Elfa CRSL606 User Manual
Ceramic Cooktop Model : CRSL606
User Manual
Working Principle
The microcomputer ceramic cooktop directly employs
resistance wire heating, and realizes power regulation with the microcomputer
controlling different heating time and closing time of the resistance wire.
High temperature protection
The temperature sensor mounted on the radiant electric the temperature
inside the cooktop from time to time. When an excessive temperature is
detected, the cooking plate will be directly disconnected and stop power
output.
Safety
Product Introduction
The microcomputer ceramic cooktop can meet dif ferent
kinds of cuisine demands because of resistance wire heating, microcomputerized control and multi-power selection, really the optimal choice
for modern families.
The ceramic cooker cooktop centers on customers and adopts personalized
design.The cooktop has safe and reliable performances, making your life
comfortable and enabling you to fully enjoy the pleasures from life.
2
3
Safety
Residual heat indicators
After using the cooktop, waste heat remains in the heating area. The
power nixie tube shows the code “H”, warning to be away from the
heating area.
Auto shut down protection
During the cooktop working, it shut off automatically when the default
timing reach by the program if without operating. If several heating
zones work simultaneously, the cooktop will be automatically shut of f when
anyone heating area reaches it’s default timer. The default working
timer for various power levels are shown in the table below:
Installation
Selection of installation equipment
Drill holes on the table surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 50 mm space shall
be preserved around the hole.
Be sure the thickness of the table surface is at least 30mm. Please select
heat-resistant table material to avoid larger deformation caused by the heat
radiation from the cooktop.
As shown in Figure (1)
Power level 1 2 3 4 5 6 7 8 9
Default working
time(hour)
8 8 8 4 4 4 2 2 2
50mm mini
50mm mini
50mm mini
50mm mini
560mm
490mm
