Electrolux U02108 EOD 982 User Manual

Model EOD 982
TECHNICAL DETAILS
MODEL NO. EOD 982
Voltage: 230/240 Volts AC 50Hz Wattage: 5.0/5.4kW Height: 897mm Width: 592mm Depth: 563mm
(excluding handles and knobs)
This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC.
2
CONTENTS
Please follow these instructions step by step to install and operate your oven safely and easily.
Technical Details Contents
Safety
Installation Instructions ................................................................7
Getting Things Ready
Making the Electrical Connections
...............................................................................
...................................................................................
Before Installation .................................................................5
During Operation ................................................................. 5
After Use ......................................................................... 6
General ..........................................................................6
Things You Need to Know
Warnings ......................................................................... 7
Things to Note ....................................................................7
Choice of Electrical Connection
Preparing Cabinet for Fitting Oven ................................................. 7
Recommended Cabinet Dimensions ............................................... 8
How to Finish Unpacking .......................................................... 9
Tools Required ................................................................... 9
Preparing Cable
To Remove Cover of Mains Terminal ..............................................9
Connecting to the Mains Terminal ................................................10
Connecting to a Hob or Cooker Point .............................................10
Checking Electrical Connections ..................................................10
.......................................................................
.........................................................
..................................................................
....................................................
.....................................................
..................................................................
2 3
5
7
7 7
9 9
Fitting Into The Cabinet Introduction
Getting to Know Your Oven ......................................................12
Rating Plate .....................................................................13
General Notes on Using The Ovens ..............................................13
About Condensation and Steam ..................................................13
Cookware .......................................................................13
The Cooling Fan for the Controls .................................................13
Control Panel Indicator Neons ....................................................13
Grill and Oven Furniture ..........................................................14
The Oven Timer ....................................................................... 15
The Dual Grill
Uses of the Dual Grill ............................................................17
Selecting the Dual Grill ...........................................................17
Things to Note ...................................................................17
The Grill Pan and Handle .........................................................17
Hints and Tips ...................................................................18
Grilling Chart ....................................................................18
...........................................................................
..........................................................................
...............................................................
11 12
17
3
The Top Oven
Uses of the Top Oven ............................................................19
Selecting the Top Oven ..........................................................19
Things to Note ...................................................................19
To Fit the Top Oven Shelf ........................................................19
Hints and Tips ...................................................................19
The Main Fan Oven ....................................................................21
Uses of the Fan Oven ............................................................21
Selecting the Fan Oven ..........................................................21
Things to Note ...................................................................21
To Fit the Main Oven Shelves ....................................................21
Hints and Tips ...................................................................22
Oven Cooking Chart ...................................................................23
Roasting Chart ........................................................................24
Defrosting .............................................................................25
Uses of Defrost Feature ..........................................................25
Selecting Defrost ................................................................25
Things to Note ...................................................................25
Hints and Tips ...................................................................25
Helpful Hints when Buying and Preparing Food ......................................26
Care and Cleaning .....................................................................27
Cleaning Materials ...............................................................27
Cleaning the Outside of the Appliance ............................................27
Cleaning Inside the Main Oven ...................................................27
Cleaning inside the Top Oven / Grill Compartment ................................27
Cleaning the Grill and Oven Furniture .............................................27
Cleaning Between the Outer and Inner Door Glass ...............................27
Care of Stayclean Surfaces ......................................................28
Hints and Tips ...................................................................29
Replacing the Oven Light Bulb ....................................................29
.........................................................................
19
Something Not Working? .............................................................30
Service and Spare Parts Customer Service Centres Guarantee Conditions
.................................................................
...............................................................
.............................................................
31 32 34
4
SAFETY
THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT YOU UNDERSTAND THEM ALL BEFORE INSTALLING OR USING THE APPLIANCE.
PLEASE READ CAREFULLY
BEFORE INSTALLATION
This appliance is heavy and care
must be taken when moving it.
Ensure that all packaging, both
inside and outside the appliance has been removed before the appliance is used.
