ELMO P100N User's Manual

Download

DOCUMENT CAMERA

INSTRUCTION MANUAL

Please read this instruction manual carefully before using this product and keep it

for future reference.

P100N

Deutch P000~P000

Français P000~P000

P00~P00

Deutch P000~P000

Français P000~P000

English P64~P125

ENGLISH

IMPORTANT SAFEGUARDS

■ Read Instructions – All the safety and operating instructions should be read before the appliance is operated.

■ Retain Instructions – The safety and operating instructions should be retained for future reference.

■ Heed Warnings – All warnings on the product and in the operating instructions should be adhered to.

■ Follow Instructions – All operating and use instructions should be followed.

■ Cleaning – Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

■ Attachments – Do not use attachments not recommended by the product manufacturer as they may cause hazards.

■ Water and Moisture – Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

■ Placement – Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer's instructions, and should use a mounting accessory recommended by the manufacturer.

■ Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.

■ Power Sources – This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home consult your appliance dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

ENGLISH

■ Grounding or Polarization – This product may be equipped with either a polarized 2-wire AC line plug (a plug having one blade wider than the other) or a 3-wire grounding type plug, a plug having a third (grounding) pin. The 2-wire polarized plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug still fails to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug. The 3wire grounding type plug will fit into a grounding type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding type plug.

■ Power-Cord Protection – Power- supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

■ Lightning – For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

■ Overloading – Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

■ A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

■ Object and Liquid Entry – Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

■ Servicing – Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

ENGLISH

■ Damage Requiring Service – Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

● When the power-supply cord or plug is damaged.

● If liquid has been spilled, or objects have fallen into the product.

● If the product has been exposed to rain or water.

● If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.

● If the product has been dropped or damaged in any way.

● When the product exhibits a distinct change in performance this indicates a need for service.

■ Replacement Parts – When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

■ Safety Check – Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

CAUTION

RISK OF

ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This marking is located at the bottom of product.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

SA 1965

SA 1966

■ Heat – The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

■ This product includes a Fluorescent Lamps component that contains mercury. Please consult your state and local regarding proper disposal or recycling, and do not place in the trash.

ENGLISH

WARNING : Handling the

cord on this product or cords associated with accessories sold with this product, will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm.

Wash hands after handling.

FOR UNITED STATES USERS:

INFORMATION

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

USER-INSTALLER CAUTION:

Your authority to operate this FCC verified equipment could be voided if you make changes or modifications not expressly approved by the party responsible for compliance to Part 15 of the FCC rules.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER MAY BE REQUIRED TO TAKE ADEQUATE MEASURES.

ENGLISH

BEFORE YOU USE

■ Be sure to use the power cord and AC adapter attached to this camera system as accessories.

■ The power cord applicable to the local power specifications is attached. Be sure to use the power cord applicable to your local power specification.

■ Do not leave this product under direct sunlight or by heaters, or this product may be discolored, deformed, or damaged.

■ Do not place this product in any humid, dusty, windy or vibrating location. Use this product in the following environmental conditions:

Temperature: 5°C~40°C (41°F~104°F) Humidity: 30%~85% (No condensation)

■ In handling (including setting up and storing) or carrying the camera, be meticulously careful not to give an impact on the camera head.

■ To prevent dropping and falling, observe the following:

• Use the camera on a stable stand, desk or table. Never put the camera on any

shaky stand or inclined or instable place.

• Before using, lay out the power cord, the AC adapter cable and the video cable

not to be pulled, and wire them accordingly.

■ Use a soft, dry cloth for cleaning. Do not use any volatile solvent, such as thinner or benzine.

■

Do not directly point the camera lens into the sun, or the camera may be damaged.

■ Caring for the batteries:

• If this camera system is not used for a long time, take out the batteries from the

wireless remote control.

• Do not use rechargeable batteries (e.g., Ni-Cd)

•

Do not use new and old batteries, or batteries of different types together.

• Do not try to recharge or short-circuit the batteries.

• When disposing of used batteries, follow the instructions from each local

government.

■ Luminescent and Black Spots This camera has a CMOS area image sensor and a color LC panel, which are composed of many pixels. Some of these pixels may not operate normally. As a result, a luminescent spot or a black spot may appear on the output screen. However, this is a phenomenon unique to the CMOS area image sensor and color LC panel and therefore this phenomenon is not faulty.

■ Do not press the LC panel strongly or with a sharp-pointed object, or it would cause break or failure to the color LC panel.

■ Transfer the data in an SD card to a PC or other data storage means for backup purpose. Note with care that the data in the SD card could be lost due to failure or repair of this product.

■ Network function This function does not guarantee the normal operation when this camera system is connected directly to the Internet. Shut down any communication not routed via packet filter or the like in a router or the like.

■ Microphone If a microphone other than that for PCs (electret condenser microphone) is connected to this camera system, this camera system could be broken down.

PART NAMES

AND

FUNCTIONS

SETTING UP STORING

OPERATION

PROCEDURE

VARIOUS

FUNCTIONS

AND OPERATIONS

ABOUT

RS-232C

TROUBLESHOOTING

SPECIFICATIONS

ENGLISH

PART NAMES

AND

FUNCTIONS

SETTING UP STORING

OPERATION

PROCEDURE

VARIOUS

FUNCTIONS

AND OPERATIONS

ABOUT

RS-232C

TROUBLESHOOTING

SPECIFICATIONS

ENGLISH

1. PART NAMES AND FUNCTIONS

Name of Each Part.......................................................73

Appearance........................................................................73

Functions ....................................................................74

Front Operating Panel ...........................................................74

Rear Panel ..........................................................................75

Side Panel ..........................................................................76

OSD (On-Screen Display) ..............................................77

Camera Mode (Menu when camera image is in display).............77

SD Mode (Menu when image stored in an SD card is in

display)

………78

Wireless Remote Control ...............................................80

Receivable Range ................................................................82

Battery Change ...................................................................82

WEB Screen ...............................................................83

Top page ...........................................................................83

LIVE ...................................................................................84

REFRESH ............................................................................84

CONFIGURATIONS ............................................................85

Network Configuration..........................................................86

FTP Client Configuration ........................................................87

WEB remote control .............................................................88

2. SETTING UP

Setting Up ..................................................................89

Connecting Cables ......................................................91

3. STORING

Storing.......................................................................93

4. OPERATION PROCEDURE

Turning ON/OFF the Power Supply

...................................

Presentation by Using Documents, Films, etc.

..........................95

Presentation using optional SD card (Option).....................96

Saving the Image ……………………………………………………97 Displaying the image

………………………………………………97

Deleting the Image

…………………………………………………98

Slide show

…………………………………………………………98

Formatting the SD card

………………………………………………98

Presentation using the supplied software

with the USB-connected PC

...........................99

Transferring the images from the SD card

into the USB-connected PC

........................100

Displaying the Video Image through

Network Connection ..............................101

Capturing the Image through Network Connection

with the FTP ...........102

Using [MIC IN] and [AUDIO IN] ..................................102

Shooting off the stage .................................................103

CONTENTS

PART NAMES

AND

FUNCTIONS

SETTING UP STORING

OPERATION

PROCEDURE

VARIOUS

FUNCTIONS

AND OPERATIONS

ABOUT

RS-232C

TROUBLESHOOTING

SPECIFICATIONS

ENGLISH

5. VARIOUS FUNCTIONS AND OPERATIONS

Lighting ....................................................................104

Zoom ......................................................................105

Image Selection.........................................................106

Input image signal that can be output from the video output terminal [VIDEO OUT] into the analog RGB

input terminal [RGB IN] .......................................................107

Focus.......................................................................108

Auto Focus........................................................................108

Manual Focus....................................................................109

Brightness Adjustment..................................................110

Auto Brightness Adjustment...................................................110

Manual Brightness Adjustment...............................................110

State Presetting ..........................................................111

Presetting..........................................................................111

Calling.............................................................................111

Microphone Input.......................................................112

White Balance ..........................................................112

How to use [Auto] ..............................................................112

How to use [One-Push]........................................................112

How to use [Manual]..........................................................112

6. RS-232C SPECIFICATIONS

Setting Up ................................................................113

Cable Connection......................................................113

Data Format Specification............................................114

Operation Command (PC → This product) ..............................114

Response Data Format (This product

→ PC) .............................114

Transmission Specifications ..........................................115

UART Communication Format .......................................115

Connection...............................................................117

7. TROUBLESHOOTING

Symptoms and Confirmation.........................................118

Replacement of Lighting Lamp (Fluorescent Lamp)..............120

About the long-time use ...............................................120

8. SPECIFICATIONS

General ...........................................................................121

Microphone input circuit ......................................................121

Main Camera ...................................................................122

Network...........................................................................123

Lighting ............................................................................123

Supplied Accessories ..........................................................123

Disclaimers ...............................................................124

CONTENTS

ENGLISH

PART NAMES

AND

FUNCTIONS

Open this cover when connecting/ disconnecting a cord.

When carrying this product, do not hold this cord cover.

1 PART NAMES AND FUNCTIONS

Name of Each Part

■ Appearance

Front

Rear/Side

Front

Rear/side

No. Name

q Camera head

w Lamp head

e Setup grip

r Camera column

t Lamp column

y Front operating panel

u Stage

i Wireless remote control

o Lock pin

P.74

P.80

The infrared sensor is also available on the front side.

