Strip Doors & EZ Hang HardwareSliding Doors & Corrosion Resistant Doors
SDA 9000
Sliding Door
Eliason SDM 9000 and SDA 9000 Horizontal Sliding
doors are designed for use in applications where an
attractive, durable and reliable sliding door is required.
OPTIONAL FEATURES
• Available in Single Slide or Bi-Parting Models
• Manual or Powered Operation
PANEL CONSTRUCTION CHOICES
ABS Clad Door Panels: Internal welded steel frame
with full perimeter PVC extrusion and impact resis-
tant ABS outer skin. The foamed-in-place, non-CFC
urethane core bonds to the outer skin and provides
an “R” value of 11. Standard total panel thickness
is 1.875”. Full thickness panels are available up to
4” thick. FRP Solid Core Door Panels: Totally
sealed solid core construction with seamless FRP
face sheets, solid polymer reinforcement at all joint
and hinge locations and choice of non-CFC urethane
foam, end grain balsa or honeycomb core.
Both panel construction designs offer a virtually
unlimited array of size and décor options.
APPLICATIONS
• Pharmaceutical • Warehouses
• Chemical Plants
• Food Processing
.100” thick textu red
ABS plastic provides
the outer skin. (Contact
Sales Rep. for Color
Options)
Non-CFC Ureth ane
foamed in place c ore
provides excellent
insula tion and sound
abatement
Extr uded al uminum floor
guide mo unted to th e
door panel
Floor gu ides an chore d
to the floor
Fiberg lass or S tainl ess
Steel Fra me (Opti onal)
Safety Opera tion
Light
Model SDA 90 00 Shown
Drop down extru ded alu minum trac k for excellent floor
seal. Ne oprene wheels for
easy and quiet op eration
Welded rigid PVC tubing
create s the stro ng perimeter
structure
Contro l Panel and operating
switch Powe r Requirements
(220V, Single Phase)
A selec tion of ergonom icall y
friendly push and pull b ars
available
Safety Door Se nsor
Back up he ader and casings
Door Closer Reinforc ement
and Doo r Close r (Optional)
Strip Doors
APPLICATIONS:
industrial, institutional, retail and cold storage environments where a high
visibility, low-cost barrier is preferred. Strip doors was suitable for pedes-
trian, cart, pallet jack and man-ridden vehicle traffic.
LIMITATIONS: Not recommended where heavy wind or excessive
air pressure is present.
EZ HANG HARDWARE
•
HTP Exclusive cross-linked polymer technology.
•
Also available in aluminum or stainless steel
DOOR MODELS
• Model SR 4001: Face of wall mount • Model SR 4003: Swing mount
• Model SR 4002: Under lintel mount • Model SR 4004: Sliding mount
OPTIONS & COLORS: Eliason also offers orange or red safety edge
strips, custom strip door configurations, as well as full roll strip material in a
variety of colors, widths and thicknesses.
Eliason SR 4000 Strip Doors are designed for commercial,
EZ HANG HARDWARE
• Easiest system on the market
• 75% faster initial installation time
• 90% faster strip replacement time
• Door strips simply push into place
• No nuts, bolts or washers
• Fits all Eliason strip doors
INSTALLATION & MAINTENANCE: Eliason
Series 4000 Strip Doors are conveniently pack-
aged and very easy to install because there are
no fasteners required to attach the strips to the
EZ Hang Hardware. Strip doors can be cleaned
using a strong industrial soap or detergent.
CF 9000 Corrosion
Resistant Door
The Single acting CF 9000 Door is engineered and
constructed using the same durable materials and
proven methods seen in our SR 9000 Double
Acting Impact Traffic Door.
