READ AND SAVE THESE INSTRUCTIONS
CONTEMPORARY
HIGHPOINT
™
54” Ceiling Fan Owner's Manual
Model Numbers
CF205BS01 -
Finish Blades & Opal Matte Glass
Brushed Steel Housing, Dark Mahogany
CF205GES01 - Golden Espresso Housing, Chocolate
Finish Blades & Sandstone Glass
CF205GRT01 - Graphite Housing, Charcoal/Timber
Gray Blades & Opal Matte Glass
CF205VS01 - Vintage Steel Housing, River Wash/
Honey Oak Dual Finish Blades & Vintage Cream Glass
Net Weight: 22.4 Lbs.
Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service
8 a.m. - 6 p.m., Eastern, Monday-Friday
Part No. F40BP73750003 Form No. BP7375-3
Revision: 161201 U.L. Model No.: CF205
1-800-654-3545
www.emersonfans.com
• Español - página 31
• Français - page 61
Table of Contents
Section Page
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
. Unpacking Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
1
2. Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Ceiling Fan Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
4. How to Hang Your Ceiling Fan . . . . . . . . . . . . . . . . . . . . 11-12
5. How to Wire Your Ceiling Fan . . . . . . . . . . . . . . . . . . . . . 13-17
6. Ceiling Cover Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7. Final Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8. Disassemble Your Light Kit for
Cover Plate Assembly Only . . . . . . . . . . . . . . . . . . . . . . . 20-21
READ AND SAVE THESE INSTRUCTIONS
Safety Instructions
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a. Use this unit only in a manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
b. Before servicing or cleaning unit, switch power off at
service panel and lock service panel disconnecting
means to prevent power from being switched on
accidentally. When the service disconnecting means
cannot be locked, securely fasten a warning device,
such as a tag, to the service panel.
1. Read your owner’s manual carefully and keep it for future
reference.
2. Be careful of the fan and blades when cleaning, painting,
or working near the fan. Always turn off the power to the
ceiling fan before servicing.
3. Do not put anything into the fan blades while they are
turning.
4. Do not operate reversing switch until fan blades have
come to a complete stop.
Additional Safety Instructions for Installation
1. To avoid possible shock, be sure electricity is turned off
at the fuse box before wiring, and do not operate fan
without blades.
2. All wiring must be in accordance with the National
Electrical Code “ANSI/NFPA 70-2014” and Local
Electrical Codes. Use the National Electrical Code if
Local Codes do not exist. The ceiling fan must be
grounded as a precaution against possible electrical
shock. Electrical installation should be made or
approved by a licensed electrician.
3. The outlet box and joist must be securely mounted and
capable of reliably supporting at least 50 pounds. Use
only U.L. outlet boxes listed as “Acceptable for Fan
Support of 22.7kg. (50 lbs.) or less”, and use the
mounting screws provided with the outlet box.
Most outlet boxes commonly used for support of light
fixtures are not acceptable for fan support and may need
to be replaced. Consult a qualified electrician if in doubt.
!
Section Page
9. Remote Control Procedures . . . . . . . . . . . . . . . . . . . . . . .22-24
0. Reverse Switch Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 25
1
11. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
12. Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27
13. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
14. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Ceiling Fan Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Spanish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
French . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
4. The longer downrod furnished with the fan provides the
minimum recommended floor to fan blade clearance for a
9 foot ceiling. The 6” downrod (supplied) must be used
for an 8 foot ceiling.
5. The fan must be mounted with the fan blades at least
7 feet from the floor to prevent accidental contact with
the fan blades.
6. Follow the recommended instructions for the proper
method of wiring your ceiling fan. If you do not know
enough about electrical wiring, have your fan installed by
a licensed electrician.
CAUTION: The halogen bulbs operate at high internal
pressure and high surface temperatures and could shatter
unexpectedly. The halogen bulbs generate UV
(ultraviolet) radiation that may cause skin and eye irritation
with prolonged exposure. To avoid risks of burns or other
injury, assure power is off before attempting to install or
replace halogen bulb. Do not operate fan/light without lower
glass in place.
7. This fan uses halogen bulbs. Do not touch the bulb with
bare hands. Fingerprints may result in shorter bulb life.
Remove fingerprints with alcohol.
NOTE: This fan is suitable for use with solid-state speed
controls.
NOTE: All setscrews must be checked and re-tightened
where necessary before installation.
WARNING
To reduce the risk of electrical shock, this fan must be
installed with an isolating wall control/switch.
To reduce the risk of fire or electrical shock, this fan
should only be used with fan speed control, Model No.
UC7067RA, manufactured by Rhine Electric Co., Ltd.
To avoid fire, shock or injury, do not use an Emerson or
any other brand of control not specifically approved for
this fan.
This product is designed to use only those parts supplied
with this product and/or any accessories designated
specifically for use this product by Emerson Electric Co.
Substitution of parts or accessories not designated for
use with this product by Emerson could result in
personal injury or property damage.
To reduce the risk of personal injury, do not bend the
blade flange when installing the blade flanges, balancing
the blades or cleaning the fan. Do not insert foreign
objects in between rotating fan blades.
!
U.L. Model No.: CF205
2
1. Unpacking Instructions
A
B
C
D
E
F
G
H
I
J
K
L
Q
M
N
O
P
R
3
5
1
2
4
7
8
9
10
6
WARNING
Do not install or use fan if any part is damaged or
missing. Call Toll-Free:
!
1-800-654-3545
WARNING
This product is designed to use only those parts supplied
with this product and/or any accessories designated
specifically for use with this product by Emerson Electric
Co. Substitution of parts or accessories not designated
for use with this product by Emerson Electric Co. could
result in personal injury or property damage.
!
1.1
Check to see that you have received the following parts:
NOTE: If you are uncertain of part description, refer to
exploded view illustration.
HARDWARE CONTENTS
Part Description Qty.
