Elmo MO-1 User manual
Please read this instruction manual carefully before using this product
and keep it for future reference
INSTRUCTION MANUAL
VISUAL PRESENTER
ＭＯ-１
IMPORTANT SAFEGUARDS
■ Read Instructions
All the safety and operating instructions should be read before the appliance is
operated.
■ Retain Instructions
The safety and operating instructions should be retained for future reference.
■ Heed Warnings
All warnings on the product and in the operating instructions should be adhered to.
■ Follow Instructions
All operating and use instructions should be followed.
■ Cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
■ Attachments
Do not use attachments not recommended by the product manufacturer as they may
cause hazards.
■ Water and Moisture
Do not use this product near water - for example, near a bath tub, wash bowl, kitchen
sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.
■ Placement
Do not place this product on an unstable cart, stand, tripod, bracket, or table. The
product may fall, causing serious injury to a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product.
Any mounting of the product should follow the manufacturer’s instructions, and
should use a mounting accessory recommended by the manufacturer.
■ Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation of the product and to protect it from overheating, and these openings must
not be blocked or covered.
The openings should never be blocked by placing the product on a bed, sofa, rug, or
other similar surface. This product should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
2
■ Power Sources
This product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home consult your
appliance dealer or local power company. For products intended to operate from battery
power, or other sources, refer to the operating instructions.
■ Grounding or Polarization
This product may be equipped with either a polarized 2-wire AC line plug (a plug
having one blade wider than the other) or a 3-wire grounding type plug, a plug having
a third (grounding) pin.
The 2-wire polarized plug will outlet, try reversing the plug. If the plug still fails to fit,
contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug. The 3-wire grounding type plug will fit into a grounding
type power outlet. This is a safety feature. If you are unable to insert the plug into the
outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the grounding type plug.
■ Power-Cord Protection
Power-supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where they exit from the product.
■ Lightning
For added protection for this product during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent damage to the product due
to lightning and power-line surges.
■ Overloading
Do not overload wall outlets, extension cords, or integral convenience receptacles as
this can result in a risk of fire or electric shock.
■ A product and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the product
and cart combination to overturn.
■ Object and Liquid Entry
Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
■ Servicing
Do not attempt to service this product yourself as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all servicing to qualified
service personnel.
3
■ Damage Requiring Service
Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
• When the power-supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the product.
• If the product has been exposed to rain or water.
• If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an
improper adjustment of other controls may result in damage and will often require
extensive work by a qualified technician to restore the product to its normal
operation.
• If the product has been dropped or damaged in any way.
• When the product exhibits a distinct change in performance - this indicates a need
for service.
■ Replacement Parts
When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as
the original part. Unauthorized substitutions may result in fire, electric shock or
other hazards.
■ Safety Check
Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
■ Heat
The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers) that produce heat.
4
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature
SA 1966
SA 1965
5
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
FOR UNITED STATES USERS:
INFORMATION
USER-INSTALLER
CAUTION:
Your authority to operate this FCC verified equipment could be voided if you make changes or
modifications not expressly approved by the party responsible for compliance to Part 15 of the FCC
rules.
THIS IS A CLASS A PRODUCT.
IN A DOMESTIC ENVIRONMENT THIS PRODUCT MAY CAUSE RADIO
INTERFERENCE IN WHICH CASE THE USER MAY BE REQUIRED TO TAKE
ADEQUATE MEASURES.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
Handling the cord on this product or cords associated with accessories sold with this product, will
expose you to lead, a chemical known to the State of California to cause birth defects or other
reproductive harm.
WARNING:
Wash hands after handling.
6
BEFORE YOU USE
■ The supplied power cord and AC adapter are designed for exclusive use with this
product. Do not use them with other equipments.
■ Be sure to use the power cord applicable to your local power specifications. If the
product was sold in Japan, use the AC adapter sold with the product with 100VAC
and 50 or 60 Hz.
■ Do not knot or coil the power cord or AC adapter cord or wrap them around the AC
adapter. Doing so may damage the cords, causing fire or electric shock.
■ When storing the product, do not leave it under direct sunlight or by heaters. It may
be discolored, deformed, or damaged.
■ Do not place this product in any humid, dusty, salt bearing wind, or vibrating
locations.
Use it under the following environmental conditions:
Temperature: 0°C - 40°C (32°F - 104°F)
Humidity: 30% - 85% (No condensation)
■ Use a soft, dry cloth for cleaning.
Do not use any volatile solvent such as thinner or benzene.
■ Do not point the camera lens directly at the sun. It may be damaged and you may not
be able to take pictures
■ Luminescent and Black Spots
■ There may be some pixels that do not properly operate due to the use of CMOS Area
Image Sensors made-up of many pixels. Though luminescent or black spots may be
found on the screen, it is a phenomenon peculiar to the CMOS Area Image Sensors
and is not a malfunction.
■ Follow the guidelines below to prevent the unit from dropping or overturning.
• Use the product on a stable base, desk, or table. Do not place the product on an
unstable base or slanted location.
• Place or wire the unit to prevent the AC adapter cord or video cable from pulling.
■ Carry the product by holding the lower part of the main unit in both hands. Never
hold the product by the arm or the camera head.
■ Pay careful attention when using (including setting-up and storing) or transferring
the product to prevent the camera head from receiving any shocks.
■ Do not look directly into the LED light. If you look directly into it at point-blank range,
your eyes may be injured.
