COLOR TV/DVD

EWC20D5 A (20 inch)

OWNER’S MANUAL

If you need additional assistance for set-up or operating after

reading owner’s manual, please call TOLL FREE : 1-800-256-2487.

Or visit our WEB SITE at http://www.emersonaudiovideo.com

Please read before using this equipment

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

SUPPLIED ACCESSORIES

BatteriesRemote Control Unit

2 AA BatteriesNE221UD

Owner’s Manual

1EMN20223

Owner's Manual

“EMERSON AND THE G-CLEF LOGO ARE REGISTERED TRADEMARKS

OF EMERSON RADIO CORP., PARSIPPANY, NEW JERSEY, U.S.A.”

–2–

1.Read instructions-All the safety and operating instructions

should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions

should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the

operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions

should be followed.

5.Cleaning-Unplug unit from the wall outlet before cleaning.

Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Do not use attachments not recommended by

the unit manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this unit near water-for

example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Do not place this unit on an unstable cart,

stand, tripod, bracket, or table. The unit may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the unit. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

Accessoires- Ne placez pas cette unit sur une table roulante, un support, un trépied, une console ou une table instable. Cette unit risquerait de tomber, pouvant gravement blesser quelqu'un et l'appareil même pourrait être sérieusement endommagé. N'utilisez qu'une table roulante, un support, un trépied, une console ou une table recommandé par le fabriquant, ou vendu avec la unit. Pour n'importe quelle installation de l'appareil, on devra suivre les instructions du fabriquant et l'on devra utiliser les accessoires d'installation recommandés par le fabriquant. L'ensemble combiné de l'appareil avec une table roulante devra être déplacé avec précaution. Des arrêts brusques, une force excessive et des surfaces inégales peuvent provoquer le renversement de l'ensemble combiné de l'appareil/table roulante.

9. Ventilation-Slots and openings in the cabinet and the back

or bottom are provided for ventilation and to ensure reliable operation of the unit and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat register. This unit should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-This unit should be operated only from the

type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For units intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization-This unit is equipped with a

polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

WARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLI-

ANCE TO RAIN OR MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

The caution marking is located on the rear of the cabinet.

IMPORTANT SAFEGUARDS

PORTABLE CART WARNING

AVERTISSEMENT POUR UNE

TABLE ROULANTE PORTATIVE

S3126A

–3–

EXAMPLE OF ANTENNA GROUNDING AS PER

12.Power-Cord Protection-Power-supply cords should be

routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13.Outdoor Antenna grounding-If an outside antenna or

cable system is connected to the unit, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-For added protection for this unit receiver dur-

ing a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power-line surges.

15.Power Lines-An outside antenna system should not be

located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Do not overload wall outlets and extension

cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind

into this unit through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the unit.

18.Servicing-Do not attempt to service this unit yourself as

opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this unit from the wall

outlet and refer servicing to qualified service personnel

under the following conditions: a. When the power-supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the

unit. c. If the unit has been exposed to rain or water. d. If the unit does not operate normally by following the oper-

ating instructions. Adjust only those controls that are cov-

ered by the operating instructions, as improper adjustment

of other controls may result in damage and will often

require extensive work by a qualified technician to restore

the unit to its normal operation. e. If the unit has been dropped or damaged in any way. f. When the unit exhibits a distinct change in performance-

this indicates a need for service.

20.Replacement Parts-When replacement parts are required,

be sure the service technician has used replacement parts

specified by the manufacturer that have the same character-

istics as the original part. Unauthorized substitutions may

result in fire, electric shock, injury to persons or other haz-

ards.

21.Safety Check-Upon completion of any service or repairs to

this unit, ask the service technician to perform routine safe-

ty checks to determine that the unit is in proper operating

condition.

22.Heat-This unit product should be situated away from heat

sources such as radiators, heat registers, stoves, or other

products (including amplifiers) that produce heat.

NATIONAL ELECTRICAL CODE

S2898A

FIGURE A

ELECTRIC SERVICE EQUIPMENT

NEC - NATIONAL ELE CTRICAL CODE

GROUND

CLAMP

ANTENNA

LEAD I N WIRE

ANTENNA

DISCHARGE UNI T (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDI NG ELECTRODE SYSTEM (NEC ART 250, PART H)

–4–

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

PRECAUTIONS

The serial number of this product may be found on the back of the unit. No other unit has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase Dealer Purchase from Dealer Address Dealer Phone No. Model No. Serial No.

A NOTE ABOUT RECYCLING

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

–5–

AV OID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

LOCATION

For safe operation and satisfactory performance of your unit, keep the following in mind when selecting a place for its installation:

•

Shield it from direct sunlight and keep it away from sources of intense heat.

•

Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

•

Install unit in a horizontal position.

•

Avoid locations subject to strong vibration.

•

Do not place the unit near strong magnetic fields.

•

Avoid moving unit to locations where temperature differences are extreme.

•

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.

•

If by accident, water is spilled on your unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.

•

Do not put your fingers or objects into the unit disc loading tray.

•

Do not place anything directly on top of the unit.

WARNING

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place or after heating a cold room or under conditions of high humidity. If a DVD is played in a unit which has moisture, it may damage the DVD and unit. Therefore when the condensation occurs inside the unit, turn POWER on and allow at least 2 hours for the unit to dry out.

The following symbols below appear in some headings and notes in this manual, with the following meanings

: Description refers to TV operation (in the TV mode).

: Description refers to playback of DVD-Video discs

(in the DVD mode).

: Description refers to playback of Audio CDs

(in the DVD mode).

: Description refers to the items to be set by the

QUICK mode (in the DVD mode).

QUICK

DVD-V

SYMBOLS USED IN THIS MANUAL

–6–

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . . . . . . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF ELECTRICAL

SHOCK AND FIRE . . . . . . . . . . . . . . . . . . . . . .5

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

SYMBOLS USED IN THIS MANUAL . . . . . . .5

C TABLE OF CONTENTS . . . . . . . . . . . . . . . . . .6

C FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

OPERATING CONTROLS AND FUNCTIONS

. . .8

INSTALLING THE BATTERIES . . . . . . . . . . .9

C PREPARATION FOR USE . . . . . . . . . . . . . . .10

ANTENNA/CABLE CONNECTIONS . . . . . . .10

CONNECTING TO EXTERNAL INPUT JACKS .11 CONNECTING TO AN AMPLIFIER

EQUIPPED WITH DIGITAL INPUT JACKS, MD DECK OR DAT DECK (for DVD only) . .11

CONNECTING TO A DOLBY DIGITAL

DECODER (for DVD) . . . . . . . . . . . . . . . . . . .12

TV SECTION

C SET UP FOR USE . . . . . . . . . . . . . . . . . . . . .13

SELECTING THE LANGUAGE . . . . . . . . . . .13

CHANNEL SET UP . . . . . . . . . . . . . . . . . . . . .13

DELETING (OR ADDING) CHANNEL(S) . . .14

C TV OPERATION . . . . . . . . . . . . . . . . . . . . . . .15

WATCHING A TV PROGRAM . . . . . . . . . . . .15

DEGAUSSING . . . . . . . . . . . . . . . . . . . . . . . .15

PICTURE CONTROL . . . . . . . . . . . . . . . . . . .15

SLEEP TIMER . . . . . . . . . . . . . . . . . . . . . . . . .16

CLOSED CAPTION SYSTEM . . . . . . . . . . . .16

V-CHIP SET UP . . . . . . . . . . . . . . . . . . . . . . . .17

TV RATING SET UP . . . . . . . . . . . . . . . . . .17

MPAA RATING SET UP . . . . . . . . . . . . . . .18

CHANGE ACCESS CODE . . . . . . . . . . . . . .17

DVD SECTION

C ABOUT THE DISCS . . . . . . . . . . . . . . . . . . . .19

PLAYABLE DISCS . . . . . . . . . . . . . . . . . . . . .19

UNPLAYABLE DISCS . . . . . . . . . . . . . . . . . .19

C PLAYING A DISC . . . . . . . . . . . . . . . . . . . . . .20

BASIC PLAYBACK . . . . . . . . . . . . . . . . . . . .20

GENERAL FEATURES . . . . . . . . . . . . . . . . . .20

DISC MENU . . . . . . . . . . . . . . . . . . . . . . . . . .20

TITLE MENU . . . . . . . . . . . . . . . . . . . . . . . . .20

RESUME . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

PAUSE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

STEP BY STEP PLAYBACK . . . . . . . . . . . . .21

FAST FORWARD / FAST REVERSE . . . . . . .21

SLOW FORWARD / SLOW REVERSE . . . . .21

C SEARCH FUNCTION . . . . . . . . . . . . . . . . . .22

TRACK SEARCH . . . . . . . . . . . . . . . . . . . . . .22

TITLE / CHAPTER SEARCH . . . . . . . . . . . . .22

TIME SEARCH . . . . . . . . . . . . . . . . . . . . . . . .22

MARKER SETUP SCREEN . . . . . . . . . . . . . .22

C SPECIAL PLAYBACK FUNCTION . . . . . . . .23

REPEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

PROGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . .23

RANDOM PLAYBACK . . . . . . . . . . . . . . . . .23

C CHANGING THE SETTINGS . . . . . . . . . . . .24

SUBTITLE LANGUAGE . . . . . . . . . . . . . . . .24

AUDIO LANGUAGE . . . . . . . . . . . . . . . . . . .24

STEREO SOUND MODE . . . . . . . . . . . . . . . .24

CAMERA ANGLE . . . . . . . . . . . . . . . . . . . . . .25

BLACK LEVEL SETTING . . . . . . . . . . . . . . .25

VIRTUAL SURROUND . . . . . . . . . . . . . . . . .25

C THE ON-SCREEN INFORMATION . . . . . . .26

C CHANGING THE DVD SETUP ITEMS . . . .27

CUSTOM MENU . . . . . . . . . . . . . . . . . . . . . .27

LANGUAGE SETTING . . . . . . . . . . . . . . . .27

DISPLAY SETTING . . . . . . . . . . . . . . . . . . .28

AUDIO SETTINGS . . . . . . . . . . . . . . . . . . .28

PARENTAL CONTROL . . . . . . . . . . . . . . . .29

INITIALIZE . . . . . . . . . . . . . . . . . . . . . . . . . . .29

C TROUBLESHOOTING GUIDE . . . . . . . . . . .30

C MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . .32

DISC HANDLING . . . . . . . . . . . . . . . . . . . . . .32

C SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . .33

C ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

C WARRANTY . . . . . . . . . . . . . . . . . . .Back Cover

–7–

TV Mode

DVD Mode

¡Dolby Digital sound

This unit can handle Dolby Digital surround sound having 5.1 channels when connected to a Dolby Digital decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.

¡Random playback for Audio CD

This unit can shuffle the order of tracks to play them in random order.

¡Program playback for Audio CD

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input from the unit for 5 minutes in the stop mode. When the screen saver program is activated for 15 minutes, the power is automatically turned off.

¡Subtitles in a desired language

You can select a desired language for the display subtitles, if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on a disc.

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡Automatic detection of discs

This unit automatically detects if the loaded disc is DVD, Audio CD on disc.

¡On-screen display

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.

¡Search

Chapter search / Title search / Track search / Time search

¡Repeat

Chapter / Title / Track / All / A-B

¡Marker

The part designated by user can be called back.

¡Resume Play

User can resume to playback from the part at which the play was stopped.

¡Virtual Surround ¡Bit rate indication ¡DRC (Dynamic range control)

You can control the range of sound volume.

•

181 channel capability PLL frequency synthesizer tuner with direct station call

(A converter may be necessary to view scrambled cable channels.)

