Emerson Electric AMS DATA SHEET

FSSF00058AK

SAFETY DATA SHEET

This Safety Data Sheet meets or exceeds the requirements of the Canadian Controlled Product Regulations
(WHMIS), the United States Occupational Safety and Health Administration (OSHA) hazard communication
standard, the Australian National Occupational Health and Safety Commission (NOHSC), the Taiwan Bur eau of
Standards, Metrology & Inspection (BSMI), the Japan Ministry of Economy, Trade and Industry (METI), the
General Administration of Quality Supervision, Inspection and Quarantine of the People’s Republic of
China(GB/T 16483-2008), Brazil standard ABNT NRB 14725-3, Malaysian Department of Environment and the
European Union Commission Regulation (EC) No 1907/2006 and (EU) No 2015/830.

1. Identification of the Substance/Mixture and of the Company/Undertaking

1.1. Product Identifier

Name of the substance: Molicel Rechargeable Lithium-ion cells and multi-cell battery packs.
Product Codes:

IBR18650*, ICR18650*, IMR18650*, INR18650*, INR20700*, IHR18650*, ICP103450*, ICP1003450*, IBR26700*,
IMR26700*, MCR1821*, ME202*.
*Product codes can be followed by letters and/or numbers (A -ZZ, 0-9) which denote model designations.
List of models can be found in section 16 of this SDS.

Identification Number: Not applicable
Registration Number: Not applicable

Synonyms: Lithium-ion Cell, Lithium-ion Pack, Lithium-ion Battery, Li-Ion Cell, Li-Ion Pack, Li-Ion Battery.

Synonyms may be preceded by the brand name Molicel and followed by the product code and model designation.
For example: Molicel Lithium-ion Battery ME202C, Molicel Lithium-ion Cell ICR18650J.

Issue Date: 05-July-2017
Version number: AK
Revision Date: 01-June-2017
Supersedes Date: 03-January-2017

1.2. Relevant identified uses of the substance or mixture and uses advised against.

Identified uses: Rechargeable Lithium-ion cell for single cell or Multi-cell lithium-ion battery packs.
Restrictions on Use: For use as a battery-based power supply only. Do not rupture or expose solution inside of the

cell or pack.

1.3. Details of the supplier of the safety data sheet.

Supplier Name: E-One Moli Energy (Canada) Ltd.
Address: 20,000 Stewart Crescent
Maple Ridge, B.C., Canada, V2X9E7
E-Mail: [e-mail]
Telephone: [phone]

1.4. Emergency telephone number

24 hour emergency number within North America: CANUTEC [phone], collect calls accepted.
(*666 on a cellular phone In Canada Only).
National Poison Control Telephone Numbers: See table 7 in Section 16 for a list by Country/State.

1.5 Details of the local distributor or agent of the products listed on the safety data sheet.

Distributor/Agent Name:
Address:
Other Information:

Factory Name: E-One Moli Energy Corp. (Taiwan)
Address: No.10 Dali 2nd Road, Tainan Science Park
Shan-Hwa, Tainan County, 741, Taiwan
E-Mail: [e-mail]
Telephone: [phone]

Telephone:
Email

:

_________________________________ ____ ___ ____ ____ ______ _ ____ ______ _ _______ ___ _ _______ ___ _____ ___ __
E-One Moli Energy (Canada) Ltd Page 1 of 18 June 2017

FSSF00058AK

2. Hazards Identification

Protective

Clothing

NFPA Rating

(USA)

1

Not required with

normal use.

GHS Hazard

Symbol

00

IATA JIS (Japan) Taiwan China

Not applicable with

normal use.

United States

Not classified as

hazardous

Table 1

2.1. Classification of the substance or mixture.

2.1.1. Preparation Hazards and Classification: The product is a Lithium ion cell or battery and is therefore classified as an

article and is not hazardous when used according to the recommendations of the manufa cturer. The hazard is
associated with the contents of the cell or battery. Under recommended use conditions, the electrode materials and
liquid electrolyte are non-reactive provided that the cell or batter y integrit y remains and the seals remain intact. The
potential for exposure should not exist unless the cell or battery leaks, is exposed to high temperatures or is
mechanically, electrically or physically abused/damaged. If the cell or battery is compromised and starts to leak, based
upon the battery ingredients, the contents are classified as Hazardous.

