Preface
Copyright 2005
All Rights Reserved.
The information in this document is subject to change without prior
notice in order to improve reliability, design and function and does not
represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability
to use the product or documentation, even if advised of the possibility
of such damages.
This document contains proprietary information protected by
copyright. All rights are reserved. No part of this manual may be
reproduced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Trademarks
CardSoft is a trademark of SystemSoft Corporation. AutoCAD and
Autoshade are trademarks of Autodesk, Inc. IBM, OS/2, and VGA are
trademarks of International Business Machines Corp. Lotus, 1-2-3,
and Symphony are trademarks of Lotus Development Corp. Windows,
Word, MS-DOS, and Microsoft are trademarks of Microsoft Corp.
VESA is a trademark of Video Electronics Standards Association.
Other product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of
their respective companies.
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy of
this manual, the manufacturer and distributor assume no liability
resulting from errors or omissions in this manual, or from the use of
the information contained herein.
i
Notices
Federal Communications Commission Radio Frequency
Interference Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and if not installed
and used in accordance with the instruction manual may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
¾
¾
Increase the separation between the equipment and receiver.
¾
¾
Connect the equipment into an outlet on a circuit different from
¾
¾
that to which the receiver is connected.
Consult the dealer or an experienced radio TV technician for help.
¾
¾
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment. Shielded interface
cables and a non-shielded AC power cord must be used in
order to comply with emission limits.
This equipment is to be used with power supply:
I/P: 100-240 Vac, 50-60Hz, 1.5A
O/P: 20Vdc, 2.5A
There is no internal power supply.
ii
Canadian DOC Notice For Class B Computing Devices
This Class B digital apparatus meets all requirements of the Canadian
Interference - Causing Equipment Regulations.
Cet appareil numerique de la classe B repecte toutes les exigences du
Règlement sur le matèriel brouilleur du Canada.
iii
Page intentionally left blank
iv
Table of Contents
Chapter 1: Before you Start ------------------------------------------------1
Conventions of This Manual.....................................................1
Regulatory Statement Sample..................................................1
Safety Precautions....................................................................3
Things you must remember before working on your computer 8
Chapter 2: Introduction------------------------------------------------------11
Welcome to the Notebook PC ..................................................11
Getting to Know Your Computer...............................................11
Chapter 3: Getting Started--------------------------------------------------21
Connecting to a Power Source.................................................21
Turning On Your Notebook Computer......................................22
Operating on Battery Power .....................................................22
Chapter 4: Using the Notebook Computer ----------------------------25
Adjusting the LCD Screen Display............................................25
A Tour of the Notebook’s Keyboard..........................................26
The TouchPad ..........................................................................27
Connecting an External Tracking Devices................................28
The CD-ROM/DVD-ROM/Combo Drive....................................28
PCMCIA Cards and Expansion Sockets ..................................29
Power Saving Modes................................................................30
Battery Calibration ....................................................................33
Chapter 5: Desktop Operation---------------------------------------------35
Audio.........................................................................................35
Connecting Peripheral Devices ................................................36
Chapter 6: Internet Connection -------------------------------------------37
Using a modem for Connection to Internet...............................37
Using a wired LAN for Connection to Internet..........................37
Using Both DHCP and Static IP for Connection to Internet......40
Using Wireless LAN Network for Connection to Internet
(Microsoft’s Service Pack 2) (Optional) ....................................42
Chapter 7: Running BIOS Setup ------------------------------------------43
Introduction...............................................................................43
Navigating through BIOS Setup................................................43
Accessing the BIOS Setup Program.........................................43
v
The Menu Bar...........................................................................43
The Legend Bar........................................................................44
Launching Submenus...............................................................45
General Help.............................................................................45
The Main Menu.........................................................................46
The Advanced Menu.................................................................47
The Security Menu....................................................................48
The Boot Menu .........................................................................49
The Exit Menu...........................................................................50
Chapter 8: VGA Utilities -----------------------------------------------------51
AutoRun Installation..................................................................51
VGA Utilities..............................................................................51
Chapter 9: Video Conferencing -------------------------------------------57
Application ................................................................................58
Chapter 10: Troubleshooting ----------------------------------------------63
Locating a Problem...................................................................63
Checking Cables and Connections...........................................63
The Power-On Self Test...........................................................64
General Hardware Problems....................................................65
Contacting Your Dealer ............................................................67
Chapter 11: Upgrading your System------------------------------------69
Upgrading your Memory...........................................................69
The Easy to Upgrade HDD Module..........................................70
Upgrading your System CPU....................................................70
Appendix A: Specification --------------------------------------------------73
Detailed Notebook Specifications.............................................73
vi
Before you Start
Conventions of This Manual
Use this manual will help you get the most from your notebook
computer.
If you are an experienced user of computers and/or Microsoft’s
¾
¾
Windows operating systems, you might find it useful to read the
Quick Start Guide that comes along with your accessories.
If you are a less experienced user, you should through the manual
¾
¾
carefully before using your system.
Whether or not you are an experienced user, you should consult on the
Troubleshooting Chapter if you encounter any problems with your
notebook.
Regulatory Statement Sample
Safety Compliance Notice
This device has been tested and certified according to the following
safety standards and is intended for use only in Information
Technology Equipment which has been tested to these or other
equivalent standards:
EN 60950-1
¾
¾
Europe – EU Declaration of Conformity
Hereby, xxx Corporation, declares that this Product is in compliance
with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
Europe – Restriction for Use of 2.4GHZ Frequencies in
European Community Countries
This device may be operated indoors or outdoors in all countries of
the European Community using the 2.4GHz band: Channels 1 – 13,
except where noted below.
In Italy the end-user must apply for a license from the national
¾
¾
spectrum authority to operate this device outdoors.
In Belgium outdoor operation is only permitted using the 2.46 –
¾
¾
2.4835 GHz band: Channel 13
1
In France outdoor operation is only permitted using the 2.4 –
¾
¾
2.454 GHz band: Channels 1 – 7
EUROPE
EUROPEAN COMMUNITY COUNTRIES
5.15-5.25GHz 36, 40, 44, 48 Austria
5.15-5.35GHz 36, 40, 44, 48, 52,
5.15-5.35 &
5.470-
5.725GHz
¾
¾
¾
¾
¾
¾
¾
¾
– RESTRICTIONS FOR USE OF 5GHZ FREQUENCIES IN
Allowed
Frequency
Bands
This device may not be operated outdoors when using the bands
5150-5350MHz (Channels 36, 40, 44, 48, 52, 56, 50, 64).
In Italy the end-user must apply for a license from the national
spectrum authority to operate this device outdoors.
To remain in conformance with European spectrum usage laws
for Wireless LAN operation, the above 5GHz channel limitations
apply. The user should check the current channel of operation. If
operation is occurring outside of the allowable frequencies as
listed above, the user must cease operating at that location and
consult the local technical support staff responsible for the
wireless network.
The 5GHz Turbo mode feature is not allowed for operation in
any European Community country
Allowed Channel
Numbers
56, 60, 64
36, 40, 44, 48, 52,
56, 60, 64, 100,
104, 108, 112,
116, 120, 124,
128, 132, 136,
140
Countries
Cyprus, Czech
Republic, France,
Hungary, Slovakia
Belgium, Bulgaria,
Denmark, Estonia,
Finland, Germany,
Greece, Iceland,
Ireland, Italy,
Latvia,
Liechtenstein,
Lithuania,
Luxembourg,
Malta,
Netherlands,
Norway, Poland,
Portugal,
Slovenia, Spain,
Sweden,
Switzerland, U.K.
2
This device must not be operated in ad-hoc mode using channels
¾
¾
in the 5GHz bands in the European Community. Ad-hoc mode
provides a direct communication between two client devices
without a Wireless LAN Access Point.
This device must be used with Access Points that have employed and
activated a radar detection feature required for European Community
operation in the 5GHz bands. This device will operate under the
control of the Access Point in order to avoid operating on a channel
occupied by any radar system in the area. The presence of nearby
radar operation may result in temporary interruption in
communications of this device. The Access Point’s radar
You may consult with the local technical support staff responsible for
the wireless network to ensure the Access Point device(s) are properly
configured for European Community operation.
