Bakery and pastry making
Page 2
Superior
performance,
home-baked
goodness
Page 3
dito electrolux bakery
3
Bakeries
When variety is of utmost
importance. Satisfy even
the most demanding
customers by offering
specialty breads for all
occasions.
Pastry shops
Prepare even the most
delicate desserts and
make your customers
smile.
Give your customers a little
taste of home
Take-away &
Corner shops
When time is short but
home-baked goodness is
a must.
Pizzerias
The perfect choice for
original recipes: use soy,
wheat, and even corn flour
to offer your customers
mouth-watering pizzas.
Page 4
dito electrolux bakery4
Planetary mixers 5, 10 litres
Dito Electrolux offers a complete range of planetary mixers designed to
withstand the strong demands of bakery and pastry making.
BE5
Professional 5 litre planetary mixer for mixing, kneading
and emulsifying.
Powerful, reliable asynchronous motor with
frequency variator for a precise adjustment of the
planetary mechanism speed between 15 and 220 rpm
Aluminium column protects the motor and speed
variator against external agents
One-piece alloy head contains the planetary gears
and transmission for added safety
Equipped with 3 tools: whisk, paddle and spiral
kneading hook
Tools rotate at speeds from 31 to 462 rpm
•
•
•
•
•
Spiral hook Accessory hub
18/8 stainless steel bowl with handle, 5.2 litre
capacity
Transparent safety screen activates the raising and
lowering of the bowl and is removable to facilitate
cleaning
A metal base ensures perfect stability at all times
even when mixing stiff doughs and pastes
A model with accessory hub is available upon
request
For an even more complete machine, accessories
such as meat mincer and vegetable cutter are
available as an option. The wide choice of slicing discs
for the vegetable cutter allows you to prepare even the
most elaborate recipes
•
•
•
•
•
Page 5
dito electrolux bakery 5
XBE10
10 litre planetary mixer which satisfies the many requirements of
professional bakeries.
Knead all types of doughs and pastry, mix sauces and emulsify
creams
Electronic speed variation allows an accurate setting of all
parameters
Powerful motor with frequency variator permits a precise adjustment
of the planetary mechanism speed between 26 and 180 rpm
Splash proof planetary system ensures water does not enter the
mechanism
18/8 stainless steel bowl, 10 litre capacity
Supplied with 3 tools: stainless steel whisk, robust paddle and spiral
hook
Tools rotate at speeds from 55 to 378 rpm
•
•
•
•
•
•
•
Stainless steel column Touch button control panel
Transparent safety screen Kit (bowl, hook, paddle, whisk)
Stainless steel column protects the
motor and speed variator
Height adjustable feet ensure stability
User friendly touch button control
panel for improved ergonomics and
protection against humidity or jets
of water
Equipped with 0-59 minute timer for an
even more precise operation
The simple movement of the safety
screen raises and lowers the bowl and
at the same time stops the motor
•
•
•
•
•
The transparent safety screen can
be easily removed for an accurate
cleaning
Available with accessory hub on
request
Kneading capacity (hook): 3,5 kg of
flour (50% moisture content)
Whisking capacity: 16 eggs
Mixing capacity (paddle): 5 kg of
potatoes or meat
The model with mechanical speed
variation (XBM10) is equipped with
a 2 speed motor. Choose up to 8
different levels for each speed
•
•
•
•
•
•
Page 6
dito electrolux bakery
6
Planetary mixers 20, 30, 40 litres
XBB 20/30 litre planetary mixers with 3 fixed speeds
(40, 80 and 160 rpm) and electronic variable speed
with 10 levels ranging from 29 to 175 rpm.
Powerful and resistant 1500 W motor
Waterproof touch button control panel with 0-59 min.
timer
Stainless steel wire safety screen protects the operator
and permits ingredients to be added without
stopping the machine
Reinforced column and base for added support and
stability
Supplied with 18/8 stainless steel bowl and 3 tools
(whisk, paddle, spiral hook). Tools rotate at speeds
from 61 to 367 rpm
Splash proof planetary mechanism eliminates the risk
of water entering the system
Wheel kit (optional) for easier movement of mixer
when not in use
•
•
•
•
•
•
•
Wire safety screen Planetary mechanism
Removable wheel kitReduction kit with 3 tools
XBB20/30
A wide range of models which offer the best response to the heavy duty
preparations in pastry making.
Page 7
dito electrolux bakery
7
Removable spout Bowl scraper Bowl trolley
Lever for raising and lowering of
the bowl
Pivoting and removable rotating
safety guard provides protection
for the operator and facilitates
cleaning
A wide range of accessories such
as bowl heating, bowl scraper
and bowl trolley
20 litre bowl reduction kit with 3
tools available as an option
•
•
•
•
model capacity hook* paddle* whisk* notes
BE5 5 litres 2.5 2 16 electronic variator
XBE10 10 litres 5.5 5 30 electronic variator
XBB20 20 litres 11 10 55 electronic variator
XBB30 30 litres 15 15 80 electronic variator
MB40 40 litres 18 20 105 electro-mechanical
MBE40 40 litres 18 20 105 electronic variator
XBE60 60 litres 30 30 130 electronic variator
XBE80 80 litres 40 40 160 electronic variator
*Hook: kg of dough with 50% moisture content
*Paddle: kg of potatoes for puree
*Whisk: max. number of egg whites
Models also available with mechanical speed variation
MB/MBE40
MB/MBE 40 litre planetary mixers specially designed for
bakery and pastry works.