7
N o t e
In the description of this manual, the notation is as follows:
-SD memory card, SDHC memory card → “SD card”
■ Depending on the type of SD card being used, it may not be used with the product.
■ Transfer the data from the SD card onto a device such as a PC to save a backup copy.
Malfunction of the product or repairs to it may cause the data saved in the SD card to
be deleted.
■ If this product is used for longer than the warranty period, its performance and
quality may deteriorate due to the lifetime of its parts. To purchase replacement parts,
consult the dealer from whom you purchased this product or our branch/office near
your location.
■ Menu
Some functions may not be set or operated depending on the mode or the menu
settings being used.
■ The product may not operate properly if a USB hub is used to connect the product
and a PC.
■ Do not commercially use or transfer images taken by the product without the
permission of the copyright holder except for personal use.
■ Do not use the camera in locations where taking images are prohibited.
■ Important notes when connecting HDMI cable.
• Use HDMI cable with Type-D Micro connectors.
• Use HIGH SPEED HDMI cable with HDMI logo.
HDMI cable that is not compliant with HDMI standard cannot be used.
• Pay attention not to apply excessive force when an external device is connected to HDMI.
It may cause damage or malfunction.
• Depending on the devices to be connected to HDMI image or audio may not output properly.
In such cases, disconnect HDMI cable and reconnect it. It may improve the problem.
When performing above connection checking, make sure the power supplies of the
product and the TV are OFF.
If the problem still remains, try to change HDMI cable.
8
CONTENTS
IMPORTANT SAFEGUARDS............................................................................................. 2
BEFORE YOU USE ........................................................................................................... 7
１ BUNDLED ITEMS ........................................................................................................ 11
２ PART NAMES AND FUNCTIONS ................................................................................12
Appearance ...................................................................................................................12
Operating panel .............................................................................................................13
Rear panel and cable connections .................................................................................15
Side Panel ....................................................................................................................18
Bottom panel .................................................................................................................19
３ PREPARATION AND CONNECTION ...........................................................................20
Setting Up ......................................................................................................................20
Moving Parts of the Mobile Document Camera ..............................................................21
Connecting to a projector or a monitor ................................ ...........................................22
Connecting to a PC .......................................................................................................23
Turning on the power .....................................................................................................24
Power supply from the AC adapter ................................................................................24
Power supply from the USB ...........................................................................................24
4 SHOOTING IMAGES ....................................................................................................25
Adjusting the size ..........................................................................................................25
Adjusting the brightness ................................................................................................25
Adjusting the focus ................................................................................................ ........25
Turning the lamp ON/OFF .............................................................................................25
Pausing the video ..........................................................................................................25
Saving a still image ........................................................................................................26
Rotating the image.........................................................................................................26
Switching the output video .............................................................................................27
In the order that the output video changes (in the order that the LED lights up) ................... 28
5 CHANGING THE SETTINGS ........................................................................................29
Changing the settings ....................................................................................................29
Descriptions of each menu ................................ ............................................................30
Camera output display mode menu ...............................................................................30
Setting Date/Time（Clock Set） ....................................................................................32
6 USING A USB .............................................................................................................33
Installing the software ....................................................................................................33
Connecting to a PC .......................................................................................................33
Controlling the product from a USB-connected PC ........................................................34
9
7 USING AN SD CARD ...................................................................................................35
Saving images ...............................................................................................................36
Displaying the saved data ..............................................................................................36
Thumbnail display mode ................................................................................................37
8 TROUBLE SHOOTING .................................................................................................38
9 SPECIFICATIONS ........................................................................................................40
General..........................................................................................................................40
Main Camera .................................................................................................................40
Illumination Device ........................................................................................................41
Trademarks and License ...............................................................................................42
Repairable Period ..........................................................................................................42
10
VISUAL PRESENTER
Product's package has the following contents. Contact your dealer if any of the following
items are not included in the package you purchased.
Power cord
USB cable
AC adapter
P12
P16
P16
P24
※North America only
CD-ROM
Manual/Image Mate CD
Contents of the CD
-Image Mate
-Instruction manual
-Basic Startup Guide
Image Mate
Instruction manual
Important Safeguards
Warranty card※
１ BUNDLED ITEMS
11
Name
①
Camera head
②
Arm
③
Operating panel
④
Rear panel
⑤
Side panel
⑥
Bottom panel
⑦
Lamp
⑧
Microphone
P22 P13
P15
P18
P19
P25
⑥
④
①
②
③
⑤
⑦
⑧
２ PART NAMES AND FUNCTIONS
Appearance
Operation of the main unit:
12
Mark
Name
Function
①
Power
To turn the power ON/OFF.
Power ON ： Blue light
Power OFF (standby status) ： Red light
②
Lamp
To turn the lamp ON/OFF
③
Image Rotation
To rotate the image
Still image (Captured image)： Rotates by 90°
Live image (Camera image)： Rotates by 180°
④
Image Freeze
/ Capture
To pause the camera image by pressing this button for
a short moment (less than 1 second). Press this button
again to restart.
To save a still image to the SD card by pressing this
button for long (more than 1 second).
⑤
Menu
To show/hide the menu on the screen
⑥
Selection
To switch the output video.
LED of the selected output video ⑫～⑮ lights up.
⑦
Auto Focus
To automatically focus on the object.
AF works once when this button is pressed.
N o t e
①
②
③
④
⑤
⑫
⑩
⑨ ⑬ ⑭
⑮
⑥
⑧
⑪
⑦
The lamp is always OFF when power is turned on.
P29
P28
Operating panel
13
Loading...
