ELECTROLUX PROFESSIONAL
LAVASTOVIGLIE A CAPPOTTINA
HOOD TYPE DISHWASHER
WT65H/WT65M
Code Type Ref. Pagina/
Page
504188 WT65H208U a 2 3 5 7
504189 WT65H240U b 2 3 5 7
504199 WT65H208DU c 2 3 5 7
504200 WT65H240DU d 2 3 5 7
504201 WT65H208RU e 2 3 5 7
504202 WT65H240RU f 2 3 5 7
504203 WT65M208U g 2 3 5 7
504204 WT65M240U h 2 3 5 7
504205 WT65M208DU i 2 3 5 7
504206 WT65M240DU l 2 3 5 7
504207 WT65M208RU m 2 3 5 7
504208 WT65M240RU n 2 3 5 7
504216 WT65H208WS o 2 4 6 7
504217 WT65H240WS p 2 4 6 7
CATALOGO PARTI DI RICAMBIO
SPARE PARTS CATALOGUE
Pagina/ Page Indice/ index
2 Vista generale / Main view
3 Componenti idraulici (non per “o,p”) / Hydraulic components (not for “o,p”)
4 Componenti idraulici (solo per “o,p”) / Hydraulic components (just for “o,p”)
5 Circuito idraulico (non per “o,p”) / Hydraulic circuit (not for “o,p”)
6 Circuito idraulico (solo per “o,p”) / Hydraulic circuit (just for “o,p”)
7 Componenti elettrici / Electrical components
8 - 17 Lista ricambi / Spare parts list
Marchio/ Brand:
Paese/ Country:
Da Ser.Nr./From Ser.nr.: /404....
A
CANADA - USA
Page 1
Ed.2010-12
Doc. Nr.: 6-41 805
101
102
103
109
111
115
133
134
141
137
138
139
140
142
143
144
145
130
131
132
119
113
114
116
150
149
110
136
112
147
148
146
117
118
120
134
135
104
107
108
154
102
155
105
106
107
104
107
104B
152
152
151
151
153
153
121
122
ill. 641805p1
Vista generale / Main view
Da Ser.Nr./From Ser.nr.: /404....
Page 2
Ed.2010-12
Doc. Nr.: 6-41 805
201
203
204
208
219
220
221
222
223
224
225
227
229
226
228
232
231
230
233
234
241
240
239
238
242
243
244
203
202
215
208
216
210
218
211
214
213
212
217
209
239
206
236
205
249
250
251 252 253 254 255
246
247
248
ill. 641005p2_USA
Componenti idraulici (non per “o,p”) / Hydraulic components (not for “o,p”)
Da Ser.Nr./From Ser.nr.: /404....
Page 3
Ed.2006-03
Doc. Nr.: 6-41 805
201a
203a
204a
208a
219a
220a
221a
222a
223a
224a
225a
227a
229a
226a
228a
232a
231a
230a
233a
234a
202a
215a
216a
210a
218a
211a
214a
213a
212a
217a
209a
206a
205a
240a
244a
238a
239a
236a
241a
242a
243a
208a
239a
244a
245a
246a
247a
248a
250a
251a
252a
253a
254a
255a
ill. 641805p3_WS
Componenti idraulici (solo per “o,p”) / Hydraulic components (just for “o,p”)
Da Ser.Nr./From Ser.nr.: /404....
Ed.2007-01
Page 4
Doc. Nr.: 6-41 805
306
306
308
309
314
310
316
305
312
317
315
313
306
306
318
307
305
306
339
338
311
311
305
304
336
337
311
316
335
311
340
306
385
384
383
349
372 373 374 375
327
371
371
302
301
302
371
301
303
352351 340362
350
324
319
320
323
321
322
323
324
328
329
330
332
333
331
331
300
ill. 641005p3_usa
Circuito idraulico (non per “o,p”) / Hydraulic circuit (not for “o,p”)
Da Ser.Nr./From Ser.nr.: /404....
Page 5
Ed.2010-12
Doc. Nr.: 6-41 805
548
527
527
514
515
555
509
508
527
520
524
517
524
524
522
501
572
573
503
519
571
545a
544
545b
545a
543
510
518
529
516
519
519
518
559
558
556
529
562
556
556
557
566
547
516
560
585
583
584
586
502
502
511
526
587
531
554
579
554
590
589
588
549
571
574
595
596
597
598
563
593
594
592
591
552
588
580
581
582
546
546
504
545
505
500
506
545
506
507
525
505
500
Up to Ser.Nr.: 809
504
ill. 641805p6_WS
Circuito idraulico (solo per “o,p”) / Hydraulic circuit (just for “o,p”)
Da Ser.Nr./From Ser.nr.: /404....
