Emerson MS7630 User Manual

HOME AUDIO SYSTEM
with CD PLAYER
and CASSETTE RECORDER

OWNER'S MANUAL

MS7630

Visit our web site at www.emersonradio.com

MS7630_011504.p65 15/1/2004, 11:2926

!

CAUTION

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrow­head symbol, within an equi­lateral triangle is intended to
alert the user to the presence
of uninsulated ‘dangerous voltage’
within the product’s enclosure
that may be of sufficient
magnitude to constitute a risk
of electric shock to persons.

WARNING: TO REDUCE THE
RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER
(OR BACK ), NO USE R
SERVICEABLE PARTS INSIDE
REFER SERVICIN G TO
Q U A L I F I ED S E R V I C E
PERSONNEL.

The exclamation point within
an equilateral triangle is in­tended to alert the user to
the presence of important
operating and maintenance
(servicing) instructions in
the literature accompany­ing the appliance.

IMPORTANT SAFETY INSTRUCTIONS

1.) Read these instructions.

2.) Keep these instructions.

3.) Heed all warnings.

4.) Follow all instructions.

5.) Do not use this apparatus near water.

6.) Clean only with dry cloth.

7.) Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.

8.) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.

9.) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10.) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.

11.) Only use attachments / accessories specified by the manufacturer.

12.) Unplug this apparatus during lightning storms or when unused for long periods of time.

13.) Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.

14.) This appliance shall not be exposed to dripping or splashing water and no object filled with
liquids such as vases shall be placed on the apparatus.

15.) Do not overload wall outlet. Use only power source as indicated.

16.) Use replacement parts as specified by the manufacturer.

17.) The product may be mounted to a wall only if recommended by the manufacturer.

18.) Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks.

1

MS7630_011504.p65 15/1/2004, 10:061

Thank you.........for purchasing this Emerson audio product. The Emerson

brand is your assurance of quality, performance and value.
Our engineers have included many useful and convenient features in this

product. Please be sure to read this Owner’s Manual completely to make
sure you are getting the maximum benefit from each feature.

This product was manufactured using the highest quality components and
standards of workmanship. It was tested by Emerson inspectors and found
to be in perfect working order before it left our factory. However, there is
always the chance that some problem may occur because of rough handling
during shipment to the retail store or to the final consumer.

If, after reading this manual, you experience any problems with the operation
of this product, please refer to the instructions for obtaining service at the
end of this manual. Emerson and Emerson retailers are committed to your
satisfaction.

Once again, thanks for purchasing this Emerson audio product.
For future reference, record the serial number in the space provided.

Model No: MS7630
Serial No:

MS7630_011504.p65 15/1/2004, 10:062

2

IMPORTANT NOTES

•Avoid instal ling this unit in places

exposed to direct s unlight or close to
heat radiating appl iances such as
electric heaters, on top of other stereo
equipment that radiates too much heat,
places lacking ventilation or dusty areas,
places subject to constant vibration and/
or humid or moist areas.

•Do not attempt to clean this unit wi th

chemical solvents as this might damage

•Operate controls and switches as
described in the manual.

•Before turning ‘On’ the power, make
certain that power c ord is properly
installed.

•Store your CDs, cassettes in a cool area
to avoid damage from heat.

•When movi ng the set, be sure to first
disconnect the power cord.

the finish. Use a clean dry cloth.

CLASS 1 LASER PRODUCT

CLASS 1 LASER PRODUCT

APPAREIL Á LASER DE CLASSE 1

PRODUCTO LASER DE CLASE 1

This product contains a low power Laser Device.

FCC INFORMATION

This equipment has been tested and found to comply with the limits for a Class B digital
device, purs uant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:

(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that

may cause undesired operation.

CAUTION

INVISIBLE LASER RADIATION

WHEN OPEN AND INTERLOCKS

DEFEATED.

