Electrolux RH14FE2FEU Parts Diagram

SPARE PARTS CATALOGUE

CATALOGO PARTI DI RICAMBIO

Refrigeration Platform

Smart Control Heavy Duty Range -2 +10,-15 -24 C°

1400 LT Refrigerated and freezer double full door

Armadi congelatori i refrigerati da 1400 LT con porta intera

Code Avv. Model Description Ref Page Brand

110705 16 ADN220E FV 2M TN PC ZAN.304 ELETTR. A 2, 3, 5 Zanussi
728547 15 C14RE2F FV 2M TN PC ELUX.304 ELETTR. B 2, 3, 5 Electrolux
728485 17 E14N0E2C FV 2M TN PC ALPEN 304 ELETTR. C 2, 3, 5 Alpeninox
110706 14 ADF220E FV 2M BT PC ZAN.304 ELETTR. D 2, 4, 5 Zanussi
726548 13 C14FE2F FV 2M BT PC ELUX.304 ELETTR. E 2, 4, 5 Electrolux

728486 19 E14C0E2C FV 2M BT PC ALPEN 304 ELETTR. F 2, 4, 5 Alpeninox

726371 05 RH14RE2FUS FV 2M TN PC ELUX.304 ELETTR. .120/60/USA G 2, 3, 5 Electrolux
726372 05 RH14FE2FUS FV 2M BT PC ELUX.304 ELETTR. .120/60/USA H 2, 4, 5 Electrolux
726493 10 RH14RE2FS 2-DOOR REFR.1400L -2+10°-ECA-SMART I 2, 3, 5 Electrolux
110093 09 ADN220ES 2-DOOR DIG.REF.1400L -2+10°-ECA-ACTIVE L 2, 3, 5 Electrolux
726598 01 RH14RE2FEU 2DOOR REF.1400L-2+10°SMART-E.SAVING-US M 2, 3, 5 Electrolux
726599 01 RH14FE2FEU 2-DR FREEZER 1400L -24-15°SMART-E.SAV-US N 2, 4, 5 Electrolux
726679 00 RH14RE4HU 4 ½-DOOR REFRIGER. 1400L -2+10° SMART-US O 2, 3, 5 Electrolux
726680 00 RH14FE4HU 4 ½-DOOR FREEZER 1400LT -24-15° SMART-US P 2, 3, 5 Electrolux
728503 00 E14N0E2CE 2-DOOR DIG.REFR.(ECA)1400L -2+10°C A304 C 2, 3, 5 Alpeninox
728508 04 E14F0E2CE 2-DR DIG.FREEZER(ECA)1400L -15-24° A304 Q 2, 4, 5 Alpeninox

726495 09 RH14FE2FS 2-DOOR FREEZER 1400L -24-15°-ECA-SMART R 2, 4, 5 Electrolux
110095 07 ADF220ES 2DOOR DIG.FREEZ.1400L -24-15°-ECA-ACTIVE S 2, 4, 5 Zanussi

Note:

Last update (15/07/2008) with up date code 728485-110093-726493-110095-726495
the n°113 main board change code from 099161 to 092023 to add ptc *the main board it is same
change compressor from serial n°81800001 on code 110095-726495 728486-728508
Previus update (12/02/2008) on page 7 - 8 - 4
Previusupdate (27/12/2007) with insertion cooling unit assembly on page 7 and 8
update New evapoartor probe from serial number 5110000.. (please check the parameter map)

Index Indice

Pag. 2 Cabinet and door Armadio e porta

3 Cooling unit assembly +2+10 C° Gruppo refrigerante +2+10 C°
4 Cooling unit assembly -15-24 C° Gruppo refrigerante -15-24 C°
5 Control panel Pannello comandi

6,7,8 Spare parts list Lista ricambi

Up date 15 07 2008

ED. 1

PAGE :1

replacement code VT 1410010 with

Doc. Nr. : 501050

33

1

2

1

4

22

21

18

17

2

5

26

31

17

6

7

25

32

29

32

8

6

9

28

13

11

14

30

20

16

23

10

19

ED. 1

PAGE :2

12

2

24

3

Doc. Nr. : 501050

Cooling unit assembly -2 +10 °C
Gruppo refrigerante -2 +10 °C

72

51

52

58

56

57

67

54

55

71

64

68

66

56

58

53

57

63

59

61

60

50

ED. 1

PAGE :3

62

70

69

Doc. Nr. : 501050

Cooling unit assembly -15 -24 °C
Gruppo refrigerante -15 -24 °C

151

170

171

164

155

154

167

179

168

166

156

158

153

152

180

172

169

159

157

149

173

150

178

71

174

162

163

161

160

176

175

Up date 19 02 2008

ED. 1

PAGE :4

Doc. Nr. : 501050

113

1

2

3

4

5

c

a

t

e

g

o

r

i

%

H

U

M

H

I

G

H

(())