Page 6
Ed.2008-11
Doc. Nr.: 6-41 805
430
428
432
434
435
442
429
438
441
439
444
443
* Cablaggio/Wiring hardness: 490
442
431
436
437
446
440
447
445
ill. 641005p4_usa
Componenti elettrici / Electrical components
Da Ser.Nr./From Ser.nr.: /404....
Page 7
Ed.2007-11
Doc. Nr.: 6-41 805
LAVASTOVIGLIE CAPPOTTINA WT65H / WT65M
HOOD TYPE DISHWASHER WT65H / WT65M
Pos. Cod.ric.
Part No.
0L0016 Piede; compl. Foot; compl. Up to Ser. Nr. 712
101
048579 Piede; compl. Foot; compl. c,d,i,l,o,p - From Ser. Nr. 713
101
049743 Pannello laterale sx Side panel, left Not for: o,p
102
0L0792 Pannello laterale sx Side panel, left o,p
102
049742 Pannello laterale dx Side panel, right N ot for: o,p
103
0L0791 Pannello laterale dx Side panel, right o,p
103
104 0L1134 Pannello comandi Control panel Not for: o,p
104 0L1685 Pannello comandi Control panel Not for: o,p
104 0L1136 Pannello comandi Control panel o,p - Up to Ser. Nr.: 810
104 0L1684 Pannello comandi Control panel o,p - From Ser. Nr.: 811
104B 0L0798 Pannello boccia sale Salt container panel o,p - Up to Ser. Nr.: 809
104B 0L1689 Pannello boccia sale Salt container panel o,p - From Ser. Nr.: 810
105 0L0287 Pannello frontale Front panel Up to Ser. nr.: 619
106 0L0013 Pannello comandi Control panel Up to Ser. nr.: 619
107 0L0007 Membrana adesiva Membrane a,b,c,d,e,f - Up to Ser. nr.: 619
107 0L1137 Membrana adesiva Membrane a,b,e,f - From Ser. nr.: 620
107 0L1137 Membrana adesiva Membrane c,d,o,p - From Ser. nr.: 620
107 0L1673 Membrana adesiva Membrane c,d,o,p - From Ser. nr.: 811
107 0L1930 Membrana adesiva Membrane c,d,o,p - From Ser. nr.: 852
107 0L0282 Membrana adesiva Membrane g,h,i,l,m,n - Up to Ser. nr.: 619
107 0L1139 Membrana adesiva Membrane g,h,i,l,m,n
108 0L0606 Asta di bloccaggio Locking rod g,h,i,l,m,n
109 0C1406 Schienale Back a,b,c,d,e,f
109 0L1968 Schienale Back a,b,c,d,e,f - From Ser. Nr.: 852
109 0L1919 Schienale Back a,b,c,d,e,f - From Ser. Nr.: 103
109 0L1399 Schienale Back o,p
109 0L0607 Schienale Back g,h,i,l,m,n - Medical line
110 0L1698 Squadretta; sx Plate; left o,p
110 0L1699 Squadretta; dx Plate; right o,p
110 0L0003 Squadretta; sx Plate; left Not for "o,p"
110 0L1921 Squadretta; sx Plate; left Not for "o,p"
110 0L0004 Squadretta; dx Plate; right Not for "o,p"
110 0L1922 Squadretta; dx Plate; right Not for "o,p"
049578 Leva di sicurezza Lever; safety
111
Descrizione Description Note / Notes
Pagina 2: Vista generale Page 2: Main view ill. 641805p1
Grassetto = variazioni
Bold Print = changes
From Ser. Nr.: 620
Up to Ser. Nr.: 810
From Ser. Nr.: 811
Up to Ser. Nr.: 810
Up to Ser. Nr.: 851
From Ser. nr.: 620
Up to Ser. Nr.: 851
Up to Ser. Nr.: 102
Up to Ser. Nr.: 851
From Ser. Nr.: 852
Up to Ser. Nr.: 851
From Ser. Nr.: 852
Da Ser.Nr./From Ser.nr.: /404....
Page 8
Ed.2010-12
Doc. Nr.: 6-41 805
LAVASTOVIGLIE CAPPOTTINA WT65H / WT65M
HOOD TYPE DISHWASHER WT65H / WT65M
Pos. Cod.ric.
Part No.