2.1.2. Classification according to Directive 67/548/EEC or 1999/45/EC as amended: Not applicable.

2.1.3. Classification according to Regulation (EC) No. 1272/2008 as amended: Not applicable.

2.1.4. Hazard Summary
Physical hazards: Not classified for physical hazards.
Health hazards: Not classified for health hazards.
Environmental hazards: Not classified for hazards to the environment.
Specific hazards: Exposure to contents of an open or damaged cell or battery: contact with this material will

Main Symptoms: Symptoms include itching, burning, redness and tearing.

2.2. Label elements

2.2.1. Label according to Regulation (EC) No. 1272/2008 as amended.
Identification Number: Not applicable.
Hazard pictograms: Not applicable.
Signal word: Not applicable.
Hazard statements: Not applicable under normal use in accordance with United Nations Conference on

Brazil

Not classified as

hazardous

EC Classification WHMIS (Canada)

Not classified as

hazardous

Not applicable with

normal use.

SafeWork

(Australia)

Not classified as

hazardous

Not classified as

hazardous

Not classified as

hazardous

Not classified as

hazardous

Malaysia

Not classified as

hazardous

cause burns to the skin, eyes and mucous membranes.
May cause sensitization by skin contact.

Environmental and Development (UNCED) and Occupational Safety and Health
Administration (OSHA) 29 CFR 1910.1200. The article does not meet the criteria for
classification.

_________________________________ ____ ___ ____ ____ ______ _ ____ ______ _ _______ ___ _ _______ ___ _____ ___ __
E-One Moli Energy (Canada) Ltd Page 2 of 18 June 2017

FSSF00058AK

Precautionary
Statement(s)
Prevention

Response

(If cell/battery
leaks)

Health

(if cell/battery leaks)

Storage

(Store as indicated
in Section 7)

Disposal

Table 2

Supplemental label information: None.

2.3. Other Hazards.

2.3.1. Appearance, Color and Odor: Solid object with no odor.

2.3.2. Primary Routes(s) of Exposure: These chemicals are contained i n a sealed enclosure. Risk of exposure occurs only

2.3.3. Potential Health Effect(s):

2.3.3.1. Acute (short term): see Section 8 for exposure controls.

In the event that this cell or pack has been ruptured, the electrolyte solution contained within the cell would be corrosive
and can cause burns to skin and eyes.
Inhalation: Inhalation of materials from a sealed cell is not an expected route of exposure. Vapors or mists from a
ruptured cell may cause respiratory irritation.
Ingestion: Swallowing of materials from a sealed cell is not an expected route of exposure. Swallowing the contents of
an open cell can cause serious chemical burns to mouth, esophagus, and gastrointestinal tract.
Skin: Contact between the cell and skin will not cause any harm. Skin contact with the contents of an open cell can
cause severe irritation or burns to the skin.
Eye: Contact between the cell and the eye will not cause any harm. Eye contact with the contents of an open cell can
cause severe irritation or burns to the eye.

2.3.3.2. CHRONIC (long term): see Section 11 for additional toxicological data.

2.3.4. Medical Conditions Aggravated by Exposure: Not Available.

2.3.5. Interactions with other chemicals: Immersion in high conductivity liquids may cause corrosion and breaching of the

2.3.6. Potential Environmental Effects: Not Available.

P102: Keep out of reach of children.
P103: Read label prior to use.
P202: Do not handle until all safety precautions have been read and understood.
P210: Keep away from heat/sparks/open flames/hot surfaces – No smoking.
P234: Keep only in original container.
P254: Wash hands thoroughly after handling.
P260: Do not breathe vapor or spray.
P280: Wear protective gloves/protective clothing/eye protection/face protection.
P301/330/331: IF SWALLOWED: Rinse mouth. DO NOT induce vomiting.
P303/361/353: IF ON SKIN (or hair): Remove/Take off immediately all contaminated clothing. Rinse skin with
water/shower.
P304/340: If INHALED: Remove victim to fresh air and keep at rest in a position comfortable for breathing.
P305/351/338: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present
and easy to do. Continue rinsing.
P310: Immediately call a POISON CENTER or doctor/physician.
P363: Wash contaminated clothing before reuse.
P370: In case of fire: Use carbon dioxide, dry chemical or water extinguisher.
P391: Collect spillage.
H314: Causes severe skin burns and eye damage.
H315: Causes skin irritation.
H317: May cause an allergic skin reaction.
H319: Causes serious eye irritation.
H335: May cause respiratory irritation.
H400: Very toxic to aquatic life.
H410: Very toxic to aquatic life with long lasting effects.
P402: Store in a dry place.
P405: Store locked up.
P410: Protect from sunlight.
P406: Store any spilled/leaking electrolyte material in a corrosive resistant container with a resistant inne r liner.
P501: Dispose of batteries in accordance with applicable hazardous waste regulations.