Safety Precautions
This section is designed to assist you in identifying potentially unsafe
conditions while working with this product. Required safety features
have been installed in the computer to protect you from injury.
However, you should use good judgment to identify potential safety
hazards:
1. Please read these safety instructions carefully.
2. Please keep this User's Manual for later reference.
3. Please disconnect this equipment from AC outlet before
cleaning. Don't use liquid or sprayed detergent for cleaning.
Use moisture sheet or cloth for cleaning.
4. For pluggable equipment, that the socket-outlet shall be
installed near the equipment and shall be easily accessible.
5. Please keep this equipment from humidity.
6. Lay this equipment on a reliable surface when installed. A
drop or fall could cause injury.
7. Make sure to use the right voltage for the power source when
connecting the equipment to the power outlet.
8. Place the power cord in such a way that people can not step on
it. Do not place anything on top of the power cord.
9. All cautions and warnings on the equipment should be noted.
10. If the equipment is not use for a long time, disconnect the
equipment from the main power outlet to avoid being damaged
by transient overvoltage.
11. Never pour any liquid into the opening, this could cause fire or
electrical shock.
3
12. Never open the equipment. For safety reason, the equipment
should only be opened by a qualified service personnel.
13. If on the following situations arises, get the equipment checked
by a service personnel:
a. The Power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment has not worked well or you cannot get
it work according to the user's manual.
e. The equipment has dropped and damaged.
f. If the equipment has obvious sign of breakage.
14. Do not leave this equipment in an environment unconditioned,
storage temperature above 60°C (140°f), it may damage the
equipment.
15. The unit can be operated at an ambient temperature of max.
35°C.
16. The sound pressure level at the operators position according to
IEC 704-1: 1982 is equal or less than 70 dB(A).
17. Power Cord Requirements
The power cord set used with the AC adaptor must meet the
requirements of the country where you use the AC adaptor,
whether it is 100-120 or 200-240 Vac. The following
information explains the requirements for power cord set
selection.
y The cord set must be approved for the country in
which it is used.
y The appliance coupler must have a configuration
for mating with a CEE22/EN6032/IEC 320
appliance inlet.
A. For U.S. and Canada:
y The cord set must be UL Listed and CSA Certified.
y The minimum specifications for the flexible cord
are No. 18 AWG.
B. For Japan:
y All components of the cord set must bear a “PSE”
or “ T ” mark and registration number in
accordance with the Japanese Dentori Law.
y The minimum specifications for the flexible cord
are .75m ㎡ conductors.
C. For Other Countries:
4
y The cord set fittings must bear the certification
mark of the agency responsible for evaluation in a
specific country.
y The flexible cord must be of a HAR (harmonized)
type H03VV-F.
y The cord set must have a current capacity of a least
2.5 Amperes and voltage rating of 125 or 250 Vac.
18. When using your telephone equipment, basic safety
precautions should always be followed to reduce the risk of fire,
electric shock and injury to persons. These precautions
includes the following:
¾ Do not use this product near water, for example, near a
bathtub, washbowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
¾ Avoid using a telephone (other than a cordless type)
during an electrical storm. There may be a remote risk
of electric shock from lightning.
¾ Do not use the telephone to report a gas leak in the
vicinity of the leak.
¾ Use only the power cord indicated in this manual.
19. Do not use the AC adapter near open water or other liquids.
Never spill liquid into the AC adapter.
20. Laser Warning: Laser Class I Product Caution - Invisible laser
radiation when open avoid exposure to beam.
21. Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer's instructions. Never remove the battery pack
while the power is on as this may result in data loss when the
system loses power.
22. The input receptacle is used as the main disconnecting device.
Wichtige Sicherheitshinweise
1. Bitte lesen Sie diese Hinweis sorgfältig durch.
2. Heben Sie dirse Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen.
Versenden Sie Keine Flüssig- oder Aerosolreiniger. Am
besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
4. Die Netzanschluβsteckdose soll nahe dem Gerät angebracht
und leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
5
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu
achten. Ein Kippen oder Fallen könnte Beschädigungen
hervorrufen.
7. Beachten Sie beim Anschluß an das Stromnet die
Anschlußwerte.
8. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber
fallen kann. Es sollte auch nichts auf der Leitun abgestellt
werden.
9. Alle Hinweise und Warnungen, die sich am Gerät befinden,
sind zu beachten.
10. Wird das Gerät üeinen längeren Zeitraum nicht benutzt, sollten
Sie es vom Stromnetz trennen. Somit wird im Falle einer
Überspannung eine Beschädigung vermieden.
11. Durch die Lüftungsöffnungen dürfen niemals Gegenstände
oder Flüssigkeien in das Gerät gelangen. Dies könne einen
Brand bzw. Elektrischen Schlag auslösen.
12. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der
elektrischen Sicherheit nur von authorisiertem Servicepersonal
geöffnet werden.
13. Wenn folgende Situationen auftreten ist das Gerät vom
Stromnetz zu trennen und von einer qualifizierten Servicestelle
zu Überprüfung.:
a. Netzlabel oder Netzstecker sind beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d. Wenn das Gerät nicht der Bedienungsanleitung
entsprechend funktioniert oder Sie mit Hilfe dieser
Anleitung keine Verbesserung erzielen.
e. Das Gerät ist gefallen und/oder das Gehäuse ist
beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes
aufweist.
14. VORSICHT: Explosiongsgetahr bei unsachgemäßen
Austausch der Batterie. Ersatz nur durch denselben oder einem
vom Hersteller empfohlenem ähnlichen Typ. Entsorgung
gebrauchter Batterien nach Angaben des Herstellers.
15. Dieses Schaltnetzteil kann bis zu einer Außentemperatur von
maximal 35ºC.
16. Die Ausgangswerte dürfen nicht die auf dem Label
angegebenen Werte überschreiten.
6
17. Anforderungen an das Stromkabel
Das Kabel-Set, das an das Netzteil angeschlossen wird, muss
den Anforderungen des Landes, in dem Sie das Netzteil
einsetzen, genügen, je nachdem, ob die Netzspannung 100-120
oder 200-240V Wechselspannung beträgt.
y Das Kabel-Set muss für das Land, in dem es
eingesetzt wird, zugelassen sein.
y Der Gerätestecker des Kabels muss in eine CEE22/
EN603/ IEC 320 Buchse passen.
A. Für die USA und Kanada:
y Das Kabel-Set muss UL-gelistet und CSA
zertifiziert sein.
y Die Minimalanforderungen für das Kabel
entsprechen No. 18 AWG.
B. Für Japan:
y Alle Teile des Kabel-Sets müssen entsprechend
dem japanischen Dentori Law mit einem „PSE“ or
„T”-Symbol markiert sein
y Die Minimalanforderungen für das Kabel
sind .75m ㎡ Leiter.
y Für andere Länder:
y Die Zubehörteile des Kabel-Sets müssen das
Prüfsiegel derjenigen Stelle, die in dem jeweiligen
Land für die Sicherheitsprüfung zuständig ist,
tragen.
y Das Kabel muss vom HAR (harmonisierten) Typ
H03VV-F sein.
y Das Kabel-Set muss eine Stromkapazität von
mindestens 2,5 Ampere haben und Spannungen
von 125 oder 250 V Wechselstrom gestatten.
18. Bei der Benutzung Ihres Telefongerätes sollten Sie immer die
grundlegenden Sicherheitsmaßnahmen beachten, um das
Risiko von Feuer, Stromschlägen und Verletzungen zu
minimieren. Zu beachten sind u.a. folgende Punkte:
¾ Benutzen Sie das Gerät nicht in der Nähe von Wasser, wie
zum Beispiel Badewanne, Waschbecken, Spülbecken,
Waschbottich, in feuchten Kellerräumen oder in der Nähe
von Schwimmbecken.
7
¾ Benutzen Sie kein Telefon (ausgenommen schnurlose
Modelle) während eines Gewitters. Es besteht das geringe
Restrisiko eines Blitzschlages.
¾ Benutzen Sie das Telefon nicht um ein Gasleck zu melden,
falls es sich in der Nähe des Lecks befindet.
¾ Benutzen Sie nur solch ein Stromkabel, wie in dieser
Anleitung beschrieben.
19. Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu
Wasser oder anderen Flüssigkeiten. Gießen Sie nie
Flüssigkeiten über das Netzteil.
20. Achtung Laser: Laser Produkt der Klasse I. Achtung -
Unsichtbarer Laserstrahl, vermeiden Sie Kontakt mit dem
Strahl bei offenem Gehäuse.
21. Es besteht Explosionsgefahr, wenn der Akku nicht
ordnungsgemäß ersetzt wird. Ersetzen Sie den Akku nur durch
einen Akku gleichen oder äquivalenten Typs, der vom
Hersteller empfohlen wird. Entsorgen Sie Akkus entsprechend
den Anweisungen des Herstellers. Entfernen Sie den Akku auf
keinen Fall bei eingeschaltetem Notebook, da hierdurch Daten
verloren gehen könnten.
22. Der Netzeingabeanschluss dient als Hauptschalter des Geräts.
Things you must remember before working on your
computer
Let your computer acclimate itself
Your notebook can easily stand temperature extremes but it doesn’t
like rapid changes in temperature, like going from the cold outdoors to
a warm office. Rapid changes in temperature can cause water droplets
to condense inside your case, threatening to damage the electronic
parts inside.
After receiving your notebook when it’s hot or cold outside, try not to
power up the computer immediately, let the computer adjust to the
room temperature gradually at least for three to four hours.
If your system arrives in cold weather, do not apply power
to the computer or monitor until they have been allowed to
come to room temperature.
8
Heat, Cold, Humidity, and Glare
Find a suitable place for your computer that’s not too hot, too cold,
too dark, or too bright. Glare can make it hard to read the screen.
Try to avoid the computer components from being destroyed if it
¾
¾
is over heated, so try to allow plenty of room for air to circulate
around the case.
Do not block the ventilation opening.
¾
¾
Do not place your computer in direct sunlight.
¾
¾
Suitable place to work
Your computer will run well wherever you’re comfortable but
extremes of temperature and humidity can be challenging to your
system’s parts.
There are some things you can tolerate that the computer can’t –
things like static electricity, dust, water, steam and oil. In case you
decide to pull over for roadside computing, try to choose a clean,
comfortable work area for your system.
A lithium-ion battery pack will be available when you are traveling.
If you are running your system for the first time on battery power,
remove the battery from the package, install it into the system and
recharge the battery to fully prepare for service.
9
Page intentionally left blank
10
Introduction
There are more and more people spending large amounts of time in
front of computer monitors now that scientists from many fields
including anatomy, psychology, and occupational safety are involved
in the study of ergonomically sound work environments.
A few tips to help you work effectively without a lot of physical
discomfort:
Purchase a chair with armrests and good back support. Don't
¾
¾
slouch when sitting; keep your back straight.
Try to place the LCD panel or external monitor so that there is
¾
¾
little glare from the sun on the monitor.
Walk around the room every hour.
¾
¾
Every half hour look away from the computer screen for a few
¾
¾
minutes.
Place everything that you need to work within easy reach.
¾
¾
Welcome to the Notebook PC
Congratulations! You’ve just taken a big stride towards turning your
notebook into a full-fledged multimedia computer. The Notebook’s
modular design provides maximum expandability without
compromising portability.
Video Conferencing
Capture Feature
Multimedia Feature
Standard Optional
3
3
3 3
Getting to Know Your Computer
Opening the LCD Panel
At the front of the Notebook computer you will find a “Frame LCD”
on the middle of the display panel for you to conveniently raise the
LCD panel.
11
Standard Version
Use your hand to pull up the “frame LCD”.
¾
¾
At any time you can tilt the display toward or away from you to a
¾
¾
comfortable viewing position.
Press on the Power button to start your computer.
¾
¾
Optional Version
Raise the LCD panel and follow the correct procedures as shown
¾
¾
on the illustration.
Please don’t raise the LCD panel from the middle part since
this is where the camera is located. The camera is a
sensitive device that a strong pull might cause damage to it.
At any time you can tilt the display toward or away from you to a
¾
¾
comfortable viewing position.
Press on the Power button to start your computer.
¾
¾
Important Notices
To avoid damage to the display panel:
Try not to slam the display upon closing it.
¾
¾
12
For optional model with camera: Please raise down the LCD
panel carefully with your hand assisting the panel until it
touches down. Try not to slam the display when closing it,
this might damage the built-in camera.
There is a magnetic sensor on the lower right hand of the
LCD panel (inside the speaker) that will detect the “Lid
Switch IC” and shut down the system.
Try not to place any object on top when it is closed or open.
¾
¾
Be sure the system is turned off before you close the display
¾
¾
panel.
With the LCD screen open, you will see several features important for
operating your Notebook computer.
13
Each of these features is briefly described below.
System Status Indicator Panel
HDD
Indicates that the computer is accessing the
hard disk drive.
Numeric Lock
Indicates that the keyboard is in Num Lock
mode.
Caps Lock
Indicates when the keyboard is in Caps Lock
mode.
Scroll Lock
Indicates when the keyboard is in Scroll Lock
mode.
Camera Button (Optional Version)
Use this key to open the built-in camera application.
This button will not function if your model is the standard
version with no built-in Camera.
Outlook Express Button
Use this key to open Microsoft's Outlook to
send/receive your mail.
Internet Explorer Button
Use this key to open the Internet Explorer.
Wireless Button
Use this key to connect or disconnect the WLAN.
Power Button
Turns your notebook on and off
The Built-in Microphone
Record sounds directly to your notebook hard disk with
this built-in microphone
Touchpad
The PS/2 compatible mouse will work with the
Notebook PC’s TouchPad simultaneously.
14
Touchpad Buttons
The buttons below the TouchPad correspond to the left
and right buttons on a standard mouse.
Speaker
The internal speakers provides true stereo sound.
The Front Panel
Standard (Without Built-in Camera)
Card Reader
Supports 4-in-1 card reader slot (support
SD/SDIO/MS/MS Pro card)
Audio Line Out Headset Jack
You can plug an external speaker, headphone or
connect the line out jack to an audio device
External Microphone Jack
Allows you to receive monophonic input from an
external microphone.
Frame LCD
Pull up this frame to raise the LCD panel.
Optional (With Built-in Camera)
Built-in Camera (Option)
Press the camera button to capture the image with this
built-in camera.
15
The Left Side
The Modem Port
Connect a standard phone line directly to the internal
modem.
Always disconnect all telephone lines from the wall outlet
before servicing or disassembling this equipment. To
reduce the risk of fire use only No. 26 AWG or larger
telecommunication line cord.
Ventilation Opening
Please don't block this opening during operation of the
system.
External CRT Port
Connect to any external monitor.
The LAN Port
Connect to a high-speed 10Base-T Ethernet network.
16
When using a LAN, please use an EMI Shielding Cable to
minimize an inteference when transmitting.
LED Indicators
These three LED indicators are separately program for the following
functions: Power On, Suspend Mode and Battery Charge.
PCMCIA Socket Cover
Open this cover to access the PCMCIA socket.
PCMCIA Button
Press this button to release the PC ca rd.
1394A
A very fast external bus standard that supports data
transfer rates of up to 400 Mbps (400 million bits per
second).
Battery Charge
This indicator will lit blue when the battery is in
charging status. When the indicator light turns off, it
indicates the system is in full charge.
Power On
This indicator will lit when the notebook is powered On.
Suspend Mode
This indicator will lit when the notebook enter the
suspend mode.
17
The Right Side
USB Ports
Your computer includes three Universal Serial Bus
(USB) port.
The CD-ROM/DVD-ROM or DVD CD-RW Combo
Your Notebook comes with a swappable 24X (or
higher) 5.25" IDE CD-ROM/DVD-ROM/Combo Drive
(DVD-ROM+CD-RW), DVD-Dual
CD-ROM release button
Use this button to release the CD-ROM/DVD-ROM from
its compartment.
18
The Rear
DC-In
Plug the AC adapter into this connector.
Kensington Lock
Allows you to connect a special computer lock to
secure your system.
19
The Bottom Panel
Battery
Your notebook comes equipped with a factory-installed
battery pack module.
Battery Release Latch
Slide this latch to release the batter y.
Battery Lock
Slide to lock the battery.
