ASCO 641 Lighting Contactor Panel

Standard and Custom Solutions for Area and Security Applications

The ASCO 641 Lighting Control Panel offers contractors
a complete, single-enclosure solution that includes
multiple ASCO Lighting Contactors and a range of
related controls and accessories. It saves space and can
be installed quickly, with a minimum of on-site wiring.

ASCO 641 Lighting Contactor Panel Array

ASCO 918 Lighting Contactor

1

2

Control Switch

Hands Off Auto

3

All 641 Lighting Con­trol Panel components are
factory wired and tested to
help ensure proper system
operation and long-term reli­ability. Integrating compo­nents into a single enclosure
eliminates the need to order
from multiple manufacturers
and the scheduling, billing
and multiple contacts that
requires.

standards. In fact, certain
lighting contactors are UL
listed for short circuit with­stand current ratings.

The panel also is fully
documented to ease trouble­shooting, if ever necessary.
It’s based on ASCO’s 100­year tradition of applied
technology and the quality
assurance that’s designed
into every ASCO product.

The ASCO-engineered

panel meets applicable code

6

3

4

Power Fusing

5

Customer Terminal

Time Clock

6

5

4

Custom configurations can include a range of controls and acces­sories to complement one or more ASCO Lighting Contactors.

1

2

ASCO 918 Product Description Offering

Standard Configurations

918 6 20 3 1 0

Product Open Frame

918

Notes : 1. 4 pole units only available on Standard 641 units not Custom.

2. Subpanels are standard with all 641 product.

3. All 641 units will be open frame 918 individual units.

# of Poles Amps

4
6
8

12

20

Voltage Sub-Panel

3 = 110-120V
6 = 208-240V
7 = 265-277V

1 0

The 918 Lighting Contactor Is the Heart of the 641 Lighting Control Panel

The ASCO 918 Remote
Control (RC) Lighting Contac­tor is the heart of the ASCO
641 Lighting Control Panel.

It provides reliable and

Distinguishing Features

convenient lighting control
in a variety of applications.
It is rated at 30 amperes to
600 volts AC and is listed to
UL 508.

Solid-state control mod­ules enable energy manage­ment systems, microproces­sors, photoelectric cells,
timers and similar control
devices to manage the light­ing contactor.

A Range of Lighting
Control Applications

Performance Features

• 3 standard models to choose from

• Feature ASCO 918 RC Contactors. (electrically operated,
mechanically held, designed for lighting applications)

• Quieter operation (no AC hum)

• Longer life expectancy for contactor

• Fully rated for all types of lighting loads, including metal
halide, mercury vapor, quartz halogen, tungsten, and uo­rescent

Construction Features

• All controls, except for photocell, in common Type 1 enclo­sure (Type 12, 3R, 4, and 4X enclosures are available)

• Available in 6 or 12 pole design

• ASCO 918 visual position indicators show open/closed
position of each main contact

• ASCO 918 line, load, and control terminals accept no. 18 to
no. 10 AWG wire

• Large dial, multifunction 7-day timer with reserve power
feature or digital time clock with battery backup (Models
641A, 641 S)

• Clamp-type, self-rising terminal plates for solderless con­nection with the screws for fast termination

Electrical Features

• Available 120 or 277 V, 60 Hz control

• All control wiring stranded #14 AWG

• UL 1015 Red wiring

• Terminal block for all incoming wiring

• Fused power circuit

• UL Listed to UL508 Industrial Controls

• Rated 20 amps to 600 VAC (30 amps general purpose)

• Fully rated for all types of lighting loads

• High withstand current ratings

The lighting control
panel is ideally suited for
ballast lighting, tungsten
and general-purpose loads.
The ASCO 641A Lighting
Contactor Panel satises
requirements of large-area
applications. 641S meets
requirements for security ap­plications and 641 AS meets
requirements for both.

Applications include
large areas, stadium park­ing garages and facilities
using TOD (Time of Day)
photo-sensor control for
automatic on-off operation.
Other applications are signs,
interior and exterior build­ing lighting, interior safety
lighting, recreational lighting
and applications suitable for
manual on-off operation.

The 641 Lighting Control
Panel is available in standard
and highly customized con­gurations. Three standard
congurations offer quicker
delivery, while customized
congurations offer the ex­ibility to tailor performance
to site-specic requirements.

Standard panels feature the
ASCO 918 Lighting Contac­tor that’s based on ASCO’s
electrically operated, me­chanically held solenoid
operator that also is the heart
of all ASCO power transfer
switches.

The solenoid does not rely
on magnetic latches or
impressed current to main­tain contacts in the open or
closed position. The contac­tor offers quieter operation,
longer life expectancy and
eliminates the continuous
power drain associated with
electrically held solenoid
designs.

This contactor is specically
designed for metal halide,
mercury vapor, quartz halo­gen, tungsten and uores­cent lighting systems.

Custom Configurations

Custom congurations for
comprehensive lighting con­trol requirements can include
up to 10 lighting contactors
in one enclosure, in addition
to related controls and acces­sories.

