EW6F5549E4

EN User Manual | Washing Machine

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings
with it decades of professional experience and innovation. Ingenious and stylish, it has
been designed with you in mind. So whenever you use it, you can be safe in the
knowledge that you’ll get great results every time.
Welcome to Electrolux.

Visit our website to:

Get usage advice, brochures, trouble shooter, service and repair information:

www.electrolux.com/support

Register your product for better service:

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.

Warning / Caution-Safety information
General information and tips
Environmental information

Subject to change without notice.

CONTENTS

1. SAFETY INFORMATION................................................................................ 3

2. SAFETY INSTRUCTIONS.............................................................................. 5

3. PRODUCT DESCRIPTION............................................................................. 7

4. TECHNICAL DATA......................................................................................... 7

5. INSTALLATION...............................................................................................8

6. ACCESSORIES............................................................................................ 11

7. CONTROL PANEL........................................................................................ 12

8. DIAL AND BUTTONS....................................................................................14

9. PROGRAMMES............................................................................................ 16

10. SETTINGS.................................................................................................. 20

11. BEFORE FIRST USE..................................................................................21

12. DAILY USE..................................................................................................21

13. HINTS AND TIPS........................................................................................ 26

14. CARE AND CLEANING.............................................................................. 28

15. TROUBLESHOOTING................................................................................ 33

16. CONSUMPTION VALUES.......................................................................... 35

17. QUICK GUIDE............................................................................................ 37

18. ENVIRONMENTAL CONCERNS................................................................38

2 ENGLISH

1. SAFETY INFORMATION

Before beginning the installation and use of this
appliance, carefully read the supplied instructions.
The manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or usage.
Always keep the instructions in a safe and accessible location
for future reference.

1.1 Children and vulnerable people safety

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.

• Children between 3 and 8 years of age and persons with

very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.

• Children of less than 3 years of age should be kept away

from the appliance unless continuously supervised.

• Children should be supervised to ensure that they do not

play with the appliance.

• Keep all packaging away from children and dispose of it

appropriately.

• Keep detergents away from children.

• Keep children and pets away from the appliance when the

door is open.

• If the appliance has a child safety device, it should be

activated.

• Children shall not carry out cleaning and user maintenance

of the appliance without supervision.

ENGLISH 3

1.2 General Safety

• This appliance is for washing domestic-type, machine-

washable laundry only.

• This appliance is designed for single household domestic

use in an indoor environment.

• This appliance may be used in, offices, hotel guest rooms,

bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.

• Do not change the specification of this appliance.

• The appliance maximum load is 9 kg. Do not exceed the

maximum load of each programme (refer to the
“Programmes” chapter).

• The operating water pressure at the water entry point from

the outlet connection must be between 0.5 bar (0.05 MPa)
and 10 bar (1.0 MPa).

• The ventilation opening in the base must not be covered by

a carpet, mat, or any floor covering.

• The appliance must be connected to the water mains using

the new supplied hose sets, or other new hose sets
supplied by the Authorised Service Centre.

• Old hose sets must not be reused.

• If the mains power supply cable is damaged, it must be

replaced by the manufacturer, its Authorised Service Centre
or similarly qualified persons to avoid an electrical hazard.

• Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the socket.

• Do not use high pressure water sprays and/or steam to

clean the appliance.

• Clean the appliance with a moist cloth. Use only neutral

detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.

4 ENGLISH

2. SAFETY INSTRUCTIONS

2.1 Installation

The installation must comply with
relevant national regulations.

• Remove all the packaging and the transit

bolts including rubber bush with plastic
spacer.

• Keep the transit bolts in a safe place. If the

appliance is to be moved in the future they
must be reattached to lock the drum to
prevent an internal damage.

• Always take care when moving the

appliance as it is heavy. Always use safety
gloves and enclosed footwear.

• Follow the installation instructions supplied

with the appliance.

• Do not install or use a damaged

appliance.

• Do not install or use the appliance where

the temperature can be less than 0°C or
where it is exposed to the weather.

• The floor area on which the appliance is to

be installed must be flat, stable, heat
resistant and clean.

• Make sure that there is air circulation

between the appliance and the floor.

• When the appliance is in its permanent

position, check if it is levelled correctly
with the aid of a spirit level. If it is not,
adjust the feet accordingly.

• Do not install the appliance directly above

a floor drain.

• Do not spray water on the appliance and

do not expose it to excessive humidity.

• Do not install the appliance where the

appliance door cannot be fully opened.

• Do not put a closed container to collect

possible water leakage under the
appliance. Contact the Authorised Service
Centre to ensure which accessories can
be used.

2.2 Electrical connection

WARNING!

Risk of fire and electric shock.

• WARNING: This appliance is designed to
be installed / connected to a grounding
connection in the building.

• Always use a correctly installed
shockproof socket.

• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.

• Do not use multi-plug adapters and
extension cables.

• Make sure not to cause damage to the
mains plug and to the mains cable. Should
the mains cable need to be replaced, this
must be carried out by our Authorised
Service Centre.

• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.

• Do not touch the mains cable or the mains
plug with wet hands.

• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.

2.3 Water connection

• The inlet water shall not exceed 25 °C.

• Do not cause damage to the water hoses.

• Before connection to new pipes, pipes not
used for a long time, where repair work
has been carried out or new devices fitted
(water meters, etc.), let the water flow until
it is clean and clear.

• Ensure that there are no visible water
leaks during and after the first use of the
appliance.

• Do not use an extension hose if the inlet
hose is too short. Contact the Authorised
Service Centre for the replacement of the
inlet hose.

• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing of the
appliance with the use of water in the
factory.

• You can extend the drain hose to
maximum 400 cm. Contact the Authorised
Service Centre for the other drain hose
and the extension.

ENGLISH 5

• Make sure that there is access to the tap
after the installation.

2.4 Use

WARNING!

Risk of injury, electric shock, fire, burns
or damage to the appliance.

• Follow the safety instructions on the
detergent packaging.

• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.

• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber parts of
the washing machine. Prewash such
fabrics by hand before loading them into
the washing machine.

• Do not touch the glass door while a
programme operates. The glass can get
hot.

• Make sure that all metal objects are
removed from the laundry.

2.5 Service

• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.

• Please note that self-repair or non­professional repair can have safety
consequences and might void the
guarantee.

• The following spare parts will be available
for 10 years after the model has been
discontinued: motor and motor brushes,
transmission between motor and drum,
pumps, shock absorbers and springs,
washing drum, drum spider and related
ball bearings, heaters and heating

elements, including heat pumps, piping
and related equipment including hoses,
valves, filters and aquastops, printed
circuit boards, electronic displays,
pressure switches, thermostats and
sensors, software and firmware including
reset software, door, door hinge and
seals, other seals, door locking assembly,
plastic peripherals such as detergent
dispensers. Please note that some of
these spare parts are only available to
professional repairers, and that not all
spare parts are relevant for all models.

• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the mains
electrical and water supplies.

• Cut off the mains electrical cable close to
the appliance and dispose of it.

• Remove the door catch to prevent children
or pets from becoming trapped in the
drum.

