surge protective Devices (spD) anD filtering
“enDuring protection”
INTRODUCTION
SolaHD understands that your operations depend on clean, continuous power. That’s why, since 1915, SolaHD has focused exclusively on being the premier brand for industrial power quality by eliminating the power interruptions, transients and noise that can stop production and corrupt data. Our full breadth of products convert, clean and maintain electric current from the factory entrance to equipment throughout your facility. Combined with service and support, our total power quality offering can save you time, money and space to ensure optimal production efciencies.
INTRODUCTION 2
PRODUCT OVERVIEW 4
SURGE PROTECTIVE DEVICE/FILTER - APPLICATION SELECTION TABLE 5
UL 1449 AND IEEE 6
SURGE PROTECTION
STV 200/400K Series 7
STV 100K Series 10
STV 25K DIN Rail Mount Series 12
ACTIVE TRACKING® FILTERING WITH SURGE PROTECTION
STF Series Active Tracking® Filters 14
STFV Plus Series Active Tracking Filters with Surge Protection (Chassis Mount) 17
STFE Elite Series Active Tracking Filters with Surge Protection (DIN Mount) 20
DATA/SIGNAL LINE SURGE PROTECTION
STC Series of Data/Signal Line Surge Protection 22
2
HOW DO YOU PROTECT YOUR POWER?
Employing an entire facility protection strategy will safeguard the electrical system against most transients. Multi-stage protection involves clamping the initial high energy surge, ltering any remaining noise or transients to the protected sensitive equipment and nally, protecting the data/signal lines entering or leaving the control panel or the factory oor. This coordination of devices provides the lowest possible let through voltage to the equipment.
B
STV 100K Surge Suppressor Device (SPD)
Surge Suppressor STV100k Series
1
LINE
SERVICE
Distribution
Transformer
STV 200/400K Service Entrance Surge Protective Device
Surge Protective Device STV200/400K Series
FULL
MODULE
PROTECTION
MODULE
DISABLED
TEST
LINE
REDUCED PROTECTION
1 2
ALARM
2
Surge Suppressor
2
LINE
STV100k Series
1
LINE SERVICE
STV 100K Surge Protective Device (SPD)
Surge Suppressor
2
LINE
STV100k Series
1
LINE
SERVICE
C
A
STC-PoE
Ethernet Surge Protective Device
(located behind server)
S5K Modular UPS
K-Factor Harmonic Transformer
LVGP Transformer
SDU Off-Line UPS
Solatron Plus Three Phase Power Conditioner
MCR Series
Constant Voltage
Power Conditioner
STC-DRS DIN mounted Surge Protective Device For Data
D
Signals
4
5
6
LINE
LINE
STS-DRS-060
SHIELD
1
2
3
OK
Active Tracking Filter STF Elite Series
STF Elite Active Tracking Filter With Surge Protection
E
STC-CCTV Surge Protective Device For Coaxial
C A B L E
STC-CCTV-751
E Q U I P
F
4 5 6
LINE LINE SHIELD
STS-DRS-060
1 2 3
OK
Active Tracking Filter STF Elite Series
G
L L1
N
LOAD
L2
G G
Status OK
Active Tracking Filter
STFV Plus Series
STFV Plus Series
Surge Protection and Active Tracking Filter
LINE L L1
N L2
G G
A STV 200/400K: Surge protective devices capable of handling
the high-impulse, potentially damaging transients commonly found at the service entrance, distribution panels, and placement in the most severe exposure locations.
B STV 100K: Surge protective devices designed to protect
sensitive equipment and microprocessor-based systems from transients on distribution and sub-distribution panels, or any medium exposure locations.
C STC-POE: Surge protective devices designed to work on
Power-over-Ethernet Category 5 PoE transmission lines as well as Category 6 applications.
D STC-DRS: DIN Rail mountable, single pair, low voltage data,
surge protective devices. e hybrid design of these data/ signal line protective devices allows them to respond quickly.
E STFE: DIN Rail mountable high-frequency noise lter/surge
protection that oers the original Active Tracking Filter technology with UL approved transient protection to guard against commonly occurring, but very damaging transients, plus provides excellent noise reduction.
F STC-CCTV: Surge protective devices tailored to protect CCTV,
data, audio and cable applications.
G STFV: High-frequency noise lter/surge protection that
oers the original Active Tracking technology with transient protection to guard against commonly high voltage transients, plus provides excellent noise reduction.
