Elonex CEWS72, CEWS73 User Manual

1 Introduction

Preface

Welcome to the world of wireless internet, eMail, messaging, word processing
and MP3s. This ultra mobile laptop is your gateway to a truly mobile life and a
whole new way to keep in contact with friends, family & colleagues, get access
to the web, and relax with music, photos and videos.

Your laptop runs Microsoft® Windows® XP® operating system. Windows®
integrates the widest range of applications, services and hardware in a familiar
way so you can easily and confidently use technology to achieve your goals and
pursue your passions.

Please read this user manual carefully to help you get the most out of your
laptop. Also please observe the safety warnings so you don’t damage your
laptop or more importantly yourself. A full support site and trouble-shooting
tips are available at www.elonex.com/support

Package Contents

Your package includes the following contents:

Laptop
Li Ion Battery Pack
Power Adapter (2 parts)
Driver & User Manual CD
Quick Setup Guide
Warranty Card

Getting Started

After unpacking your laptop please check you have all the package contents
and they are in good order. If you are missing any package contents or any
item has been damaged please contact your retailer as soon as possible.

web

surfer

- User Manual

Important Safety Instructions

All the safety and operating instructions should be read before the product is
operated. Always adhere to these instructions and follow the proper working
procedures for the computer. Shut the computer down properly and don’t
forget to save your work often. Remember to periodically backup your data
as Elonex accepts no responsibility for data loss. Failure to adhere to these
Safety Instructions may invalidate your warranty.

Peripherals

Take care when using peripheral
devices. Always check compatibility
with your laptop and follow the
manufacturer’s guidelines for
installation and proper use.

Cleaning

Unplug this product from the wall
outlet before cleaning. Do not use
liquid cleaners, volatile chemicals or
aerosol cleaners as these may cause
damage to your laptop’s chassis or
internal components. Use a damp
cloth for cleaning.

Water and Moisture

Do not use this product near water,
for example, near a kitchen sink etc.
Any liquid entry into the internal
workings of this unit may damage
your laptop.

Ventilation

Slots and openings in the cabinet
are provided for ventilation to
ensure reliable operation of the
product and to protect it from
overheating. These openings must
not be blocked or covered.

Heat

The product should be situated
away from heat sources such as
radiators, heat stoves or other
products that produce heat.

Power Sources

This product should be operated
only from the type of power source
indicated on the marking label and
only using an Elonex authorized
power adapter.

Grounding

This product should only be used
with proper electrical grounding.
Please only use power supplies
supplied by Elonex as this may cause
damage to the electronics or injury
to yourself.

Power Cord Protection

Power supply cords should be
routed so that they are not likely to
be walked on or pinched by items
placed upon or against them. If your
power cord is damaged in any way
please contact customer services.

web

surfer

- User Manual

Lightning

For added protection for this
product during a lightning storm, or
when it is left unattended and
unused for long periods of time,
please unplug it from the power
socket. This will prevent damage to
the product due to lightning and
power lines surges.

Overloading

Do not overload wall outlets,
extension cords or integral
convenience receptacles, as this can
result in a risk of fire or electric
shock.

Object Entry

Never push objects of any kind into
your laptop through openings as
they may touch dangerous voltage
points or short-out parts that could
result in a fire or electric shock.

Servicing

Do not attempt to service this
product yourself as opening or
removing covers may expose you to
dangerous voltage or other hazards.
Refer all servicing to qualified
service personnel.

Damage Requiring Service

If your laptop is damaged or
behaving abnormally unplug this
product from the wall outlet and
refer servicing to qualified service
personnel. Please refer all warranty
claims to Elonex Warranty Service.

Replacement Parts

Only use replacement parts
specified by Elonex. Unauthorized
substitutions may result in damage
to your unit.

Avoid EM interference

The product should be situated
away from all sources of Electro
Magnetic radiation, ie microwaves,
amplifiers, speakers etc. These can
hinder proper performance and
damage your data.

This equipment generates, uses and
can radiate radio frequency energy
and, if not installed and used in
accordance with the instructions,
may cause harmful interference to
radio communications.
However, there is no guarantee that
interference will not occur in a
particular installation.

European CE Notice

The websurfer
Is herewith confirmed to comply with the requirements set out in the
Council Directive on the Approximation of the Laws of the Member
States relating to

Electromagnetic Compatibility (89/336/EEC),
Low Voltage Directive (73/23/EEC)
and the Amendment Directive (93/68/EEC),
the procedures given in European Council Directive 99/5/EC and 89/3360EEC.