• Dispose of the appliance in accordance
with local requirements for the disposal of
Waste Electrical and Electronic Equipment
(WEEE).

6 ENGLISH

3. PRODUCT DESCRIPTION

1 2 3

9

5

6

7

4

10

8

11 12

00000000

00A

Mod.

xxxxxxxxx

000V ~ 00Hz 0000 W

910000000

00

A
B
C

Prod.No.

D

3.1 Appliance overview

Worktop

1

Detergent dispenser

2

Control panel

3

Door handle

4

Rating plate

5

Drain pump filter

6

Feet for levelling the appliance

7

4. TECHNICAL DATA

Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /65.8 cm

Electrical connection Voltage

Drain hose

8

Inlet hose connection

9

Mains cable

10

Transit bolts

11

Hose support

12

The rating plate reports the model name (A) ,
product number (B), electrical ratings (C) and serial
number (D).

Overall power
Fuse
Frequency

230 V
2100 W
10 A
50 Hz

ENGLISH 7

Level of protection against ingress of solid particles and moisture ensured

1

2

by the protective cover, except where the low voltage equipment has no
protection against moisture

Water supply pressure Minimum

Water supply

Maximum Load Cotton 9 kg

Spin Speed Maximum spin speed 1351 rpm

1)

Connect the water inlet hose to a water tap with a 3/4'' thread.

1)

Maximum

IPX4

0.5 bar (0.05 MPa)
10 bar (1.0 MPa)

Cold water

5. INSTALLATION

WARNING!

Refer to Safety chapters.

5.1 Unpacking

1. Open the door. Remove all the items from

the drum.

Accessories delivered with the
appliance may vary depending on the
model.

2. Put the packaging element on the floor
behind the appliance and carefully put it
down onto its rear side. Remove the

polystyrene protection from the bottom.

CAUTION!

Do not lay washing machine on its
front.

3. Put the appliance back into an upright
position. Remove the power supply cable
and the drain hose from the hose holders.

8 ENGLISH

WARNING!

It is possible to see water flowing
from the drain hose. This is because
the washing machine has been
tested at the factory.

4. Remove the three transit bolts and pull

20º20º

45º45º

out the plastic spacers.

We recommend that you keep the
packaging and the transit bolts for
any transport of the appliance.

5. Put the plastic caps, that you find in the

user manual bag, in the holes.

5.2 Information for installation

Positioning and levelling

Adjust the appliance correctly to prevent
vibration, noise and movement of the
appliance when it operates.

1. Install the appliance on a flat hard floor.
The appliance must be levelled and stable.
Make sure that the appliance does not touch
the wall or other units and there is air
circulation below the appliance.

2. Loosen or tighten the feet to adjust the
level. All feet must rest firmly on the floor.

WARNING!

Do not put cardboard, wood or equivalent
materials below the appliance feet to
adjust the level.

The inlet hose

CAUTION!

Make sure there is no damage to hoses
and there are no leaks from the
couplings. Do not use an extension hose
if the inlet hose is too short. Contact the
service centre for a replacement inlet
hose.

1. Connect the water inlet hose to the back of

the appliance.

2. Position it toward left or right depending on

the positon of the water tap. Make sure that
the inlet hose is not in vertical position.

3. If necessary, loosen the ring nut to set it in

the correct position.

4. Connect the water inlet hose to the cold

water tap with 3/4'' thread.

WARNING!

The inlet water shall not exceed 25 °C.

Water drainage

ENGLISH 9

The drain hose should stay at a height of no
less than 60 cm and not more than 100 cm.

You can extend the drain hose to
maximum 400 cm. Contact the
authorised service centre for the other
drain hose and the extension.

It is possible to connect the drain hose in
different ways:

1. Make a U shape with the drain hose and
put it around the plastic hose guide.

2. On the edge of a sink - Fasten the guide to
the water tap or to the wall.

Make sure that the plastic guide cannot
move when the appliance drains and the
drain hose end is not immersed in the
water. There may be a return of dirty
water into the appliance.

3. If the end of the drain hose looks like this
(see the picture), you can push it directly into
the stand pipe.

4. To a stand pipe with vent hole - Insert the

drain hose directly into a drain pipe. Refer to
the illustration.

The end of the drain hose must always
be ventilated , i.e. the inner diameter of
the drain pipe (min. 38 mm - min. 1.5")
must be larger than the external diameter
of the drain hose.

5. Without the plastic hose guide, to a sink

spigot- Put the drain hose in the spigot and
tighten it with a clamp. Refer to the
illustration.

10 ENGLISH

Make sure that the drain hose makes a loop
to prevent particles going into the appliance
from the sink.

ø16

1

W011

2

Connect the drain hose to the spigot and
tighten it with a clamp. Make sure that the
drain hose makes a loop to prevent particles
going into the appliance from the sink.

6. Position the hose directly to a built-in drain
pipe in the room wall and tighten it with a
clamp.

5.3 Electrical connection

At the end of installation you can connect the
mains plug to the mains socket.

The rating plate on the inner edge of the
appliance door and the 'Technical Data'

chapter indicate the necessary electrical
ratings. Make sure that they are compatible
with the mains power supply.

Check that your domestic electrical
installation can take the maximum load
required, also taking into account any other
appliances in use.

Connect the appliance to an earthed
socket.

The power supply cable must be easily
accessible after installing the appliance.

For any electrical work required to install this
appliance, contact our Authorised Service
Centre.

The manufacturer does not accept any
responsibility for damage or injury through
failure to comply with the above safety
precaution.

6. ACCESSORIES

6.1 Available in www.electrolux.com/shop or from authorised dealer

Read carefully the instructions supplied with
the accessory.

Only appropriate accessories approved
by ELECTROLUX ensure the safety
standards of the appliance. If unapproved
parts are used, any claims will be
invalidated.

6.2 Fixing plate kit

If you install the appliance on a plinth that is
not an accessory supplied by ELECTROLUX,
secure the appliance in the fixing plates.

Read carefully the instructions supplied with
the accessory.

6.3 Stacking kit

The tumble dryer can be stacked on the top
of the washing machine only by using the

correct stacking kit.

ENGLISH 11

6.4 Pedestal with the drawer

WARNING!

Do not put the tumble dryer under the
washing machine. Verify the compatible
stacking kit by checking the depth of your
appliances.

7. CONTROL PANEL

7.1 Special features

Your new washing machine meets all modern
requirements for an effective treatment of
laundry with low water, energy and detergent
consumption and will care for fabrics.

• Thanks to the Soft Plus option, the fabric
softener is uniformly spread out in the
laundry and deeply penetrates the fabric
fibres favouring a perfect softness.

To raise your appliance and make loading
and unloading laundry easier. The drawer
can be used for laundry storage e.g.: towels,
cleaning products and more.

• The SensiCare System detects the
laundry load weight defining the
programme duration in 30 seconds. The
washing programme is tailored to the
laundry load and the type of fabric without
consuming more time, energy and water
than necessary. Read the paragraph "The
SensiCare load detection " for more
details.

