ZLX Powered Loudspeaker Series
ZLX-12BT-US, ZLX-15BT-US,
ZLX-12BT-EU, ZLX-15BT-EU
en
Installation manual
ZLX Powered Loudspeaker Series Table of contents | en 3
Table of contents
1
1.1 Important safety instructions 4
1.2 Suspension 5
1.3 FCC Information 5
1.4 Precautions 6
1.5 Certifications 7
1.6 Notices 7
2
2.1 System features 9
2.2 Quick setup 9
2.3 Quick setup – wireless streaming 10
3
3.1 Tripod or pole mount 12
3.2 Floor monitor 13
4
4.1 Amplifier DSP controls 15
4.2 System status 16
4.3 DSP controls 18
4.3.1 DSP control menu 18
5
5.1 Daisy-chaining full-range systems 24
5.2 MP3 player MONO configuration 25
5.3 Using full-range systems as monitors 26
5.4 Stacking full-range systems with subwoofers 27
5.5 Wireless audio STEREO configuration 28
6
7
7.1 Dimensions 33
7.2 Frequency response 33
Safety 4
Description 9
Tripod, pole mount, and floor monitor operation 12
Amplifier DSP 15
Recommended configuration 24
Troubleshooting 29
Technical data 32
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
4 en | Safety ZLX Powered Loudspeaker Series
!
1 Safety
1.1 Important safety instructions
The lightning flash with arrowhead
symbol, within an equilateral triangle is
intended to alert the user to the
WARNING: TO REDUCE THE RISK OF
FIRE OR ELECTRIC SHOCK, DO NOT
OVEREXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE
AVIS: RISQUE DE CHOC ELECTRIQUE,
NE PAS OUVRIR.
WARNING: THE MAINS PLUG OR AC
INLET IS USED AS A DISCONNECT
DEVICE. THE DISCONNECT DEVICE
SHALL REMAIN READILY OPERABLE.
WARNING: CONNECT ONLY TO MAINS
SOCKET WITH PROTECTIVE EARTHING
CONNECTION.
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK) AS THERE ARE NO
USER-SERVICABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
PERSONNEL.
presence of uninsulated “dangerous
voltage” within the product’s enclosure
that may be sufficient magnitude to
constitute a risk of electric shock to
persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
The asterisk within an equilateral
triangle is intended to inform the user to
necessary installation or removal
instructions regarding equipment or
hardware use relating to the system.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong is provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of
the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug the apparatus during lightning storms or when unused for long periods of time.
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Safety | en 5
!
!
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
15. No naked flame sources, such as lighted candles, should be placed on the apparatus.
16. To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture. The apparatus should not be exposed to dripping or splashing. Objects filled
with liquids, such as vases should not be placed on apparatus.
17. Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
18. Minimum 60 cm (2 ft) distances around the apparatus for sufficient ventilation.
19. The ventilation should not be impeded by covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
20. To completely disconnect AC power from this apparatus, the power supply cord must be
unplugged.
1.2 Suspension
Warning!
Suspending any object is potentially dangerous and should only be attempted by individuals
who have a thorough knowledge of the techniques and regulations of suspending objects
overhead. Electro-Voice strongly recommends all loudspeakers be suspended taking into
account all current national, federal, state, and local laws and regulations. It is the
responsibility of the installer to ensure all loudspeakers are safely installed in accordance
with all such requirements. When loudspeakers are suspended, Electro-Voice strongly
recommends the system be inspected at least once per year or as laws and regulations
require. If any sign of weakness or damage is detected, remedial action should be taken
immediately. The user is responsible for making sure the wall, ceiling, or structure is capable
of supporting all objects suspended overhead. Any hardware used to suspend a loudspeaker
not associated with Electro-Voice is the responsibility of others.
Warning!
Do not suspend this product in any other manner than explicitly described in this manual, or
Electro-Voice installation guides. Suspending any object (loudspeaker) is potentially
dangerous and should only be done by individuals with thorough knowledge of techniques,
materials, and regulations for suspending objects overhead. Electro-Voice loudspeakers can
only be suspended using accessories and hardware described in Electro-Voice manuals and
installation guides. Do NOT use handles to suspend the loudspeaker. Handles on Electro-
Voice loudspeakers are intended to only be used for temporary transport by people. Items,
such as fiber rope, wire rope, cables, or other types of materials cannot be used to
suspend loudspeaker from the handles. Any hardware used to suspend a loudspeaker not
associated with Electro-Voice is the responsibility of others.
1.3 FCC Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
6 en | Safety ZLX Powered Loudspeaker Series
!
Notice!
This product has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This product generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this product does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Please take attention that changes or modification not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain
de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité
nécessaire à l'établissement d'une communication satisfaisante.
