■■■■ chapter 4 upgrading your computer
CHAPTER▼▼▼▼ FOUR
UPGRADING YOUR COMPUTER
In this chapter, you will learn how to
upgrade the DRAM, hard disk drive, and
to install the optional wireless LAN mini
PCI.
4-1
■■■■ chapter 4 upgrading your computer
Upgrading the Hard Disk Drive
Replacing the original drive with one of larger capacity can increase
the hard drive capacity of your computer. The computer uses a 9.5
mm (height), 2.5-inch Ultra ATA-66 / 100 / 133 type hard disk.
Be sure to make a backup copy of all your data before attempting
this operation.
Warning:
instructions carefully or have a qualified technician install it for you. Damages due to
mishandling of this procedure are NOT covered by the manufacture’s warranty.
Hard drive upgrade is a delicate process. Please observe the following
Warning:
Do not drop or apply any shock.
Do not press on the cover.
Do not touch the connector with your f i ngertips.
Mishandling of the hard drive can result i n permanent loss of data. Make a
backup copy of the drive s content before you remove it.
Apply care when handling the hard disk.
Note:
Certain models that come with the IBM-brand hard drive emit a clattering
sound when it is being rattled. This is a normal condition.
4-2
■■■■ chapter 4 upgrading your computer
Upgrading the Hard Disk Drive
To replace the hard disk drive, do the following:
1. Turn OFF the computer and remove the battery. Unhook
the AC cord and all cables/devices attached to the notebook.
2. Place your hand on a large metal object momentarily to
discharge any static electricity.
3. Locate and remove Screw A.
4. Remove HDD Cover.
H
D
D
C
o
v
e
r
5. Life the HDD module away from the bay and carefully
separate the module from the HDD connector.
Screw A
4-3
■■■■ chapter 4 upgrading your computer
HDD Connector
HDD Module
6. Locate and remove 4 Screw B’s from the HDD module.
Remove the meta l case.
Screw B x2
Screw B x2
7. Re-attach the metal cover to the new hard drive and
tighten 4 Screw B’s. Note the green PC board of the hard disk
drive is facing against the metal case.
8. Re-attach the HDD module to the HDD connector.
9. Place the HDD module back to the HDD bay.
10. Put the HDD cover back and re-attach Screw A.
4-4