049584 Molla per leva Spring; lever
112
049591 Perno per sicurezza Pin; safety
113
049583 Tendimolla Spring stretcher
114
049582 Molla Spring
115
049794 Coperchio Cover
116
049627 Magnete Magnet
117
049761 Boccola Bush
118
049585 Molla; sicurezza Spring; safety
119
0H2562 Dado M6 Nut M6
120
121 0L2463 Fascetta 50-70 Hose clamp 50-70 From Ser. Nr.: 103
122 0L2464 Squadretta di fissaggio Floor fixing bracket From Ser. Nr.: 103
049598 Rotella; maniglia Ro ller; hendle
130
131 049597 Guida; maniglia Guide; handle
132 048635 Perno Pin
133 0L0018 Cappotta Hood Up to ser. nr. 406
133 0L0433 Cappotta Hood a,b,c,d,e,f,o,p
133 0L2123 Cappotta Hood a,b,c,d,e,f,o,p
133 0L0435 Cappotta Hood g,h,i,l,m,n
134 049989 Maniglione; compl. Handle; compl. Up to ser. nr. 527
134 049996 Maniglione; compl. Handle; compl. From ser. nr. 528
134 0L1927 Maniglione; compl. Handle; compl. From ser. Nr.: 852
135 0L0480 Coibentante adesivo Adhesive insulated panel
136 048657 Ruota Wheel
137 048656 Perno; ruota Pin; wheel
138 049846 Filtro piano Filter plate a,b,e,f,g,h,i,l,m,n
138 049846 Filtro piano Filter plate c,d,o,p - Up to Ser. Nr.: 851
139 048252 Filtro; cestello Filter; basket a,b,e,f,g,h,i,l,m,n
139 048252 Filtro; cestello Filter; basket c,d,o,p - Up to Ser. Nr.: 851
140 0L1871 Sensore Sensor
141 049594 Supporto Support
142 049629 Guida cesto; compl. Guide; compl. Up to ser. nr. 527
142 0L0289 Guida cesto; compl. Guide; compl. From ser. nr. 528
142 049629 Guida cesto; compl. Guide; compl. From Ser. nr. 620
143 049502 Tappo; M20X1,5 Plug; M20x1,5
144 048245 Guarnizione Gasket
145 049436 Dado; M20X1,5 Nut; M20x1,5
146 049586 Perno; leva Pin; lever
147 049579 Squadretta Plate
148 048710 Paracolpi; inferiore Shock absorber; lower
0L0100 Vite Screw
149
0L0101 Dado Nut
150
Descrizione Description Note / Notes
Grassetto = variazioni
Bold Print = changes
From Ser. Nr.: 407
Up to Ser. Nr.: 851
From Ser. Nr.: 852
Up to Ser. Nr.: 851
Up to ser. nr. 619
Da Ser.Nr./From Ser.nr.: /404....
Page 9
Ed.2010-12
Doc. Nr.: 6-41 805
LAVASTOVIGLIE CAPPOTTINA WT65H / WT65M
HOOD TYPE DISHWASHER WT65H / WT65M
Pos. Cod.ric.
Part No.