<
<

<<

HA

CC

P

HIS

T

OR

Y

A

CTIVE

FOODS

AFE

CONTR

OL

115

111

104

102

101

103

104

<
<

P

Y

CC

OR

HA

T

HIS

<<

(())

M

%

H

U

G

H

I

H

ri
o
g

e

t
a
c

112

116

ALARM
SERVICE

ALARM
SERVICE

110

114

P

C

C

Y

A

R

H

O

T

IS

H

P

C

C

A

H

P

C

C

Y

A

R

H

O

T
S

I

H

P

C

C

A

H

ACTIVE

106

107

108

109

ED. 1

PAGE :5

Doc. Nr. : 501050

Refrigerators - 1200/1400 lt

PNC Ref. PNC Ref. PNC Ref. PNC Ref. PNC Ref.

110705 A 726493 I 110095 S
726547 B 110093 L
728485 C 726598 M
110706 E 726599 N
728486 F 726679 o

726371 G 726680 P
726372 H 726495 R

Pos. Code Descrizione Description Ref. / Note

Pagina 2 Mobile 2 PC Page 2 Cabinet Two full door

1 087128 Cerniera superiore Upper hinge
1 087788 Cerniera superiore Upper hinge g,h,m,n,o,p
2 082219 Cerniera a tuffo Hinge for door
3 087223 Grglia centrale Central grid i,l,r,s,q
4 0A8053 Serratura porta Lock for door
5 0A9663 Cremagliera ant. Rack-rail until to ser.n° 7380000..
5 091629 Cremagliera ant. Rack-rail from ser.n°73900001
6 083839 Tappo per gancio Plug Hook support
7 0A9680 Guida per ripiano Shelf runner a,b,c,d,e,f,i,l,q,r,s
7 090184 Guida per ripiano Shelf runner g,h,m,n,o,p
8 083635 Griglia Shelf a,b,d,e,f,i,l,q,r,s
8 099994 Griglia Shelf c,g,h,m,n,o,p
9 083838 Aggancio cremagliera Hook

9 090210 Aggancio cremagliera Hook h,g,l,i,m,o,p,s,f,q
10 0A9664 Cremagliera post. Rack-rail until to ser.n° 738000..
10 091630 Cremagliera post. Rack-rail from ser.n°73900001
11 081654 Boccola cerniera Bushing for hinge
12 087127 Staffa inferiore Lower hinge
12 087792 Staffa inferiore Lower hinge h,g,m,n
13 087129 Guarnizione porta Gasket door a,b,c,d,e,f,i,l,q,r,s
13 090186 Guarnizione porta Gasket door g,h,m,n
14 087091 Porta schiumata Zanussi Door Zanussi a,d,l,s
14 085973 Porta schiumata Electrolux Door Electrolux b,e,i,r
14 090187 Porta schiumata Electrolux Door Electrolux g,h,m,n
14 0A9686 Porta schiumata Alpeninox Door Alpeninox c,f,q
16 0A9138 Piedino Foot
17 083837 Aggancio cremagliera Hook
17 090214 Aggancio cremagliera Hook h,g,l,i,m,n,o,p,s,r,q
18 087486 Cruscotto Zanussi Panel Zanussi a,d,l,s
18 087489 Cruscotto Electrolux Panel Electrolux b,e,g,h,i,m,n,o,p,r
18 092032 Cruscotto alpeninox Panel alpeninox c,f,q
19 0A9679 Cavo riscaldante Heating cable a,b,c,i,l,q,r,s,q
19 081170 Cavo riscaldante Heating cable d,e,f,
19 090188 Cavo riscaldante Heating cable g,m,n
19 090189 Cavo riscaldante Heating cable h
19 099867 Cavo riscaldante Heating cable o,p
20 081797 Controdado Nut a,b,c,g,i,l,m,o
21 081823 Piletta Discharge pipe a,b,c,g,i,l,m,o
22 085535 Tappo piletta Plung a,b,c,g,i,l,m,o
23 088982 Piedino elux quadro Foot elux square b.e,i,r
23 090190 Piedino elux quadro Foot elux square g,h,m,n,o,p
24 099862 Staffa inferiore 1\2 Lower hinge 1\2 o,p
25 099863 Staffa centrale Central hinge o,p
26 085985 Cremagliera ant. superiore Upper frontRack-rail o,p
28 085988 Cremagliera ant. inferiore Lower frontRack-rail o,p
29 099864 1\2 porta sup. dx o inf. sx Half door upper right or lower left o,p
30 099865 12\ porta infer.dx o sup. sx Half door lower right or upper left o,p
31 099866 Guarnizione 1\2 porta Half door gasket o,p
32 0A8856 Boccola cerniera Bushing for hinge o,p
33 099860 Griglia protezione Grid protection o,p

* 089808 Cornice verticale Vertical frame a,b,c,d,e,f,l,q,r,s,i
* 099861 Cornice verticale 1\2 porta Vertical frame 1\2 door o,p
* 090191 Cornice verticale Vertical frame g,h,m,n
* 088944 Cornice orrizontale Orrizontal frame a,b,c,d,e,f,i,l,q,r,s
* 090192 Cornice orrizontale Orrizontal frame g,h,m,n,o,p
* 089808 Cornice verticale montante Vertical frame for central supp.