AVOID EXPOSURE TO BEAM

MS7630_011504.p65 15/1/2004, 10:063

3

PREPARATION FOR USE

AC Outlet

UNPACKING AND SET UP

• Carefully remove the unit from the carton and remove all packing materials

from the unit.

• Carefully remove any small strips of tape which may have been used to keep

the CD and Cassette doors closed during shipment.

• Open the CD compartment by pressing the “PUSH OPEN” position on top

panel. Inside the CD compartment you will see a white transit card which is
used to prevent the laser pick-up from moving during shipment. Carefully
remove this card and close the CD compartment door.

• Please save the carton and packing materials in the event that your unit ever

needs to be returned for service. The original carton and packing materials are
the only way to protect the unit from damage during shipment.

• Unwind the FM lead wire antenna and extend it to its full length.

• Remove the twist-tie from the AC power cord and extend it to its full length.

• Connect the plug to your AC outlet.

POWER SOURCE

This system is designed to operate on normal 120V 60 Hz AC house current only.
Attempting to operate this system from any other power source may cause damage
to the system, and such damage is not covered by your warranty.

NOTE: This unit has a polarized AC plug with one wide blade and one narrow
blade. This plug will only fit into a matching polarized AC outlet. This is a safety
feature to reduce the possibility of electric
shock. If this plug will not fit in your AC
outlet, you probably have an outdated non­polarized outlet. You should have your
outdated outlet changed by a qualified,
licensed electrician. Do not file the wide
blade on the plug, or use an adapter to
make the plug fit into your outlet. This
defeats the safety feature and could expose you to electric shock.

4

MS7630_011504.p65 15/1/2004, 10:064

AC Plug

SPEAKER CONNECTION

E

D

R

+

R

-

L

+

L

-

Connect each speaker to the corresponding speaker terminals on the back panel
of the main unit. Make sure that the left speaker is connected to the (L) left pair of
speaker terminals and the right speaker to the (R) right pair of speaker terminals.
Also make sure that the speaker wires are correctly connected: that the red wires
are connected to the red terminals and the black wires to the black terminals.

Depress the plastic lever to open the terminal, insert the bare end of the speaker
wire into the opening and release.

Red Wire

Power

Power

ON

OFF

Black Wire

R

BLACKRED

PROTECT YOUR FURNITURE

This model is equipped with non-skid rubber 'feet' to prevent the product from
moving when you operate the controls. These 'feet' are made from non-migrating
rubber material specially formulated to avoid leaving any marks or stains on your
furniture. However certain types of oil based furniture polishes, wood preservatives,
or c leaning sprays may cause the rubber 'feet' to soften, and leave marks or a
rubber residue on the furniture. To prevent any damage to your furniture we strongly
recommend that you purchase small self-adhesive felt pads, available at hardware
stores and home improvement centers everywhere, and apply these pads to the
bottom of the rubber 'feet' before you place the product on fine wooden furniture.

5

MS7630_011504.p65 15/1/2004, 10:065

LOCATION OF CONTROLS AND INDICATORS

1234568

2122232425262728293031327

353637

FRONT PANEL

9

10

11
12

13
14

15
16

17
18

19

20

BACK PANEL

33

34

Power

ON

Power

OFF

6

MS7630_011504.p65 15/1/2004, 10:066

FRONT PANEL

1.) POWER ‘On’ Indicator.

2.) CD Track Number Display.

3.) REPEAT Indicator.

4.) CD PLAY/Pause Indicator.

5.) FM ST. Indicator.

6.) Remote Sensor.

7.) CD Door.

8.) CD Door PUSH OPEN Position.

9.) Tuning Dial Scale.

10.) AM Button.

11.) AM ‘On’ Indicator.

12.) TAPE ‘On’ Indicator.

13.) POWER ON/OFF-VOLUME Control.

14.) CD SKIP Button.

15.) CD SKIP Button.

16.) CD Button.

17.) TAPE Button.

18.) BBS ‘On’ Indicator.