1 Threaded Studs, #8-32 x 1-1/4” 2
2 Knurled Knobs, #8-32 2
3 Lockwashers, External Tooth, #8 2
4 Wire Connectors 7
5 Clevis Pin 1
6 Hairpin Clip 1
7 1/4-20 x 11mm Pan Head Screws 7
8 10-24 x 9 mm Oval Head Screws 10
9 #8-32 x 10 mm Pan Head Screw w/Lockwashes 1 (spare)
10 Blade Balance Kit 1
PACKAGE CONTENTS
Part Description Quantity
A Fan Motor/Housing Assembly 1
B Ceiling Cover 1
C Motor Coupler Cover 1
D Fan Blades 3
E Fan Blades Flanges 3
F Decorative Blade Nuts (bagged) 9
G Hanger Bracket 1
H Hanger Ball/12” Downrod Assembly 1
I 6” Downrod 1
J Rod Support Assembly 3
K Decorative Rod Assembly 3
L Decorative Rod Assembly Screw (bagged) 6
M Light Kit Plate 1
N Lower Glass 1
O Cover Plate 1
P 50-Watt Mini-Candelabra Base Halogen Bulb 2
Q Remote Control Transmitter, SR401 1
R Remote Control Receiver 1
NOTE: The loose parts are individually packaged for
ease of installation. Place the parts from the loose
parts bags in a small container to keep them from
being lost. If any parts are missing, contact your local
retailer or catalog outlet for replacement before
proceeding.
1.2
Re move the fan assembly from the pro tective
plastic bag. Place the fan assembly into the upper foam
pad with the bottom of the motor facing up.
The upper foam pad serves as a holder for the fan during
the first stages of assembly.
3
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF205
1. Unpacking Instructions (Continued)
This Manual Is Designed to Make it as Easy as Possible for You to Assemble,
Install, Operate and Maintain Your Ceiling Fan
our Emerson ceiling fan comes supplied with a Fan/Light
Tools Needed for Assembly
One Phillips head screwdriver One stepladder
One wire stripper One wire cutter
Materials
Wiring outlet box and box connectors must be of type
required by the local code. The minimum wire would be a
3-conductor (2-wire with ground) of following size:
Installed Wire Length Wire Size A.W.G.
Up to 50 ft. 14
50-100 ft. 12
Y
Remote Control which consists of a receiver mounted
inside the ceiling cover of the fan motor housing. This
system allows you to regulate your ceiling fan speed and
light ON/OFF.
NOTE: An optional Emerson Electric SW406 Wall
Control may also be used to control your ceiling fan.
WARNING
Before assembling your ceiling fan, refer to section on
proper method of wiring your fan (page 13). If you feel
you do not have enough wiring knowledge or experience,
have your fan installed by a licensed electrician.
!
2. Electrical Requirements
Your new ceiling fan will require a grounded electrical
supply line of 120 volts AC, 60 Hz, 15 amp circuit.
The outlet box must be securely anchored and capable of
withstanding a load of at least 50 pounds.
WARNING
To reduce the risk of fire, electric shock, or personal
injury, mount fan to outlet box marked “Acceptable for
Fan Support of 22.7kg. (50 lbs.) or less”, and use screws
supplied with outlet box. Most outlet boxes commonly
used for support of light fixtures are not acceptable for
fan support and may need to be replaced. Consult a
qualified electrician if in doubt.
WARNING
Turning off wall switch is not sufficient. To avoid possible
electrical shock, be sure electricity is turned off at the
main fuse box before wiring. All wiring must be in
accordance with National and Local codes and the ceiling
fan must be properly grounded as a precaution against
possible electrical shock.
!
!
If your fan is to replace an existing ceiling light fixture, turn
electricity off at the main fuse box at this time and remove
the existing light fixture.
WARNING
To avoid fire or shock, follow all wiring instructions
carefully.
Any electrical work not described in these
instructions should be done or approved by a licensed
electrician.
Pl ease ca ll Em erson t echnical support at
1- 800-654- 3545 if you have a ny que stions about
installation and operation of this ceiling fan.
!
U.L. Model No.: CF205
4
3. Ceiling Fan Assembly
FAN BLADE
DECORATIVE
BLADE NUTS (3)
BLADE FLANGE
10-24 x 9mm OVAL
HEAD SCREW (3)
1/4-20 x 11mm PAN HEAD
SCREW (2 per flange)
BLADE FLANGE
MOTOR HUB
3.1
Mount the fan blades to the blade flanges using three
0-24 x 9mm oval head screws and three decorative blade
1
nuts (supplied) (Figure 1).
WARNING
To reduce the risk of personal injury, do not bend the
blade flange when installing the blade flanges,
alancing the blades or cleaning the fan. Do not insert
b
foreign objects in between rotating fan blades.
!
3.2
Remove and discard the three shipping retainers securing
the motor hub in the motor housing.
NOTE: Take care not to scratch the fan housing when
installing the blade assemblies.
Rotate the motor hub to position the slot in the motor plate
over the fan motor/housing flange hole.
Attach the blade flange assembly on the fan motor/
housing by slowly rotating the motor hub to align screw
holes. Tighten the 1/4-20 x 11mm pan head screws
securely while interlocking the flange assemblies as you
rotate the hub (Figure 2).
Figure 1
5
Figure 2
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF205
3. Ceiling Fan Assembly (Continued)
LIGHT KIT PLATE
MOTOR SCREW (3)
LIGHT KIT
PLATE
BLACK WIRE
B
LUE WIRE
FAN MOTOR/
H
OUSING
ASSEMBLY
WHITE WIRES
3.3
Your ceiling fan can be assembled with the light kit
and glass or without the light kit and glass.
o assemble without the light kit and glass, you will
T
use the no-light cover plate. In order to use the
no-light cover plate, the light sockets will need to be
removed from the light kit plate.
NOTE: In order to remove the light sockets, the wires
on the light kit plate will need to be cut. MAKE SURE
THIS IS THE NO LIGHT ASSEMBLY DESIRED.
NOTE: If no light kit is to be used on the ceiling fan,
disregard Steps 3.3 and 3.4; proceed to “How to
Disassemble Your Light Kit for Cover Plate Assembly
Only”, then continue to Step 3.5.
Connect the white wire from the light kit plate to the white
wire in the fan motor/ housing assembly (Figure 3).
Connect the black wire from the light kit plate to the black
wire in the fan motor/housing assembly.
CAUTION: Before installing and tightening the
screws, be sure there are no wires pinched between
the light kit plate and the fan motor/housing
assembly.
Figure 3
3.4
Remove one of the fan motor/housing assembly screw
(retain for later use). Position the light kit plate on the fan
motor/housing assembly aligning the keyhole slots over
the fan motor screws. Rotate the light kit plate clockwise to
engage the screws into the keyhole slots. Reinstall the
previous removed screw. Tighten the three screws to
secure t he light k it plate t o the fan motor/h ousing
(Figure 4).
A spare #8-32 x 10 mm pan head screw with lockwasher
supplied in parts bag, if needed.
3.5
Carefully remove the fan assembly from the lower foam
pad. Turn the partially assembled ceiling fan over and
position it on the lower foam pad. The light kit plate should
be resting on the pad so that the top of the motor faces up.