12 ENGLISH

7.2 Control panel description

2

3 4 5

11 10 716

89

Programme dial

1

Display

2

Delay Start touch button

3

Time Manager touch button

4
5

Start/Pause touch button
Soft Plus touch button

6

Extra Rinse touch button

7

Prewash touch button

8

7.3 Display

Spin reduction options touch button

9

• No Spin option

• Rinse Hold option

• Night option
Temp. touch button

10

On/Off push button

11

ENGLISH 13

A B C D

E

FG

A Door locked indicator.

Outdoor

Puuvilla

Puuvilla

Koneen puhdistus

Silkki

Villa

Tyhjennys/Linkous

Huuhtelu

Pika 14 min.

Hienopesu

Synteettiset

Denim

UltraWash

Anti-Allergy

B Delay start indicator.

C The digital indicator can show:

• Programme duration (e. g. ).

• Delay time (e. g. ).

• Cycle end (

).

• Warning code (e.g. ).

D Time Manager bars level indicator.

E Drum clean indicator.

F Child safety lock indicator.

7.4 Multilingual badges

Adhesive badges in different languages are
supplied with the appliance.

The desired badge can be glued next to the
programme dial.

8. DIAL AND BUTTONS

8.1 Introduction

The options/functions are not available
with all washing programmes. Check the
compatibility between options/functions
and washing programmes in the
"Programme Chart". An option/function
can exclude another one, in this case the
appliance doesn't allow you to set
incompatible options/functions.

G Add garments indicator. Illuminates at

the beginning of the Wash phase,
while the user can still pause the
appliance and add more laundry.

8.2 On/Off

Press this button for a few seconds to
activate or deactivate the appliance. Two
different tunes sound while switching the
appliance on or off.

As the Stand-by function automatically
deactivates the appliance after several
minutes to reduce the energy consumption,
you may need to activate the appliance
again.

For more details, refer to Stand-by paragraph
in Daily Use chapter.

14 ENGLISH

8.3 Temp.

When you select a washing programme, the
appliance automatically proposes a default
temperature.

If you touch the Start/Pause button, the
appliance performs only the draining
phase.

The indicator Cold

The indicator of the set temperature comes
on.

= cold water.

8.4 Spin

When you set a programme, the appliance
automatically sets the maximum spin speed
allowed except programme Denim.

Additional spin options:

• No Spin
on.
Set this option to deactivate all spin
phases. The appliance performs only the
draining phase of the selected washing
programme. Set this option for very
delicate fabrics. The rinse phase uses
more water for some washing
programmes

• Rinse Hold . The related indicator
comes on.
The final spin is not performed. The water
of the last rinse is not drained out to
prevent the fabrics from creasing. The
washing programme ends with water in
the drum.
The door stays locked and the drum turns
regularly to reduce creasing. You must
drain the water to unlock the door.

If you touch the Start/Pause button, the
appliance performs the spinning phase
and drains the water.

• Night . The related indicator comes
on.
The intermediate and the final spinning
phases are suppressed and the
programme ends with water in the drum.
This helps to reduce creasing. The door
stays locked. The drum turns regularly to
reduce creasing. You must drain the water
to unlock the door.
As the programme is very quiet, it is
suitable for use at night time when
cheaper electricity tariffs are available. In
some programmes the rinses are
performed with more water.

. The related indicator comes

The appliance empties the water out
automatically after approximately 18
hours.

8.5 Prewash

With this option you can add a prewash
phase to a washing programme.

The relevant indicator illuminates.

• Use this option to add a pre-wash phase
at 30 °C before the washing phase.
This option is recommended for heavily
soiled laundry, especially if containing
sand, dust, mud and other solid particles.

These options can increase the
programme duration.

8.6 Permanent Extra Rinse

With this option you can add a few rinses
according to the selected washing
programme.

Use this option for people with allergies to
detergent residues and with sensitive skin.

This option increases the programme
duration.

The corresponding indicator above the touch
button illuminates and also stays permanently
on during next cycles until this option is
deactivated.

8.7 Permanent Soft Plus

Set this option to optimise the fabric softener
distribution and improve fabric softness.

Recommended when you use fabric softener.

This option increases the programme
duration.

ENGLISH 15

The corresponding indicator above the touch
button illuminates and also stays permanently
on during next cycles until this option is
deactivated.

8.8 Delay Start

With this option you can delay the start of a
programme to a more convenient time.

Touch the button repeatedly to set the
required delay. The time increases in steps of
1 hour up to 20 hours.

The display shows the indicator and the
selected delay time. After touching the Start/

Pause button, the appliance begins the
countdown and the door is locked.

8.9 Time Manager

With this option you can reduce the
programme duration depending on the load
size and the degree of soiling.

When you set a washing programme, the

display shows the default duration and
dashes.

Touch Time Manager button to reduce the
programme duration according to your needs.
The display shows the new programme
duration and a number of dashes will
decrease accordingly:

suitable for a full load of normally soiled

garments.

a quick cycle for a full load of lightly

soiled garments.

very quick cycle for a smaller lightly

soiled load (max. half load recommended).

the shortest cycle to freshen up a small

amount of laundry.

The Time Manager is available only with the
programmes in the table.

indicator

Eco 40-60

1)

1)

Default duration for all programmes.

■

■ ■ ■

■

■ ■ ■

■ ■ ■

Cottons

■ ■

■ ■

Synthetics

8.10 Start/Pause

Touch the Start/Pause button to start,
pause the appliance or interrupt a running
programme.

9. PROGRAMMES

9.1 Programme Chart

Programme
Default temper‐
ature
Temperature
range

Eco 40-60

1)

40 °C

16 ENGLISH

Reference
spin speed
Spin speed
range
[rpm ]

1400 rpm
(1400- 800)

Maxi‐
mum
load

9 kg White cotton and fast-coloured cotton. Normally soiled

items. The energy consumption decreases and the time of the
washing programme is extended, ensuring good washing re‐
sults.

Programme description

(Type of load and level of soiling)

Programme
Default temper‐
ature
Temperature
range

Cottons
40 °C
90 °C - Cold

Synthetics
40 °C
60 °C - Cold

Delicates
30 °C
40 °C - Cold

Rapid 14min
30 °C

Rinse 1400 rpm

Spin/Drain 1400 rpm

Anti-Allergy
60 °C

Duvet
40 °C
60 °C - Cold

Silk
30 °C

Wool

40 °C
40 °C - Cold

Sport
30 °C
40 °C - Cold

Reference
spin speed
Spin speed
range
[rpm ]

1400 rpm
(1400- 800)

1200 rpm
(1200 - 800)

1200 rpm
(1200- 800)

800 rpm
(800- 800)

(1400- 800)

(1400 -800)

1400 rpm
(1400 - 800)

800 rpm
(800 - 800)

800 rpm
(800 - 800)

1200 rpm
(1200- 800)

1200 rpm
(1200 - 800)

Maxi‐

(Type of load and level of soiling)
mum
load

9 kg White cotton and coloured cotton. Normal and heavy soil.

Programme description

4 kg Synthetic items or mixed fabric items. Normally soiled

2 kg Delicate fabrics such as acrylics, viscose and mixed fab‐

1,5 kg Synthetic and mixed fabric items. Lightly soiled items and

9 kg All fabrics, except woollens and very delicate fabrics.