* COMPONET AVAILABLE UPPON REQUEST TO SPLC
* COMPONENTI DISPONIBILI A RICHIESTA PRESSO LO SPLC

ED. 1

PAGE :6

Up date 18 07 2008

Doc. Nr. : 501050

Refrigerators - 1200/1400 lt

PNC Ref. PNC Ref. PNC Ref. PNC Ref. PNC Ref.

110705 A 726493 I 110095 S
726547 B 110093 L
728485 C 726598 M
110706 E 726599 N
728486 F 726679 o

726371 G 726680 P
726372 H 726495 R

Pos. Code Descrizione Description Ref. / Note

Pagina 3 Gruppo -2C° Page 3 Cooling -2C°

50 099763 Basamento Cooling support
51 0A9674 Scambiatore Heat exchanger
52 0A8171 Valvola ricarica Valve
53 083752 Compressore GP12 TB Comprerssor GP12 TB
53 084697 Compressore Comprerssor g,o
54 081756 Relè avviamento Relay a,b,c,i,l
55 083152 Protettore termico Protector for compressor a,b,c,i,l
56 084745 Ventilatore Motor ventilator a,b,c,i,l
56 088423 Ventilatore Motor ventilator g
56 099870 Ventilatore Motor ventilator m,o
57 082230 Ventola Fan a,b,c,i,l
57 085532 Ventola Fan g,m,o
58 089755 Protezione ventola Fan protection
59 0A9669 Condensatore Condenser
60 087480 Sonda condensatore/amb. Probe for condenser/amb.
61 089619 Bacinella raccogli condensa Basin
62 0A9673 Resistenza sbrinamento Defrost heating element a,b,c,i,l
62 090204 Resistenza sbrinamento Defrost heating element g,m,o

63 099659 Sonda evaporatore Probe for evaporator from ser.n°5110000..

64 090194 Tappo fusibile per alta pressione Safety plug for hight pressure g,m
66 0A9671 Termostato ELTH Thermostat a,b,c,i,l
66 090105 Termostato ELTH Thermostat g,m,o
67 0A9672 Evaporatore Evaporator
68 084078 Filtro Filter a,b,c,i,l
68 083854 Filtro Filter g,m,o
69 0KX010 Guarnizione campana Cover gasket
70 099227 Campana Cover
71 081707 Molla per fissaggio resistenza Heating element spring
72 0A8764 Condensatore di spunto Electric start condenser a,b,c,i,l
78 088066 Sonda cella Probe for cell

* 099439 Ass. gruppo refrigerante Complete cooling unit a,l,i,c
* 099376 Ass. gruppo refrigerante Complete cooling unit b
* 858747208 Ass. gruppo refrigerante Complete cooling unit g,m,o

Pagina 4 Gruppo -24C° Page 4 Cooling -24C°

149 092028 Basamento gruppo condensatore Cooling support (condenser)

150 099763 Basamento gruppo evaporatore Cooling support (evaporator)
151 087116 Scambiatore Heat exchanger
151 091951 Scambiatore Heat exchanger d,e,q,r,s,f,q From serial n°81800001
151 * Scambiatore Heat exchanger Art. 845723400- n
152 0A9459 Valvola ricarica Discharge valve Until serial N°817000...
152 085505 Valvola ricarica Discharge valve From serial n°81800001
153 084076 Compressore J2192 GK Comprerssor J2192 GK d,e,q,r,s Until serial N°817000...
153 091950 Compressore Tecu.CAJ2446Z Comprerssor Tecu.CAJ2446Z d,q,r,s,e,f,q From serial n°81800001\
153 090205 Compressore J2192 GK 115/60Hz Comprerssor 115/60Hz h,n,p
154 083448 Relè avviamento Relay d.e.f,q,r,s (J2192 GK)
154 091788 Relè avviamento Relay p,h,n
155 083449 Condensatore di spunto Electric starter condenser d.e.f,q,r,s (J2192 GK)
155 091790 Condensatore di spunto Electric starter condenser p,h,n
156 087168 Ventilatore condensatore Motor ventilator for condenser d,e,f,q,r,s
156 088098 Ventilatore condensatore Motor ventilator for condenser h,n,p
157 084780 Ventola condensatore Fan for condenser d,e,f,q,r,s
157 084781 Ventola condensatore Fan for condenser h,n,p,f
158 0A9728 Protezione ventola cond. Protection fan for condenser
159 087115 Condensatore Condenser

* COMPONET AVAILABLE UPPON REQUEST TO SPLC
* COMPONENTI DISPONIBILI A RICHIESTA PRESSO LO SPLC

ED. 1

PAGE :7

Up date 18 07 2008

Doc. Nr. : 501050

Refrigerators - 1200/1400 lt

PNC Ref. PNC Ref. PNC Ref. PNC Ref. PNC Ref. PNC Ref.