CPU Fan
This fan will reduce the heat on the CPU.
CPU Compartment
This compartment will serve for you to upgrade your
CPU.
Expansion Compartment
This compartment will serve as an expansion to
upgrade your RAM module.
HDD Compartment
Your computer includes a 2.5-inch IDE hard disk drive
(9.5mm in height).
20
Getting Started
Connecting to a Power Source
Connecting the AC Adapter
A universal AC adapter is provided to supply your computer with
power and also charge the computer’s battery pack.
The adapter’s AC input
voltage can range anywhere
from 100 to 240 volts,
covering the standard
voltages available in almost
every country.
The power cord for the AC
adapter requires a three-hole
grounded AC outlet. To
connect the computer to an
external power source:
Do not use inferior extension cords as this may result in
damage to your Notebook. The Notebook comes with its
own AC adapter. Do not use a different adapter to power the
computer and other electrical devices.
Whenever possible, keep the AC adapter plugged into the Notebook
and an electrical outlet to recharge the battery.
Never turn off or reset your Notebook while the hard disk is
in use and the HDD status icon is lit; doing so can result in
loss or destruction of your data. Always wait at least 5
seconds after turning off your Notebook before turning it
back on; turning the power on and off in rapid succession
can damage the Notebook’s electrical circuitry.
21
Turning On Your Notebook Computer
Turn on your Notebook by pressing the power button. Hold the
button down for a second or two and release. The Power-On Self Test
(POST) runs automatically.
After the POST is completed, the computer reads the operating system
from the hard disk drive into computer memory (this is commonly
referred to as “booting” a computer). If your OS (Operating System
such as Windows XP…. etc) is installed, it should start automatically.
To turn the Notebook off, save your work and close all open
applications, click on Start, then select the “Turn off the computer”.
A selection box will be displayed and click on the “Turn Off” button
to shut down your computer.
When your computer hangs up, press the power button for
4-6 seconds to shut down the computer
Operating on Battery Power
Your computer comes with a rechargeable battery pack that lets you
operate the computer without an external power source. When the
battery pack is fully charged, you can operate the computer for
approximately 2 hours under the following conditions:
The battery pack initially has a full charge.
¾
¾
No peripheral devices are installed.
¾
¾
The disk/CD-ROM drives run no more than 10% of the time.
¾
¾
Only use batteries that are approved by an authorized
dealer. All batteries are not the same and therefore should
not be treated as such. Using the wrong battery could
cause serious damage to your computer and yourself
through toxic emissions.
22
Inserting and Removing the Battery Pack
The battery pack should already be inserted in your Notebook
computer when you unpack it. If not inserted, follow these directions:
To remove the battery pack:
23
Charging the Battery Pack
The installed battery pack charges automatically any time the
computer is connected to the AC adapter and an external power source.
It is a good idea to occasionally discharge the battery pack fully to
preserve its operating performance.
24
Using the Notebook Computer
Adjusting the LCD Screen Display
The LCD screen display can be adjusted by the following key
combinations.
KEYS FUNCTIONS
[Fn] + [F7] Decreases the brightness level.
[Fn] + [F8] Increases the brightness level.
[Fn] + [F10] Use this key combination to expand your
video screen or reset to its original size.
This function will be disabled when the
system is in Overlay mode (playing video).
[Fn] + [F12] This key combination toggles the display
between the LCD, CRT, simultaneous
LCD/CRT. This function will be disabled
when the system is in Overlay (playing
video) or Extended Desktop mode.
LCD Care
LCD screens are delicate devices that need careful handling. Please
pay attention to the following precautions:
When you are not using the computer, keep the LCD screen
¾
¾
closed to protect it from dust.
If you need to clean your LCD screen, use a soft tissue to gently
¾
¾
wipe the LCD surface.
Do not put your fingers or sharp objects directly on the surface
¾
¾
and never spray cleaner directly onto the display.
Do not press on, or store any objects on the cover when it is
¾
¾
closed. Doing so may cause the LCD to break.
External CRT Display
You can hook up an external monitor through the 15-pin CRT
connector. Configurations are available:
LCD only
¾
¾
CRT only
¾
¾
25
Simultaneous display of the LCD screen and CRT monitor
¾
¾
You can switch between these display configurations by pressing the
key combination [Fn] + [F12].
A Tour of the Notebook’s Keyboard
The Notebook’s keyboard uses a standard QWERTY layout with the
addition of special function keys and an embedded numeric keypad
for number intensive data entry. Your keyboard supports Windows by
incorporating the two Windows specific keys. With the two Windows
keys you will be able to access and take advantage of many of the
timesaving features of Windows software.
The function keys (F1-F12) on the top row of the keyboard, serve
different purposes and carry out different tasks depending on the
application you are running.
The cursor (arrow) keys (which are all located in the lower right
corner of your keyboard) and the [PgUp], [PgDn], [Home] and [End]
keys (which are located along the right edge of the keyboard) allow
you to move the active cursor of the computer to various locations on
the screen or within the document.
The embedded numeric keypad consists of 15 keys that make number
intensive input more convenient. Like the [Num Lock] key, these keys
are labeled in blue on the keycaps. Numeric assignments are located at
the upper right of each key.
When the numeric keypad is engaged, the NumLock icon will appear
in the System Window. The keypad is activated by pressing the [Fn] +
[NumLk] key. If an external keyboard is connected, pressing the
NumLock key on either the Notebook or external keyboard will
enable/disable NumLock of both keyboards in unison. To disable the
Notebook numeric keypad while keeping the keypad on an external
keyboard activated, use the [Fn] + [NumLk] hot key on the Notebook
keyboard.
The Notebook’s Hot Key Controls
KEYS FUNCTION(S)
Power Button Press this button once to power on or
enter the suspend/resume mode.
Press this button for more than 4
seconds to power off the system.
Capture Button Open “Capture” function short-cut key
Internet Button Open Internet WWW Home short-cut
key
26
Outlook Button Open Internet Outlook short-cut key
Wireless LAN
On/Off Button
[Fn] + [F2] This key combination turns on/off the
[Fn] + [F3] Decreases the speaker volume.
[Fn] + [F4] Increases the speaker volume.
[Fn] + [F5] Enable/Disable the system Touchpad
[Fn] + [F7] Decreases the brightness level.
[Fn] + [F8] Increases the brightness level.
[Fn] + [F10] Use this key combination to expand
[Fn] + [F12] This key combination toggles the
Open Email Reader short-cut key
volume.
function
your video screen or reset to its original
size. This function will be disabled
when the system is in Overlay mode
(playing video).
display between the LCD, CRT,
simultaneous LCD/CRT. This function
will be disabled when the system is in
Overlay (playing video) or Extended
Desktop mode.
The TouchPad
The touchpad is a rectangular electronic panel located just below your
keyboard. You can use the static-sensitive panel of the touchpad and
slit it to move the cursor. You can use the buttons below the touchpad
as left and right mouse buttons.
27
TouchPad Precautions
The TouchPad is a pressure sensitive device. Please take note of the
following precautions.
Make sure the TouchPad does not come into contact with dirt,
¾
¾
liquids or grease.
Do not touch the TouchPad if your fingers are dirty.
¾
¾
Do not rest heavy objects on the TouchPad or the TouchPad buttons.
¾
¾
You can use the TouchPad with Microsoft Windows as well as nonWindows applications.
Connecting an External Tracking Devices
The system will only enables you to use one tracking device whether
it is an internal or external tracking device.
Data Storage and Retrieval
Data storage and retrieval are two of the most fundamental tasks you
will perform when working with your computer. The Notebook is
equipped with a hard disk drive (HDD). The HDD is removable
allowing for easy upgrades.
The CD-ROM/DVD-ROM/Combo Drive
Features of the CD-ROM/DVD-ROM/Combo Drive
The features of the CD-ROM/DVD-ROM/Combo Drive are listed
below.
The Audio Play feature allows you to play music CDs
¾
¾
Front panel load/unload button
¾
¾
Supports CD-DA, CD-ROM mode 1 and mode 2, Multi-Session
¾
¾
Photo CD™, CD-I/Video CD (pcs.)
Low power consumption
¾
¾
12.7mm height
¾
¾
Precautions for Handling CD-ROM/DVD-ROM/Combo Drive
Always hold the disc by the edges, avoid touching the surface.