9 kg All fabrics, except woollens and delicate fabrics. To spin

9 kg White cotton items. This high-performance wash program

3 kg Single synthetic blanket, padded clothes, duvets, down

3 kg Special programme for silk and mixed synthetic items.

1,5 kg Machine washable wool, hand washable wool and other

4 kg Mixed fabric sportswear. Lightly soiled items or items to re‐

items.

rics requiring gentler washing. Normally and lightly soiled
items.

items to freshen up.

Programme for rinsing and spinning the laundry. The default
spin speed is the one used for cotton programmes. Reduce
the spin speed accordingly to the type of laundry. If necessa‐
ry, set the Extra Rinse option to add rinses. With a low spin
speed, the appliance performs delicate rinses and a short
spin.

the laundry and to drain the water in the drum.

combined with steam vapour, removes more than 99,99% of

bacteria and viruses2) keeping the temperature above 60°C
throughout the washing phase; with an additional action on
the fibers thanks to a vapour phase, an enhanced rinsing
phase ensures a proper removal of detergent and micro-or‐
ganism residues. This program ensures also a proper reduc‐
tion of pollens/allergenic items.

jackets and similar items.

fabrics with «hand washing» care symbol3).

fresh.

ENGLISH 17

Programme
Default temper‐
ature
Temperature
range

Outdoor
30 °C
40 °C - Cold

Reference
spin speed
Spin speed
range
[rpm ]

1200 rpm
(1200- 800)

Maxi‐
mum
load

2,5 kg

1 kg

Programme description

(Type of load and level of soiling)

4)

5)

Do not use fabric softener and make sure that
there is no softener residue in the detergent
dispenser.

Synthetic sport items. This programme is designed to gently
wash modern outdoor sportswear and is also suitable for
gym, cycling or jogging clothes or similar. The recommended
laundry load is 2,5 kg.

Waterproof, waterproof-breathable and water repellent
fabrics. This programme can also be used as a water repel‐

lency restoring cycle, specifically tailored for treating clothes
with a hydrophobic coating. To perform the water repellency
restoring cycle, proceed as follows:

• Pour the washing detergent in the compartment .

• Pour a special water repellency restorer for fabric into the

softener compartment of the drawer .

• Reduce the laundry load to 1 kg.

To further improve the water repellency restor‐
ing action, dry the laundry in a tumble dryer by
setting the Outdoor drying programme (if avail‐
able and if the garment care label permits tum‐
ble drying).

Denim
30 °C
40 °C - Cold

1)

According to Commission Regulation EU 2019/2023, this programme at 40 °C is able to clean normally soiled

cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.

For the reached temperature in the laundry, the programme duration and other data, please refer to 'Con‐
sumption Values' chapter.
The most efficient programmes in terms of energy consumption are generally those that perform at lower tem‐
peratures and longer duration.

2)

Tested for Staphylococcus aureus, Enterococcus faecium, Candida albicans, Pseudomonas aeruginosa and

MS2 Bacteriophage in external test performed by Swissatest Testmaterialien AG in 2021 (Test Report No.

202120117).

3)

During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't rotate or

doesn't rotate properly, but this is normal for this programme.

4)

Washing programme.

5)

Washing programme and waterproofing phase.

800 rpm
(1200 - 800)

4 kg Special programme for Denim clothing with delicate

washing phase to minimize colour fading and marks. For
better care a reduced load size is recommended.

18 ENGLISH

Programme options compatibility

Spin

Prewash

Soft Plus

Extra Rinse

Delay Start

Programme

Eco 40-60 ■ ■ ■ ■ ■ ■ ■ ■

Cottons ■ ■ ■ ■ ■ ■ ■ ■ ■

Synthetics ■ ■ ■ ■ ■ ■ ■ ■ ■

Delicates ■ ■ ■ ■ ■ ■ ■

Rapid 14min ■ ■ ■

Rinse ■ ■ ■ ■ ■

Spin/Drain ■ ■ ■

Anti-Allergy

Duvet ■ ■ ■

Silk

Wool

Sport ■ ■ ■ ■ ■ ■

Outdoor

Denim ■ ■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■ ■

■ ■

■ ■ ■ ■

■ ■ ■ ■ ■

Suitable detergents for washing programmes

Programme Universal

powder

Eco 40-60 ▲ ▲ ▲ -- --

Cottons

Synthetics

Delicates

Rapid 14min

Anti-Allergy

Duvet

Silk

▲ ▲ ▲ -- --

▲ ▲ ▲ -- --

-- -- -- ▲ ▲

-- ▲ ▲ -- --

▲ ▲ -- -- ▲

-- -- -- ▲ ▲

-- -- -- ▲ ▲

1)

Liquid Uni‐

versal

Liquid for
coloureds

Delicates
woollens

Special

Time Manager

ENGLISH 19

Programme Universal

powder

Wool

Sport

Outdoor

Denim

1)

At temperature higher than 60 °C the use of powder detergent is recommended.

-- -- -- ▲ ▲

-- ▲ ▲ -- ▲

-- -- -- ▲ ▲

-- -- ▲ ▲ ▲

1)

Liquid Uni‐

versal

Liquid for
coloureds

Delicates
woollens

▲ = Recommended -- = Not recommended

9.2 Woolmark Wool Care - Blue

The wool wash cycle of this machine has been approved
by The Woolmark Company for the washing of wool gar‐
ments labelled as «hand wash» provided that the prod‐
ucts are washed according to the instructions on the gar‐
ment label and those issued by the manufacturer of this
washing machine. M1512
The Woolmark symbol is a Certification mark in many
countries.

10. SETTINGS

Special

10.1 Acoustic signals

This appliance has different acoustic signals,
that operate when:

• You activate the appliance (special short
tune).

• You deactivate the appliance (special
short tune).

• You touch the buttons (click sound).

• You make an invalid selection (3 short
sounds).

• The programme is completed (sequence
of sounds for about 1 minute).

• The appliance has a malfunction
(sequence of short sounds for about 5
minutes).

To deactivate/activate the acoustic signals
set a one of the programme, touch the Temp.
and the Spin buttons simultaneously for about
2 seconds. The display shows On/Off

20 ENGLISH

If you deactivate the acoustic signals,
they continue to operate when the
appliance has a malfunction.

10.2 Child Lock

With this option you can prevent children from
playing with the control panel.

To activate/deactivate this option, hold down

the Soft Plus button until comes on/goes
off on the display.

The appliance will default to this option after
you switch it off.

The Child Lock function may not be available
for a few seconds after switching the
appliance on.

10.3 Operating Hours Counter

It is possible to visualise the total operating
time of the appliance in hours, starting from
the first switching on. This value will count
operating time of the cycles (does not include
pauses, delayed start time). To visualise this
value, proceed as follows:

1. Switch the appliance on by pressing

On/Off button.

2. Turn the programme knob to the Eco

40-60 programme (1st position
clockwise).

3. Press and hold the Spin and Temp.

buttons for some seconds (within 10
seconds after the switching on. After
these 10 seconds, the key combination
activates and deactivates the acoustic
signals).