1.4 Precautions
If an Electro-Voice loudspeaker is used outdoors on a sunny day, place the
loudspeaker in a shaded or covered area. The loudspeaker amplifiers have
protection circuits that temporarily shut the loudspeaker off when extremely
high temperatures are reached. This can happen on hot days when the
loudspeaker is in direct sunlight.
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Safety | en 7
!
!
!
Do not use Electro-Voice loudspeakers in an environment where temperatures
are below 0°C (32°F) or exceed +35°C (95°F).
Never expose an Electro-Voice loudspeaker to rain, water, or high moisture.
Electro-Voice loudspeakers are easily capable of generating sound pressure
levels sufficient to cause permanent hearing damage to anyone within normal
coverage distance. Caution should be taken to avoid prolonged exposure to
sound pressure levels exceeding 90 dB.
1.5 Certifications
1.6 Notices
Old electrical and electronic appliances
Electrical or electronic devices that are no longer serviceable must be collected separately and
sent for environmentally compatible recycling (in accordance with the European Waste
Electrical and Electronic Equipment Directive).
To dispose of old electrical or electronic devices, you should use the return and collection
systems put in place in the country concerned.
Copyright and disclaimer
All rights reserved. No part of this document may be reproduced or transmitted in any form by
any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of the publisher. For information on getting permission for reprints and
excerpts, contact Electro-Voice.
All content including specifications, data, and illustrations in this manual are subject to change
without prior notice.
Notice!
Bluetooth® is available in select countries.
Contact your nearest Electro-Voice dealer or Electro-Voice distributor for more information.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by Bosch Security Systems, Inc. is under license. Other trademarks
and trade names are those of their respective owners.
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
8 en | Safety ZLX Powered Loudspeaker Series
For use in China: CHINA ROHS DISCLOSURE TABLE
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Description | en 9
2 Description
Thank you for choosing an Electro-Voice powered loudspeaker system. Please take time to
consult the manual to understand all the features built into your EV system and fully utilize its
performance capabilities.
NOW STREAMING: Cut through the competition with Bluetooth® enhanced ZLX portable
loudspeakers
ZLX portable loudspeakers offer the best performance and reliability in their class - with
components and engineering that work together to make it quicker and easier than ever to
take control of your sound, whatever the gig. Now with Bluetooth® enabled wireless audio
streaming, legendary ZLX performance becomes even more convenient with the ability to
connect to any mobile device for streaming your music library.
Featuring custom drivers housed in an innovative cabinet design, the two new wireless,
compact, and versatile ZLX models make EV's renowned sound quality and rugged reliability
more accessible than ever before.
Bluetooth® is available in select countries.
2.1 System features
ZLX-12BT and ZLX-15BT—Powered Loudspeaker Systems
The only loudspeaker in its class that matches EV-engineered drivers with a custom-built
Class-D amplifier module and powerful DSP. Whether pole-mounted or used as a floor
monitor, ZLX delivers stunning sonic impact and intelligibility—the legendary “EV Sound” the
pros trust.
– High-quality Bluetooth® audio streaming for background music or musical
accompaniment. Bluetooth® connectivity is available in select countries.
– QuickSmartDSP features best-in-class processing. Easy setup via four presets, sub/top
system-match, two-band EQ, five user-programmable presets, visual monitoring of limiter
status, input level control and meters, and master volume control to optimize gain
structure, all via LCD.
– High-efficiency 1000 W Class-D power amplifier delivers us to 127 dB peak SPL utilizing
transducers designed and engineered by EV.
– EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise
and consistent coverage, minimal distortion, and maximized acoustical loading.
– Three optimally located handles combined with a rugged composite structure provides
the most portable professional sound speaker on the market.
2.2 Quick setup
The ZLX series loudspeakers from Electro-Voice are fully integrated audio systems with
carefully matched electronics and transducers. These products make it easy to setup a high
quality sound system quickly with a minimum amount of cables and external electronics.
Full-Range powered loudspeaker
Models: ZLX-12BT and ZLX-15BT
To set up a full-range powered loudspeaker, do the following:
Step Illustration
1. Connect the AC power cord from a
grounded line receptacle to the MAINS
IN.
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
10 en | Description ZLX Powered Loudspeaker Series
ZLX
Step Illustration
2. Connect the 3.5 mm mini jack, XLR or
TRS cable from an audio source to AUX
IN, INPUT 1 or INPUT 2.
3. Adjust the input gain to (infinity).
4. Switch POWER to ON.
5. From the DSP home screen, increase the
input gain to the desired signal level.
6. Adjust the MASTER VOL knob to the
desired volume.
See also
– Amplifier DSP controls, page 15
2.3 Quick setup – wireless streaming
Follow these instructions to quickly and correctly pair and tune your system for wireless
streaming from a Bluetooth® enabled mobile device.
