Owner’s Manual Drive Safe
Driving while talking on your mobile phone is dangerous, and
illegal in many states.
Check local laws regarding the use of a mobile handset and wireless
headset while driving. If you use the Bluetooth Headset while
driving, ensure your attention and focus remains on your driving.
Please use your mobile phone, and our
product responsibly while driving!
Location of controls
®
Wireless Headset
Silicone
cushion
Volume up
(Press 3 seconds to redial)
Volume down
Model: EM228
In the box
Bluetooth
Headset
S M L
Silicone cushions
Earhook type 1
Earhook type 2
Owner’s Manual
®
Wireless Headset
Model: EM228WM
Owner’s
Manual
USB charging
cable
AC charger
Car Charger
Charging the Bluetooth Headset Pairing with the SONY PlayStation®3 (PS3™)
1. Connect the charging pin of the USB cable to the charging
socket of the headset.
2. Connect the other end of the USB cable to either the:
• AC Charger, and plug into a wall (A/C) outlet
• Car Charger
• Computer’s USB port
3. The RED LED indicator light turns on.
4. The RED LED indicator light shuts o when the headset
is fully charged (approximately 2-3 hours).
NOTE: When the battery is running low, the RED LED indicator
light starts to ash.
Headset
NOTE: Charge your headset for at least 8 hours before using
it for the rst time.
CAUTION: Although this device enables drivers to
conduct handsfree conversations, it is still safer to pull
over before using a mobile phone.
Always keep your full attention on your driving.
Charging socket
Power button
Power ON/OFF
Answer/end a call
Indicator light
Microphone
(Charging pin)
USB cable
Charging
Socket
AC Charger
Indicator
light
PC
Car Charger
Pairing the headset with a Bluetooth enabled device
1. Make sure the Bluetooth Headset is turned o.
2. Keep your Bluetooth Headset and mobile phone within 3
feet of each other during the pairing process.
3. Press and HOLD the
lights ash alternately.
4. The headset is now in Pairing Mode and is ready to connect
to your mobile phone.
[POWER]
button until the RED and BLUE
Power button
(Press & HOLD)
within 3 feet
Indicator light
NOTE: To enter the Pairing Mode, you must press and HOLD the
[POWER] button for approximately 10 seconds.
5. Set your mobile phone to search for Bluetooth devices.
Bluetooth: Enabled
Paired Devices:
6. When the phone nds the headset, conrm by selecting EM228
from the list.
Bluetooth: Enabled
Paired Devices:
EM228
EM228
7. Enter passcode “0000” when prompted by the phone.
Bluetooth: Enabled
Paired Devices:
EM228
0000
OR depending on which model mobile phone you are trying
to connect the headset to, it may not be necessary to enter a
passcode and the following message (or similar) may appear on
your phone’s display.
Bluetooth: Enabled
Paired Devices:
EM228
Select “Pair” to complete the pairing process.
*Empty *
Searching for devices
ound
1 f
Stop
Select Device:
Cancel
Enter numeric passkey
for EM228:
OK
“EM228” would like to pair
with your phone. Would you
like to allow it to pair?
Cancel Pair
8. Your mobile phone will conrm that the pairing was completed,
and prompt you to accept the connection. Please select
“YES” to connect the headset to your mobile phone. If the pairing
was successful, the headset’s indicator light ashes a steady blue.
Bluetooth: Enabled
Paired Devices:
EM228
Confirm connection to
EM228?
YES NO
/
9. When attempting to reconnect the headset to your mobile
phone, you may see the message below, and your mobile
phone will prompt you to accept the connection request to
the EM228 headset, and an option not to ask this again.
Please accept the connection, and if you select “Don’t ask this
again”, your phone will automatically accept future connection
requests from your Bluetooth Headset.
Bluetooth: Enabled
Paired Devices:
EM228
Accept connection request
from EM228?
YES NO
/
Don’t ask this again
NOTE: The screenshots above are typical of many Bluetooth enabled
phones in the market today, and are used to assist in the
explanation of the pairing process. Your mobile phone’s
interface and interaction with the Bluetooth Headset may
slightly dier from the illustrations above.