•

Infrared remote control

•

Trilingual on screen menu display selectable in English, Spanish or French

¡Sleep Timer

The Sleep Timer function enables you to shut off the power without hitting

[POWER] after a desired time period.

¡Closed Caption Decoder

You may view specially labeled (cc) TV programs, movies, news, etc. with either a dialogue caption or text display added to the program.

¡Auto Shut Off Function

If there is no air signal input from the antenna terminal and no operation for 15 minutes, the unit will turn itself off automatically.

¡V-CHIP

Enables parents to prevent their children from watching inappropriate material on TV.

FEATURES

–8–

7. Remote Sensor Window

8. STOP C Button [page 21]

Stops operation of the disc.

9.SKIP H Button [page 22]

Plays back from the beginning of the current chapter or track.

SEARCH h Button (Front Panel) [page 21]

During playback or in the pause mode, press and hold button down

for a few seconds to change

reverse playback speed.

10. PLAY OOButton [page 20]

Starts playback of the disc contents. Hit to change to DVD mode when TV mode.

11. SKIP G Button [page 22]

Plays back from the beginning of the next chapter or track.

SEARCH g Button (Front Panel) [page 21]

During playback or in the pause mode, press and hold button down

for a few seconds to change for-

ward playback speed.

12. PAUSE F Button [page 21]

Pauses the current disc operation.

13. OPEN/CLOSE AAButton [page 20]

Hit to insert a disc into or remove it from the tray.

14. HEADPHONE Jack

To connect headphone (not supplied) for personal listening.

15. MODE Button [pages 23-24]

Activates program playback or random playback mode when playing CDs.

16. Number Buttons TV Mode:

[page 14]

Hit two digits to directly access the desired channel. Remember to hit

[0] before a single digit channel.

+100 Button

Hit to select cable channels which are higher than 99.

DVD Mode: [page 22]

Hit to enter the desired number.

+10 Button

Hit to enter the desired numbers which are higher than 9.

VIDEO

L–AUDIO–R

POWER

VOLUME CHANNEL STOP SKIP SKIPPLAY PAUSE CLOSE

OPEN/

HEADPHONE

– SEARCH –

7428910111213 146531

12 23

22 15

13 34

19 18

REV

SLOW

PLAY

STOP

FWD

ENTER

PAUSE

DISC

RETURNTITLESETUP

REPEATSEARCH MODE

CLEAR

MODE

ANGLESUBTITLEAUDIO

DISPLAY

SKIP

SELECT

POWER PICTURE

OPEN/ CLOSE

CH.

VOL.

MUTEV.SURR

SLEEP

123

456

789

0 +10

+100

OPERATING CONTROLS AND FUNCTIONS

FRONT PANEL

REMOTE CONTROL

[Fig. 2]

[Fig. 1]

1. Disc loading tray

2. VIDEO input Jack [page 11]

Connect to the video output jack of a video camera or VCR.

3. AUDIO L/R input Jacks [page 11]

Connect to the audio output jacks of a video camera or VCR.

4. POWER Button [page 13]

Hit to turn the power on and off.

5. VOLUME K/L (VOL.mm/nn) Buttons [page 15]

Press to control the volume level for the DVD and TV.

6. CHANNEL K/L (CH. K/L) Buttons [page 15]

Press to select memorized channel. Press to change to TV mode when DVD mode.

–9–

COAXIAL

ANT.

3938

32. K / L / { / B Buttons

TV Mode:

[page 13]

Hit to select a setting mode from the menu on the TV screen. Hit to select or adjust from a particular menu.

DVD Mode: [page 20]

Press to select a menu item.

33. DISC MENU Button [page 20]

Displays the menus in the DVD.

34. SELECT Button [page 20]

Hit to change to TV mode, external input mode or DVD mode.

35. MUTE Button [page 15]

Hit to turn off the sound portion of the TV program. (Volume level display turns LIGHT RED from LIGHT BLUE.) Hit it again or hit

[VOL.

mm /nn

] to

restore sound.

36. PICTURE Button [page 15]

Hit to enter picture adjustment mode.

37. Power cord

Connect to a standard AC outlet (120V/60Hz). NOTE: Remove the power cord from the hook to

avoid breaking a wire before you connect to a standard AC outlet.

38. COAXIAL digital audio out Jack (DVD Audio Only)

[pages 11, 12]

Connect to the digital input of an external amplifier or decoder.

39. ANT(ENNA). Jack

Connect to an antenna, cable system or satellite system.

NOTE: When you select the DVD mode by this

button, press

[PLAYOO] or [OPEN/CLOSE A]

first. Otherwise, the DVD features are not operated.

17. SLEEP Button [page 16]

Hit to display the sleep timer and start the function. The shut off time can be determined by the number of times you hit this button. (0, 30, 60, 90 or 120 minutes)

18. REV h Button [page 21]

Hit to fast reverse the Disc. Hit [PAUSE F], then hit this button to begin slow motion playback. Hit this button repeatedly to change the reverse speed of slow motion.

FWD g Button [page 21]

Hit to fast forward the Disc. Hit [PAUSE F], then hit this button to begin slow motion playback. Hit this button repeatedly to change the forward speed of slow motion.

19. V.SURR (VIRTUAL SURROUND) Button

[page 25]

Hit to set virtual surround on/off.

20. SETUP Button [pages 13, 27-29]

Hit to enter or exit the setup menu of TV or DVD.

21. TITLE Button [page 20]

Displays the title menu.

22. CLEAR Button [pages 22-23]

Resets a setting.

23. DISPLAY Button TV Mode:

Hit to display the channel number on the screen. If you hit it again, the channel number will disappear.

DVD Mode: [page 26]

Displays the current status on the TV screen.

24. SEARCH MODE Button [page 22]

Hit to locate a desired point.

25. AUDIO Button [page 24]

Hit to select a desired audio language or sound mode.

26. SUBTITLE Button [page 24]

Hit to select a desired subtitle language.

27. REPEAT Button [page 23]

Repeats playback of the current disc, title, chapter or track.

28. ANGLE Button [page 25]

Hit to change the camera angle to see the sequence being played back from a different angle (if available).

29. REPEAT A-B Button [page 23]

Repeats playback of a selected section.

30. RETURN Button [page 22]

Returns to the previous screen in the setup menu.

31. ENTER Button [pages 13, 20]

Hit to accept a setting.

REAR VIEW

[Fig. 3]

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.

3)Replace the cover.

NOTES:

¡Do not mix alkaline and manganese batteries. ¡Do not mix old and new batteries.

–10–

NOTE:

Before plugging the antenna into the ANT. jack of the unit, check that the pin is not bent. If it is bent, straighten the pin as illustrated, then plug the pin into the ANT. jack of the unit.

PREPARATION FOR USE

ANTENNA/CABLE CONNECTIONS

CABLE WITH CONVERTER/DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown here.

Channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the TV/ DVD Remote Control.

TO VIEW A SCRAMBLED/UNSCRAMBLED CHANNEL

1.Set the unit channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to view on your Cable Converter

Box or Satellite Box.

Bent pin

Cable

Plug

(Needs to be straightened)

(Straight pin)

VHF/UHF Antenna (Not supplied)

VHF/UHF Combiner (Not supplied)

Flat twin-lead cable

UHF Antenna (Not supplied)

VHF Antenna (Not supplied)

From Cable System

75-ohm Coaxial Cable (Not supplied)

Satellite Box or Cable Box (Not supplied)

From Cable System or Satellite Dish

[Fig. 4]

VHF/UHF COMBINED ANTENNA

A VHF UHF 75 ohm combination antenna can be connected to ANT. jack.

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

CABLE WITHOUT CONVERTER/ DESCRAMBLER BOX

Use this connection if your cable system connects directly to your unit without a converter box. Use the TV/ DVD Remote Control to select channels.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

NOTE:

•

For your safety and to avoid damages to the unit, unplug the antenna cable from the ANT. jack before moving the unit.

OUT

COAXIAL

ANT.

–11–

CONNECTING TO EXTERNAL INPUT JACKS

When you watch a program recorded on another source (VCR or video camera), use the audio/video input jacks on the front of the unit.

Connect the audio/video output jacks of another source to the AUDIO L/R and VIDEO jacks of this unit.

Then hit [SELECT] until

"AUX" appears on the screen. NOTE:

•

When you connect a monaural VCR (another source) to this unit, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this unit. The audio will output in both L and R channel equally.

[Another source]

To the audio output jacks

Audio/Video cables (not supplied)

etc.

To the video output jack

[Front of the unit]

AUX

[Fig. 5]

CONNECTING TO AN AMPLIFIER EQUIPPED WITH DIGITAL

INPUT JACKS, MD DECK OR DAT DECK (for DVD only)

Use an audio coaxial digital cable available at retail for the audio connections.

NOTES:

•

The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital sound by an MD or DAT deck.

•

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for the components to be connected to the unit.

•

Set DOLBY DIGITAL to OFF for audio output in the setup mode. Playing a unit using incorrect settings may generate noise distortion and may also damage the speakers. (See page 28 to set DOLBY DIGITAL to OFF.)

COAXIAL

ANT.

Amplifier equipped with digital

input jacks, MD deck,

DAT deck, etc.

To COAXIAL DIGITAL AUDIO INPUT jack

To DIGITAL AUDIO OUT (PCM/BITSTREAM) COAXIAL jack (Only DVD AUDIO OUT)

[Fig. 6]

VIDEO L–AUDIO–R

–12–

CONNECTING TO A DOLBY DIGITAL DECODER (for DVD)

If using this unit to play a DVD disc in a 5.1 channel Dolby Digital surround format, the unit outputs a DOLBY DIGITAL Data stream from its COAXIAL digital audio out jack. By hooking the unit up to a Dolby Digital decoder, you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound as enjoyed in movie theaters.

Use audio coaxial digital cables available at retail for the audio connections.

NOTES:

•

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for the components to be connected to the unit.

•

If connected to a Dolby Digital decoder, set DOLBY DIGITAL to ON for audio output in the setup mode. (See page 28 to set DOLBY DIGITAL to ON.)

•

Unless connected to a Dolby Digital decoder, set DOLBY DIGITAL to OFF for audio output in the setup mode. Playing a unit using incorrect settings may generate noise distortion and may also damage the speakers.

COAXIAL

ANT.

Front speaker

(left)

Center

speaker

Front speaker

(right)

Surround

speaker

(left)

Surround

speaker

(right)

Subwoofer

To DIGITAL AUDIO OUT (PCM/BITSTREAM) COAXIAL jack (Only DVD AUDIO OUT)

To COAXIAL DIGITAL AUDIO INPUT jack

Dolby Digital decoder

[Fig. 7]

Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

–13–

SELECTING THE LANGUAGE

1 Plug in the unit power cord

Plug the unit power cord into a standard AC outlet.

NOTE:

•

If any digits appear in the corner of the screen, hit [POWER] without unplugging the power cord.

Make sure ...

•

Hit [POWER] to turn on the unit.

NOTE:

•

This function effects only the language on the screen menu and not the audio source.

2 Select “LANGUAGE”

Hit [SETUP] on the remote control. Press

[KK/LL] to point to “LAN-

GUAGE”.

3 Select “ENGLISH”, “ESPAÑOL” or “FRANÇAIS”

Select “ENGLISH”, “ESPAÑOL”= Spanish or “FRANÇAIS”= French using [ENTER].

4 Exit the Language mode

Hit [SETUP] to return to TV mode. NOTE: If for some reason the menu is in Spanish or

French, press [KK/LL] to point to “IDIOMA [ESPAÑOL]” or “LANGAGE [FRANÇAIS]”, then hit [ENTER], then hit [SETUP] on the remote control.

