Electrolux VP3 User Manual
ITEM #
MODEL #
Spin Dryers
Vegetable Dryer, 20gal with
basket
Spin Dryers
Vegetable Dryer, 20gal with basket
601560 (VP3)VP3 POL Y SALAD DRYER -
602024 (VP3220)SALAD AND VEGETABLE
20 GAL.
DRYER-20 GAL.-220V
NAME #
SIS #
AIA #
Main Features
•Very flexible machine, it can be placed on various
surfaces and thanks to the built in reservoir, water can
be easily collected. (only for 601560)
•Dries up to 16 heads of lettuce in under 5 minutes without
damaging even the most fagile leaves. (only for 601560)
•Easy to reach control knob with adjustable ON/OFF 5
minute timer. (only for 601560)
•Easy lock castors. (only for 601560)
•Easy to load polyethylene inner basket with handle grips.
(only for 601560)
•Balanced stainless steel driver, easy to remove for
cleaning. (only for 601560)
•Built in water drain reservoir. (only for 601560)
•ETL electrical and sanitation listed. (only for 601560)
•2 year parts warranty, 1 year labor. (only for 601560)
Construction
•Sturdy polyethylene base totally sealed. (only for 601560)
•Polyethylene and lid dimensions:
-Height: 32.5"
-Diameter: 27" (only for 601560)
•Inner line capacity: 20 gal./18 lbs.
-Height: 17"
-Diameter: 15.68" (only for 601560)
•Removable resin basket, 20 gal capacity. (only for
601560)
•Basket rotate at approximately 455 rpm. (only for 601560)
Short Form Specification
Item No.
VP3-Greens Machine Vegetable Dryer, floor model, 20 gallon
capacity approximately 16 heads of chopped lettuce,
adjustable on/off timer, high density polyethylene outer shell,
polyethylene inner liner, casters, 1/4 HP, 115v /60/1, 2.7 amps,
NEMA 5-15P , 8' cord
VP3220-Greens Machine Vegetable Dryer, floor model, 20
gallon, capacity approximately 16 heads of chopped lettuce,
adjustable on/off timer, polyethylene outer shell, polyethylene
inner liner, polyethylene lid, casters, 8' cord, 220v/60/1
APPROV AL:
Included Accessories
•1 of High density polyethylene lid for VP3
vegetable dryer
Optional Accessories
•High density polyethylene lid for VP3
vegetable dryer
•Inner lid for 20gal vegetable dryer (only
for 601560)
PNC 653627
PNC 653627
❑
PNC 653630
❑
Vegetable Dryer, 20gal with basket
Spin Dryers
Electrolux Professional, Inc.
10200 David T aylor Drive, Charlotte, NC 28262 • T elephone Number: 866-449-4200 • Fax Number: 704-547-7 401
www.electroluxusa.com/professional
Spin Dryers
Vegetable Dryer, 20gal with basket
Front
Electric
Supply voltage:
601560 (VP3)115 V /1N ph/60 Hz
602024 (VP3220)220 V /1N ph/50/60 Hz
Electrical power:0.186 kW
Total W atts:0.186 kW
Key Information:
External dimensions, Width:26 9/16" (675 mm)
External dimensions, Depth:26 9/16" (675 mm)
External dimensions, Height:32 1/64" (813 mm)
Shipping width:27 1/ 64" (686 mm)
Shipping depth:27 1/64" (686 mm)
Shipping weight:60 lbs (27 kg)
Shipping volume:13.93 ft³ (0.39 m³)
Top
EI=Electrical connection
Side
Vegetable Dryer, 20gal with basket
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
Spin Dryers
2016.04.13