Powerful motor 2200 W with strengthened transmission
and heat treated gearing
MB40
with electromechanical 3 speed selection (40,
80 and 160 rpm), stop button and timer (0-15 min.)
MBE40
with 3 fixed speeds (40, 80 and 160 rpm) and
electronic variable speed with 10 levels ranging from
29 to 175 rpm, stop button and timer (0-59 min.)
Supplied with 18/8 stainless steel bowl and 3 tools
(whisk, paddle spiral hook)
Tools rotate at speeds from 84 to 336 rpm (MB40) and
from 63 to 361 rpm (MBE40)
Kneading: average speed of 40 rpm with hook; Mixing:
average speed of 80 rpm with paddle; Emulsifying:
average speed of 160 rpm with whisk
•
•
•
•
•
•
Page 8
dito electrolux bakery8
LMP 500 table top dough sheeter.
Thanks to its compact size it can be placed on a
table or fitted onto a mobile stand (optional)
The rolling direction can be inverted by the simple
movement of a joystick. Cylinders can be regulated
from 0,1 to 34 mm in thickness allowing all types of
doughs to be worked. Flour container fixed on top
Long lasting structure painted white with chromium
plated steel rollers (60 mm diameter). Slides have a
non-stick surface for easier dough movement and
can be disassembled to save space
All parts in contact with pastry dough are easily
accessible to facilitate cleaning. Removable upper
and lower roller scrapers
Safety microswitch avoids operator injury.
Emergency stop button with lock and manual re-start
ensures the rolling cylinders stop immediately
•
•
•
•
•
LMP500
Choose from a wide selection of dough sheeters perfect for rolling all types
of lining pastry, doughs and puff pastry work directly on the premises.
Dough sheeters
LMP400
LMP 400 manual hand dough sheeter.
Extremely versatile since it can be placed on a table
and moved easily around the kitchen
The slides can be disassembled to reduce the overall
size of the machine and save space
Steel cylinders (60 mm diameter) with non-stick
coating facilitate the sliding of the dough
The cylinders can be regulated from 0,1 to 34 mm in
thickness and have a working width of 400 mm
The inclined stainless steel flaps are removable for
easier cleaning
•
•
•
•
•
Page 9
dito electrolux bakery 9
LMP 500 BT (1 speed) table top belt
dough sheeter.
Versatility in the preparation of all
types of pastry with a working width
of 500 mm and two working belts of
1000 mm in length
Slides can be raised for optimum
space saving and cleaning
The flour container is fixed on the top
to continue dough preparation without
stopping the machine
The ergonomic controls are closely
situated to suit natural movements
•
•
•
•
Cutting module Foot pedal
LMP500BT
LMP600BF
LMP500BF
LMP 500 BF (1 speed or variable
speeds) mobile floor standing belt dough
sheeter.
Sturdy base for optimum support in a
white painted finish to last longer
Chromium plated steel cylinders (60
mm diam.) with a 500 mm working
width and 2 working belts 1000 mm
in length
Invert rolling direction by means of
a joystick
Emergency stop button with lock
and manual re-start ensure operator
safety
•
•
•
•
LMP 600 BF (2 speeds)
mobile floor standing belt
dough sheeter.
The chromium plated steel rollers (71,5 mm diam.)
have a working width of 600 mm and a belt length
of 1300 mm
Operator safety is guaranteed by a microswitch
which controls the gratings and stops the motor if they
exceed a certain level
Croissants made easy thanks to the optional cutting
module 130x140 mm
Easily invert the rolling
direction thanks to the
optional remote foot
pedal (excl. LMP400)
•
•
•
•
Page 10
dito electrolux bakery
10
BPO 25/40 litre fork kneaders ideal for preparing specialty breads,
pizza doughs and Viennese pastries.
2 speed motor for optimum kneading quality: slow speed (45 rpm)
for traditional kneading and 2nd speed (90 rpm) for fast kneading
User friendly touch button control panel incorporates a timer (0-59
min.) for precise control
Welded base for added support and stability of the kneading head
and removable aluminium bowl with progressive action brakes for
perfect regulation of rotation speed
Operator safety assured thanks to the particular head raising and
instantaneous locking system
Maximum hygiene thanks to the transparent screen which allows
products to be added during operation and avoids the emission of
flour into the work area
Safety guaranteed, the machine will not start if the bowl is not
correctly placed on the base
•
•
•
•
•
•
ZSP 12 to 49 litre
spiral kneaders have all of the characteristics to
create a perfect mixture every time.