CHANNEL SET UP

You can program the tuner to scan all the channels you receive in your area.

NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just select the unit channel selector to the output channel of the cable box or satellite box (Ex CH3), then select the channel to be viewed on the Cable Box or Satellite Box.

Make sure ...

•

Hit [POWER] to turn on the unit.

1 Select “CHANNEL SET UP”

Hit [SETUP] on the remote control. Press

[KK/LL] to point to “CHAN-

NEL SET UP”. Then hit

[ENTER].

2 Begin auto ch programming

Press [KK/LL] to point to “AUTO CH PROGRAMMING”.

Then hit

[ENTER].

The tuner scans and memorizes all the active channels in your area.

3 After scanning

The tuner stops on the lowest memorized channel.

•

When AUTO CH PROGRAMMING is activated where there is no TV signal input, “NO TV SIGNALS” will appear on the display after the completion of the channel scanning.

•

The unit may recognize CATV channels to be TV channels by the receiving conditions. In this case, try auto ch programming again in the fine receiving conditions.

SET UP FOR USE

TV SECTION

- TV SETUP -

CHANNEL SET UP V-CHIP SET UP

B LANGUAGE [ENGLISH]

CAPTION [OFF]

- TV SETUP -

B CHANNEL SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF]

– CHANNEL SET UP –

ADD / DELETE CH (CATV)

B AUTO CH PROGRAMMING

NO TV SIGNALS

–14–

DELETING (OR ADDING)

CHANNEL(S)

The channels you no longer receive or seldom watch can be deleted from the memory. (Of course, you can add the deleted channel into the memory again.)

1 Select “CHANNEL SET UP”

Hit [SETUP] on the remote control. Press

[

KK /LL

] to point to “CHAN-

NEL SET UP”. Then hit

[ENTER].

2 Select “ADD/DELETE CH”

Press [

KK /LL

] to point to

“ADD/DELETE CH”. Hit

[ENTER].

3 Enter the desired channel number

Press [

KK /LL

] until your desired

channel number appears. (You can also press the number buttons or

[CH.

KK /LL

] to enter it)

(Example: CH8)

•

You must precede single-digit channel numbers with a zero (Example: 02 ... 09).

•

When selecting cable channels which are higher than 99, hit +100 first, then hit the last two digits. (Example: to select channel 125, first hit +100, then press 2 and 5).

4 Delete (or add) it from (or into) memory

Hit [ENTER]. The channel number changes to light red. The channel is deleted from memory.

•

To delete another channel, repeat steps [3] to [4].

•

If you hit [ENTER] again, the channel is memorized again.

5 Exit the channel setup mode

Hit [SETUP] to return to TV mode. NOTE: To confirm that channel(s) has been deleted

or added, press [CH.

KK /LL

- TV SETUP -

B CHANNEL SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF]

Added channel: Light blue Deleted channel: Light red

ADD / DELETE

– CHANNEL SET UP –

B ADD / DELETE CH (CATV)

AUTO CH PROGRAMMING

–15–

DEGAUSSING

Magnetism from nearby appliances and speakers might affect the color of the TV picture.

If this happens, move this unit away from the appliance. If the color is still not correct, disconnect

power

cord from AC outlet then reconnect it after

30 minutes.

WATCHING A TV PROGRAM

1 Turn on the unit

Hit [POWER] to turn on the unit.

2 Select the channel number

Press [CH. KK/LL] to select your desired channel number or press the number buttons.

Notes for using the number buttons on the remote control:

•

You must precede single-digit channel numbers with a zero (Example: 02 ... 09).

•

When selecting cable channels which are higher than 99, hit +100 first, then press the last two digits. (Example: to select channel 125, first hit +100, then press 2 and 5).

Remember:

¡If the unit is connected to a cable box or satellite

box, the unit must be on CH3 or CH4, then the channel to be viewed must be selected on the cable box or satellite box.

3 Adjust sound

Press [VOL. XX/YY] to adjust the volume.

NOTE:

•

If you press [CH. KK/LL] in the DVD mode, you can change the TV channels.

Even if you turn off the unit in the DVD mode, when you turn it on again, it will go into the TV mode.

BRIGHT to decrease to increase

brightness brightness

CONTRAST to decrease to increase

contrast contrast

COLOR to pale to brilliant TINT to purple to green

SHARPNESS to soft to clear

PICTURE CONTROL

The unit’s picture controls – BRIGHT, CONTRAST, COLOR, TINT and SHARPNESS – are

preset to factory specifications. Although they are usually the best, you may need to make some further adjustments for a more natural looking image.

Make sure ...

•

unit power must be turned on.

1 Select “PICTURE CONTROL”

Hit [PICTURE] on the remote control.

2 Select item you want to adjust

Press [KK/LL] until desired control is displayed.

BRIGHT CONTRAST COLOR TINT SHARPNESS

3 Adjust the picture control

Press [ss/ BB] to adjust to your desired level within 5 seconds.

NOTE:

•

At step 3, the picture adjustment display will disappear from the TV screen after about 5 seconds unless you press any buttons, even though you may not be finished. In this case, repeat from step 1.

•

If there is a power failure of any kind, the unit will retain its memory for this feature.

VOLUME 20

C C C C C C C C C C C C C C C C

BRIGHT

–

PP PP PPPP PP PP PP CC PP PP PP PP PP PP PP

TV OPERATION

–16–

CLOSED CAPTION SYSTEM

You can view specially labeled (cc) TV programs, movies, news, etc. with either a dialogue caption or text display.

CAPTION mode: By choosing the caption mode, you

can watch dramas, movies and news while captioning the dialogues and the contents of news.

TEXT mode: By choosing the text mode, you can

watch half screen text information if you want.

1-2: You may get these captions or text information

by selecting either “1” or “2”. Caption “2” is used, usually for a second language if available.

NOTE:

Not all programs are broadcast with closed captions. Your television is designed to provide error free closed captions from high quality antenna, cable and VCR signals. Conversely, poor quality signals are likely to result in caption errors or no captions at all. Common signal conditions which may cause captions errors are listed below:

•

Automobile ignition noise

•

Electric motor brush noise

•

Weak snowy reception on TV screen

•

Multiplex signal reception displaying picture ghosts or airplane flutter.

NOTE:

If the unit displays a black box on the TV screen, this means that the unit is set to the TEXT mode. To clear screen, select [CAPTION1], [CAPTION2] or [OFF].

Make sure ...

•

unit power must be turned on.

1 Select “CAPTION”

Hit [SETUP] on the remote control. Press

[

KK / LL

] to point to “CAP-

TION”.

2 Select your desired caption menu

Hit [ENTER] until your desired caption menu appears.

([CAPTION1], [CAPTION2], [TEXT1] or [TEXT2])

3 Exit the caption setting mode

Hit [SETUP] to return to TV mode. NOTE:

•

Even if there is a power failure of any kind, the unit will retain its memory for this feature.

TO CANCEL THE CLOSED CAPTION SYSTEM

Repeat steps 1to 2, select [OFF] using ENTER. Hit [SETUP] on the remote control to return to TV mode.

- TV SETUP -

CHANNEL SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [OFF]

- TV SETUP -

CHANNEL SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [CAPTION1]

he Sleep Timer function enables you to shut off the power

without hitting [POWER] after a desired time period.

1 Set “SLEEP TIMER”

Hit [SLEEP] on the remote control. You may change the sleep time with hitting [SLEEP] repeatedly. The timer is set up to 120 minutes, 30 minutes each time SLEEP is pressed.

NOTES:

•

When you disconnect the unit from the AC outlet, or if you have a power failure, the sleep time will be lost.

•

To view the time left for sleep timer, hit [SLEEP] once when SLEEP display disappears. After 10 seconds, display will disappear again.

To cancel the sleep timer:

Hit [SLEEP] repeatedly until “SLEEP 0 MINUTE” is displayed.

SLEEP 120 MINUTE

SLEEP TIMER

–17–

V-CHIP enables parents to prevent their children from watching inappropriate material on TV.

V-CHIP reads the ratings for programming (except for news and sports programs, unedited movies on premium cable channels and Emergency Broadcast System signals), then denies access to programming if the program’s rating meets the limitations you select. In this case, “PROTECTED PROGRAM by ...” message appears on the TV screen.

To block ratings, follow the steps below.

•

Programming may be rated by the Motion Picture Association of America (MPAA) or according to the Television Parental Guidelines. In order to block any inappropriate programming, set your limits in both places (MPAA RATING and TV RATING).

V-CHIP SET UP

Make sure ...

•

The unit must be turned on.

1 Select “V-CHIP SET UP”

Hit [SETUP]. Press

[K / L] to select “V-CHIP

SET UP”, then hit [ENTER].

2 Enter Access code

Press the Number buttons to enter the access code.

•

For the first time set-up or in the event the unit has lost power, enter the default code of 0000.

3 Select the desired item

Press [K / L] to select “TV RATING”, “MPAA RATING” or “CHANGE CODE”, then hit [ENTER].

Refer to the pages below to set up each item.

TV RATING SET UP

Follow steps 1to 3in the “V-CHIP SET UP” section above.

4 Blocking TV programs

Press [K / L] to select a rating that you wish to block.

Hit

[ENTER] repeatedly to set it

to [BLOCK] or [VIEW].

V-CHIP SET UP

Selection Rating Category Explanations

TV-Y Appropriate for all children TV-Y7 Appropriate for children seven and older TV-G General Audience TV-PG Parental Guidance suggested. TV-14 Unsuitable for children under 14

TV-MA Mature audience only

A B C

P17 Step

P18 Step

NOTE:

•

When you select a rating and set it to [BLOCK], the higher ratings will be blocked automatically. The lower ratings will be available for viewing.

•

When you set the lowest rating to [VIEW], all other ratings will automatically be available for viewing.

5 Setting “Sub-Ratings”

When you select the ratings of TVY7, TV-PG, TV-14 or TV-MA you will have the option of setting sub rating categories.

Press

[K / L] to select a rating with

sub-ratings you wish to block, then hit [ENTER] twice.

Press

[K / L] to select a sub-rating,

then hit [ENTER] to set it to [BLOCK] or [VIEW].

NOTE:

•

The blocked sub-ratings will appear next to the rating category in the “TV RATING” menu.

6 Exit the V-Chip setting mode

Hit [SETUP] to exit the menu. NOTE:

•

To change the rating, the TV must be turned to an unprotected program. If “PROTECTED PROGRAM by ...” appears on the screen, please change the channel to a station that is not protected.

TV–Y [VIEW] TV–Y7 ( ) [VIEW] TV–G [VIEW]

B TV–PG (DLSV ) [BLOCK]

TV–14 (DLSV ) [BLOCK] TV–MA ( LSV) [BLOCK]

TV–Y7 [BLOCK]

B FV [BLOCK]

TV–PG [BLOCK]

B D [BLOCK]

L [BLOCK] S [BLOCK] V [BLOCK]

Selection Rating Category Explanations

TV-Y7

FV Fantasy Violence

TV-PG, TV-14, TV-MA

D Suggestive Dialog

(TV-PG, TV-14 only) L Coarse Language S Sexual Situation

VViolence

TV–Y [VIEW]

B TV–Y7 ( ) [VIEW]

TV–G [VIEW] TV–PG ( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]

PROTECTED PROGRAM

by TV-Y

TV–Y [VIEW] TV–Y7 ( ) [VIEW]

B TV–G [BLOCK]

TV–PG (DLSV) [BLOCK] TV–14 (DLSV) [BLOCK] TV–MA( LSV) [BLOCK]

- TV SETUP -

CHANNEL SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF]

ACCESS CODE

_ _ _ _

– V-CHIP SET UP –

B TV RATING

MPAA RATING CHANGE CODE

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG ( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]

–18–

MPAA RATING SET UP

Follow steps 1to 3in the “V-CHIP SET UP” section on page 17.

