Identification: |
D02-D04 |
Technical |
|
Bulletin no: |
CGX2006-26 (page 1 of 2), 2nd ed. |
Date: |
08 March 2007 |
Issuer: |
R. Sartor (DWS Customer Support) |
Factory: |
DW Vallenoncello - Italy |
Subject |
Water Leakage at the Rear Window of CWS machines |
|
Model |
Undercounter LS6EA / WT38 and Hood Type LS14EA / WT65E with |
|
|
Continuous Water Softener built-in. |
|
Problem |
Water leakage from the rear open window (air break). |
|
Reason |
Tank filling not properly set or boiler/tank filling not working properly. |
|
Action in |
Since serial number 61700001 we have introduced the firmware release |
|
Factory |
4.0260004 in main boards 0L0731 (not lead-free) and 0L1238 (lead-free) with |
|
|
following new features: |
|
|
• Disabled tank filling by boiler overflow whether SEr = 9 even if btF = 0. |
|
|
Therefore Undercounter/Hood Type with Continuous Water Softener built- |
|
|
in are always filled by short rinse cycles (btF = 75 as standard). |
|
|
• Disabled tank filling by boiler overflow if the water level decreases |
|
|
because of: |
|
|
1. |
level switch malfunctioning |
|
2. |
over-flow pipe not fitted properly |
|
3. |
drain cycle / self-cleaning cycle stop manually before the end |
|
4. |
opening door during drain cycle / self-cleaning cycle |
|
5. |
drain hose connected as for gravity drainage instead of having outlet |
|
|
between 750 mm and 1000 mm from the floor (see handbook). |
Therefore Undercounter/Hood Type with Continuous Water Softener builtin are always filled by short rinse cycles.
• Decreased inlet valve delay from 3 seconds to 2 seconds since reed sensor at the rear has open circuit (float level switch is in upper position).
This parameter cannot be changed by the user interface.
main board 0L1238
Firmware release |
|
|
Firmware release |
4.0260004 |
|
|
4.0260004 |
