Elmo CRA-1 User Manual

ELMO Wireless Slate / Tablet

CRA-1

User's Guide

Please read this manual well before using CRA-1.

Please preserve this manual in preparation for the emergency importantly.

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in a way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This marking is located at the bottom of product. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

PRODUCT TO RAIN OR MOISTURE.

WARNING: Handling the cord on this product or cords associated with accessories sold with this product, will

expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm.

Wash hands after handling.

NOTICE:

This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause

undesired operation.

Changes or modifications made to this equipment not expressly approved by (manufacturer name)

may void the FCC authorization to operate this equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or more of

the following measures: • Reorient or relocate the receiving antenna. • Increase the separation

between the equipment and receiver. • Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV

technician for help.

Radiofrequency radiation exposure Information:

The radiated output power of the device is far below the FCC radio frequency exposure limits.

Nevertheless, the device shall be used in such a manner that the potential for human contact

during normal operation is minimized.

Usage Precautions

About radio waves used by this product

This product uses radio waves on the 2.4 GHz band. When using this product, a radio

station license is not necessary. However, please note the following cautions.

Do not use near the following:

■ Microwave ovens, industrial, scientific or medical equipment, such as pacemakers

■ In-factory radio stations for mobile unit identification systems (radio stations that require

a license) used in production lines of factories.

■ Specified low power radio stations (radio stations that do not require a license)

■ IEEE802.11g/b wireless LAN units

When this unit is used near any of the equipment mentioned above, it is possible that

electric wave interference could occur.

About wireless equipment used on the 2.4 GHz band

This frequency bandwidth is the same as for industrial, scientific, and medical equipment

such as microwave ovens, mobile unit identification systems (radio stations that require a

license) used in factory production lines, and specified low-power radio stations (radio stations that do not require a license).

■ Before using this device, check that there are no radio stations for mobile unit

identification systems or specified low-power radio stations nearby.

■ If this product emits radio waves which interfere with in-factory radio stations for mobile unit

identification systems, cease use immediately and stop generating the radio waves. For

information on countermeasures, etc. (for example, erecting partitions), contact one of our sales departments whose details are provided at the end of this manual.

■ If this unit emits radio waves which interfere with specified low-power radio stations

used for mobile unit identification systems, or causes similar problems, contact one of our sales departments whose details are provided at the end of this manual.

About lithium-ion batteries

The lithium-ion battery that is used in the tablet is a rechargeable Li-ion battery. Because

this lithium-ion battery is easily affected by temperature and humidity, store it in a dry location between 15 and 25°C.

During charging, after charging, and during use, the lithium-ion battery becomes warm.

Remove the lithium-ion battery from the tablet if it will not be used for a long time. When using the lithium-ion battery, check that the outside and terminals of the battery are

not deformed in any way. Deformed lithium-ion batteries can be very dangerous and

should not be used under any circumstances. The lithium-ion battery's service life is reduced if frequent top-up charging is performed.

For unneeded lithium-ion batteries, cover the metallic sections with insulating tape such as Scotch Tape, and recycle them in accordance with your local regulations, or take them to one

of our sales departments whose details are provided at the end of this manual.

Replacing the lithium-ion battery

If the unit can only be used for an extremely short time or the power does not come on, the lithium-ion battery has reached the end of its service life.

Please purchase a new lithium-ion battery from one of our sales departments whose

details are provided at the end of this manual. Note that the lithium-ion battery is considered to be a consumable item and therefore a fee is

charged even if it falls within our warranty period.

About the operating environment and storage

■ This model is for indoor use only. It cannot be used outdoors.

■ Do not place the product in a damp or dusty location, in a location exposed to the sea

breeze, or in an area exposed to high vibration.

The operating environment conditions are as follows.

Temperature: 0 to 40°C

Humidity: 30 to 90% (no condensation)

■ Do not store in a location exposed to direct sunlight or near to heating equipment. Discoloration, deformation or malfunctions could result.

Maintenance

Remove the connected cable and the lithium-ion battery, and store this product in a

location that is not subject to humidity or moisture.

- Remove any dirt from the product with a soft, dry cloth.

- To remove stubborn dirt, dilute some detergent in water, dip a soft cloth in the water,

and then ring it out before using it to wipe away the dirt. Do not use any volatile solvents

such as thinner or benzene.