¾
¾
Use a clean, dry, cloth to remove dust, smudges, or fingerprints.
¾
¾
Wipe from the center outward.
Do not write or place objects on the surface of the disc.
¾
¾
Store discs in a cool dry place not to damage the disc.
¾
¾
Do not use benzene, thinners, or cleaners with detergent. Only
¾
¾
use CD-ROM/DVD-ROM cleaning kits.
Do not bend or drop the discs.
¾
¾
28
Loading a Disc
To play a CD disc, follow the instructions listed below.
¾
¾
Push the CD-ROM/DVD-ROM/Combo Drive eject button on the
¾
¾
CD drive door. Gently pull the tray all the way out.
Carefully lift the CD-ROM/DVD-ROM/Combo Drive by the
¾
¾
edges and make sure the shiny surface is face down (the side with
no writing on it).
Carefully insert the CD-ROM onto the tray. Push the CDROM/DVD-ROM/Combo Drive down gently so that it snaps
onto the center ring.
Push the tray back into the drive.
¾
¾
To remove a disk, do the following:
Check the LED display and make sure that the computer is not
¾
¾
accessing the CD-ROM/DVD-ROM/Combo Drive.
Push the eject button and pull the tray all the way out.
¾
¾
Carefully pick up the CD disk by the edges and – while pressing
¾
¾
down on the center ring – remove the CD-ROM/DVDROM/Combo from the tray.
Do not insert any foreign objects into the disc tray. If you
experience difficulty when ejecting the CD disk tray, stretch
a paper clip (or use a pin or a thin metal rod) and insert it
into the emergency eject hole located on the right side of
the front panel. The CD disk tray should eject immediately.
This procedure can also be used to remove a CD from the
drive when the Notebook is powered off.
PCMCIA Cards and Expansion Sockets
The Notebook features one PCMCIA expansion socket design to
interface with one Type II card.
Inserting a PCMCIA Card
The computer will emit a medium tone followed by a high tone when
a PC card is inserted. When you eject a card, the computer will emit a
high tone followed by a medium tone. You can insert and remove a
PC card whether the computer is turned On or Off.
Follow these instructions to insert a PCMCIA card:
1. Hold the PCMCIA card with the arrow side up and the
connector side toward the socket.
29
2. Align the card connectors with the socket and carefully slide
into the socket until it locks into place. The system will beep
once to indicate that it has detected the PC card.
To remove a PC card push the eject button, the button will pop out,
push the button again to eject the PCMCIA.
When inserting a Type II PC card, make sure the connector
is inserted in the socket. Before ejecting a PC card, ensure
that it is not being accessed by the System.
For example, if the message “Write protect error writing
Drive x” is displayed, the user has to change the write
protect switch setting on the memory card. To change the
switch setting, (a) eject the card, (b) change the switch
setting, and (c) re-insert the card.
Always disconnect all telephone lines from the wall outlet
before servicing or disassembling this equipment. To
reduce the risk of fire, use only No. 26 AWG or larger
telecommunication line cord.
Power Saving Modes
This section contains information on the Notebook’s power system,
including the AC Adapter, the battery system, recharging the battery,
and tips for conserving battery power.
The power system is comprised of two parts, the AC Adapter and the
battery system. The AC Adapter converts AC power from a wall
outlet to the DC power required by the computer.
The Battery Power System
A fully charged pack will provide approximately 2 hours of battery
life depending on your system configuration application it runs.
Before using the computer on battery power for the first time, check
the battery status icon on the Windows Toolbar to make sure the
battery is fully charged.
See Battery Status later in this section for a description and
explanation of the Windows Battery icon. Charging the battery takes
about 3 hours to charge when the system is in off state. If possible,
always charge the battery completely.
30
If you use the battery so frequently that it exceed more than
20 times by fully discharging/charging in a single month
alone, we recommend you to perform the “Battery
Calibration” process every 3 months to maintain the battery
life. Please refer to the topic on “Battery Calibration”
describing how to calibrate your system battery discussed
on the latter part of this chapter.
If you discover the battery life is getting shorter, please
perform the “Battery Calibration” process immediately.
Removing the Battery Pack
To remove the battery pack from its compartment, please refer to
Chapter 3, Inserting and Removing the Battery Pack.
Preparing the Battery Pack for Use
Before using the battery pack for the first time, the Smart Battery IC
within the battery pack should be calibrated in order to get accurate
reporting of remaining battery life status.
To calibrate the battery pack, follow the instructions below:
1. Insert the battery into the battery compartment and turn on the
Notebook. If the battery is completely without power go to the
next step.
Otherwise, let the battery run down until the battery low-low
warning beeps are heard.
The system will automatically enter Suspend mode.
2. Turn the Notebook off. Connect the AC adapter and let the
battery fully recharge. When the battery charge indicator turns
off, the battery is fully charged.
3. Turn On the notebook, let the battery run down until the
battery is in low-low state and you hear a warning beeps. The
system will automatically enter the Suspend mode. You can
now connect the AC adapter.
4. The battery pack is now calibrated properly.
In general, using the battery until the low-low battery-warning
indicator appears and fully recharges the battery each time (full
discharge/charge cycle) will ensure the accurate reporting of the
battery gauge status.
31
Automatic Battery Pack Charging Function
You can automatically charge the battery pack by using the AC
Adapter. The charge time is about three hours when the Notebook
power is turned off. The following table summarizes the charging
modes:
Charge Mode Charge Time
Fast 3 hours with the system off or in Suspend
mode. The temperature must be 25°C or
below room temperature.
Pre-Charge A pre-charge is supplied to the Li-Ion
battery pack.
Battery Status
Windows XP has an applet in the Control Panel that will display an
icon in the Windows taskbar indicating when the Notebook is running
on battery power or is attached to the AC adapter.
This applet also displays a meter that indicates how much charge is
remaining in the battery.
Battery Low Warning
When the pack initially reaches the “Battery Low” state
approximately 10 ~ 15 minutes of the usable battery life is left. You
will hear an audible beep signal every 1.5 seconds alerting you to the
“Battery Low” status. When the battery power reaches the “Battery
Low Low” status the beeping sound will accelerate. Your battery now
has 1 ~ 2 minutes of battery charge remaining. You must save your
data or connect AC power immediately; otherwise, you may lose your
data.
Sound Meaning
Continuous
beeping every
Battery Low: Indicates that there is 7
to 10 minutes charge remaining.
1.5 seconds
Beeping
accelerates
Battery Low Low: Indicates that
there is 1 to 2 minutes of battery
charge remaining. Save your work
and turn off the Notebook, or connect
the AC adapter.
32
Small Battery for the Real Time Clock
There is a small built-in battery pack that supplies power to the system
in order to maintain certain system information while the power is off.
If the Notebook is left without a power source for long period of time,
this battery will be exhausted and system information will be lost.
Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer's instructions. Never remove the battery pack while
the power is on as this may result in data loss when the system
loses power.
Battery Calibration
The purpose for this process is to provide a longer battery life for your
system battery pack.
1. Turn on the computer, when the text appears, press [Del] or the
[Delete] key until the system enters the BIOS Setup screen, you
may now make the necessary changes.
2. Press the Î arrow key until it reaches the “Exit” menu screen.
Again press the Ð arrow key and select the “Battery Calibration”
item.
Press the [Enter] key and disconnect the AC adapter then press
the [Y] key until you hear continuous battery low-low warning
beeping sounds. The system will be fully discharge and shutdown
completely.
3. Connect the AC adapter and let the battery fully recharge. The
“Battery Charge LED” of the notebook will light indicating it is
in charging status.
4. When the battery charge LED turns off will indicate the system is
fully charged.
5. Repeat step 1 to 4 once again.
6. The battery is now fully calibrated.
Resetting the System
After installing a software application package, you may be prompted
to reset the system to load the changed operating environment. To
reset the system, or “reboot,” press the [Ctrl] + [Alt] + [Delete] keys
simultaneously. This is known as “warm boot.”
This key combination acts as “software” reset switch when you
encounter hardware or software problems, which lock up the
Notebook.
33
If this key combination does not shut down the Notebook, you can
reset the Notebook by using the Notebook’s power button. Should the
Notebook lock up for some reason, pressing this button powers the
Notebook off.
