates the digital communications fault action as soon as the fault is
detected. The fault timeout (last measured value timeout) allows you to delay the digital
communications fault action for a specified interval, for certain faults only. During the fault timeout
period, digital communications reports the last measured value.

Note: The fault timeout applies only to the digital communications fault action. The “alarm active”
status bit is set as soon as the fault is detected (all alarm severity levels), and the “alarm active”
record is written to history immediately (Fault and Informational alarms only). For more information
on alarm handling, see Section 7.7. For more information on alarm severity, see Section 8.8.

The fault timeout applies only to specific faults. Other faults are reported immediately, regardless of
the fault timeout setting. For information on which faults are affected by the fault timeout, see
Table 8-8.

72 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

To configure fault timeout:

• Using ProLink II, see Figure C-2.

• Using a PROFIBUS host with the EDD, see Figure C-9.

• Using PROFIBUS bus parameters, use the Diagnostic block (see Table D-4), Index 19.

Note: This functionality cannot be configured via the display menus.

8.11 Configuring device settings

The device settings are used to describe the flowmeter components. Table 8-13 lists and defines the
device settings.

Table 8-13 Device settings

Parameter Description

Descriptor Any user-supplied description. Not used in transmitter processing, and not required.

Maximum length: 16 characters.

Message Any user-supplied message. Not used in transmitter processing, and not required.

Maximum length: 32 characters.

Date Any user-selected date. Not used in transmitter processing, and not required.

To configure device settings using ProLink II, see Figure C-2.

Note: This functionality cannot be configured via the display menus or PROFIBUS protocol.

If you are entering a date, use the left and right arrows at the top of the calendar shown in ProLink II
to select the year and month, then click on a date.

8.12 Configuring PROFIBUS I&M function values

Most I&M function values are configured at the factory and cannot be changed by the user. Two I&M
function values can be configured by the user:

• Device identification tag

• Device location identification tag

To configure these values:

• Using ProLink II, see Figure C-2. ProLink II v2.6 or later is required.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

• Using a PROFIBUS host with the EDD, see Figure C-12. You must connect as a Specialist to
use the I&M Functions menu.

• Using PROFIBUS bus parameters, see Table D-9.

Note: These values cannot be configured via the display menus.

Configuration and Use Manual 73

Optional Configuration

8.13 Configuring sensor parameters

The sensor parameters are used to describe the sensor component of your flowmeter. One sensor
parameter (curved or straight tube) must be set during characterization (see Section 6.2). The
remaining sensor parameters are not used in transmitter processing, and are not required:

• Serial number

• Sensor material

• Liner material

•Flange

To configure sensor parameters:

• Using ProLink II, see Figure C-2.

• Using a PROFIBUS host with the EDD, see Figure C-10.

• Using PROFIBUS bus parameters, use the Device Information block (see Table D-5),
Indices 7–12.

Note: This functionality cannot be configured via the display menus.

8.14 Configuring the petroleum measurement application

The API parameters determine the values that will be used in API-related calculations. The API
parameters are available only if the petroleum measurement application is enabled on your
transmitter.

Note: The petroleum measurement application requires liquid volume measurement units. If you plan
to use API process variables, ensure that liquid volume flow measurement is specified. See
Section 8.2.

8.14.1 About the petroleum measurement application

Some applications that measure liquid volume flow or liquid density are particularly sensitive to
temperature factors, and must comply with American Petroleum Institute (API) standards for
measurement. The petroleum measurement application enables Correction of Temperature on volume
of Liquids, or CTL.

Terms and definitions

The following terms and definitions are relevant to the petroleum measurement application:

• API – American Petroleum Institute

• CTL – Correction of Temperature on volume of Liquids. The CTL value is used to calculate
the VCF value

• TEC – Thermal Expansion Coefficient

• VCF – Volume Correction Factor. The correction factor to be applied to volume process
variables. VCF can be calculated after CTL is derived

CTL derivation methods

There are two derivation methods for CTL:

• Method 1 is based on observed density and observed temperature.

• Method 2 is based on a user-supplied reference density (or thermal expansion coefficient, in
some cases) and observed temperature.