0L0802 Aggancio maschio Male spring latch o,p
151
0L0803 Aggancio femmina Female spring latch o,p
152
0L0801 Distanziale Spacer o,p
153
047604 Misurino sale Salt fannel o,p
154
155 0L0069 Filtro Filter c,d,o,p - From Ser. Nr.: 852
048308 Trappola d'aria Air trap
201
068642 O ring O Ring
202
203 046946 Fascetta 8-12 Hose cl amp 8-12
204 048883 Tubo 5x12 Hose 5x12 Up to Ser. nr.: 006
204 049904 Tubo Hose From Ser. nr.: 007
205 0L0422 Pompa lavaggio; 208-240V Wash pomp; 208-240V 60HZ
048531 Tubo gomma; L=1645 MM Hose
206
046853 Fascetta 68-85 Hos e clamp 68-85
208
049268 Dado; M14X1,5 Nut; M14x1,5
209
0L0558 Manicotto Hose Up to ser. nr.: 443
210
0L0612 Manicotto Hose From ser. nr.: 44 4
210
0L0193 Fascetta 40-60 Hos e clamp 40-60
211
0L0185 O Ring O Ring
212
049596 Ghiera Ring nut Up to Ser. nr.: 425
213
0L0557 Ghiera Ring nut From Ser. nr.: 426
213
049593 O Ring O Ring
214
049595 Tubo; collegamento getti Pipe; jets connection Up to Ser. nr.: 425
215
0L0556 Tubo collegamento getti Pipe; jets connection From Ser. nr.: 426
215
045456 Tubo Hose Up to ser. nr.: 443
216
0L0613 Tubo Hose From ser. nr.: 444
216
049810 Protezione pompa; compl. Pump protection;compl.
217
048242 Manicotto Hose
218
048235 Supporto getti inferiore Jets support; lower
219
048931 Parzializzatore Flow reducer
220
048979 Anello seger C-Clamp
221
048236 Guarnizione Gasket
222
048237 Ghiera Ring nut
223
048401 Mozzo Hub
224
0L0597 Assieme getto lavaggio Washing arm assembly
225
048632 Rondella di fermo Lock washer
226
048716 Getto risciacquo Rinse jet Up to Ser. Nr.: 938
227
0L2095 Getto risciacquo Rinse jet From Ser. Nr.: 939
227
048714 Tappo Plug Up to Ser. Nr.: 938
228
048290 Perno; per getti risciaquo Pin; for rinse jets
229
048231 Tappo Plug
230
048230 Guarnizione Gasket
231
Descrizione Description Note / Notes
Pagina 3: Componenti idraulici Page 3: Hydraulic components ill. 641005p2_USA
Grassetto = variazioni
Bold Print = changes
(not for: o,p)
Da Ser.Nr./From Ser.nr.: /404....
Page 10
Ed.2010-02
Doc. Nr.: 6-41 805
LAVASTOVIGLIE CAPPOTTINA WT65H / WT65M
HOOD TYPE DISHWASHER WT65H / WT65M
Pos. Cod.ric.
Part No.
049600 Supporto scarico Support; drain
232
048229 Guarnizione Gasket
233
049140 Troppo pieno Overflow pipe
234
047555 Tappo Plug
236
049831 Tubo di scarico; per pompa Drain pipe; for drain pump
238
046878 Fascetta 38-50 Hos e clamp 38-50
239
048939 Pompa di scarico Drain pump 60hz Up to ser. nr.: 418
240
0L1131 Pompa scarico Drain pump 60hz Fr om ser. nr.: 419
240
048328 Tubo di scarico Drain pipe
241
048853 Nasello di sfiato Spigot; air relief
242
068642 O Ring O Ring
243
049268 Dado; M14x1,5 Nut; M14x1,5
244
049436 Dado; M20X1,5 Nut; M20x1,5
246
046799 O ring O ring
247
049634 Supporto getti superiore Jets support; upper
248
049849 Tappo ingresso det. Plug inlet det.
249
049560 Tappo Plug
250
049561 Portagomma Hose nipple
251
0L0496 Chiocciola Shell
252
0L0494 Girante Impeller
253
0L0491 Tenuta Shaftsealing
254
049178 Flangia Flange
255
Descrizione Description Note / Notes
Grassetto = variazioni
Bold Print = changes
Pagina 4: Componenti idraulici Page 4: Hydraulic components ill. 641805p3_WS
048308 Trappola d'aria Air trap
201a
202a 068642 O ring O Ring
203a 046946 Fascetta 8-12 Hose clamp 8-12
204a 048883 Tubo 5x12 Hose 5x12 Up to Ser. nr.: 006
204a 049904 Tubo Hose From Ser. nr.: 007
205a 0L0422 Pompa lavaggio; 208/240V Wash pomp; 208/240V 60 Hz
048531 Tubo gomma Hose L=1645 mm
206a
046853 Fascetta 68-85 Hos e clamp 68-85
208a
049268 Dado; M14X1,5 Nut; M14x1,5
209a
0L0612 Manicotto Hose
210a
0L0193 Fascetta 40-60 Hos e clamp 40-60
211a
0L0185 O Ring O Ring
212a
0L0557 Ghiera Ring nut
213a
049593 O Ring O Ring
214a
0L0556 Tubo collegamento getti Pipe; jets connection
215a
0L0613 Tubo Hose
216a
049810 Filtro aspirazione pompa suction pump filter
217a
048242 Manicotto Hose
218a
048235 Supporto getti inferiore Jets support; lower
219a
048931 Parzializzatore Flow reducer
220a
Da Ser.Nr./From Ser.nr.: /404....
Page 11
Ed.2010-02
Doc. Nr.: 6-41 805
LAVASTOVIGLIE CAPPOTTINA WT65H / WT65M
HOOD TYPE DISHWASHER WT65H / WT65M
Pos. Cod.ric.
Part No.
