1 Introduction
Preface
Welcome to the world of wireless internet, eMail, messaging, word processing
and MP3s. This webbook is your gateway to a truly mobile life and a whole new
way to keep in contact with friends, family & colleagues, get access to the web,
and relax with music, photos and videos.
Please read this user manual carefully to help you get the most out of your
webbook. Also please observe the safety warnings so you don’t damage your
webbook or more importantly yourself. A full support site and trouble-shooting
tips are available at www.elonex.com/support
Specification
Package Contents
Your package includes the following contents:
webbook
Power Adapter (2 parts)
User Manual
3
2 Appearance
4
1. LAN port
2. USB 2.0 Port
3. LCD Display Panel
4. Keyboard
5. Touch pad
6. Microphone jack
7. Headphone jack
8. Memory Card slot
9. Caps Lock indicator
10. Read Activity indicator
11. Power indicator
12. Number lock indicator
13. Wireless LAN activity indicator
14. Charger indicator
15. DC in jack (for power)
16. VGA port
17. USB 2.0 Port
18. USB 2.0 Port
19. Power Button
20. Battery
21. Display on/off switch
22. Drive Caddy
23. Memory
24. Speakers
The following key explains the webbook’s various ports and sockets:
5
3 Using your webbook
Getting Started
After unpacking your webbook please check you have all the package contents
and they are in good order. If you are missing anything or any item has been
damaged please contact the store you purchased your webbook from, or call
customer services on 0870 087 0168.
Power and Battery Charging
The webbook has a rechargeable
battery which will give you usage on
the move when fully recharged. You
can also use the power adapter
plugged into mains electricity for
continuous use (the webbook will
recharge its battery while in
operation).
Elonex recommends that the first time you charge your battery you should
charge it for 8 hours to get the best battery life from your webbook. Plug the
power adapter into the power port (see Appearance) and mains electricity.
When the battery is charging the Charging Indicator (14) will go orange, when
fully charged it will turn green. To turn your webbook on, press the Power
Button (19) and wait for the operating system to fully load.
Shutting Down
When you have finished using your webbook you can shut down using the
following procedure;
Full system shutdown: use the Shut Down function of the operating system to
fully shut the software and hardware down.
Low power shutdown: when the webbook detects that its battery is very low it
will automatically power down. It is recommended that you regularly save your
work to prevent any data loss when this happens.
Note: If the system crashes due to an unknown cause press and hold the power
button to force a shutdown. You can then start up normally.
6
Software
Your webbook comes with the operating system preinstalled. This is either
Linux or Windows XP depending on which model you’ve chosen. It is, however,
possible to upgrade the operating system from Linux to Windows XP along with
a new larger hard drive. Please see in-store for details or call customer services
on 0870 087 0168.
We recommend that you do not install Windows XP if you have less than 4GB of
storage on your webbook. You can find webbook drivers on the CD that
accompanies your XP upgrade/in this pack if you already have Windows XP. You
will need these drivers if your change or re-install your operating system.
Windows XP is a registered Trademark of Microsoft Corporation
Inputs and Outputs
The webbook has a number of inputs and outputs to give you a truly versatile
way to incorporate it into your daily life.
USB Ports The webbook is compatible with a whole range of USB devices
including wristVAULT, which lets you transfer and store music, photos, video
and documents on your wrist, so they are always to hand.
Microphone and Headphone Jacks Let’s you input and output music to and
from your webbook. Play your favourite music through the webbook’s onboard
speakers or out to headphones or external speakers.
Memory Card Slot Transfer photos quickly and easily from your digital camera
to the webbook using the memory card slot (compatible with MMC, SD and MS
memory cards) so you can eMail or upload them to the internet to share the
fun with your friends and family.
VGA output You can use this connection to output your screen to another
monitor, projector or VGA enabled TV. (Requires a 15 pin VGA Cable)
Please check the minimum requirements of any accessories to ensure compatibility
7
4 Important Safety Precautions
Please read
Please read and follow all these safety instructions and precaution. Failure to do
so may result in damage to your webbook or yourself, and may invalidate your
warranty.
CAUTION- To reduce the risk of electrical
shock do not remove the cover as there are
no user serviceable parts inside. Refer all
servicing to Elonex Service Personnel only.
To prevent fire or shock hazard, do not use near water or expose the unit
to rain or moisture. Do not spill any kind of liquid on the unit.
Do not block any ventilation openings, adequate ventilation is essential
to prevent heat build up that can reduce the service life of your unit or
lead to failure of electronic components.
Avoid exposing the unit to direct sunlight. Do not place the unit near any
heat sources such as radiators, heaters, stoves, or naked flame sources.
Do not place next to any sources of EM or magnetic radiation, eg
microwaves, large speakers
Do not drop or push any objects into holes or slots in the case.
Always store your unit carefully and avoid shocks or dropping.
Power Safety
It is advised that you unplug the unit from mains electricity during
prolonged periods of unuse or during lightning storms.
Avoid directly pulling out the power cord when unplugging from the
mains, switch the mains off first.
Before running out of power plug in the adapter to recharge the battery
to prevent any data loss.
8
Cleaning
Before cleaning always shut down your unit and unplug the power adapter. You
should clean with an anti-static dry cloth only. Do not clean with water,
abrasive cleaners or any other fluid.
Ergonomics
Here are some suggestions on how to best position and use your webbook:
The top of the LCD should be slightly below eye-level or slightly below and
directly in front of you. Sit with good posture and use a chair which offers good
back support (especially lower-back). The seat should allow your feet to rest
flat on the floor. Where possible, illuminate your working environment with
natural daylight or use a non-flickering light source.
Place the keyboard and mouse so that your arms are at your sides and your
forearms are roughly parallel to the floor. Take a break, get up, stretch, flex
your wrists, walk about, and look at something other than your screen for
about 10 minutes every hour.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your
warranty and expose you and the computer to electric shock. Refer all servicing
to authorised service personnel.
Customer Service and Warranty
For customer service, technical queries or warranty related issues please call
our helpdesk on 0870 087 0168
9