To pair the system for wireless streaming, do the following:
1. Using the MASTER VOL knob, turn the output gain LEVEL down to MUTE.
2. Push the MASTER VOL knob.
The DSP Control menu appears.
3. Using the MASTER VOL knob, scroll to STREAMING.
4. Push the MASTER VOL knob to select STREAMING .
The focus moves to the parameters on the right side of the DSP menu.
5. Using the MASTER VOL knob, scroll to PAIRING mode.
6. Push the MASTER VOL knob to select PAIRING.
The setting is saved. The focus returns to the menu items on the left side of the DSP menu.
7. Within 120 seconds, follow the manufacturer’s instructions on your mobile device to pair
with a Bluetooth® device.
The loudspeaker appears as EV ZLX BT on your mobile device.
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Description | en 11
Gain structuring
After pairing your mobile device with the system, you can set the volume for your streaming
device.
To set the volume for your streaming device, do the following:
1. Set the loudspeaker output gain to MUTE.
2. Start playing music from your desired player/source.
3. Increase the volume on your mobile device.
The BT VU meter on the ZLX loudspeaker's LCD responds to the incoming signal.
4. Increase the volume from your device until the BT VU meter is ~75% full.
Take note of the volume slider on your mobile device as well: to prevent clipping, do not go
past this level.
5. Using the MASTER VOL knob, increase the output gain to the desired listening level.
Be mindful of the CLIP and LIMIT notifications.
6. Turn the level down on your mobile device for convenient volume control (optional).
To prevent clipping, do not exceed the level previously observed (~75% BT VU).
See also
– DSP controls, page 18
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
12 en | Tripod, pole mount, and floor monitor operation ZLX Powered Loudspeaker Series
!
!
3 Tripod, pole mount, and floor monitor operation
3.1 Tripod or pole mount
ZLX-12BT and ZLX-15BT loudspeakers mount on a tripod stand or on a pole above a
subwoofer.
Mounting a loudspeaker on a tripod stand
Figure3.1: Full-Range models on a tripod stand
Caution!
Tripod is not evaluated for safety with this loudspeaker. Check the specifications of the
tripod stand to be certain it is capable of supporting the weight of the loudspeaker.
Caution!
Two person lift and placement is recommended for the heavier loudspeakers. Single person
lift and placement of heavier loudspeakers could cause injury.
To mount a loudspeaker on a tripod stand, do the following:
1. Place the tripod stand on a level and stable surface.
– Fully extend the legs on the tripod stand.
– Do not compromise the tripod stands structural integrity by trying to make the stand
taller.
– Do not attempt to suspend more than one loudspeaker on a stand designed for a single
loudspeaker.
2. Using two hands lift the loudspeaker.
3. Set the pole cup located on the bottom of the loudspeaker onto the pole.
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Tripod, pole mount, and floor monitor operation | en 13
!
Mounting a loudspeaker on a pole
Caution!
Two person lift and placement is recommended for the heavier loudspeakers. Single person
lift and placement of heavier loudspeakers could cause injury.
To mount a loudspeaker on a pole, do the following:
1. Place the subwoofer on a level stable surface.
2. Insert the pole into the pole cup on the top of the subwoofer.
3. If you are using a threaded pole mount, turn the pole clockwise to secure the pole to the
subwoofer.
OR
If you are not using a threaded pole mount, continue to the next step.
4. Using two hands lift the loudspeaker.
5. Set the pole cup located on the bottom of the loudspeaker onto the pole.
3.2 Floor monitor
ZLX-12BT and ZLX-15BT loudspeakers may be used as a floor monitor by placing the
loudspeaker on the integral monitor angle.
Setting up as a floor monitor
To set up a loudspeaker as a floor monitor, do the following:
1. Place the loudspeaker on a level and stable surface.
2. Safely route cables to prevent injury to performers, production crew, and audience
members.
Notice!
Secure cables with wire ties or tape whenever possible.
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
14 en | Tripod, pole mount, and floor monitor operation ZLX Powered Loudspeaker Series
60º
OPTIMAL
COVERAGE
90º
OPTIMAL
COVERAGE
Front View Side View
Figure3.2: Optimum coverage in monitor position
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Amplifier DSP | en 15
1
2
5
3
4
8
7
6
ZLX
4 Amplifier DSP
4.1 Amplifier DSP controls
The amplifier has a combination of controls and connectors to ensure the most versatile
loudspeaker system.
Full-Range loudspeaker control and monitoring interface
The full-range loudspeaker DSP control menu selections are available for the ZLX-12BT and
ZLX-15BT.
Figure4.1: Full-Range loudspeaker amplifier panel
1. LCD - DSP control and monitoring interface.
2. MASTER VOL - Adjusts the sound level.
DSP - Scroll through the menu and select the available choices. Push the MASTER VOL
knob to enter the DSP menu.
