Elgen DIAL DAMPER REGULATOR SET Data Sheet
DIAL DAMPER
REGULATOR SET (1/4”)
Product Data Sheet
Description
Elgen’s Dial Damper Regulator Set is used for
controlling the damper inside the ductwork.
1/4” regulator sets for dampers up to 10”.
Kit Components
EDR-2X
Item Qty
RP-2X 1
RP-6 1
RP-8 1
EDR-2XL
Item Qty
RP-2X 1
RP-6XL 1
RP-8XL 1
Features
Corrosion resistant
Quick and easy installation
Optional Construction
EDR-2XL-SS
Item Alloy Qty
RP-2X-SS
RP-6XL-SS
RP-8XL-SS
Stainless Steel
304
Stainless Steel
304
Stainless Steel
304
Packaging
Item# Box Qty
GE1015 100
GE1042 100
1
1
1
Elgen Manufacturing
10 Railroad Ave, Closter NJ 07624
Tel: 800.503.9805 :: Fax: 201.964.9030
info@elgenmfg.com :: www.elgenmfg.com
ALL STATED SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION
Guarantee
All Elgen products are guaranteed by Elgen Manufacturing
against defective material.
DIAL REGULATOR (RP-2X)
Product Data Sheet
Description
Elgen’s Dial Regulator is used conjunction with
damper blade for controlling the damper inside
the ductwork.
Standard Construction
Handle is stamped from 19 GA ASTM A-653
Galvanized Steel
Base is stamped from 19 GA ASTM A-653
Galvanized Steel
Bolt and wing nut are Grade 2 zinc plated.
Features
Corrosion resistant
Heavy gauge zinc plated steel regulators for
low leakage applications
Require only a twist of a wing nut for easy
tightening and adjustments
Dial shows damper position
Optional Construction
Stainless Steel 304
Packaging
Item# Box Qty
GE1022 100
Elgen Manufacturing
10 Railroad Ave, Closter NJ 07624
Tel: 800.503.9805 :: Fax: 201.964.9030
info@elgenmfg.com :: www.elgenmfg.com
ALL STATED SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION
Guarantee
All Elgen products are guaranteed by Elgen
Manufacturing against defective material.
SPRING END BEARINGS
Product Data Sheet
Description
Elgen’s Spring End Bearing is used conjunction
with damper blade or controlling the
damper inside the ductwork.
Standard Construction
Manufactured from Zinc Plated carbon steel
Item
RP-6 1/4 5/8 3/8 1/2 1/2 7/8 1-1/8 2-1/2
RP-6XL 1/4 5/8 3/8 1/2 1/2 7/8 1-1/8 4
RP-7 3/8 7/8 7/16 3/4 5/8 1-3/16 1-7/16 2-1/2
RP-7XL 3/8 7/8 7/16 3/4 5/8 1-3/16 1-7/16 4
A
(In)B(in)C(in)D(in)E(in)F(in)
G
(in)L(in)
Features
Corrosion resistant
The spring enables easy installation
Packaging
Item# Box Qty
GE1031 100
GE1007 100
GE1032 100
GE1008 100
Guarantee
Elgen Manufacturing
10 Railroad Ave, Closter NJ 07624
Tel: 800.503.9805 :: Fax: 201.964.9030
info@elgenmfg.com :: www.elgenmfg.com
ALL STATED SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION
All Elgen products are guaranteed by Elgen
Manufacturing against defective material.