No. Name

!0 Infrared sensor

!1 Safety lock knob

!2 Rear panel

!3 Side panel !4 Cord cover

P.89

P.75

P.76

ENGLISH

PART NAMES

AND

FUNCTIONS

Functions

■ Front Operating Panel

* Hereinafter the menu items to be displayed/selected on the monitor or projection screen

are referred to as "OSD (On-Screen Display)".

qwerty

oiu

1!0

Name Function

q LCD panel To display the output image and the OSD w LAMP To switch the illumination

e TEXT (Text mode) To switch the mode to Text1 To make B&W images of letters or lines sharp in contrast Use this button to display materials such as documents

r GRAPHICS (Color document) To switch the mode to Graphics To display color objects such as figures and photos

t BRIGHTNESS (Dark) To darken the camera image

(Brightness)

y (Light) To lighten the camera image

u CAMERA To switch the output image to the camera image i PC (RGB IN video) To switch the output image to the RGB IN image o (SD mode) To switch the output image mode to the SD mode !0 AF (Auto Focus) To focus the camera automatically !1 ZOOM To operate the zoom function by turning the dial

P.104

P.110

P.106

P.106 P.108

P.105

ENGLISH

PART NAMES

AND

FUNCTIONS

■ Rear Panel

q DVI OUT To output digital video signal to the projector, the Camera image

(DVI Output Terminal)

PC monitor or other DVI input device SD mode

w RGB OUT To output analog video signal to the projector, the Camera image (Analog RGB PC monitor or other RGB input device [RGB IN] image Output Terminal) SD mode

e RGB IN Input image is output from the analog RGB output (Analog RGB terminal or the video out terminal when RGB IN Input Terminal) ( ) is selected with image select button

r VIDEO OUT To output image from the RCA pin-jack terminal to

Camera image

(Composite Video

the NTSC/PAL-system monitor (e.g., TV monitor)

[RGB IN] image

Output Terminal)

SD mode

t RS-232C To control the main unit from a PC through the

(RS-232C Terminal)

RS-232C cable

y 12VDC IN Socket for the AC adapter (Power Socket)

u DIP Switch To execute the following switching:

When switching the DIP switch key settings, be sure to turn OFF the power supply to the main unit.

i AUDIO OUT To output the microphone input and the audio

(Audio Output Terminal)

input in the mixed status

o AUDIO IN To output the input audio as it is from the AUDIO

(Audio Input Terminal)

OUT terminal

[Video Out] → [Camera & SD] on the OSD skips [RGB IN] image.

Image whose display is selectable

with image select button

P.91

P.92

P. 11 3

0 1

ABCD

[A] and [B] keys: Switch the resolution of the DVI and analog RGB output

[C] key: Switches the VIDEO output type

[D] key: Switches the VIDEO screen size

Settings

SXGA

XGA

720p

(SXGA)

[A] key

0 1 0 1

[B] key

0 0 1 1

Settings

NTSC

PAL

[C] key

0 1

Settings

Over scan

Under scan

[D] key

0 1

Name Function

P. 10 2

Display of Rear Panel

ytr

ENGLISH

PART NAMES

AND

FUNCTIONS

■ Side Panel

Name Function

q (USB terminal, To enable the image transfer or the main unit control by compliant with 2.0) using the utility software on the supplied CD-ROM when

the camera is connected to the PC

w (SD Card Slot) To insert an SD card To remove the SD card, push it in once

e Main Switch To turn ON/OFF the power supply r (Ethernet terminal, To enable the image transfer or the main unit control when

100BASE/10BASE) the camera is connected to the network t MIC To enable the audio output from the AUDIO OUTPUT

(Microphone input terminal) terminal when the PC microphone (electret condenser microphone) is connected to the PC. The audio volume is adjustable

P.91

P.96

P.101,102

Explanation of the Ethernet terminal LED

Yellow … ON: Link OK, Blinking: Access

Green … ON: 100BASE, OFF: 10BASE

ENGLISH

PART NAMES

AND

FUNCTIONS

OSD (On-Screen Display)

The menu items displayed/selected on the monitor or the projection screen are referred to as "OSD (On-Screen Display)". When the [MENU] button on the wireless remote control is pressed, the OSD menu appears on the monitor screen. (When this [MENU] button is pressed again, the OSD menu disappears.) Move to the item to be set by pressing the [] direction buttons on the wireless remote control, and press the [ENTER] button to fix the setting. When the []direction button is pressed, the OSD menu hierarchy is traced back. When the same button is pressed on the first hierarchy, the OSD menu disappears.

■ Camera Mode (Menu when camera image is in display)

Sample image of the top and 2nd hierarchies

Name Function Top hierarchy 2nd hierarchy

3rd hierarchy

IP Address Display To display the IP address Brightness Auto To vary the degree of brightness automatically according to the object Manual To fix the image brightness to any level Mode Text3

Text1, Text2 and Text3 are used to display B&W characters and documents

Text2

sharply. The larger the number affixed to Text is, the larger the effect is.

Text1

Graphics is used to display color figures and photographs

Graphics

cleanly. Only when Graphics is selected, Edge Effect and

Gamma can be set. White Balance Auto To set the white balance to automatic following One-Push To set the white balance to fix Manual To adjust the red intensity and the blue intensity manually R-Gain

(Displayed in level bar form)

To adjust the red intensity when the white balance is set to manual B-Gain

(Displayed in level bar form)

To adjust the blue intensity when the white balance is set to manual Edge Effect 3 This can be set only when the mode is set to Graphics. 2 Edge enhancement is provided to the image to make it 1 sharp. The larger this number is, the larger the effect is Off Gamma High To set the gamma curve when the mode is set to Graphics Normal The grayscale can be varied as you like. Low USB Mode Mass Storage Yes or No Mode to be set to transfer the data from the SD card into /Ethernet (Transfer) the USB-connected PC Application Yes or No Mode to be set to control the main unit from the USB connected PC or transfer the image into the USB connected PC Ethernet Yes or No Mode to be set to control the main unit from the Ethernet connected PC or transfer the image into the Ethernet connected PC

P. 11 0

P. 10 0

P. 11 0

P. 99

Setting change becomes effective when the power switch is turned OFF and then turned ON.

P.101,102

IP Address

Brightness

Mode White Balance R-Gain B-Gain Edge Effect Gamma

Top hierarchy

Auto

Manual

2nd hierarchy

Name Function Top hierarchy 2nd hierarchy

3rd hierarchy

Capture SD

Mode to write the image on the SD card set on the main unit side

when the button on the wireless remote control is pressed Ethernet Mode to save the image file in the FTP server when USB Mode/Ethernet is set to Ethernet Guide On To set whether the operation status of the main unit should Off be displayed. Video Out All Mode

To output the [VIDEO OUT] terminal signal according to

all video switching

Camera & SD To limit the switching of the [VIDEO OUT] terminal output

(Image of Camera & SD only)

to the camera video and the SD mode

Flickerless 60Hz To reducer fluorescent lamp flicker due to power supply

(Flicker compensation)

50Hz frequency

Ethernet Status Default To reset the Ethernet Status to the factory settings

Call (Setting Call) Default To reset the Call to the factory settings (not applicable to USB Mode/Ethernet, Flickerless/WEB Ethernet settings) Mic Volume

(Displayed in the level-bar form)

To adjust the audio level of the microphone input

Setting change becomes effective when the power switch is turned OFF and then turned ON.

PART NAMES

AND

FUNCTIONS

ENGLISH

[ ] indicates the factory default settings. The factory default settings of Flickerless vary according to the destination. The settings of USB Mode and Flickerless retain the last set state.

■ SD Mode (Menu when image stored in an SD card is in display)

Name Function

Top hierarchy

2nd hierarchy 3rd hierarchy

Delete Current No To cancel the delete (Selected Image) Yes To delete the image in display on the full screen or the image selected from the split screen. Locked image can not be deleted. All (All images) No To cancel the delete Yes To delete all images Lock Current To lock the image in display on the full screen or the (Selected image) image selected from the split screen.

Can set the image not to be deleted or select image for slide-show.

On the split screen, a green frame appears on the locked image. All (All Images) To lock all image files. Can select the delete-protected image or the image to be displayed on the slide show Unlock Current To release the lock of the image in display on the full

(Lock Release)

(Selected Image) screen or the image selected from the split screen All (All Images) To release the lock of all image files Format Format No To cancel the format Media (Initialize) Yes To format the SD card

All data will be deleted from the card.

P. 98

Sample image of the 1st, 2nd and 3rd hierarchies

White Balance

R-Gain B-Gain Iris Edge Effect Gamma

Top hierarchy

Auto/One-Push

Manual

2nd hierarchy

Yes

3rd hierarchy

PART NAMES

AND

FUNCTIONS

ENGLISH

Name Function

Top hierarchy

2nd hierarchy 3rd hierarchy

Slide Interval 3 Sec To set the interval of slide show until displaying the next Show (Interval of Image 5 Sec image from 3 to 30 sec Settings Feed) 10 Sec 15 Sec 30 Sec Effect Left to right To slide from left to right (Effect of Image LT to RB To slide diagonally from left top to right bottom Feed) RT to LB To slide diagonally from right top to left bottom None To show no visual effect Select All To set the slide-show objects to all displayable images in (Object File) an SD card Locked Only To set the slide-show objects only to the locked image files Order Forward To give slide show in order of file name serial No. from (Order of Image the smallest to the largest Feed) Backward To give slide show in order of file name serial No. from the largest to the smallest Repeat Off

To set whether the slide show should be played repeatedly

or not Start Slide To start the slide show Show Display Single To set the number of the images in an SD card to be 3 ×3 displayed on the split screen 4 ×4

P. 98

* [ ] indicates the factory settings.

PART NAMES

AND

FUNCTIONS

ENGLISH

Wireless Remote Control

q w

r y

u t y

i o !0

!3 !4

@2 @3

@4 @6 @7

Name Function

q PRESET (State Save) To save the current setting state of the unit Use this function together with the memory No.

w CALL (State Call) To call the setting state Use this function together with the memory No.

e (Memory No.) To indicate the memory No.