Figure 4
U.L. Model No.: CF205
6
3. Ceiling Fan Assembly (Continued)
DOWNROD
THREE 80" MOTOR
LEADS (UNTWISTED)
MOTOR
COUPLING
DOWNROD
LOOSEN PHILLIPS
HEAD SET
SCREWS (2)
PHILLIPS HEAD SET SCREW (LOOSENED)
H
ANGER BALL
DOWNROD
PIN
GREEN GROUND WIRE
3.5
Remove the hanger ball by loosening the Phillips head set
screw in the hanger ball until the ball falls freely down the
ownrod (Figure 5).
d
Remove the pin from the downrod, then remove the
anger ball (Figure 5).
h
Retain the pin and hanger ball for reinstallation in
Step 3.13.
NOTE: If you have an eight-foot ceiling, you will have
to use the 6” downrod (supplied) in order to maintain
the necessary blade-to-floor clearance of seven feet.
3.6
Separate, untwist and unkink the three 80” motor leads.
Route the three 80” black, blue, and white motor leads
through the downrod (Figure 6).
Figure 5
3.7
Loosen the two Phillips head set screws in the motor
coupler for installation of the downrod (Figure 7).
Seat the downrod in the motor coupler (Figure 7).
Rotate and align the downrod holes with all the holes in the
motor coupler (Figure 7).
7
Figure 6
Figure 7
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF205
3. Ceiling Fan Assembly (Continued)
MOTOR
HOUSING
GROMMET
COUPLER
COVER
H
AIRPIN
C
LIP
CLEVIS
PIN
MOTOR
COUPLING
HAIRPIN
CLIP
CLEVIS
PIN
RETIGHTEN
PHILLIPS HEAD
SET SCREW (2)
COUPLER
COVER
ROD SUPPORT
ASSEMBLY
SCREWS (3)
(Toward Top)
GROMMET
3.8
Align the clevis pin holes in the downrod with the holes in
he motor coupler.
t
Install the clevis pin and secure with the hairpin clip
Figure 8).
(
The clevis pin must go through the holes in the motor
coupler. It is critical that the clevis pin in the motor coupler
is properly installed and securely tightened.
Retighten the two Phillips head set screws to secure the
downrod to the motor (Figure 8).
WARNING
It is critical that the clevis pin and setscrews in the motor
coupler are properly installed and securely tightened.
Failure to verify that the pin and setscrews are properly
installed could result in the fan falling.
!
3.9
Make sure the grommet is properly installed in the coupler
cover, then slide the coupler cover on the downrod until it
rests on the motor housing (Figure 9).
Figure 8
Figure 9
3.10
NOTE: If you installed the 6” downrod, the three
decorative rod assemblies and the rod support
assembly will not be installed. Disregard Steps 3.11
through 3.12; proceed to Step 3.13.
Make sure the grommet is properly installed in the rod
support assembly. Slide the rod support assembly onto the
downrod (Figure 10).
Then pos ition the three screw s in the rod support
assembly toward the top (Figure 10).
U.L. Model No.: CF205
Figure 10
8
DECORATIVE
ROD ASSEMBLY
DECORATIVE
ROD SCREW
DOWNROD
ROD
SUPPORT
ASSEMBLY
D
ECORATIVE
R
OD ASSEMBLY
DECORATIVE
ROD SCREW
3. Ceiling Fan Assembly (Continued)
3.11
Using the decorative rod screws (supplied), attach the
three decorative rod assemblies to the motor housing
Figure 11). The decorative rods must be oriented so that
(
they lean in towards the downrod. Do not tighten the rod
screws at this time.
Figure 11
3.12
Slide the rod support assembly up the downrod until the
threaded holes in the rod support align with the holes in the
decorative rod assemblies (Figure 12). Secure the
decorative rods to the rod support using three decorative
rod screws; do not tighten the rod screws at this time.
Rotate the rod support assembly until the decorative rod
assemblies are aligned vertically with the downrod
(Figure 12). Hold the rod support in this position while
tightening all six decorative rod screws securely.
Figure 12
emersonfans.com
9
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF205
DOWNROD
CEILING
COVER
6 TO 9
INCHES
HANGER BALL
WHITE WIRE
BLACK WIRE
1/2-INCH
BLUE WIRE
DOWNROD
CEILING
C
OVER
PIN
HANGERBALL
SETSCREW
3. Ceiling Fan Assembly (Continued)
3.13
Place the ceiling cover over the downrod. Then reinstall
the hanger ball (Figure 13) on the downrod as follows.
oute the three 80” motor leads through the hanger ball
R
and slide the hanger ball over the downrod. Position the
pin through the two holes in the downrod and align the
hanger ball so the pin is captured in the groove in the top
of the hanger ball. Pull the hanger ball up tight against the
pin and securely tighten the setscrew in the hanger ball.
A loose setscrew could create fan wobble.
Figure 13
3.14
The fan comes with black, blue and white leads that are
80” long.
Measure up approximately 6 to 9-inches above top of
hanger ball / downrod assembly (Figure 14).
Cut off excess leads and strip back insulation 1/2-inch from
end of leads.
You have now completed the initial assembly of your new
ceiling fan. You can now proceed with hanging and wiring
your fan.
Pl ease ca ll Em erson t echnical support at
1- 800-654- 3545 if you hav e any que stions
about installation and operation of this ceiling fan.
Figure 14
U.L. Model No.: CF205
10
TWO SCREWS
SUPPLIED WITH
OUTLET BOX
HANGER BRACKET
ANTI-ROTATION TAB
OUTLET BOX
FLOOR
C
EILING
AT LEAST
7'
4.
How
to
Hang
Your
Cei
ng
i
l
Fan
WARNING
The fan must be hung with at least 7' of clearance from
floor to blades (Figure 15).
WARNING
Turning off wall switch is not sufficient. To avoid possible
electrical shock, be sure electricity is turned off at the
main fuse box before wiring. All wiring must be in
accordance with National and Local codes and the ceiling
fan must be properly grounded as a precaution against
possible electrical shock.
WARNING
The outlet box and joist must be securely mounted and
capable of supporting at least 50 lbs. Use only a U.L.
outlet box listed as “Acceptable for Fan Support of
22.7 kg. (50 lbs.) or less”.
!
!
!
Figure 15
WARNING
To reduce the risk of fire, electric shock, or personal
injury, mount fan to outlet box marked “Acceptable for
Fan Support of 22.7 kg. (50 lbs.) or less”, and use screws
supplied with outlet box. Most outlet boxes commonly
used for support of light fixtures are not acceptable for
fan support and may need to be replaced. Consult a
qualified electrician if in doubt.
