Electrolux SAL25N04 User Manual

ITEM #

MODEL #

NAME #

Digital Undercounter

Compact Refrigerated Saladette

Table-66 gal (250 lt) 4 Drawer no

SIS #

AIA #

worktop

Main Features

•Suitable for use in ambient temperatures of up to

32 °C.

•Adjustable temperature range from 2 °C to 10 °C

to suit meat, fish and dairy storage requirements.

•Anti-tilt runners accept GN 1/1 containers.

•Digital control panel.

•Forced air circulation for rapid cooling and an even

temperature distribution.

•CFC and HCFC free (ecological refrigerant type:

R134a, - gas in foam: cyclopenthane).

•50 mm insulation for energy saving.

•Automatic evaporation of defrost water.

Prearrangement for drain outlet.

Compact Refrigerated Saladette Table-66 gal (250 lt) 4 Drawer

Digital Undercounter
Compact Refrigerated Saladette

Table-66 gal (250 lt) 4 Drawer no
worktop

728633 (SAL25N04)Compact Refrigerated

Saladette Table - 66 gal (250
lt) 4 1/2 Drawers, no worktop ­230 V/1N/50Hz

Short Form Specification

Item No.

The Electrolux range of refrigerated counters combines the convenience of
worktop space with cold storage located below. This range of counters is
manufactured throughout in Stainless steel to meet the highest hygiene
standards. The model detailed in this sheet is a refrigerated table with four
1/2 drawers, without worktop and is suitable for GN 1/1 trays.

Construction

•Mounted on legs with height adjustment.

•Built-in compressor to suit operating conditions.

•Constructed from AISI 304 Stainless steel

throughout to meet the highest hygiene standards.

•Rounded internal corners for ease of cleaning.

•Access to all components from the front.

•Developed and produced in ISO 9001 and ISO

14001 certified factory.

Optional Accessories

•1/1GN plastic container h=65mmPNC 881038 ❑

APPROVAL:

Digital Undercounter

no worktop

Electrolux Professional

www.electrolux.com/foodservice

[e-mail]

Digital Undercounter

Compact Refrigerated Saladette Table-66

gal (250 lt) 4 Drawer no worktop

Front

Electric

Supply voltage:

728633(SAL25N04)230 V/1N ph/50 Hz

Key Information

Built-in Compressor and Refrigeration Unit
External dimensions, Height810 mm
External dimensions, Width950 mm
External dimensions, Depth700 mm
External dimensions, Weight85 kg
Depth with doors open:1120 mm
Number and type of grids

(included):None GN 1/1

Top

Refrigeration Data

Compressor power:1/4; hp
Refrigerant type:R134a
Refrigeration power:224 W
Refrigerant weight:120 kg

EI=Electrical connection

Side

Compact Refrigerated Saladette Table-66 gal (250 lt) 4 Drawer no worktop

The company reserves the right to make modifications to the products

without prior notice. All information correct at time of printing.

Digital Undercounter

2009.10.26