P.111

PART NAMES

AND

FUNCTIONS

ENGLISH

Name Function

r (OSD t Operation) ENTER (Input) To fix the OSD item y To select the OSD item, and scroll the LCD monitor when

(Directions) the digital zoom is used u (Menu Cancel) To cancel the OSD from the screen when the top OSD item

is resumed i POSI/NEGA To switch the posi/nega of the camera image o COLOR/B&W To switch the Color/Black and White of the camera image

(Color/Black and White) !0 BRIGHT NORMAL !1 !2 (Dark) To darken the camera image !3 ZOOM (Telescopic) To zoom in

!4 (Wide-angle) To zoom out

!5 (Image Save) To save the image on the SD card or FTP-transfer the image.

!6 (SD mode) To switch the output image mode to the SD mode

NESS

(Brightness

(Bright) To brighten the camera image

adjustment)

MENU To display/cancel the OSD

Use this function to make the black-and-white document easy-to-read To return the automatic brightness adjustment level to the standard level

P.77

P.110

P.105

P.106

!7 (CAMERA) To switch the output image to the camera image

!8 (PC) To switch the output image to the RGB IN image

P.106

!9 GRAPHICS (Color documents) To switch the mode to Graphics To display color objects, such as figures and photos @0 Text (Text Mode) To switch the mode to Text1

To sharpen the image with black-and-white characters and lines

Use this function to shoot the document or the like @1 EDGE EFFECT To switch the 1/2/3/OFF of the edge enhancement

(Edge Enhancement) The edge effect is applied to the image for sharpening This function is enabled when the mode is set to Graphics

@2 PAUSE To pause the camera image. When this button is pressed again, the moving image is restored

The paused image cannot be processed in any other way.

IMAGE ROTATION (Image Turn)

@4 FOCUS NEAR To move the focus near @5 FAR To move the focus far @6 AF (Auto Focus) To focus the camera automatically

To turn the camera image by 180°

P.108

@7 (Lamp) Each time this button is pressed, the material illumination lights up → the base illumination lights up → both illuminations go out in this order.

P.104

PART NAMES

AND

FUNCTIONS

ENGLISH

■ Receivable Range

Point the infrared emitting part of the wireless remote control at the infrared sensor of the main unit, and press the button for desired function. The receiving range may be reduced when the main unit is placed in direct sunlight, near an inverter fluorescent lamp or in any other unfavorable surroundings. Depending on the conditions of fluorescent lamps, etc., the sensor may fail to receive the infrared light. In such case, relocate the main unit, or take other countermeasures.

• Receivable range Distance: Approx. 7m (23ft) or less from the front of the infrared sensor Angle: Approx. 30° or less to the rightward, leftward, upward and downward,

respectively, from the infrared sensor

■ Battery Change

Remove the battery case cover on the rear side by pressing down the [ OPEN] mark part in the direction as indicated by the arrow. Install 2 batteries (Type R03, AAA) in the battery case in the direction as indicated.

Install the batteries with the correct polarity.

Although the battery life depends on the operating conditions and battery type, the batteries are recommended to be changed once a year.

The supplied batteries are only for use in initially confirming the operation of this product. Therefore, it is not guaranteed that these batteries remain alive for the validated period.

Within 7m (23ft)

Wireless remote

control housing case

The infrared sensor is also built in the wireless remote control housing case, so that the wireless remote control can be operated while it is housed in the case.

Infrated sensor

PART NAMES

AND

FUNCTIONS

ENGLISH

■ Top page

When connection is made to http://192.168.0.100 on the browser, its top page opens. By clicking each item there, the clicked item can be operated.

P.101

It is necessary to set USB Mode/Ethernet to Ethernet on the OSD, and use it in the camera mode.

If the resolution settings are changed with the DIP switch or the USB Mode/Ethernet settings are changed, restart the browser.

If USB Mode/Ethernet has been set to Mass Storage or Application on the OSD, SET UP alone will become effective.

“192.168.0.100” is default. Input the IP address used in the network configuration of SET UP.

WEB Screen

Name Function

q LIVE (Video image display) To display the video image at 50%, 75% or 100% scale

w REFRESH To display the REFRESH page e CAPTURE To display the still image r SET UP (Ethernet setting) To display the configurations page

P.84

P. 85

PART NAMES

AND

FUNCTIONS

ENGLISH

■ REFRESH

■ LIVE

q w

e r

When the [PAUSE] button on the wireless remote control is pressed in the SD mode, the video image and the still image cannot be displayed.

Name Function

q CONTROL To display the WEB remote control when this item is (WEB remote control) clicked

P.88

Name Function

q manual To display the [refresh] button without automatically updating the still image

w Interval To update the still image at each time intervals e refresh To update the still image when this item is clicked

(applicable only in the manual mode) r CAPTURE To display the still image in another window when this item

is clicked t TOP To display the top page

PART NAMES

AND

FUNCTIONS

ENGLISH

■ CONFIGURATIONS

Name Function

q Network Configuration To display the network configuration page w  Configuration of the current network e FTP Client Configuration To display the FTP client configuration page r  Configuration of the current FTP client t TOP To display the top page

P.86

P.87

PART NAMES

AND

FUNCTIONS

ENGLISH

■ Network Configuration

q w

e r t

Name Function (< >: Factory settings) q IP address IP address information set in this camera system

<192.168.0.100> w Subnet mask <255.255.255.0> e Default gateway Router IP address

<0.0.0.0> r Root password Password for setting the network, using the FTP server

function, setting of the FTP client and using the telnet. Up to 127 alphanumeric characters

t User password Password for setting the FTP client to enable the use of the [image transfer] button and using the FTP server function. Up to 127 alphanumeric characters <Setting Information>

y Change To set or change the password, this check box should be checked. If this check box is checked but nothing is entered in the password edit box, the relevant password information will be cleared.

u Setup To set to the contents in display i Clear To reset all edit contents to the state as of opening of this

page o Configurations To display the configurations page

Network configuration change becomes effective when the power switch is turned OFF and then turned ON.

PART NAMES

AND

FUNCTIONS

ENGLISH

■ FTP Client Configuration

Name Function

q The IP address of the image To designate the IP address of the saving destination FTP server receiving server <0.0.0.0> as of shipment from our factory

w The port number of the image To designate the port No. of the FTP server running in the receiving server saving destination host <21> as of shipment from our factory

e User account for the image To designate the account name necessary for connection to the receiving server saving destination host. <anonymous> as of shipment from our factory Up to 127 alphanumeric characters including hyphen ( - ) and underscore ( _ )

r Password for the image receiving To designate the password of the above account server No setting as of shipment from our factory Up to 127 alphanumeric characters

t Passive Mode To designate which mode should be used for file transfer, passive mode or active mode No use as of shipment from our factory

y Destination directory to save To designate the image file saving directory <root directory> as of shipment from our factory Up to 255 alphanumeric characters including hyphen ( - ), underscore ( _ ) and slash (/)

u The name of image file To designate the name of the saving file The file name is affixed automatically with the [.jpg] extension. <img> as of shipment from our factory Up to 255 alphanumeric characters including hyphen ( - ) and underscore ( _ )

i Add the sequence number to To designate whether sequence No. should be added to the file file name? name or not: [Yes]/[No] <[Yes]> as of shipment from our factory

o The start number of sequence To designate the sequence start No. when the file name is added with sequence No. <0> as of shipment from our factory

!0 The end number of sequence To designate the sequence end No. when the file name is added with sequence No. If there is any file name added with the same No., such file will be overwritten. Therefore, it is advisable to designate the sequence end No. on the larger side. <999> as of shipment from our factory

!1 Setup To set to the contents in display !2 Clear To reset all edit contents to the state as of opening of this page !3 Configurations To display the configurations page

q w e

r t

u i

o !0

PART NAMES

AND

FUNCTIONS

ENGLISH

■ WEB remote control

t y

i o

!4 !5

Name Function (One-click operation)

q ZOOM TELE To zoom in w WIDE To zoom out e LAMP Each time this button is pressed, the material illumination

lights up → the base illumination lights up → both illuminations go out in this order.

r BRIGHTNESS NORMAL To return the automatic brightness adjustment level to the standard level

t OPEN To brighten the camera image y CLOSE To darken the camera image u FOCUS NEAR To move the focus near i FAR To move the focus far o AF To focus the camera automatically !0 GRAPHICS To switch the mode to Graphics !1 TEXT To switch the mode to Text1 !2 EDGE EFFECT To switch the 1/2/3/OFF of the edge enhancement

Effective only in the Graphics mode

!3 IMAGE ROTATION To turn the camera image by 180° !4 POSI/NEGA To switch the posi/nega of the camera image !5 COLOR/B&W To switch the color/B&W of the camera image

ENGLISH

2 SETTING UP

Setting Up

(1) Release the camera column lock by turning the

security lock knob.

(2) As shown in the right figure, hold the setup grip

and raise the camera column. At this time, the camera head slides up in conjunction with the rise of the camera column. The lamp column also rises together.

(3) If necessary, move the lamp column and the lamp

head to an appropriate position as shown in the right figure.

When using a glossy paper, the document could reflect the illumination to disable normal display. In this case, adjust the lamp position to a position in which such reflection can be avoided.

SETTING UP

Locked Unlocked

setup grip

SETTING UP

ENGLISH

If the camera column is pulled or pushed forcedly, the camera might be pushed out of position by a function not to break mechanical parts, and the camera image might be displaced from the display center. In this case, initialize the camera position as follows:

(1) Fold the camera column on the stage. When

the camera column is folded in the storage position, the camera position is initialized.

(2) Then, raise the camera column.

setup grip

SETTING UP

ENGLISH

Connecting Cables

To protect this product and the peripheral units to be connected to this product, be sure to turn OFF the power supply to all units beforehand.

When plugging in/out the connection cable, hold the plug part of the cable.

For the information of image output switching, refer to P.75 (DIP Switch).

Load the SD card with the label facing up. Forcible insertion by mistake could cause failure.

This camera system does not accept the SDHC card. Use the recommended card only.

q Connecting to the PC with a USB cable

Connect the USB cable to the [ ] (USB) terminal on the side panel.

The USB cable compliant with USB2.0 is recommended.

If you plug into a USB cable with power on, PC may not recognize this product.

