Elgen HAMMER-ON REGULATOR SETS Data Sheet

HAMMER-ON REGULATOR
SETS

Product Data Sheet

Description

Elgen’s Hammer-on Damper Regulator Set
is used for controlling the damper inside the
ductwork.

Kit Components

E-69

Item Qty

E-704 1

E-705 1

E-706 1

E-708 1

E-70

Item Qty

E-704 1

E-705 1

E-706 1

E-708 2

E-71

Item Qty

E-702 1

E-704 1

E-705 1

E-706 1

E-708 1

Features

Corrosion resistant
Provide quick and economical means of
installing and assembling damper blade

Designed for round or square damper blades up
to 24 GA steel

Packaging

Item# Box Qty

GH1014 144

GH1015 144

GH1016 144

Guarantee

All Elgen products are guaranteed by Elgen Manufacturing
against defective material.

Elgen Manufacturing

10 Railroad Ave, Closter NJ 07624
Tel: [phone] :: Fax: [phone]
[e-mail] :: www.elgenmfg.com

ALL STATED SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION

TIP for DAMPER BLADE
REGULATOR (E-702)

Product Data Sheet

Description

Elgen’s Tip for Damper Blade Regulator is used
with conjunction with Damper blade for
controlling the airow inside smoke-ttings and
round ductwork.

Standard Construction

Manufactured from Zinc Plated carbon steel

Features

Corrosion resistant

Packaging

Item# Box Qty

GH1000 100

Elgen Manufacturing

10 Railroad Ave, Closter NJ 07624
Tel: [phone] :: Fax: [phone]
[e-mail] :: www.elgenmfg.com

ALL STATED SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION

Guarantee

All Elgen products are guaranteed by Elgen
Manufacturing against defective material.

WASHER for DAMPER

BLADE REGULATOR (E-704)

Product Data Sheet

Description

Elgen’s Washer for Damper Blade Regulator is
used with conjunction with Damper blade for
controlling the airow inside smoke-ttings and
round ductwork.

Standard Construction

Manufactured from Zinc Plated carbon steel

Features

Corrosion resistant

Packaging

Item# Box Qty

GH1001 100

Elgen Manufacturing

10 Railroad Ave, Closter NJ 07624
Tel: [phone] :: Fax: [phone]
[e-mail] :: www.elgenmfg.com

ALL STATED SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION

Guarantee

All Elgen products are guaranteed by Elgen
Manufacturing against defective material.

HANDLE for DAMPER BLADE

REGULATOR (E-705)

Product Data Sheet

Description

Elgen’s Handle for Damper Blade Regulator is
used with conjunction with Damper blade for
controlling the airow inside smoke-ttings and
round ductwork.

Standard Construction

Manufactured from 18 GA ASTM A-653 G60
material

Features

Corrosion resistant

Packaging

Item# Box Qty

GH1002 100

Elgen Manufacturing

10 Railroad Ave, Closter NJ 07624
Tel: [phone] :: Fax: [phone]
[e-mail] :: www.elgenmfg.com

ALL STATED SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION

Guarantee

All Elgen products are guaranteed by Elgen
Manufacturing against defective material.

WING NUT for DAMPER BLADE
REGULATOR (E-706)

Product Data Sheet

Description

Elgen’s Wing Nut for Damper Blade Regulator
is used with conjunction with Damper blade for
controlling the airow inside smoke-ttings and
round ductwork.

Standard Construction

Cold Forged Zinc Plated carbon steel

Size: 5/16”
Threading Type: 18

Features

Corrosion resistant

Packaging

Item# Box Qty

GH1003 100

Elgen Manufacturing

10 Railroad Ave, Closter NJ 07624
Tel: [phone] :: Fax: [phone]
[e-mail] :: www.elgenmfg.com

ALL STATED SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION

Guarantee

All Elgen products are guaranteed by Elgen
Manufacturing against defective material.

BEARING for DAMPER BLADE

REGULATOR (E-708)

Product Data Sheet

Description

Elgen’s Bearing for Damper Blade Regulator is
used with conjunction with Damper blade for
controlling the airow inside smoke-ttings and
round ductwork.

Standard Construction

Manufactured from Zinc Plated carbon steel

Features

Corrosion resistant

Packaging

Item# Box Qty

GH1004 100

Elgen Manufacturing

10 Railroad Ave, Closter NJ 07624
Tel: [phone] :: Fax: [phone]
[e-mail] :: www.elgenmfg.com

ALL STATED SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION

Guarantee

All Elgen products are guaranteed by Elgen
Manufacturing against defective material.