Contents

Usage Precautions .............................................................................................................. 4

About radio waves used by this product ............................................................................ 4

About wireless equipment used on the 2.4 GHz band ...................................................... 4

About lithium-ion batteries ................................................................................................. 4

Replacing the lithium-ion battery ....................................................................................... 5

About the operating environment and storage .................................................................. 5

Maintenance ...................................................................................................................... 5

Before Use ........................................................................................................................... 8

Main functions ................................................................................................................... 8

System requirements ......................................................................................................... 9

Supplied Items ................................................................................................................... 10

Preparations....................................................................................................................... 11

Software installation and uninstallation ........................................................................... 11

Connections .................................................................................................................... 12

Part Names ......................................................................................................................... 13

Charging the tablet .......................................................................................................... 14

Tablet preparations .......................................................................................................... 15

About the LEDs ............................................................................................................... 17

Using the Pen .................................................................................................................. 18

Operating the tablet ......................................................................................................... 21

Storing the wireless adapter and pen .............................................................................. 23

Using Image Mate Accent ................................................................................................. 24

Starting Image Mate Accent ............................................................................................. 24

Screen configuration........................................................................................................ 24

Mode descriptions ........................................................................................................... 25

Drawing ........................................................................................................................... 26

Deleting ........................................................................................................................... 26

Document Camera mode ................................................................................................ 27

Displaying the Document Camera image ...................................................................... 27

Operating the Document Camera ................................................................................. 28

Using the mask ............................................................................................................. 28

Using the highlight ......................................................................................................... 29

Using the scroll .............................................................................................................. 29

Using compare pictures ................................................................................................. 30

Setting the computer image as the background ............................................................ 30

Saving the contents of a lesson on video ...................................................................... 31

Saving the contents of a lesson as a picture ................................................................. 31

Whiteboard mode ............................................................................................................ 34

Setting the whiteboard .................................................................................................. 34

Changing the background ............................................................................................. 34

Setting the computer image as the background ............................................................ 34

Saving the contents of a lesson on video ...................................................................... 34

Saving the contents of a lesson as a picture ................................................................. 34

Teaching material mode .................................................................................................. 37

Viewing pictures and videos .......................................................................................... 37

Operating a video .......................................................................................................... 40

Setting the computer image as the background ............................................................ 40

Saving the contents of a lesson on video ...................................................................... 40

Saving the contents of a lesson as a picture ................................................................. 40

Using the mask ............................................................................................................. 40

Using the highlight ......................................................................................................... 40

Using the scroll .............................................................................................................. 40

Using compare pictures ................................................................................................. 40

Teaching material creation mode ..................................................................................... 43

Creating a new teaching material .................................................................................. 43

Opening a teaching material ......................................................................................... 43

Saving a teaching material ............................................................................................ 45

Operating the Document Camera ................................................................................. 45

Creating a Document Camera video ............................................................................. 45

Changing the background ............................................................................................. 48

Inserting pictures ........................................................................................................... 49

Using stamps................................................................................................................. 50

Entering text .................................................................................................................. 51

Selecting a line or picture .............................................................................................. 51

Setting the computer image as the background ............................................................ 51

Saving the contents of a displayed screen .................................................................... 51

Changing the pen settings ............................................................................................. 52

Changing a line or picture ............................................................................................. 53

Setting mode ................................................................................................................... 56

Button list ......................................................................................................................... 58

Troubleshooting ................................................................................................................ 60

Product Specifications ..................................................................................................... 63

About Trademarks ............................................................................................................. 63

Before Use

Please note that screens and figures used in this manual may differ from the actual

Caution

Thank you very much for purchasing this product.

Please read this manual carefully to make suitable use of this product. Also, please be sure to

refer to any supplemental information included with this product.

views.

Main functions

This product is an educational tool for making lessons using ELMO's Document Camera more

enjoyable and easier to understand. The product has various indispensable features for teaching more effective lessons.

- Drawing on the Document Camera image

Because you can draw directly onto the Document Camera image, you can directly

communicate the important points that cannot be explained fully just by display.

- Large and viewer-friendly screen

Equipped with an innovative user interface born from ELMO's in-depth knowledge of lessons

using Document Cameras. The icons are large and easy to remember, and are simple to operate from anywhere in the classroom. This provides powerful support for your lessons.

- Wireless function brings new possibilities

Thanks to the USB wireless communication, you are free to draw up to 15 meters away from

the computer.

- Various recording methods are available immediately

With "Lesson recording", you can easily record both the text written on the Document Camera

and audio. Easy, one-touch playback can be performed of recorded images. Both the examples that you want to show the students and any written text are recorded together, so

you can show them to students again to help with their learning.

Other recording methods are also available to suit different objectives. "Intermittent recording" enables the monitoring of changes over a long period of time, while "Frame recording" allows

you to record only the scenes that you want.