19.) BBS (Bass Boost) Button.

20.) Cassette Door (Behind Cassette Cover).

21.) FM Button.

22.) FM ‘On’ Indicator.

23.) CD PROG. ‘On’ Indicator.

24.) TUNING Control.

25.) CD STOP Button.

26.) CD PLAY/PAUSE Button.

27.) CD REPEAT Button.

28.) CD PROG. (Program) Button.

29.) CD RANDOM ‘On’ Indicator.

30.) CD RANDOM Button.

31.) Main Door Open Tab.

32.) Cassette Control Keys (Behind Cassette Cover).

Record / Play / Fast Rewind / Fast Forward / Stop Ejectct /PAUSEAUSE .

BACK PANEL

33.) External FM Wire Antenna.

34.) AC Power Cord.

35.) Main POWER ON/OFF Switch.

36.) SPEAKER Terminals.

37.) PHONES Jack.

MS7630_011504.p65 15/1/2004, 10:067

7

23456

7

REMOTE CONTROL (CD Operations Only)

1.) SKIP Button.

2.) SKIP Button.

3.) PLAY/PAUSE Button.

4.) STOP Button.

5.) REPEAT Button

6.) PROG (Program) Button.

7.) Battery Compartment.

(Back Cabinet)

BATTERY INSTALLATION

1

1.) Open the battery door on the back of the remote control by pressing the battery

door locking tab in the direction of the arrow.

2.) Insert two “AAA” alkaline batteries (not included) into the battery compartment.

Be sure the batteries are inserted according to the polarity markings inside
the battery compartment.

3.) Replace the battery door.

8

MS7630_011504r.p65 15/1/2004, 12:158

BATTERY REPLACEMENT

When the batteries become too weak, the operating distance of the remote control
is greatly reduced and you will need to replace the batteries.

USING THE REMOTE CONTROL CORRECTLY

• Point the remote control at the Remote Sensor.

• The functions of the buttons on the remote c ontrol are the same as the

corresponding controls on the main unit.

• When there is a strong ambient light sourc e, the performance of the infrared

Remote Sensor may be degraded, causing unreliable operation.

• The maximum effective distance for remote control operation is about 15 feet.

BATTERY PRECAUTIONS

Follow these precautions when using batteries in this device:

1.) Use only the size and type of batteries specified.

2.) Be sure to follow the correct polarity when installing the batteries as indicated in the battery
compartment. Reversed batteries may cause damage to the device.

3.) Do not mix different types of batteries together (e.g. Alkaline and Carbon-Zinc) or old
batteries with fresh ones.

4.) If the device is not to be used for a long period of time, remove the batteries to prevent
damage or injury from possible battery leakage.

5.) Do not try to recharge batteries not intended to be rec harged; they can overheat and
rupture. (Follow battery manufacturer’s directions.)

MS7630_011504.p65 15/1/2004, 10:069

9

OPERATING INSTRUCTIONS

GENERAL CONTROLS

Main POWER Switch (Vacation Switch)

The MAIN POWER SWITCH is located on the back panel of the main unit. This
switch must be ‘On’ in order to operate the system. It is not necessary to turn the
MAIN POWER SWITCH ‘Off’ each time you turn the system ‘off’. Leave the MAIN
POWER SWITCH in the ‘ON’ position at all times, unless the system will not be
used for 30 days or more. In that case you may set the MAIN POWER SWITCH to
the ‘OFF’ position for maximum energy conservation.

Bass Boost Switch (BBS)

This system includes a BBS (Bass Boost) button that provides increased bass
response, especially at lower listening levels. Press the BBS button once to turn
the Bass Boost circuit ‘On’. The BBS indicator comes ‘On’. Press the BBS button
again to turn the Bass Boost circuit ‘Off’. The BBS indicator goes ‘Off’.

Note: If you experience any distortion when listening at high volume levels,
turn the Bass Boost ‘off’.