Adjusting the Brightness
To adjust the brightness on the LCD screen, press and hold down the
[Fn] key in the lower left hand corner of the keyboard and press the
[F7] key to reduce the brightness or [F8] to increase the brightness.
34
Desktop Operation
Your notebook is capable of providing you with efficient and
productive mobile computing, it also has the speed and capacity to
service as a desktop system. This chapter discusses those functions of
your notebook that are typical of desktop systems.
Audio
The Multimedia Sound System
The Notebook’s built-in audio capabilities allow you to take
advantage of a wide range of education and entertainment multimedia
software. The Notebook is equipped with internal stereo speakers, a
microphone, and input audio ports for external audio units. An
external microphone can be connected to the microphone jack.
External speakers or headphones can be connected to the Notebook’s
audio-out jack.
External audio devices can be connected to the Line in jack. All audio
features are software controlled. The Notebook’s multimedia sound
system includes the following features:
Supports Windows Sound System compatibility
¾
¾
Full Duplex operation
¾
¾
Dynamic filtering reduces noise and distortion rate
¾
¾
16-bit digitized audio playback
¾
¾
A built-in microphone for convenient recording
¾
¾
Built-in stereo speakers
¾
¾
Digitized audio recording through the Notebook’s built-in
¾
¾
microphone or any external source
Audio Volume Control
The Notebook is equipped with hot-key volume controls: Pressing the
[Fn] + [F3] hot-key combination decreases the audio output volume,
press the [Fn] + [F4] hot-key combination increases the audio output
volume.
35
Audio Software
Your notebook comes equipped with an integrated sound system
capable of providing you with quality audio sound through the built-in
speakers or through external speakers connected via the system ports.
Sound Recording
Your system allows you to record sounds and store them as files using
the microphone via the microphone jack on the rear of the notebook
computer.
Check the Windows Help and Support Center in Windows for
information on using the various elements in sound recording.
For a high-quality sound, click on the "Volume Control" at
the lower right end of your screen. From the Volume
Control windows, click on the "Advanced" tab, click and
select the "Microphone Boost" item.
Playing Sound Files
Your notebook can play audio files stored in MIDI, WAVE or MP3
file format. Check the Help and Support Center in Windows for
information on the functions of the Media Player.
External Speakers and Microphone
The sound system is capable in providing high-quality sound to
external speakers and receiving and processing sounds from an
external microphone or external sound source.
Connecting Peripheral Devices
To expand your computing capabilities, you can add a variety of
external devices to your computer.
36
Internet Connection
There are numerous ways to connect to the Internet. This may vary
from the user’s working environment as well as system specifications.
Using a modem and a telephone line
¾
¾
Using a wired LAN
¾
¾
Using a wireless LAN (Optional)
¾
¾
Using a modem for Connection to Internet
Use a telephone line to connect to the modem port of your computer.
¾
¾
Do not use a digital telephone line.
Please apply to an Internet Service Provider (ISP) for Internet
¾
¾
service in order for you to connect the modem to the Internet and use
e-mail.
For more detail on the Network key, please refer to your
local ISP provider and follow the procedures describe in the
“ISP Installation Guide” to proceed with the installation.
Using a wired LAN for Connection to Internet
For you connect to the Internet, a wired LAN environment normally
uses the company’s LAN or a broadband modem.
1. Use the network (LAN) cable to connect to the LAN port of
the system.
2. Select on “My Network Places” and click on the “View
Network Connection” in the “Control Panel” window.
3. In the “Network Tasks” window, use your mouse pointer to
click on the “Local Area Connection”.
37
4. Select “Properties” from the popup menu that appears
5. In the “This connection uses the following items” field, select
“Internet Protocol (TCP/IP), and click “Properties”.
38
6. Enter the system’s IP and DNS server addresses on the General
tab of the “Internet Protocol (TCP/IP) Properties” window. If
DHCP is used, click “Obtain an IP address automatically” and
“Obtain DNS server address automatically” on the General tab.
39
7. After all the all the information are correctly entered in the
“Internet Protocol (TCP/IP) Properties” window, click “OK” to
finish.
Using Both DHCP and Static IP for Connection to Internet
When you are alternatively using networks with either DHCP or static
IP addressing, you can use alternative settings that enable
simultaneous configurations of DHCP and static IP to use both of the
network connects without reconfiguring.
1. Follow the steps mentioned when you are using wired LAN
connection from 1 to 7.
2. Click on the “User configured” and enter the appropriate
values in the “Alternate Configuration” tab.
40
3. When you have completed the entire configuration, click “OK”.
41
Using Wireless LAN Network for Connection to Internet
(Microsoft’s Service Pack 2) (Optional)
42
Running BIOS Setup
Introduction
The BIOS (Basic Input and Output System) Setup program is a menu
driven utility that enables you to make changes to the system
configuration and tailor your system to reflect installed hardware or
alter system performance. When the Notebook is turned back on, the
system is configured with the values stored in CMOS. With easy-touse menus, you can configure such items as:
Hard drives and peripherals
¾
¾
Bootup Drive Sequence
¾
¾
Password protection
¾
¾
The settings made in the BIOS Setup program intimately affect how
the Notebook performs.
Navigating through BIOS Setup
The Setup program has been designed to make it as easy to use as
possible. If you accidentally make a setting and don’t know which
one to switch back to, the Setup program has a hot key that allows you
to return to the previous value.
Accessing the BIOS Setup Program
To access the BIOS Setup program, press the DEL key after the
Notebook has run through its POST.
Item Specific Help
On the right side of the Setup screen is an area labeled Item Specific
Help. This area will list navigation key shortcuts and information that
is specific for the item that you are currently editing.
The Menu Bar
The top of the screen has a menu bar with the following selections:
Main - Use this menu to make changes to the basic system
configuration.
Advanced - Use this menu to enable and make changes to the
advanced features available on your system.
43
Security - Use this menu to set a password. The password allows
bootup and controls access to the BIOS setup menu.
Boot - Use this menu to configure the default system device used to
locate and load the Operating System and for booting up the Notebook.
Exit - Use this menu to exit the current menu or specify how to exit
the Setup program.
To access the menu bar items, press the right or left arrow key on the
keyboard until the desired item is highlighted.
The Legend Bar
At the bottom of the Setup screen you will notice a legend bar. The
keys in the legend bar allow you to navigate through the various setup
menus.
The following table lists the keys found in the legend bar with their
corresponding alternates and functions.
Legend Key Alternate
Key
F1 Displays the General
Help window. It can be
enabled from anywhere
in the BIOS.
Esc Jumps to the Exit menu
or returns to the Main
menu from a submenu.
←
→
↑ or ↓
Tab Enter Moves the cursor to the
Minus key (-)
Plus key (+) Scrolls forward through
Selects the menu item to
the left.
Selects the menu item to
the right.
Keypad
arrow keys
Scrolls backward
Moves the cursor up and
down between fields.
next position available in
the field.
through the values for
the highlighted field.
the values for the
Function
44
highlighted field.
Home PgUp Moves the cursor to the
field at the top of the
window.
End PgDn Moves the cursor to the
field at the bottom of the
window.
F9 Sets the parameters for
the current menu to their
default values.
F10 Save and Exit.
Enter Will select a sub menu
or show a range of
options for a field.
Launching Submenus
Note that a right pointer symbol X appears to the left of certain fields.
This pointer indicates that a submenu can be launched from this field.
A submenu contains additional options for a field parameter. To call
up a submenu, simply move the cursor to highlight the field and press
the [Enter] key. Use the [Esc] key to return to the Main menu.
General Help
In addition to the Item Specific Help window, the BIOS Setup
program also provides a General Help screen can be called up from
any menu by simply pressing [F1].
Use the [PgUp] and [PgDn] keys or the up and down arrow keys (↑↓)
to scroll through the entire help document. Press the Home key to
display the first page, press End to go to the last page. To exit the
help window, press the [Enter] or the [Esc] key.
Save Changes and Exit the Setup Program
Refer to the Exit menu section of this chapter for detailed information
on saving changes and exiting the setup program.