- Effortless creation of the required teaching materials

You can create teaching materials for lessons with the Document Camera. It is simple to

retrieve the created teaching materials for use in class. This product is designed especially for use while lessons are in progress, enabling you to teach a wide range of lessons without

interrupting the flow of the class.

System requirements

Computer model

IBM PC/AT compatible

Operating system

(OS)

CPU

Memory

Hard disk

Video Board

Screen resolution

USB

Compatible document

cameras

Microsoft Windows XP Home Edition / Professional SP2

(32bit)

Microsoft Windows Vista Home Basic / Home Premium /

Business / Enterprise / Ultimate SP1 (32bit)

Microsoft Windows 7 Starter / Home Premium /

Professional / Ultimate (32bit)

Intel Core 2 Duo 2 GHz equivalent or higher

2 GB or higher

1 GB or higher

Correspond to Microsoft DirectX 9.0c

1024×768 pixels or higher

32-bit or higher

USB 2.0 HI-SPEED

· L-1ex / TT-02RX

· L-1n / TT-02s

· P10S

Caution

· P10

· P30S

· CO-10 ( i-Pochette )

- If a sound device cannot be used, some of the functions may not operate.

- Operation is not guaranteed for all computer environments.

9 10

Supplied Items

The product's package has the following contents. Contact your dealer if any of the

following items are not included in the package you purchased.

Wireless

adapter

Tablet

Tweezers for

replacing

the extra cores

USB cable

for charging

Installation

Extra core ×3

Pen

Dry cell AAA

battery

(For the pen)

pplication software

(Image Mate

Accent)

CD-ROM

Lithium-ion

battery for tablet

RGB / USB composite cable

(For connecting Document Camera

to computer)

Manual

Installation

Manual

Preparations

Software installation and uninstallation

■ Installation

To use this product, you need to install Image Mate Accent on the computer you are using. Use the following procedure to install the software.

1. Insert the supplied CD in the computer's CD drive.

2. Select "Install Image Mate Accent" from the menu.

Depending on your environment, the menu may not be displayed automatically. Run

Caution

3. Follow the on-screen instructions to install.

Caution

4. When installation is complete, the "Image Mate Accent" icon is displayed on the desktop.

"Win → startup.exe" from the CD drive.

Depending on your environment, a warning message may appear about

compatibility with the hardware or digital signatures. No problems will occur, so

continue with the installation.

Depending on your environment, you may be prompted to restart the computer.

Caution

■ Uninstallation To remove Image Mate Accent from your computer, remove it using your OS's uninstall

function.

Caution

Follow the instructions to restart the computer.

There is no influence on other software though a part of data might remain in uninstallation for reinstalling.

Connections

This section shows a connection example for the effective use of this product.

■ Items to prepare

This product, and items supplied with this

product

Items sold separately

● Tablet

● Wireless adapter

● RGB / USB composite cable

(1)

Arrange the parts and connect the cables as shown in the figure.

● Document Camera (L-1n / TT-02s, L-1ex /

TT-02RX, P10S, P30S, P10, CO-10

(i-Pochette) )

● Computer

● Projector

● RGB cable

Caution

For more details about the installation and operation of each device, see the

corresponding User's Guide.

Part Names

Tablet

USB

Power button

Turns the tablet ON or OFF.

Press the button for 3 seconds or

more to turn the tablet OFF.

When the power is ON, it is lit blue.

When the battery charge is low, it

flashes.

Status LED

Indicates the wireless and battery

charge status.

Function keys

Tablet base

Enables quick Image Mate Accent

operations. See <

more details.

Function keys> for

Pen slot

Holds the pen.

Wireless settings button

Used when performing communication

settings with the wireless adapter.

Wireless adapter storage slot

Insert the wireless adapter.

Battery box

Only install a lithium-ion battery made

for this product.

Pen

Side button 2 Side button 1

Wireless adapter

Only open when absolutely

Caution

necessary.

Wireless settings button (LED)

Used when performing

communication settings with the

tablet.

Charging the tablet

(1)

Install the lithium-ion battery in the tablet.

Install the supplied lithium-ion battery in the battery box on the base of the

tablet.

Note the insertion direction of the lithium-ion battery.

Caution

Only open the battery box when necessary.

Battery box cover

Printed surface upwards

Lithium-ion battery

Tablet base

(2)

Connect the computer and the tablet via a USB cable for charging.

When charging starts:

The "Status LED" in the center of the

tablet is lit.

When charging is complete:

The "Status LED" turns off.

Charging time: Approx. 4 hours

Disconnect the USB cable for charging from the computer as soon as charging

Caution

is complete.

Tablet preparations

(1)

(2)

Connect the wireless adapter to the computer's USB port.