!
4.1
Securely attach the hanger bracket to the outlet box using
the two screws supplied with the outlet box. (Figure 16).
WARNING
Hanger bracket must seat firmly against outlet box. If the
outlet box is recessed, remove wall board until bracket
contacts box. If bracket and/or outlet box are not securely
attached, the fan could wobble or fall.
!
Figure 16
11
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF205
4. How to Hang Your Ceiling Fan (Continued)
OUTLET
BOX
HANGER
BRACKET
HANGER BALL/
DOWNROD
ASSEMBLY
NOTE: CEILING COVER, SUPPLY WIRES AND FAN WIRES
OMITTED FOR CLARITY.
HANGER BRACKET
HANGER BALL
HANGER BALL
GROOVE
ANTI-ROTATION
TAB
4.2
Ca refully lift t he fan and seat the ha nger ball/
downrod assembly on the hanger bracket that was just
attached to the outlet box (Figure 17).
Be sure the groove in the ball is engaged with the antirotation tab on the hanger bracket (Figure 17).
WARNING
Failure to seat tab in groove could cause damage to
electrical wires and possible shock or fire hazard.
WARNING
To avoid possible fire or shock, do not pinch wires
between the hanger ball/downrod assembly and hanger
bracket.
!
!
INSTRUCTION TO THE USER (if device contains a digital device)
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This equipment has been certified to comply with the limits for a class B computing device, pursuant to FCC Rules.
In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation
with non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The
user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could
void the user’s authority to operate this equipment.
Figure 17
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
U.L. Model No.: CF205
12
FO
R
L
I
G
H
T
T
O
M
O
T
O
R
N
A
C
I
N
N
T
O
M
O
T
O
R
L
RE CEI VER ANT ENN A WIRE
AC
IN
L
RECEIVER
5. How to Wire Your Ceiling Fan
f you feel that you do not have enough electrical
I
wiring knowledge or experience, have your fan
installed by a licensed electrician.
WARNING
To avoid possible electrical shock, be sure electricity is
turned off at the main fuse box before wiring.
OTE: If you are not sure if the outlet box is grounded,
N
contact a licensed electrician for advice, as it must be
grounded for safe operation.
!
5.1
AUTION: To reduce the risk of electrical shock,
C
disconnect the electrical supply circuit before
installing the fan, light kit or receiver.
Disconnect electrical power to the branch circuit at the
circuit breaker or fuse box before attempting to wire the
ceiling fan.
WARNING
!
WARNING
!
Turning off wall switch is not sufficient. To avoid possible
electrical shock, be sure electricity is turned off at the
main fuse box before wiring. All wiring must be in
accordance with National and Local codes and the ceiling
fan must be properly grounded as a precaution against
possible electrical shock.
5.2
Locate the electronic receiver and insert its antenna wire
into the opening of the hanger bracket above the hanger
ball. Continue to insert the body of the receiver (flat side
facing up) into the opening, orient as shown. Be careful
not to pinch any wires between the receiver body and the
bracket or ball (Figure 18).
WARNING
To avoid possible fire or shock, do not pinch the
antenna wire between the hanger bracket and the
receiver.
!
This product is designed to use only those parts
supplied with this product and/or any accessories
designated specifically for use with this product
by Emerson Electric Co. Substitution of parts or
accessories not designated for use with this product by
Emerson Electric Co. could result in personal injury
or property damage.
Figure 18
13
Please contact 1-800-654-3545 for further assistance
emersonfans.com
U.L. Model No.: CF205
5. How to Wire Your Ceiling Fan (Continued)
F
O
R
L
I
G
H
T
T
O
M
O
T
O
R
L
A
C
I
N
L
T
O
M
O
T
O
R
N
A
C
I
N
N
HANGER BALL, HANGER BRACKET, & SUPPLY GREEN
GOUNDING WIRES
WIRE
CONNECTOR
FO
R
L
I
G
HT
T
O
M
O
T
O
R
L
AC
IN L
AC
I
N
N
T
O
M
OT
OR
N
WIRE
CONNECTOR
SU PPLY A ND REC EIVER
WHITE WIRES
5.3
NOTE: Make all wiring connections using the wire
connectors supplied in the hardware kit and remote
control kit. Make sure that all connections are tight,
including ground, and that no bare wire is visible at
he wire connectors, except for the supply circuit
t
ground wire.
Connect the green grounding lead from the hanger ball
and the green grounding lead from the hanger bracket to
the grounding conductor of supply (this may be a bare
wire or wire with green colored insulation). Securely
connect wires with wire connectors (supplied in parts bag)
(Figure 19).
Figure 19
5.4
Securely connect the receiver white wire (AC IN N) to the
supply white wire (neutral) using the wire connector
(supplied in parts bag) (Figure 20).
Figure 20
U.L. Model No.: CF205
14
5. How to Wire Your Ceiling Fan (Continued)
F
O
R
L
I
G
H
T
T
O
M
O
T
O
R
L
T
O
M
O
T
O
R
N
A
C
I
N
N
A
C
I
N
L
WIRE
CONNECTOR
SUPPLY AND
RECEIVER
BLACK WIRES
T
O
M
O
T
O
R
L
T
O
M
O
T
O
R
N
A
C
I
N
N
A
C
IN
L
F
O
R
L
I
G
H
T
FAN AND
RECEIVER
WHITE WIRES
WIRE
CONNECTOR
5.5
ecurely connect the receiver black wire (AC IN L) to the
S
supply black wire (hot) using the wire connector (supplied
in parts bag) (Figure 21).
Figure 21
5.6
Securely connect the receiver white wire (TO MOTOR N)
to the fan motor white wire using the wire connector
(supplied in parts bag) (Figure 22).
15
Figure 22
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF205
5. How to Wire Your Ceiling Fan (Continued)
T
O
M
OT
OR
N
A
C
IN
N
A
C
I
N L
F
O
R
L
IG
HT
T
O
M
OT
OR
L
SU PPLY AND RE CEIV ER
BLACK WIRES
WIRE CONNECTOR
T
O
M
O
T
O
R
N
A
C
I
N N
AC IN L
T
O
M
O
T
O
R
L
F
OR
L
I
GH
T
WIRE CONNECTOR
SUPPLY AND RECEIVER
BLUE WIRES
5.7
Securely connect the receiver black wire (TO MOTOR L)
o the fan motor black wire using the wire connector
t
(supplied in parts bag) (Figure 23).
Figure 23
5.8
Securely connect the receiver blue wire (TO LIGHT) to the
fan motor blue wire using the wire connector (supplied in
parts bag) (Figure 24).