3
SURGE PROTECTION, FILTERING, DATA/SIGNAL LINE PROTECTION
SURGE PROTECTION • First Line of Defense in Limiting High-Impulse Transients
High-energy transients either externally or internally generated pose an immediate threat to the reliability and performance of your sensitive electronic equipment. SolaHD recommends placing high­energy Surge Protective Devices (SPDs) on key panels throughout your facility. Within your facility, motors, inductive loads and various equipment load switching can cause damage or costly downtime.
Our surge protective devices focus on limiting high-voltage spikes to a level that is acceptable to most electronic equipment. Plus, they’re a great rst line of defense, using components that are placed in parallel with the line and serve as clamping mechanisms for high­energy impulses. Protection at this level is referred to in the industry as Sine Wave Tracking or electronic grade. Surge Protective Devices are typically installed at service entrances and on larger distribution panels.
ACTIVE TRACKING FILTERING WITH SURGE PROTECTION • Provides Clean AC Power by Eliminating Low-Voltage Noise
Service Entrance/ Sub Panels
STV 200/400K
• Typical applications of 800 amperes and above
• Surge current
capacity – 200,000 to 400,000 Amps per phase
Low-energy transients and high-frequency noise are the primary causes for system disruption and long-term degradation of microprocessor­based equipment within your facility. For more than 30 years, our Active Tracking Filters have proven to be the most eective solution in critical equipment protection within harsh industrial environments. Active Tracking Filters are built upon a unique multi-stage hybrid design. is design creates a foundation for a family of products that attenuate impulses that would normally go untouched by standard, parallel clamping devices.
Changing technology and dependence on total automation processes within modern facilities create a critical need for clean AC power at the equipment level. Active Tracking Filters are a perfect solution for your microprocessor-based products, including industrial PLCs, OEM applications and motion control systems.
STFE Elite Series
• DIN mount
• Critical loads up to 20
amperes of continuous current
Branch Distribution
STV 100K
• Typical applications
up to 1,200 amperes
• Surge current
capacity – 100,000 Amps per phase
STF & STFV Series
• Hard-wired connection
• Critical loads up to 30
amperes of continuous current
Point of Use Locations
STV 25K
• Typical applications
of 20 amperes and below
• Surge current
capacity – 25,000 Amps per phase
DATA/SIGNAL LINE SURGE PROTECTION • Designed to Protect Sensitive Instrumentation
e rapid development of automated controls, telecommunications and re/alarm/security systems make it imperative to have properly coordinated low-voltage surge protection. Modern networked industrial facilities require error-free transmission of information for maximum productivity and integrity of data, but these areas are often overlooked when it comes to power protection.
e need to protect all susceptible low-voltage cable routes entering a facility and at key points within the building is as critical as protecting the equipment from high-energy impulses. e importance of protecting at this level grows as your facility’s reliance on sensitive instrumentation, networked automation, and uncorrupted data transmission increases. Our Data/Signal Line products utilize high-speed, high-energy components that come in a variety of voltage levels and unique packaging congurations.
4
POWER QUALITY SOLUTIONS
STC Series
• Three stage hybrid protection
• <1 nanosecond response times
• Variety of voltage and packaging congurations
SURGE PROTECTION
ACTIVE TRACKING FILTERING
WITH SURGE PROTECTION
DATA/SIGNAL
APPLICATIONS
STV 200/400K STV 100K STV25K STFE STFV STC
Facility Service
Entrance
Distribution Panels
Sub-Distribution
Panels
Branch Panelboards
(Commercial)
Branch Panelboards
(Residential)
Motor Control
Centers
Programmable
Logic Controllers
Control Panels
(AC Power)
Various OEM
Equipment
Transmitters
PoE
(Power-over-Ethernet)
Industrial
Communications
Programmable
Logic Controllers
(I/O Circuits)
Control Panels
(Low Voltage)
Water/Wastewater
Instrumentation
SURGE PROTECTIVE DEVICE/FILTER APPLICATION SELECTION TABLE
55
FOR ALL YOUR APPLICATION NEEDS
UL 1449 AND IEEE
Underwriters Laboratories (UL) Standard for Safety, Transient Voltage Surge Suppressors (UL 1449) has undergone a number of changes and will continue to drive application changes throughout the industry. is includes a change in nomenclature from transient voltage surge suppressors (TVSS) to surge protective devices (SPD) and recognition of the standard by the American National Standard Institute (ANSI). e adoption of the third edition of UL 1449 also aects performance testing methodologies, SPD ratings and the appropriate application of SPDs.
Prior versions of the standard did not take into account the performance of the protector. So many products have entered the market that essentially provided no benet, but were ‘safe for use’. To address this, UL under took these major changes and introduced a 2nd edition to the standard. Once the new standard was put into practice, it became clear there were still some more issues that needed to be addressed, therefore, UL decided to make further changes in the form of a 3rd edition to UL 1449.
