INSTRUCTION MANUAL
2 Doors Direct Cool Refrigerator
Thank you for choosing refrigerator.
Please read this manual before operating your refrigerator.
It contains valuable information to help you maximize the use of the refrigerator
and to obtain total satisfaction for years.
2MK-6-P101-156-00-0
Printed : 18 Jan. 2008
FEATURES
1
2
3
4
5
6
7
8
9
WRM2000_A-R
1
2
3
4
5
6
7
8
9
WRM3500_A-R
14
12
13
12
11
10
12
13
12
11
10
1
2
3
4
5
6
7
8
9
WRM2800_A-R
Freezer Compartment
1.
2.
Ice Cube Tray Freezer Shelf
3. Scraper
4.
Temperature Control
5.
6.
Shelf Crisper
7. Evaporation Tray
8.
Adjustable Legs
9.
Bottle Guard
10.
11.
Bottle Locker
12.
Canned Food Rack Egg Rack13.
14.
Utility Rack
14
12
13
12
12
11
10
2
INSTALLATION
1.
Install the unit on a strong and level surface. Leveling can be obtained by using the adjusting screws on the bottom of the unit. For proper performance the front of the refrigerator “Cabinet” should be slightly higher than the back.
2.
Allow at least 30 cm. space above the unit, 15 and 10 cm. at the back and sides to allow air ventilation.
30 cm.
3.
Place the unit away form direct sunlight or heat from stoves.
4.
Place the unit away from sinks and water faucets.
5.
Provide the unit with its own electrical outlet (230V, 60 Hz, single phase AC). Never plug your refrigerator simultaneously with other appliances. Never use multipurpose adapter.
10 cm.
15 cm.
6.
Attach the ground wire (Green/yellow color wire located at the lower left portion at the back of the refrigerator) to any metal pipe or to a cover screw of the wall receptacle or to a rod buried at least 2.4 meters. in the ground.
3
OPERATION
Making a test run
1.
Clean the Refrigerator thoroughly. Wipe the external surface with a soft dry cloth, the interior with a damp cloth.
2.
Keep the door open and plug the power cord into its own electrical outlet.
The interior lamp should lit.
3.
Turn the thermostat dial to “7”. Close the door and allow the unit to operate
for 15-20 minutes. The evaporator should then show some traces of frost. The compressor will run smoothly with just a soft humming sound.
4.
lf the test run is not satisfactory, check your power supply (blown fuse). Contact your appliance dealer or appliance authorized Service Center if the source of trouble cannot be traced.
Temperature Control
You can control the inside temperature by turning the thermostat dial.
Turn the button to the left for warmer temperature.
Turn the button to the right for colder temperature.
Making Ice Cubes
Fill the ice cube tray 3/4-full with cold water and
place it on the bottom of the freezer compartment.
When the ice-cubes are ready they can easily be
removed by simply twisting the both ends of the ice cube tray.
4