3. INPUT LEVEL - Level control for adjusting the individual inputs’ level. The 12 o’clock
position is unity gain (no gain or attenuation), the range to the left of zero is for adjusting
line level sources, and the range to the right of zero (0) is for adjusting microphone
levels. LINE and MIC input level control is available for both INPUT 1 and INPUT 2.
4. POWER - AC switch or switching the power ON or OFF. The LCD screen lights up when
the power is turned ON, after approximately 3 seconds.
5. MAINS IN - AC connection is established via an IEC-connector.
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
16 en | Amplifier DSP ZLX Powered Loudspeaker Series
IN1
IN
2
LEVEL 0dB
1
BT
1
2
3
4
5
6
7
S
E
6. INPUT - Balanced input for the connection of signal sources like mixing consoles,
instruments, or microphones. Connections can be established using ¼ inch TRS or XLR
connectors.
7. OUTPUT - XLR output sends the mix of all input signals to another loudspeaker or
subwoofer. INPUT LEVEL controls the signal level to OUTPUT. The MASTER VOL or DSP
control settings do not affect OUTPUT. This is also the output for the BT signal which is
configurable via the MIX OUT setting.
8. AUX IN - 3.5 mm audio jack input for connecting external audio media devices, such as
MP3 players.
4.2 System status
Normal
Figure4.2: Normal system status home screen with Bluetooth® status
1. LEVEL – Indicates the master gain of the system in dB. The range is from mute to +10 dB,
in 1 dB increments.
2. IN1 – VU meter displays the signal level of INPUT 1 into the amplifier INPUT 1 XLR
connector. IN1 and IN2 are independent of each other.
3. IN2 – VU meter displays the signal level of INPUT 2 into the amplifier INPUT 2 XLR
connector. IN1 and IN2 are independent of each other.
4. BT - VU meter displays the signal level of wireless audio input.
5. 1 - Indicates the selected store function number. There are five user defined store
function numbers available.
6. E - Indicates the preset is not saved. When the preset is saved the E is not displayed.
7. S - Audio streaming; the available options are:
OFF - DISABLED
FLASHING - PAIRING MODE (120s)
SOLID - CONNECTED
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
Notice!
Bluetooth® is available in select countries.
Contact your nearest Electro-Voice dealer or Electro-Voice distributor for more information.
System protection
System protection limiters indicate when a system is exceeding recommended usage by
indicating CLIP or LIMIT on the LCD display.
CLIP
Figure4.3: Clipping system status
CLIP indicates the signal to the loudspeaker is too high, resulting in a clipped signal into the
loudspeaker. If CLIP is shown, reduce the input gain knob and/or the signal on the mixer or
source equipment.
ZLX Powered Loudspeaker Series Amplifier DSP | en 17
LIMIT
OR
Figure4.4: Limit system status
LIMIT protects the loudspeaker from short-term peaks which can cause distortion. When
LIMIT is shown small on the screen, the limiter is active but keeps distortion under control.
The large LIMIT indicates the sound is negatively affected. Reducing the output volume
(MASTER VOL) is strongly recommended when the large limit indication is shown.
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
18 en | Amplifier DSP ZLX Powered Loudspeaker Series
4.3 DSP controls
An integrated DSP control menu allows the user to select multiple DSP system settings on the
loudspeaker.
To access the DSP controls menu, do the following:
1. Push the MASTER VOL knob.
The DSP Control menu appears.
2. Using the MASTER VOL knob, scroll through the menu items.
3. Push the MASTER VOL knob to select the menu item you want to modify.
The focus moves to the parameters on the right side of the DSP menu.
4. Using the MASTER VOL knob, scroll through the parameters.
5. Push the MASTER VOL knob to confirm the selected parameter.
The setting is saved. The focus returns to the menu items on the left side of the DSP menu.
6. Repeat steps 2 through 5 to modify additional DSP and system settings.
7. Select EXIT to return to the home screen.
4.3.1 DSP control menu
The full-range loudspeaker DSP control menu selections are available for the ZLX-12BT and
ZLX-15BT loudspeakers.
EXIT
MODE MUSIC (Default)
LOCATION POLE (Default)
LIVE
SPEECH
CLUB
MONITOR
BRACKET
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Amplifier DSP | en 19
SUB OFF (Default)
80Hz
100Hz
120Hz
150Hz
ELX200-12SP
ELX200-18SP
EKX-15SP
EKX-18SP
ELX118P
TREBLE 0 db (Default)
-10 dB to +10 dB
BASS 0 db (Default)
-10 dB to +10 dB
MIX OUT L + R (Default)
R
LED ON (Default)
OFF
LIMIT
DISPLAY LCD DIM ON (Default)
OFF
BRIGHT 5 (Default)
1 to 10
CONTRAST 5 (Default)
1 to 10
STORE EXIT, 1, 2, 3, 4, 5, EXIT
RECALL EXIT, 1, 2, 3, 4, 5, EXIT
STREAMING OFF (Default)
PAIRING
ON
LOCK ON
OFF (Default)
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
20 en | Amplifier DSP ZLX Powered Loudspeaker Series
RESET RESET ARE YOU SURE?
