Electrolux 726465, RS13DFX2F User Manual

Electrolux Benefit Cabinets

Dual temperature - 1300 lt

The range consists of 1 fan assisted model of 600 litres refrigeration cabinets that offer excellent standards in
terms of performance and efficiency. These models come in fridge/freezer version in 304 AISI and is available
with full doors.

• Internal and external structure in
304 AISI stainless steel, external
base, top and back in galvanized
steel. 150 mm height-adjustable
feet.

• Digital control panel allowing the
easy and precise setting and
control of the internal temperature.

• Completely automatic defrosting
and automatic evaporation of
defrost water.

• High standards of hygiene and
ease of cleaning are guaranteed
by the rounded internal corners of
the cabinet and easily removable
runners and grids (without the use
of tools).

• The refrigeration unit can
operate in tropical climates (+43°C
ambient temperature).

• Excellent forced air cooling
system that ensures the utmost

uniformity of temperature in the
cabinet and guarantees a perfect
storage quality of the goods.

• High-density expanded
polyurethane insulating foam, 60
mm in thickness, with
cyclopenthane injection,
guarantees exceptional, long-term
insulation and notable energy
savings.

• The rational use of the internal
space of the refrigerator
guarantees a large storage area
suitable to contain 2/1 GN grids.

• Self-closing door, positioned in
less than 90°, with a stop at 95°
and a maximum opening at 180°,
equipped with a magnetic door
seal to guarantee perfect closure.

• The pressed stainless steel
recessed door handle without
joints makes opening the cabinet

726465

extremely easy. All the doors are
fitted as standard with locks and
keys and a microswitch to switch
off the fan when the door is
opened.

• Stainless steel feet (plastic
interior).

• A wide range of optional
accessories are available.

• CFC and HCFC free.

726465

Electrolux Benefit CabinetsDual temperature - 1300 lt

RS13DFX2F

726465

LEGEND

EI - Electrical connection 230 V, 1, 50

TECHNICAL DATA

Operating temperature
first compartment - min/max °C -2 / 10
second compartment - min/max °C -22 / -15
Operating mode Ventilated
Gross capacity (D.I.N. 8952) - l. 650, 650
External dimensions - mm
width 1440
depth/with open doors 788, 1440
height 2000
Door hinges 1 Left+1 Right
N° and type of grids (included) 6, GN 2/1
Compressor power - HP 1/5
N° defrost in 24 hrs. 4/20'
Refrigerant type R134a
Refrigerant quantity - g. 130, 300
Refrigeration power - W 752
Power - kW
installed-electric 0.99
Net weight - kg. 250
Power supply - V, phases, Hz 230 V, 1, 50

INCLUDED ACCESSORIES

2 S/S RUNNERS FOR 600-650/1300-1400L.REF 6
2/1 GN GREY "RILSAN" GRID 6

ACCESSORIES

2 S/S RUNNERS FOR 600-650/1300-1400L.REF 881456
2 WHEELS FOR REFRIGERATORS/REFRIG.TABLES 880539
2/1 GN AISI 304 S/S GRID 881067
2/1 GN GREY "RILSAN" GRID 880720
KIT HACCP EKIS 922166
KIT INTEGRATED HACCP-DIG. REFR. (IR33) 880205
MEAT RAIL FOR 650-1400 L REFRIGERATORS 881451
PRINTER FOR HACCP BASIC VERSION REFRIG. 881457

HAEC0202009-10-06Subject to change without notice

Internet: http://www.electrolux.com/foodservice