if the cell or pack is mechanically, thermally, electrically or physically abused to the point of compromising the enclosure.
If this occurs, exposure to the electrolyte solution contained within can occur by inhalation, ingestion, eye contact and
skin contact.

cell or battery enclosure. The electrolyte solution inside of the cells may react with alkaline (basic) materials and
present a flammability hazard.

_________________________________ ____ ___ ____ ____ ______ _ ____ ______ _ _______ ___ _ _______ ___ _____ ___ __
E-One Moli Energy (Canada) Ltd Page 3 of 18 June 2017

FSSF00058AK

3. Composition/information on ingredients

3.1. As a solid, manufactured article, exposure to hazardous ingredients is not expected with normal use.

Canada: This is not a controlled product under WHMIS. This product meets the definition of a “manufactured article” and is

not subject to the regulations of the Hazardous Products Act.
USA: This cell or battery is an article pursuant to 29 CFR 1910.1200 and, as such, is not subject to the OSHA Hazard

Communication Standard requirement. The information contained in this Safety Data Sheet contains valuable information
critical to the safe handling and proper use of the product. This SDS should be retained and available for employees and
other users of this product.

Australia: The product is a Lithium-ion cell or battery and is therefore classified as an article and is not hazardous when
used according to the recommendations of the manufacturer. The hazard is associated with the contents of the cell or
battery. If the cell or battery is compromised and starts to leak, based upon the battery ingredients, the contents are
classified as Hazardous according to the criteria of the National Occupational Health and Safety Commission (SafeWork
Australia).

EU: This product is an article according to the REACH Regulation (1907/2006) and (EC) No 2015/830.
Taiwan: This product is not classified as a dangerous good.
Japan: This product is not classified as a dangerous good.
China: This product is not classified as a dangerous good.
Brazil: This product is an article according to ABNT NRB 14725-2:2009.

*Concentration

Cell

Component

Electrolyte
Electrolyte salt

Electrolyte
solvents

Chemical Name CAS No. EINECS

Contains Electrolyte salt
and solvents.
Lithium
hexafluorophosphate
Includes one or more of
the following;
Ethylene Carbonate
Propylene Carbonate
Diethyl Carbonate
Dimethyl Carbonate
Ethyl Methyl Carbonate

5-20
21324-40-3 244-334-7 5-30 1-5 -

96-49-1
108-32-7
105-58-8
616-38-6
623-53-0

202-510-0
203-572-1
203-311-1
210-478-4

Not Listed
PVDF Polyvinylidenfluoride 24937-79-9 Not Listed - <1 ­Copper Cu 7440-50-8 231-159-6 - 9-18 ­Aluminium Al 7429-90-5 231-072-3 - 17-27 -

Cathode

Anode

Includes one or more of
the following;
Lithium Cobaltite
Manganese
Nickel
Aluminum
Includes one or more of
the following;
Graphite
Carbon Black

12190-79-3
7439-96-5
7440-02-0
7429-90-5

7782-42-5
1333-86-4

235-362-0

231-105-1

231-111-4

231-072-3

231-955-3

215-609-9
Steel, Nickel,
and inert

Various Various - Balance -

components

Table 3

*Quantities may vary depending on cell or battery model.

_________________________________ ____ ___ ____ ____ ______ _ ____ ______ _ _______ ___ _ _______ ___ _____ ___ __
E-One Moli Energy (Canada) Ltd Page 4 of 18 June 2017

range in

electrolyte

*Mass range

in cell (g/g %)

GHS

Classification

(w/w %)

Skin Corr 1B
– H314

70-95 5-20 -

- 20-50 -

- 13-18 -

FSSF00058AK

4. First Aid Measures

4.1. Description of first aid measures

The hazardous components of this cell or battery are contained within a sealed unit. The following measures are only applicable if
exposure has occurred to components when a cell or battery leaks, is exposed to high temperatures or is mechanically, electrically
or physically abused/damaged. The hazardous contents are caustic alkaline electrolytes contained in cells with lithium metal oxide
cathodes, graphite and carbon anodes and Polyvinylidenfluoride binders.