FEATURES
• Tough Exterior
• Impervious Core
• Unlimited Sizes
Wide Range of Hardware
•
TRAFFIC
• Pedestrian
APPLICATIONS
• Food Processing
• Pharmaceutical
• Chemical Plants
Waste Water Treatment
•
• Car Washes
• Swimming Pools
Vision panel is 1/4” clear
Acrylic set in a r igid PVC
frame
Cylindrical lever
passa ge set (Optional)
Prep for C ylindrical
passa ge set
.100” thick textu red
ABS plastic provides
the outer skin. Available
in many colors.
Prep for mortise hinge s (3)
Black PVC c hanne l covers
the entire perimeter
Welded 1-1/4” square tube
steel cr eates th e strong
interior peri meter structu re
Non-CFC, foamed-in-place
Uretha ne core p rovide s
excellent insul ation and
sound abatement.
Panel “R ” Value = 11
WARRANTY: Eliason SR 4000 series
strip doors carry a one year warranty
against defects in material or workmanship.
Industrial Strength
Door Solutions
Over 50 Years Strong • www.eliasoncorp.com • (800) 828-3655
CORPORATE HEADQUARTERS 9229 SHAVER ROAD, KALAMAZOO, MI 49024 • FAX (800) 828-3577
Page 2
IMPACT RESISTANT
ABS CLADDING
HIGH DENSITY NON-CFC
URETHANE FOAM
INTERNAL WELDED STEEL FRAME
PVC FRAME
HEAVY DUTY
BLADE GASKET
(REPLACEABLE)
Heavy & Extra Heavy Duty Traffic Doors Light Industrial Doors Flexible Industrial Doors
SR 9000 Heavy Duty & FX 9000 Extra Heavy Duty
Impact Traffic Doors
The SR 9000 Heavy Duty and FX 9000 Extra Heavy Duty Impact Traffic Doors are manufactured to the same demanding
Eliason design and quality standards that have been the envy of the door industry for nearly sixty years. These rugged doors
operate smoothly, require very little maintenance and are built to survive in the toughest applications. Both models are NSF
and CFIA accepted.
SR 9000 Heavy Duty Impact Traffic Door
DOOR BODY: A heavy duty reinforced internal steel frame combined with a full
perimeter extruded PVC frame ensure panel strength and integrity. Both sides of each
door panel are clad with .100” thick impact resistant ABS plastic. The non-CFC urethane
foam core bonds to the outer door shell and creates an “R” factor of 12.18. These doors
are impervious to moisture, acid, petroleum products, animal fat, rodents, insects and
salt solutions. Replaceable blade gaskets on the vertical and bottom edges and a frame
mounted top-seal are standard. Overall panel thickness is 1-7/8”.
HINGES (SR 9000): Heavy duty ductile iron V-Cam, upper and lower hinge posts
and heavy duty roller assembly. Steel lower hinge guards are standard.
APPLICATIONS: Industrial, Institutional, Cold Storage, Food Processing,
Warehouse, Supermarket.
TRAFFIC: Pedestrian, Pallet Jacks
FX 9000 Extra Heavy Duty Impact Traffic Door
DOOR BODY: Panel construction is the same as the SR 9000, except the FX 9000 has
additional internal steel reinforcement for maximum strength in the toughest applications
where forklift and other man-ridden vehicle traffic exists.
HINGES (FX 9000): Heavy duty stainless steel V-Cam, ducile iron upper and lower
hinge posts and heavy duty roller assembly. Steel lower hinge guards are standard.
APPLICATIONS: Industrial, Institutional, Cold Storage, Food Processing,
Warehouse, Supermarket.
TRAFFIC: Pedestrian, Pallet Jacks, Forklifts, Man-Ridden Vehicles.
WINDOWS (SR 9000 & FX 9000):
Standard single pane vision panels are 1/4“ thick polycarbonate mounted in a recessed
PVC frame, all sealed to the door panel. Optional double pane vision panels are 1/8”
thick polycarbonate mounted in a self locking black rubber gasket. All vision panels are
centered at 60” from the floor and sized based on door panel width. Refer to the
vision panel chart for sizing.