WARNING
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors, except for the supply circuit ground wire. Do
not operate fan until blades are in place.
Noise and fan damage could result.
NOTE: Failure to properly connect the receiver wires
will damage the device and render it non-operable.
!
Figure 24
U.L. Model No.: CF205
16
5. How to Wire Your Ceiling Fan (Continued)
WIRE
CONNECTORS
(Tucked Inside
Outlet Box)
STANDARD ON-OFF WALL
SWITCH OR OPTIONAL
SW406 WALL CONTROL
BLACK
BLACK
WHITE
RED
BLACK
WHITE
HANGER BALL
GREEN WIRE (GROUND) FROM
HANGER BALL AND HANGER
BRACKET
TWO-CONDUCTOR
CABLE
(WITH GROUND)
BLACK
(HOT)
WHITE
GROUND
TO
120-VOLT
SUPPLY
WHITE
BLUE
WHITE
BLUE
5.9
hile inserting the receiver fully into the hanger bracket,
W
turn leads upward and carefully push leads into the outlet
box, with the white and green leads on one side of the
outlet box and position the black and blue leads on the
other side of the outlet box (Figure 25).
WARNING
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors, except for the ground wire. Do not
operate fan until blades are in place. Noise and fan
damage could result.
!
5.10
Wiring Schematic for reference (Figure 26).
Figure 25
Figure 26
17
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF205
6. Ceiling Cover Installation
THREADED STUDS (2)
HANGER BRACKET
THREADED
STUD (2)
CEILING
COVER
KNURLED
KNOB (2)
LOCKWASHER (2)
6.1
Screw the 1-1/4” threaded studs into the threaded holes
on the bottom of the hanger bracket with your fingers
Figure 27).
(
Figure 27
6.2
Lift the ceiling cover up to the threaded studs and turn until
studs protrude through the holes in the ceiling cover
(Figure 28).
Secure the ceiling cover in place by sliding lockwashers
over the threaded studs and installing the two knurled
knobs (supplied in parts bag). (Figure 28).
Tighten the knurled knobs securely until the ceiling cover
fits snugly against the ceiling and the hole in the ceiling
cover is clear of the downrod.
WARNING
To avoid possible fire or shock, make sure that the
electrical wires are completely inside the outlet box and not
pinched between the ceiling cover and the ceiling.
WARNING
To avoid possible fire or shock, make sure that antenna
wire is not pinched between the ceiling cover and the
ceiling.
!
!
Figure 28
U.L. Model No.: CF205
18
7. Final Installation
L
IGHT KIT PLATE
LIGHT KIT PLATE
SOCKETS (2)
50-WATT MINI-CANDELABRA
BASE HALOGEN BULBS (2)
LIGHT KIT
PLATE
LIGHT KIT
LOWER
GLASS
FLAT AREA
WARNING
Turning off wall switch is not sufficient. To avoid possible
electrical shock, be sure electricity is turned off at the
main fuse box before wiring. All wiring must be in
accordance with National and Local codes and the ceiling
fan must be properly grounded as a precaution against
possible electrical shock.
!
7.1
Screw the two 50-watt mini-candelabra base halogen
bulbs (supplied) into the light kit plate sockets (Figure 29).
Do not touch the glass bulb; use the porcelain base to
screw in the bulb, or wear soft gloves.
CAUTION: To avoid risks of burns or other injury,
assure power is off before attempting to install or
replace the halogen bulbs.
NOTICE: Do not touch halogen bulbs with bare hands.
Fingerprints may result in shorter bulb life. Remove
fingerprints with alcohol.
Figure 29
7.2
Place the lower glass into the light fitter, aligning the three
flat areas on the top flange of the lower glass with the
three pins on the inside of the fitter (Figure 30). Then turn
the lower glass clockwise until it stops turning.
Your ceiling fan is now installed and wired to be controlled
by your wall control.
Figure 30
19
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF205
8. Disassemble Your Light Kit
LIGHT KIT PLATE
BLACK WIRE
BLUE WIRE
FAN MOTOR/
HOUSING
ASSEMBLY
WHITE
WIRES
LIGHT KIT
PLATE
CUT LIGHT
SOCKET
WIRES
CUT LIGHT
SOCKET WIRES
for Cover Plate Assembly Only
WARNING
Turning off wall switch is not sufficient. To avoid possible
electrical shock, be sure electricity is turned off at the
main fuse box before wiring. All wiring must be in
ccordance with National and Local codes and the ceiling
a
fan must be properly grounded as a precaution against
possible electrical shock.
CAUTION: To reduce the risk of electrical shock,
disconnect the electrical supply circuit before
installing the fan, light kit or receiver.
!
8.1
Detach the light kit plate from the fan motor/housing
assembly by removing one screw and loosening the two
other screws (located in the keyholes). Rotate the light kit
plate counter-clockwise to disengaging the screws in the
two key hole slots (Figure 31).
8.2
Disconnect the black wire of the light kit plate from the
black wire of the fan motor/housing assembly. Disconnect
the white wire of the light kit plate from the white wire of
the fan motor/housing assembly (Figure 32).
Figure 31
U.L. Model No.: CF205
Figure 32
20
8. Disassemble Your Light Kit
REASSEMBLE
LIGHT KIT
PLATE
REASSEMBLE
MOTOR SCREW (3)
REMOVE SOCKET
PLATE SCREWS
(2 per plate)
REMOVE SOCKET/
SOCKET PLATE (2)
LIGHT KIT
PLATE
LIGHT KIT
COVER
PLATE
FLAT
AREA
LIGHT KIT
PLATE
SOCKETS
REMOVED
for Cover Plate Assembly Only (Continued)
8.3
Cut light socket wires using wire cutters. Unscrew the
screws that is securing the socket plates to the light kit
plate. Pull socket wiring though light kit plate holes to
completely disengage the light sockets from light kit plate
(Figure 33).
Figure 33
8.4
Carefully tuck blue and white wires from motor up into the
fan motor/housing assembly (Figure 34).
Place the cover plate onto the fan motor/housing aligning
the three flat areas on the top flange of the cover plate
with the three pins on the inside of the fan motor/housing
(Figure 34).
Then turn the cover plate clockwise until it stops turning.
Your cover plate is now installed.
WARNING
To avoid possible fire or shock, make sure that the
electrical wires are completely tucked inside the lower
assembly and not pinched by the cover plate.
!