4 Select your desired item

Press [K / L] to point to your desired item, then hit

[ENTER] to

select [BLOCK] or [VIEW].

•

When you select a rating and set it to [BLOCK], the higher ratings will be blocked automatically. The lower ratings will be available for viewing.

•

When you set the lowest rating to [VIEW], all other ratings will automatically be available for viewing.

5 Exit the V-Chip setting mode

Hit [SETUP] to exit the menu.

Selection Rating Category Explanations

G General Audience PG Parental Guidance suggested. PG-13 Unsuitable for children under 13 R Restricted; under 17 requires accompa-

nying parent or adult guardian

NC-17 No one under 17 admitted X Mature audience only

CHANGE ACCESS CODE

Follow steps 1to 3in the “V-CHIP SET UP” section on page 17.

4 Enter New code

Press the Number buttons to enter your desired access code in the “NEW CODE” space, then enter the same code in the “CONFIRM CODE” space. When completed, the menu will return to “V-CHIP SET UP”.

•

Make sure you enter exactly the same new code in the “CONFIRM CODE” space as one in the “NEW CODE” space. If they are different, the “NEW CODE” space is cleared for redoing.

5 Exit the V-Chip setting mode

Hit [SETUP] to exit the menu. NOTE:

•

Your personal access code will be erased and will return to the default (0000) when a power failure occurs or when you turn off the power using a wall switch. If you have forgotten the code, unplug the power cord for 10 seconds to restore the access code to 0000.

G [VIEW] PG [VIEW] PG–13 [VIEW]

B R [BLOCK]

NC–17 [BLOCK] X [BLOCK]

NEW CODE

_ _ _ _

CONFIRM CODE

_ _ _ _

–19–

DVD SECTION

ABOUT THE DISCS

If you cannot play back a disc which bears one of the marks above, check the following notes.

*1: This unit conforms to the NTSC color system. Discs recorded in other color systems such as PAL cannot

be played back.

*2:

Certain DVD-Video discs do not operate as described in this manual due to the intentions of the disc’s producers. *3: Scratched or stained discs may not be played back. *4: Some discs cannot be played back because of incompatible recording conditions, characteristics of the

recorder or special properties of discs. *5: You can play back discs which bear the marks above. If you use nonstandardized discs, this unit may not

play them back. Even if they are played back, the sound or video quality will be compromised. *6: You may play back the unfinalized DVD-R/RW disc recorded in the video format on our brand’s DVD

recorder. However, depending on the recording status of a disc, the disc may not be played back at all or

normally (the picture or sound may not be smooth, etc.). In this case, you need to finalize the disc with

the DVD recorder. Refer to the manual accompanying the DVD recorder. *7: Only the discs recorded in the video format and finalized can be played back.

Unfinalized discs cannot be played back. Depending on the recording status of a disc, the disc may not be

played back at all or normally (the picture or sound may not be smooth, etc.). *8: If there is too much recording space left on a disc (the used portion is less than 55mm across), it may not

play back properly. *9:

Do not glue paper or put stickers on to the disc. These may damage the disc and the unit may not read it correctly.

*10: The number inside the symbol refers to a region of the world and a disc encoded in a specific region for-

mat can only be played back on unit with the same region code.

This label indicates playback compatibility with DVD-RW discs recorded in VR mode (Video Recording Format)

NOTE:

• This player cannot play the DVD-RW that supports CPRM (Contents Protection for Recordable Media).

• This player cannot play the DVD-R discs recorded in VR mode (Video Recording Format).

DVD-Video

* 1,2,3,10

* 1,3,4,5,7,8,9

* 1,3,4,5,6

8,9

* 3,5

* 3,4,5,8,9

DVD-RW

DVD-R

DVD+RW

DVD+R

Audio CD

CD-RW

CD-R

Digital video

(MPEG2)

Digital audio

Region code

Mark (logo)

Playable

discs

Recorded

signals

Disc size

Disc types

12 cm

8cm

12 cm

8cm

Example

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1

Chapter 2

Chapter 3 Chapter 4

Example

Tra c k 1

Tra c k 2

Tra c k 5

Tra c k 6

Tra c k 3

Tra c k 4

Audio CD

NEVER play back the following discs. Otherwise, malfunction may result!

DVD-RAM / CD-I / Photo CD / Video CD / DVD with region codes other than 1 or ALL / DTS-CD / DVD-ROM for personal computers / CD-ROM for personal computers / MP3

On the following disc, the sound MAY NOT be heard.

Super Audio CD NOTE: Only the sound recorded on the normal CD layer can be delivered.

The sound recorded on the high density Super Audio CD layer cannot be delivered.

Any other discs without compatibility indications

PLAYABLE DISCS

UNPLAYABLE DISCS

is a trademark of DVD Format/Logo Licensing Corporation.

–20–

BASIC PLAYBACK

Getting started

¡Turn on the power of amplifier and any other com-

ponents, if necessary.

1 Hit [POWER].

¡The power will turn on.

2 Hit [OPEN/CLOSE A] to open disc loading

tray.

3 Place the chosen disc in the tray, with the

label facing up.

DVD-V

PLAYING A DISC

4 Hit [PLAY

¡The tray will close automatically and playback will

then start from the first chapter or track of the disc. If the playback does not start automatically, hit

[PLAY

¡When you playback a DVD which features a title

menu, it may appear on the screen. In this case, refer to “TITLE MENU”.

5 Hit [STOP] to stop playback.

NOTES:

¡When the DVD mode has been switched to the TV

mode, the DVD mode shuts down first and then the TV picture and sound appears in about 4 seconds. Similarly, when POWER is pressed to turn off in the DVD mode, this mode shuts down first and then the unit’s power is turned off.

¡A “prohibited icon” may appear at

the top-right on the TV screen during operation, warning that a prohibited operation has been encountered by the DVD or the disc.

¡With DVDs that use titles for playback program sig-

nals, playback may start from the second title or it may skip these titles.

¡During the playback of a two layered disc, pictures

may stop for a moment. This happens when the 1st layer switches to the 2nd layer. This is not a malfunction.

GENERAL FEATURES

DVD may contain menus to navigate the disc and access special features. Press appropriate the number buttons or [KK/LL/ss/BB]

to highlight your selection in the DVD

main menu and hit [ENTER] to confirm.

NOTES:

¡Select DVD mode by hitting [SELECT] on the

remote control. Then hit [PLAYOO] or [OPEN/CLOSE AA] before you operate the DVD

functions.

¡Unless stated, all operations described are based on

remote control use. Some operations can be carried out using the menu bar on the TV screen.

DVD-V

TITLE MENU

1 Hit [TITLE] on the remote control.

¡The title menu will appear.

2 If the feature is not available, symbol

may appear on the TV screen.

3 Press [K/L/s /B] to select an item and hit

[ENTER] to confirm selection.

DVD-V

DISC MENU

1 Hit [DISC MENU] on the remote control.

¡The DVD main menu will appear.

2 If the feature is not available, symbol

may appear on the TV screen.

3 If disc menu is available on the disc, audio

language, subtitle options, chapters for the title and other options will appear for selection.

4 Press [

KK/LL

ss /BB

] to select an item and hit

[ENTER] to confirm selection.

DVD-V

CALLING UP A MENU SCREEN DURING PLAYBACK

¡Hit [DISC MENU] to call up the DVD menu. ¡Hit [TITLE] to call up the title menu.

NOTE:

¡Contents of menus and corresponding menu opera-

tions may vary between discs. Refer to the manual accompanying the disc for details.

–21–

STEP BY STEP PLAYBACK

1 During playback, hit [PAUSE F].

¡Playback will pause and sound will be muted.

2 The disc goes forward by one frame each

time [PAUSE

F] is pressed.

3 To exit step by step playback, hit [PLAY

DVD-V

RESUME

1 During playback, hit [STOP C].

¡Resume message will appear on the TV screen.

2 Hit [PLAY

], playback will resume from the

point at which playback was stopped.

¡To cancel resume, hit [STOP C] twice. ¡If unit is turned off, resume function will be can-

celled.

DVD-V

PAUSE

1 During playback, hit [PAUSE F].

¡Playback will pause and sound will be muted.

2 To continue playback, hit [PLAY

DVD-V

1 During playback, press [FWD g] or

[REV

h ].

¡“ g 1” or “h 1” appears on the screen.

2 To select another speed, repeat step 2 until

your required speed appears on the screen.

¡For DVDs, fast forward/reverse search speed is dif-

ferent depending on the disc. Approximate speed is 1 (×2), 2 (×8), 3 (×50) and 4 (×100).

¡For Audio CDs, approximate speed is ×16. ¡When you press buttons on the front panel, press and

hold [SEARCH

hh/ gg

] for a few seconds.

3 To return to normal playback, hit [PLAY

DVD-V

FAST FORWARD /

FAST REVERSE

SLOW FORWARD /

SLOW REVERSE

1 During playback, hit [PAUSE F]. 2 Press [FWD g] or [REV h ].

¡“ 1” or “ 1” appears on the screen.

3 To select another speed, repeat step 2 until

your required speed appears on the screen.

¡Slow forward or reverse speed varies with the disc.

Approximate speed is 1 (1/16), 2 (1/8) and 3 (1/2).

¡When you press buttons on the front panel, press

and hold [SEARCH

hh/ gg

] for a few seconds.

4 To return to normal playback, hit [PLAY

DVD-V

–22–

TRACK SEARCH

There are three ways to begin playback on an Audio CD at a specific track.

Using the number buttons on the remote control

1 Press the number buttons to enter the

desired track number.

¡Playback will start at the selected track. ¡For single digit tracks (1-9), press a single number

(eg. track 3, hit [3]).

¡To play track 26, hit [+10], [2], [6].

Using SEARCH MODE

1 Hit [SEARCH MODE].

¡The Track search display appears.

2 Within 30 seconds, select a desired track

number using the number buttons.

¡For single digits hit [0] first, if the total track of the

disc is more than 10.

¡Playback will start at the selected track.

Using SKIP

H/ G

During playback, hit [SKIP G] to move the next track. Hit it repeatedly to skip subsequent tracks. Hit [SKIP H ] to go back to beginning of the current track. Hit it repeatedly to go to the previous tracks.

¡If [SKIP H / G ] is pressed while the playback is

paused, the playback will be paused again after skipping to the next track.

NOTE:

¡[SKIP H / G] are not operative when playback

is stopped.

TITLE / CHAPTER SEARCH

1 Hit [SEARCH MODE] once for the Chapter

search, twice for the Title search during playback.

2 Enter the desired chapter/title number using

the number buttons.

¡Playback will start at the selected chapter or title. ¡Hit [CLEAR] to erase the incorrect input. ¡For single digits hit [0] first, if the total chapter or

title of the disc is more than 10.

DVD-V

TIME SEARCH

1 During playback, hit [SEARCH MODE] three

times (CD: twice) to display the Time Search on the TV screen.

2 Within 30 seconds, enter a desired disc

time using the number buttons.

¡Playback will start at the specified time. ¡Hit [CLEAR] to erase the incorrect input. ¡When there is no need to enter a number, “0”

appears automatically. For example, “ 0 : 0 - :

- -

” appears in the Time Search display if the total time of the track or title is less than 10 minutes.

DVD-V

SEARCH FUNCTION

MARKER SETUP SCREEN

Use markers to memorize your favorite places on a disc.

1 Hit [SEARCH MODE] four times (CD: three

times) during playback.

