Page 1
AUTO CORNER FOR C & F
Product Data Sheet
Features
Add rigidity to the Transverse Duct Flange
Hold ductwork together
Provides a sealing surface for the Elgen 440 Butyl
Gasket
Union Made
Description
The Elgen Auto Corner for C & F is used in
conjunction with the Transverse Duct Connection and Transverse Duct Flange formed on
Flange.
Standard Construction
Stamped from 16 GA ASTM A-653 G60/G90
material
Manually inserted into C Flange
Accepts a 3/8” carriage bolt
Weight(per box): 36 lbs
Optional Construction
Stainless Steel 304
Stainless Steel 316
Aluminum
PCD
Galvanneal (Paint Grip)
Packaging
Box Qty Skid Qty
300 24,000
Elgen Manufacturing
10 Railroad Ave, Closter NJ 07624
Tel: 800.503.9805 :: Fax: 201.964.9030
[email protected] :: www.elgenmfg.com
ALL STATED SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION
Guarantee
All Elgen products are guaranteed by Elgen
Manufacturing against defective material.