Depending on the USB environment used by the PC or the influence of peripheral units, the video transfer could be disturbed.

This does not guarantee the normal operation in any environment.

w Connecting to the unit having the DVI input terminal

Connect the DVI cable to the [DVI OUT] terminal on the rear panel.

SD card

MIC terminal

• From PC microphone (electret condenser microphone)

USB terminal

• To PC

Ethernet terminal

• To PC

• To HUB

DVI OUT terminal

• To projector

• To PC monitor

RGB OUT terminal

• To projector

• To PC monitor

VIDEO OUT terminal

• To TV monitor

AUDIO OUT terminal

• To speaker with amplifier

• To audio equipment

AUDIO IN terminal

• From audio reproducer

RGB IN terminal

• To PC

SETTING UP

ENGLISH

e Connecting to the unit having the analog RGB input terminal

Connect the analog RGB cable to the [RGB OUT] terminal on the rear panel.

The display position may be displaced from the center of the screen. In such case, adjust the horizontal and vertical positions manually from the connected device.

Vertical stripes may appear on the LCD projector screen or the monitor screen. This phenomenon can be mitigated by adjusting the dot clock manually from the connected device.

r Connecting to the unit having the analog RGB output terminal

Connect the analog RGB cable to the [RGB IN] terminal on the rear panel.

• Specifications of the analog RGB input terminal of this product

Signal allocation

Pin assignment

t Connecting to the unit having the composite video input terminal

Connect the video cable with RCA pin plug to the [VIDEO OUT] terminal on the rear panel.

y Connecting to the microphone

Connect the microphone for PCs (electret condenser microphone) equipped with 3.5mm mini plug cord to the [MIC] terminal on the side panel.

u Connecting to the PC and the network with the Ethernet cable

Connect the Ethernet cable to the [ ] (Ethernet) terminal on the side panel.

i Connecting to the speaker

Connect the speaker equipped with amplifier and RCA pin plug cord to the [AUDIO OUT] terminal on the rear panel.

o Connecting to the audio reproducer

Connect the audio cable equipped with 3.5mm mini plug to the [AUDIO IN] terminal on the rear panel.

54321

109876

12 11

DSUB 15P shrink terminal (Female)

15 14 13

Pin No. Name

Video signal (Red)

Video signal (Green)

Video signal (Blue)

3 4 5

N.C

GND

Video signal : Analog 0.7V(p-p) 75Ω terminated

Horizontal synchronized signal : TTL level (Positive/negative polarity)

Vertical synchronized signal : TTL level (Positive/negative polarity)

Pin No. Name

6 7 8 9

GND (Red)

GND (Green)

GND (Blue)

N.C

GND

Pin No. Name

11 12 13 14 15

GND

N.C Horizontal synchronized signal Vertical synchronized signal

N.C

STORING

ENGLISH

3 STORING

Storing

(1) Return the lamp to the original position. Then,

hold the setup grip of the camera column and fold the camera column. At this time, the camera head slides down and the lamp column also folds.

Turn OFF the power switch before the storing.

(2) Lock the camera column and the lamp column by

turning the security lock.

Do not force down the camera column and the lamp column when folding them.

Do not fold the camera column when the close-up lens holder remains open, or the close-up lens could be damaged.

Close-up lens holder

When this camera system is not in use, unplug the power cord and the AC adapter from the plug socket.

Locked Unlocked

OPERATION

PROCEDURE

ENGLISH

4 OPERATION PROCEDURE

Be sure to use the main switch on the main unit to turn ON/OFF the power supply to the main unit.

Do not turn ON/OFF the power supply by plugging/unplugging the AC adapter or the power plug.

When connecting to other units, turn OFF the power supply to all connecting units.

It takes the main unit about 30 seconds to be ready for operation. During this time, the logo is on display.

It takes the main unit about 10 seconds to be shut down completely. During this time, the logo is on display.

Connection of the AC adapter

Plug the DC plug of the attached AC adapter into the [12VDC IN] terminal on the rear panel, and then plug the AC adapter into the plug socket.

About power failure

Even if it is momentary, power failure would turn OFF the power supply to the main unit. In case of power failure, manually turn ON the power supply to the main unit after power recovery. If power failure is probable, it is advisable to install a UPS (uninterruptible power supply system).

Turning ON/OFF the Power Supply

Yellow

Light blue

OPERATION

PROCEDURE

ENGLISH

Presentation by Using Documents, Films, etc.

q Setting the main unit

Set the main unit as show in the above figure, connect the main unit to the projector or the PC monitor, and then turn ON the power supply.

w Adjusting the size

Place an object on the stage, and adjust the position of the object with the zoom dial [ZOOM] on the front operating panel or the zoom button ([], []) on the wireless remote control so that the part of the object to be viewed can fit the screen size.

e Adjusting the focus

Press the [AF] button on the front operating panel or wireless remote control to focus the camera on the object.

r Adjusting the brightness

Press the [BRIGHTNESS

] button on the front operating panel or wireless

remote control to adjust the brightness of the image by the lens iris. When the illumination is switched by pressing the [ LAMP] button, the light distribution according to the material can be achieved.

When the main unit is connected to the DLP projector and GRAPHICS is selected, both documents and photos may be projected sharply. If necessary according to the projected condition, select GRAPHICS.

P.108

P.105

P.110

P.104

P.77

OPERATION

PROCEDURE

ENGLISH

Before starting the operation, insert an optional SD card (Option) into the SD card slot on the side panel. Push it again to remove the SD card.

When loading/unloading the SD card or the power supply is turned off, be sure to select the camera image by pressing the

[]button on the front operation panel or wireless remote control and confirm that the output image has been turned to the camera image beforehand. Otherwise, the SD card contents could be broken or failure could be caused to this camera system.

The SD card is composed of parts vulnerable to static electricity. Therefore, due to the impact of static electricity, the SD card could malfunction or its contents could be destroyed. When handling the SD card, take care to avoid static electricity.

The image data viewable on this camera system is limited to the image data saved in this camera system and the image data converted on the dedicated conversion software attached to this camera system.

If the data of the system that is not compatible with this product, a black or gray image will be displayed.

If the camera conversion to the image on the SD card is tried without loading the SD card, the output screen will be blackened. ([NO CARD] will be displayed on the screen.)

After using the SD card, do not leave it inside this product but be sure to remove it.

As an SD card, Panasonic 256MB or 512MB is recommended. The resolutions of the image to be stored are 1280

1024 (SXGA output), 1280 ×720 (HDTV output)

and 1280

960 (XGA output).

This product can store images up to 2048 pcs.

ELMO is not liable for any damage caused by the loss of the data in the SD card or passive damage.

The dedicated conversion software attached to this camera system cannot be used in the SD mode. Also, do not switch the mode to the SD mode during when the dedicated conversion software is in use, or failure could be caused to this camera system.

Presentation using optional SD card (Option)

SD card

OPERATION

PROCEDURE

ENGLISH

■ Saving the Image

(1) Press the []button on the front operating panel or wireless remote control to switch

the image mode to the Camera mode.

(2) Press the

[]button on the wireless remote control.

(3) When the

[]mark lights up on the screen, the image saving starts. When this mark

goes out, the image saving is completed.

Set [Capture] to [SD] on the OSD

Be sure to try shooting and confirm the normal saving of the image beforehand. If the image should be unable to be saved normally due to some problem with this camera or the SD card, we are not liable to compensate for such failure.

The

[]mark on the screen is displayed only when the [Guide] menu is set to ON.

When the SD card is write-protected, the image cannot be saved in the SD card.

When the capacity of the SD card becomes full and no more images can be saved, the

[]mark

does not light up. Then, delete unnecessary images or use a new SD card. When the SD card is in the read/write mode, do not remove the SD card, or failure could occur with

this product. If the image saving is tried when the digital zoom is in operation, the digital zoom will be cancelled and

the image will be saved at the magnification set as of the shipment.

The image file does not record the correct time and date.

■ Displaying the image

(1) When the [] button on the operating panel or the

wireless remote control is pressed to switch the mode to the SD mode, the images saved on the SD card are displayed on the split-screen. The number of divisions can be changed by changing the OSD [Display] setting, which is 3×3 by default.

(2) Move the selection frame (cursor) of the recorded image to the desired image by using

the direction buttons

[]on the wireless remote control, and press the [ENTER]

button on the wireless remote control to display the selected image on the full-screen.

• When the images are displayed on the split screen (3

×3, 4×4)

Move the selection frame (cursor) of the recorded image to the desired image by using the direction buttons []on the wireless remote control, and press the [ENTER] button on the wireless remote control to display the selected image on the full-screen. When the direction button [] is held down, the selection frame (cursor) keeps downward movement as shown in the right figure.

•

When the images are displayed on the full-screen When the direction button []or []on the wireless remote control is pressed, the next image is displayed. When the direction button []or []is pressed, the previous image is displayed again. The image displayed on the full-screen can be zoomed in/out by using the zoom dial on the front operating panel or the zoom button on the wireless remote control. When the image is zoomed in, the displayed part of the image can be scrolled by using the direction buttons [].

(To the top of the next page)

Cursor

Presentation using optional SD card (Option)

(Continued)

3 × 34 × 4

OPERATION

PROCEDURE

ENGLISH

■ Deleting the Image

(1) Press the []button on the front operating panel or wireless remote control to

display the images stored in the SD card in the full screen display mode or the divided screen display mode.

(2) Select the image to be deleted by using the direction buttons

[]on the wireless

remote control.

(3) Press the

[MENU] button on the wireless remote control, and select the [Delete] menu of

the OSD. To delete only the selected image, select [Current]. To delete all images, select [All].

When [Yes] is selected by pressing the

[ENTER] button on the wireless remote control,

the deletion is executed. (To cancel the deletion, select [No].)

■ Slide show

(1) Press the []button on the front operating panel or wireless remote control, and

switch the output image mode to the SD mode.