Figure 34
21
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF205
9. Remote Control Procedures
CODE
SWITCHES
REMOTE CONTROL
BATTERY
COMPARTMENT
COVER
REMOTE CONTROL
LEVERS
O
N
1
234
5 I
REMOTE CONTROL
BATTERY
COMPARTMENT
COVER
TWO AAA
BATTERIES
9.1: Preset Memory Feature
Your Emerson receiver is equipped with a preset memory
feature. If the AC supply to the receiver is powered
through a wall switch, when the switch is turned OFF, the
control will remember the light intensity and fan speed.
9.2: Installation of Batteries
The remote control transmitter is powered by two AAA
alkaline batteries (not included).
To prevent possible battery leakage damage, be sure to
remove the batteries when the control is not to be used for
an extended period of time.
Remove the battery cover by pressing firmly below the
arrow and sliding the cover off the remote control.
Install two new AAA alkaline batteries into the battery
compartment following the correct battery placement
printed on the compartment (Figure 35).
NOTE: Never use old and new batteries together in
unit.
When the switch is turned back ON the light and fan will
resume operation as they we re prior to the switch being
turned OFF.
Figure 35
Replace the battery compartment cover by sliding the
cover back onto the remote control.
9.3: Setting Operating Frequency
of Remote Control
Remove the battery cover by pressing firmly below the
ar row an d sliding the cover off the contro l
(Figure 36).
Your remote control has code switches which must be set
in one of 32 possible code combinations.
The five levers (numbered 1, 2, 3, 4, and 5) on the
switches are factory-set in the ON (up) position. Change
the switch settings as follows:
Slide the five switch levers in the remote control to your
choice of ON (up) or down positions. Use a ball-point pen
or small screwdriver and slide the levers firmly up or down
(Figure 36).
The sixth switch marked ON and I is for dimming control of
lights: Set switch to ON to allow for dimming of the lights.
Set switch to I for no dimming of the lights such as for
fluorescent bulbs.
Figure 36
NOTE: If your fan and light go on and off without
using your control, you may be getting interference
from other remote units such as garage door openers,
car alarms or security systems.
To remedy this situations, simply change the combination
code in your remote control transmitter.
U.L. Model No.: CF205
22
P
OWER INDICATOR
L
IGHT
OFF BUTTON
9. Remote Control Procedures (Continued)
HIGH TO LOW
BUTTONS
POWER INDICATOR
LIGHT
OFF BUTTON
9.4
When power is restored, push and hold the fan OFF
utton ( ) for 3 to 5 seconds to set the code in the
b
receiver (Figure 37).
OTE: The power indicator light on the remote control
N
will flash when the code is set.
Figure 37
WARNING
Fan installation must be completed, including the
installation of the fan blades, before testing the remote
control.
9.5
Your Emerson Ceiling Fan consists of hand-held remote
control transmitter and a receiver which is mounted under
the fan ceiling cover.
The remote control is designed to separately control your
ceiling fan speed and light intensity (Figure 38).
There are four push buttons (.,..,
speed and turn the fan off.
!
...,....
) to set the fan
Figure 38
23
Please contact 1-800-654-3545 for further assistance
emersonfans.com
U.L. Model No.: CF205
9. Remote Control Procedures (Continued)
TO INSTALL BRACKET TO
WALL:
SLIDE THE COVER UP TO
EXPOSE THE SCREW
HOLES FOR INSTALLATION
COVER
WALL
BRACKET
SCREW
HOLES (2)
TO INSTALL BRACKET
TO WALL:
INSTALL THE TWO SCREWS
SLIDE THE COVER DOWN
WALL
BRACKET
SCREWS (2)
COVER
HIGH TO LOW
BUTTONS
POWER INDICATOR
L
IGHT
LIGHT BUTTON
9.6
The light ( ) push button turns the light on and off and
controls the light intensity (Figure 39).
To vary the int ensity of the light, hold the
( ) button down until the desired light intensity is
eached, then release the button (Figure 39).
r
NOTE: When turning the light on, light will turn on at
the light intensity previously selected.
Your remote control has full control of your fan and light.
The power indicator light (blue glow) will illuminate while
any button is pressed, indicating that the battery is good.
9.7: Storage Bracket Installation
A storage bracket is provided for holding your remote
control when not in use. If you desire to use the bracket,
install it on a wall that is away from excess heat or
humidity.
Figure 39
Slide the wall bracket cover up to expose the screw holes
for installation (Figure 40).
Position the bracket on the wall in desired location.
9.8: Storage Bracket Installation
Install the two screws (provided with bracket) into the wall
bracket and tighten to secure to wall (Figure 41).
Slide the wall bracket cover back down over the screws.
Figure 40
Figure 41
U.L. Model No.: CF205
24
10. Reverse Switch Operation
COUPLING
COVER
MOTOR
HOUSING
REVERSE
SWITCH
10.1
Restore electrical power to the outlet box by turning the
electricity on at the main fuse box.
All fans are shipped from the factory with the reversing
switch positioned “left” to circulate air downward.
If airflow is desired in the opposite direction, turn the fan
off and wait for the blades to stop turning.
Then slide the coupling cover up, push the reversing
switch in opposite direction (Figure 42).
Slide coupling cover down to rest on motor housing and
turn the fan on again. The blades will turn in the opposite
direction and reverse the airflow.
The fan blades will turn in the opposite direction and
reverse the airflow.
Reverse Switch Information
Season Rotation Direction Switch Position
Summer Counter-Clockwise Left
Winter Clockwise Right
Figure 42
11. Accessories
See your local Emerson dealer, www.emersonfans.com
or the Emerson Ceiling Fan catalog for these accessories:
• Ceiling Fan Receiver / Remote Controls
• Downrod Extension Kits
• Slope Ceiling Kit
WARNING
The use of any other control not specifically approved for
this fan could result in fire, shock and personal injury.
!
WARNING
This product is designed to use only those parts supplied
with this product and/or any accessories designated
specifically for use with this product by Emerson Electric
Co. Substitution of parts or accessories not designated
for use with this product by Emerson Electric Co. could
result in personal injury or property damage.
!