10

MS7630_011504.p65 15/1/2004, 10:0610

LISTENING TO THE RADIO

• Make sure that the main POWER switch on the back of unit is set to “ON”.

• Make sure that the FM Wire antenna is extended to its full length.

1.) To turn the system ‘on’, rotate the POWER ON/OFF-VOLUME control
downwards until a ‘click’ is heard, and set the Volume to a low level. The POWER
indicator comes ‘on’.

2.) Press the AM or FM button to select radio band as desired. The corresponding
Indicator comes ‘on’.

3.) Turn the TUNING control to tune to the desired radio station.
If you tune to an FM Stereo station, the FM ST indicator will come ‘on’.

4.) Adjust the VOLUME and BBS controls as desired.

5.) When you are finished listening turn the POWER ON/OFF-VOLUME control
upwards until a ‘click’ is heard. All indicators go ‘off’

HINTS FOR BETTER RECEPTION
FM: The FM lead wire antenna on the back panel should be extended to its full

length. You may also have to vary the direction of this antenna until you find
the position that provides the best reception.

AM: The AM bar antenna is inside the cabinet of the main unit. You may need to

change the position of the main unit until you find the position that provides
the best reception for your favorite AM stations.

11

MS7630_011504.p65 15/1/2004, 10:0611

PLAYING COMPACT DISCS

NOTE: Although this portable CD play er can read CD-R and CD-RW discs, in
addition to normal CDs, the playability of CD-R and CD-RW discs may be effected
by the type of software that was used to create the discs, as well as the quality and
condition of the blank media you are using. 100% playability cannot be guaranteed.
This is not an indication of a problem with the player.

• Make sure that the main POWER switch on the back of unit is set to “ON”.

NORMAL PLAYBACK

1.) To turn the system ‘on’, rotate the POWER ON/OFF-VOLUME control
downwards until a ‘click’ is heard, and set the Volume to a low level. The POWER
indicator comes ‘on’.

2.) Press the CD button to select CD function.

3.) Open the CD door by pressing the PUSH OPEN area on top of CD door. If you
have not already removed the white transit card from the CD player, please
remove it now.

4.) Place your CD on the center spindle with the printed
label side facing up. Close the CD door. The player will
read the Table of Contents and the display will show the
total number of tracks on the disc.

If the disc is damaged or up side down, display shows “0 0”.

5.) Press the CD PLAY/PAUSE button to begin playback
on Track 1. The PLAY “Dot” Indicator appears in the
display.

6.) Adjust the VOLUME and BBS controls as desired.

7.) Playback will continue until the end of the disc. When the disc ends the display
again shows the total number of tracks on the disc. You may also stop playback

at any time by pressing the CD STOP button.

Pause Control

To pause momentarily during playback press the CD PLAY/
PAUSE button again. Playback stops but the disc

continues to spin and the PLAY indicator flashes. Press the
CD PLAY/PAUSE button once more to cancel Pause
and resume playback. The PLAY indicator stops flashing.

12

MS7630_011504.p65 15/1/2004, 10:0612

Skipping Tracks and High Speed Music Search

During CD Playback, repeatedly press the SKIP or SKIP buttons to skip to
higher or lower number tracks. When the desired track number appears on the
display release the buttons and playback will begin on the desired track.

To rapidly search forward or back within a track to locate a specific musical passage,
depress and hold either the SKIP or SKIP buttons. The player will move
forward or backward at high speed as long as the buttons are depressed. When
you hear the desired passage release the buttons. Normal playback will resume at
that point.

Repeat Playback

This feature allows you to continuously repeat a single track or the entire disc.

To Repeat A Single Track

Press the REPEAT button once. The REPEAT indicator
flashes. Press the or buttons to select the desired
track, then press the CD PLAY/PAUSE button to begin
Repeat Playback of the selected track.