(2) Display the OSD by pressing the

[MENU] button on the wireless remote control. When

the [START SLIDE SHOW] menu is selected, the slide show starts.

(3) When one of the direction buttons or the

[ENTER] button on the wireless remote control is

pressed, the slide show stops.

• [Effect] (visual effect), [Interval] (display interval) and [Repeat] (repetition) can be set from the [Slide Show Settings] menu of the OSD.

■ Formatting the SD card

When the SD card is formatted, insert the SD card into this product, and execute formatting. (1) Press the []button on the front operating panel or wireless remote control, and

switch the output image mode to the SD mode.

(2) Display the OSD by pressing the

[MENU] button on the wireless remote control, and

select [Format Media].

(3) When [Yes] is selected by pressing the

[ENTER] button on the wireless remote control,

the deletion is executed. (To cancel the deletion, select [No].)

Now, [format] starts.

All data on the SD card is deleted.

OPERATION

PROCEDURE

ENGLISH

Presentation using the supplied software with the USB-connected PC

Set [USB Mode/Ethernet] to [Application] on the OSD.

"Utility Software" is available from the supplied CD-ROM supplied from us. "Utility Software" contains PC link software "Image Mate for Presentation" and TWAIN driver "ELMO TWAIN DS" (VHN) to allow the following operation:

• Transfer of moving/still images to the PC

• Operation of this product from the PC

A PC that Microsoft Windows2000 (SP4 or newer) or XP (SP2 or newer) has been installed is recommended. For details, refer to the "Utility Software" Installation Manual and the help folder with the software.

When the power supply to this camera system is ON, do not connect/disconnect the USB cable, or malfunction will be caused to this camera system.

The USB cable compliant with USB2.0 is recommended.

When this camera is connected with the PC with a USB cable, the camera image frame rate lowers.

Depending on the USB environment used by the PC or the influence of peripheral units, the video transfer could be disturbed.

This does not guarantee the normal operation in any environment.

100

OPERATION

PROCEDURE

ENGLISH

Set [USB Mode/Ethernet] to [Mass Storage] on the OSD.

When this product is USB-connected to the PC, image data in the SD card can be transferred into the PC. The connectable PC is one that has been installed with Microsoft OS Windows2000 (SP4 or newer) / XP (SP2 or newer) / Vista. (1) Turn ON the power supply to this product and to the PC.

(2) Connect this product to the PC with the supplied USB cable.

When this product is connected to the PC for the first time, the required drivers are installed automatically due to the plug-and-play function of Windows. For the second time and thereafter, the drivers are no longer installed.

(3) This product is recognized as a removable disk. The image data in an SD card can be

viewed by using the viewer software of the PC.

• The image data are stored in JPEG format in the following folders:

My Computer

Removable disk

DCIM

100_ELMO

IMAG0001.JPG IMAG0002.JPG

An SD card set in this product cannot be formatted or written, deleted, locked, and unlocked with image data from the PC.

The image data cannot be recorded with the correct date and time.

When the power supply to this camera system is ON, do not connect/disconnect the USB cable, or malfunction will be caused to this camera system.

Do not switch [USB Mode/Ethernet] when this camera system is in USB connection.

The USB cable compliant with USB2.0 is recommended.

When this camera is connected with the PC with a USB cable, the camera image frame rate lowers.

Depending on the USB environment used by the PC or the influence of peripheral units, the video transfer could be disturbed.

This does not guarantee the normal operation in any environment.

Transferring the images from the SD card into the USB-connected PC

101

OPERATION

PROCEDURE

ENGLISH

Displaying the Video Image through Network Connection

Set [USB Mode/Ethernet] to [Ethernet] on the OSD.

When connection is made to http://192.168.0.100 on the browser, its top page opens. When [50%], [75%] or [100%] of [Live] is clicked, the video image is displayed. When [REFRESH] or [CAPTURE] is clicked, the still image is displayed.

To enable the access to this camera system on the web browser, the PC environment should be as follows:

• Windows2000 (SP4 or newer) / XP (SP2 or newer) / Vista has been installed.

• JRE (Java Runtime Environment) 1.5.0_12 or newer has been installed, and Java (Sun) is valid.

• Internet Explorer6 or 7 has been installed.

This camera system does not guarantee the normal access operation on all web browsers.

Depending on the version of the OS, the window size could not be set properly and/or the scroll bar could be displayed.

Depending on the settings of the Windows or virus check software, unfavorable phenomena, such as impossible connection to the camera and disturbed video image display, could occur. In this case, adjust the settings properly following the instruction manual of Windows or the virus check software.

This camera system uses the port of HTTP:80, FTP:20,21, telnet:23. When this camera system is connected to a router, firewall, etc., set the ports of these equipment accordingly.

In the SD mode or when the [PAUSE] button is pressed on the wireless remote control, neither the video image nor the still image can be displayed.

This camera system can be remote-controlled or the status of this camera system can be captured by using the telnet. For the information of its command, etc., contact the sales outlet from which you have purchased this camera system or the nearest branch office or sales office of ours.

The browser address

“http://192.168.0.100” is in default setting. Input the IP address to be used for

the network configuration of [SET UP].

When the resolution settings are renewed with the DIP switch or the settings of [USB Mode/Ethernet] are changed on the OSD, restart the browser.

102

OPERATION

PROCEDURE

ENGLISH

Capturing the Image through Network Connection with the FTP

Set [USB Model/Ethernet] to [Ethernet] on the OSD.

Set [Capture] to [Ethernet] on the OSD. (FTP client function)

The following 2 functions are available:

• FTP client function — Saving the image file in the FTP server by pressing the [ ] button on the wireless remote control

• FTP server function — Capturing the image to the PC through the FTP connection

The time and date of the file displayed on the FTP server are not correct.

This camera system does not guarantee all normal operations through the FTP connection.

This camera system uses the port of HTTP:80, FTP:20,21, telnet:23. When this camera system is connected to a router, firewall, etc., set the ports of these equipment accordingly.

Using [MIC IN] and [AUDIO IN]

The microphone input and the audio input are mixed and output from [AUDIO OUT]. The microphone input level alone can be adjusted on the OSD.

Only the microphone for PCs (electret condenser microphone) can be connected to [MIC IN]. If a microphone other than that for PCs is connected to [MIC IN], this camera system could be broken down. Before connection, carefully check the specifications of the microphone.

P.121

103

OPERATION

PROCEDURE

ENGLISH

When the camera head is set horizontally for shooting ahead of this camera, the image can be rotated automatically by 180°.

Shooting area when the close-up lens holder is opened:

TELE (Telescopic): 500mm –

∞

from the zoom lens

WIDE (Wide-angle): 100mm –

∞

from the zoom lens

Shooting off the stage

Close-up lens holder

When the camera head is set in the horizontal direction, walls, distant views, etc. can be shot. When the object is distant, open the close-up lens holder.

Do not fold the camera column when the close-up lens holder remains open, or the close-up lens could be damaged.

Close-up lens holder

104

ENGLISH

VARIOUS FUNCTIONS AND OPERATIONS

Lighting

This camera is equipped with material illumination for presenting materials, such as printed matter, and base illumination for transparent materials, such as slide films and negative films. When the [ LAMP] button on the front operating panel or wireless remote control is pressed, the fluorescent lamp lights up in 1 – 3 seconds.

•Each time the [ LAMP] button is pressed, the

material illumination lights up → the base illumination lights up → both illuminations go out in this order.

Both the material illumination and the base illumination cannot be extinguished together.

The illumination lamp helps obtain sharp display with good color rendering when it is used for a material surface with low brightness or for a three-dimensional object.

Do not look into the lamp unit of the material illumination. Also, do not touch the lamp unit of the material illumination when it is lighting, since it could be very hot.

Front operating panel

Wireless remote control

WEB remote control

Wireless remote control

WEB remote control

VARIOUS

FUNCTIONS

AND OPERATIONS

WEB remote control

105

ENGLISH

Zoom

When the zoom dial [ , ] on the front operating panel is turned or the zoom button [ ,

] on the wireless remote control is pressed, the

document display range can be adjusted. According to the zoom dial turning angle, the zooming speed varies in 3 steps (3-step speed change).

● Zoom magnification in the Camera mode

When the optical zoom is maximized (about 16×), the digital zoom is activated and the image can be zoomed in further up to 4× (about 64× combined with the optical zoom).

Within the digital zoom range, the image quality is degraded.

Within the digital zoom range, the zoom speed is locked.

When the digital zoom is use, the LCD monitor can be scrolled by using the direction button

[]on

the wireless remote control.

During the video image transfer through the USB connection or during the image transfer through the Ethernet connection, the digital zoom slows down.

When the zoom button on the WEB remote control is clicked once, the zoom operates at regular intervals.

When the image is in transmission through the USB cable, the digital zoom speed get slow.

The digital zoom does not operate through the zoom via the WEB remote control.

If the zoom via the WEB remote control is tried when the digital zoom is in operation, the digital zoom will be cancelled and the maximum zoom-in position of the optical zoom will be resumed.

Front operating panel

Wireless remote control

Front operating panel

VARIOUS

FUNCTIONS

AND OPERATIONS

Wireless remote control

WEB remote control

106

ENGLISH

VARIOUS

FUNCTIONS

AND OPERATIONS

Image Selection

Each time the [], [] button and []button on the front operating panel or wireless remote control are pressed, the image is switched among the camera image, the image inputted in the analog RGB input terminal [RGB IN] and the image stored in the SD card. When the PC or other unit is connected to the analog RGB input terminal [RGB IN], the output image can be switched without spending time and labor exchanging the connection cables.

The image from the DVI output terminal [DVI OUT] cannot be switched to [RGB IN] image.

The display mode of the image from the video output terminal [VIDEO OUT] cannot be switched when [Video Out] is set to [Camera & SD] on the OSD.

If the image mode switching is tried to the SD mode when an SD card is not in this product, the screen will turn black.