048979 Anello seger C-Clamp
221a
048236 Guarnizione Gasket
222a
048237 Ghiera Ring nut
223a
048401 Mozzo Hub
224a
0L0597 Assieme getto lavaggio Washing arm assembly
225a
048632 Rondella di fermo Lock washer
226a
048716 Getto risciacquo Rinse jet
227a
048714 Tappo Plug
228a
048290 Perno; per getti risciaquo Pin; for rinse jets
229a
048231 Tappo Plug
230a
048230 Guarnizione Gasket
231a
049600 Supporto scarico Support; drain
232a
048229 Guarnizione Gasket
233a
049140 Troppo pieno Overflow pipe
234a
047555 Tappo Plug
236a
0L0806 Tubo di scarico Drain pipe
238a
046878 Fascetta 38-50 Hos e clamp 38-50
239a
0L1131 Pompa di scarico Drain pump 60 Hz
240a
0L0759 Manicotto scarico Drain manifold
241a
0L0210 Raccordo a T T fitting
242a
0L0800 Manicotto scarico Drain manifold
243a
047578 Fascetta 26-38 Hose clamp 26-38
244a
0L0367 Fascetta D=33 Hose clamp D=33
245a
049436 Dado; M20X1,5 Nut; M20x1,5
246a
046799 O ring O ring
247a
0L0812 Supporto getti superiore Jets support; upper
248a
049560 Tappo Plug
250a
049561 Portagomma Hose nipple
251a
0L0496 Chiocciola Shell
252a
0L0494 Girante Impeller
253a
0L0491 Tenuta Shaftsealing
254a
049178 Flangia Flange
255a
Descrizione Description Note / Notes
Grassetto = variazioni
Bold Print = changes
Pagina 5: Circuito idraulico Page 5: Hydraulic circuit ill. 641005p3_usa ( not for:
o,p)
300 049847 Protezione ghiera Guard ring nut
049905 Tubo detergente (bianco) Detergent pipe (white) 2.66 m - a,b,e,f,g,h,m,n
301
0L0481 Tubo brillantante (blu) Rinse aid pipe (blue) 2.66 m - a,b,g,h
302
0L0478 Connessione Connection
303
072393 Tubo gomma Hose L=2100 mm
304
048531 Tubo gomma Hose L=1645 mm
305
048126 Fascetta 13-20 Hos e clamp 13-20
306
048531 Tubo gomma Hose L=1645 mm
307
308 049459 Salto in aria AIR GAP Up to Ser. Nr.: 102
Da Ser.Nr./From Ser.nr.: /404....
Page 12
Ed.2010-12
Doc. Nr.: 6-41 805
LAVASTOVIGLIE CAPPOTTINA WT65H / WT65M
HOOD TYPE DISHWASHER WT65H / WT65M
Pos. Cod.ric.
Part No.
308 0L2435 Salto in aria AIR GAP From Ser. Nr.: 103
049828 Guarnizione Gasket
309
049480 Ghiera Ring nut
310
047578 Fascetta 26-38 Hos e clamp 26-38
311
312 049287 Tubo; D 25, L=430 MM Hose; diam 25
313 0L0347 Boiler Boiler Up to Ser. Nr.: 851
313 0L1951 Boiler Boiler From Ser. Nr.: 852
049460 O ring O Ring
314
048436 Fascetta 226-256 Hose clamp 226-256
315
0L0367 Fascetta Cobra Hose clamp
316
0L0420 Coimbentazione boiler Boyler insulation
317
049599 Tubo Hose
318
049418 Tubo; interno, pompa brill. Hose;internal, rinse aid pump c,d,e,f,i,l,m,n
319
049419 Tubo; interno, pompa det. Hose; internal, detergent pump c,d,i,l
320
0L0506 Pompa peristaltica brillantante Rinse aid pump c,d,e,f,i,l,m,n - Up to ser. nr.