To Repeat The Entire Disc

Press the REPEAT button twice. The REPEAT indicator
remains ‘on’. Press the CD PLAY/PAUSE button to begin
Repeat Playback of the entire disc.

To cancel Repeat Playback press the REPEAT button until the REPEAT Indicator
goes ‘off’. Repeat Playback is also canceled by pressing the STOP button, or
setting the Function selector to the TAPE, AM or FM position.

13

MS7630_011504.p65 15/1/2004, 10:0613

PROGRAMMED PLAYBACK

This feature allows you to program up to 20 tracks on a disc for playback in any
desired order.

Note: You cannot program tracks while a disc is playing. If the disc is playing
press the STOP button first before beginning the programming steps below:

1.) Press the PROG. button to enter the
Program Mode. The PROG. indicator
and Program number ‘01’ flash.

2.) Press the SKIP or buttons to
select the first track number you wish to
enter in the program memory.

Example: Track Number 8.

3.) When the desired track number appears
on the display, press the PROG. button
again to enter that track in memory. The
program number display advances to
“02”.

4.) Repeat Steps 2-3, selecting a different track number each time until you have
entered up to 20 tracks in the program memory.

Note: You may program the same track number to play multiple times in
the program sequence if desired.

5.) Press the PLAY/PAUSE button to
begin Programmed Playback. The
PROG. indicator stops flashing and
remains ‘on’. Playback will begin with the
first track you programmed and will
continue until the last programmed track
has played.

14

MS7630_011504.p65 15/1/2004, 10:0614

6.) After the last track has played the player stops and the display shows the total
number of tracks on the disc. However the program sequence remains in the
memory and the PROG indicator remains ‘on. Press the PLAY/PAUSE
button to play the programmed sequence again.

7.) To cancel the programmed sequence from the memory press the STOP
button while the player is stopped. The PROG indicator goes ‘off’.

The programmed sequence may also be canceled by removing the disc,
changing function to TAPE, AM, FM, or shutting the system ‘off’.

Program Repeat Playback

You can use the Program and Repeat features together to continuously repeat a
programmed sequence of tracks.

First, program the desired tracks according to Steps 1 through 5 on page 14.
When Programmed Playback begins press the REPEAT button twice to activate

the All Tracks Repeat feature.
The REPEAT Indicator lights and all the

tracks in your programmed sequence will be
repeated continuously.

To cancel Programmed Repeat Playback press the STOP button until both the

PROG. and REPEAT Indicators go ‘Off’.

RANDOM PLAYBACK (Front Panel Only)

This feature allows you to play all the tracks on a disc in random order.
Load the disc as usual and wait until the display shows the total playing time and

number of tracks. Press the RANDOM button on the front panel. The RANDOM
indicator comes ‘on’. The tracks will be played in random order continuously.

To cancel the Random mode press the RANDOM button once more until the
RANDOM indicator goes ‘off’.

15

MS7630_011504r.p65 15/1/2004, 12:1615

PLAYING CASSETTE TAPES

CASSETTE COVER OPEN TAB

1.) To turn the system ‘on’, rotate the POWER ON/OFF-VOLUME control

downwards until a ‘click’ is heard, and set the Volume to a low level. The
POWER indicator comes ‘on’.

2.) Open the cassette cover by pulling it outwards at the open tab.

3.) Open the cassette door by pressing the / key..

4.) Place a pre-recorded cassette tape into the slots on the inside of the door with

the exposed tape facing down and the full reel on the left side.

5.) Press the TAPE button to select Tape function. The TAPE indicator comes

‘on’

6.) Press the cassette Play key to begin playback.

7.) Adjust the VOLUME and BBS controls as desired.

8.) To advance the tape rapidly press the key. To stop the tape before it ends

press the / key..

9.) To rewind the tape rapidly press the key. To stop the tape before it ends

press the / key..

10.) When the tape ends the Automatic Stop System releases the Play key and

shuts off the tape motor. You may then open the cassette door, remove your
tape, turn it over and play the other side if desired.