25
Please contact 1-800-654-3545 for further assistance
emersonfans.com
U.L. Model No.: CF205
12. Repair Parts
3
2
1
5
4
15
16
6
7
18
18
16
19
9
24
11
8
14
10
21
20
23
25
22
22
12
PARTS BAG
27
29
28
26
13
4
5
6
7
8
9
10
11
12
13
U.L. Model No.: CF205
26
12. Repair Parts Listing
Model Numbers
Key
No. Description CF205BS01 CF205GES01 CF205GRT01 CF205VS01
* Hanger Pack,
Consisting of: 761655-74 761655-39 761655-103 761655-91
1 Hanger Bracket — — — —
2 Hanger Ball — — — —
3 12” Downrod — — — —
* Parts Bag, Containing: 763596 763596-1 763596-1 763596-1
4 Wire Connector (7) — — — —
5 Threaded Stud, 8-32 x 1-1/4” (2) — — — —
6 Knurled Knob (2) — — — —
7 Lockwasher (2) — — — —
8 Hairpin Clip — — — —
9 Clevis Pin — — — —
10 Screw, Oval Head, 10-24 x 9 mm (10) — — — —
11 Screw, Pan Head, 1/4-20 x 11 mm (7) — — — —
12 Screw, Pan Head, #8-32 x 10 mm and lockwashers (1) — — — —
13 Blade Balance Kit — — — —
14 Decorative Blade Nuts (9) 763599-BS 763599-GES 763599-GRT 763599-VS
15 Cover, Ceiling 763592-BS 763592-GES 763592-GRT 763592-VS
16 Support Assembly, Rod 762709-BS 762709-GES 762709-GRT 762709-VS
17 Rod Assembly, Decorative (3) 762710-BS 762710-GES 762710-GRT 762710-VS
18 Screw, Decorative Rod (6) 762711-BS 762711-GES 762711-GRT 762711-VS
19 Cover, Coupler 762708-BS 762708-GES 762708-GRT 762708-VS
20 Blade Set (full set for one fan) 763601 763601-1 763601-CR/TM 763601-2
21 Flange Set (full set for one fan) 763597-BS 763597-GES 763597-GRT 763597-VS
22 Harness Assembly, Wiring 763595 763595 763595 763595
23 Fitter Assembly, Light 763603-BS 763603-GES 763603-GRT 763603-VS
24 Glass, Lower 763605 763605-1 763605 763605-2
25 Cover Plate 763609-BS 763609-GES 763609-GRT 763609-VS
26 Bulb, Halogen, 50-watt Mini-Candelabra Base — — — —
27 Downrod, 6” 761631-32 761631-44 761631-117 761631-104
28 Transmitter, Remote Control, SR401 764090 764090 764090 764090
29 Receiver 764089 764089 764089 764089
— Owner's Manual BP7375-3 BP7375-3 BP7375-3 BP7375-3
Bef
ore discarding packaging material, be certain all parts have been removed.
HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION:
•
PART NUMBER
•
PART DESCRIPTION
The model number of your Fan will be found on a label attached to the top housing.
For repair parts, phone 1-800-654-3545.
•
NAME OF ITEM
•
MODEL NUMBER
27
Please contact 1-800-654-3545 for further assistance
emersonfans.com
U.L. Model No.: CF205
13. Maintenance
MPORTANT CARE INSTRUCTIONS
I
for your Ceiling Fan
Periodic cleaning of your new ceiling fan is the only
maintenance that is needed.
When cleaning, use only a soft brush or lint free cloth to
avoid scratching the finish.
Abrasive cleaning agents are not required and should be
avoided to prevent damage to finish.
14. Troubleshooting
o not use water when cleaning your ceiling fan.
D
It could damage the motor or the blades and create the
possibility of an electrical shock.
!
WARNING
WARNING
!
FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE
TROUBLESHOOTING YOUR FAN.
TROUBLE PROBABLE CAUSE SUGGESTED REMEDY
1. Fan will not start. 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers.
2. Reversing switch in neutral position. 2. Make sure reversing switch position is all the way to
one side.
2. Fan sounds 1. Blades not attached to fan. 1. Attach blades to fan before operating.
noisy.
are snug (not over-tight).
3. Screws securing fan blade flanges to 3. Check to make sure the screws which attach
motor hub are loose. the fan flanges to the motor hub are tight.
4. Screws holding blades to flanges 4. Tighten screws securely.
are loose.
3. Fan wobbles 1. Setscrews in motor coupler are loose. 1. Tighten both setscrews securely in the motor coupler.
assembly is loose. assembly.
3. Screws securing fan blade flanges to 3. Check to be sure screws which attach the fan
motor are loose. blade flanges to the motor are tight.
4. Fan blade flanges not seated properly. 4. Check to be sure the fan blade flanges seat
firmly and uniformly to the surface of the motor.
If flanges are seated incorrectly, loosen the
flange screws and retighten according to the
procedure in the section on "Ceiling Fan Assembly”.
5. Hanger bracket and/or ceiling outlet 5. Tighten the hanger bracket screws to the outlet
box is not securely fastened. box, and/or secure outlet box.
6. Fan blades out of balance. 6. Interchanging an adjacent (side-by-side) blade pair can
redistribute the weight and result in smoother operation.
2. Loose screws in motor housing. 2. Check to make sure all screws in motor housing
excessively.
2. Setscrew in hanger ball/downrod 2. Tighten the setscrew in the hanger ball/downrod
Make sure main power is turned OFF.
!
WARNING
U.L. Model No.: CF205
28
Emerson Air Comfort Ceiling Fan Limited Warranty
What The Limited Warranty Covers:
This limited warranty is offered by Air Comfort Products division of Emerson Electric Co. ("Emerson" "we" or "us") located at the address stated below to the original retail
purchaser ("you" or "your") of an Emerson Air Comfort Ceiling Fan product ("Emerson Ceiling Fan") and covers the motor and the other components and accessories of the
Emerson Ceiling Fan against all defects in workmanship and materials.
What The Period Of Coverage Is:
This limited warranty will cover the Emerson Ceiling Fan motor for the expected lifetime of your Emerson Ceiling Fan (when operated in accordance with your Owner's Manual or
other instructions provided by Emerson to you with the Emerson Ceiling Fan). All other components and accessories of the Emerson Ceiling Fan are covered by this limited warranty
for a period of one (1) year from its date of original retail purchase. ANY IMPLIED WARRANTY, INCLUDING WITHOUT LIMITATION, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE THAT IS AVAILABLE TO YOU UNDER THE LAWS OF YOUR STATE OR PROVINCE SHALL COVER THE
MOTOR FOR THE EXPECTED LIFETIME OF THE MOTOR (SUBJECT TO PROPER USE), AND FOR ONE YEAR WITH RESPECT TO COMPONENTS AND ACCESSORIES.
