Elkay ECTCE3322104 User Manual
®
SP EC IFIC ATIONS
GENERAL
Formed of #18 (1.2mm) gauge bowls featuring a #20 (0.9mm)
gauge deck, type 304 nickel bearing stainless steel. Top Mount.
DESIGN FEATURES
Bowl Depth: 10" (254mm).
Coved Corners: 1-7/32" (31mm) vertical and horizontal radius.
Raised Rim: 1-1/4" (32mm) above outside edge of sink.
Finish: Exposed surfaces are polished to a Bright Euro
Highlighted finish.
Maximum countertop thickness: 1-3/8" (35mm).
Underside: Fully protected by heavy duty Sound Guard under-
coating to reduce c
OTHER
Drain Opening: 3-1/2" (89mm)
NOTE: Unless otherwise specified, sink is furnished with 4
faucet holes as illustrated.
Sink complies with ASME A112.19.3-2008 / CSA B45.4-08
SINK DIMENSIONS*
Model
Number L W L W D L W 4" (102mm) Center Size
ECTCE332210 33 22 127/8 139/16 10 323/8 213/8 1,2,MR2,3,4,5 36
*Lengt h is left to right . Width is f ront to back.
(838mm ) (559mm) (327mm) (344mm) (254mm) (822mm ) (543mm) (914mm )
ondensation and dampen sound.
.
Cutout in Countertop
Overall Inside Each Bowl Corner Radius]
[11/2" (38mm)
Model ECTCE3322104
No. of
1
/2" (38mm) Minimum
1
Dia. Faucet Holes Cabinet
Echo Double Bowl Sink
M
odel ECTCE332210 Series
22"
(539mm)
13-9/16"
(344mm)
1-7/32" R
(31mm)
12-7/8"
(327mm)
10"
(254mm)
In keep ing with our policy of cont inuing product im provement, Elkay reserves t he right to change
produc t specifications wit hout notice. Please visit elkayusa.c om for most current version of Elkay
product specification sheets.
Elkay
elkayusa.com
33"
(838mm)
12-7/8"
(327mm)
1-1/4"
(32mm)
1-7/32" R
(31mm)
2222 Camden Court
Oak Brook, IL 60523
SINKS ARE
MADE IN THE USA
This specification d escribes an Elkay p ro duct with d esign, quality and funct ional benefits t o the
user. When making a c
overlooked.
omparison of other pr
oducers’ of ferings, be certain these f eatures are not
Printed in U.S.A.
©2010 Elkay
(Rev. 4/10) 1-358
Echo Double Bowl Sink
5
Model ECTCE332210 Series
®
SP EC IFIC ATIONS
OPTIONAL ACCESSORIES
Model Number Description L W Depth/ Thick ness Material
LK99
D
rain Fits 31/2" (89mm ) Drain Opening Stainless Steel
*
Overall
LKEOBG1315SS Bottom Grid 115/8 123/8 11/4 Stainless Steel
(295mm ) (314mm) (32mm)
LKERB1315SS Rinsing Basket 115/8 123/8 7 Stainless Steel
(295mm ) (314mm) (178mm)
LKWUCSS
U
tensil Caddy 151/8 31/2 43/8 Stainless Steel
for rinsing basket (384mm ) (89mm) (111m m)
LKCB1315HW Cutting Board 14 145/8 1 Hardwood
(356mm ) (371mm) (25mm)
*Lengt h is left to right . Width is f ront to back.
LK99
LKEOBG1315SS
LKERB1315SS
HOLE DRILLING CONFIGURATIONS
(102mm)
LKWUCSS
LKCB1315HW
1
4"
2
4"
(102mm)
MR2
4"
(102mm)4"(102mm)
3
4"
(102mm)4"(102mm)4"(102mm)
4
4"
(102mm)4"(102mm)4"(102mm)4"(102mm)
Elkay
1-358 (Rev. 4/10)
2222 Camden Court
Oak Brook, IL 60523
elkayusa.com
Printed in U.S.A.