45
The Main Menu
When the Setup program is accessed, the following screen appears:
46
The Advanced Menu
Selecting Advanced from the menu bar displays the Advanced menu:
47
The Security Menu
The Notebook’s advanced system of security allows you to set a
password to prevent unauthorized access to system resources, data,
and the BIOS Setup Program.
48
The Boot Menu
The Boot menu allows the user to specify the order in which the
Notebook is to check for a device to boot the system. You can also
configure the way that the system will boot up. To make changes,
select Boot from the menu bar. The following screen appears:
49
The Exit Menu
Once you have made all of your selections from the various menus in
the Setup program, you should save your changes and exit Setup.
Select Exit from the menu bar to display the following menu:
50
VGA Utilities
AutoRun Installation
Installing the Drivers
To make installation of the drivers easier, we offer an auto installation
method for the Microsoft Windows system. To install the driver for
the system, the attached CD disk contains the driver installation, users
manual.
Follow the step-by-step procedures to execute the “AutoRun”
application by selecting the topic of “Driver Installation”.
Select the drivers that you desired and follow the instructions on the
screen. The drivers will be installed in the system automatically.
During the installation, it is very normal that the system may restart.
VGA Utilities
After you have restarted Windows, open the “Control Panel” and
double click on the “Display” icon. From the “Display Properties”
window, select the “Settings” tab and click on the “Advanced” tab to
enter the “Plug and Play Monitor on Mobile Intel® 915GM/GMS,
910GML, Express Chipset Family" window.
51
52
Display Devices
53
Display Settings
Color Correction
54
Hot keys
Launch Zoom
55
3D Setting
Video Overlay
56
Video Conferencing
This application offers video conferencing capabilities to work and
communicate in real-time with one or more participants through
streaming video, from any location.
After installing the PC Camera driver, there is a shortcut in desktop,
and a folder in “Programs”.
Press on the “Camera” button
¾
¾
atop the system keyboard to
run the “Capture”
application.
You can also click on the
¾
¾
icon on the Windows screen
display to run the capture
application.
Press the “Snap” button to launch the application.
You will have to press the button for 0.5 second to launch
application.
The first press is to launch the application while the second
press is to snap.
There are only 10 pictures for you to decide whether to save or
cancel the captured picture.
57
Application
After a video appear on the application window, press on the
“Capture” button to capture the picture.
Using Commands and Buttons
The File Menu Commands and Buttons
Set Capture File -
¾
¾
Set to save directory
and video file name.
Allocate File
¾
¾
Space - Allocate
free space for video
file.
Save Captured Video As - Saved as video file after capturing.
¾
¾
Exit - Exit the application.
¾
¾
The Device Menu Commands and Buttons
This application set the camera device.
58
The Options Menu Commands
Preview - Set
¾
¾
preview in screen or
not.
Video Capture
¾
¾
Filter - Set
Properties.
Video Capture Pin - settings of stream format.
¾
¾
You can set the corresponding feature for Environment, Frequency,
Rotation and Extension of your captured image file.
Environment - set camera work environment.
¾
¾
Frequency - set the frequency.
¾
¾
Rotation - set to horizontal rotation or vertical rotation.
¾
¾
Reset - reset all settings in this page to default.
¾
¾
59
Brightness/Contrast/Hue/Saturation/Sharpness/Gamm
¾
¾
a/White Balance/Backlight Comp - To adjust video settings
and show value.
Default - Reset all settings in this page to default.
¾
¾
60
Exposure - De-select the check mark on the box if you want to
¾
¾
change the value.
Frame Rate - This function is to set video frame rate. If your
¾
¾
utility rate of CPU is too high, you can choose the low frame rate
to reduce the CPU’s utility rate.
Output Size - Change the output size.
¾
¾
Capture Menu Commands and Buttons
Start Capture -
¾
¾
start capture video
stream.
Stop Capture - stop
¾
¾
capture video stream.
Set Frame Rate - set frame rate while capturing a video.
¾
¾
Set Time Limit - set time limit of capture stream.
¾
¾
61
Page intentionally left blank
62
Troubleshooting
This chapter describes locating and solving problems that you may
encounter while using your computer.
Locating a Problem
Problems with your computer can be caused by something as minor as
an unplugged power cord – or as major as a damaged hard disk. The
information in this chapter is designed to help you find and solve
minor problems. If you try all the suggested solutions and you still
have a problem, make a list of what steps you have taken to correct
the problem and contact your dealer.
Successful troubleshooting is the result of careful observation,
deductive reasoning, and an organized approach to solving the
problem.
The problems that you will encounter can be divided into two basic
categories: hardware problems and software problems. Hardware
problems can be further divided into electrical and mechanical
problems. You will know you have a hardware problem if the screen
is dark, the computer cannot read the disk drives, or you get an error
message during the Power-On Self Test (POST).
Software errors can occur at several levels. The ROM BIOS and the
operating system can give you a large number of error messages. On
top of this, each application software package has its own set of error
messages. It is important to determine whether the software error
message you are getting is from the application or the operating
system. Once you know this, you can look in the respective manual
for a solution to the problem.
Checking Cables and Connections
Start by performing a careful visual inspection of the exterior of the
computer. If no LEDs are illuminated, make sure that your computer
and its peripherals are getting power and communicating with each other
properly.
63
To check the power cables, and connections:
1. If you have been using battery power, connect the Notebook to
an external power source and make sure that the battery has a
charge.
2. If you are using the Notebook with the AC adapter, check the
power outlet, the power cord, and any power switches that may
affect your computer.
¾ Check the wall outlet or power strip with an item that
you know is functioning properly. A lamp or radio is a
convenient item for checking the power. You may also
need to check the fuses and breakers in your electric box.
¾ If the outlet is controlled by a wall switch, make sure
that the switch is on.
¾ If the outlet is controlled by a dimmer switch, use a
different outlet.
¾ If your computer is plugged into a power strip with an
On/Off switch, make sure the switch is on.
3. With the computer’s power switched off, check all cable
connections. If the computer is connected to any peripheral
devices, look for loose or disconnected cables.
If the computer is too close to a wall, a cable connection may be loose
or the cables may be crimped.
Do not substitute cables for different devices (other than
the manufacturer recommended cables) even if they look
exactly alike. The wiring inside the cable may be different.
4. When you are certain that you have power available and all
connections are good, turn the computer on again. If the
computer still does not start, you may have a hardware problem.
The Power-On Self Test
The Power-On Self Test (POST) runs every time you turn on or reset
the Notebook. The POST checks memory, the main system board, the
display, the keyboard, the disk drives, and other installed options.
A few seconds after you turn on your computer, a copyright message
appears on your display screen. A memory test message appears next;
as the test continues, memory size increases until all installed memory
is tested.
64
Normally, the only test routine visible on the screen will be the
memory test.
Two classifications of malfunctions can be detected during the POST:
Error messages that indicate a failure with either the hardware,
¾
¾
the software, or the Basic Input/Output System (BIOS). These
critical malfunctions prevent the computer from operating at all
or could cause incorrect and apparent results. An example of a
critical error is microprocessor malfunction.
Messages that furnish important information on the power-on and
¾
¾
boot processes (such as memory status). These non-critical
malfunctions are those that cause incorrect results that may not be
readily apparent. An example of a non-critical error would be a
memory chip failure.
In general, if the POST detects a system board failure (a critical error),
the computer halts and generates a series of beeps. If failure is
detected in an area other than the system board (such as the display,
keyboard, or an adapter card) an error message is displayed on the
screen and testing is stopped. It is important to remember that the
POST does not test all areas of the computer, only those that allow it
to be operational enough to run diagnostic programs.
If your system does not successfully complete the POST, but displays
a blank screen, emits a series of beeps, or displays an error code,
consult your dealer.
General Hardware Problems
A few common hardware problems and suggested solutions are
presented in the table below:
Problem: Failure in the installation of the Audio driver.
Solution: Be sure to first remove the current audio device
from your system. Please follow the instruction on the
installation of audio driver.
Problem: The display screen is dark
Solution: Make sure that the computer is not in Suspend
mode. Check the Brightness controls for the screen. If the
controls are turned too far down, the screen will be dark.
65
Problem: An incorrect date and time are displayed.