The equipment was passed. The test was performed according to the following
European standards:

EN 300 328-2 V.1.2.1 (2001-12)
EN 301 489-1 V.1.3.1 (2001-09) / EN 301 489-17 V.1.1.1 (2000-09)
EN 50371: 2002
EN 55022: 2006
EN 55024: 2001
EN 60950-1:2001
EN 61000-3-2: 2000
EN 61000-3-3: 1995 + A1: 2001

web

surfer

- User Manual

2 Laptop Appearance

CEWS72 / CEWS73

Right Side View

Left Side View

web

surfer

- User Manual

Laptop Appearance

CEWS71

Right Side View

Left Side View

web

surfer

- User Manual

Inputs and Outputs

The laptop has a number of inputs and outputs to give you a truly versatile way
to incorporate it into your daily life. When purchasing any peripheral devices
please check the peripheral’s minimum Hardware and Software requirements
to ensure compatibility with your laptop and always follow the manufacturer’s
instructions.

USB Ports The laptop is compatible with a whole range of USB peripheral
devices such as printers, scanners, digital cameras, MP3 players etc. The laptop
has 2 USB2.0 ports (and is also compatible with USB1.0 devices) however you
will achieve a much higher data transfer rate with USB2.0 (up to 480Mbps).

Webcam (CEWS71 only) Your laptop has a built in webcam at the top of the
screen. You can use this to have video chats over the internet. You can initiate
the webcam using the ‘Start WebCam’ hotkey located at the top right of the
keyboard.

Microphone Jack (3.5mm) let’s you use a microphone to record audio to your
laptop. The laptop also has an integrated microphone to give you the option of
speaking directly into your laptop. Please only use a 3.5mm Jack when
connecting external devices.

Headphone Jack (3.5mm) let’s you play audio from your laptop to a set of
external speakers or headphones. It also has integrated stereo speakers to give
you the option of playing audio directly from the laptop. Please only use a

3.5mm Jack when connecting external devices.

4-in1 Memory Card Slot Transfer photos quickly and easily from your digital
camera to the laptop using the memory card slot (compatible with SD / MMC /

MS / MSPro memory cards) so you can eMail or upload them to the internet to
share the fun with your friends and family.

RJ45 Ethernet Port Use the 10/100Mbps Ethernet port for connecting your
laptop to cable broadband to give you internet access or connect to a network.
For details of how to connect to the internet see “Connecting to the Internet”
section of this booklet.

DVI output You can use this high quality connection to output your screen to
another monitor, projector or DVI enabled TV. (Requires a monitor cable not
supplied, you can also use with a VGA monitor using a DVI to VGA connector)

web

surfer

- User Manual

How to connect an external monitor:

1. Turn off your computer and make sure the monitor power switch is
turned off. You may damage you laptop or monitor by connecting these devices
while the laptop is turned on.

2. Connect the monitor cable to the DVI port at the left of your UMPC (if your
monitor takes VGA then use a DVI to VGA adapter).

3. Connect the monitor power cable and plug it into a properly earthed wall
outlet.

4. Turn on the monitor.

5. Turn on your websurfer. Both the LCD panel and the monitor screen will
show the display. Your computer is set as default to run in simultaneous
display mode.

6. If you only want to show the display on the external monitor and shut off
the LCD display, you can use the <Fn> + <F3> hot-key to switch the display type
between LCD and external monitor. Keep pressing the hotkey until you get the
display to external monitor only.

LED Indicators

Battery Charging LED

Lights to indicate battery in charging status.

Lights orange to indicate that the battery is in charging mode.
When the light is off, it indicates the battery is fully charged or the
battery pack is not connected.

Hard Drive Access

Lights to indicate that the system is accessing the Hard Disk.

Wi-Fi Connection

When the LED is lit this indicates that the wireless LAN/Bluetooth module is
activated. When the LED light is off, it indicates that the function is disabled.

Caps Lock

When LED is lit the Caps Lock key on the keyboard is activated. When activated,
all alphabet keys typed will be in UPPERCASE.

web

surfer

- User Manual

Power, Charging and Battery Care

This laptop has a rechargeable battery which will give you usage on the move
when recharged. You can also use the power adapter plugged into mains
electricity for continuous use (the laptop will recharge its battery while in
operation).

It is recommended that the first time you charge your battery you should
charge it for at least 8 hours to get the best battery life.

Connecting your Battery Pack

Caution: You must shut your system down before changing the battery pack.

1.Turn the computer over so that the battery slot faces up.

2. Place the battery pack in the battery slot, and align the protrusions on the
battery pack with the two slits on the side of the battery slot.

3. Gently push the battery pack into the slot until you hear a click. Lock the
battery pack in place by pushing the left battery latch to the left. When you
hear a click, the battery pack is locked in.

4. Connect the AC adapter and open the LCD panel. Start charging the battery.
When the battery is charging the Battery Status Indicator will go orange, when
fully charged it will turn off.