16

MS7630_011504.p65 15/1/2004, 10:0616

11.) When you are finished listening stop the tape, open the door, remove the tape

and close the door. If you are playing a tape and then switch to the Radio or
CD function be sure to press the / key to disengage the tape mechanism.
This prevents excess wear and tear on the mechanism.

IMPORTANT:

Always press the / key to shut off the tape motor before opening the cassette
door to remove y our tape. The Automatic Stop System does not function in the
Fast Forward and Rewind modes. When the tape ends in the Fast Forward

and Rewind modes the motor continues to run. You must press the /

key to shut off the motor before opening the door to remove your tape.

MS7630_011504.p65 15/1/2004, 10:0617

17

MAKING A TAPE RECORDING

This model allows you to make tape recordings directly from the CD player, or the
radio.

• Refer to “PLAYING COMPACT DISCS” if necessary to operate the CD player.

• Refer to “LISTENING TO THE RADIO” if necessary to tune in the station you

wish to record from radio.

1.) Press the / key to open the cassette door..

2.) Insert a good quality blank cassette tape into the slots on the cassette door

with the open end facing up and the full reel on the right. Use normal tape only.
Do not use tape identified as “CrO2” (Chrome) or “Metal” tape formulations.
For best results use tapes of 60 minutes (C-60) or less. Do not use 90 minute
or 120 minute tapes as these thinner tapes are more likely to jam in the
mechanism.

3.) Close the cassette door.

4.) When you are ready to start recording press the Record key. The Play

key will also engage. The CD you are playing, or radio program you selected
will be recorded directly on to the tape.

5.) Press the Pause key during recording to stop the tape temporarily and

avoid recording unwanted material such as radio commercials.

6.) When you have finished recording press the / key to stop and remove the

tape.

Automatic Recording Volume Level Control

This unit has an Automatic Level Control (ALC) circuit which controls the recording
volume level and prevents overloaded and distorted recordings. The VOLUME
and BBS controls has no effect on recording volume level. You may change the
VOLUME control setting during the recording or even reduce the volume level to
“Minimum”. This will not effect the level of the recording.

18

MS7630_011504.p65 15/1/2004, 10:0618

STEREO HEADPHONE JACK

Connect a set of stereo headphones (not included) with a 3.5mm mini plug to the
PHONES jack (located at back panel) for private listening without disturbing others.
Before putting on the headphones reduce the VOLUME control to a low level, then
put the headphones on and gradually increase the VOLUME control to a comfortable
listening lev el. The built in speakers are automatically disconnected when
headphones are connected to the headphone jack.

MS7630_011504.p65 15/1/2004, 10:0619

19

COVER OPENING WITH TAPE

BREAK OUT TO PREVENT RECORDING

CARE AND MAINTENANCE

ABOUT CASSETTE TAPES

Whenever you record on a cassette any previously recorded material is erased as
the new material is recorded. To prevent you from accidentally erasing material
which you wish to save, blank cassettes are equipped with erase prevention tabs
for each s ide of the tape. If the erase prevention tab for side A is removed, you
cannot accidentally record on side A. The record key cannot be depressed if the
erase prevention tab on the cassette has been removed.

To prevent ac cidental erasing on side A of a cassette use a small screw driver or
similar tool to break off the erase prevention tab for side A. This prevents the
record key from locking.

A

TAB FOR SIDE A

If later you do wish to record on side A of the cassette, cover the tab opening with
a piece of cellophane tape. This will allow the record key to function again.

A

IN ORDER TO RECORD AGAIN.

20

MS7630_011504.p65 15/1/2004, 10:0620

CASSETTE CARE

Two common causes of trouble experienced when using cassettes are:

1.) Tape jamming — Leading to uneven speed in playback, and

2.) Tape tangling — Where the tape wraps itself around vital parts of themechanism.