Turn on the tablet.

(1) When you press the power button, the power

LED is lit.

* If the power LED flashes or stays off, there

is not enough charge in the lithium-ion battery. Charge the lithium-ion battery.

(2) If the "Status LED" on the tablet flashes

repeatedly and communication is not possible, see <If tablet communication cannot be

performed>.

If this product is used as described below, the communication range between

the tablet and wireless adapter may be shortened, or communication may become unstable.

- There is an obstruction between the tablet and wireless adapter

- The product is used while placed on top of a computer

Caution

- A wireless device or electronic equipment is being used nearby

- The tablet is moved while being used Also, due to the inherent characteristics of wireless communication, the

communication may become unstable in some positional relationships between the tablet and wireless adapter.

■ If tablet communication cannot be performed (Status LED flashes)

Perform the wireless settings using the "Wireless settings buttons" on the base of the

tablet and the wireless adapter.

Turn ON the tablet's power, and

press the "Wireless settings button"

on the rear side.

↓

The "Status LED" flashes at high

speed.

↓

Tablet rear side

Press the "Wireless settings button"

on the wireless adapter.

↓

The "Status LED" on the tablet turns

off for a few seconds. When the "Status LED" turns off, the

tablet and wireless adapter can

communicate, and the tablet can be used.

Wireless adapter

Caution

Perform the wireless setting within 30 seconds of pressing the "Wireless

settings button" on the rear side of the tablet.

About the LEDs

The power button LED and status LED on the tablet and the wireless settings button LED on

the wireless adapter indicate the status of the devices.

■ Power LED

LED status Operation

OFF

Power is OFF.

Press the power button to turn the power ON.

Power is ON.

Lit

Press the power button for 3 seconds to turn the power OFF.

There is not enough charge in the lithium-ion battery.

Flashing

Charge the battery.

■ Status LED

LED status Operation

OFF

High-speed flashing

(Turns ON and OFF

every 0.5 second)

Flashing

(Turns ON and OFF

every 1 second)

When the power is ON, communication with the wireless adapter is

being performed correctly.

The wireless settings button is pressed.

Cannot communicate with the wireless adapter.

See <

If tablet communication cannot be performed>.

Lit Charging.

■ Wireless settings button LED

LED status Operation

OFF

High-speed

flashing

Flashing

The computer's power is not ON, or when the power is ON, communication

with the tablet is being performed correctly.

The wireless settings button for the wireless adapter is pressed.

Cannot communicate with the tablet.

See <

If tablet communication cannot be performed>.

Using the Pen

■ Installing the dry cell battery

Install the dry cell battery in the pen before

use.

- Pay attention to the polarity (+/-) of the dry cell battery.

- Remove the dry cell battery if the pen will not be used for a long time.

- Do not try to recharge or short-circuit the dry cell battery.

Caution

Battery replacement period

When the dry cell battery is running low, the operability may deteriorate.

Caution

■ Replacing the pen tip

When the pen tip becomes round, replace it with the supplied "extra core".

Use the supplied extra core replacement

tweezers when replacing the pen tip.

Caution

- Use an AAA alkali dry cell battery. Do not use a rechargeable battery (such as

Ni-cd).

- The supplied dry cell battery is for an initial operation check. Its operating life

is not guaranteed.

- Be careful because the dry cell battery may pop out when you remove the pen

cap.

- You should replace the dry cell battery at least once a year.

When replacing the pen tip, be

sure to replace it with a supplied

"extra core".

Make sure that children do not put

small parts into their mouths.

■ Setting the side buttons and pen

The pen is equipped with "side buttons" to provide assistance with pen operations.

Pen

Side button 2 Side button 1

Place the cursor on the "Tablet driver" icon that is displayed on the

(1)

taskbar, click side button 2 (for the initial setting) or right-click, and then select "Setting" in the menu that appears.

(2)

The tablet driver Setting & Test draw screen is displayed.

②

③

①

④

⑤

① Drawing area It is a trial drawing area to confirm pen touch sense. ② Menu Setting drawing and operate application.

Deletes all the lines that are drawn on the screen when

③ Drawing setting

push eraser button.

Setting color of pen by the color buttons.

Sets the value determining when the pen has touched the tablet.

When the value is hardened, you need to press more

firmly to draw a line. If cursor movements are generating unintended

④ Pen touch sense

drawing and tapping, harden the value.

When the pen touch sense is changed,

Caution

please wait for about one second with

the pen away from the tablet.

⑤ Close button Close Setting & Test draw screen.

Notice

• Only when the tablet is connected, Pen touch sense is displayed.

+ 44 hidden pages