4. After 3 seconds the total hours operated

by the appliance are shown in the display:
e.g. 1276 hours, the display shows the
text Hr for 2 seconds, 12 (thousands and
hundreds) for 2 seconds and 76 (tens and
units).

If the procedure does not work (due to
timeout, wrong programme dial position
or wrong keys combination), switch the
appliance off and repeat sequence from
the beginning.

10.4 Factory Reset

This function allows to restore the factory
default options. To activate this option follow
steps below:

1. Switch the appliance on by pressing
On/Off button.

2. Turn the programme knob to the
Synthetics programme (3rd position
clockwise).

3. Press and hold the Spin and Temp.
buttons for some seconds (within 10
seconds after the switching on. After
these 10 seconds, the key combination
activates and deactivates the acoustic
signals).

4. The display will show for about 5
seconds.

If the procedure does not work (due to
timeout, wrong programme dial position
or wrong keys combination), switch the
appliance off and repeat sequence from
the beginning.

11. BEFORE FIRST USE

1. Make sure that the electrical power is

available and the water tap is open.

2. Pour a small quantity of detergent into the

compartment marked by .

3. Set and start a programme for cotton at
the highest temperature without any
laundry in the drum.

12. DAILY USE

WARNING!

Refer to Safety chapters.

This removes all possible dirt from the drum
and the tub.

12.1 Activating the appliance

1. Connect the mains plug to the mains

socket.

2. Open the water tap.

ENGLISH 21

3. Press the On/Off button for a few

1

2

seconds to activate the appliance.

A short tune sounds.

12.2 Loading the laundry

1. Open the appliance door.

2. Empty the pockets and unfold the items

before you put them in the appliance.

3. Put the laundry in the drum, one item at a
time.

Do not put too much laundry in the drum.

4. Close the door firmly.

CAUTION!

Make sure that no laundry gets caught
between the seal and the door to avoid
risk of water leakage and damage to the
laundry.

Compartment for prewash phase, soak
programme or stain remover.

Compartment for washing phase.

Compartment for liquid additives (fabric
conditioner, starch).

Maximum level for quantity of liquid addi‐
tives.

Flap for powder or liquid detergent.

Always follow the instructions that you
find on the packaging of the detergent
products, but we recommend that you do
not exceed the maximum indicated level

( ). This quantity will however
guarantee the best washing results.

After a washing cycle, if necessary,
remove any detergent residue from the
detergent dispenser.

12.4 Check the position of the detergent flap

1. Pull out the detergent dispenser until it

stops.

Washing heavily oiled, greasy stains
could cause damage to rubber parts of
the washing machine.

12.3 Filling the detergent and

additives

22 ENGLISH

2. Press the lever down to remove the

dispenser.

3. To use powder detergent, turn the flap
up.

4. To use liquid detergent, turn the flap
down.

With the flap in the position DOWN:

• Do not use gelatinous or thick liquid

detergents.

• Do not exceed to liquid detergent dose

indicated on the flap.

• Do not set the prewash phase.

• Do not set the delay start function.

5. Measure out the detergent and the fabric
conditioner.

6. Carefully close the detergent dispenser.

12.5 Setting a programme

1. Turn the programme dial to select the

desired washing programme.

The indicator of the Start/Pause button
flashes.
The display shows an indicative programme
duration.

2. To change the temperature and/or the
spin speed, touch the related buttons.

3. If desired, set one or more options by
touching the related buttons. The related
indicators illuminate on the display and
the given information changes
accordingly.

If a selection is not possible an acoustic
signal sounds and the display shows

.

12.6 Starting a programme

Touch the Start/Pause button to start the
programme. It is not possible to start the
programme when the indicator of the button
is off and doesn't flash (e.g. programme dial
on a wrong position).

The related indicator stops flashing and stays
on.
The programme starts, the door is locked.

The display shows the indicator

The drain pump can operate shortly
before the appliance fills water.

.

Make sure that the flap does not cause a
blockage when you close the drawer.

12.7 Starting a programme with the

delay start

1. Touch the Delay Start button repeatedly

until the display shows the desired delay
time. On the display the indicator shows

.

2. Touch the Start/Pause button. The
appliance door locks and starts the
countdown of the delay start. The display

shows the indicator .

When the countdown is completed, the
programme starts automatically.

ENGLISH 23

Cancelling the delay start after the countdown has started

To cancel the delay start:

1. Touch the Start/Pause button to
pause the appliance. The related
indicator flashes.

2. Touch the Delay Start button repeatedly

until the display shows and the

indicator

3. Touch the Start/Pause button again to
start the programme immediately.

goes off.

About 20 minutes after the programme
start, the programme duration could be
adjusted again depending on the
capacity of water absorption of the
fabrics.

The SensiCare detection is carried out
with complete washing programmes only
and if the programme duration has not
been reduced.

Changing the delay start after the countdown has started

To change the delay start:

1. Touch the Start/Pause
pause the appliance. The related
indicator flashes.

2. Touch the Delay Start button repeatedly
until the display shows the desired delay
time.

3. Touch the Start/Pause button again to
start the new countdown.

button to

12.8 The SensiCare System load

detection

The programme duration in the display is
referred to a medium/high load.

After touching the Start/Pause button, the
SensiCare System starts the laundry load
detection:

1. The appliance detects the load in the first
30 seconds. In the programmes where
Time Manager is available, during this

phase the Time Manager bars
placed below the time digits play a simple
animation. The drum rotates shortly.

2. The programme duration could be
adjusted accordingly and could increase
or decrease. After further 30 seconds, the
water filling starts.

The SensiCare System is not available
with all programmes such as :Wool,
Rinse, Spin and programmes with short
cycles.

12.9 Interrupting a programme and changing the options

When the programme is running, you can
change only some options:

1. Touch the Start/Pause button.

The related indicator flashes.

2. Change the options. The given
information in the display changes
accordingly.

3. Touch the Start/Pause button again.

The washing programme continues.

To start the programme again make sure
that the programme dial is correctly
positioned on the interrupted programme

and the indicator of the Start/Pause
button is flashing.

12.10 Cancelling a running

programme

1. Press the button On/Off to cancel the

programme and to deactivate the
appliance.

2. Press the button On/Off again to activate
the appliance.

24 ENGLISH

If the SensiCare System has completed
and the water filling has already started,
the new programme starts without
repeating the SensiCare System. The
water and the detergent are not drained
out in order to avoid waste. The display
shows the maximum duration of the
programme, updating it about 20 minutes
after the starting of the new programme.

There is also an alternative way of cancelling:

1. Rotate the selector knob to the "Reset"

position .

2. Wait for 1 second. The display shows

.

Now, you can set a new washing programme.

12.11 Opening the door - Adding garments

programme or the delay start continues.

12.12 End of the programme

When the programme has finished, the
appliance stops automatically. The acoustic
signals operate (if they are active). The

display shows

The indicator of the Start/Pause button
goes off.

If the temperature and level of the water
in the drum are too high and/or the drum
is still rotating you should not open the
door.

While a programme or the delay start
operates, the appliance door is locked. The

display shows the indicator .

1. Touch the Start/Pause button. The

indicator

2. Wait until the door lock indicator
stops flashing and goes off. Open the
appliance door. If necessary, add or
remove the items. Close the door and

touch the Start/Pause button. The

starts flashing.