DURING OPERATION
Do not use this appliance if it is in contact
with water and never operate it with wet hands.
This appliance is designed to be operated by adults. Young children must not be allowed to tamper with the appliance or play with the controls.
During use the appliance becomes Hot. Care should be taken to avoid touching heating elements inside the oven.
Accessible parts, especially around the grill area, may become hot when the appliance is in use. Children should be kept away until it has cooled.
Take great care when heating fats and oils as they will ignite if they become too hot.
lift
Do Not try to appliance by pulling the door handles. Refer to installation instructions.
The appliance must be installed according to the instructions supplied. Any electrical installation work must be undertaken by a qualified electrician/competent person.
It is dangerous to alter or modify the specifications of the appliance in any way.
Do not allow young children to play with any part of the packaging.
After installation, please dispose of the packaging with due regard to the environment, your local authority can arrange this.
or move the
This appliance has been designed for
cooking edible foodstuffs only, and must
not be used for any other purposes.
Never place plastic or any other material
which may melt in the oven.
Ensure cooking utensils are large enough to contain foods to prevent spillages and boil overs.
Take care to follow the recommendations given for tending the food when grilling. Use the handle provided in the recommended way.
Always use oven gloves to remove and replace food in the oven.
Ensure that you support the grill pan when
it is in the withdrawn or partially withdrawn position.
5
Ensure that all vents are left unobstructed to ensure ventilation of the oven.
You must ensure that the grill control is in the 'OFF' position when the timer control has been set for automatic cooking.
Do not leave utensils containing foodstuffs, e.g. fat or oil in or on the appliance in case it is inadvertently switched ON.
Cookers and hobs become very hot, and retain their heat for a long period of time after use. Children should be kept well away from the appliance until it has cooled.
Ensure that the anti-tilt shelves are put in place correctly. Refer to instructions on pages 19 and 21.
Never line any part of the appliance with aluminium foil. Do not allow heatproof cooking material, e.g. roasting bags, to come into contact with oven elements.
Always stand back from the appliance when opening the oven door to allow any build up of steam or heat to release.
Stand clear when opening the drop down oven door. Do not allow it to fall open - support it using the door handle, until it is fully open.
Never leave the appliance unattended when the oven doors are open.
GENERAL
Under no circumstances should repairs
be carried out by inexperienced persons as this may cause injury or serious malfunction.
This appliance should be serviced by an
authorised Service Engineer and only genuine approved spare parts should be used. Details of servicing and repair arrangements are supplied on page 31 of this book.
Do not stand on the appliance or on the
open oven door.
Do not hang towels, dishcloths or clothes from the appliance or its handle. They are a safety hazard.
Always allow the cooling fan to cool the appliance down before switching off at the wall prior to carrying out any cleaning or maintenance work.
AFTER USE
Do not place sealed cans or aerosols
inside the oven. They may explode if they are heated.
Ensure that all control knobs are in
the OFF position when not in use.
For hygiene and safety reasons this appliance should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan.
Only clean this appliance in accordance with the instructions given in this book.
Your safety is of paramount importance.
Therefore, if you are unsure about any of the meanings of these WARNINGS contact the:
Customer Care Department Telephone: 0870 5 950950
6
INSTALLATION INSTRUCTIONS
THINGS YOU NEED TO KNOW
WARNINGS:
l
This appliance must be installed by a qualified electrician/competent person. Safety may be impaired if installation is not carried out in accordance with these instructions.
l
This appliance must be earthed.
l
Do not remove the screws from the earth tab extending from the oven mains terminal block (Fig. 6).
l
Before connecting the appliance make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This is situated on the lower front frame of the appliance upon opening the main cavity door. Alternatively the rating plate may also be found on the back or top of some models (where applicable).
l
Do not alter the electrical circuitry of this appliance.
THINGS TO NOTE
l
This appliance is designed to be fitted in cabinets of the recommended dimensions as shown (Fig.
2).
