Eliason is a global leader in
providing solutions for the
retail & supermarket industries.

Our business is dedicated to bringing value to our customers.

For over 50 years, we have provided our clients with quality

products engineered and built for high-performance, specifi cally

designed to meet our customers needs and applications.

Model RMR-1500

Door Bo dy: Rota tionally molde d, monolithic door panel wit h

CFC-free f oam core and full perim eter gasket s. 1.5” total door
thick ness. Polye thylene door skin is .188” t hick

Window: 18” x 18” High Imp act Polycarbonate

Hinges:

Easy Swing Hin ging System

Easy S pring Bump er: 18” high

Jamb G uard: 3” x 9”

Model SCG-3 / FCG-3

SCG-3 Door Bo dy: .75” ex terior grade s olid wood core, 1”
total d oor thickness Fin ish: 18 gauge f ull length stainless steel
panels ( both sides ) Window: 9” x 14” clear acrylic set in black
rubber moldin g Gasketing: Perimeter seal w ith adjustable
bottom gasket Ea sy Spring Bu mper: 18” high (bot h sides)

Show n with Opti onal: 15” x 20” clear acrylic windows

FCG-3 Same fi nish and gasketing as SCG 3 wit h 1.5” foam

insulat ed core and dou ble glaz ed wind ow

Model EISA-30

Door Bo dy: 3.5” thick wit h rigid PVC st ructural frame an d high-

densit y, CFC-fre e urethane fo am core. R-25

Finish: Clad full height both sides with .100” thick impact- resistant
thermoplas tic, available in a variety of colors

Gaske ting: Full perimeter seal

Window: Double pane acr ylic window se t in black r ubber

molding.

Options: Easy S pring Bumpers, Jamb Guards, Push Plates, Flat
Impac t Plates

Model LWP-3

Door Bo dy: .06 3” thick tempered alu minum alloy with

delta f ormed vertical edges

Finish: Satin ano dized (bot h sides )

Window: 9” x 14” clear acrylic set in black rubber molding

Show n with opti onal: 10” rou nd transluce nt window

Model HCP-10

Door Bo dy: Uret hane foam cor e with a high str ength structural

PVC frame, 1.5” total door thickness

Finish: .100” t hick high impac t thermoplastic ex terior

Window: 14” x 16” clear acr ylic, double glazed set in black rubber

molding

Easy S pring Bump er: 18” high (b oth sides) or optional 24” high
scuf f plate (bot h sides)

Show n with Opti onal: 5” x 18” jamb guards with h eavy dut y
bottom lea ves and 14” x 16” fl ush window

Model SFI-1750

Door Bo dy: High st rength struct ural PVC frame wit h insulating,

moisture-resis tant, energy-absor bing core, 1.50 ” total door thickne ss

Finish: .100” t hick high impac t thermoplastic ex terior

Gaske ting: Perimet er edge, top and hinge seals

Wind ow: 18” x 18” Double Pane High Impa ct Polycar bonate Set In

Ther moplastic Window Frame

Hinges: He avy Duty V- Cam Hinging Sy stem

Jamb G uard: 3” X 9” With H eavy Dut y Bottom Le af

We are proud of our long-term relationships with some of the world’s largest and most successful retail and

supermarket chains and independent grocers. All have one thing in common, the desire to improve their

retailing performance by reducing costs without sacrifi cing quality.

Attention to Our Customers.

Eliason is structured for prompt response to meet the requirements of our many different customers. Our

dedicated sales, service, and support organizations can deliver the right solution at the right time and at the

right price to meet the needs of each specifi c customer. Whether we are assisting with a single independent

store start-up or working with a large chain operation wanting unique customized solutions that fi t their

high-volume business models, the team at Eliason is ready to respond rapidly with the right solutions.

Model SCP-1

Door Bo dy: .75” ex terior grade solid wood core, 1” total door
thickness

FINISH: Top Pa nel: .03 2” tempered aluminum alloy wit h
satin anodized fi nish (both sides ) Base Plate : 48” high, 18
gauge stainle ss ste el (both side s), Back C hannel: 18 gau ge
stainless st eel

Window: 9 ” x 14” clear ac rylic, set in black rubber molding
Show n with opti onal: 14” x 16” windows

Model FMP

Door Bo dy: Double ply .120” vin yl sheet, .24 0” total doo r
thickness

Finish: P ebble embossed

Window: 14” x 16” clear vinyl

Hardware: Top mou nted ONLY, No bottom p ivot

Model PE-500

Door Bo dy: .5” thick door p anels are cons tructed of USDA

accepted s tres s-relieved high-density pol yethylene w ith a
16 gauge stainless steel back c hannel for added str ength
and rigidity

Window: 9” x 14” scrat ch-resistant acrylic vision p anels
set in bla ck rubber molding.

Hinge: Eas y Swing Syst em

Model FCDM

Door Bo dy: Single ply .120” clear vinyl s heet

Hardware: Top moun ted, no bottom piv ot, off-set

mounting hardwar e available if required

Model PMP-2

Door Bo dy: .70” to tal door thick ness throu ghout the imp act area,

.20” t hick (double ply 1/8” ABS material) in window ar ea

FINISH: Surface: Textured surface (both sides)
One Pie ce: .25” thick AB S base plate an d back spline (b oth sides)
Back Ch annel: 16 gau ge stainless s teel

Window: 14” x 16” clear acr ylic, set in black rubb er molding

Show n with Opti onal: 14” x 16” AB S window frames

Strip Doors

Door Bo dy: Clear fl exible P VC strips are availa ble in thicknesses

rangin g from .06” to .160” and widths f rom 4” to 16”. Strips c ome
in both s tandard and USDA low-temp reinforced grade s. Strip
overlap is adjus table depending on the applic ation

Mounting : We offer four di fferent t ypes of mounting hardware,
providing versatility to mount o n the wall above t he door header
or under the doo r jamb

Enhanced Products and Services.

Retailing is all about product, service and the consumer – enhancing services and ensuring product

availability to meet the ever changing needs of the customer. Eliason provides a full range of

energy-saving and environmentally responsible solutions for the supermarket and retail industries

that are durable, sustainable and renewable.

Eliason’s Energy Saving Products include the EISA R-25 door and our Econo-Cover line which reduces

energy consumption while increasing product shelf life.

Econo Cover

®

Double Action (white)

Econo Cover

Easy Mount

®

Econo Strips

All night covers are not created equal.

Econo Covers from Eliason outperformed competitive woven aluminum night covers in a side-by-side test, generating

a 36% savings in refrigeration energy costs while increasing product shelf life. And—Econo Covers from Eliason are

available at a fraction of the cost.

Econo Covers are available in clear, black and white and feature no mechanical moving parts to maintain or replace.

Unique, simple and effective in directing cold air fl ow, our see-through strips reduce refrigeration loss, create warmer

aisles and provide 24-hour product protection.

Eliason Econo Covers… Right Night Shade. Right Price.