No Other Express or Implied Warranty Applies:
THE LIMITED WARRANTIES PROVIDED ABOVE ARE THE SOLE AND EXCLUSIVE WARRANTIES PROVIDED BY EMERSON TO YOU FOR YOUR EMERSON CEILING FAN,
AND ARE IN LIEU OF ALL OTHER WARRANTIES, WRITTEN OR ORAL, EXPRESS OR IMPLIED, WHETHER ARISING BY OPERATION OF LAW OR OTHERWISE, WHETHER
OR NOT THE PURPOSE HAS BEEN DISCLOSED AND WHETHER OR NOT THE EMERSON CEILING FAN HAS BEEN SPECIFICALLY DESIGNED OR MANUFACTURED FOR
YOUR USE OR PURPOSE. EMERSON HEREBY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE FOR COMPONENTS AND ACCESSORIES AS OF THE EXPIRATION OF THE ONE YEAR WARRANTY
PERIOD FOR SUCH COMPONENTS AND ACCESSORIES. IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE FOR THE MOTOR
PORTION OF THE EMERSON CEILING FAN ARE LIKEWISE DISCLAIMED BY EMERSON AT SUCH TIME THAT THE EXPECTED LIFETIME OF THE EMERSON CEILING FAN
UNDER NORMAL USAGE HAS BEEN REACHED. EXCLUSIONS OR LIMITATIONS OF IMPLIED WARRANTIES MAY VARY FROM STATE TO STATE AND PROVINCE TO
PROVINCE SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
What We Will Do To Correct Problems:
If during the one (1) year warranty period the motor or any component or accessory of your Emerson Ceiling Fan is defective in materials or workmanship, or if during the expected
lifetime of the Emerson Ceiling Fan (when used in accordance with the User Manual or other instructions) the motor is defective in materials or workmanship, you must contact
Emerson during the applicable warranty period. If the defect is covered by warranty, Emerson will repair or replace the defective motor, component or other accessory at no charge
to you. If repair of the motor, component or accessory is not practical or possible within a reasonable time and no replacement Emerson Ceiling Fan can be provided, Emerson will
refund to you the actual purchase price of your Emerson Ceiling Fan. We will ship the repaired or the replacement Emerson Ceiling Fan to you at no charge, but you are responsible
for all costs of removal and reinstallation of your Emerson Ceiling Fan.
How You Can Receive Warranty Service:
You must be the original retail purchaser and have proof of your purchase of the Emerson Ceiling Fan to obtain your remedy under this limited warranty. You can return your
Emerson Ceiling Fan to your place of purchase, or you can call Emerson Customer Service at 1-800-237-6511 to obtain a return authorization and service identification tag. In order
for us to confirm that your Emerson Ceiling Fan is still under warranty, please retain your receipt or other proof of purchase and have that information readily available when returning
your Emerson Ceiling Fan to your place of purchase, or upon calling Emerson Customer Service. If you call Emerson Customer Service, prior to your call please be prepared to
provide all model numbers shown on your Emerson Ceiling Fan. Once we have processed your return authorization request, we will provide you with a postage paid return label
which should be affixed to the Emerson Ceiling Fan package you ship to the address listed at the end of this limited warranty. The return label will be sent to the mailing address you
provide to us by phone.
What Is Not Covered:
This limited warranty does not extend to and expressly excludes:
• The glass globes and light bulbs of your Emerson Ceiling Fan,
• Loss or damage to the motor or any component or accessory caused by normal wear and tear, rather than due to defects in materials or workmanship,
• Loss or damage resulting from conditions beyond our reasonable control, including without limitation, repairs not made at our factory or authorized service center, use of parts or
accessories not provided to you as part of this warranty by our factory or authorized service center, mishandling, unreasonable use, misuse, abuse, modifications or other
damage caused by you or a third party to your Emerson Ceiling Fan while not in our possession,
• Loss or damage resulting from improper installation, or other failure to comply with instructions in your Owner's Manual.
This limited warranty is deemed null and void upon the occurrence of either of the following events:
• You cease to own the Emerson Ceiling Fan product, or
• The Emerson Ceiling Fan is moved from its original point of installation.
This limited warranty is only valid within the 50 United States, the District of Columbia, and Canada. No other written or oral warranties apply, and no employee, agent, dealer or
other person is authorized to give any warranties on behalf of Air Comfort Products or Emerson Electric Co.
Limitation of Liability
REPAIR, REPLACEMENT OR A REFUND ARE THE EXCLUSIVE REMEDIES AVAILABLE TO YOU UNDER THIS LIMITED WARRANTY. TO THE EXTENT PERMITTED BY LAW,
IN NO EVENT SHALL EMERSON OR ANY EMERSON AUTHORIZED DEALER BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,
INCLUDING ANY ECONOMIC LOSS, WHETHER RESULTING FROM NONPERFORMANCE, USE, MISUSE OR INABILITY TO USE THE EMERSON CEILING FAN OR FOR THE
NEGLIGENCE OF EMERSON OR AN EMERSON AUTHORIZED DEALER. EMERSON SHALL NOT BE LIABLE FOR DAMAGES CAUSED BY DELAY IN PERFORMANCE AND
IN NO EVENT, REGARDLESS OF THE FORM OF THE CLAIM OR CAUSE OF ACTION (WHETHER BASED IN CONTRACT, INFRINGEMENT, NEGLIGENCE, STRICT
LIABILITY, OTHER TORT OR OTHERWISE), SHALL EMERSON'S OR ANY EMERSON AUTHORIZED AGENT'S LIABILITY TO YOU OR ANY INDIVIDUAL USING THE
EMERSON CEILING FAN EXCEED THE PRICE PAID BY THE ORIGINAL OWNER FOR THE EMERSON CEILING FAN. The term "consequential damages" shall include, but not
be limited to, loss of anticipated profits, business interruption, loss of use or revenue, cost of capital or loss or damage to property or equipment.
How State and Provincial Law Relates To The Warranty:
Some states and provinces do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion or limitation may not apply to you. This limited
warranty gives you specific legal rights, and you may also have other rights which vary from state to state or province to province.
29
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF205
SERIAL NUMBER: DATE CODE:
The serial number of this fan can be found on the nameplate on top of the fan housing. The date code can be
found on the carton and on top of the fan housing, stamped in ink on a white label. You should record this data
above and keep it in a safe place for future use.
Air Comfort Products
DIVISION OF EMERSON ELECTRIC CO.
8100 W. Florissant • St. Louis, MO63136
Questions, problems, missing parts: Before returning to the store call
Emerson Electric Customer Service
8 a.m. - 6 p.m., Eastern, Monday-Friday
1-800-654-3545
www.emersonfans.com
Retain this manual for future use.
Part No. F40BP73750003 Form No. BP7375-3
Revision: 161201 U.L. Model No.: CF205
Printed in China
12/16
Loading...