By setting [Guide] to [On] on the OSD, the setting contents are displayed on the screen.

To use a notebook-sized PC provided with the external output mode selective function, press the [ ] button on the front operation panel or wireless remote control, and then set the notebook-sized PC side to the external output mode.

If the [PAUSE] button on the wireless remote control is pressed in the SD mode, neither the video image nor the still image can be displayed on the WEB screen.

P.75

Front operating panel

Wireless remote control

107

VARIOUS

FUNCTIONS

AND OPERATIONS

ENGLISH

■

Input image signal that can be output from the video output terminal [VIDEO OUT] into the analog RGB input terminal [RGB IN]

This product may not accommodate any signal other than those listed in the above table.

Depending on the input signal, the image may not be outputted in full size.

This product does not accommodate such synchronized signal as composite and SyncOnGreen.

Signal Frequency Resolution

Mode name VGA1 VGA2 VGA3 VGA@60Hz VGA@72Hz VGA@75Hz VGA@85Hz SVGA@56Hz SVGA@60Hz SVGA@72Hz SVGA@75Hz SVGA@85Hz XGA@60Hz XGA@70Hz XGA@75Hz XGA@85Hz SXGA1 SXGA2 SXGA3 SXGA@60Hz SXGA@75Hz SXGA@85Hz UXGA@60Hz UXGA@65Hz UXGA@70Hz UXGA@75Hz UXGA@85Hz Mac 13 Mac 16 Mac 19 Mac 21 PC98

Horizontal Vertical

kHz Hz MHz

37.861

37.861 85.080

37.927

31.469

37.861

37.500

43.269

35.156

37.879

48.077

46.875

53.674

48.363

56.476

60.023

68.677

67.500

60.000

85.938

63.981

79.976

91.146

75.000

81.250

87.500

93.750

106.250

35.000

49.725

60.241

68.681

24.825

84.889 31.500

85.039

59.941

72.809

75.000

85.008

56.250

60.317

72.188

75.000

85.061

60.004

70.069

75.029

84.997

75.000

60.000

85.003

60.020

75.025

85.024

60.000

65.000

70.000

75.000

85.000

66.667

74.550

74.927

75.062

56.420

Pixel clock

31.500

35.500

25.175

31.500

36.000

40.000

50.000

49.500

56.250

65.000

75.000

78.750

94.500

108.000

148.500

108.000

135.000

157.500

162.000

175.500

189.000

202.500

229.500

30.240

57.283

80.000

100.000

21.052

(Number of lines)

Horizontal Vertical HS/VS

640 640 720 640 640 640 640 800 800 800 800

800 1024 1024 1024 1024 1152 1280 1280 1280 1280 1280 1600 1600 1600 1600 1600

640

832 1024 1152

640

Polarity of synchronized signal

(P: Positive, N: Negative)

350 400 400 480 480 480 480 600 600 600 600 600 768 768 768 768 864 960

960 1024 1024 1024 1200 1200 1200 1200 1200

480

624

768

870

400

P / N N / P

N / P N / N N / N N / N N / N

P / P

P / P N / N N / N

P / P

P / P N / N N / N N / N N / N N / N

WEB remote control

108

VARIOUS

FUNCTIONS

AND OPERATIONS

ENGLISH

Focus

The focus on the object is adjusted.

■ Auto Focus

When the [AF] button on the front operating panel or wireless remote control is pressed, the camera is focused automatically. This product is of one-shot auto focus type. That is, once the camera is focused, the auto focus operation is released, and then focus position is maintained.

The objects listed below may not be brought into focus in the auto focus. In such case, use the manual focus mode.

• Objects having little contrast

• Objects with fine repeated patterns, such as lateral

stripes and cross stripes

• Objects glittering or reflecting strong light

• Objects with bright background or excessive contrast

• Objects that are entirely dark

• Objects located near and far away at the same time

• Objects in motion

If the manual focus button

[FOCUS ·NEAR] or

[FOCUS ·FAR] on the wireless remote control is

pressed when the auto focus is in operation, the auto focus operation will be cancelled.

Front operating panel

Wireless remote control

WEB remote control

109

VARIOUS

FUNCTIONS

AND OPERATIONS

ENGLISH

■ Manual Focus When the focus button [FOCUS ·NEAR] or [FOCUS ·FAR] on the wireless remote control is

pressed, the height on which the camera is focused changes. This function is used for focusing the camera on any portion of a 3D object or the like.

Limit of focus adjustment:

• With close-up lens TELE (Telescopic) : 250 – 410mm (9.8 – 16.1 in) from close-up lens WIDE (Wide-angle) : 85 – 410 mm (3.3 – 16.1 in) from close-up lens

• Without close-up lens TELE (Telescopic) : 500mm –

∞

(19.7 in – ∞) from zoom lens

WIDE (Wide-angle) : 100mm –

∞

(3.9 in – ∞) from zoom lens

Even if the focus button on the WEB remote control is held down for a long time, the intended operation will not continue accordingly. To adjust the focus continuously, repeat clicking the focus button.

Wireless remote control

Limit of focus adjustment:

• With close-up lens TELE (Telescopic) : 250 – 410mm (9.8 – 16.1 in) from close-up lens WIDE (Wide-angle) : 85 – 410 mm (3.3 – 16.1 in) from close-up lens

• Without close-up lens TELE (Telescopic) : 500mm –

∞

(19.7 in – ∞) from zoom lens

WIDE (Wide-angle) : 100mm –

∞

(3.9 in – ∞) from zoom lens

WEB remote control

110

VARIOUS

FUNCTIONS

AND OPERATIONS

ENGLISH

Brightness Adjustment

Front operating panel

Wireless remote control

The default setting is [Auto] (Auto Brightness Adjustment).

In the Manual Brightness Adjustment, the brightness is locked and the change in the object brightness is not tracked.

When adjusting the brightness manually, even if the brightness buttons [ ] and [

NORMAL] on the front operation panel are pressed together or the [NORMAL] button on the wireless remote control or WEB remote control is pressed or clicked, nothing will work.

When [Guide] is set to [On] on the OSD, the setting contents are displayed on the screen.

When any button on the WEB remote control is clicked once, operation continues ar regular intervals.

WEB remote control

When either of the brightness adjustment buttons [

] on the front operation panel or either of the

brightness adjustment buttons [NORMAL

]

on the wireless remote control or WEB remote control is pressed or clicked, the image brightness is adjusted through the adjustment of the lens iris. This adjustment is performed in 2 adjustment modes as described below. Each mode is set by selecting [BRIGHTNESS] on the OSD.

■ Auto Brightness Adjustment

■ ([Brightness] is set to [Auto] on the OSD.)

It is so set that the brightness to be tracked automatically can be adjusted. When the brightness adjustment buttons []and []on the front operation panel are pressed together or the [NORMAL] button on the wireless remote control or WEB remote control is pressed or clicked, the current settings are reset to the default settings.

■ Manual Brightness Adjustment

■ ([Brightness] is set to [Manual] on the OSD.)

It is set so that the brightness can be locked to any level.

111

VARIOUS

FUNCTIONS

AND OPERATIONS

ENGLISH

State Presetting

The setting position of this product can be saved/called. Up to 8 positions can be saved. The presets that can be saved are as follows:

• Current zoom field angle (Optical zoom range)

• Brightness status

• White Balance state

• R-Gain

(When the white balance is set to Manual)

• B-Gain

(When the white balance is set to Manual)

•

Edge Effect settings (When Graphics mode is selected)

•

Gamma value settings (When Graphics mode is selected)

• Lighting ON/OFF

• Color/B&W selection settings

• Image Rotation state

• Mode settings

• Posi/Nega settings

• Microphone volume

The saved state can be retained even if the power supply is turned OFF.

Rotated position cannot be saved to "Power On" setting. (Memory No.8 on remote control)

The zoom angle of the digital zoom is not saved. When the digital zoom status is saved, the zoom angle to be saved is to the full extent of the telescopic [ ] side of the optical zoom range.

■ Presetting

When the [PRESET] button on the wireless remote control is pressed and then "within 4 seconds", the memory number button on the wireless remote control is pressed, the present camera using status is memorized in the selected memory number. When the [PRESET] button on the wireless remote control is pressed and then the memory number [8] button on the wireless remote control is pressed, the contents of this setting are called when the power is turned on the next time.

■ Calling

When the [CALL] button on the wireless remote control is pressed and then "within 4 seconds", the memory number button on the wireless remote control is pressed, the settings of the selected memory number are called. When [Call]

→ [Default]

on the OSD are selected, the factory-set settings are called.

Wireless remote control

112

VARIOUS

FUNCTIONS

AND OPERATIONS

ENGLISH

Microphone Input

Adjusting the microphone volume When []of [Mic Volume] is pressed on the OSD, the volume level bar is displayed. Then, adjust the volume by using the direction buttons []on the wireless remote control.

When the volume is brought to the left end of the level bar, the microphone falls into the mute status.

White Balance

■ How to use [Auto]

To be used for adjusting the white coloring automatically according to the status of the document. Default setting as of the shipment from our factory is [Auto].

■ How to use [One-Push]

To be used in case of the disruption of the image color balance due to the document status.

■ How to use [Manual]

When [White Balance] is set to [Manual] on the OSD, the white balance is fixed, and furthermore, [R-Gain] and [B-Gain] can be adjusted on the OSD.

The color temperature range that can be followed automatically is around 3000K — 8000K.

When [Guide] is set to [On] on the OSD, the setting details are displayed on the screen.

If the precise automatic adjustment is impossible due to the object or light source, adjust the white coloring automatically by imaging a white object, and set [White Balance] to [One-Push] on the OSD.

Flickerless Ethernet Status Call Mic Volume

113

ABOUT

RS-232C

ENGLISH

Setting Up

q Connect this product to a PC with an RS-232C cable.

When using an RS-232C cable available on the market, make sure that pin connections are the same as below.