74 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

API reference tables

Reference tables are organized by reference temperature, CTL derivation method, liquid type, and
density unit. The table selected here controls all the remaining options.

• Reference temperature:

- If you specify a 5x, 6x, 23x, or 24x table, the default reference temperature is 60

- If you specify a 53x or 54x table, the default reference temperature is 15 °C. However, you

• CTL derivation method:

- If you specify an odd-numbered table (5, 23, or 53), CTL will be derived using method 1

- If you specify an even-numbered table (6, 24, or 54), CTL will be derived using method 2

• The letters A, B, C, or D that are used to terminate table names define the type of liquid that the
table is designed for:

- A tables are used with generalized crude and JP4 applications.

- B tables are used with generalized products.

°F, an d

cannot be changed.

can change the reference temperature, as recommended in some locations (for example, to

14.0 or 14.5 °C).

described above.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

described above.

- C tables are used with liquids with a constant base density or known thermal expansion

coefficient.

- D tables are used with lubricating oils.

• Different tables use different density units:

-Degrees API

- Relative density (SG)

- Base density (kg/m

3

)

Table 8-14 summarizes these options.

Configuration and Use Manual 75

Optional Configuration

Table 8-14 API reference temperature tables

CTL

Density unit and range

derivation

Table

5A Method 1 60 °F, non-configurable 0 to +100

5B Method 1 60 °F, non-configurable 0 to +85

5D Method 1 60 °F, non-configurable –10 to +40

23A Method 1 60 °F, non-configurable 0.6110 to 1.0760

23B Method 1 60 °F, non-configurable 0.6535 to 1.0760

23D Method 1 60 °F, non-configurable 0.8520 to 1.1640

53A Method 1 15 °C, configurable 610 to 1075 kg/m

53B Method 1 15 °C, configurable 653 to 1075 kg/m

53D Method 1 15 °C, configurable 825 to 1164 kg/m

method Base temperature

Degrees API Base density Relative density

3

3

3

Reference temperature Supports

6C Method 2 60 °F, non-configurable 60 °F Degrees API

24C Method 2 60 °F, non-configurable 60 °F Relative density

54C Method 2 15 °C, configurable 15 °C Base density in kg/m

8.14.2 Configuration procedure

The API configuration parameters are listed and defined in Table 8-15.

3

Table 8-15 API parameters

Variable Description

Table type Specifies the table that will be used for reference temperature and reference density unit. Select

User defined TEC

Temperature units

Density units Read-only. Displays the unit used for reference density in the reference table.

Reference
temperature

(1) Configurable if Table Type is set to 6C, 24C, or 54C.
(2) In most cases, the temperature unit used by the API reference table should also be the temperature unit configured for the transmitter

to use in general processing. To configure the temperature unit, see Section 6.3.4.

the table that matches your requirements. See API reference tables.

(1)

Thermal expansion coefficient. Enter the value to be used in CTL calculation.

(2)

Read-only. Displays the unit used for reference temperature in the reference table.

Read-only unless Table Type is set to 53x or 54x. If configurable:

• Specify the reference temperature to be used in CTL calculation.

• Enter reference temperature in °C.

To configure the petroleum measurement application:

• Using ProLink II, see Figure C-3.

• Using a PROFIBUS host with the EDD, see Figure C-11.

• Using PROFIBUS bus parameters, use the API block (see Table D-7), Indices 13–15.

Note: This functionality cannot be configured via the display menus.

76 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

For the temperature value to be used in CTL calculation, you can use the temperature data from the
sensor, or you can configure external temperature compensation to use either a static temperature
value or temperature data from an external temperature device.

• To use temperature data from the sensor, no action is required.

• To configure external temperature compensation, see Section 9.3.

8.15 Configuring the enhanced density application

Micro Motion sensors provide direct measurements of density, but not of concentration. The enhanced
density application calculates enhanced density process variables, such as concentration or density at
reference temperature, from density process data, appropriately corrected for temperature.

Note: For a detailed description of the enhanced density application, see the manual entitled
Micro Motion Enhanced Density Application: Theory, Configuration, and Use.

