Electronics TC-1P User Manual
0912941
Primary TIT and CHT Instruments
and
Remote Switches
Operating and Installation Instructions
OII 091294
9/12/94
You must read this manual before installing or operating the instrument. This
manual contains warranty and other information that may affect your decision
to install this product and/or the safety of your aircraft.
(This manual covers 12 instruments and remote switches)
Model:
S/N:
(Supersedes OI 101461, II 121161, II 110361 and II 111361)
(FAA Approved)
Electronics International Inc. ®
2092 N.W. Aloclek #523 Hillsboro OR 97124 (503) 439-8484
Important Installation Information
All steps must be read before installing a probe.
F
1. Leave slack in the cable to allow
for engine movement and vibration.
S.S. Washer.
2. Do Not Overtighten.
Over time, tight wire
wraps will cause the wire
to break.
Hose Clamp.
0720921
E
Male Conn.
3. Both clip rings must be on
the inside of the hose clamp.
The rubber band is used to hold
the washer on during shipping.
4. The tab inside the male connector must be centered (not
bent up or down) to mate properly. Check each connector
before installation. Two drops of oil on the connector will
protect it from corrosion for many years.
5. If you remove a connector, double over the wire
before installing it into a new connector. Each connector must be double crimped very tightly.
6. If connectors have been disconnected several times the female connector may become
loose. If this happens use a pair of needle nose pliers to retighten the female recep-
tacle then mate the connectors.
Important Notice
***** MUST READ *****
If you think it is not important to read this manual, you're wrong! This manual
contains important installation information that may affect the safety of your aircraft, delay your installation or affect the operation of your instrument. You
read this manual prior to installing your instrument. Any deviation from these
installation instructions is the sole responsibility of the installer/pilot and may
render the STC invalid.
Read the Warranty / Agreement. There is information in the Warranty / Agreement that may alter
your decision to install this product. If you do not accept the terms of the Warranty / Agreement, do not
install this product. This product may be returned for a refund. Contact Electronics International inc. for
details.
Check that the instrument make and model marked on the side of the instrument and on the invoice are
correct before starting the installation.
Must
Check that the limit information on this instrument matches the published limits in your aircraft's
P.O.H. or Flight Manual. Also, this information may be listed in the T.C. Data Sheet for your aircraft. Any
AD's and/or STC's may set forth additional limitations on the operation of your engine.
owner's and/or installer's responsibility to determine proper instrument calibration and range markings
for your aircraft.
It is possible for any instrument to fail thereby displaying inaccurate high, low or jumpy readings.
Therefore, you must be able to recognize an instrument failure and you must be proficient in operating your
aircraft safely in spite of an instrument failure. If you do not have this knowledge, contact the FAA or a
local flight instructor for training.
The ability for this product to detect a problem is directly related to the pilots ability to program proper
limits and the pilots interpretation and observation skills.
The pilot must understand the operation of this product before flying the aircraft. Do not allow anyone
to operate the aircraft that does not know the operation of this product. Keep the Operating Manual in the
aircraft at all times.
It is the aircraft
Contents
Warranty --------------------------------------------------------------------------- 2
Operating Instructions: ----------------------------------------------------------- 3
Features ------------------------------------------------------------------------------------------ 3
TIT ------------------------------------------------------------------------------------------------ 4
EGT's --------------------------------------------------------------------------------------------- 6
CHT's -------------------------------------------------------------------------------------------- 7
Installation Instructions: ---------------------------------------------------------- 10
1. Important Information and Initial Check Out ------------------------------------------ 10
2. CHT Probe Installation -------------------------------------------------------------------- 11
3. TIT Probe Installation --------------------------------------------------------------------- 11
4. EGT Probe Installation -------------------------------------------------------------------- 11
5. Route the Extension Cables -------------------------------------------------------------- 12
6. Hook Up Connecting Wires -------------------------------------------------------------- 13
7. Connect and Install the Instrument and/or Remote Switch ------------------------- 13
8. System Ground Test ----------------------------------------------------------------------- 13
Troubleshooting Suggestions ---------------------------------------------------- 14
1. Instrument Check Out --------------------------------------------------------------------- 14
2. Probe Check Out --------------------------------------------------------------------------- 15
3. Extension Cable Check Out -------------------------------------------------------------- 15
Specifications and Operating Features ----------------------------------------- 16
Insturment Wiring Diagrams ---------------------------------------------------- 17
Remote Switch Connected to a Primary TIT Channel ------------------------ 18
Remote Switch Connected to a Primary CHT Channel ----------------------- 19
STC Information ------------------------------------------------------------------ 20
1
Warranty / Agreement
Electronics International Inc. warrants this instrument and system components to be free from defects in
materials and workmanship for a period of one year from the user invoice date. Electronics International Inc. will repair or replace any item under the terms of this Warranty provided the item is returned
to the factory prepaid.
1. This Warranty shall not apply to any product that has been repaired or altered by any person other
than Electronics International Inc., or that has been subjected to misuse, accident, incorrect wiring,
negligence, improper or unprofessional assembly or improper installation by any person. This warranty
does not cover any reimbursement for any persons time for installation, removal, assembly or repair.
Electronics International retains the right to determine the reason or cause for warranty repair.
2. This warranty does not extend to any machine, vehicle, boat, aircraft or any other device to which the
Electronics International Inc. product may be connected, attached, interconnected or used in conjunction
with in any way.
3. The obligation assumed by Electronics International Inc. under this warranty is limited to repair,
replacement or refund of the product, at the sole discretion of Electronics International Inc.
4. Electronics International Inc. is not liable for expenses incurred by the customer or installer due to
factory updates, modifications, improvements, upgrades, changes, or any other alterations to the product
that may affect the form, fit, function or operation of the product.