GETTING THINGS READY
CHOICE OF ELECTRICAL CONNECTION
l
There are three possible ways to connect your appliance. In each case the appliance should be operated using at least 6mm² twin core and earth PVC insulated multicore cable. Please choose from the most appropriate after reading the different methods:-
a) By connecting the appliance to a cooker point (having a
double pole isolating switch with at least 3mm contact separation in all poles and neutral) and protected with a fuse or miniature circuit breaker at your mains fuse box.
Subject to Regional Electricity Companies regulations if you wish to connect the oven and hob to the power supply you may use one of the following two methods:-
b) By connecting the appliance together with a hob directly
to a cooker point(s). Having a double pole isolating switch with at least 3mm contact separation in all poles and neutral.
c) If you wish to connect an oven and a hob to a cooker
point you can by connecting the oven and hob separately to the cooker point. Oven and hob units should be separately connected to a control panel. See Fig. 1.
l
If your cabinet interior dimension is between 565-570mm the oven may still be fitted. However a minor modification to the cabinet will be required to reduce the aperture size down to 560-565mm. To allow the appliance to be securely screwed into the cabinet.
l
The dimensions given provide adequate air circulation around the unit within the cabinet, ensuring compliance with BS EN60-335.
l
Enquiries regarding the installation of the cooker point, if required, should be made to your Regional Electricity Company to ensure compliance with their regulations.
l
The cooker socket switch should be outside the cabinet but within 2m of the appliance to make it accessible to switch off the appliance in case of an emergency.
l
To protect the hands, wear gloves when lifting the oven into its housing.
NOTE: HOUSE CIRCUIT
Earth leakage and continuity tests must be carried out before the appliance is connected to the mains supply and re-checked after fitting.
Fig. 1
NOTE: It is good practice to:
l
Fit an Earth Leakage Circuit Breaker to your house wiring.
l
Wire your appliance to the latest IEE regulations.
PREPARING CABINET FOR FITTING OF OVEN
l
Make sure the cabinet is the correct size for the appliance to be fitted (Ref. Fig. 2).
l
If the size is between 565-570mm, then the cabinet should be modified so that at the screw fixing points the recommended dimension of at least 560-565mm is maintained. The modification should ideally be localised to ensure that after screw fitment the oven is securely fixed into position.
l
The cabinet must be stable and level by firmly securing it to the wall or floor. If necessary, make arrangements to ensure the shelf upon which the oven will rest is level.
l
When the appliance is installed ensure a minimum gap
of 2mm is maintained between the trim on the bottom edge of the appliance and any corresponding door/ panel underneath.
7
RECOMMENDED CABINET DIMENSIONS (IN MILLIMETRES)
6
0
0
m
i
n
5
6
0
m
i
n
5
5
8
8 7 2
907 min
See Below
5
7
0
m
a
x
n
i
m
0
5
5
d e d n e
m m
o c e
R 0
0 0 2
300 min
6 1
5
Cross section
through
cabinet
showing oven
9
897
872
7 8
- 4 7 8
positioned
9
5
Fig.2 Built In Installation
542
8
HOW TO FINISH UNPACKING
l
Place packed appliance next to the cabinet in which it will be installed.
l
Remove the appliance packing except for bottom tray which should be left in position until the appliance is ready to be fitted into its cabinet.
l
Carefully score down from each end of the cable sheathing along the length of the bare earth wire (if a cut was made along the length of the live or neutral wires, it might cut into their sheathing) to the cuts already made.
l
Carefully prise open the sheathing at each end of the cable to expose the encased wiring.
NOTE: It is imperative that the appliance is left in the base to protect both the appliance and the floor.
l
Ensure the owner is given these operating instructions.
TOOLS REQUIRED
The following tools will be needed and it helps to assemble them before starting to install your oven:
A terminal screwdriver (3mm wide blade) A pozidrive screwdriver Pliers Wirestrippers Knife Sidecutters Adhesive Tape Tape Measure
TO REMOVE COVER OF MAINS TERMINAL
From the rear of the appliance, remove mains input terminal cover to gain access to terminal block.
l
First remove retaining screw with pozidrive screwdriver. See Fig. 3.