Note: The enhanced density application requires liquid volume measurement units. If you plan to use
enhanced density process variables, ensure that liquid volume flow measurement is specified. See
Section 8.2.

Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host Required Configuration Optional ConfigurationUsing the TransmitterUsing a PROFIBUS Host

8.15.1 About the enhanced density application

The enhanced density calculation requires an enhanced density curve, which specifies the relationship
between temperature, concentration, and density for the process fluid being measured. Micro Motion
supplies a set of six standard enhanced density curves (see Table 8-16). If none of these curves is
appropriate for your process fluid, you can configure a custom curve or purchase a custom curve from
Micro Motion.

The derived variable, specified during configuration, controls the type of concentration measurement
that will be produced. Each derived variable allows the calculation of a subset of enhanced density
process variables (see Table 8-17). The available enhanced density process variables can be used in
process control, just as mass flow rate, volume flow rate, and other process variables are used. For
example, an event can be defined on an enhanced density process variable.

• For all standard curves, the derived variable is Mass Conc (Dens).

• For custom curves, the derived variable may be any of the variables listed in Table 8-17.

The transmitter can hold up to six curves at any given time, but only one curve can be active (used for
measurement) at a time. All curves that are in transmitter memory must use the same derived variable.

Table 8-16 Standard curves and associated measurement units

Name Description Density unit Temperature unit

Deg Balling Curve represents percent extract, by mass, in

solution, based on °Balling. For example, if a wort
is 10 °Balling and the extract in solution is 100%
sucrose, the extract is 10% of the total mass.

Deg Brix Curve represents a hydrometer scale for sucrose

solutions that indicates the percent by mass of
sucrose in solution at a given temperature. For
example, 40 kg of sucrose mixed with 60 kg of
water results in a 40 °Brix solution.

Deg Plato Curve represents percent extract, by mass, in

solution, based on °Plato. For example, if a wort is
10 °Plato and the extract in solution is 100%
sucrose, the extract is 10% of the total mass.

g/cm

g/cm

g/cm

3

3

3

°F

°C

°F

Configuration and Use Manual 77

Optional Configuration

Table 8-16 Standard curves and associated measurement units continued

Name Description Density unit Temperature unit

HFCS 42 Curve represents a hydrometer scale for HFCS 42

(high fructose corn syrup) solutions that indicates
the percent by mass of HFCS in solution.

HFCS 55 Curve represents a hydrometer scale for HFCS 55

(high fructose corn syrup) solutions that indicates
the percent by mass of HFCS in solution.

HFCS 90 Curve represents a hydrometer scale for HFCS 90

(high fructose corn syrup) solutions that indicates
the percent by mass of HFCS in solution.

g/cm

g/cm

g/cm

3

3

3

°C

°C

°C

Table 8-17 Derived variables and available process variables

Available process variables

Derived variable – ProLink II label
and definition

Density @ Ref

Density at reference temperature

Mass/unit volume, corrected to a given
reference temperature

SG

Specific gravity

The ratio of the density of a process fluid at
a given temperature to the density of water
at a given temperature. The two given
temperature conditions do not need to be
the same.

Mass Conc (Dens)

Mass concentration derived from reference
density

The percent mass of solute or of material
in suspension in the total solution, derived
from reference density

Mass Conc (SG)

Mass concentration derived from specific
gravity

The percent mass of solute or of material
in suspension in the total solution, derived
from specific gravity

Volume Conc (Dens)

Volume concentration derived from
reference density

The percent volume of solute or of material
in suspension in the total solution, derived
from reference density

Density at
reference
temperature

✓✓

✓✓✓

✓✓ ✓ ✓

✓✓✓✓ ✓

✓✓ ✓ ✓

Standard
volume
flow rate

Specific
gravity

Concentration Net

mass
flow rate

Net
volume
flow rate

78 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Optional Configuration

Table 8-17 Derived variables and available process variables continued

Available process variables

Derived variable – ProLink II label
and definition

Volume Conc (SG)

Volume concentration derived from specific
gravity

The percent volume of solute or of material
in suspension in the total solution, derived
from specific gravity