NO (Default)
YES
INFO [PRODUCT NAME]
[FIRMWARE VERSION]
©YYYY ELECTRO-VOICE
EXIT
Tab.4.1: Full-Range Loudspeaker DSP Control Menu
EXIT Menu
The Exit menu is used to return to the home screen.
Notice!
The display returns to the home screen after two minutes of inactivity.
MODE Menu
The Mode menu is used to configure the type of sound the loudspeaker delivers.
Available options for this selection are: MUSIC, LIVE, SPEECH and CLUB.
– MUSIC – is used for recorded music playback and electronic dance music applications.
(Default)
– LIVE – is used for live sound applications.
– SPEECH – is used for spoken word applications.
– CLUB – is used for recorded electronic music playback.
LOCATION Menu
The Location menu is used to optimize the loudspeaker for different boundaries.
Available options for this selection are: POLE, MONITOR and BRACKET.
– POLE – is used when the loudspeaker is placed on a tripod stand or placed on a pole.
(Default)
– MONITOR – is used when the loudspeaker is placed on the angled monitor panel in
monitor position. This setting compensates for the amount of low frequency boost
created by placing the speaker close to the floor.
– BRACKET – is used when the loudspeaker is mounted to the wall using the mounting
bracket (Mounting Bracket accessory sold separately). This setting compensates for the
amount of low frequency boost created by placing the loudspeaker close to the wall.
SUB Menu
The Sub menu is used to select a high pass frequency for use with a subwoofer or a matched
subwoofer.
Available options for this selection are: OFF, 80Hz, 100Hz, 120Hz, 150Hz, ELX200-12SP,
ELX200-18SP, EKX-15SP, EKX-18SP, and ELX118P. The high passes are 24 dB/octave Linkwitz/
Riley crossovers. The 80 Hz, 100 Hz, 120 Hz, and 150 Hz choices are generic high pass settings
for use with other subwoofers. The ELX200-12SP, ELX200-18SP, EKX-15SP, EKX-18SP, and
ELX118P settings are specifically optimized for subwoofers by including delay for best
summation.
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Amplifier DSP | en 21
TREBLE Menu
The Treble menu is used to adjust the high frequency performance of the loudspeaker for
different applications or personal preference. The parameter controls a high shelving filter
that is centered on 6 kHz.
The range is -10 dB to +10 db.
The default is zero (0).
BASS Menu
The Bass menu is used to adjust the low frequency performance of the loudspeaker for
different applications or personal preference. The parameter controls a parametric EQ filter
that is centered on 60 Hz.
The default is zero (0).
MIX OUT Menu
The Mix Out menu is used to select which channel of the BT signal should be output at MIX
OUT and which channel should be delivered by the loudspeaker.
– L+R: The left and right signals of BT are summed. The sum is output at MIX OUT and is
delivered by the loudspeaker. (Default)
– R: Only the right signal of BT is output at MIX OUT. The loudspeaker will deliver only the
left signal.
LED Menu
The LED menu shows power on and indicates limit. Available options for this selection are:
ON, OFF or LIMIT.
– ON – turns the LED on when the power to the loudspeaker is ON. (Default)
– OFF – turns the LED off.
– LIMIT – turns the LED off under normal operation. The LED brief blinking indicates the
limiter is activating. Short-term blinking is not critical because the integrated limiter
keeps distortion under control. Constant lighting of the LED indicates the sound is
negatively affected. If the LED is constantly lit, check the rear LCD for more information.
Reducing the output volume is strongly recommended.
LCD DIM Menu
The LCD Dim menu is used to dim the display when the display is idle for two minutes.
Available options for this selection are: ON or OFF.
The default is ON.
CONTRAST Menu
The Contrast menu is used to increase or decrease the visibility of the LCD screen.
The range is -10 dB to +10 db.
The default is zero (0).
STORE Menu
The Store menu allows you create up to five customized user settings. Available options for
this selection are: EXIT, 1, 2, 3, 4, and 5.
Notice!
The customized user setting name can contain a combination of alphanumeric characters
including spaces. The alphanumeric character range is A to Z and 0-9.
The name field length is 12 characters.
To store customized user settings, do the following:
1. From the DSP menu, scroll to STORE.
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
22 en | Amplifier DSP ZLX Powered Loudspeaker Series
2. Push the MASTER VOL knob to select STORE.
The store screen appears.