Ingestion: Have victim rinse mouth thoroughly with water. DO NOT INDUCE VOMITING.

Contact your local poison control center and quickly transport victim to an emergency care facility.

EYE: If eye contact with contents of an open cell occurs, immediately flush the contaminated eye(s) with

water. Quickly transport victim to an emergency care facility.

Skin Contact: Immediately flush with water. If irritation or pain persists, seek medical attention.
Inhalation: Remove the patient from exposure into fresh air, seek medical attention.

PROTECTION FOR FIRST
AIDERS: Do not enter corrosive vapor contaminated areas without a respirator or Self Contained Breathing

Apparatus. Wear adequate personal protective equipment as indicated in Section 8.

FIRST AID FACILITIES: Eye wash bottle, fountain, safety showers or at least a source of running water are required in the

area where the product is used.

4.2 MOST IMPORTANT SYMPTOMS & EFFECTS, ACUTE & DELAYED, CAUSED BY EXPOSURE:
ACUTE: The contents of the battery are rated as corrosive. Ingestion of the electrolyte could lead to severe

gastrointestinal tract irritation with nausea, vomiting and potentially burns. Inhalation of va pors may
lead to severe irritation of the mouth and upper respiratory tract with a burning sensation, pain,
burns and inflammation in the nose and throat; there may also be coughing or difficulty breathing.
Eye contact may lead to severe eye irritation or in worst case scenario irreversible damage and
possible eye burns. Skin contact may lead to irritation and possible skin burns.

CHRONIC: Skin contact may aggravate/exacerbate existing skin conditions, such as dermatitis. Chronic

inhalation may lead to the same symptoms as listed for acute inhalation above.

4.3 Indication of any immediate medical attention and special treatment needed
ADVICE TO DOCTOR: Treat symptomatically if the person comes into contact with the corrosive electrolyte liquid contents

of a damaged battery.

5. Fire Fighting Measures

5.1 Extinguishing media

5.1.1 Suitable extinguishing media: Dry chemical, carbon dioxide and foam. Water acts as a cooling agent.

5.1.2 Unsuitable extinguishing media: Strong oxidizing agents, strong reducing agents, strong acids and strong alkalis.

Despite water incompatibility, water is the most effective firefighting tool to control the spread of fire to other
cells and batteries and combustibles.

5.1.3 Explosion Data: Closed containers may explode, burst, rupture or vent when exposed to temperatures above 120°C
(248°F).

5.1.4 Hazchem Code (Australia, New Zealand, UK and Malaysia): 4W

5.1.5 TDG/DOT ERG Code: 147

5.1.6 Sensitivity to Mechanical Impact: Extreme mechanical abuse will result in rupture of the individual battery cells.

5.1.7 Sensitivity to Static Discharge: Electrostatic discharges imposed directly on the spilled electrolyte may start
combustion.

5.2 Special hazards arising from the Chemical:

The interaction of water vapor and exposed lithium hexafluorophosphate (LiPF6) may result in the generation of hydrogen and
hydrogen fluoride (HF) gas. Contact with battery electrolyte may be irritating to skin, eyes and mucous membranes. Thermal
degradation may produce hazardous fumes of lithium, cobalt and manganese, hydrofluoric acid, hydrogen and oxides of carbon,
aluminum, lithium, copper and cobalt as well and smoke and irritating, corrosive and/or toxic gases. Fumes may cause dizziness
or suffocation.

5.3 Advice for firefighters:
In case of fire where lithium-ion cells and batteries are present, flood the area with water. If any cells or batteries are burning,

water may not extinguish them, but will cool the adjacent cells or batteries and control the spread of fire. Carbon Dioxide, dry
chemical and foam extinguishers may be preferred for small fires, but also may not extinguish burning lithium-ion cells or batteries.
Burning cells or batteries will burn themselves out. Virtually all fires involving lithium-ion cells and batteries can be controlled with

_________________________________ ____ ___ ____ ____ ______ _ ____ ______ _ _______ ___ _ _______ ___ _____ ___ __
E-One Moli Energy (Canada) Ltd Page 5 of 18 June 2017

FSSF00058AK

water. When water is used, however, hydrogen gas may be evolved which can form an explosive mixture with air. LITH-X
(powdered graphite) or copper powder fire extinguishers, sand, dry ground dolomite or soda ash may also be used. These
materials act as smothering agents.