Conc (Dens)

Concentration derived from reference
density

The mass, volume, weight, or number of
moles of solute or of material in
suspension in proportion to the total
solution, derived from reference density

Conc (SG)

Concentration derived from specific gravity

The mass, volume, weight, or number of
moles of solute or of material in
suspension in proportion to the total
solution, derived from specific gravity

Density at
reference
temperature

✓✓✓✓ ✓

✓✓ ✓

✓✓✓✓

Standard
volume
flow rate

Specific
gravity

Concentration Net

mass
flow rate

Net
volume
flow rate

8.15.2 Configuration procedure

Complete configuration instructions for the enhanced density application are provided in the manual
entitled Micro Motion Enhanced Density Application: Theory, Configuration, and Use.

Note: The enhanced density manual uses ProLink II as the standard configuration tool for the
enhanced density application. Because the menu structure defined in the EDD is very similar to the
ProLink II menus, you can follow the instructions for ProLink II and adapt them to your host.

The typical configuration procedure simply sets up the enhanced density application to use a standard
curve. The following steps are required:

1. Set the transmitter’s density measurement unit to match the unit used by the curve (as listed in
Table 8-16).

2. Set the transmitter’s temperature measurement unit to match the unit used by the curve (as
listed in Table 8-16).

3. Set the derived variable to Mass Conc (Dens).

4. Specify the active curve.

To perform these steps:

• With ProLink II, see Figures C-2 and C-3.

• With a PROFIBUS host and the EDD, see Figures C-8 and C-11.

• With PROFIBUS bus parameters, use the Measurement block and the Enhanced Density block
(see Tables D-2 and D-8).

79 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

80 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Chapter 9

Pressure Compensation and External Temperature Compensation

9.1 Overview

This chapter describes the following procedures:

• Configuring pressure compensation – see Section 9.2

• Configuring external temperature compensation – see Section 9.3

• Obtaining external pressure or temperature data – see Section 9.4

Note: All procedures provided in this chapter assume that you have established communication with
the Model 2400S DP transmitter and that you are complying with all applicable safety requirements.

Note: If you are using Pocket ProLink, the interface is similar to the ProLink II interface described in
this chapter.

9.2 Pressure compensation

The Model 2400S DP transmitter can compensate for the effect of pressure on the sensor flow tubes.
Pressure effect is defined as the change in sensor flow and density sensitivity due to process pressure
change away from calibration pressure.

Note: Pressure compensation is an optional procedure. Perform this procedure only if required by
your application.

Measurement Performance DefaultsTroubleshootingCompensation

9.2.1 Options

There are two ways to implement pressure compensation:

• You can use an output module to obtain pressure data from the system. See Section 9.4.

• If the operating pressure is a known static value, you can configure that value in the
transmitter.

Note: Ensure that your pressure value is accurate, or that your pressure measurement device is
accurate and reliable.

9.2.2 Pressure correction factors

When configuring pressure compensation, you must provide the flow calibration pressure – the
pressure at which the flowmeter was calibrated (which therefore defines the pressure at which there
will be no effect on the calibration factor). Refer to the calibration document shipped with your
sensor. If the data is unavailable, enter

Configuration and Use Manual 81

20 PSI.

Pressure Compensation and External Temperature Compensation

Enter Flow factor

Configure

Enter Density factor

Enter Cal pressure

Set up output

module

(2)

Enter External

Pressure

Enable External Pressure

Compensation

Enable

Apply

Enter Pressure units

Set measurement unit

(1)

Yes

Done

Apply

View >
Preferences

ProLink >
Configuration >
Pressure

ProLink >
Configuration >
Pressure

Apply

Apply

Use static

pressure value?

No

(1) Pressure measurement unit must be configured to match

pressure unit used by external device or static pressure value.
See Section 6.3.

(2) See Section 9.4.