To protect this product and the PC, be sure to turn OFF the power supply to all units before starting the connection work.

w Start the PC, and set the communication mode of the RS-232C to the communication

mode of this product.

For the information how to set the communication mode of the RS-232C, refer to the instruction manual of the PC.

e Start the PC program to operate this product.

r Control through the RS-232C will start.

For communication control, be sure to take the above steps for settings.

This product can be controlled from a PC connected to this product through the RS-232C terminal [RS-232C].

Cable Connection

6 RS-232C SPECIFICATIONS

This product side

(DSUB-9P)

DSUB-9P (Female)

54321

9876

RI (CI)

RXD

TXD DTR

DSR

RTS CTS

1 2 3 4 5 6 7 8 9

PC side (DSUB-9P)

CD RXD TXD DTR SG DSR RTS CTS RI

PC side: DSUB-9P (Female)

54321

9876

114

ABOUT

RS-232C

ENGLISH

Data Format Specification

This command is executed in the form of 1-command/1-packet. The next command is not accepted until the previous processing is completed.

• The communication command always starts with STX (Start of Text), and ends with ETX (End of Text).

• If the communication format of command name is wrong, NAK (Negative Acknowledge) will be sent from this product as a result of failing to receive correctly.

• When communication format is received correctly, this product sends ACK (Normal Acknowledge).

■ Operation Command (PC → This product)

Each operation command is executed in ASCII code, and transmitted in a set of 7 bytes as follows:

■ Response Data Format (This product → PC)

All response data is transmitted as ASCII code, corresponding to the parameters in the operation command table.

• Status 0

• Status 2

•

ROM Ver0 (MASTER)

• ROM Ver1 (SLAVE)

• ROM Ver2 (LENS)

• ROM Ver3 (MAIN) . . . Upper 6 bytes

• ROM Ver4 (MAIN) . . . Lower 4 bytes

(PC)

(This product) → ACK

T X

Command

Parameter

Data

Lighting

Brightness

mode

S T X

56H

S T X

56H

S T X

56H

S T X

Status

display

Gamma

selection

rotation

48H

Posi/

Nega


Color/

B&W

Edge

effect

4EH

Display

mode

White

balance

Display

Text

20H

Pause

Video output

Flickerless

20H

USB

Mode/

Ethernet

E T X

115

ABOUT

RS-232C

ENGLISH

UART Communication Format

Commands, parameters and data are all transmitted in ASCII code.

Transmission Specifications

• Full duplex start-stop sync. mode

• Start bit : 1 bit

• Data bit : 8 bits

• Stop bit : 1 bit

• Parity bit : None

• X parameter : None

• Baud rate (Communication speed) : 9600bps

Function

Command

Parameter Data Contents

Auto Focus AF 0 ■■ To perform the one-shot auto focus Focus adjustment FO + (Near) ■■ To adjust the focus – (Far) 0 (Stop) Zoom adjustment ZO + (Tele) ■■ To adjust the zoom – (Wide) 0 (Stop) Brightness IR + (Open) ■■ To adjust the brightness adjustment – (Close) 0 (Stop) 1 (Auto) 2 (Manual) Lighting selection PL 0 (OFF) ■■ To turn ON/OFF the lighting 1 (BASE) 2 (UPPER) Display mode AV 0 (Camera) ■■ To switch the display mode selection 1 (RGB IN) 2 (SD) Video output MO 0 (All Mode) ■■ To switch the video output selection 1

(Camera & SD) Direction KE 0 (Menu) ■■ To scroll in the direction indicated by arrow when 1 (Enter) the digital zoom is in operation 2 (→) To select and determine an image on the split 3 (←) screen 4 (

↑

)

5 (

↓

) Pause FZ 0 (OFF) ■■ To freeze the image 1 (ON) Guide GU 0 (OFF) ■■ To set whether the main unit operation state should 1 (ON) be displayed on the screen or not Display DP 0 (Single) ■■ To select whether the images in the SD card mode 1 (3×3) should be displayed on the split screen or not 2 (4×4) Slide show SS 0 (Stop) ■■ To start/stop the slide show 1 (Start)

116

ABOUT

RS-232C

ENGLISH

Function

Command

Parameter Data Contents

Slide-show image SE 0 (Left to right) ■■ To set the visual effect of the slide show feed effect 1 (LT to RB) 2 (RT to LB) 3 (None) Slide-show object ST 0 (All) ■■ As a slide show target, select all images stored on file 1 (Locked) the SD card or only the locked image files Slide-show feed SO 0 (FWD) ■■

To set whether the slide show should be proceeded

order 1 (BWD)

in the ascending order or in the descending order Slide-show image SI 0 (3s) ■■ To set the interval of the image switching in the feed interval 1 (5s) slide show 2 (10s) 3 (15s) 4 (30s) Slide-show repeat SR 0 (OFF) ■■ To proceed the slide show repeatedly 1 (ON) File delete DE 0 (Current) ■■ To delete an image file in the SD card 1 (All) File lock SL 0 (Current) ■■ To lock an image file in the SD card 1 (All) File unlock SU 0 (Current) ■■ To unlock the locked image file in the SD card 1 (All) Format SF 0 ■■ To format the SD card Image save CA 0 ■■ To save the image on the SD card or FTP-transfer the image USB Mode/ UM 0 (Mass Storage) ■■ To switch the USB Mode/Ethernet Ethernet switching 1 (Application) 4 (Ethernet) Gamma setting GM 0 (High) ■■ To set the gamma value of the image 1 (Normal) 2 (Low) Flicker-less FL 0 (60Hz) ■■ To set the flicker-less 1 (50Hz) Microphone MV + (UP) ■■ To adjust the microphone volume volume adjustment – (DOWN) Capture mode CM 0 (SD) ■■ To switch the Capture mode switching 1 (Ethernet) Ethernet

ED 0 ■■ To reset the Ethernet status to the default setting

default status

117

ABOUT

RS-232C

ENGLISH

Connection

If the RS-232C cable is not connected correctly between this product and the PC, no acknowledgement is transmitted. Connect the RS-232C cable correctly, and fix it firmly with the connector set screws before starting the operation.

For "■■" in the data column, transmit the SPACE [20H] twice.

Function

Image rotation RO 0 (0°) ■■ To turn the image 1 (180°) Edge effect AP 0 (OFF) ■■ To set the edge enhancement 1 (Low) 2 (Mid) 3 (High) White balance AW 0 (Manual) ■■ To switch the white balance mode 1 (Auto) 2 (One Push) 3 (R_Up) 4 (R_Down) 5 (B_Up) 6 (B_Down) Text CT 0 (GRAPHICS) ■■ To set the contrast 1 (TEXT1) 2 (TEXT2) 3 (TEXT3) Posi/Nega NP 0 (Posi) ■■ To set the Posi/Nega 1 (Nega) Color/B&W CB 0 (Color) ■■ To set the Color/B&W 1 (B&W) Local lockout LL 0 (OFF) ■■ To invalidate the operations of the front operation 1 (ON) panel and the wireless remote control Default DF 0 ■■ To reset to the default settings Status request QS 0 ■■ To inquire about the status of the camera system 2 ROM version QR 0 ■■ To inquire about the ROM version 1 2 3 4 ACK check SA 0 (OFF) ■■ To switch the ACK check mode 1 (ON) CR addition SC 0 (OFF) ■■ To switch the CR addition settings 1 (ON)

Command

Parameter Data Contents

TROUBLESHOOTING

ENGLISH

7 TROUBLESHOOTING

Check the following items. If any abnormality is found, consult the seller from whom you have purchased this product or our branch/office near your location.

Symptoms and Confirmation

Symptom Check this item

No image is displayed • The cable is not connected correctly to the video-in terminal of the on the TV monitor. monitor.

• The power cord is disconnected from the wall AC outlet.

• The DC cord plug of the AC adapter is off the power socket of this

camera system.

• The power switch is not ON.

• Zoom is set at the TELE side, displaying only the white/black part of the

document.

• The power switch is turned ON immediately after it is turned OFF. In this case, this product may not start immediately. Wait for several seconds after turning OFF the power switch, and then turn it ON.

The image is out of • The document (object) is too close to the lens. focus. • Zoom is at the TELE side after focusing at a wide angle (at the WIDE

side). Focus on the point of max. at the TELE side.

• In the auto focus, focusing is difficult in some cases.

The lamp does not • For the protection purpose, the lamp is arranged to light up after light up quickly. preheating for 2 seconds. This is not a fault.

The video output • The video output is set to the PAL system. If this product, set to the PAL image is disarrayed. system, is connected to the monitor specially designed for the NTSC

system, the video image may not be outputted normally but be disarrayed or in black and white. In such case, switch the system of the video output by referring to "DIP Switch" at P. 75.

The image is too dark. • The intensity of the lighting is not sufficient. Press the

[]button on

the front operating panel or wireless remote control to turn ON the lamp.

• The brightness has been adjusted to the close side. Adjust the brightness so that the image can become bright.

The image is striped. • This may be interference fringes between dots of printed matter

and TV scanning lines or CMOS pixels. This may be mitigated by changing the projection range.

• When using an LCD projector, vertical stripes may appear on the screen. This may be mitigated by manually adjusting the dot clock frequency on the projector side.

The brightness tone is • This may be mitigated by switching gamma settings. out of order.

The material (object) • Initialize the camera position by referring to P. 90. does not come to the center of the display

The microphone volume • Only the microphone for PCs (electret condenser microphone) can be is not output. connected to [MIC IN]. Before connection, carefully check the

specifications of the microphone.

The network function • Reconfirm this camera system and the network configuration of the PC does not operate. to be connected to this camera system, and then, cross-check them with

the phenomena described below.

• Reconfirm the restrictive conditions (e.g., number of connections) and the setting details of this camera system, as well.