Pairing the Bluetooth Headset with a Sony PlayStation 3
<SET ACCESSORY to BLUETOOTH on PS3>
1. Go to the PS3 main menu, scroll to and select “Settings”.
2. Scroll to and select “Accessory Settings”.
3. Scroll to and select “Manage Bluetooth Devices”.
4. The menu will ask: “The Bluetooth device has not been
registered. Do you want to register it?”, then select “YES”.
<REGISTER EM228 to PS3>
Put your Bluetooth Headset into pairing mode.
(See “Pairing the headset with a Bluetooth enabled device”)
1. Select “Start Scanning” from the PS3 menu.
2. Once the PS3 has discovered the Headset, the screen will read
“Select the Bluetooth device to register”, then select “EM228”
3. The PS3 will ask for a passkey. Enter [0000] then select “OK”. Now
press [O] (the PS3 circle button) to get back to the previous menu.
4. Scroll to and select “Audio Device Settings” to change the
“Input Device” to “EM228”.
NOTE: “Input Device” is the microphone, and determines the
method of how others will hear you speak. By
default, the “Output Device” will now switch to “EM228”.
“Output Device” is the audio, and determines how you will
hear the PS3 audio and others speaking.
To test the connection, speak into the headset and you will see
the bars above the “Microphone Level” moving, if not, repeat the
pairing process.
Press “OK” to conrm the new settings. You are now ready to use
the Bluetooth Headset with your PS3 Entertainment System. If you
would like to hear the PS3 audio through your TV or Audio System,
scroll to “Output Device” and switch to “System Default Device”.
For further assistance with Bluetooth settings on your PS3 please
refer to your PS3 instruction manual.
Using your Bluetooth Headset Wearing your Bluetooth Headset Troubleshooting tips
Powering ON/OFF
• To turn ON, press and hold the [POWER] button until the
BLUE LED indicator light turns on.
• To turn OFF, press and hold the [POWER] button until the
BLUE LED indicator light changes to RED, and then shuts o.
Power button
Indicator light
Answering/Ending a call
• To answer a call, press and release the [POWER] button.
• To end a call, press and release the [POWER] button.
Power button
Answer/end a call
Rejecting an incoming call
During an incoming call, press and HOLD the
button until you hear the conrmation tone.
[POWER]
To make a call
Dial the number and press the send button on your mobile
phone, the call is automatically transferred to the headset.
For added comfort and noise suppression, 3 silicone cushions
are included with your Bluetooth Headset. Choose the silicone
cushion (S) (M) (L), which ts most comfortably in your ear, and
insert it on the Bluetooth Headset as shown in the diagram below.
S M L
Silicone cushions
You may wear your headset with or without the provided
earhooks (2 dierent earhooks are provided). If you choose to
wear your headset with the earhook, select the one that ts
most comfortably on your ear and connect it to the headset as
shown in the diagrams below.
Earhook type 1
I cannot get the Bluetooth Headset into Pairing Mode
Make sure the Bluetooth Headset is turned o before
•
beginning the pairing process.
Press and hold the [Power] button (10 seconds) until the RED and
•
BLUE lights ash alternately, this will signal that the headset
is in Pairing Mode, and ready to connect to your mobile phone.
My mobile phone is not able to pair with the Bluetooth Headset
Make sure that you fully charged the headset before pairing.
•
Keep your Bluetooth Headset and mobile phone within 3
•
feet of each other during the pairing process.
Check that your phone’s Bluetooth feature is turned ON.
•
Try repeating the pairing process, see “Pairing the headset
•
with a Bluetooth enabled device.”
After successfully pairing my mobile phone and Bluetooth
Headset, when I shut my phone and turn it on again, my
headset did not automatically connect
Try turning the headset OFF, and then turning it ON again.
•
Many mobile phones have an auto reconnect option when rst
•
attempting to reconnect to a newly paired Bluetooth device.
Make sure you accept this option, so that your Bluetooth Headset
automatically reconnects to your mobile phone; check the user
guide of your mobile phone for more information regarding
this option.
Try unpairing the headset from your phone, and repeat the pairing
•
procedure.
I hear distortion, and the sound quality is poor
For the best audio quality, always wear your Bluetooth Headset
•
on the same side of the body as your mobile phone.