321
0L0697 Pompa peristaltica brillantante Rinse aid pump c,d,e,f,i,l,m,n - From ser. nr. 522
321
0L0507 Pompa peristaltica detergente Detergent pump c,d,i,l - Up to ser. nr. 521
322
0L0704 Pompa peristaltica detergente Detergent pump c,d,i,l - From ser. nr. 522
322
049905 Tubo detergente (bianco) Detergent pipe (white) 2.66 m - c,d,i,l
323
0L0481 Tubo brillantante (blu) Rinse aid pipe (blue) 2.66 m - e,f,m,n
324
049801 Iniettore detergente Inie c tion spigot
327
049260 Condensatore per pompa risc. Rinse aid pump capacitor 6,3 ìF
328
0L0052 Raccordo portagomma Connection From Ser. nr.: 620
329
0L1115 Tubo 12x19,5WRC Hose 12x19,5WRC From Ser. nr.: 620
330
049888 Fascetta Hose clamp From Ser. nr.: 620
331
046799 O Ring O Ring From Ser. nr.: 620
332
049436 Dado M20x1,5 Nut M20x1,5 From Ser. nr.: 620
333
049628 Trapola d'aria;boiler Air trap;boiler
335
0L0365 Raccordo 3 vie; D 27-12 Connection 3 ways; D 27-12
336
049773 Tubo Hose
337
0L0421 Pompa risciacquo Rinse pump Up to ser. nr.: 607
338
0L1098 Pompa risciacquo Rinse pump From ser. nr.: 608
338
339 049540 Tubo; dritto+90 GR, 2,1m Pipe; straight + 90 degr, 2,1m Up to ser. nr.: 527
339 0L0733 Tubo alimentazione Feeding hose From ser. nr.: 528
339 0L1967 Tubo alimentazione Feeding hose From ser. nr.: 852
339 0L1887 Tubo alimentazione Feeding hose From Ser. nr.: 023
340 049201 Guarnizione; D 3/4 Gasket; diam 3/4 Up to Ser. Nr.: 851
340 0L1945 Guarnizione; D 3/4 Gasket; diam 3/4 From ser. nr.: 852
349 049650 Parzializzatore; 10L/min Flow reducer Up to Ser. Nr.: 102
349 0L0170 Parzializzatore; 5.5L/min Flow reducer From Ser. Nr.: 103
350 0L2038 Raccordo 3/4” - 3/4” G Connection 3/4” - 3/4” G From Ser. Nr.: 019
351 068121 Ass.filtro 3/4 G Filter
352 072457 Nipplo ottone 3/4" - 3/4" Brass nipple 3/4" - 3/4"
Descrizione Description Note / Notes
Grassetto = variazioni
Bold Print = changes
521
Up to Ser. Nr.: 851
Up to Ser. nr.: 022
Da Ser.Nr./From Ser.nr.: /404....
Page 13
Ed.2010-12
Doc. Nr.: 6-41 805
LAVASTOVIGLIE CAPPOTTINA WT65H / WT65M
HOOD TYPE DISHWASHER WT65H / WT65M
Pos. Cod.ric.
Part No.
049201 Guarnizione; D 3/4 Gasket; diam 3/4
362
0L0349 Assieme tappo Plug assembly
371
0L0495 Chiocciola Shell Up to ser. nr.: 607
372
0L0492 Girante Impeller Up to ser. nr.: 607
373
0L0489 Tenuta Sharftsealing Up to ser. nr.: 607
374
0L0497 Flangia Flange Up to ser. nr.: 607
375
0L0477 Portagomma Fitting
383
0L0423 Elettrovalvola Electric valve a,c,e,g,i,m - Up to ser.: 429
384
0L0488 Elettrovalvola Electric valve b,d,f,h,l,n - Up to ser.: 429
384
0L0569 Elettrovalvola Electric valve From ser. nr.: 430
384
0L0479 Nipplo ottone 3/4"- 3/8" Brass nipple 3/4"- 3/8"
385
500 0L1691 Guarnizione boccia sale Salt container gasket From Ser. Nr.: 810
501 0L0697 Pompa perist. Brillantante Pump; rinse aid
502 049905 Tubo detergente (bianco) Detergent pipe (white)
503 0L0704 Pompa perist. Detergente Pump; detergent
504 0L1694 Boccia Sale + Elettrovalvola Salt container + Solenoid
504 0L1692 Boccia Sale + Elettrovalvola Salt container + Solenoid valve From Ser. Nr.: 810
505 0L1693 Ghiera boccia sale Salt container nut From Ser. Nr.: 810
506 0L0272 Tappo boccia sale Salt container plug
507 0L0749 Tappo contenitore brillantante Rinse aid container plug Up to Ser. Nr.: 809
508 0L1376 Boiler Boiler Up to Ser. Nr.: 851
508 0L1957 Boiler Boiler From Ser. Nr.: 852
509 0L0420 Isolante per boiler Insulation; for boiler
510 048222 Fascetta 210-230/12 Hose clamp 210-230/12
0L1098 Pompa risciacquo 208/240V Ri nse pump 208/240V 60Hz
511
049287 Tubo scarico Drain hose
513
049599 Tubo Hose
514
0L0481 Tubo brillantante (blu) Rinse aid pipe (blue)
515
048531 Tubo 12x19.5 Hose 12x19.5
516
049379 Tubo 11.5x19.5 WRC Hose 11.5x19.5 WRC
517
049287 Tubo 25.5x32 Hose 25.5x32
518
072393 Tubo 4x7.4 Hose 4x7.4
519
0L0786 Tubo 8x12 Hose 8x12
520
046878 Fascetta a vite 35 -50 Hose clamp 35-50
522
048126 Fascetta a vite 13 -20 Hose clamp 13-20
524
525 0L0750 Guarnizione boccia sale Salt container gasket Up to Ser. Nr.: 809
049260 Condensatore per pompa risc. Rinse pump capacitor 6,3 ìF
526
047578 Fascetta 26-38 Hos e clamp 26-38
527
0L0367 Fascetta D=33 Hose clamp D=33
529
049888 Fascetta Hose clamp
531
046799 O Ring O Ring
533
Descrizione Description Note / Notes
Pagina 6: Circuito idraulico Page 6: Hydraulic circuit ill. 641805p6_WS
valve
Grassetto = variazioni
Bold Print = changes
(only for: o,p)
Up to Ser. Nr.: 809
Da Ser.Nr./From Ser.nr.: /404....