The door unlocks and the indicator
off.

1. Press button On/Off to deactivate the
appliance.

After five minutes from the end of the
programme, the energy saving function
automatically deactivates the appliance.

When you activate the appliance again,
the display shows the end of the previous
programme. Turn the programme dial to
set a new cycle.

2. Remove the laundry from the appliance.

3. Make sure that the drum is empty.

4. Keep the door and the detergent

dispenser slightly ajar to prevent mildew
and odours.

goes

12.13 Draining water out after end

of cycle

If you have chosen a programme or an option
that does not empty out the water of the last
rinse, the programme is completed, but:

• The time area shows and the

display shows the door locked .

ENGLISH 25

• The drum still turns at regular intervals to
prevent creases in the laundry.

• The door stays locked.

• You must drain the water to open the
door:

1. If necessary, touch the Spin button to

decrease the spin speed proposed by the
appliance.

2. Press the Start/Pause button:

• If you have set Rinse Hold the
appliance drains the water and spins.

• If you have set Night the appliance
only drains the water

The option indicator Rinse Hold and Night

disappears.

3. When the programme is completed and

the door locked indicator
you can open the door.

4. Press the On/Off button for a few
seconds to deactivate the appliance.

goes off,

12.14 Stand-by option

The Stand-by function automatically
deactivates the appliance to reduce the
energy consumption when:

13. HINTS AND TIPS

• You do not use the appliance for 5
minutes when no programme is running.
Press the button On/Off to activate the
appliance again.

• 5 minutes after the end of the washing
programme.
Press the On/Off button to activate the
appliance again.
The display shows the end of the last
programme.
Turn the programme dial to set a new
cycle.

If the dial is rotated to the "Reset" position ,
the appliance automatically turns off in 30
seconds.

If you set a programme or an option that
ends with water in the drum, the Stand­by function doesn't deactivate the
appliance to remind you to drain the
water.

WARNING!

Refer to Safety chapters.

13.1 The laundry load

• Divide the laundry into: white, coloured,
synthetics, delicates and wool.

• Follow the washing instructions on the
laundry care labels.

• Do not wash white and coloured items
together.

• Some coloured items can discolour with
the first wash. We recommend that you
wash them separately for the first couple
of times.

• Turn multilayered fabrics, wool and items
with printed illustrations inside out.

• Pre-treat stubborn stains.

• Wash stubborn stains with a special
detergent.

26 ENGLISH

• Be careful with curtains. Remove the
hooks and put the curtains in a washing
bag or pillowcase.

• A very small load can cause balance
problems with the spin phase leading to
excessive vibration. If this occurs:

a. interrupt the programme and open the

door (refer to "Daily Use" chapter);

b. manually redistribute the load so that

the items are spaced evenly around
the tub;

c. press the Start/Pause button. The

spin phase continues.

• Button up pillowcases, close zippers,
hooks and poppers. Tie up belts, cords,
shoelaces, ribbons and any other loose
elements.

• Do not wash laundry without hems or with
cuts. Use a washing bag to wash small
and/or delicate items (e.g. underwired
bras, belts, tights, shoelaces, ribbons,
etc. ).

• Empty pockets and unfold the items.

13.2 Stubborn stains

For some stains, water and detergent is not
sufficient.

We recommend that you pre-treat these
stains before you put the items in the
appliance.

Special stain removers are available. Use the
special stain remover that is applicable to the
type of stain and fabric.

13.3 Detergent type and quantity

The choice of detergent and use of correct
quantities not only affects your wash
performance, but also helps to avoid waste
and protect the environment:

• Use only detergents and other treatments
specially made for washing machines.
First, follow these generic rules:

– powder detergents for all types of

fabric, excluding delicate. Prefer
powder detergents containing bleach
for whites and laundry sanitization,

– liquid detergents, preferably for low

temperature wash programmes (60 °C
max) for all types of fabric, or special
ones for woollens only.

• The choice and quantity of detergent will
depend on: type of fabric (delicates,
woollens, cottons, etc), the colour of
clothes, size of the load, degree of soiling,

wash temperature and hardness of the
water used.

• Follow the instructions that you find on
packaging of the detergents or other
treatments without exceeding the

indicated maximum level ( ).

• Do not mix different types of detergents.

• Use less detergent if:

– you are washing a small load,
– the laundry is lightly soiled,
– there is large amounts of foam during

washing.

• When using detergent tabs or pods,
always put them inside the drum, not in
the detergent dispenser.

Insufficient detergent may cause:

• unsatisfactory washing results,

• the wash load to turn grey,

• greasy clothes,

• mould in the appliance.

Excessive detergent may cause:

• sudsing,

• reduced washing effect,

• inadequate rinsing,

• a greater impact for the environment.

13.4 Ecological hints

To save water, energy and to help protect the
environment, we recommend that you follow
these tips:

• Normally soiled laundry may be washed
without prewash in order to save
detergent, water and time (the
environment is protected too!).

• Loading the appliance to the maximum

capacity indicated for each
programmes helps to reduce energy
and water consumption.

• With adequate pre-treatment, stains and
limited soiling can be removed; the
laundry can then be washed at a lower
temperature.

• To use the correct quantity of detergent,
refer to the quantity suggested by the
detergent producer and check the water
hardness of you domestic system. Refer
to 'Water hardness'.

• Set the maximum possible spin speed
for the selected washing programme

before drying your laundry in a tumble
dryer. This will save energy during drying!

ENGLISH 27

13.5 Water hardness

If the water in your area is hard or medium
hard, we recommend that you use a water
softener for washing machines.

The water is hard or medium hard when the
hardness exceeds 8dH.

In areas where the water is soft it is not
necessary to use a water softener.

14. CARE AND CLEANING

To find out the water hardness in your area,
contact your local water authority.

Use the correct quantity of water softener.
Follow the instructions that you find on the
packaging of the product.

WARNING!

Refer to Safety chapters.

14.1 Periodic cleaning schedule

Periodic cleaning helps to extend the life
of your appliance.

After each cycle, keep the door and the
detergent dispenser slightly ajar to get air
circulation and dry the humidity inside the
appliance: this will prevent mildew and
odours.

If the appliance is not used for a long time:
close the water tap and unplug the appliance.

Indicative periodic cleaning schedule:

Descaling Twice a year

Maintenance wash Once a month

Clean door seal Every two months

Clean drum Every two months

Clean detergent dispens‐erEvery two months

Clean drain pump filter Twice a year

Clean the inlet hose and
the valve filter

The following paragraphs explain how you
should clean each part.

Twice a year

14.2 Removing foreign objects

Make sure that pockets are empty and all
loose elements are tied up before
running your cycle. Refer to "The laundry
load" in "Hints and tips".

Remove any foreign objects (such as metal
clip, buttons, coins, etc) that you may find in
the door seal, the filters and the drum. Refer
to "Door seal with double lip trap", "Cleaning
the drum", "Cleaning the drain pump" and
"Cleaning the inlet hose and the valve filter"
paragraphs. If necessary, please contact the
Authorised Service Centre.