Sturdy and reliable construction in painted steel
When screen is raised the motor automatically stops, guaranteeing
operator safety
High capacity stainless steel bowl with rounded bottom facilitates
cleaning
Extremely resistant stainless steel mixing arm
Optimum speed and reliability thanks to the carefully designed
power system
•
•
•
•
•
BPO
ZSP
Dough kneaders
An indispensable asset, Dito Electrolux dough kneaders are the best choice
for professional bakeries and pizzerias.
model capacity power speeds note
BPO25/45 25/40 lt 750 W 2 fork kneaders
ZSP10 12 lt 550 W 1
spiral kneaders
ZSP20 25 lt 750 W 1
ZSP25 32 lt 750 W 1
ZSP30 38 lt 1100 W 1
ZSP40 49 lt 1100 W 1
** 50/100 litre spiral kneaders available on request
Page 11
2 zones
Infrared cook tops are the ideal choice when having to
prepare creams, sauces or fillings.
Choose either lengthwise or crosswise
configuration based on the space available
Maintain sauces and creams silky smooth without
the risk of burning
The extremely flexible infrared cook top allows you
to safely use stainless steel, cooper, cast iron or mild
steel pans
Simple touch button control panel with a digital power
level display (from 1 to 9)
Two independent double spiral cooking zones for
maximum efficiency.
•
•
•
•
•
Single zone
Induction cook tops for a perfect work environment
during the delicate preparation of pastries.
Induction technology assures there is no heat
emission into the work area
The automatic pan detection transfers power only
when the pan is present
Easy to use touch button control panel with power
level display
Smooth round edges facilitate cleaning
Start cooking immediately thanks to the fast startup time of induction heating
Space savings with the single zone configuration
Heavy duty stainless steel construction with a glass
ceramic cooking surface
Completely sealed surface for durability and easier
cleaning
Operator safety is assured. Induction technology
keeps the surface cold
Save up to 60%
in energy costs compared to
standard cook tops
•
•
•
•
•
•
•
•
•
•
line
model cooking zones power dimensions (wxdxh) configuration
Infrared 2 2 x 1,8 kW 325x600x130 lengthwise/crosswise
Infrared 1 2,5 kW 325x400x130 single
Induction 2 2 x 1,8 kW 325x600x130 lengthwise/crosswise
Induction 1 3,2 kW 325x400x130 single
Page 12
dito electrolux bakery
12
The ideal machines for a professional chef. Chop, mince, grid, mix, puree
and blend any preparation your recipe requires.
K55
K Food processors available in 4.5, 5.5 and 7 litre
capacities to meet all your requirements.
Increased flexibility with your choice of 1, 2 or
variable speeds
A special pulse function for an even more precise
mixing
A unique scraper / emulsifier allows you to prepare
everything from grated nuts to smooth creams
The transparent lid permits you to check the
consistency during operation and eventually add
ingredients without having to open the lid
Ergonomic handle allows the bowl to be placed on
the base with ease and self-locking feature assures
maximum stability
The smooth or microtoothed blades allow you to
grind nuts or prepare the finest creams
•
•
•
•
•
•
The unique design of the bowl bottom guarantees
perfect results when mixing both large or small
quantities of food
Stainless steel cutter bowl guarantees hygiene and
food safety
Smooth design with rounded corners for improved
cleanability. The transparent lid can be easily
dismantled and all of its parts are dishwasher safe
•
•
•
model speeds power phases
K45 1, 2, variable 750/900/1000 W 1 or 3 ph
K55 2, variable 1000/1300 W 1 or 3 ph
K70 2, variable 1200/1500 W 1 or 3 ph
** other versions available upon request
Food processors
Page 13
dito electrolux bakery 13
Fruit & Vegetable slicers
Dito Electrolux fruit and vegetable slicers are the solution for slicing, dicing,
mincing, grating, shredding and much more.
TRS
TRS Fruit/Vegetable slicers, thanks to the vast
selection of cutting discs, offer outstanding cut quality
and superior performance.
Slice, dice, shred and julienne with a simple touch
of a button
Cleaning made easy: all parts can be dismantled
without tools and are dishwasher safe
Long lifetime thanks to the durable stainless steel
construction
Compact, powerful and with angled base (20°)
makes loading and unloading operations quick and
easy
Large hopper (215 cm2) guarantees a higher output
and allows fruits and vegetables of large size and
unusual shapes to be easily inserted
High discharge zone permits the use of deep GN
containers (up to 20 cm)
Pulse control for precise slicing
•
•
•
•
•
•
•
Save time and effort: powerful lever remains in
upright position so operator can freely use both hands
to feed items
A versatile machine that can be used for slicing,
dicing and shredding apples, kiwis, pears or other
fruits as well as chocolate and coconut
•
•
speed phases power rpm
1 speed 1 ph 370 W 360
1 ph 500 W 360
3 ph 500 W 360
2 speeds 3 ph 750 W 360-720
external dimensions (wxdxh) 252x500x502mm
Page 14
www.dito-electrolux.com
Share more of our thinking at www.electrolux.com
9JD BFU
The C omp any re ser ves t he right to chan ge sp ecifi cat ion s wit hou t n otice .
Loading...