Page 14
Ed.2008-09
Doc. Nr.: 6-41 805
LAVASTOVIGLIE CAPPOTTINA WT65H / WT65M
HOOD TYPE DISHWASHER WT65H / WT65M
Pos. Cod.ric.
Part No.
049436 Dado; M20x1,5 Nut; M20x1,5
534
0L0764 Assieme addolcitore Water softener assembly
543
0L0767 Scheda elettronica addolcitore Water softener board
544
0L0765 Elettrovalvola addolcitore Water softener solenoid valve
545a
0L0766 Elettrovalvola addolcitore Water softener solenoid valve
545b
0L1369 Sensore reed addolcitore Water softener reed sensor
546
049801 Iniettore detergente Detergent inje ctor
548
0L0169 Parzializzatore; 5L/min Flow reducer; 5L/min
549
552 072457 Nipplo ottone 3/4" - 3/4" Brass nipple 3/4" - 3/4"
554 049201 Guarnizione; D 3/4 Gasket; diam 3/4 Up to Ser. Nr.: 851
554 0L1945 Guarnizione; D 3/4 Gasket; diam 3/4 From ser. nr.: 852
555 0L0733 Tubo alimentazione Feeding hose Up to Ser. Nr.: 851
555 0L1927 Tubo alimentazione Feeding hose From Ser. Nr.: 852
0L0814 Fascetta D=18 Hose clamp D=18
556
0L0769 Fascetta D=14 Hose clamp D=14
557
0L0770 Fascetta D=8.8-9.3 Hose clamp D=8.8-9.3
558
0L0815 Fascetta D=7.8-8.3 Hose clamp D=7.8-8.3
559
0L1106 Fascetta D=14.4-15.1 Hose clamp D=14.4-15.1
560
0L0771 Fascetta D=11 Hose clamp D=11
562
0L1516 Tubo scarico addolcitore Water softener drain hose
563
0L0083 Fascetta D=9.3-9.9 Hose clamp D=9.3-9.9
566
0L0082 Fascetta D=7.3-7.8 Hose clamp D=7.3-7.8
567
0L0349 Assieme tappo Plug assembly
571
049419 Tubo; interno, pompa detergente Hose; internal, detergent pump
572
049418 Tubo; interno, pompa brillantante Hose;internal, rinse aid pump
573
0L0478 Connessione Connection
574
068121 Assieme filtro 3/4 G Filter assembly 3/4 G
578
049201 Guarnizione D 3/4 Gasket
579
0L0262 Riduzione M.3/4" - F.1/2" Adapter M.3/4" - F.1/2"
580
0L0263 Manicotto F.3/4" Coupling F.3/4"
581
0L0264 Doppia valvola di non ritorno Double check valve
582
0L0752 Guarnizione D=27x40 Gasket D=27x40
583
0L0903 Dado fissaggio addolcitore Water softener fixing nut
584
0L0747 Coperchio Cover
585
0L0799 Raccordo addolcitore Water softener fitting
586
0L1107 Protezione anteriore Front protection
587
0L0477 Portagomma Fitting
588
0L0569 Elettrovalvola Electric valve
589
0L0479 Nipplo ottone 3/4" - 3/8" Brass nipple 3/4" - 3/8
590
048853 Nasello per vasca Spigot; air relief
591
049268 Dado Es. M 14x1.5 Nut; M14x1.5
592
068642 OR 3062; 2.62x15.54 O Ring
593
046946 Fasc. Torro W2 8-12/7.5 IVP Hose clamp 8-12
594
0L0495 Chiocciola Shell
595
0L0492 Girante Impeller
596
Descrizione Description Note / Notes
Grassetto = variazioni
Bold Print = changes
Da Ser.Nr./From Ser.nr.: /404....
Page 15
Ed.2008-05
Doc. Nr.: 6-41 805
LAVASTOVIGLIE CAPPOTTINA WT65H / WT65M
HOOD TYPE DISHWASHER WT65H / WT65M
Pos. Cod.ric.
Part No.