Two additional pressure correction factors may be configured: one for flow and one for density. These
are defined as follows:

• Flow factor – the percent change in the flow rate per psi

• Density factor – the change in fluid density, in g/cm

Not all sensors or applications require pressure correction factors. For the pressure correction values
to be used, obtain the pressure effect values from the product data sheet for your sensor, then reverse
the signs (e.g., if the flow factor is 0.000004 % per PSI, enter a pressure correction flow factor of
–0.000004 % per PSI).

9.2.3 Configuration

To enable and configure pressure compensation:

• With ProLink II, see Figure 9-1.

• With a PROFIBUS host with the EDD, see Figure 9-2.

• With PROFIBUS bus parameters, see Figure 9-3.

Figure 9-1 Pressure compensation – ProLink II

3

/psi

82 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Pressure Compensation and External Temperature Compensation

Enter Pressure correction factor

for flow

Enter Pressure correction factor

for density

Enter Flow calibration pressure

Set up output module

(2)

Enter External Pressure Input

Enable Pressure Compensation

Select Pressure unit

(1)

Yes

MMI Coriolis Flow >
Pressure >
Pressure Configuration

MMI Coriolis Flow >
Pressure >
Pressure Compensation

Transfer

Transfer

Done

Use static

pressure value?

Transfer

No

(1) Pressure measurement unit must be configured to match pressure unit used by external device

or static pressure value. See Section 6.3.

(2) See Section 9.4.

Enable

Set pressure unit

Block: Calibration (Slot 2)

(1)

Index 36

Configure pressure

correction factor for flow

Block: Calibration (Slot 2)
Index 38

(2)

Block: Calibration (Slot 2)
Index 39

Configure pressure

correction factor for density

Block: Calibration (Slot 2)
Index 40

Configure flow calibration

pressure

Block: Calibration (Slot 2)
Index 41

Yes

Use static

pressure value?

No

Set up output

module

(3)

Block: Calibration (Slot 2)
Index 37

Set static value

(1) See Table D-3 for more information

about the bus parameters.

(2) Pressure measurement unit must be

configured to match pressure unit used
by external device or static pressure
value. See Section 6.3.

(3) See Section 9.4.

Figure 9-2 Pressure compensation – PROFIBUS host with the EDD

Measurement Performance DefaultsTroubleshootingCompensation

Figure 9-3 Pressure compensation – PROFIBUS bus parameters

Configuration and Use Manual 83

Pressure Compensation and External Temperature Compensation

Configure

Enable Use External

Temperature

Enable

Apply

Enter Temperature units

(1)

View Menu >
Preferences

ProLink >
Configuration >
Temperature

Set up output

module

(2)

Enter External

Temperature

YesNo

Use static

temp value?

Apply

Apply

Done

(1) Temperature measurement unit must be

configured to match temperature unit used
by external device or static temperature
value. See Section 6.3.

(2) See Section 9.4.

9.3 External temperature compensation

External temperature compensation can be used with the petroleum measurement application or the
enhanced density application:

• If external temperature compensation is enabled, an external temperature value (or a static
temperature value), rather than the temperature value from the sensor, is used in petroleum
measurement or enhanced density calculations only. The temperature value from the sensor is
used for all other calculations.

• If external temperature compensation is disabled, the temperature value from the sensor is
used in all calculations.

There are two ways to implement external temperature compensation:

• You can use an output module to obtain temperature data from the system. See Section 9.4.

• If the operating temperature is a known static value, you can configure that value in the
transmitter.

Note: Ensure that your temperature value is accurate, or that your temperature measurement device is
accurate and reliable.

To enable and configure external temperature compensation:

• With ProLink II, see Figure 9-4.

• With a PROFIBUS host with the EDD, see Figure 9-5.

• With PROFIBUS bus parameters, see Figure 9-3.

Figure 9-4 External temperature compensation – ProLink II

84 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Pressure Compensation and External Temperature Compensation

Set up output module

(2)

Enter External

Temperature Input

Enable External Temp

for API or ED

Yes

MMI Coriolis Flow >
Temperature >

MMI Coriolis Flow >
Temperature >
External Temperature

Transfer

Done

Use static

temp value?

Transfer

No

Check Temperature unit

(1)

Transfer

(1) Temperature measurement unit must be

configured to match temperature unit used
by external device or static temperature
value. See Section 6.3.