Besides the 918 Lighting
Contactor, the panel also
is available with the 920
Lighting Contactor. Panels
congured with 920 Light­ing Contactors become the
ASCO 642 Lighting Contactor
Panel.

Controls and accessories can
include relays, building man­agement interfaces, time
clocks, photocell interfaces,
pilot lights, control switches,
power fusing, and other func­tionalities.

ASCO 641 Standard Lighting Control Units

Catalog Number Poles Voltage Time Clock

ASCO 641 Standard Lighting Control Units
(Area & Security)

641AS043CPDST
641AS083CPDST
641AS123CPDST
641AS047CPDST
641AS087CPDST
641AS127CPDST

641AS043CPD7
641AS083CPD7
641AS123CPD7
641AS047CPD7
641AS087CPD7
641AS127CPD7

641AS043CTM7
641AS083CTM7
641AS123CTM7
641AS047CTM7
641AS087CTM7
641AS127CTM7

Note: All Units Include (2) 918 20A Contactor with (2) Accessory 47 - 2- Wire
Control voltage and (2) 53B - Hands Off Auto Control switch mounted on the
front of the enclosure.

4
8

12

4
8

12

4
8

12

4
8

12

4
8

12

4
8

12

120

277

120

277

120

277

Intermatic

365-Day Digital

Display Timer

Intermatic
7-Day LCD

Display Timer

Intermatic

7-Day Electro

Mechanical

Timer

641 Available Options

• Control switches 2 & 3 – Wire

• Hands off Control – 3 position selector switch

• Momentary Toggle switch Hands off with Center off posi­tion

• Double Throw Aux Contacts

• Photocell (Shipped Loose)

• Push Button Controls

• Pilot Lights/Alarm Lights

• Control Power Transformers

• Time Clock (Intermatic Tork Name brands)

• Control Relays

• Terminal Blocks

• Control circuit fuses

Catalog Number Poles Voltage Time Clock

641S043C
641S083C
641S123C
641S047C
641S087C
641S127C

641AS043CPDST
641AS083CPDST
641AS123CPDST
641AS047CPDST
641AS087CPDST
641AS127CPDST

641AS043CPD7
641AS083CPD7
641AS123CPD7
641AS047CPD7
641AS087CPD7
641AS127CPD7

641AS043CTM7
641AS083CTM7
641AS123CTM7
641AS047CTM7
641AS087CTM7
641AS127CTM7

Note: All (S) Security Units Include (1) 918 20A Contactor with (1) Accessory 47 ­2- Wire Control voltage and (1) 53B - Hands Off Auto Control switch mounted on
the Front of the enclosure.

4
8

12

4
8

12

4
8

12

4
8

12

4
8

12

4
8

12

4
8

12

4
8

12

120

277

120

277

120

277

120

277

N/A

Intermatic

365-Day Digital

Display Timer

Intermatic
7-Day LCD

Display Timer

Intermatic

7-Day Electro

Mechanical

Timer

Configure an
ASCO 641 Lighting
Contactor Panel ac­cording to your facil­ity’s specific lighting
requirements.

The range of ac­cessories and related
control products
provide a high degree
of customization.

ASCO 641 Optional Accessories

Accessory Description

47
48

53B

53BK

53A

53AK

14H

14HA

9A/B

Solid state control module for 2-wire control
Solid state control module for 3-wire control
Hands off auto 3 position selector switch with center off position
Key operated hands off auto 3-position selector switch with center off
position
Momentary toggle switch with center off position for 3-wire control
Keyed momentary toggle switch with center off position for 3-wire control
One (1) form C one pole double throw aux contact
Two (2) form C one pole double throw aux contact
(2) indicating lights on/off

ASCO 641 Lighting Contactor Panel

ASCO 641 Timers

Standard

Timers

Code - PDST

Code - PD7

Code - TM7

Optional

Timers

T1
T2
T3
T4
T5
T6
T7
T8

ASCO 641 Ordering Information

Product

641

918

+

# of 6

Pole

1
2

3
4

5
6

7
8
9

10

12 20

+ +

# of 12

Pole

1
2

3
4

5
6

7
8
9

10

Timer

Descriptions

Intermatic - 365 Day Digital Display
Intermatic - 7 Day LCD Display
Intermatic - Electro Mechanical 7 - Day Time Dial
Tork - 7 or 365 Day LCD Display
Tork - 7 - Day LCD Display
Intermatic - 7 - Day 2 - Output Astro Digital Display
Tork - 365 Day 2 - Output LCD Display
Intermatic - 365 Day (4) Output Digital Display

Amps

20 A

+

Photocell

0 = No

Photocell

Note 1:P

Photocell

P

OR

=

T1 C

+

Timeclock

T1
T2

T3
T4

T5
T6

T7
T8

+

F

L

H

G

Enclosure

C

(Standard)

(Outdoor)

Type 1

Type 3R

Secure

Type 12

Type 4X

Type 4

+

2

Size of Enclosure

1 = 1-2 Units

2 = 2-3 Units

3 = 3-4 Units

4 = 4-6 Units

5 = 6-9 Units

Note : Maximum (10) 918’s based on combination of 6 and 12 pole units
Note : Unit is combination of contactors and timeclocks.