Fig.3
MAKE THE ELECTRICAL CONNECTIONS
Important: Switch off at mains, miniature circuit breaker and, if appropriate, remove fuse before commencing any electrical work.
PREPARING CABLE
We recommend you use a new length of cable to ensure your safety.
l
Ensure you have the correct length of cable appropriate to the wiring method you are using. When fitting new cable allow sufficient cable for removal of the unit at a later date, should it be necessary.
l
Score, but do not cut through, around the sheathing with a knife 100mm (4in) from each end of the cable and break through to the encased wires by bending the cable backwards and forwards to fatigue the sheathing.
l
Prise cover loose using screwdriver in position (1) then lever off with screwdriver in position (2) at either side. See Fig. 4.
Fig.4
9
l
Lift cover and remove screw from cable clamp. See Fig. 5.
l
Clamp the mains cable securely ensuring 5mm of the outer insulation is inside the terminal block and that the wires are not taught but not so slack as to cause any fouling. See Fig. 6.
l
Place fuse/ miniature circuit breaker in circuit and switch on at mains.
CONNECTING TO A HOB OR COOKER POINT
WARNING: THIS APPLIANCE MUST BE EARTHED.
l
Either follow in general terms the instructions for connecting to the terminal block or refer to the hob suppliers installation instructions.
Fig.5
CONNECTING TO MAINS TERMINAL
Warning: This appliance must be earthed.
l
Make connection as shown in Fig. 6 by proceeding as follows:-
Fig.6
l
Preform wires to the appropriate shape to suit fitting into the mains terminal block.
Feed the cable through the cabinet and arrange to route the cable away from the appliance which may become hot.
CHECKING ELECTRICAL CONNECTIONS
l
Correct electrical connection can be confirmed when switching on the appliance as the electronic minute minder will be flashing.
NOTE: HOUSE CIRCUIT
Earth leakage and continuity tests must be carried out before the appliance is connected to the mains supply and re-checked after fitting.
l
Strip inner insulation on wires using wirestrippers.
l
Twist the bared wires using pliers.
l
Cut bared wires10mm away from the end of the inner insulation. Where uninsulated Earth wires are used ensure they are suitably sheathed to leave 10mm bare wire to fit into the terminal.
l
Clamp bare wires into the relevant terminal and check they are held by tugging each one in turn.
10
FITTING INTO THE CABINET
IMPORTANT: Ensure that the oven is switched off at the wall before any further work is carried out.
l
Using a tape measure establish the internal width of the cabinet. Refer to page 7 if greater than 565mm.
l
Position the appliance in front of the cabinet. See Fig. 7.
l
Take out all oven furniture before installation to reduce the weight you need to lift. The oven door should be taped up to keep it closed whilst lifting.
l
To place the appliance into the cabinetry follow the procedure below:
l
N.B. Two people will be required to carry out the lifting procedure.
a) Each person should squat either side of the
appliance.
Fig.7
Mains Cable
Pack Base
b) Tilt the appliance so that your hands can support
the underside of the appliance.
Warning: Not attempt to lift this appliance by the handles.
c) Keeping your back straight, raise the appliance to
the cabinet by straightening at the knees.
d) Rest the rear underside of the appliance on the
cabinet floor while your hands support the front.
e) The appliance can be pushed fully into the
cabinet. Take care to avoid damaging the mains lead.
f) Ensure the appliance is central in the cabinet and
level.
g) Do not remove spacers fitted behind fixing
holes.
h) When the appliance is fully housed screw the
stability screws (supplied with the appliance) into the side of the cabinet taking care not to distort the side trims (See Fig. 8). It is advisable to turn each screw alternately to avoid damaging the trims.
Fig.8
i) Switch on the appliance then refer to the
operating instructions in the following pages.
11
Loading...
+ 25 hidden pages