¡The display screen and Markers will appear on the

TV screen.

2 Press [s / B] to select 1, 2, 3, 4, 5, 6, 7, 8, 9,

or 10 and ensure that “

- - - - :- - :- -

”

appears in the display.

3 When you reach the desired point, hit

[ENTER].

¡The title or track and elapsed playing time will

appear in the TV screen.

4 To return to the Marker later, hit [SEARCH

MODE] four times (CD: three times) during playback and [

ss/BB

] to choose the desired

marker, then hit [ENTER].

NOTES:

¡Opening the disc tray, turning off the power hitting

[SELECT], or selecting AC at step 2 and hitting [ENTER] will erase all Markers.

¡To clear a marker, press [

ss/BB

]

to select a cursor

on to the marker number to be cleared and hit [CLEAR].

¡Yo u can mark up to 10 points.

5 Press [SEARCH MODE] or [RETURN] to

exit.

DVD-V

_/2

–23–

REPEAT

REPEAT TITLE / CHAPTER

To activate the repeat function, hit [REPEAT] during playback.

¡The repeat mode changes as described below every

time you hit the button.

DVD-V

REPEAT is available only during playback.

CHAPTER TITLE OFF

(current chapter repeat) (current title repeat)

(repeat

off)

NOTES:

¡Repeat Title/Chapter is not available with some

scenes.

¡The REPEAT setting will be cleared when moving

to other title or chapter.

REPEAT TRACK

To activate the repeat function, hit [REPEAT] during playback.

¡The repeat mode changes as described below every

time you hit the button.

TRACK ALL OFF

(current track repeat) (entire disc repeat)

(repeat

off)

NOTES:

¡Repeat setting will be cleared when moving to other

track.

¡Repeat playback does not function during repeat A-

B playback.

REPEAT A-B

1 Hit [REPEAT A-B] at your chosen starting

point.

¡“ A-” appears briefly on the TV screen.

2 Hit [REPEAT A-B] again at your chosen end

point.

¡“ A-B” appears briefly on the TV screen, and the

repeat sequence begins.

3 To exit the sequence, hit [REPEAT A-B].

NOTES:

¡The repeat A-B section can only be set within the

current title (for DVDs) or current track (for Audio CDs).

¡Repeat A-B is not available with some scenes in DVD. ¡To cancel the A point which was set, hit [CLEAR]. ¡Repeat A-B playback does not function during title,

chapter, track or all repeat playback.

DVD-V

PROGRAM

You may determine the order in which tracks will play.

1 In stop mode, hit [MODE].

¡The PROGRAM screen will appear.

2 Press [▲ / ▼] to select a track, then hit

[ENTER].

¡Hit [CLEAR] to erase the

most recently entered program.

3 Repeat step 2 until you have selected all the

tracks you want to play in the program.

Hit [PLAYOO] to play the programmed tracks.

NOTES:

¡While the program is being played back, the STOP

works as follows.

¡Hit [STOP C] once and then [PLAY

] again,

playback will restart from the point where STOP was pressed. (Program continued)

¡Hit [STOP

] twice and then [PLAYOO] again,

playback will restart from the track in the usual way. (Program canceled)

¡Up to 99 programs can be entered. ¡To erase all tracks in the program at once, select

“ALL CLEAR” at the bottom of the list at step 2.

¡If you like to repeat the current track in the program,

hit [REPEAT] repeatedly until “ TRACK” appears during playback. If you like to repeat the entire program hit [REPEAT] repeatedly until “ ALL” appears during playback.

RANDOM PLAYBACK

This shuffles the playing order of tracks instead of playback in the sequence.

1 In stop mode, hit [MODE] twice.

¡RANDOM screen appears.

2 Hit [PLAY

] to start random playback.

NOTE:

¡If you like to repeat the current track in the random

selection, hit [REPEAT] repeatedly until “ TRACK” appears during playback. If you like to repeat the entire random selection hit [REPEAT] repeatedly until “ ALL” appears during playback.

SPECIAL PLAYBACK FUNCTION

RANDOM

CD-DA TOTAL 0:45:55

PLAY

RANDOM PROGRAM

- - no indication - -

TOTAL

–24–

AUDIO LANGUAGE

The unit allows you to select a language during DVD disc (if multi languages are available) playback.

1 Hit [AUDIO] during playback.

2 Hit [AUDIO] repeatedly to select your

desired language.

NOTE:

¡Hitting [AUDIO] may not work on some DVDs

with multiple audio languages (e.g. DVDs which allow audio language setting on the disc menu).

DVD-V

STEREO SOUND MODE

1 Hit [AUDIO] repeatedly during playback to

select between STEREO, L-CH or R-CH.

¡STEREO - both right and left

channels are active (stereo) L-CH - only left channel is active R-CH - only right channel is active

NOTE:

¡If the Virtual Surround setting is ON, the sound mode

will be fixed to STEREO, and can not be changed.

The unit allows you to select a language for subtitles during DVD disc (if available) playback.

1 Hit [SUBTITLE] during playback.

¡The subtitle language will be

displayed on the display bar at the top of the screen.

2 Hit [SUBTITLE] repeatedly to select your

desired subtitle language.

3 To turn off subtitles, hit [SUBTITLE] repeat-

edly until OFF appears.

NOTES:

¡Hitting [SUBTITLE] may not work on some DVDs

with multiple subtitle languages. In this case, set it on the disc menu. (Operation varies between discs. Refer to the manual of the disc.)

¡If the desired language is not shown after hitting

[SUBTITLE] several times, the disc does not have subtitles in that language.

¡When “NOT AVAILABLE”

appears on the TV screen, it means no subtitle is recorded on the scene.

¡If you choose a Language that has a 3 letter language

code, the code will be displayed every time you change the Subtitle language setting. If you choose any other languages, ‘---’ will be displayed instead. (Refer to page 27.)

DVD-V

SUBTITLE LANGUAGE

CHANGING THE SETTINGS

1.ENG/6

NOT AVAILABLE

1.ENG Dolby D 3/2.1ch 48k/ 3

STEREO

–25–

CAMERA ANGLE

Some DVD discs contain scenes which have been shot simultaneously from various angles. You can change the camera angle when the ( ) icon appears on the screen.

1 Hit [ANGLE] during playback.

¡If the “ANGLE ICON” set-

ting is “OFF” in the DISPLAY SETTING menu, the

() icon will not appear. (Refer to page 28.)

2 Hit [ANGLE] repeatedly to select your

desired angle.

¡The selected angle will be displayed on the display

bar at the top of the screen.

DVD-V

Adjust the Black Level Settings to make the black parts of the picture brighter.

1 Hit [MODE] during playback.

2 Hit [ENTER] to switch ON/OFF.

ON: Makes the dark parts brighter. OFF: Shows the original picture as recorded.

3 Press [MODE] twice or [RETURN] to exit.

NOTE:

¡The setting will be saved even if the unit is turned

off.

DVD-V

BLACK LEVEL SETTING

You can enjoy surround-sound effect over two speakers on this unit.

1 Press [V.SURR] once or [MODE] twice

(CD: once) during playback.

2 Hit [ENTER] to set it 1 (Natural effect) or 2

(Emphasized effect) or OFF.

3 Press [V.SURR] or [MODE] to exit.

You can also exit the menu by hitting [RETURN]. NOTE (for CD play only):

¡Virtual Surround will not be effective if the sound

mode is set to something other than STEREO.

DVD-V

VIRTUAL SURROUND

1 / 8

OFF

–26–

For DVD-Vs

1 Hit [DISPLAY] during playback to show cur-

rent Chapter.

¡The elapsed and remaining

playing time of the current chapter will be displayed.

Hit [DISPLAY] again to show current Title.

¡The elapsed and remaining

playing time of the current title will be displayed.

3 Hit [DISPLAY] again.

¡The bit rate and the current

repeat setting will be displayed.

¡If you are playing a dual layered disc, the layer num-

ber will also be displayed (L0: Layer 0 is playing. L1: Layer 1 is playing).

4 Hit [DISPLAY] again to exit.

THE ON-SCREEN INFORMATION

For Audio CDs

1 Hit [DISPLAY] during playback to show the

current Track.

¡The elapsed and remaining

playing time of the current track will be displayed.

2 Hit [DISPLAY] again to show current Total

Track.

¡The elapsed and remaining

playing time of the total track will be displayed.

3 Hit [DISPLAY] again to exit.

NOTE:

¡When you are playing a disc in PROGRAM or RAN-

DOM mode, “ PROGRAM (or RANDOM)” will be displayed at step 2.

You can check the information about the current disc by hitting [DISPLAY].

DVD-V

9/49 0:00:00 -0:03:30

1/3 0:00:00 - 1:23:45

TL1

4/12 0:03:21 - 0:02:15

4/12 0:13:45 - 0:45:40

PROGRAM

–27–

CHANGING THE DVD SETUP ITEMS

CUSTOM MENU

You can change the DVD player’s settings.

1 Hit [SETUP] twice in STOP mode so that the

DVD SETUP menu appears.

¡Hit [L] to select

“CUSTOM”then hit [ENTER].

NOTE:

¡If the menu does not appear, hit [PLAY

], [STOP

C]. Then slowly hit [SETUP] twice.

2 Select the desired item.

¡Press [K / L] to select the desired item then hit

[ENTER] to confirm.

Refer to the pages below to set up each item.

LANGUAGE SETTING

Follow steps 1to 2in the “CUSTOM MENU” section above.

3 Press [K / L] to select the desired item then

hit [ENTER].

AUDIO:

Sets the audio language.

SUBTITLE:

Sets the subtitle language.

DISC MENU:

Sets the language for DVD menu.

4 Press [K / L] to select a setting then hit

[ENTER].

¡If “OTHER” is selected on

the “AUDIO”, “SUBTITLE” or “DISC MENU” screen, press four-digit number to enter the code for the desired language. (Refer to the language code list.)

¡Only the languages supported

by the disc can be selected.

5 Hit [SETUP] to exit the menu.

NOTES:

¡Language Setting for Audio and Subtitle are not

valid for some discs due to default setting of the disc. In this case, set them by hitting [AUDIO] and [SUBTITLE]. (Refer to page 24.)

¡If you select a language that is not supported by the

disc, subtitle will automatically be set OFF, and first item of the audio languages will be automatically set.

DVD-V

If you choose a language that has a 3 letter language code, the code will be displayed every time you change the AUDIO or SUBTITLE language setting above. If you choose any other languages, ‘---’ will be displayed instead. (3 letter language code is written in bracket.)