0L0489 Tenuta Sharftsealing
597
0L0497 Flangia Flange
598
0L0540 Trasform. 30VA 180/254V Transform. 30VA 180/254V g,h,i,l,m,n
406
0L0603 Elettromagnete Electromagnet g,h,i,l,m,n
427
0L0425 Resistenza vasca; 208V, 3KW Tank heating element; 208V, 3 kW a,c,e,g,i,m
428
428 0L0427 Resistenza vasca; 240V, 3KW Tank heating element; 240V, 3 kW b,d,f,h,l,n
429 0L0428
429 0L2244
429 0L0429 Resistenza sinistra; 240V, 6KW Left heating element; 240V, 6 kW b,d,f,h,l,n - Up to Ser. Nr.: 102
429 0L2459 Resistenza sinistra; 240V, 6KW Left heating element; 240V, 6 kW b,d,f,h,l,n - From Ser. Nr.: 103
430 048429 Squadretta Bracket
431 0L0484 Resistenza destra; 208V, 6KW
431 0L2245 Resistenza destra; 208V, 6KW
431 0L0485 Resistenza destra; 240V, 6KW Right heating element; 240V, 6 kW b,d,f,h,l,n - Up to Ser. Nr.: 102
431 0L2460 Resistenza destra; 240V, 6KW Right heating element; 240V, 6 kW b,d,f,h,l,n - From Ser. Nr.: 103
432 049620 Pressostato Pressure switch
434 0L0111 Morsettiera Principale Junction box
435 0L0430 Contattore; 208-240 V, 60HZ,
436 049998 Interfaccia utente User interface Up to ser. nr.: 421
436 0L0548 Interfaccia utente User interface From ser. nr.: 422
436 0L0709 Interfaccia utente User interface From ser. nr.: 524
436 0L1240 Interfaccia utente User interface From ser. nr.: 623
436 0L1566 Interfaccia utente User interface From ser. nr.: 743
436 0L1973 Interfaccia utente User interface From Ser. Nr.: 023
437 0L1412 Scheda madre Main board Not for "o,p"
437 0L1811 Scheda madre Main board Not for "o,p"
437 0L1411 Scheda madre Main board o,p - Up to Ser. Nr.: 820
437 0L1812 Scheda madre Main board o,p - From Ser. Nr.: 821
046376 OR 2027 O-Ring 2027
438
049643 Sonda di temperatura Temperature probe
439
0E5993 Fascetta elastica 7,8-8,3 Hose clamp 7,8-8,3
440
0L0280 Premistoppa per termostato Stuffing box
441
0E5037 OR 56.52X5.33 O-Ring
442
046376 OR 2037 O Ring
443
0L0366 Supporto sensore temp. Support; sensor
444
049643 Sonda di temperatura vasca Temperature probe
445
002670 Prolunga pulsante Extension Up to Ser. Nr.: 742
446
0L1568 Copertura interfaccia utente User interface cover From Ser. Nr.: 743
447
Descrizione Description Note / Notes
Pagina 7: Componenti elettrici Page 7: Electrical components ill. 641005p4_usa
Resistenza sinistra; 208V, 6KW
Resistenza sinistra; 208V, 6KW
32A
Left heating element; 208V, 6 kW
Left heating element; 208V, 6 kW
Right heating element; 208V, 6 kW
Right heating element; 208V, 6 kW
Contactor; 208-240 V, 60HZ, 32A
Grassetto = variazioni
Bold Print = changes
a,c,e,g,i,m - Up to Ser. Nr.: 022
a,c,e,g,i,m - From Ser. Nr.: 023
a,c,e,g,i,m
a,c,e,g,i,m
Up to ser. nr.: 523
Up to Ser. nr.: 622
Up to Ser. nr.: 742
Up to Ser. Nr.: 022
Up to Ser. Nr.: 820
From Ser. Nr.: 821
- Up to Ser. Nr.: 022
- From Ser. Nr.: 023
Da Ser.Nr./From Ser.nr.: /404....
Page 16
Ed.2010-12
Doc. Nr.: 6-41 805
LAVASTOVIGLIE CAPPOTTINA WT65H / WT65M
HOOD TYPE DISHWASHER WT65H / WT65M
Pos. Cod.ric.
Part No.
0L0487 Cablaggio Wiring harness Not for: o,p
490
0L1398 Cablaggio Wiring harness o,p
490
0L0605 Cablaggio aggiuntivo Additional wiring harness g,h,i,l,m,n
490
490 0L1400 Cablaggio aggiuntivo Additional wiring harness o,p
Descrizione Description Note / Notes
Grassetto = variazioni
Bold Print = changes
Da Ser.Nr./From Ser.nr.: /404....
Page 17
Ed.2010-12
Doc. Nr.: 6-41 805
Loading...
