Electrolux WT730 TCW, WTF2, WTF4, WTF4H, WTF3H User Manual

Flight Type Dishwashers

General features

• Electrolux, the leading choice for catering
equipment, introduces its new line of flight type
dishwashers.

• Compact, ergonomic design and cost saving,
combined with perfect washing results, make the
Electrolux flight type dishwasher the best choice

for large canteens, in-flight catering, hospitals,
hotels and marine installations.

• Electrolux appliances have been designed using
a modular approach, allowing them to be
tailored to individual requirements.

2

• All the new machines have well designed
functions making them easier to work with and
creating a pleasant working environment.

• The working environment in the dishwashing
area is improved with low temperatures, low
noise levels and reduced humidity.

• The new flight type dishwashers feature a
double skinned structure with thermal and
acoustic insulation (less than 70dB).

• Electrolux new generation of flight type
dishwashers has been engineered with tried and
tested technology.

3

Reliability

Electrolux flight type dishwashers have
been carefully designed to offer long term
reliability, even in the most arduous
conditions.

Reliability:

• the panels and the inspection doors
have a double skin structure in order to
reduce noise and heat dispersion

• in order to completely avoid any
detergent corrosive action, the tank is
made of AISI 316 stainless steel

• all the main elements are made in AISI 304
stainless steel:

- baring structure

- feet

- internal and external panels

- inspection doors

- washing and rinsing arms

- filter plates and filter boxes

- screws

- side support for dishes

• all electric components, wash and rinse
pumps are tested to guarantee a long
lasting operation of the dishwasher

• Stainless steel washing pumps are
standard on version “A”, optional on “B” &
“C”. As standard, all the units are
equipped with low voltage (24 volt)
control panel to guarantee high safety
standards and long lasting reliability

4

Accessibility

Electrolux flight type dishwashers have
been designed to be extremely accessible
and easy to use.

Accessibility:

• easier maintenance, thanks to the
accessibility from the front and sides of
the machine

• all the main working components are
placed on the front of the machine

• adjustments of the tension of the conveyor
belt can be made from the loading side

• the fingers in the conveyor are easily
replaceable

• electrical and water service connections
can be made from above or below

• the electric control box is clearly
organized and centrally located

• the ESD (Energy Saving Device) and
condenser unit are accessible via the
hinged top

5

Cleanability

The flight type dishwasher has been
specifically engineered to be easily
cleanable both internally and externally.

Internal cleanability:

• final wash & rinse area behind one large
balanced inspection door to allow an easy
access to the washing area

• drying zone with inspection door for
cleaning and removal of fallen items

• washing chamber without internal pipes

• internal screws in the wash chamber do

not project past the nuts

• the loading end is easily accessible for
cleaning and emptying of the large scrap box

• washing arms in stainless steel, easily
removable for daily control and cleaning

• double tank filters (flat and box) are
easily removable

• tank with round corners to make easy
periodical cleaning, avoiding the stagnation
of food remains

• sloping base to convey the dirty water
towards the drain

• optional cleaning ramp available in
loading sections above 700 mm in length

External cleanability:

• smooth external surfaces

• 200 mm height feet enable ease of
cleaning under the machine

• loading area without feet

• the back is completely closed so that the
machine can be placed against the wall

• IPX 5 water protection