Solution: Correct the date and time using the DOS DATE
and TIME commands or the options in the Setup Utility. If the
date and time become incorrect after a short time, your CMOS
battery may be depleted. Contact your dealer to change the
battery.
Problem: You hear irregular beeps during operatio n of the
Notebook and the system halts.
Solution: The problem is beyond the scope of this manual.
Contact technical support.
Problem: An unidentified message is displayed.
Solution: Reboot the computer and run the BIOS system
setup. Confirm the Setup parameters. If the same message is
displayed after booting up again, contact technical support for
assistance.
Problem: The system cannot access the CD-ROM/DVD-
ROM drive.
Solution: Check that a CD is properly inserted in the drive.
Make sure that you are using the correct program for that kind
of CD. For example, the system cannot read a data CD using
an audio program.
Problem: You cannot operate the printer.
Solution: Check the printer cable connection. Ensure that
the printer power switch is turned on. Confirm that the printer is
on-line.
Problem: You cannot use the mouse.
Check the cable connection.
¾
¾
Check the mouse with another application to see if there is a
¾
¾
software incompatibility problem.
If possible, check the mouse with another computer to see if it
¾
¾
works. If it doesn’t operate on a different system, the mouse
might be broken.
66
Contacting Your Dealer
If you still have a problem after reading the preceding sections, the
next step is to contact your dealer. Your dealer can determine if the
problem is something that requires the computer to be taken to the
shop. Before you call your dealer, however, prepare the following
information:
How is your computer configured? Your dealer needs to know
¾
¾
what peripheral devices you are using.
What messages, if any, are on the screen?
¾
¾
What software were you running at the time?
¾
¾
What have you done already to try to solve the problem? If you
¾
¾
have overlooked a step, your dealer may be able to solve the
problem over the phone.
67
Page intentionally left blank
68
Upgrading your System
Upgrading your Memory
Refer to the following instructions and illustration for information on
upgrading your notebook's memory.
Turn off the computer and disconnect the AC adapter and all
¾
¾
peripherals.
Turn the notebook over so that the rear ports are facing you and
¾
¾
locate the memory module compartment.
Remove the screws that secure the RAM module compartment
¾
¾
cover and set it aside in a safe place.
If you need to install a higher capacity module, gently push the
¾
¾
edge clips on both sides to release the module. Angle the card
slightly upward and gently slide it from its edge connector slot.
Store the card in the anti-static bag that contains your new
module(s).
To install the new memory card, hold the card with its gold edge
¾
¾
connector toward the edge connector slot of the compartment. To
help you orient the cards, the edge connector has been made with
two unequal-length sections. You will only be able to insert the
card in one direction.
Insert the edge connector into the slot. The gold edge connector
¾
¾
of the card should not be visible when the card is fully inserted.
Press the card downward where you should hear an audible click
¾
¾
as the latches of the connector secure the card in place.
Once the module is properly seated, you can replace the cover on
¾
¾
this compartment.
69
Replace and tighten the screw.
¾
¾
The Easy to Upgrade HDD Module
The hard drive in your notebook computer is made to be easily
swapped out for upgrading. You should back up your hard drive
before attempting o change the hard drive. Make sure that before you
install a new drive, all the files in your system should be backed up.
To upgrade your Hard Drive
Power down the system completely. Turn the system over with
¾
¾
the front of the unit facing you.
Remove the three screws that secure the compartment cover and
¾
¾
set them in a safe place.
Slide the HDD cover away from the compartment.
¾
¾
The drive is attached to a special bracket that secures it to the
¾
¾
notebook computer. There are 4 screws hold the bracket.
Remove the screws and set them in a safe place.
Push the HDD slightly in the direction of the arrow as shown in
¾
¾
the illustration to release it from the pins of the drive.
Gently hold the grip of the HDD, lift it up to release from its
¾
¾
compartment.
To install the new HDD, you will need to align the tabs on the
¾
¾
drive bracket with the slots on the bay. Press down gently on the
drive bracket until it engages with the system. Do not force the
drive into place this can bend the pins on the hard drive.
Slide the compartment cover into place and be sure the screw
¾
¾
holes on the cover align completely with the screw holes in the
case.
Secure the cover with the three screws.
¾
¾
Upgrading your System CPU
Refer to the following instructions and illustration for information on
upgrading your notebook's CPU.
70
Turn off the computer and disconnect the AC adapter and all
¾
¾
peripherals. From the rear side of your notebook, locate the CPU
compartment and unscrew the 5 screws that is attached to the
CPU compartment door
Lift up the compartment door by using your index finger to lift
¾
¾
the cover from the latch.
Remove the 4 screws that are attached to the heatsink on top of
¾
¾
the CPU.
Use a screw to turn the screw that is attached to the CPU in
¾
¾
counterclockwise direction as shown on the illustration.
After the screw is loosen you can lift up the CPU to finish the
¾
¾
procedures.
71
Page intentionally left blank
72
Detailed Notebook Specifications
Processor
Operating System
Compliance
Core Logic
Memory
LCD Display
Video & Graphics
Hard Drive
Optical Drive
Pointing Device
Application
Launch Key
LED Status
¾ Intel
¾ 478pin mFCPGA package
¾ Microsoft
¾ Microsoft
¾ Intel
¾ Expansion 1 slot of 200pin DDR module,
¾ Support DDR-333 module
¾ 12.1” WXGA (1280 x 800; 16:10) TFT Glare
¾ 12.1” XGA (1024 x 768; 4:3) TFT LCD
¾ Intel
¾ 2.5" 9.5mm height, ATA100/66 support
¾ 5.25" 12.7 mm height Combo Drive (DVD-
¾ Synaptic touchpad
¾ E-mail, Internet, Capture, WLAN, Power
¾ Power, Suspend/Resume, Battery Charging
®
Pentium® M processor
715/725/735/745/755/765, (2
Mobile Microarchitecture, 2MB L2 cache,
400MHz FSB).
®
Windows® XP Professional
Edition
®
Windows® XP Home Edition
®
915GM(Alviso) + ICH6-M
1GB total memory capacity
Type LCD display with 1.3Mega pixel
CMOS Camera
display
®
915GM with Embedded 3D engine
(New Generation GMA 900), SMA up to
64MB DDR SDRAM
ROM + CD-RW), DVD Dual (DVD+/-RW),
Super Multi (DVD-RAM+ DVD+/-RW)
Staus, Hard Disk Access, NumLock mode,
Specification
nd
Generation
73
Indicator
CapsLock mode, ScrollLock mode
Keyboard
PCMCIA
Audio
AC Adapter
Battery
Battery Charge
BIOS
Card Reader
Communication
USB Connector
Power
Management
Security
Size
Weight
¾ 3.0mm travel, inverted-T, 87 keys with 3
windows key
¾ One Type II PCMCIA slot, support CardBus
¾ AC97 2.3 compliant, SPDIF, 5.1 channel
support
¾ Built-in two high quality stereo speakers
¾ Input: 100-240V AC, 50-60Hz, 1.5A,
Universal
¾ Output: 20V DC, 2.5A, 65W
¾ 6 cell Li-Ion battery pack
¾ 3.5 hours charge time to 100% capacity
while system off
¾ AMI, Support PnP, password, Bootable
from USB FDD, Optical Drive Device
¾ 4-in-1 card reader (support
SD/MMC/MS/MS Pro card)
¾ 10/100 Base-T LAN on board
¾ Built-in MDC V.92 56Kbps Fax/Modem
¾ Intel
®
PRO/Wireless 2200BG/2915ABG
network connection
¾ CMOS camera with USB interface, 1.3
Mega pixel resolution CMOS image, up to
240 degree (-30° ~ 210°) (12.1" WXGA
only)
¾ Three USB2.0 ports, up to 480Mbit/s
¾ ACPI 2.0 compliance
¾ Support Stand-by, Suspend to Disk,
Suspend to RAM
¾ Smart Battery System Support
¾ Kensington Lock, BIOS password
protection
¾ 320.0(W) x 242.0(D) x 22.0(H)mm/28.0 mm
(front/back)
¾ Under 2.3kg with 12.1” panel, 6cell battery
and Optical drive installed (TBD)
74
PS
¾ Battery life will vary depending on your
specific hardware and software
configuration
¾ Spec subject to change without notice
75
Loading...