Language Code

A-B

Abkhazian 4748 Afar 4747 Afrikaans 4752 Albanian 6563 Amharic 4759 Arabic 4764 Armenian 5471 Assamese 4765 Aymara 4771 Azerbaijani 4772 Bashkir 4847 Basque 5167 Bengali;Bangla 4860 Bhutani 5072 Bihari 4854 Bislama 4855 Breton 4864 Bulgarian 4853 Burmese 5971 Byelorussian 4851

C-E

Cambodian 5759 Catalan 4947 Chinese [CHI] 7254 Corsican 4961 Croatian 5464 Czech 4965 Danish [DAN] 5047 Dutch [DUT] 6058 English [ENG] 5160 Esperanto 5161 Estonian 5166

F-H

Faroese 5261 Fiji 5256 Finnish [FIN] 5255 French [FRE] 5264 Frisian 5271 Galician 5358 Georgian 5747 German [GER] 5051 Greek [GRE] 5158 Greenlandic 5758 Guarani 5360 Gujarati 5367 Hausa 5447 Hebrew 5569 Hindi 5455 Hungarian [HUN] 5467

I-K

Icelandic [ICE] 5565 Indonesian 5560 Interlingua 5547 Interlingue 5551 Inupiak 5557 Irish [IRI] 5347 Italian [ITA] 5566 Japanese [JPN] 5647 Javanese 5669 Kannada 5760 Kashmiri 5765 Kazakh 5757 Kinyarwanda 6469 Kirghiz 5771 Kirundi 6460 Korean [KOR] 5761 Kurdish 5767

Language Code

L-N

Laothian 5861 Latin 5847 Latvian;Lettish 5868 Lingala 5860 Lithuanian 5866 Macedonian 5957 Malagasy 5953 Malay 5965 Malayalam 5958 Maltese 5966 Maori 5955 Marathi 5964 Moldavian 5961 Mongolian 5960 Nauru 6047 Nepali 6051 Norwegian [NOR] 6061

O-R

Occitan 6149 Oriya 6164 Oromo(Afan) 6159 Panjabi 6247 Pashto;Pushto 6265 Persian 5247 Polish 6258 Por tuguese [POR] 6266 Quechua 6367 Rhaeto-Romance 6459 Romanian [RUM] 6461 Russian [RUS] 6467

Samoan 6559 Sangho 6553 Sanskrit 6547 Scots Gaelic 5350 Serbian 6564 Serbo-Croatian 6554 Sesotho 6566 Setswana 6660 Shona 6560 Sindhi 6550 Singhalese 6555 Siswat 6565 Slovak 6557 Slovenian 6558 Somali 6561 Spanish [SPA] 5165 Sundanese 6567 Swahili 6569 Swedish [SWE] 6568

Tagalog 6658 Tajik 6653 Tamil 6647 Tatar 6666 Telugu 6651 Thai 6654 Tibetan 4861 Tigrinya 6655 Tonga 6661 Tsonga 6665 Tu rkish [TUR] 6664 Tu rkmen 6657 Tw i 6669

U-Z

Ukrainian 6757 Urdu 6764 Uzbek 6772 Vietnamese 6855 Volapuk 6861 Welsh 4971 Wolof 6961 Xhosa 7054 Yiddish 5655 Yo r uba 7161 Zulu 7267

P27 Step

P28 Step

P29 Step

B C D

SETUP CUSTOM

LANGUAGE DISPLAY AUDIO PARENTAL

SETUP

QUICK CUSTOM INITIALIZE

SETUP LANGUAGE

AUDIO SUBTITLE DISC MENU

SETUP LANGUAGE

AUDIO

ORIGINAL ENGLISH FRENCH

SETUP LANGUAGE

SUBTITLE

OFF ENGLISH FRENCH

SETUP LANGUAGE

DISC MENU

ENGLISH FRENCH SPANISH

ORIGINAL OFF ENGLISH

–28–

AUDIO SETTINGS

Choose the appropriate Audio settings for your equipment as it only affects during the playback of DVD discs.

Follow steps 1to 2in the “CUSTOM MENU” sec-

tion on page 27.

3 Press [K / L] to select the below items then

hit [ENTER].

DRC

(Dynamic Range Control)

¡To compress the range of soft

to loud sound.

¡The default setting is “ON”.

DOWN SAMPLING:

¡ON : Output in 48 kHz.

(default)

¡OFF : Output the original

sound.

When playing disc with copyright Protection

¡If you select “OFF”, copyright protection will be

activated and sound will be down sampled at 48kHz.

DOLBY DIGITAL:

Set to “ON” when the unit is connected to a Dolby Digital Decoder.

¡ON: Output a Dolby Digital signal (default) ¡OFF: Convert the Dolby Digital to PCM

(2 channel stereo)

4 Hit [SETUP] to exit the menu.

QUICK

DISPLAY SETTING

You can change certain aspects of the DVD display screens and on-screen messages on the TV screen.

Follow steps 1to 2in the “CUSTOM MENU” sec-

tion on page 27.

3 Press [K / L] to select the below items then

hit [ENTER].

TV MODE:

¡Press [K / L] for an item

selection, then hit [ENTER].

¡Select “4:3 LETTER BOX”

for black bars to appear on top and bottom of the screen.

¡Select “4:3 PAN & SCAN” for a full height picture

with both sides trimmed.

¡The default setting is “4:3 LETTER BOX”.

STILL MODE

¡Press [K / L] for an item

selection, then hit [ENTER].

¡Select “AUTO” normally. ¡If you select “FIELD”, the picture in the still mode

will be stabilized.

¡If you select “FRAME”, the picture in the still

mode will be highly defined.

ANGLE ICON:

¡Hit [ENTER] repeatedly to turn Angle icon “ON” or

“OFF”.

¡The default setting is “ON”.

AUTO POWER OFF:

¡Hit [ENTER] repeatedly to turn Auto Power off

“ON” or “OFF”.

¡The default setting is “ON” and the screen saver pro-

gram starts when there is no input from the unit for 5 minutes in the stop mode. After the screen saver program is activated for 15 minutes, the power is automatically turned off.

4 Hit [SETUP] to exit the menu.

QUICK

TV SETUP MENU IN DVD MODE

•

Language setting for on-screen menus is only available in TV SETUP menu. You can access it by hitting [SETUP] in DVD mode (Refer to “SELECTING THE LANGUAGE” on page 13).

•

“CHANNEL SET UP” menu is not operative in DVD mode although it is displayed on the screen. Press [SELECT] to move to TV mode first, then follow steps in “CHANNEL SET UP” on page 13.

SETUP DISPLAY

TV MODE 4:3 LETTERBOX STILL MODE AUTO ANGLE ICON ON AUTO POWER OFF ON

SETUP DISPLAY

TV MODE 4:3 LETTERBOX STILL MODE AUTO ANGLE ICON ON AUTO POWER OFF ON

SETUP AUDIO

DRC ON DOWN SAMPLING DOLBY DIGITAL

ON ON

–29–

CONTROL LEVELS

ALL

All parental lock is cancelled.

Level 8

DVD software of any grade (adult/general/children) can be played back.

Levels 7 to 2

Only DVD software intended for general use and children can be played back.

Level 1

Only DVD software intended for children can be played back, with those intended for adult and general use prohibited.

PARENTAL CONTROL

Parental Control limits the disc viewing that exceed your setting (with a password or playback will stop). This feature allows you to prevent discs with alternative scenes from being played by your children.

PARENTAL LEVEL

Parental Level allows you to set the rating level of your DVD discs. Playback will stop if the disc’s ratings exceed the level you set.

Follow steps 1 to 2 in the “CUSTOM MENU” sec-

tion on page 43.

3 Enter your four-digit password then hit

[ENTER].

4 Press [K / L] to select “PARENTAL LEVEL”

then hit [ENTER].

5 Press [K / L]to select the desired level

then hit [ENTER].

6 Hit [SETUP] to exit the menu.

NOTES:

¡When doing this for the first time, enter any 4 digits.

(except for 4737) That number will be used as the password.

¡To change the password, press [K / L] to select

“CHANGE” at step 4 then hit [ENTER]. Enter the four-digit password, then hit [ENTER].

¡With some DVDs, it may be difficult to find if they

are compatible with parental lock. Be sure to check if the parental lock function operates in the way that you have set.

¡Record the password in case you forget it.

IF YOU FORGET THE PASSWORD

1 Hit the number buttons [4], [7], [3], [7] at

step

3.Then enter your new password.

¡Password will be cleared and parental level will be

set to “ALL”.

2 Proceed steps 4 to 6 again.

This allows you to return all selections of SETUP (except for “PARENTAL” and menu language) to their default settings.

1 Hit [SETUP] twice in STOP mode so that the

“INITIALIZE” menu appears.

2 Press [K / L] to select “INITIALIZE” then hit

[ENTER].

3 Select “YES” then hit [ENTER] twice.

All the settings (except for “PARENTAL” and menu lan- guage) will be cleared.

¡To cancel the initialization,

select “NO”.

4 Hit [SETUP] to exit the menu.

DVD-V

INITIALIZE

SETUP PARENTAL

PASSWORD Enter current password.

SETUP PARENTAL

PARENTAL LEVEL ALL

CHANGE

SETUP

QUICK CUSTOM INITIALIZE

SETUP PARENTAL

PARENTAL LEVEL ALL

8 7 [NC-17] 6 [R]

SETUP INITIALIZE

Initialize? NO YES

–30–

If the unit does not perform properly when operated as instructed in this Owner’s Manual, check the unit, consulting the following checklist.

TROUBLESHOOTING GUIDE

Problem Corrective Action

No Picture or Sound

•

Try a new channel, if OK, then possible station trouble.

•

Make sure the power is turned on.

•

Hit [SELECT] on the remote control to select TV mode. Then try other TV feature.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

Bars On Screen

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

Picture Distorted or Blurred

•

Try a new channel, if OK, then possible station trouble.

•

If outside antenna is being used, check for broken wire.

Picture Rolls Vertically

•

Try a new channel, if OK, then possible station trouble.

Lines or Streaks in Picture

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

No Color

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust COLOR control.

Poor Reception on Some Channels

•

Try a new channel, if OK, then possible station trouble.

Ghosts in Picture

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

Weak Picture

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust CONTRAST & BRIGHT control.

Sound OK, Picture Poor

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to terminal on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Adjust CONTRAST & BRIGHT control.

Picture OK, Sound Poor

•

Try a new channel, if OK, then possible station trouble.

•

Check for local interference.

Different color marks on screen

•

Magnetism from nearby appliances and geomagnetism might affect the color of the TV picture. Move the unit away from the appliances, the unit can repair itself automatically. If you want to repair immediately, unplug the unit power cord, then plug it in again 30 minutes or so later. This automatically resets the unit.

Problem Corrective Action

No power

•

Make sure the power plug is connected to an AC outlet.

•

Make sure the power is turned on.

No operation by infrared remote

•

Check if the power plug is connected to an AC outlet.

control

•

Check the batteries in the remote control.

•

Aim the remote control directly at the remote sensor. If necessary,

remove all the obstacles between the sensor and the remote.

•

You have to be within 23 feet of the unit.

•

Check if the correct mode is selected. If not switch the mode by hitting [SELECT] on the remote control,whichever you need.

TV Mode

–31–

NOTES:

•

Some functions are not available in specific modes, but this is not a malfunction. Read the description in this Owner’s Manual for details on correct operations.

•

Playback from a desired track and random playback are not available during program playback.

Closed Caption Problem Possible Remedy

The unit is showing captions • You are watching a live broadcast and spelling errors made by the that are misspelled. • closed captioning production company may pass through uncorrected.

• A prerecorded program will not show any misspelled words because

• of the normal time available for editing the captions.

The unit will not show the text • Captions that are delayed a few seconds behind the actual dialogue in its entirety or there is a delay of • are common for live broadcast. Most captioning production companies what is being said. • can display a dialogue to a maximum of 220 words per minute. If a

• dialogue exceeds that rate, selective editing is used to insure that the

• captions remain up-to-date with the current TV screen dialogue.

The captions are scrambled with • Interference caused by building, power lines, thunderstorms, etc. white boxes on the TV screen. • may cause scrambled or incomplete captions to appear.

The program guide listed a TV show

• Broadcasters may at times use a time compression process to the as being closed captioned but none • actual program so that additional advertising time can be given. of the captions were displayed. • Since the decoder cannot read the compressed information,

• captions will be lost.

The unit screen shows a black • You are in the TEXT mode. Select CAPTION mode or CAPTION box on certain channels. • [OFF].

Problem Corrective Action

No picture • Insert a correct video disc that plays on this unit.

• Hit

[SELECT] on the remote control to select DVD mode. Next, hit

[PLAYOO] or [OPEN/CLOSE AA]. Then, try other DVD feature.