(2) See Section 9.4.

Enable

Set temperature unit

Block: Calibration (Slot 2)

(1)

Index 34

Block: Measurement (Slot 1)

(1)

Index 7

(2)

Yes

Use static

temp value?

No

Set up output

module

(3)

Block: Calibration (Slot 2)
Index 35

Set static value

(1) See Tables D-3 and D-2 for more information about the bus parameters.
(2) Temperature measurement unit must be configured to match temperature unit used by external device or static temperature

value. See Section 6.3.

(3) See Section 9.4.

Figure 9-5 External temperature compensation – PROFIBUS host with the EDD

Measurement Performance DefaultsTroubleshootingCompensation

Figure 9-6 External temperature compensation – PROFIBUS bus parameters

Configuration and Use Manual 85

Pressure Compensation and External Temperature Compensation

9.4 Obtaining external pressure and temperature data

The output modules used to obtain external pressure and/or temperature data are listed in Table 9-1.
Use standard methods to implement the required connection.

Table 9-1 Output modules used for pressure or temperature compensation

Module number Module name Size

34 External pressure 4 bytes

35 External temperature 4 bytes

86 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Chapter 10

Measurement Performance

10.1 Overview

This chapter describes the following procedures:

• Meter verification – see Section 10.3

• Meter validation and adjusting meter factors – see Section 10.4

• Zero calibration – see Section 10.5

• Density calibration – see Section 10.6

• Temperature calibration – see Section 10.7

Note: All procedures provided in this chapter assume that you have established communication with
the Model 2400S DP transmitter and that you are complying with all applicable safety requirements.

Note: If you are using Pocket ProLink, the interface is similar to the ProLink II interface described in
this chapter.

10.2 Meter validation, meter verification, and calibration

The Model 2400S transmitter supports the following procedures for the evaluation and adjustment of
measurement performance:

• Meter verification – establishing confidence in the sensor’s performance by analyzing
secondary variables associated with flow and density

• Meter validation – confirming performance by comparing the sensor’s measurements to a
primary standard

• Calibration – establishing the relationship between a process variable (flow, density, or
temperature) and the signal produced by the sensor

Meter validation and calibration are available on all Model 2400S DP transmitters. Meter verification
is available only if the meter verification option was ordered with the transmitter.

These three procedures are discussed and compared in Sections 10.2.1 through 10.2.4. Before
performing any of these procedures, review these sections to ensure that you will be performing the
appropriate procedure for your purposes.

Measurement Performance DefaultsTroubleshootingCompensation

10.2.1 Meter verification

Meter verification evaluates the structural integrity of the sensor tubes by comparing current tube
stiffness to the stiffness measured at the factory. Stiffness is defined as the load per unit deflection, or
force divided by displacement. Because a change in structural integrity changes the sensor’s response
to mass and density, this value can be used as an indicator of measurement performance. Changes in
tube stiffness are typically caused by erosion, corrosion, or tube damage.

Note: Micro Motion recommends performing meter verification at regular intervals.

Configuration and Use Manual 87

Measurement Performance

There are two versions of the meter verification application: the original version and Micro Motion
Smart Meter Verification. Table 10-1 lists requirements for each version. Table 10-2 provides a
comparison of the two versions.

Note: If you are running an older version of ProLink II or the EDD, you will not be able to access the
additional features in Smart Meter Verification. If you are running an updated version of ProLink II
or the EDD with the original version of meter verification, the meter verification procedures will be
slightly different from the procedures shown here.

Table 10-1 Version requirements for meter verification application

Meter verification application

Requirement type

Transmitter v1.0 v1.4

ProLink II requirements v2.5 v2.9

EDD requirements 2400SDP_pdmrev1_00 folder 2400SDP_pdmrev1_40 folder

Original version Smart Meter Verification

Table 10-2 Comparison of meter verification features and functions: original version vs. Smart Meter

Verification

Meter verification application

Feature or function

Process interruption No need to halt flow No need to halt flow

Measurement interruption Three minutes. Outputs go to:

Result storage Test results stored only for tests run with

Result data on display Pass/Fail/Abort for current test For all results stored on transmitter:

Original version Smart Meter Verification

• Last Measured Value

• Configured Fault Value

ProLink II, and stored on the PC

User option:

• Continue Measurement. Measurement is
not interrupted. Test requires
approximately 90 seconds.