To reduce the likelihood of these problems occurring, the following precautions

should be observed:

• Check that there are no loose layers of tape visible through the cassette center

window (see Fig. 1). Take up any loose layers, using a pencil or hexagonal

barrelled ballpoint pen, before inserting the cassette into the machine (see Fig. 2).

• If the cassette feels “tight” while performing operation shown (see Fig. 2), the tape

may be jamming due to “ridges” formed in the winding of the tape (visible through

the center window). These may be removed, in most cases, by fast winding of the

cassette from one end to the other and back again.

• Use only well-known brands of tape. Avoid use of C-120 cassettes.

Furthermore, do not expose cassettes to direct sunlight, dust or oil, and do not touch

the tape surfaces.

21

MS7630_011504.p65 15/1/2004, 11:3221

HEAD CLEANING

The tape heads, pinch roller and capstan require periodic cleaning. This removes
particles of the metal oxide coating that wear off the tape and accumulate on these
parts and impair performance. Turn off the power, press the / key to open the
cassette door, and press the Play key. Clean the tape heads, pinch roller and
capstan with a soft cloth or cotton pad dampened in isopropyl alcohol or special tape
head cleaner.

MS7630_011504.p65 15/1/2004, 10:0622

22

COMPACT DISC CARE

• To remove a disc from its storage case, press down on the center of the case

and lift the disc out, holding it carefully by the edges.

• Fingerprints and dust should be carefully wiped off the disc’s recorded surface

with a soft cloth.Unlike conventional records, compact discs have no grooves
to collect dust and microscopic debris, so gently wiping with a soft cloth should
remove most particles. Wipe in a straight line from the inside to the outside of
the disc. Small dust particles and light stains will have absolutely no effect on
reproduction quality.

• Clean the disc periodically with a soft, lint-free, dry cloth. Never use detergents

or abrasive cleaners to clean the disc. If necessary, use a CD cleaning kit.

• Never write on or affix labels to the surface of compact discs.

CARE OF THE CABI NET

If the cabinet becomes dusty wipe it with a soft dry dust cloth. Do not use any wax,
polish sprays, or abrasive cleaners on the cabinet.

CAUTION

Never allow any water or other liquids to get inside the unit while cleaning.

23

MS7630_011504.p65 15/1/2004, 10:0623

LIMITED WARRANTY

R

Emerson Radio Corp. warrants manufacturing defects in original material, including
original parts and workmanship, under normal use and conditions, for a period of
ninety (90) days from the date of original purchase in the U.S. With your dated
proof of purchase, we will provide repair service at no charge for labor and parts at
an authorized Depot Repair Facility, or replace the product in our discretion. For
repair or replacement, pack your unit in a padded box, enclose your check or
money order payable to Emerson Radio Corp. in the amount of $9.00 (not required
by California residents) to cover shipping and handling costs, and enclose a copy
of your proof of purchase. Send your unit to:

Emerson Radio Corp.
1901 Diplomat Drive.

Farmers Branch, TX 75234.

This warranty does not cover damage from negligence, misuse, abuse, accident,
failure to follow operating instructions, commercial use, rental, repairs by an
unauthorized facility, or products purchased, used, serviced or damaged outside
of the United States.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

AU898M

SERVICE

CALL TOLL FREE: 1-800-695-0098

FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE

FOR CUSTOMER SERVICE, PLEASE WRITE TO:

MS7630_011504.p65 15/1/2004, 10:0624

TO FIND THE LOCATION AND PHONE
NUMBER OF YOUR NEAREST SERVICE
CENTER PERMITTED TO PERFORM
WARRANTY...

PLEASE CALL:

1-800-898-9020

Emerson Radio Corp.

Consumer Affairs Dept.

1901 Diplomat Drive,

Farmers Branch, TX 75234.

24

EMERSON

R

Part No. : 16-2929

401-01

MS7630_011504.p65 15/1/2004, 10:0625

Printed in China