110705 A 726493 I 110095 S 726547 B 110093 L 728485 C
726598 M 110706 E 726599 N 728486 F 726679 o 726371 G
726680 P 726372 H 726495 R

Pos. Code Descrizione Description Ref. / Note

160 087480 Sonda condensatore Probe for condenser
161 089619 Bacinella raccogli condensa Basin
162 0A9673 Resistenza sbrinamento Defrost heating element d,e,f,q,r,s
162 090204 Resistenza sbrinamento Defrost heating element h,n,p

163 099659 Sonda evaporatore Probe for evaporator from ser.n°5110000..

164 091789 Condensatore di marcia Electric run capacitor p,h,n (J2192 GK)
166 0A9671 Termostato ELTH Security thermostat d,e,f,q,r,s
166 090105 Termostato ELTH Security thermostat h,n,p
167 091949 Evaporatore Evaporator q,r,s,f,q
167 0A9672 Evaporatore Evaporator
168 0A9371 Filtro Filter d,e,f,q,r,s
168 083854 Filtro Filter h,n,p
169 0A9377 Corpo valvola Parker Body valve
170 089755 Protezione ventola evap. Fan protection
171 082230 Ventola evaporatore Fan for evaporator d.e.f,q,r,s
171 085532 Ventola evaporatore Fan for evaporator h,n,p
172 085847 Bobina Valve
173 084745 Ventilatore evaporatore Motor ventilator for evaporator d.e.f
173 088423 Ventilatore evaporatore Motor ventilator for evaporator h
173 091196 Ventilatore evaporatore Motor ventilator for evaporator q,s
173 099870 Ventilatore evaporatore Motor ventilator for evaporator n,p
174 087090 Cavo riscaldante Heating cable d.e.f,q,r,s
174 090207 Cavo riscaldante Heating cable h,n,p
175 0KX010 Guarnizione campana Cover gasket
176 099227 Campana Cover
178 088066 Sonda cella Probe for cell
179 090194 Tappo fusibile per alta pressione Safety plug for hight pressure h,n,p

180 085088 Pressostato Pressostat h,n,p

* 091742 Ass. gruppo refrigerante Complete cooling unit d,e,f,
* 858774308 Ass. gruppo refrigerante Complete cooling unit h,n,p,

* 092028 Ass. gruppo refrigerante Complete cooling unit q,r,s

Pagina 5 Pannello di controllo Page 5 Control panel

101 087481 Scheda user Electronic board user

102 002670 Prolunga pulsante Button extension
103 0A9312 Morsettiera Clamp
104 099853 Cerniera cruscotto Hinge for panel
105 053342 Molla arresto marchio Spring for panel
106 087485 Microinterruttore Microswitch
107 082050 Boccola portalampade Bushing for light
108 082326 Portalampade Support light
109 081697 Schermo luce Light protection
110 081696 Lampada Light a,b,c,d,e,f,i,l,q,r,s
110 090199 Lampada Light g,h,m,n,o,p
111 048726 Filtro antidisturbo Filter
112 088523 Adesivo Electrolux (new) Sticker Electrolux (new) b,i
112 088525 Adesivo Electrolux (new) Sticker Electrolux (new) e,r
112 090200 Adesivo Electrolux (new) Sticker Electrolux (new) g ,m,o
112 090201 Adesivo Electrolux (new) Sticker Electrolux (new) h ,n,p
113 092023 Scheda main Elettronic board main

113 090202 Scheda main Elettronic board main g,m,o,p to be programmed
114 088990 Adesivo Zanussi (active) Sticker Zanussi (active) a,l
114 088992 Adesivo Zanussi (active) Sticker Zanussi (active) d,s
115 088557 Rele`(teleruttore) Relay d,e,f,q,r,s
115 085959 Rele` Relay h,n,p
116 090208 Adesivo alpeninox Sticker alpeninox c
116 090209 Adesivo alpeninox Sticker alpeninox f,q,f

change code from 099161 to 092023 for
add ptc on main board

programmed

to be

* COMPONET AVAILABLE UPPON REQUEST TO SPLC
* COMPONENTI DISPONIBILI A RICHIESTA PRESSO LO SPLC

ED. 1

PAGE :8

Up date 18 07 2008

Doc. Nr. : 501050