• Last Measured Value. Outputs fixed and
measurement interrupted for
approximately 140 seconds.

• Configured Fault Value Outputs fixed and
measurement interrupted for
approximately 140 seconds.

Twenty most recent results stored on the
transmitter, independent of tool used to
perform the procedure. For tests run with
ProLink II, additional result data stored on
PC.

• Pass/Fail/Abort

• Abort code (if relevant)

• Stiffness of the right and left pickoffs

88 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Measurement Performance

Table 10-2 Comparison of meter verification features and functions: original version vs. Smart Meter

Verification continued

Meter verification application

Feature or function

Result data with EDD Pass/Caution/Abort for current test For all results stored on transmitter:

Result data with ProLink II For all results stored on PC:

Startup methods Manual Manual

Original version Smart Meter Verification

• Pass/Caution/Abort

• Abort code (if relevant)

• Stiffness of the right and left pickoffs

• Comparison table for stored results

• Comparison plot for stored results

For all results stored on transmitter:

• Pass/Fail/Abort

• Abort code (if relevant)

• Stiffness of the right and left pickoffs

• Test execution metadata

• Comparison graphs

• Test reports

• Data export and manipulation
capabilities

• Pass/Fail/Abort

• Abort code (if relevant)

• Stiffness of the right and left pickoffs

• Test execution metadata

• Comparison graphs

•Test reports

• Data export and manipulation
capabilities

Scheduler
Event

10.2.2 Meter validation and meter factors

Meter validation compares a measurement value reported by the transmitter with an external
measurement standard. Meter validation requires one data point.

Note: For meter validation to be useful, the external measurement standard must be more accurate
than the sensor. See the sensor’s product data sheet for its accuracy specification.

Measurement Performance DefaultsTroubleshootingCompensation

If the transmitter’s mass flow, volume flow, or density measurement is significantly different from the
external measurement standard, you may want to adjust the corresponding meter factor. A meter
factor is the value by which the transmitter multiplies the process variable value. The default meter
factors are

1.0, resulting in no difference between the data retrieved from the sensor and the data

reported externally.

Meter factors are typically used for proving the flowmeter against a Weights & Measures standard.
You may need to calculate and adjust meter factors periodically to comply with regulations.

10.2.3 Calibration

The flowmeter measures process variables based on fixed points of reference. Calibration adjusts
those points of reference. Three types of calibration can be performed:

• Zero, or no flow

• Density calibration

• Temperature calibration

Density and temperature calibration require two data points (low and high) and an external
measurement for each. Zero calibration requires one data point. Calibration produces a change in the
offset and/or the slope of the line that represents the relationship between the actual process value and
the reported value.

Note: For density or temperature calibration to be useful, the external measurements must be
accurate.

Configuration and Use Manual 89

Measurement Performance

Micro Motion flowmeters with the Model 2400S transmitter are calibrated at the factory, and
normally do not need to be calibrated in the field. Calibrate the flowmeter only if you must do so to
meet regulatory requirements. Contact Micro Motion before calibrating your flowmeter.

Note: Micro Motion recommends using meter validation and meter factors, rather than calibration, to
prove the meter against a regulatory standard or to correct measurement error.

10.2.4 Comparison and recommendations

When choosing among meter verification, meter validation, and calibration, consider the following
factors:

• Process and measurement interruption

- Smart Meter Verification provides an option that allows process measurement to continue
during the test.

- The original version of meter verification requires approximately three minutes to
perform. During these three minutes, flow can continue (provided sufficient stability is
maintained); however, measurement is halted.

- Meter validation for density does not interrupt the process. However, meter validation for
mass flow or volume flow requires process down-time for the length of the test.