5. Personal injury or property damage do to misinterpretation or lack of understanding this product is solely the
pilots responsibility. The pilot must understand the operation of this product before flying the aircraft. Do not
allow anyone to operate the aircraft that does not know the operation of this product. Keep the Operating Manual
in the aircraft at all times.
6. E. I. Inc. is not responsible for shipping charges or damages incurred under this Warranty.
7. No representative is authorized to assume any other liability for Electronics International Inc. in
connection with the sale of Electronics International Inc. products.
8. If you do not agree to and accept the terms of this warranty, you may return the product for a
refund.
This Warranty is made only to the original user. THIS WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES OR OBLIGATIONS: EXPRESS OR IMPLIED. MANUFACTURER EXPRESSLY
DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. PURCHASER AGREES THAT IN NO EVENT SHALL MANUFACTURER BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING LOST PROFITS OR LOSS OF USE OR OTHER ECONOMIC LOSS. EXCEPT AS
EXPRESSLY PROVIDED HEREIN, MANUFACTURER DISCLAIMS ALL OTHER LIABILITY
TO PURCHASER OR ANY OTHER PERSON IN CONNECTION WITH THE USE OR PERFORMANCE OF MANUFACTURERS PRODUCTS, INCLUDING SPECIFICALLY LIABILITY IN
TORT.
2
OPERATING INSTRUCTIONS
Features
1. Instruments:
The Electronics International line of primary TIT/CHT instruments offer the following features:
A. Digital Display - The digital display allows you to read absolute temperatures at a glance. It does
not require interpretation of dials or tic marks. In a short period of time you will be come familiar with
the normal operating temperatures of your engine. Abnormal temperatures will be easy to spot. The
digital display is easily viewable in direct sunlight. If the instrument backlight has been permanently
powered up (as recommended), the digital display will be easier to see during low ambient light conditions and at night.
B. Over Temperature Warning Light - Over the digital display is a warning light that will turn on any
time the temperature exceeds the maximum operating temperature limit indicated on the front of the
instrument. Also, there is a control line that may be use to turn on Electronics International's AL-1
remote mounted warning light. During power-up the warning lights will flash. This indicates the light
and over-temp circuitry is operating properly.
C. 1 Degree Resolution - The digital display resolves temperatures to 1 degree. This allows you to
interpret trends quickly. This can be very helpful in diagnosing problems and leaning your engine.
Also, any unit may be ordered to display in degrees F or degrees C.
D. 1/2% Accuracy - Electronics International Instruments are not affected by shake, shock, vibration,
tilt, stick-slip, bearing wear, spring wear, lead resistance, probe resistance, magnetic fields or the many
other factors that plague analog instrument accuracy. All E.I. instruments are temperature compensated
to read cabin temperature when a probe is disconnected. E.I. instruments should never need
recalibration.
E. Flexibility - Electronics International instruments are compatible with any type K ungrounded
probe. Lead resistance does not affect the accuracy of these instruments. You may use any length
extension cable between the unit and the probe without affecting the accuracy of the instrument.
F. Upgradeable - Any single channel TIT and/or CHT unit may be upgraded to a full multi-channel
analyzer by simply adding a Primay Remote Switch to the system. The instruments, remote switches,
extension cables and probes were designed in a modular fashion with slip-on connectors. This means a
remote switch may be added to your existing system by simply mounting it into your instrument panel,
installing the additional wires and probes and plugging it in. You do not have to buy a new system to
upgrade to a full analyzer.
3
2. Primary Remote Switches:
A. Used with a Primary TIT Instrument - A Priamry Remote Switch may be connected to a TIT
channel on any appropriate Electronics International Instrument. This gives the TIT instrument
multi-channel EGT capability. Only the TIT or any EGT cylinder may be displayed on a Primary
TIT instrument. The channel marked "Primary" on the remote switch is used to display TIT.
B. Used with a Primary CHT Instrument - A Primary Remote Switch may be connected to a CHT
channel on any approprate Electronics International Instrument. This gives the CHT instrument
multi-channel CHT capability. Only CHT's may be displayed on a Primary CHT Instrument. The
channel marked "Primary" on the remote switch is used to display the primary CHT cylinder (i.e., if
cylinder number 3 is the primary CHT cylinder for your engine, cylinder 3 will be displayed on the
CHT instrument when the remote switch is set to the channel marked "3" or the channel marked
"Primary").
TITOperating Instructions
Note:
during flight.
When using a Primary Remote Switch, the switch must be left in the "Primary" posistion
TIT
1. Maximum Operation TIT Limit (Red Line):
Do not operate your engine above the Maximum Operating Temperature Limit as indicated on the front
of this instrument. Operating above TIT Red Line can cause turbine housing and component failures,
detonation or preignition (which will destroy engine and turbine components), loss of engine power,
reduced turbocharger and engine life and can cause a fire hazard. It is essential to operate your engine
within its TIT operating limits. Electronics Internationals TIT instruments give you three mechanisms
to detect an over-temperature limit (Red Line) condition.
A. The Large Digital Display gives you a fast and very accurate indication of your current temperature condition. This instrument will display temperatures from ambient to 1999F in 1F
increments. This also allows you to interpret rate and trend information at a glance.
B. This instrument incorporates an Over-Temperature Warning Light. This light will come on any
time the TIT is above the Maximum Operating Temperature Limit as indicated on the front of this
insturment. This light provides the advantage of catching your attention without your having to
scan or interpret the display.
C. This insturment also comes with an External Warning Control Line. This line can be connected
to an external light in a control panel or mounted in front of the pilot. This control line will turn on
the external light any time the TIT exceeds the Maximum Operating Temperature Limit as indicated
on the front of this instrument.
4