118

119

TROUBLESHOOTING

ENGLISH

Symptom Check this item

The network operation • The WEB connection works only in the following environment: is unstable. 1. The OS installed is Microsoft Windows2000/XP/Vista.

2. JRE1.5.0_12 or newer has been installed and Java (Sun) is valid.

3. Internet Explorer6 or 7 has been installed.

The LAN cable cannot • The LAN connector (RJ45) is located on the main unit side. be connected.

The LAN connector link • Power is not supplied to this camera system or the unit to be connected lamp (orange LED) to this camera system. Check whether the cable is connected firmly, and cannot light up. then turn ON the power supply.

• The cable is disconnected. Check the conduction between the cable terminals.

• The cable used is wrong. Basically, when the unit to be connected to this camera system is a PC, “cross cable” or “LAN cross cable (attached to this camera system)” is used, and when it is a hub or router, “straight cable” is used. Actually, the specifications of the unit should be checked.

Connection from the • The IP address of this camera system has not been designated. client is impossible. Designate the IP address set in this camera system.

• The IP address of the client is not compatible with the network of this camera system. To establish the connection from the client to this camera system, the network address (192.168.1.* when this camera system settings are default) should be the same between the client and this camera system. * If the IP address of this camera system has escaped your memory,

refer to “IP Address” (P. 77) or “Ethernet” (P. 78) of the OSD.

• The router settings are wrong. Check the network configuration of this camera system and the client, and set the router accordingly.

The network • The authority “user” was used for login. Use the authority “root” for configuration page login. cannot be accessed.

The FTP client • Use the authority “root” or “user” for login. configuration page cannot be accessed.

Image capture through

• [USB Mode/Ethernet] has not been set to [Ethernet] on the OSD.

the network is impossible.

• The mode is not the camera mode. The camera image cannot be captured in the SD mode.

• [PAUSE] is working in the camera mode.

Image capture through

• [USB Mode/Ethernet] has not been set to [Application] on the OSD.

Image Mate is impossible. Image capture through • [Capture] has not been set to [Ethernet] on the OSD.

the FTP client is impossible.

Image cannot be saved • [Capture] has not been set to [SD] on the OSD. on the SD card.

120

TROUBLESHOOTING

ENGLISH

Replacement of Lighting Lamp (Fluorescent Lamp)

The lighting lamps (fluorescent lamps) are expendables. When any of them begins to shimmer or dim, replace it.

For the replacement of the lamp, consult the dealer from whom you have purchased this product or our branch/office near your location.

About the long-time use

When this camera system is used for a long time exceeding the warranty period or it is used for a long time with the power always ON, the performance or quality of this camera system could be degraded due to the expiry of the service life of some parts. In this case, the exhausted parts can be replaced with payment. For this replacement, contact the sales outlet from which you have purchased this camera system or the nearest branch office or sales office of ours.

121

SPECIFICATIONS

ENGLISH

■ General

8 SPECIFICATIONS

Item Specifications Power source 12VDC (AC adapter: 100 ~ 240VAC) Power consumption 35W (AC adapter included) Outside dimensions 457×562×138mm (18.0×22.1×5.4 in) (When folded)

457×519×587mm (18.0×20.4×23.1 in) (When set up)

Weight Approx. 8.5kg (18.7 lbs) (Main body only) Input selection Main body / External one system Output terminal DVI output DVI-D 24P connector, female ×1

RGB output Mini DSUB 15P connector, female ×1 Composite video

RCA pin jack / 75Ω unbalanced ×1

output

(NTSC/PAL)

Audio output (stereo) RCA pin jack / compatible impedance ×1

1kΩ or more 300mV (rms)

Input terminal RGB input Mini DSUB 15P connector, female ×1

Audio input (stereo) 300mV (rms) impedance ×1

20 kΩ or more

3.5mm stereo mini jack

Microphone input

3.5mm jack / compatible impedance ×1

(mono) 6.9kΩ 30mV (rms)

Ext. control terminal RS-232C Dsub 9P connector, male ×1

USB (2.0 compliant) Type B receptacle ×1 Ethernet 8-core modular type (RJ-45) ×1

Memory interface SD card slot ×1

■ Microphone input circuit

6.8kΩ 100Ω

2.4V

µF10µF

0.33

µF

IC input

122

SPECIFICATIONS

ENGLISH

■ Main Camera

Item Specifications Lens f = 4.9 ~ 78.4mm (16-time zoom), F = 2.7 Shooting speed 30 frames/sec Shooting area

SXGA 405×324mm (15.9×12.8 in) max. 30×24mm (1.2×0.9 in) min. HDTV 405×224mm (15.9×8.8 in) max. 30×17mm (1.2×0.7 in) min. XGA 405×303mm (15.9×11.9 in) max. 30×23mm (1.2×0.9 in) min.

Limit of focus With close-up lens:

adjustment TELE side : 250 ~ 410mm (9.8 ~ 16.1 in) from close-up lens

WIDE side : 85 ~ 410mm (3.3 ~ 16.1 in) from close-up lens

Without close-up lens:

TELE side : 500mm ~ ∞ (19.7 in ~ ∞) from zoom lens

WIDE side : 100mm ~ ∞ (3.9 in ~ ∞) from zoom lens Optical zoom 16× Digital zoom 4× Focus Auto/Manual Brightness Auto (level adjustable) / Manual Image pick-up element 1/3˝ 1.3M CMOS Total picture elements Horizontal 1312, Vertical 1032 ... Approx. 1,350,000 pixels Effective picture elements SXGA Horizontal 1280, Vertical 1024

HDTV Horizontal 1280, Vertical 720

XGA Horizontal 1280, Vertical 960 Synchronizing system Internal Resolution Analog RGB output:

Horizontal 800TV lines or more Vertical 800TV lines or more

Video output:

Horizontal 450TV lines or more

DVI output TMDS data signal 0.5 (Vp-p)

50Ω (Terminated) Analog RGB output 0.7 (Vp-p) 75Ω unbalanced,

Synchronized signal: SXGA Positive polarity

HDTV Negative polarity

XGA Negative polarity Composite video output Compliant with NTSC/PAL White balance Full auto / One-push / Manual Video output selection Provided (NTSC/PAL) Posi/Nega conversion Provided Color/B&W selection Provided Image rotation Provided

(0°/180°, Automatic rotation by 180° for forward shooting) Text mode Text1 / Text2 / Text3 / GRAPHICS Gamma setting Provided (GRAPHICS mode only) Edge enhancement Provided (GRAPHICS mode only) Pause Provided Image recording Provided (SD card) Split display Provided (SD card image / 9-splits / 16-splits) Slide show Provided (SD card image)

SXGA: Horizontal frequency 63.98kHz; Vertical frequency

60.02Hz (1280×1024 at 60Hz); Compliant with VESA HDTV: Horizontal frequency 44.7kHz; Vertical frequency 60Hz (1280×720 at 60Hz); Compliant with HDTV XGA: Horizontal frequency 48.363kHz; Vertical frequency 60.004Hz (1024×768at 60Hz); Compliant with VESA

123

SPECIFICATIONS

ENGLISH

■ Network

Item Specifications Interface 10BASE-T/100BASE-TX (RJ-45) Compliant protocol

IP, ARP, ICMP, TCP, HTTP, FTP, telnet

Recommended browser

Internet Explorer6.0 or newer Compliant OS Windows2000 (SP4 or newer)/XP (SP2 or newer)/Vista Connection port No.

HTTP:80, FTP:20,21, telnet:23 Compliant language

Japanese, English Image format Motion-JPEG Image size SXGA: Horizontal 1280, Vertical 1024

HDTV: Horizontal 1280, Vertical 720

XGA: Horizontal 1280, Vertical 960 Frame rate Max. approx. 5fps Number of clients

5 clients simultaneously connectable to live screen

Number of clients

1 clients simultaneously connectable to FTP server

Still image display

JPEG Main unit

ZOOM, LAMP, BRIGHTNESS, FOCUS, GRAPHICS, TEXT, EDGE EFFECT, remote function

IMAGE ROTATION, POSI/NEGA, COLOR/B&W

■ Supplied Accessories

For the RCA pin, use a pin plug compliant with EIAJ RC-6703.

The above specifications are subject to change without notice.

Name Quantity Power adapter 1 Power cord (1.5m) 1 Video cable (RCA pin connector) (3m) 1 Analog RGB cable (DSUB 15P connector) (2m) 1 DVI cable (2m) 1 Infrared wireless remote control 1 Batteries (Type R03, AAA) 2 Instruction Manual for P100N 1 Warranty Card for P100N 1 USB cable (1.8m) 1 Utility Software Installation Manual 1 Utility Software CD-ROM 1 Ethernet cross cable (1m) 1

■ Lighting

Item Specifications

Lighting

High frequency lighting mode, twin fluorescent lamp, Type 9 (Model: FPL9EX-N)

Base illumination Cold-cathode tube

124

SPECIFICATIONS

ENGLISH

The software contained in this camera system is composed of several independent components. Some of them are applied with GPL/LGPL.

For the information of GPL/LGPL and ACME Labs Freeware License, access to the following URL for reference: http://(IP address of this camera system)/license.html

Disclaimers

Please be informed that Elmo shall not be liable at all to any damage, direct or indirect, caused by the use of our Ethernet function.

Depending on the software installed in your PC or peripheral unit connected to your PC, the functional operation of the Ethernet of this camera system could be affected.

125

ENGLISH

Trademark Acknowledgements

is a trademark of ELMO Co., Ltd. VESA and SVGA are registered trademarks of Video Electronics Standards Association. SXGA, VGA and XGA are trademarks or registered trademarks of International Business

Machines Corporation.

: SD logo is a trademark.

Microsoft, Windows, Internet Explored are registered trademarks of Microsoft Corporation in the United States and other counties.

Java is a trademark of Sun Microsystems, Inc. Any other company names and product names appeared in this manual are trade names,

trademarks or registered trademarks of the respective relevant companies.

ELMO P100N User's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