ANSI/UL 1449 ird Edition Revisions Field Summary
SPD Locations by UL 1449 Types:
UL now categorizes surge protective devices (SPD) into categories based on its intended application.
• TYPE 1 - Connect anywhere in the customer’s facility – we strongly urge this to be specied for all critical installations.
• TYPE 2 - Connect downstream on load side of main breaker. Be aware that some competitors may have “conditions of acceptability” that can limit how the device is installed.
• TYPE 3 - Typically cord connected, plug in devices.
• TYPE 4 - Components
Nominal Discharge Current (I Nominal Rating):
is is the peak value of surge current which goes through the SPD (15 surges).
• TYPE 1 - UL tests to 10kA or 20kA. Not to be confused with maximum kA rating of the device. We recommend 20kA I Nominal rating be specied. While this is the highest UL rating, it is a low level surge which should be required by any device in even moderate exposure installations.
•TYPE 2 - UL tests to 3kA, 5kA, 10kA or 20kA I Nominal ratings. Again, 20kA is recommended for all specied SPD located at service entrances.
Voltage Protection Rating (VPR):
ese ratings replace the Suppressed Voltage Ratings (SVR) of the prior standard. UL uses a surge six times the current level of the SVR testing, so ALL measured VPR ratings are higher than the previous SVR rating.
All facilities that employ mission-critical electronic equipment should have a properly sized surge protective device (SPD) installed at the main electrical service entrance and throughout their facility at the distribution and branch levels. e surge protection connected to the incoming power line provides the rst line of defense against transient surges which are typically caused by nearby utility grid switching, lightning or other power disturbances. However, disturbances can be internally generated as well as externally generated so employing SPDs at key panels throughout your facility will also provide suitable downstream protection from external surges and local protection from internal high-energy transients caused by motors, inductive loads, and various equipment load switching that can also cause damage or costly downtime.
IEEE Standard 1100-2005, e Emerald Book: IEEE Recommended Practice for Powering and Grounding Electronic Equipment recommends a tiered SPD protection from your Service Entrance down to branch panel level.
7.2.4 Surge suppressors: “…Eective surge protection for an entire building power distribution system requires the coordinated use of large-capacity current-diverting devices at the service entrance followed by lower capacity voltage-clamping devices applied strategically throughout the power system.”
6
STV 200/400K SERIES
SolaHD STV 200/400K Series oers continuous protection from damaging voltage transients and electrical noise commonly found at the service entrance or distribution panel. e modular design of the STV 200/400K allows for installation exibility and the robust design allows for installation in the most severe exposure locations. ey are capable of handling the high-impulse, potentially damaging transients commonly found at the service entrance or distribution panels. e modular design of the STV 200/400K allows for installation exibility. e robust design allows for placement in the most severe exposure locations.
e STV 200/400K utilizes circuitry to monitor the status of all protection modes, including neutral to ground. Should protection be unavailable in any mode, the Green LED will be extinguished, and the Red LED will be illuminated. In addition, high isolation form C dry contacts provide remote monitoring of protection system failure, under voltage, phase and power loss. e STV 200/400K protection integrity monitoring indicates failure for both shorted or opened protection components.
ese devices are built to meet your unique requirements, and are available in hardwire, three phase conguration. ey are designed for years of trouble free operation and require little or no operator intervention after installation.
Applications
e STV 200/400K Series can be a facility-wide product family and may be installed from service entrances to distribution panels to branch panels.