14.3 External cleaning

Clean the appliance with mild soap and warm
water only. Fully dry all the surfaces. Do not
use a scouring pads or any scratching
material.

CAUTION!

Do not use alcohol, solvents or chemical
products.

CAUTION!

Do not clean the metal surfaces with
chlorine-based detergent.

28 ENGLISH

14.4 Descaling

If the water in your area is hard or
medium hard, we recommend that you
use a water softener for washing
machines.
The water is hard or medium hard when
the hardness exceeds 8dH.

Regularly examine the drum to check for
limescale.

Regular detergents already contain water
softening agents, but we recommend to run a
cycle with an empty drum and a descaling
product.

Clean it when needed, using ammonia cream
cleanser agent without scratching the seal
surface.

Always obey the instructions that you find
on the packaging of the product.

Always follow the instructions that you
find on the packaging of the product.

14.5 Maintenance wash

The repeated and prolonged use of low
temperature programmes can cause
detergent deposits, fluff residues, bacterial
growth inside the drum and the tub. This
could generate bad odours and mildew. To
eliminate these deposits and clean the inner
part of the appliance, run a maintenance
wash regularly (at least once a month).

Refer to "Cleaning the drum" paragraph.

14.6 Door seal with double lip trap

This appliance is designed with a self
cleaning draining system, allowing light fluff

fibers that fall off the clothes to be drained out
with the water. Regularly examine the seal.
Coins, buttons, other small items can be
recovered at the end of the cycle.

14.7 Cleaning the drum

Regularly examine the drum to prevent
unwanted deposits.

Rust deposits in the drum may occur due to
rusting foreign body in the washing or tap
water containing iron

Clean the drum with special products for
stainless steel.

Always follow the instructions that you
find on the packaging of the product.
Do not clean the drum with acidic
descaling products, scouring products
containing chlorine or iron or steel wool.

For a thorough clean:

1. Remove all laundry from the drum.

2. Run a Cottons programme with the

highest temperature.

3. Add a small quantity of powder detergent

into the empty drum, in order to rinse out
any left residues.

Occasionally, at the end of a cycle the

display may show the icon : this is a
recommendation to perform the “drum
cleaning”. Once the drum cleaning has
been performed, the icon disappears.

ENGLISH 29

14.8 Cleaning the detergent

1

2

dispenser

To prevent possible deposits of dried
detergent or clotted fabric softener and/or
formation of mould in the detergent dispenser
drawer, once in a while carry out the following
cleaning procedure:

1. Open the drawer. Press the catch
downwards as indicated in the picture
and pull it out.

2. Remove the top part of the additive
compartment to aid cleaning and flush it
out under running warm water, to remove
any traces of accumulated detergent.
After cleaning, put the top part back into
position.

3. Make sure that all detergent residue is
removed from the upper and lower part of
the recess. Use a small brush to clean
the recess.

4. Insert the detergent drawer into the guide
rails and close it. Run the rinsing
programme without any clothes in the
drum.

14.9 Cleaning the drain pump

Regularly check the drain pump filter and make sure that it is clean.

Clean the drain pump if:

• The appliance does not drain the water.

• The drum does not turn.

• The appliance makes an unusual noise because of the blockage of the drain pump.

• The display shows the alarm code

30 ENGLISH

WARNING!

1

2

180˚

2

1

• Disconnect the mains plug from the mains socket.

• Do not remove the filter while the appliance operates.

• Do not clean the pump if the water in the appliance is hot. Wait until the water cools
down .

• Repeat Step 3 several times by closing and opening the valve until the water stops
flowing out.

Always keep a rag nearby to dry up any water spillages when removing the filter.

Proceed as follows to clean the pump:

1.

3.

5. 6.

2.

4.

ENGLISH 31

7.

2

1

2

1

1

3

1

2

45°

20°

WARNING!

Make sure that the impeller of the pump can rotate. If it does not rotate, contact the
Authorised Service Centre. Make sure also that you tighten the filter correctly to prevent
leakages.

8.

14.10 Cleaning the inlet hose and the valve filter

14.11 Emergency drain

If the appliance cannot drain the water, carry
out the same procedure, described in
'Cleaning the drain pump' paragraph. If
necessary, clean the pump.

32 ENGLISH

14.12 Frost precautions

If the appliance is installed in an area where
the temperature can reach values around 0°
C or drop below, remove the remaining water
from the inlet hose and the drain pump.

1. Disconnect the mains plug from the
mains socket.

2. Close the water tap.

3. Put the two ends of the inlet hose in a

container and let the water flow out of the
hose.

4. Empty the drain pump. Refer to the

WARNING!

Make sure that the temperature is higher
than 0 °C before you use the appliance
again.
The manufacturer is not responsible for
damages caused by low temperatures.

emergency drain procedure.

5. When the drain pump is empty, install the
inlet hose again.

15. TROUBLESHOOTING

WARNING!

Refer to Safety chapters.

15.1 Alarm Codes and Possible failures

The appliance does not start or it stops during operation. First try to find a solution to the problem
(refer to the tables).

WARNING!

Deactivate the appliance before carrying out any check.

With some problems, the display shows an alarm code and the Start/

Pause button may flash continuously:

Problem Possible solution

• Make sure that the water tap is open.

The appliance does not fill
with water properly.

The appliance does not
drain the water.

The appliance door is open
or not closed correctly.

• Make sure that the pressure of the water supply is not too low. For this infor‐
mation, contact your local water authority.

• Make sure that the water tap is not clogged.

• Make sure that the inlet hose has no kinks, damages or bends.

• Make sure that the connection of the water inlet hose is correct.

• Make sure that the filter of the inlet hose and the filter of the valve are not clog‐
ged. Refer to 'Care and cleaning'.

• Make sure that the sink spigot is not clogged.

• Make sure that the drain hose has no kinks or bends.

• Make sure that the drain filter is not clogged. Clean the filter, if necessary. Re‐
fer to "Care and cleaning".

• Make sure that the connection of the drain hose is correct.

• Set the drain programme if you set a programme without drain phase.

• Set the drain programme if you set an option which ends with water in the tub.

• Make sure that the door is properly closed.

ENGLISH 33

• The programme was not finished properly or the appliance stopped too early.

Internal fail. No communica‐
tion between electronic ele‐
ments of the appliance.

The mains supply is unsta‐
ble.

Switch the appliance off and on again.

• If the alarm code appears again, contact the Authorised Service Centre.

• Wait until mains supply is stable.

If the display shows other alarm codes, deactivate and activate the
appliance. If the problem continues, contact the Authorised Service Centre.
In case of different problem with the washing machine check the table
below for possible solutions.

Problem Possible solution

• Make sure that the mains plug is connected to the mains socket.

• Make sure that the appliance door is closed.

The programme does not

start.

The appliance fills with water
and drains immediately.

The spin phase does not op‐
erate or the washing cycle
lasts longer than usual.

There is water on the floor.

You cannot open the appli‐
ance door.

The appliance makes an un‐
usual noise and vibrates.

• Make sure that there is no damaged fuse in the fuse box.

• Make sure that the Start/Pause has been touched.

• If the delay start is set, cancel the setting or wait for the end of countdown.