5.4 Protective Equipment and Precautions for firefighters:
In the case of a fire and the release of hydrogen fluoride, it is critical to protect the skin from any contact. Fire fighters should wear
a self-contained breathing apparatus. Burning lithium-ion cells and batteries can produce toxic fumes including hydrogen fluoride
(HF), oxides of carbon, aluminum, lithium, copper and cobalt. Volatile phosphorous penta fluoride may form at temperatures above
110°C (230°F). Wear adequate personal protective equipment as indicated in Section 8.

6. Accidental Release Measures

6.1. Personal precautions, protective equipment and emergency procedures:

6.1.1. For non-emergency personnel.

6.1.1.1. As an immediate precautionary measure, isolate spill or leak area for at least 25 meters (75 feet) in all directions.

Keep unauthorized personnel away. Stay upwind. Keep out of low areas. Ventilate closed areas before entering.
Wear adequate personal protective equipment as indicated in Section 8.

6.1.2. For emergency responders

6.1.2.1. As an immediate precautionary measure, isolate spill or leak area for at least 25 meters (75 feet) in all directions.

Keep unauthorized personnel away. Stay upwind and keep out of low areas. Ventilate closed areas before
entering. Do not enter corrosive vapor contaminated areas without a respirator or Self Contained Breathing
Apparatus.
Suitable fabric for personal protective clothing: Chemical resistance gloves, safety glasses/goggles or face shield
and chemical resistant clothing. Wear adequate personal protective equipment as indicated in Section 8.

6.2. Environmental precautions

6.2.1. Absorb spilled material with non-reactive absorbent such as vermiculite, clay or earth. Prevent from migration into soil,

sewers and natural waterways – inform local authorities if this occurs.

6.3. Methods and material for containment and cleaning up

6.3.1. Evacuate spill area immediately and remove sources of ignition. Do NOT touch spilled material. Use non-sparking tools

and equipment where applicable. Ensure that cleanup procedures do not expose spilled material to any moisture.
Cover all drains and exits to the environment to prevent migration into the soil, sewers and natural waterways.

6.3.2. Cleanup personnel must be trained in the safe handling of this product. Spills may be absorbe d b y non- reactive

absorbents such as vermiculite and then collected with an electrically protected vacuum cleaner or by wet-brushing and
placing into a suitable container for disposal. Place cells or batteries into individual plastic bags and then place into
appropriate containers and close tightly for disposal. Immediately transport closed containers outside. Lined steel
drums are suitable for storage of damaged cells or batteries until proper disposal can be arranged. Ventilate area and
wash spill site after material pickup is complete. Please consult local regulations on disposal of hazardous waste for
complete details.

6.3.3. Never dispose of damaged cells or batteries in a fire.

6.4. Reference to other sections

6.4.1. For information on Hazards, see Section 2 of the SDS.

6.4.2. For information on personal protective equipment, see Section 8 of the SDS.

6.4.3. For information on physical and chemical properties, see Section 9 of the SDS.

6.4.4. For information on stability and reactivity, see Section 10 of the SDS.

6.4.5. For information on environmental effects, see Section 12 of the SDS.

6.4.6. For waste disposal, see section 13 of the SDS.

7. Handling and Storage

7.1. Precautions for safe handling

7.1.1. Do not short circuit, open, disassemble, crush, puncture or burn cells or batteries. Do not expose cells or batteries to

extreme heat or fire. Do not solder cells. Do not mix cells of different types and brands. Do not mix new and used cells
or batteries. Do not incinerate the cells or batteries as there is a danger of explosion. Do not use or charge damaged,
defective or deformed cells or batteries.

7.1.2. Observe good industrial hygiene practices. Wash hands thoroughl y after handling.

_________________________________ ____ ___ ____ ____ ______ _ ____ ______ _ _______ ___ _ _______ ___ _____ ___ __
E-One Moli Energy (Canada) Ltd Page 6 of 18 June 2017