Check that the battery is charged enough.
•
The sound is very low
Try adjusting the volume by using the [VOLUME UP] or
•
[VOLUME DOWN] button on your headset; make sure the
volume on your mobile phone is turned up as well.
FCC and telephone company information
FCC Part 15
This equipment has been tested and found to comply with the
requirements for a Class B digital device under Part 15 of the
Federal Communications Commission (FCC) rules. These
requirements are intended to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Do not attempt to repair or modify this equipment.
Warning: Changes or modications to this equipment not
expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Industry Canada
Operation is subject to the following two conditions: (1) This
device may not cause interference and (2) This device must
accept any interference, including interference that may
cause undesired operation of the device.
The term “IC:” before the certication/registration number
only signies that registration was performed based on a
Declaration of Conformity indicating that Industry Canada
technical specications were met. It does not imply that
Industry Canada approved the equipment.
Redialing the last number called (Dependent
on your phone supporting this feature)
Press the [VOLUME UP] button for 3 seconds, and release.
The last number called will be redialed.
Volume up
(Hold down 3 seconds,
and release)
Adjusting the volume
Press the [VOLUME UP] or [VOLUME DOWN] button to adjust
the volume to the desired level.
Volume up
Volume down
NOTE: You may also adjust the volume from your mobile phone’s
volume control.
Left ear Right ear
Earhook type 2
Right earLeft ear
NOTE: For the best audio quality, always wear your Bluetooth
Headset on the same side of the body as your mobile phone
Warranty information
Limited Warranty
In the unlikely event that this product is defective, or does
not perform properly, you may within one (1) year from your
original date of purchase return it to the authorized service
center for repair or exchange.
TO OBTAIN WARRANTY SERVICE:
• Provide proof of the date of purchase within the package
(Dated bill of sale).
• Prepay all shipping costs to the authorized service center,
and remember to insure your return.
• Include a return shipping address (no P.O. Boxes),
a telephone contact number, and the defective unit within
the package.
• Describe the defect or reason you are returning the product.
Your product will be repaired or replaced, at our option, for the same
or similar model of equal value if examination by the service center
determines this product is defective. Products received damaged
as a result of shipping will require you to le a claim with the carrier.
The shipping address of the authorized service center is:
Southern Telecom, Inc.
ATTN: Returns Department
14-C 53rd Street
Brooklyn, NY 11232
Should you have any questions or problems concerning this
product, please contact our customer service department at:
1-877-768-8483 (Toll Free)
Monday - Thursday: 9AM - 5PM (EST)
Friday: 9AM - 3PM (EST)
or
via e-mail at
cs@southerntelecom.com
Warranty service not provided
This warranty does not cover damage resulting from accident,
misuse, abuse, improper installation or operation, lack of reasonable
care, and unauthorized modication. This warranty is voided in
the event any unauthorized person opens, alters or repairs this
product. All products being returned to the authorized service
center for repair must be suitably packaged.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY
APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE
HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION
GIVEN BY SOUTHERN TELECOM INC. IT’S AGENTS, OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE
SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY
IS THE EXCLUSIVE REMEDY OF THE CONSUMER. SOUTHERN
TELECOM INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS
PRODUCT OR ARISING OUT OF ANY BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER
OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED
BY THE LAWS OF THE STATE OF NEW YORK. EXCEPT TO THE
EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRA NTY OF MERC HANTABI LITY OR FIT NESS FO R A
PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO
THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
Some states do not allow the exclusion nor limitation of incidental
or consequential damages, or limitations on how long an implied
warranty lasts so the above limitations or exclusions may not apply
to you. This warranty gives you specic legal rights, and you
also may have other rights that vary from state to state.
www.emersonphones.com
Distributed by Southern Telecom Inc. Brooklyn, NY 11232
© 2010 Southern Telecom Inc. All rights reserved.
Emerson and the G-Clef logo are registered trademarks of
Emerson Radio Corp. Parsippany, New Jersey USA.
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc.
SONY PlayStatiion® & PS3™ are either trademarks or registered
trademarks of SONY.
All other trademarks are trademarks of their respective owners.
Loading...