3. Push the MASTER VOL knob to select 1.
The Enter name for 1 screen appears.
4. Use the MASTER VOL knob to scroll through the characters.
The characters appear.
5. Push the MASTER VOL knob to select the desired character.
6. Turn the MASTER VOL knob to move to the next character entry.
Continue selecting characters until the desired name is entered.
7. Use the MASTER VOL knob to scroll to SAVE.
8. Push the MASTER VOL knob to select SAVE.
9. Repeat steps 3 through 8 to store additional customized user settings.
10. Select EXIT to return to the home screen.
RECALL Menu
The Recall menu allows you retrieve up to five customized user settings. Available options for
this selection are: EXIT, 1, 2, 3, 4, and 5.
To recall customized user settings, do the following:
1. From the DSP menu, scroll to RECALL.
2. Push the MASTER VOL knob to select RECALL.
The recall screen appears.
3. Push the MASTER VOL knob to select 1.
The selected item is loaded.
4. Select EXIT to return to the home screen.
STREAMING
The Streaming menu is used to stream audio from your Bluetooth® enabled device to the
loudspeaker system. Available options for this selection are: PAIRING, ON or OFF.
The default is OFF.
Paring mode is enabled for 120 seconds.
Pairing the loudspeaker with your Bluetooth® enabled device
To pair the loudspeaker with your Bluetooth® enabled device, do the following:
1. From the DSP menu, scroll to STREAMING.
2. Select PAIRING.
PAIRING mode enables 120 seconds of visibility to Bluetooth® enabled devices.
3. On your mobile device, select EV ZLX BT to initiate the pairing process.
Once the device is paired, all device audio will be output through the ZLX loudspeaker.
LOCK Menu
The Lock menu is designed to prevent users from inadvertently changing settings. Available
options for this selection are: ON or OFF.
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Amplifier DSP | en 23
The default is OFF.
RESET Menu
The Reset menu is used to reset the loudspeaker to original factory settings. Available options
for this selection are: NO or YES.
The default is NO.
To reset the system to original factory settings, do the following:
1. From the DSP menu, select RESET.
The reset are you sure message appears.
2. Select YES.
The loudspeaker restarts and resets the system to the original factory settings.
Notice!
Performing a reset erases the user customized settings saved under the STORE menu.
The five user customized settings in the STORE and RECALL menus return to <EMPTY>.
INFO Menu
The Information menu is used to display the product name and firmware version.
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
24 en | Recommended configuration ZLX Powered Loudspeaker Series
ZLX
ZLX
5 Recommended configuration
5.1 Daisy-chaining full-range systems
LINE and MIC input level control is available for both INPUT 1 and INPUT 2. The 12 o’clock
position is unity gain (no gain or attenuation) and the range to the right of zero (0) is for
adjusting microphone levels.
Notice!
The direction of the arrow indicates the signal path.
Mode: Speech
Location: Pole
Sub: Off
Tab.5.2: DSP settings loudspeaker on a tripod
See also
– Tripod or pole mount, page 12
– Amplifier DSP, page 15
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Recommended configuration | en 25
ZLX
ZLX
5.2 MP3 player MONO configuration
Notice!
The direction of the arrow indicates the signal path.
Mode: Music
Location: Pole
Sub: Off
Tab.5.3: DSP settings loudspeaker on a tripod
See also
– Tripod or pole mount, page 12
– Amplifier DSP, page 15
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
26 en | Recommended configuration ZLX Powered Loudspeaker Series
ZLX
ZLX
5.3 Using full-range systems as monitors
LINE and MIC input level control is available for both INPUT 1 and INPUT 2. The 12 o’clock
position is unity gain (no gain or attenuation) and the range to the right of zero (0) is for
adjusting microphone levels.
Notice!
The direction of the arrow indicates the signal path.
Mode: Live
Location: Monitor
Sub: Off
Tab.5.4: DSP settings loudspeakers as monitors
See also
– Floor monitor, page 13
– Amplifier DSP, page 15
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Recommended configuration | en 27
ZLX-12 BT
ELX200-18 SP
MASTER VOL INPUT1
INPUT2
OUTPUT1 OUTPUT 2
PUSHFORDSP
WARNING: ,TOREDUCERISKOFSHOC K D O NOT
.EXPOSETHISAPPLIANCETORAI N OR MOISTUR E
CAUTION
RISK OF ELECTRIC SHOCK
DO NO
T OPEN
RISQUE DE CHOC ELECTRIQUE NE
P
AS OUVRIR
AVIS
QuickSmartDSPMONITOR|
ELX200
MASTER VOL INPUT1
INPUT2
OUTPUT1 OUTPUT
2
PUSHFORDSP
WARNING: ,TOREDUCERISKOFSHOC K D O NOT
.EXPOSETHISAPPLIANCETORAI N OR MOISTUR E
CAUTION
RISK OF ELECTRIC SHOCK
DO NO
T OPEN
RISQUE DE CHOC ELECTRIQUE NE
P
AS OUVRIR
AVIS
QuickSmartDSPMONITOR|
ELX200
ZLX
ZLX
5.4 Stacking full-range systems with subwoofers
Notice!