Disc cannot be played

• Insert the disc.

• Clean the disc.

• Place the disc correctly, with the label side up.

• Cancel the parental lock or change the control level. No sound

• Connect the audio cables firmly.

• Turn the power of the audio component on.

• Correct the audio output settings.

• Correct the input settings on the audio component. No DTS audio is output

• This unit does not support DTS audio. This is not a malfunction. Distorted picture

• There are some cases where pictures may be slightly distorted, which

are not a sign of a malfunction.

• Although pictures may stop for a moment, this is not a malfunction. Audio or subtitle language • The selected language is not available for audio or subtitles on the

does not match the set up DVD.

This is not a malfunction.

The camera angle cannot be • The DVD does not contain sequences recorded from different camera changed angles. This is not a malfunction.

Audio or subtitle language cannot • The DVD does not contain audio source or subtitles in the selected be changed language. This is not a malfunction. “Prohibited icon” appears on the • That operation is prohibited by the unit or the disc. screen, prohibiting an operation This is not a malfunction. CD sound dropout • Scratched disc. Replace the disc with an unscratched one. No CD reproduction DVD picture dropout DVD picture freeze DVD picture in mosaic No DVD reproduction

DVD Mode

–32–

CABINET CLEANING

•

Wipe the front panel and other exterior surfaces of the unit with a soft cloth immersed in lukewarm water and wrung dry.

•

Never use a solvent or alcohol. Do not spray insecticide liquid near the unit. Such chemicals may cause damage and discoloration to the exposed surfaces.

SERVICING

•

Should your unit become inoperative, do not try to correct the problem by yourself. There are no userserviceable parts inside. Turn off, unplug the power cord and please call our help line at 1-800-2562487, to locate an Authorized Service Center.

IF THE LASER OPTICAL PICKUP UNIT IS DIRTY

•

If the unit still does not perform properly when it is operated, while referring to the relevant sections and to “TROUBLESHOOTING GUIDE” in this Owner's Manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

•

Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.

•

Always store the disc in its protective case when it is not used.

DISC HANDLING

•

To clean-off, use a soft cloth.

•

Do not use a hard cloth since this will mar the disc.

•

Wipe the disc in a straight line from center to edge.

•

Never wipe with a circular motion.

•

Do not use detergent or abrasive cleaning agents.

MAINTENANCE

–33–

CRT : 20 inch in-line gun,

90˚ deflection tube

Television system: NTSC-M

TV Standard Closed caption system: §15.119/FCC Channel coverage:

VHF: 2 ~ 13 UHF: 14 ~ 69 CATV: 2 ~13, A ~ W,

W+1 ~ W+84,

A-5 ~ A-1, 5A Tuning System: 181 channel

frequency synthesized

tuning system Channel access: Direct access keyboard,

programmable

scan and up/down

Discs: DVD-Video, Audio CD Output signal format: NTSC color

•

Designs and specifications are subject to change without notice.

•

If there is a discrepancy between languages, the default language will be English.

DVD

GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS

Sound output: 2 speakers, 1W, 8 ohm

OTHER SPECIFICATIONS

Terminals

Antenna input: VHF/UHF/CATV

75 ohm unbalanced (F-type) Video input: RCA connector [ 1 Audio L/R input: RCA connector [ 2 Headphone: 1/8

" stereo (3.5 mm)

Coaxial digital audio output (only DVD): One pin jack,

500m Vpp (75 ohm)

Remote control: Digital encoded

infrared light system

Operating temperature: 5°C to 40°C

(41°F~104°F)

Power requirements: AC 120V, 60Hz

Power consumption (Maximum) : 80W Dimensions : H:20-3/16" (514mm)

W:20-3/16" (512mm)

D:19-13/16" (503mm)

Weight : 46.3lbs (21.0kg)

SPECIFICATIONS

–34–

INDICE

■ CONTROLES DE OPERACIÓN Y FUNCIONES . . . . . 34

PANEL FRONTAL DE LA UNIDAD . . . . . . . . . . . . . . . 34

MANDO A DISTANCIA. . . . . . . . . . . . . . . . . . . . . . . . . 34

VISTA POTERIOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

PARA INSERTAR LAS PILAS . . . . . . . . . . . . . . . . . . . . 35

■ PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 35

CONEXIONES DE ANTENA/CABLE . . . . . . . . . . . . . . 35

CONEXIÓN A TOMAS DE ENTRADA EXTERNA. . . . 36

CONEXIÓN A UN AMPLIFICADOR EQUIPADO CON TOMAS DE ENTRADA DIGITAL, PLATINA

MD O PLATINA DAT (Para DVD) . . . . . . . . . . . . . . . . . 36

CONEXCIONA UN DECODIFICADOR DOLBY DIGITAL (Para DVD)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

SECCIÓN DE TV

■ PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 37

SELECCIÓN DE IDIOMA . . . . . . . . . . . . . . . . . . . . . . . 37

AJUSTE DE CANAL . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

SECCIÓN DE DVD

■ REPRODUCCIÓN DE UN DVD DE VIDEO O UN

CD DE AUDIO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

REPRODUCCIÓN BÁSICA . . . . . . . . . . . . . . . . . . . . . . 38

CONTROLES DE

OPERACIÓN Y FUNCIONES

PANEL FRONTAL DE

LA UNIDAD

Consulte la figura 1 de la página 8

MANDO A DISTANCIA

Consulte la figura 2 de la página 8

VISTA POSTERIOR

Consulte la figura 3 de la página 9

1. Bandeja de carga del disco

2. Toma de entrada VIDEO

Conecte aquí la toma de salida de vídeo de una videocámara o de una videograbadora.

3. Tomas de entrada AUDIO L/R

Conecte aquí las tomas de salida de audio de una videocámara o de una videograbadora.

4. Botón POWER

Presione para conectar y desconectar la alimentación.

5. Botones VOLUME K/L (VOL.mm/nn)

Presione para controlar el nivel del volumen para el

DVD y el televisor.

6. Botones CHANNEL K/L (CH. K/L)

Presione para seleccionar el canal memorizado. Presione para cambiar a un modo de televisor cuando esta en el modo de DVD.

7. Ventanilla del sensor del mando a distancia

8. Botón STOP

Detiene la operación del disco.

9. Botón SKIP H

Reproduce desde el inicio del capítulo o canción actual.

Botón SEARCH (REV) h (panel frontal)

Durante la reproducción o en el modo de pausa, mantenga presionado el botón durante unos segundos para cambiar la velocidad de reproducción hacia atrás.

10. Botón PLAY

Inicia la reproducción del contenido del disco. Presione para cambiar a un modo de DVD cuando esta en el modo de televisor.

11. Botón SKIP G

Reproduce desde el inicio del siguiente capítulo o canción.

Botón SEARCH g (panel frontal)

Durante la reproducción o en el modo de pausa, mantenga presionado el botón durante unos segundos para cambiar la velocidad de reproducción en avance.

12. Botón PAUSE F

Hace una pausa en la operación del disco.

13. Botón OPEN/CLOSE A

Presione para insertar un disco en la bandeja o retirarlo de ella.

14. Toma HEADPHONE

Para conectar auriculares (no suministrados) y escuchar en privado.

15. Botón MODE

Activa el modo de reproducción programada o el modo de reproducción aleatoria cuand se reproducen CDs.

16. Botones de números Modo del televisor:

Presione dos dígitos para tener acceso directamente al canal deseado. Recuerde presionar [0] antes de elegir un canal de un solo dígito.

Botón +100

Presione para seleccionar canales de televisión por cable cuyo número sea superiors a 99.

Modo DVD:

Presione para introducir el número deseado.

Botón +10

Presione para introducir números superiors a 9.

17. Botón SLEEP

Presione para visualizar el temporizador para dormir y activar la función. La hora de apagado puede determinarse por el número de veces que usted pulsa el botón. (0, 30, 60, 90 o 120 minutos)

18. Botón REV h

Presione

para

volver rápidamente en el disco.

Presione [PAUSEF] y presione este botón para empezar la reproducción en cámara lenta. Presione repetidamente este botón para cambiar la velocidad en avance de la cámara lenta.

Botón FWD g

Presione para avanzar rápidamente en el disco. Presione [PAUSE F] y presione este botón para empezar la reproducción en cámara lenta. Presione repetidamente este botón para cambiar la velocidad de avance de la cámara lenta.

19. Botón V.SURR (envolvente virtual)

Presione para activar/desactivar el envolvente virtual.

20. Botón SETUP

Presione para entrar o salir del menú de configuración de televisor o DVD.

–35–

21. Botón TITLE

Visualiza el menú de títulos.

22. Botón CLEAR

Repone un ajuste.

23. Botón DISPLAY Modo del televisor:

Presione para visualizar el número del canal en la pantalla. Si lo presiona de nuevo, el número del canal desaparecerá.

Modo de DVD:

Visualiza el estado actual en la pantalla del televisor.

24. Botón SEARCH MODE

Presione para localizar un punto deseado.

25. Botón AUDIO

Presione para seleccionar un idioma de audio o un modo de sonido deseado.

26. Botón SUBTITLE

Presione para seleccionar un idioma de subtítulos

deseado.

27. Botón REPEAT

Repite la reproducción del disco, título, capítulo o pista actual.

28. Botón ANGLE

Presione para cambiar el ángulo de la cámara y ver, desde un ángulo diferente, la secuencia que está siendo reproducida (si existe).

29. Botón A-B REPEAT

Repite la reproducción de una sección seleccionada.

30. Botón RETURN

Permite volver a la pantalla anterior en el modo de configuración.

31. Botón ENTER

Presione para establecer un ajuste.

32. Botones K / L / { / B Modo de televisor:

Presione para seleccionar un modo de ajuste desde el menú que aparece en la pantalla del televisor. Presione para seleccionar o ajustar desde un menú particular.

Modo de DVD:

Presione para seleccionar un ítem de menú.

33. Botón DISC MENÚ

Muestra menú del DVD.

34. Botón SELECT

Presione para cambiar a un modo de televisor, modo de entrada externa o modo de DVD.

35. Botón MUTE

Presione para apagar el sonido de un programa de TV. (La visualización del nivel del sonido cambia de ROJO CLARO a AZUL CLARO.) Presione de nuevo este botón o [VOLmm/ nn] para restaurar el sonido.

NOTA: Cuando seleccione el modo DVD con este botón, Presione primero [PLAYOO] u [OPEN/CLOSEAA]. De lo contrario, las funciones del DVD no se activarán.

36. Botón PICTURE

Presione para entrar en el modo de ajuste de imagen.

37. Cable de alimentación

Conéctelo a una toma de CA convencional (120 V/60 Hz). NOTA: Retire el cable de alimentación del gancho

para evitar romperlo antes de conectarlo a una toma de CA convencional.

38. Toma de salida de audio digital COAXIAL (audio de DVD solamente)

Conecte a la entrada digital de un amplificador o decodificador externo.

39. Toma de entrada ANT.

Conecte a una antena, sistema de televisión por cable o sistema de satélite.

PREPARACIÓN PARA LA

UTILIZACIÓN

Nota para el instalador de sistemas CATV

Esta nota tiene la finalidad de llamar la atención del instalador de sistemas CATV para que tenga en cuenta el Artículo 820-40 del NEC, el cual proporciona consejos para hacer una conexión a tierra apropiada y, en particular, especifica que la tierra del cable deberá estar conectada al sistema de puesta a tierra del edificio, tan cerca del punto de entrada del cable como sea posible.

NOTA:

Antes de enchufar la antena a la toma ANT. de la unidad, compruebe que la clavija no esté doblada. Si esta doblada, póngala derecha como se muestra en la ilustración, y luego conéctela en la toma ANT. de la unidad.

