Elonex eTouch 1000ET User Guide

Important Safety Instructions

1. All the safety and operating
instructions should be read before
the product is operated.

2. Retain Instructions
The safety and operating
instructions should be retained for
future reference.

3. Heed Warnings
All warnings on the product and in
the operating instructions should be
adhered to.

4. Follow Instructions
All operating instructions should be
followed.

5. Cleaning
Unplug this product from the wall
outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.

6. Attachments
Do not use attachments not
recommended by Elonex as they
may cause hazards.

7. Water and Moisture
Do not use this product near water
for example, near a kitchen sink
etc.

8. Accessories
Do not place this product on an
unstable surface. The product may
fall, causing injury or damage to
the product.

9. Cleaning
If fingerprints or dust make the LCD
screen dirty, we recommend using
a soft, non-abrasive cloth to clean
the LCD screen. Please do not
apply too much pressure as this
may cause damage to your
screen.

If you use an LCD Cleaning Kit,
apply the cleaning liquid to the
cloth. Do not apply the liquid
directly to your LCD screen

10. Ventilation
Slots and openings in the cabinet
are provided for ventilation and to
ensure reliable operation of the
product and to protect it from
overheating, and these openings
must not be blocked or covered.

11. Power Sources
This product should be operated
only from the type of power source
indicated on the marking label.

12. Grounding
This product should only be used
with proper electrical grounding.
Please only use power supplies
supplied by Elonex as this may
cause damage to the electronics
or injury to yourself.

13. Power Cord Protection
Power supply cords should be
routed so that they are not likely to
be walked on or pinched by items
placed upon or against them.

10” eTouch™ User Guide to Android™

14. Outdoor Antenna Grounding
If an outside antenna or cable
system is connected to the
product, be sure the antenna or
cable system is grounded so as to
provide protection against voltage
surges and built-up static charges.

15. Lightning
For added protection for this
product during a lightning storm, or
when it is left unattended and
unused for long periods of time,
please unplug it from the power
socket and disconnect the
antenna or cable system.

16. Power Lines
An outside aerial system should not
be located in the vicinity of
overhead power lines or other
electric light or power circuits, or
where it can fall into such power
lines or circuits. When installing an
outside antenna system, extreme
care should be taken to keep from
touching such power lines or
circuits as contact with them might
be fatal.

17. Overloading
Do not overload wall outlets,
extension cords, or integral
convenience receptacles, as this
can result in a risk of fire or electric
shock.

18. Object and Liquid Entry
Never push objects of any kind into
this product through openings as
they may touch dangerous voltage
points or short-out parts that could
result in a fire or electric shock.

Never spill liquid of any kind on the
product.

19. Servicing
Do not attempt to service this
product yourself as opening or
removing covers may expose you
to dangerous voltage or other
hazards. Refer all servicing to
qualified service personnel.

20. Damage Requiring Service
Unplug this product from the wall
outlet and refer servicing to
qualified service personnel. Please
refer all warranty claims to Elonex
Warranty Service.

21. Replacement Parts
Only use replacement parts
specified by Elonex. Unauthorized
substitutions may result in damage
to your unit.

22. Safety Check
Upon completion of any service or
repairs to this product, ask the
service technician to perform
safety checks to determine that the
product is in proper operating
condition.

23. Heat
The product should be situated
away from heat sources such as
radiators, heat stoves, or other
products that produce heat.

24. EM
The product should be situated
away from all sources of Electro
Magnetic radiation, ie microwaves,
amplifiers, speakers etc.

Introduction

Thank you for purchasing the Elonex eTouch.

Before using the unit, please read this manual thoroughly and retain it
for future reference. This manual will help you get the best out of your
eTouch, as well as what to do in case you experience any issues.

Technical Support

To help you get the best out of your product we provide you with a
limited 1 year Return to Base Warranty and Support Helpdesk (terms
and conditions apply).

For all technical support please contact our helpdesk using the details
below:

If you have any problems or questions

please DON’T take your eTouch™ back to the store

Please contact us for some helpful advice.

For all technical support issues or warranty issues please contact our
helpdesk:

Its well worth checking the Elonex support website at
(www.elonex.com/support) for Frequently Asked Questions (FAQs),
helpful hints, as well the latest firmware updates that become available
over time.

10” eTouch™ User Guide to Android™

Getting Started

Package Contents

When you open your box please check your package is complete and
all items are in good order.

Your box should contain:

• 10” eTouch 1000ET

• DC Power Adapter

• Information Booklet

• Warranty card

If you have anything missing or any items are damaged please contact
your place of purchase.

Setting up your eTouch

Open the package and carefully remove the packaging. It‟s
recommended that you retain the package for the duration of the
warranty period.

Your eTouch has a screen protector (a thin film to protect the screen
during transit). Please use the tab to slowly and carefully remove this
from the screen as it will reduce the quality of the screen image.

Battery Icon The Battery icon shows in the menu bar at eth
top of your screen. It shows the amount of charge in your
battery. When the lightning symbol shows it means the
battery is still charging.

Battery Charging

Your eTouch has a built in rechargeable lithium battery which is
supplied with no charge in for transportation reasons. We recommend
that you charge the battery for around 8 Hours for its first charge, to
achieve the best battery life. You can still use the eTouch but it‟s best to
keep it plugged in for this charging period.

To maximise your battery life it‟s recommended that you always fully
charge the battery and then use the eTouch unplugged until the
battery power is low, at which point you can recharge the battery.
Using full charging and draining cycles is much better than charging
the battery bit by bit.

To charge the battery, simply connect the power adaptor to your mains
wall socket and the DC Power Input and switch it on.

 The LED Battery Indicator (at the top right of the eTouch) will

illuminate red.

 Once the battery is fully charged the LED will turn off.
 You can see the battery charge status in the menu bar at the

top of your eTouch‟s screen.

 NOTE: The LED will illuminate Blue when the eTouch is powered

ON (even when in standby mode). It will show Blue and Red
when powered ON and charging.

Only use the authorised Elonex power adaptor as supplied in your
package.

10” eTouch™ User Guide to Android™

About your eTouch

Back Button Click to „Go Back‟ to the previous screen.

Power Button Press and hold for 1 second to turn ON or OFF.

Menu Button Click the Menu Button at any time to bring up a menu of

options relevant to the App you have open.

App Manager Button Click to bring up a list of Apps you currently have
open, then tap an App to switch between apps (multi-tasking).

10” eTouch™ User Guide to Android™

Turning your eTouch ON

Once you‟ve charged the battery (or connected the
power adaptor) you can turn the eTouch ON by pressing
the power button and the Android™ operating system
will load.

To unlock the screen (its locked to avoid accidentally
pressing buttons when not being used) slide the padlock
icon until it covers the green dot.

The eTouch™ will then load your home screen for you to
start navigating to your chosen App.

The screen will automatically lock after a period of non-use
(you can change the length of this time period in the Settings
menu, or you can lock it at any point by pressing the Padlock

icon in the menu bar)

Security

You can increase the security settings to protect your eTouch™ by
using a unique unlock pattern.

From your home screen tap Settings > Location
and Security > Set Unlock Pattern and follow the
on-screen instructions.

Please Note that your unlock pattern should use

at least 4 dots and the eTouch™ will be more

secure with a greater number of dots included
in the pattern.

To turn your eTouch OFF simply press and hold the Power button for

about 1 second and tap Power off then OK.

About your Home Screens

The eTouch has 5 home screens where you can add shortcuts to places
and Apps as well as adding widgets (apps that reside on your home
screen such as a clock/calendar).