The direction of the arrow indicates the signal path.
ZLX-12BT
Mode: Live
Location: Pole
Sub: ELX200-18SP
ELX200-18SP
Mode: Live
Location: Pole
Low Pass: ZLX-12BT
Tab.5.5: DSP settings loudspeaker and subwoofer stacked
See also
– Tripod or pole mount, page 12
– Amplifier DSP, page 15
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
28 en | Recommended configuration ZLX Powered Loudspeaker Series
R
L
ZLX
ZLX
5.5 Wireless audio STEREO configuration
Wireless audio streaming via Bluetooth® is available for ZLX-12BT and ZLX-15BT loudspeakers.
Bluetooth® is available in select countries.
R Right
L Left
Notice!
The direction of the arrow indicates the signal path.
Mode: Music
Mix Out: R
BT Audio: On
Tab.5.6: DSP settings wireless audio streaming
See also
– Amplifier DSP, page 15
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Troubleshooting | en 29
6 Troubleshooting
Problem Possible Cause(s) Action
1. No sound Amplifier Verify all the electronics are on, the signal routing is
correct, the source is active; the volume is turned up,
etc.
Correct/repair/replace as necessary. If there is still no
sound, then the problem may be wiring.
Wiring Verify you have connected the correct cables to the
amplifier. Play something at a low level through the
amplifier. Connect a test loudspeaker in parallel with the
malfunctioning line. If the sound level is gone or is very
weak, the line has a short in it (possibly a severe scrape,
pinch, or a missed connection). Using the test
loudspeaker, move down the line and test each
connection/junction until you find the problem and
correct it. Observe proper polarity.
2. Poor Low-
Frequency
Response
3. Intermittent output
such as cracking or
distortion
4. Constant noise
such as buzzing,
hissing or humming
5. No sound produced
with microphone
connected to INPUT
1 or INPUT 2
With SUB menu
cross-over frequency
activated
Faulty connection Check all connections at amplifier and loudspeakers to
Defective source or
other electronic
device
Poor system
grounding or ground
loop
Input gain knob is
not in the MIC
position
Microphone requires
phantom power.
If no subwoofers are used with the system, select the
OFF position.
ensure they are all clean and tight. If the problem
persists, check the wiring. See problem 1.
If noise is present, but no program material is playing,
evaluate each component as necessary to isolate the
problem. Most likely there is a break in the signal path.
Check and correct the system grounding, as required.
Slowly increase the input gain knob level to engage the
microphone pre-amp.
Use a dynamic microphone that does not require
phantom power. If using a microphone requiring
phantom power, an external phantom power source is
needed.
Input gain knob is
not in the MIC
position
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
Slowly increase the input gain knob level to engage the
microphone pre-amp.
30 en | Troubleshooting ZLX Powered Loudspeaker Series
Problem Possible Cause(s) Action
6. Sound is distorted
Excessive input level Reduce the input level or loudspeaker level knobs to
front LED is OFF,
LCD screen LIMIT is
ON
Incorrect gain
structure or source
input (mixing
console/preamp) is
overdriven
7. Microphone
produces acoustic
Incorrect gain
structure
feedback when
input level is
amplified
MODE is set to
MUSIC
Microphone position
is too close to the
front of the
loudspeaker
8. DSP menu is locked The Menu Lock
function has been
turned on. A lock
symbol displays on
the LCD screen.
prevent limit.
Verify level controls of the source are properly structured
by using the VU meter indicator on the LCD screen. If the
VU meter bar is solid or the system indicates LIMIT, the
input or source level is too high.
Reduce the microphone levels at the mixing console or
input source. If the microphone is connected directly to
the speaker, reduce the input level on the speaker.
Positioning the microphone close to the sound source
increases gain-before-feedback. See problem 6.
Change the MODE to LIVE or SPEECH.
Whenever possible setup the loudspeakers so the
microphone is behind them. If using the loudspeaker in a
monitor position, aim the loudspeaker to the back of the
microphone.
Press and hold the MASTER VOL knob for 5 seconds.
9. No streaming audio STREAMING is set to
OFF
Mobile device is
paired to the wrong
speaker.
Input level is too low While music is playing, turn up the volume on the paired
Output Gain is too
low
Set STREAMING to PAIRING and initiate the Bluetooth®
pairing process on your mobile device.