1) Abra la cubierta del compartimiento de las pilas empujando la cubierta del mando a distancia en el sentido de la flecha.

2) Inserte 2 pilas "AA" en el compartimiento de las pilas, en el sentido indicado por las marcas de polaridad (+/-).

3) Vuelva a poner la cubierta.

NOTAS:

•

No mezcle pilas alcalinas y de manganeso.

•

No mezcle pilas viejas y nuevas.

PARA INSERTAR LAS PILAS

CONEXIONES DE

ANTENA/CABLE

Clavija doblada

Cable

Clavija

(Necesita enderezarse)

(Clavija derecha)

Consulte la figura 4 de la página 10

–36–

NOTA:

•

Cuando conecte una videograbadora monofónica (otra fuente) a esta unidad, conecte la toma de salida de audio de la videograbadora monofónica (otra fuente) a la toma AUDIO L de esta unidad. El audio saldrá igualmente por los canales izquierdo y derecho.

Utilice un cable digital coaxial de audio de venta en el comercio especializado para hacer las conexiones de audio.

NOTAS:

•

La fuente de audio de un disco en un formato de sonido envolvente Dolby Digital de 5,1 canales no se puede grabar como sonido digital mediante una platina MD o DAT.

•

Asegúrese de desconectar la alimentación de todos los componentes antes de conectar otro componente.

•

Consulte los manuales del propietario de los componentes que va a conectar a la unidad.

•

Ponga DOLBY DIGITAL en OFF para la salida de audio en el modo de preparación. La reproducción en una unidad utilizando ajustes incorrectos puede provocar distorsión por ruido, y también se pueden dañar los altavoces.

Consulte la figura 6 de la página 11

CONEXIÓN A UN

AMPLIFICADOR EQUIPADO

CON TOMAS DE ENTRADA

DIGITAL, PLATINA MD O

PLATINA DAT (Para DVD)

Consulte la figura 5 de la página 11

ANTENA COMBINADA DE VHF/UHF

La antena combinada de VHF/UHF de 75 ohmios puede conectarse al terminal ANT.

ANTENA SEPARADAS DE VHF/UHF

En algunas zonas será necesario utilizar una antena exterior.

TELEVISION POR CABLE SIN CAJA DE CONVERTIDOR / DECODIFICADOR

Utilice esta conexión si su sistema de televisión por cable se conecta directamente a su televisor/DVD sin una caja de convertidor. Utilice el mando a distancia de la unidad para seleccionar los canales.

TELEVISION POR CABLE CON CAJA DE CONVERTIDOR/DECODIFICADOR O CAJA DE SATÉLITE

Si su empresa de televisión por cable le suministra una caja de convertidor, o si usted utiliza un sistema de satélite, podrá utilizar la conexión básica mostrada aquí. La selección de los canales deberá hacerse con la caja de convertidor o con la caja de satélite. Esto significa que los canales no se podrán cambiar utilizando el mando a distancia de la unidad.

PARA VER UN CANAL CODIFICADO/DECODIFICADO

1) Ponga el selector de canales de la unidad en la posición del canal de salida de la caja de convertidor de televisión por cable o de la caja de satélite. (Ej., CH3)

2) Seleccione el canal que va a ver en su caja de

convertidor de televisión por cable o caja de satélite.

Cuando vea un programa grabado en otra fuente (videograbadora o videocámara), utilice las tomas de entrada de audio/vídeo de la parte delantera de la unidad. Conecte las tomas de salida de audio/vídeo de otra

fuente a las tomas AUDIO L/R y VIDEO de esta unidad.

Después presione [SELECT] hasta que

aparezca "AUX" en la pantalla.

CONEXIÓN A TOMAS DE

ENTRADA EXTERNA

NOTA:

•

Para su seguridad y para evitar que se dañe la unidad, desenchufe el cable de antena de la toma ANT. antes de mover la unidad.

–37–

1 Enchufe el cable eléctrico

de la unidad

Enchufe el cable eléctrico de la unidad en una toma de CA estándar.

NOTA:

•

Si aparecen algunas cifras en la esquina de la pantalla, presione [POWER] sin desenchufar el cable eléctrico.

Asegúrese de que ...

•

Presiona [POWER] para encender la unidad.

NOTA:

•

Esta función afecta sólo el idioma en el menú de la pantalla y no la fuente de audio.

2 Seleccione “LANGUAGE”

Presione [SETUP] en el mando a distancia.

Presione

[KK/ LL] para señalar

“LANGUAGE”.

Seleccione “ENGLISH”, “ESPAÑOL” o “FRANÇAIS”

Seleccione “ENGLISH” = inglés, “ESPAÑOL” o “FRANÇAIS” = francés con [ENTER].

4 Salga del modo de idioma

Presione [SETUP] en el mando a distancia para volver al modo del televisor.

NOTA: Si, por alguna razón, el menú está en francés, presione [SETUP] en el mando a distancia, presione [KK/ LL] para señalar el “LANGAGE [FRANÇAIS]”, a continuación, presione [ENTER] y presione

[SETUP] en el mando a distancia.

SELECCIÓN DE IDIOMA

SECCIÓN DE TV

PREPARACIÓN PARA LA

UTILIZACIÓN

Fabricado bajo licencia de Dolby Laboratories. “Dolby” y el símbolo de la D doble son marcas de fábrica de Dolby Laboratories.

Si utiliza esta unidad para reproducir un disco DVD en un formato de sonido envolvente Dolby Digital de 5,1 canales, la unidad dará salida a un flujo de datos DOLBY DIGITAL desde su toma de salida de audio digital COAXIAL. Si conecta la unidad a un decodificador Dolby Digital, podrá disfrutar de una tonalidad más convincente y real, con un sonido envolvente potente y de alta calidad similar al de los cines. Utilice cables digitales coaxiales de audio disponibles en el comercio especializado para hacer las conexiones de audio.

NOTAS:

•

Asegúrese de desconectar la alimentación de todos los componentes del sistema antes de conectar a otro componente.

•

Consulte los manuales del propietario de los componentes que vaya a conectar a la unidad.

•

Si conecta un decodificador Dolby Digital, ponga DOLBY DIGITAL en ON para la salida de audio en el modo de preparación.

•

A menos que se haga la conexión a un decodificador Dolby Digital, ponga DOLBY DIGITAL en OFF para la salida de audio en el modo de preparación. La reproducción en la unidad utilizando ajustes incorrectos puede generar distorsión de ruido, y también puede estropear los altavoces.

Consulte la figura 7 de la página 12

CONEXCIONA UN

DECODIFICADOR DOLBY

DIGITAL (Para DVD)

- TV SETUP -

CHANNEL SET UP V-CHIP SET UP

B LANGUAGE [ENGLISH]

CAPTION [OFF]

Para empezar

¡Conecte el interruptor del amplificador y otros

equipos, si fuera necesario.

1 Presione [POWER].

¡La alimentación se conectará.

2 Presione [OPEN/CLOSE A].

¡La bandeja de carga del disco se abrirá.

3 Ponga el dlsco en la bandeja con el lado de

la etiqueta hacia arriba.

4 Presione [PLAY

¡La bandeja se cerrará automáticamente y la

reproducción empezará después desde el primer capítulo o pista del disco. Si la reproducción no empieza automáticamente, presione [PLAYOO].

¡Cuando reproduzca un DVD que tenga grabado un

menú de títulos, el menú aparecerá en la pantalla.

5 Presione

[STOP] para detener

la reproducción.

CDDVD-V

–38–

Puede programar el sintonizador para buscar todos los canales que recibe en su localidad.

NOTA: El canal preparado NO es necesario cuando esté conectado a una caja de cable o caja de satélite. Sólo tiene que seleccionar con el selector de canal de la unidad al canal de salida de la caja de cable o caja de satélite (por ejemplo CA3). Seleccione el canal a ver en la caja de cable o caja de satélite.

Asegúrese de que ...

•

Presiona [POWER] para encender el la unidad.

1 Seleccione “AJUSTE DE CANAL”

Presione [SETUP] en el mando a distancia.

Presione

[KK/ LL] para señalar

“AJUSTE DE CANAL”. A continuación, presione

[ENTER].

2 Empiece el prefijado automático

Presione [KK/ LL] para señalar “AUTOPROGRAMACION DE CA”.

A continuación, presione [ENTER]. El sintonizador busca y memoriza todos los canales

activos en su localidad.

3 Después de buscar

El sintonizador se detiene en el canal memorizado más bajo.

•

Cuando se activa AUTOPROGRAMACION DE CA, donde no hay entrada de señal del televisor, aparecerá “NO HAY SEÑAL DE TV” en la pantalla después de terminar la búsqueda de canales.

•

La unidad puede reconocer los canales de TV de cable para que sean canales de TV de antena con las condiciones de recepción. En este caso, pruebe nuevamente con el prefijado automático en las condiciones de recepción fina.

AJUSTE DE CANAL

REPRODUCCIÓN BÁSICA

SECCIÓN DE DVD

REPRODUCCIÓN DE UN

DISCO

– T V P R E P –

B AJUSTE DE CANAL

AJUSTE DE V-CHIP IDIOMA [ESPAÑOL]` TITULO [OFF]

–

AJUSTE DE CANAL

–

AGREGAR/BORRAR (CATV)

B AUTOPROGRAMACION DE CA.

NO HAY SEÑAL DE TV

–39–

MEMO

Printed in Malaysia 1EMN20223

T9014UQ ★★★★★

LIMITED WARRANTY

FUNAI CORP. will repair this product, free of charge in the USA in the event of defect in materials or workmanship as follows:

DURATION: PARTS:

FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase. Two (2) years for Picture Tube. Certain parts are excluded from this warranty.

LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date

of original retail purchase.

LIMITS AND EXCLUSIONS:

This warranty is extended only to the original retail purchaser. A purchase receipt or other proof of original retail purchase will be required together with the product to obtain service under this warranty.

This warranty shall not be extended to any other person or transferee.

This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced, missing or if service was attempted by an unauthorized service center. This FUNAI CORPORATION Limited warranty does not apply to any product not purchased and used in the United States.

This warranty only covers failures due to defects in material or workmanship which occurs during normal use. It does not cover damage which occurs in shipment, or failures which are caused by repairs, alterations or product not supplied by FUNAI CORP., or damage which results from accident, misuse, abuse, mishandling, misapplication, alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or office use of this product or damage which results from fire, flood, lightning or other acts of God.

THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE CONTROL), ANY COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.

FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE USE OF OR THE INABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND OF ALL OTHER LIABILITIES ON THE PART OF FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY FUNAI AND ITS REPRESENTATIVES IN THE UNITED STATES. ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE PERFORMED BY A FUNAI AUTHORIZED SERVICE CENTER. THIS WARRANTY IS ONLY VALID WHEN THE UNIT IS CARRIED-IN TO A FUNAI AUTHORIZED SERVICE FACILITY.

IMPORTANT:

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU ARE UNABLE TO OBTAIN SATISFACTION WITH THE REPAIR OF THIS PRODUCT, PLEASE CONTACT FUNAI CORP.

ATTENTION:

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT WITHOUT PRIOR NOTICE.

To locate your nearest FUNAI Authorized Service Center or for general service procedure, please call or write to the following:

FUNAI CORPORATION, INC.

SERVICE CENTER

19900 Van Ness Avenue, Torrance, CA 90501

Tel :1-800-256-2487

http://www.emersonaudiovideo.com

Head Office: 100 North Street, Teterboro, NJ 07608

PLEASE DO NOT SHIP YOUR UNIT TO THE TETERBORO ADDRESS.