Industrial Plants
Commercial Buildings
Institutional Facilities
Any facility that has an environment with electronics based
equipment
• Custom options (contact technical support)
- NEMA 12 enclosure, NEMA 3R, 4, and 4X
- Optional rotary disconnect, transient counter and remote monitor panel
Selection Table
CATALOG NUMBER
STV 400K-10Y
STV 200K-10Y
120/208 V ree-Phase Wye, 4-Wire + Ground
208 Y/120 V ree-Phase Wye, 4-Wire + Ground
INPUT
VOLTAGE
Features
• Modular design allows for exibility
• Surge current capacity of 200 to 400 kA per phase
• UL 1449 3rd Edition, Type 1, 20kA I-nominal approved
device
• Industry’s highest surge current repeatability
• All modes transient protection (L-N, L-G, and N-G)
• Form C dry contacts and audible alarm status indications
• Internal/external monitoring, including neutral to ground
• EMI/RFI Filtering
• Five year limited warranty
STV 400K-27Y
STV 200K-27Y
STV 400K-48D
STV 200K-48D
480 Y/277 V ree-Phase Wye, 4-Wire + Ground
480 Y/277 V ree-Phase Wye, 4-Wire + Ground
480 V ree-Phase ∆, 3-Wire + Ground
480 V ree-Phase ∆, 3-Wire + Ground
7
Surge protection
Specications
STV 200/400K SERIES
Parameters
STV200K-10Y STV200K-27Y STV200K-48D STV400K-10Y STV400K-27Y STV400K-48D
Catalog Number
208 Y/120 V 480 Y/277 V 480 V 208 Y/120 V 480 Y/277 V 480 V
Input Voltage
Maximum Continuous Operating Voltage (MCOV)
3Ph Wye,
4 W + G
3Ph Wye,
4 W + G
3Ph Delta,
3 W + G
3Ph Wye,
4 W + G
125% of the nominal level for 120 V; 115% for all other voltages
3Ph Wye,
4 W + G
3Ph Delta,
3 W + G
Line Frequency 47–63 Hz
Response Time < 0.5 ns
Enclosure Metal, UL Listed /NEMA type 12 (3R, 4, 4X also available)
Mounting Type Wall Mounted (mounting hardware ¼ in.)
Connection Internally connected
Status Indication Red and green LED status indicators, audible alarm, summary alarm contacts
Operating Temperature -40°C to +50°C
Operating Humidity 0% to 95% non-condensing
Noise Attenuation 50 dB maximum
Modes of Protection All Modes: L–N, L–L, L–G, N–G *
AIC Rating 200 kAIC
Nominal Discharge Current Rating (I
)
n
20 kA
Warranty 5 year limited warranty
rd
UL 1449, 3
Edition, Type 1 Voltage Protection Ratings (VPRs)
Line to Neutral 800 V 1200 V N/A 700 V 1200 V N/A
Line to Line 1200 V 2000 V 2000 V 1200 V 1800 V 2000 V
Line to Ground 900 V 1200 V 1800 V 800 V 1200 V 1800 V
Neutral to Ground 700 V 1000 V N/A 700 V 1000 V N/A
Peak Surge Current Capability
Per Phase 200 kA 200 kA 200 kA 400 kA 400 kA 400 kA
Line to Neutral 100 kA 100 kA N/A 200 kA 200 kA N/A
Line to Line 100 kA 100 kA 100 kA 200 kA 200 kA 200 kA
Line to Ground 100 kA 100 kA 100 kA 200 kA 200 kA 200 kA
Neutral to Ground 100 kA 100 kA N/A 200 kA 200 kA N/A
* Delta Model does not offer N–G mode of protection
8
Surge protection
STV 200/400K SERIES
8.25
(209.6)
1.30 max. (33.0)
12.00
(304.8)
14.25
(362.0)
16.25 (412.8)
16.75 (425.5)
0.31 (7.9)
Phase L1/A Phase L2/B Phase L3/C
Service Panel for
Loads to be Protected
Disconnect/Main
Neutral Bus
Ground Bus
Panel
Breaker for
Recommended Wire
Entrance
Dedicated
(Optional)
Disconnect
Summary Alarm Contacts (x2)
Pin 1 = Normally Open
Pin 2 = Common
Pin 3 = Normally Closed
TB1 TB2
1 2 3 1 2 3
Dimensional Drawings
Dimensional Specications
STV 200/400K SERIES
CATALOG NUMBER
STV200K
STV400K
CATALOG NUMBER
STV200K 38 (17.23) 8.25 x 14.25 x 16.25 40 A #8 15–175 A #14–2/0
STV400K 45 (20.41) 8.25 x 14.25 x 16.25 100 A #2 15–175 A #14–2/0
WEIGHT
LBS (KG)
35 (15.88) 8.25 x 14.25 x 16.25 40 A #8 15–100 A #14–2
42 (19.05) 8.25 x 14.25 x 16.25 100 A #2 15–100 A #14–2
WEIGHT
LBS (KG)
DIMENSIONS D x W x H (IN.)
Dimensions
D x W x H (IN.)
SUGGESTED
BREAKER SIZE
UNITS WITH ROTARY DISCONNECT
SUGGESTED
BREAKER SIZE
SUGGESTED WIRE
SIZE (AWG)
SUGGESTED WIRE
SIZE (AWG)
ALLOWABLE
BREAKER RANGE
ALLOWABLE
BREAKER RANGE
ALLOWABLE
WIRE
RANGE
ALLOWABLE
WIRE
RANGE
9
Surge protection