If you have previously paired to a different Bluetooth®
enabled ZLX loudspeaker, you may be pairing with the
wrong device. Try deleting all saved connections labeled
EV ZLX BT and try the pairing process again.
mobile device. You will see the BT VU Meter receiving
signal. Reduce if you see a CLIP notification.
Increase output gain by setting your LEVEL with the
MASTER VOL knob, paying attention to CLIP and LIMIT
notifications.
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Troubleshooting | en 31
Problem Possible Cause(s) Action
10. Skipping or
stuttering playback
with streaming
audio
Paired mobile device
Move the mobile device closer to the loudspeaker.
is too far away from
the loudspeaker
High amount of
interference in the
use area.
This Bluetooth® enabled loudspeaker occupies the same
operating frequencies as other Bluetooth® devices, as
well as Wi-Fi and other wireless transmissions (like
wireless home phones). If you are experiencing drop-
outs, your speaker may be in an environment that makes
reliable wireless audio difficult. Try to move the
loudspeaker to different locations in the room, and
especially away from 2.4gHz routers and microphone
receivers. If the problem persists, revert back to a wired
connection while at that particular venue.
If these suggestions do not solve your problem, contact your nearest Electro-Voice dealer or
Electro-Voice distributor.
See also
– Amplifier DSP, page 15
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
32 en | Technical data ZLX Powered Loudspeaker Series
7 Technical data
ZLX-12BT
Frequency Response (-3 dB)1: 65 Hz - 18 KHz
Frequency Range (-10 dB): 50 Hz - 20 KHz
Maximum SPL2: 126 dB
Coverage (H x V): 90° x 60°
Power Rating: 1000 W
LF Transducer: EVS-12K, 300 mm (12 in) woofer
HF Transducer: DH-1K
Connectors: (2) XLR/TRS Combo Jack (1) 3.5 mm Input and (1) XLR link
Output
Enclosure: Polypropylene
Grille: 18 Gauge steel with black powder coat
Color: Black
Dimensions (H x W x D): 610 mm x 356 mm x 356 mm
(24 in x 14 in x 14 in )
Net Weight: 15.6 kg (34.3 lb)
Shipping Weight: 19.0 kg (41.8 lb)
Power Consumption3: 100 - 240 V~, 50 - 60 Hz, 0.8 - 0.5 A
1. Full-Space measurement using the MUSIC DSP preset.
2. Maximum SPL is measured at 1 m using broadband pink noise at maximum output.
3. Current rating is specified at 1/8 full output power.
ZLX-15BT
Frequency Response (-3 dB)1: 55 Hz - 18 KHz
Frequency Range (-10 dB): 42 Hz - 20 KHz
Maximum SPL2: 127 dB
Coverage (H x V): 90° x 60°
Power Rating: 1000 W
LF Transducer: EVS-15L, 380 mm (15 in) woofer
HF Transducer: DH-1K
Connectors: (2) XLR/TRS Combo Jack (1) 3.5 mm Input and (1) XLR link
Output
Enclosure: Polypropylene
Grille: 18 Gauge steel with black powder coat
Color: Black
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
ZLX Powered Loudspeaker Series Technical data | en 33
610 mm
[24 in]
356 mm
[14 in]
183 mm
[7 in]
356 mm
[14 in]
43.4°
43.4°
ZLX
383 mm
[15 in]
187 mm
[7 in]
423 mm
[17 in]
43.4°
43.4°
[27 in]
685 mm
ZLX
Dimensions (H x W x D): 685 mm x 426 mm x 383 mm
(27 in x 17 in x 15 in )
Net Weight: 17.3 kg (38.0 lb)
Shipping Weight: 23.0 kg (50.78 lb)
Power Consumption3: 100 - 240 V~, 50 - 60 Hz, 0.8 - 0.5 A
1. Full-Space measurement using the MUSIC DSP preset.
2. Maximum SPL is measured at 1 m using broadband pink noise at maximum output.
3. Current rating is specified at 1/8 full output power.
7.1 Dimensions
Figure7.1: Dimensions ZLX-12BT
Figure7.2: Dimensions ZLX-15BT
7.2 Frequency response
Figure7.3: Frequency response ZLX-12BT
Electro-Voice Installation manual 2018.04 | 01 | F.01U.349.854
34 en | Technical data ZLX Powered Loudspeaker Series
Figure7.4: Frequency response ZLX-15BT
2018.04 | 01 | F.01U.349.854 Installation manual Electro-Voice
Bosch Sicherheitssysteme GmbH
Robert-Bosch-Ring 5
85630 Grasbrunn
Germany
www.boschsecurity.com
© Bosch Sicherheitssysteme GmbH, 2018
Bosch Security Systems, Inc
12000 Portland Avenue South
Burnsville MN 55337
USA
www.electrovoice.com
Loading...