• Deactivate the Child Lock function if it is on.

• Check the position of the knob on the selected programme.

• Make sure that the drain hose is in the correct position. The hose may be posi‐
tioned too low. Refer to "Installation instruction".

• Set the spin programme.

• Make sure that the drain filter is not clogged. Clean the filter, if necessary. Re‐
fer to "Care and cleaning".

• Adjust manually the items in the tub and start the spin phase again. This prob‐
lem may be caused by balance problems.

• Make sure that the couplings of the water hoses are tight and there is not wa‐
ter leakages.

• Make sure that the water inlet hose and the drain hose have no damages.

• Make sure you use the correct detergent and the correct quantity of it.

• Make sure that a washing programme that ends with water in tub, has not
been selected.

• Make sure that the washing programme is finished.

• Set the drain or the spin programme if there is water in the drum.

• Make sure that the appliance receives electrical power.

• This problem may be caused by a failure of the appliance. Contact the Author‐
ised Service Centre.

• Make sure the levelling of the appliance is correct. Refer to "Installation in‐
struction".

• Make sure that the packaging and/or the transit bolts are removed. Refer to
"Installation instruction".

• Add more laundry in the drum. The load may be too small.

34 ENGLISH

Problem Possible solution

The programme duration in‐
creases or decreases during
programme execution.

The washing results are not
satisfactory.

Too much foam in the drum
during the washing cycle.

After the washing cycle,
there are some detergent
residues in the dispenser
drawer.

• The SensiCare System is able to adjust the programme duration according to
the type and the laundry load size. Refer to "The SensiCare System load de‐
tection" in "Daily Use" chapter.

• Increase the detergent quantity or use a different detergent.

• Use special products to remove the stubborn stains before you wash the laun‐
dry.

• Make sure that you set the correct temperature.

• Decrease the laundry load.

• Reduce the quantity of detergent.

• Make sure that the flap is in the correct position (UP for powder detergent ­DOWN for liquid detergent).

• Make sure you have used the detergent dispenser according the indications
given in this user manual.

After the check, activate the appliance. The programme continues from the
point of interruption.
If the problem occurs again, contact the Authorised Service Centre.
The necessary data for the service centre are on the rating plate.

16. CONSUMPTION VALUES

16.1 Introduction

See the web link www.theenergylabel.eu for detailed information about Energy Label.

The QR code on the energy label supplied with the appliance provides a web link to the
information related to the performance of the appliance in the EU EPREL database. Keep
the energy label for reference together with the user manual and all other documents
provided with this appliance.
It is also possible to find the same information in EPREL using the link https://
eprel.ec.europa.eu and the model name and product number that you find on the rating
plate of the appliance. Refer to 'Product description' chapter for the position of the rating
plate.

16.2 Legend

kg Laundry load. hh:mm Programme duration.

kWh Energy consumption. °C Temperature in the laundry.

ENGLISH 35

Litres Water consumption. rpm Spin speed.

% Remaining moisture at the end of spinning phase. The higher is the spin speed, the higher is the

noise and the lower is the remaining moisture.

Values and programme duration may differ depending on different conditions (e.g. room
temperature, water temperature and pressure, load size and type of laundry, supply
voltage) and also if you change the default setting of a programme.

16.3 According to Commission Regulation Eu 2019/2023

Eco 40-60 pro‐
gramme

Full load 9 0.760 64.0 3:40 53.00 33 1351

Half load 4,5 0.440 47.0 2:45 53.00 27 1351

Quarter load 2,5 0.300 39.0 2:35 54.00 26 1351

1)

Maximum spin speed.

kg kWh Litres hh:mm % °C

rpm

Power consumption in different modes

Off (W) Stand-by (W) Delay start (W)

0.50 0.50 4.00

Time to Off/Standby mode is 15 minutes maximum.

16.4 Common programmes

These values are indicative only.

Programme

2)

Cottons
90°C

Cottons
60°C

3)

Cottons
20°C

Synthetics
40°C

kg kWh Litres hh:mm % °C

9 2.75 85.0 4:00 52.00 85 1400

9 1.65 80.0 3:30 52.00 55 1400

9 0.35 80.0 3:00 52.00 20 1400

4 0.85 75.0 2:30 35.00 40 1200

rpm

1)

1)

36 ENGLISH

Programme

1

2

1

2

3

1 32

180˚

2

1

Delicates
30°C

Wool
30°C

1)

2)

3)

4)

4)

Reference indicator of the spin speed.

Suitable for washing heavily soiled textiles.

Suitable for washing lightly soiled cottons, synthetic and mixed fabrics.

It also performs as quick washing cycle for lightly soiled laundry.

kg kWh Litres hh:mm % °C

2 0.35 60.0 1:25 35.00 30 1200

1,5 0.30 70.0 1:05 30.00 30 1200

17. QUICK GUIDE

17.1 Daily use

rpm

1)

Connect the mains plug to the mains socket.

Open the water tap.

Load the laundry.

Pour the detergent and other treatment in the
proper compartment of the detergent
dispenser.

1. Push the On/Off button to turn the
appliance on. Turn the programme dial to
set the desired programme.

17.2 Cleaning the drain pump filter

2. Set the desired options (1) by means of

the corresponding touch buttons. To start
the programme, touch the Start/Pause

(2) button.

3. The appliance starts.
At the end of the programme, remove the
laundry.

Push the On/Off button to turn the
appliance off.

ENGLISH 37

Clean the filter regularly and, especially, if the

alarm code appears on the display.

17.3 Programmes

Programmes Load Product description

Eco 40-60 9 kg White and coloured cottons. Normally soiled garments.

Cottons 9 kg White cotton and coloured cotton.

Synthetics 4 kg Synthetic items or mixed fabric items.

Delicates 2 kg Delicate fabrics such as acrylics, viscose, polyester items.

Rapid 14min 1,5 kg Cotton and synthetic lightly soiled items or once worn items.

Rinse 9 kg

Spin/Drain 9 kg

Anti-Allergy

Duvet 3 kg

9 kg

All fabrics, except woollens and very delicate fabrics. Pro‐
gramme for rinsing and spinning.

All fabrics, except woollens and very delicate fabrics. Pro‐
gramme for spinning and draining the water.

White cotton items. This program removes more than 99,99%

of bacteria and viruses1). It also ensure a proper reduction of
allergens.

Synthetic or feather and down filled blankets, padded clothes,
duvets.

Silk

Wool

Sport 4 kg Sportswear.

Outdoor

Denim 4 kg Denim clothing.

1)

Tested for Staphylococcus aureus, Enterococcus faecium, Candida albicans, Pseudomonas aeruginosa and

MS2 Bacteriophage in external test performed by Swissatest Testmaterialien AG in 2021 (Test Report No.

202120117).

2)

Washing programme.

3)

Washing programme and waterproofing phase.

3 kg Special programme for silk and mixed synthetic items.

1,5 kg Machine washable wool, hand washable wool and delicates.

2)

2,5 kg

1 kg

Modern outdoor sporting garments.

3)

18. ENVIRONMENTAL CONCERNS

Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of

38 ENGLISH

appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.

*

135966430-A-142023