- Calibration requires process down-time. In addition, density and temperature calibration
require replacing the process fluid with low-density and high density fluids, or with
low-temperature and high-temperature fluids. Zero calibration requires stopping flow
through the sensor.

• External measurement requirements

- Neither version of meter verification requires external measurements.

- Zero calibration does not require external measurements.

- Density calibration, temperature calibration, and meter validation require external
measurements. For good results, the external measurement must be highly accurate.

• Measurement adjustment

- Meter verification is an indicator of sensor condition, but does not change flowmeter
internal measurement in any way.

- Meter validation does not change flowmeter internal measurement in any way. If you
decide to adjust a meter factor as a result of a meter validation procedure, only the reported
measurement is changed – the base measurement is not changed. You can always reverse
the change by returning the meter factor to its previous value.

- Calibration changes the transmitter’s interpretation of process data, and accordingly
changes the base measurement. If you perform a zero calibration, you can return to the
factory zero (or, if using ProLink II, the previous zero). However, if you perform a density
calibration or a temperature calibration, you cannot return to the previous calibration
factors unless you have manually recorded them.

Micro Motion recommends that you purchase the meter verification option and perform meter
verification frequently.

90 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP

Measurement Performance

10.3 Performing meter verification

10.3.1 Preparing for the meter verification test

Process fluid and process conditions

The meter verification test can be performed on any process fluid. It is not necessary to match factory
conditions.

During the test, process conditions must be stable. To maximize stability:

• Maintain a constant temperature and pressure.

• Avoid changes to fluid composition (e.g., two-phase flow, settling, etc.).

• Maintain a constant flow. For higher test certainty, reduce or stop flow.

If stability varies outside test limits, the test will be aborted. Verify the stability of the process and
repeat the test.

Transmitter configuration

Meter verification is not affected by any parameters configured for flow, density, or temperature. It is
not necessary to change the transmitter configuration.

Measurement Performance DefaultsTroubleshootingCompensation

Control loops and process measurement

If the transmitter outputs will be set to Last Measured Value or Fault during the test, the outputs will
be fixed for two minutes (Smart Meter Verification) or three minutes (original version). Disable all
control loops for the duration of the test, and ensure that any data reported during this period is
handled appropriately.

Specification uncertainty limit

The specification uncertainty limit defines the acceptable degree of variation from factory results,
expressed as a percentage. Variation inside the limit is reported as Pass. Variation outside the limit is
reported as Fail or Caution.

• In Smart Meter Verification, the specification uncertainty limit is set at the factory and cannot
be configured.

• In the original version of meter verification, the specification uncertainty limit is configurable.
However, Micro Motion suggests using the default value. Contact Micro Motion Customer
Service before changing the specification uncertainty limit.

10.3.2 Running the meter verification test, original version

To perform meter verification:

• Using ProLink II, follow the procedure illustrated in Figure 10-1.

• Using the display menu, follow the procedure illustrated in Figure 10-2. For a complete
illustration of the meter verification display menu, see Figure C-17.

• Using a PROFIBUS host with the EDD, refer to Figure C-7 and follow the procedure
illustrated in Figure 10-4.

• Using PROFIBUS bus parameters, use the Diagnostic block (see Table D-4) and follow the
procedure illustrated in Figure 10-4.

Note: If you start a meter verification test remotely, the transmitter display shows the following
message:

Configuration and Use Manual 91

Measurement Performance

Verify configuration

parameters

Tools >
Meter Verification >
Structural Integrity Method

View previous test data

Next

Enter optional test data

Initialize and start meter

verification

Next

Abort

Next

Fault

configuration

Hold last

value

Progress bar shows

test in progress

Next

Finish

(2)

Graph of results

Rerun

test?

Yes

PassFail

No

Start

Back

(1)

View report (option to print

or save)

Back

Abort

(1) If the graph was viewed at the beginning of the procedure,

clicking Back here will return to the beginning of the procedure
(along the dotted line).

(2) The results of the meter verification test are not saved until

Finish is clicked.

SENSOR
VERFY/x%

Figure 10-1 Meter verification procedure – ProLink II

92 Micro Motion® Model 2400S Transmitters for PROFIBUS-DP