OPTIONS (SR 9000 & FX 9000):
EASY SPRING BUMPERS: Up to 42” high, both sides of each door panel.
HINGES: Optional 180 degree V-Cam Hinges.
RMR-1500 Traffic Door
DOOR BODY: Rotationally molded, monolithic door panel with CFC-
free foam core and full perimeter gaskets. 1.5” total door thickness.
Polyethylene door skin is .188” thick.
WINDOWS: 18”x18” high-impact polycarbonate set in two-piece
black molded window frame.
HINGES: Eliason
EASY SPRING BUMPERS: Available up to 42” high on both sides of
each door panel.
JAMB GUARDS: 3” x 9”
COLORS: Gray, Beige, Sand, White, Blue, Red, Green,
Appliance White, Black or Brown.
Easy Swing
®
Hinging System.
PE-500 HDPE Traffic Door
DOOR BODY: High density polyethylene, USDA accepted and
textured both sides with 16 gauge stainless steel back channel.
½” total door thickness.
WINDOWS: 9” x 14” acrylic set in black rubber molding.
HINGES: Eliason
AVAILABLE OPTIONS:
– Full Perimeter Gasketing
– 3” x 9” Jamb Guards
– Impact Plates
– Molded Spring Bumpers
– Special Vision Panel Configurations
COLORS: Gray, Beige, Sand, White, Blue, Red, Green,
Appliance White, Black or Brown.
Easy Swing
Available
Colors:
While the PE-500 im pact traffic door is designed to withsta nd abuse from cart and pedestrian traffic, it is not intended for applications where motorized traffic exists.
Gray Beige Sand White Blue Red Green
®
Hinging System.
Appliance
White
Black Brown
FCD-160 Doors
DOOR BODY: One layer of .160” thick clear PVC with 48” high textured vinyl
impact plates on both sides, jamb-edge balloon seals and wiper seals at top and
bottom of each door panel. Large flexible PVC vision panels for maximum visibility.
Hinge pocket is constructed with two layers of black, reinforced vinyl-coated nylon
material. Bi-parting models have 3” overlap at center.
HINGES: Eliason heavy-duty, top mounted, gravity-operated hinges are adjustable
and allow the door panels to open easily and close automatically. Top mounted only
design leaves maximum WIC available for passage of wide loads.
APPLICATIONS: Cold Storage Facilities; Walk-in Coolers; Shipping and
Receiving Areas; High Volume Industrial Openings
FLT-400 Doors
DOOR BODY: Two layers of flexible, abrasion-resistant, USDA accepted belting
material bonded back to back with jamb edge balloon seals and wiper seals at top
and bottom of each door panel. Large flexible PVC vision panels for maximum vis-
ibility. Hinge pocket is reinforced with vinyl-coated nylon material. Bi-parting models
have 3” overlap at center.
HINGES: Eliason heavy-duty, top mounted, gravity-operated hinges are adjustable
and allow the door panels to open easily and close automatically. Top mounted only
design leaves maximum WIC available for passage of wide loads.
APPLICATIONS: Cold Storage Facilities (Temperatures to -40°F); Walk-In Cool-
ers and Freezers; Food Processing Facilities; Shipping and Receiving Areas; High
Volume Industrial Openings
SR 1240 / FMP-240 Doors
DOOR BODY: Two layers of .120” thick textured PVC bonded back to back with jamb-
edge balloon seals and wiper seals at the top and bottom of each door panel. Large
flexible vision panels provide maximum visibility. Hinge pocket is reinforced with vinyl-
coated nylon material. Bi-parting models have 3” overlap at center. CFIA Accepted.
HINGES: Eliason heavy-duty, top mounted, gravity-operated hinges are adjustable
and allow the door panels to open easily and close automatically. Top mounted only
design leaves maximum WIC available for passage of wide loads.
APPLICATIONS: Dock Openings; Stock Rooms; Walk-In Coolers.
COLORS: Red, Gray, Green, Tan, Brown or Black
